AOpen P5TC-AWD User Manual

Chapter 3
Award BIOS
This chapter tells how to configure the system parameters. You may update your BIOS via AWARD Flash Utility.
Important: Because the BIOS code is the most often changed part of the mainboard design, the BIOS information contained in this chapter (especially the Chipset Setup parameters) may be a little different compared to the actual BIOS that came with your mainboard.
3-1
AWARD BIOS
3.1 Entering the Award BIOS Setup Menu
The BIOS setup utility is a segment of codes/routines residing in the BIOS Flash ROM. This routine allows you to configure the system parameters and save the configuration into the 128 byte CMOS area, (normally in the RTC chip
or directly in the main chipset). To enter the BIOS Setup, press during POST (Power-On Self Test). The BIOS Setup Main Menu appears as follows.
Tip: Choose "Load Setup Defaults" for recommended optimal performance. Choose "Load Turbo Defaults" for best performance with light system loading. Refer to section 3.7.
The section at the bottom of the screen tells how to control the screen. Use the arrow keys to move between items, to color scheme of the display, to exit, and to save the changes before exit. Another section at the bottom of the screen displays a brief description of the highlighted item.
After selecting an item, press to select or enter a submenu.
3-2
AWARD BIOS
3.2 Standard CMOS Setup
The "Standard CMOS Setup" sets the basic system parameters such as the date, time, and the hard disk type. Use the arrow keys to highlight an item and
or to select the value for each item.
Standard CMOS à Date
To set the date, highlight the Date parameter. Press or to set the current date. The date format is month, date, and year.
Standard CMOS à Time
To set the time, highlight the Time parameter. Press or to set the current time in hour, minute, and second format. The time is based on the 24 hour military clock.
3-3
AWARD BIOS
Standard CMOS à Primary Master à Type Standard CMOS à Primary Slave à Type Standard CMOS à Secondary Master à Type Standard CMOS à Secondary Slave à Type
Type
Auto User None 1 2 ... 45
This item lets you select the IDE hard disk parameters that your system supports. These parameters are Size, Number of Cylinder, Number of Head, Start Cylinder for Pre-compensation, Cylinder number of Head Landing Zone and Number of Sector per Track. The default setting is Auto, which enables BIOS to automatically detect the parameters of installed HDD at POST (Power­On Self Test). If you prefer to enter HDD parameters manually, select User. Select None if no HDD is connected to the system.
The IDE CDROM is always automatically detected.
Tip: For an IDE hard disk, we recommend that you use the "IDE HDD Auto Detection" to enter the drive specifications automatically. See the section "IDE HDD Auto Detection".
Standard CMOS à Primary Master à Mode Standard CMOS à Primary Slave à Mode Standard CMOS à Secondary Master à Mode Standard CMOS à Secondary Slave à Mode
Mode
Auto Normal LBA Large
The enhanced IDE feature allows the system to use a hard disk with a capacity of more than 528MB. This is made possible through the Logical Block Address (LBA) mode translation. The LBA is now considered as a standard feature of current IDE hard disk on the market because of its capability to support capacity larger than 528MB. Note that if HDD is formatted with LBA On, it will not be able to boot with LBA Off.
3-4
Standard CMOS à Drive A Standard CMOS à Drive B
AWARD BIOS
Drive A
None 360KB 5.25"
1.2MB 5.25" 720KB 3.5"
1.44MB 3.5"
2.88MB 3.5"
These items select floppy drive type. The available settings and types supported by the mainboard are listed on the left.
Standard CMOS à Video
Video
EGA/VGA CGA40 CGA80 Mono
This item specifies the type of video card in use. The default setting is VGA/EGA. Since current PCs use VGA only, this function is almost useless and may be disregarded in the future.
Standard CMOS à Halt On
Halt On
No Errors All Errors All, But Keyboard All, But Diskette All, But Disk/Key
This parameter enables you to control the system stops in case of Power-On Self Test (POST) error.
3-5
AWARD BIOS
3.3 BIOS Features Setup
This screen appears when you select the option "BIOS Features Setup" from the main menu.
