FALCON®
1
BEAM
2
Indoor/outdoor xenon searchlight
Increased brightness
Reduced size & weight
Fast zoom eect
Colour changer
Integrated electronic power
supply
Exceptionally sturdy and cost
eective
Providing ease of installation and
long-term performance integrity
The FALCON® BEAM 2 is the first
choice for demanding illumina-
tions in the fields of entertain-
ment and architectural lighting.
With reduced power consumption,
swift zoom progressions and the
increased speed of its pan and tilt
movements the FALCON® BEAM 2
offers another plus: the compact
searchlight takes up very little
space for a device of such lumi-
nosity. The low maintenance costs
and highly efficient optics make
the FALCON® BEAM 2 a must for
every lighting design.
Tilt movement
234 °
Pan movem ent 500 °
7,000 W
BEAM 2 - Entertainment Lighting
®
DATASHEET - FALCON
Dimensions
h: 1,396 mm I 54.96 inch
w: 791 mm I 31.1 inch
d: 686 mm I 27 inch
1012 mm I 39.8 inch
d
514 m m I 20.2 inch
403 mm I
15.9 inch
w
378 mm I
14.9 inch
403 I 15.9
714 mm I 28.1 inch
h
762 mm I 30 inch
1110 mm I 43.7 inch
695 mm I 27.4 inch
117°
Pivoting
angle: 234 °
Page 2
Technical
specifications
2
Lamp
Type Xstage® 7,000 W
Colour temperature 6,000 K
Colour changer system
Colour changer Gel scroller with up to 13 single colours
Reflector
Material Nickel with high precision electro-shaped dichroic coating
Diameter 406 mm / 16 inch
Function
Main functions Lamp on / off, hot strike, electronic / mechanical dimmer, electronic strobe, mechanical strobe, zoom,
Movement Pan = 500 °, tilt = 234 °
Control
Standard DMX protocol DMX 512 in / out
DMX channels 13
Power
System
Input power
(other input voltages
on request)
Max. tolerances + 5 % / - 5 %
Power consumption 7,500 W, cos φ > 0.98
Temperature
Operating temperature - 15 °C up to + 42 °C, non-condensed; 5 °F up to 107.6 °F, non-condensed
Housing
Material Non-corrosive aluminium / stainless steel
Colour Standard colour: black, matt, RAL 9005; other RAL-tones possible
Protection
Protection rating IP 54
Specifications (touring)
Dimensions h x w x d 1,396 x 791 x 686 mm; 54.96 x 31.1 x 27 inch
Weight (standard,
without clamps and
safety chain)
FALCON® BEAM 2
7,000 W
pan / tilt movement 16 bit, reset, colour changer
Built-in electronic power supply
400 VAC 50-60 Hz, balanced, 3-phase
182 kg (401 lb)
BEAM 2 - Entertainment Lighting
®
DATASHEET - FALCON
AO Multimedia & Drones
[email protected] www.ao-creative.com
September 2016 All of the descriptions, illustrations, diagrams and technical details in this folder describe examples
of design or construction and they do not form any element of the contract. Text and photographs are the copyright of
AO Multimedia & Drones. All rights reser ved. The right is reserved to make technical alterations.
