Apacer AS330 User Manual

SATA SSD

Applications

 PC/NB for general

storage

 Operating system

boot drive for PC/NB

 Network servers
 Industrial PCs
 Graphic and video

applications

 Kiosk, POS and

automation.

 Multimedia
 Gaming

AS330

Apacer AS330

Reliable Solution for Computer System

Optimization

Apacer AS330 is a solid state drive (SSD) in standard 2.5” SATA
form factor. Designed in SATA 6 Gb/s interface, the drive can
deliver outstanding performance up to 520 MB/s data transfer
speed, highly suitable to serve as operating system boot drive or
storage media of important data. The mechanical design of
AS330 conforms to the latest requirements of SATA 6.0 Gbps
interface. Hence, power efficiency wise, AS330 supports SATA
power management modes which greatly cut power
consumptions to make it an environmental and economical
storage drive than traditional hard disk drives.

In terms of reliability, AS330 supports wear leveling, S.M.A.R.T.,
NCQ command, and ECC engine correcting up to 72bit per 1KB
data. With the advantages of performance and reliability
mentioned above, AS330 is proved to be the best companion for
PC and laptop upgrade.

Features:

 SATA 6.0 Gb/s interface compliance
 Outstanding read/write performance
 Supports SATA Power Management

 Powerful ECC engine correcting up

to 72bit/1KB

 Supports S.M.A.R.T. commands
 Supports TRIM commands

© 2015 Apacer Technology Inc. Rev. 1.0

Specifications

Interface

SATA 6.0 Gb/s interface

SATA 6.0 Gbps Burst Speed

600 MB/s

Capacity1

120 GB, 240 GB, 480 GB, 960 GB

Performance

2

(Unit: MB/s)

Capacity

Read

Write

120 GB

495

385

240 GB

515

475

480 GB

520

480

960 GB

520

485

Form Factor

2.5 inch

NAND Flash Media

TLC

ECC

Up to 72bit/1KB

MTBF

1,000,000 hours (approx.)

Operating Voltage

5V ± 5%

Power consumption3
(Unit: mA)

Active

1,200

Idle

150

Dimension

100.10mm(L) x 69.85mm(W) x 7.00mm(H)

Reliability Features

S.M.A.R.T, TRIM, Wear-leveling

Temperature
Operating

0°C to 70°C

Storage

-40°C to 85°C

Humidity

RH 90% under 40°C

Shock4

500G/2ms

Vibration4

80 – 2000Hz/20G

Acoustic

0dB

Warranty

3 years

Package Content

Retail package

Certifications

RoHS, CE, FCC

Global Offices

Taiwan (HQ)

Apacer Technology Inc.

1F., No.32, Zhongcheng Rd.,
Tucheng Dist., New Taipei City
Taiwan, R.O.C
Tel: [phone]
Fax: [phone]

[e-mail]

U.S.A

Apacer Memory America, Inc.

46732 Lakeview Blvd., Fremont,
CA 94538
Tel: [phone]
Fax: [phone]

[e-mail]

Japan

Apacer Technology Corp.

5F, Matsura Bldg., Shiba, Minato-Ku
Tokyo, 105-0014, Japan
Tel: [phone]
Fax: [phone]

[e-mail]

Europe

Apacer Technology B.V.

Science Park Eindhoven 5051 5692
EB Son,
The Netherlands
Tel: [phone]
Fax: [phone]#6199

[e-mail]

China

Apacer Electronic (Shanghai)
Co., Ltd

Room D, 22/FL, No.2, Lane 600,
Jieyun Plaza, Tianshan RD,
Shanghai, 200051, China
Tel: [phone]
Fax: [phone]

[e-mail]

India

Apacer Technologies Pvt Ltd

Unit No.201, Brigade Corner,
7th Block Jayanagar,Yediyur Circle,
Bangalore – 560082, India
Tel: [phone]
Fax: [phone]

[e-mail]

General Product Specifications

SATA SSD

AS330

1

Unformatted. Theoretically, 1GB=1,000,000,000 Bytes. Under operating systems, the capacity might appear to be

less than the theoretical capacity because the calculation in OS is based on 1 GB = 1024 MB / 1MB =1024KB and a
minority of the capacity is reserved for maintenance purposes.

2

Performance results may vary from flash configurations or host system settings. Test results are based on ATTO

platform.

3

Power consumption was measured at 5.0V and for 960 GB capacity only. The results may vary from flash

configurations or host system settings.

4

Shock and vibrations are subject to change without notice.