BIOS Features à Virus Warning
Virus Warning
Enabled Disabled
Type "Y" to accept write, or "N" to abort write
3-6
Set this parameter to Enabled to activate the warning message. This feature protects the boot sector and partition table of your hard disk from virus intrusion.
Any attempt during boot up to write to the boot sector of the hard disk drive stops the system and the following warning message appears on the screen. Run an anti-virus program to locate the problem.
! WARNING !
Disk Boot Sector is to be modified
Award Software, Inc.
BIOS Features à External Cache
AWARD BIOS
External Cache
Enabled Disabled
Enabling this parameter activates the secondary cache (currently, PBSRAM cache). Disabling the parameter slows down the system. Therefore, we recommend that you leave it enabled unless you are troubleshooting a problem.
BIOS Features à Quick Power On Self Test
Quick Power on Self test
Enable Disabled
This parameter speeds up POST by skipping some items that are normally checked.
BIOS Features à Boot Sequence
Boot Sequence
A,C,SCSI C,A,SCSI C,CDROM,A CDROM,C,A D,A,SCSI E,A,SCSI F,A,SCSI SCSI,A,C SCSI,C,A C only LS/ZIP,C
This parameter allows you to specify the system boot up search sequence. The hard disk ID are listed below:
C: Primary master D: Primary slave E: Secondary master F: Secondary slave LS: LS120 drive ZIP: IOMEGA ZIP drive
BIOS Features à Swap Floppy Drive
Swap Floppy Drive
Enabled Disabled
This item allows you to swap floppy drives. For example, if you have two floppy drives (A and B), you can assign the first drive as drive B and the second drive as drive A or vice-versa.
3-7
AWARD BIOS
BIOS Features à Boot Up NumLock Status
Boot Up NumLock Status
On Off
Setting this parameter to On enables the numeric function of the numeric keypad. Set this parameter to Off to disregard the function. Disabling the numeric function allows you to use the numeric keypad for cursor control.
BIOS Features à Boot Up System Speed
Boot Up System Speed
High Low
Select High or Low system speed after boot.
BIOS Features à Typematic Rate Setting
Typematic Rate Setting
Enabled Disabled
Set this parameter to Enable/Disable the keyboard repeat function. When enabled, continually holding down a key on the keyboard will generate repeatedly keystrokes.
BIOS Features à Typematic Rate (Chars/Sec)
Typematic Rate
6 8 10 12 15 20 24 30
This item allows you to control the speed of repeated keystrokes. The default is 30 characters/sec.
BIOS Features à Typematic Delay (Msec)
Typematic Delay
250 500 750 1000
3-8
This parameter allows you to control the delay time between the first and the second keystroke (where the repeated keystrokes begin). The typematic delay settings are 250, 500, 750, and 1000 msec.
BIOS Features à Security Option
AWARD BIOS
Security Option
Setup System
The System option limits access to both the System boot and BIOS setup. A prompt asking you to enter your password appears on the screen every time you boot the system.
The Setup option limits access only to BIOS setup. To disable the security option, select Password Setting
from the main menu, don't type anything and just press <Enter>.
BIOS Features à PCI/VGA Palette Snoop
PCI/VGA Palette Snoop
Enabled Disabled
Enabling this item informs the PCI VGA card to keep silent (and to prevent conflict) when palette register is updated (i.e., accepts data without responding any communication signals). This is useful only when two display cards use the same palette address and plugged in the PCI bus at the same time (such as MPEQ or Video capture). In such case, PCI VGA is silent while MPEQ/Video capture is set to function normally.
BIOS Features à OS Select for DRAM > 64MB
OS Select for DRAM > 64MB
OS/2 Non-OS/2
Set to OS/2 if your system is utilizing an OS/2 operating system and has a memory size of more than 64 MB.
BIOS Features à Video BIOS Shadow
Video BIOS Shadow
Enabled Disabled
VGA BIOS Shadowing means to copy video display card BIOS into the DRAM area. This enhances system performance because DRAM access time is faster than ROM.
3-9
AWARD BIOS
BIOS Features à C800-CBFF Shadow BIOS Features à CC00-CFFF Shadow BIOS Features à D000-D3FF Shadow BIOS Features à D400-D7FF Shadow BIOS Features à D800-DBFF Shadow BIOS Features à DC00-DFFF Shadow
C8000-CBFFF Shadow
Enabled Disabled
These six items are for shadowing ROM code on other expansion cards. Before you set these parameters, you need to know the specific addresses of that ROM code. If you do not know this information, enable all the ROM shadow settings.
Note: The F000 and E000 segments are always shadowed because BIOS code occupies these areas.
3-10
AWARD BIOS
3.4 Chipset Features Setup
The "Chipset Features Setup" includes settings for the chipset dependent features. These features are related to system performance.
Caution: Make sure you fully understand the items contained in this menu before you try to change anything. You may change the parameter settings to improve system performance . However, it may cause system unstable if the setting are not correct for your system configuration.
3-11
AWARD BIOS
Chipset Features à Auto Configuration
Auto Configuration
Enabled Disabled
When Enabled, the DRAM and cache related timing are set to pre-defined value according to CPU type and clock. Select Disable if you want to specify your own DRAM timing.
Chipset Features à DRAM Timing
DRAM Timing
60 ns 70 ns
There to sets of DRAM timing parameters can be automatically set by BIOS, 60ns and 70ns.
Warning: The default memory timing setting is 60ns to get the optimal performance. Because the specification limitation of INTEL TX chipset , 70ns SIMM can only be used with CPU external clock 60MHz. To use 70ns SIMM with 66MHz CPU external clock may result in unstable system behavior.
Chipset Features à DRAM Leadoff Timing
DRAM Leadoff Timing
11/7/3/4 10/6/3/3 11/7/4/4 10/6/4/3
The Leadoff means the timing of first memory cycle in the burst read or write. Actually, this item controls only page miss read/write leadoff timing and the clocks of RAS precharge and RAS to CAS delay. The four digital represent Read Leadoff/ Write Leadoff/ RAS Precharge/ RAS to CAS delay. For example, default is 10/6/3/3, which means you have 10-x-x-x DRAM page miss read and 6-x-x-x DRAM write, with 3 clocks RAS precharge and 3 clocks RAS to CAS delay.
3-12
Chipset Features à DRAM Read Burst (EDO/FP)
AWARD BIOS
DRAM Read Burst (EDO/FP)
x444/x444 x333/x444 x222/x333
Read Burst means to read four continuous memory cycles on four predefined addresses from the DRAM. The default value is x222/x333 for 60ns EDO or FPM (Fast Page Mode) DRAM. Which means the 2nd,3rd and 4th memory cycles are 2 CPU clocks for EDO and 3 clocks for FPM. The value of x is the timing of first memory cycle and depends on the "DRAM Leadoff Timing" setting.
Chipset Features à DRAM Write Burst Timing
DRAM Write Burst Timing
x444 x333 x222
Write Burst means to write four continuous memory cycles on four predefined addresses to the DRAM. This item sets the DRAM write timing of the 2nd,3rd and 4th memory cycles. There is no difference of EDO and FPM DRAM on the write burst timing. The value of x depends on the "DRAM Leadoff Timing" setting.
Chipset Features à Fast EDO Lead Off
Fast EDO Lead Off
Enabled Disabled
This item enables fast EDO read timing, results 1 clock pull-in for read leadoff latency of EDO read cycles. It must be Disabled, if any FPM DRAM is installed.
Chipset Features à Refresh RAS# Assertion
Refresh RAS# Assertion
5 Clks 4 Clks
This item controls the number of clocks RAS is asserted for refresh cycle.
3-13
AWARD BIOS
Chipset Features à DRAM Page Idle Timer
DRAM Page Idle Timer
2 Clks 4 Clks 6 Clks 8 Clks
This item determines the amount of time in CPU clocks that DRAM page will be close after CPU becomes idle.
Chipset Features à DRAM Enhance Paging
DRAM Enhance Paging
Enabled Disabled
When Enabled, TX chipset will keep DRAM page open as long as possible according to enhanced method.
Chipset Features à SDRAM (CAS Lat/RAS-to-CAS)
SDRAM(CAS Lat/RAS-to-CAS)
2/2 3/3
These are timing of SDRAM CAS Latency and RAS to CAS Delay, calculated by clocks. They are important parameters affects SDRAM performance, default is 2 clocks. If your SDRAM has unstable problem, change 2/2 to 3/3.
Chipset Features à SDRAM Speculative Read
SDRAM Speculative Read
Enabled Disabled
Enable this item reduce one clock of SDRAM read leadoff timing by presenting the SDRAM read request before the controller chip decodes the final memory target. This Item must be Disabled if more than one DIMM is installed in the system.
Chipset Features à System BIOS Cacheable
System BIOS Cacheable
Enabled Disabled
3-14
Enabling this item allows you to cache the system BIOS to further enhance system performance.
Chipset Features à Video BIOS Cacheable
AWARD BIOS
Video BIOS Cacheable
Allows the video BIOS to be cached to allow faster video performance.
Enabled Disabled
Chipset Features à 8 Bit I/O Recovery Time
8 Bit I/O Recovery Time
1 2 3 4 5 6 7 8 NA
For some old I/O chips, after the execution of an I/O command, the device requires a certain amount of time (recovery time) before the execution of the next I/O command. Because of new generation CPU and mainboard chipset, the assertion of I/O command is faster, and sometimes shorter than specified I/O recovery time of old I/O devices. This item lets you specify the delay of 8-bit I/O command by count of ISA bus clock. If you find any unstable 8-bit I/O card, you may try to extend the I/O recovery time via this item. The BIOS default value is 4 ISA clock. If set to NA, the chipset will insert 3.5 system clocks.
Chipset Features à 16 Bit I/O Recovery Time
16 Bit I/O Recovery Time
1 2 3 4 NA
The same as 16-bit I/O recovery time. This item lets you specify the recovery time for the execution of 16­bit I/O commands by count of ISA bus clock. If you find any of the installed 16-bit I/O cards unstable, try extending the I/O recovery time via this item. The BIOS default value is 1 ISA clocks. If set to NA, the chipset will automatically insert 3.5 system clocks.
3-15
AWARD BIOS
Chipset Features à Memory Hole At 15M-16M
Memory Hole At 15M-16M
Enabled Disabled
This option lets you reserve system memory area for special ISA cards. The chipset accesses code/data of these areas from the ISA bus directly. Normally, these areas are reserved for memory mapped I/O card.
Chipset Features à PCI Passive Release
PCI Passive Release
Enabled Disabled
This item lets you control the Passive Release function of the PIIX4 chipset (Intel PCI to ISA bridge). This function is used to meet latency of ISA bus master. Try to enable or disable it, if you have ISA card compatibility problem.
Chipset Features à PCI Delayed Transaction
PCI Delayed Transaction
Enabled Disabled
This item lets you control the Delayed Transaction function of the PIIX4 chipset (Intel PCI to ISA bridge). This function is used to meet latency of PCI cycles to or from ISA bus. Try to enable or disable it, if you have ISA card compatibility problem.
Chipset Features à Mem. Drive Str. (MA/RAS)
Mem. Drive Str. (MA/RAS)
10mA/10mA 10mA/16mA 16mA/10mA 16mA/16mA
This option controls the driving strength of memory address and control signals. It is recommended to use less driving current for light memory loading, to prevent undershoot or overshoot.
3-16
3.5 Power Management Setup
AWARD BIOS
The Power Management Setup screen enables you to control the mainboard green features. See the following screen.
Power Management à Power Management
Power Management
Max Saving Mix Saving User Defined Disabled
This function allows you to set the default parameters of power-saving modes. Set to Disable to turn off power management function. Set to User Defined to choose your own parameters.
’s
Mode Doze Standby Suspend HDD Power Down
Min Saving 1 hour 1 hour 1 hour 15 min Max Saving 1 min 1 min 1 min 1 min
3-17
AWARD BIOS
Power Management à PM Controlled by APM
PM Controlled by APM
Yes No
If "Max Saving" is selected, you can turn on this item, transfer power management control to APM (Advanced Power Management) and enhance power saving function. For example, stop CPU internal clock.
Power Management à Video Off After
Video Off After
N/A Doze Standby Suspend
To turn off video monitor at which power down mode.
Power Management à Break Switch
Break Switch
Enabled Disabled
Setting this item to Enabled allows you to use the Turbo switch as Suspend switch. Pressing the Turbo switch changes nothings for a Pentium system, so we usually use this switch to act as a Suspend switch. The default value of this item is Disabled.
Warning: If you use toggle mode Turbo switch as Suspend switch, be sure to push it twice to simulate momentary mode. Otherwise the system may hang or fail to reboot.
Power Management à Doze Mode
Doze Mode
Disabled 1 Min 2 Min 4 Min 8 Min 12 Min 20 Min 30 Min 40 Min 1 Hour
3-18
This item lets you set the period of time after which the system enters into Doze mode. In this mode, the CPU clock slows down. The ratio is specified in the "Throttle Duty Cycle". Any activity detected returns the system to full power. The system activity (or event) is detected by monitoring the IRQ signals.
Power Management à Standby Mode
AWARD BIOS
Standby Mode
Disabled 1 Min 2 Min 4 Min 8 Min 12 Min 20 Min 30 Min 40 Min 1 Hour
This item lets you set the period of time after which the system enters into Standby mode. In this mode, CPU clock slows down, hard disk will be shut off and the monitor power-saving feature activates. Any activity detected returns the system to full power. The system activity (or event) is detected by monitoring the IRQ signals.
Power Management à Suspend Mode
Suspend Mode
Disabled 1 Min 2 Min 4 Min 8 Min 12 Min 20 Min 30 Min 40 Min 1 Hour
This item lets you set the period of time after which the system enters into Suspend mode. The Suspend mode can be Power On Suspend or Suspend to Hard Drive, selected by "Suspend Mode Option".
Power Management à HDD Power Down
HDD Power Down
Disabled 1 Min
.....
15 Min
This option lets you specify the IDE HDD idle time before the device enters the power down state. This item is independent from the power states previously described in this section (Standby and Suspend).
3-19
AWARD BIOS
Power Management à Suspend Mode Option
Suspend Mode Option
Power On Suspend Suspend to Hard Drive
You can select suspend mode by this item. Power On Suspend is the traditional Green PC suspend
mode, the CPU clock is stop, all other devices are shut off. But power must be kept On to detect activities from modem, keyboard/mouse and returns the system to full power. The system activities is detected by monitoring the IRQ signals. Suspend to Hard Drive saves system status, memory and screen image into hard disk, then the power can be totally Off. Next time, when power is turned On, the system goes back to your original work within just few seconds. You need AOZVHDD to reserve disk space. Refer to section 3.16 "Suspend to Hard Drive" for more information".
Power Management à Throttle Duty Cycle
Throttle Duty Cycle
12.5 %
25.0 %
37.5 %
50.0 %
62.5 %
75.0 %
87.5 %
Clock Throttling means at the Doze/Standby state, the CPU clock count in a given time (not the frequency) is reduced to the ratio specified in this parameter. Actually, the period per CPU clock is not changed. For example, a 66MHz CPU clock remains the same 30ns clock period when system goes into Doze/Suspend. The chipset generates the STPCLK (stop clock) signal periodically to prevent CPU for accepting clock from clock generator. For full power on, the CPU can receive 66M count in one second. If the Slow Clock Ratio is set to 50%, the CPU will only receive 33M clock count in one second. This will effectively reduce CPU speed as well as CPU power.
Power Management à VGA Activity Monitor
VGA Activity Monitor
Enabled Disabled
3-20
To enable or disable the detection of VGA activity for power down state transition.
Power Management à IRQ 8 Clock Event
AWARD BIOS
IRQ 8 Clock Event
Enabled Disabled
To enable or disable the detection of IRQ8 (RTC) event for power down state transition. OS2 has periodically IRQ8 (RTC) interruptions, If IRQ8 is not set to Disabled, OS/2 may fail to go into Doze/Standby/Suspend mode.
Power Management à IRQ [3-7,9-15], NMI
IRQ [3-7,9-15], NMI
Enabled Disabled
To enable or disable the detection of IRQ3-7, IRQ9­15 or NMI interrupt events for power down state transition.
Power Management à Primary IDE 0 Power Management à Primary IDE 1 Power Management à Secondary IDE 0 Power Management à Secondary IDE 1 Power Management à Floppy Disk Power Management à Serial Port Power Management à Parallel Port
Primary IDE 0
Enabled Disabled
These items enable or disable the detection of IDE, floppy, serial and parallel port activities for power down state transition. Actually it detects the read/write to/from I/O or address port.
3-21
AWARD BIOS
3.6 PNP/PCI Configuration Setup
The PNP/PCI Configuration Setup allows you to configure the ISA and PCI devices installed in your system. The following screen appears if you select the option "PNP/PCI Configuration Setup" from the main menu.
PNP/PCI Configuration à PnP OS Installed
PnP OS Installed
Yes No
3-22
Normally, the PnP resources are allocated by BIOS during POST (Power-On Self Test). If you are using a PnP operating system (such as Windows 95), set this item to Yes to inform BIOS to configure only the
resources needed for booting (VGA/IDE or SCSI). The rest of system resources will be allocated by PnP operating system.
AWARD BIOS
PNP/PCI Configuration à Resources Controlled By
Resources Controlled by
Auto Manual
Setting this option to Manual allows you to individually assign the IRQs and DMAs to the ISA and PCI devices. Set this to Auto to enable the auto­configuration function.
PNP/PCI Configuration à Reset Configuration Data
Reset Configuration Data
Enabled Disabled
In case conflict occurs after you assign the IRQs or after you configure your system, you can enable this function, allow your system to automatically reset your configuration and reassign the IRQs.
PNP/PCI Configuration à IRQ3 (COM2) PNP/PCI Configuration à IRQ4 (COM1) PNP/PCI Configuration à IRQ5 (Network/Sound or Others) PNP/PCI Configuration à IRQ7 (Printer or Others) PNP/PCI Configuration à IRQ9 (Video or Others) PNP/PCI Configuration à IRQ10 (SCSI or Others) PNP/PCI Configuration à IRQ11 (SCSI or Others) PNP/PCI Configuration à IRQ12 (PS/2 Mouse) PNP/PCI Configuration à IRQ14 (IDE1) PNP/PCI Configuration à IRQ15 (IDE2)
IRQ 3
Legacy ISA PCI/ISA PnP
If your ISA card is not PnP compatible and requires a special IRQ to support its function, set the selected IRQ to Legacy ISA. This setting informs the PnP BIOS to reserve the selected IRQ for the installed legacy ISA card. The default is PCI/ISA PnP. Take note that PCI cards are always PnP compatible (except old PCI IDE card).
3-23
AWARD BIOS
PNP/PCI Configuration à DMA 0 PNP/PCI Configuration à DMA 1 PNP/PCI Configuration à DMA 3 PNP/PCI Configuration à DMA 5 PNP/PCI Configuration à DMA 6 PNP/PCI Configuration à DMA 7
DMA 0
Legacy ISA PCI/ISA PnP
If your ISA card is not PnP compatible and requires a special DMA channel to support its function, set the selected DMA channel to Legacy ISA. This setting informs the PnP BIOS to reserve the selected DMA channel for the installed legacy ISA card. The default is PCI/ISA PnP. Take note that PCI card does not require DMA channel.
PNP/PCI Configuration à PCI IDE IRQ Map To
PCI IDE IRQ Map To
ISA PCI-Slot1 PCI-Slot2 PCI-Slot3 PCI-Slot4 PCI-Auto
Some old PCI IDE add-on cards are not fully PnP compatible. These cards require you to specify the slot in use to enable BIOS to properly configure the PnP resources. This function allows you to select the PCI slot for any PCI IDE add-on card present in your system. Set this item to Auto to allow BIOS to
automatically configure the installed PCI IDE card(s).
PNP/PCI Configuration à Primary IDE INT# PNP/PCI Configuration à Secondary IDE INT#
Primary IDE INT#
A B C D
These two items, in conjunction with item "PCI IDE IRQ Map To", specify the IRQ routing of the primary or secondary channel of the PCI IDE add-on card (not the onboard IDE). Each PCI slot has four PCI interrupts aligned as listed in the table below. You must specify the slot in the "PCI IDE IRQ Map To", and set the PCI interrupt (INTx) here according to the interrupt connection on the card.
PCI Slot Location 1
(pin A6)
3-24
Location 2 (pin B7)
Location 3 (pin A7)
Location 4 (pin B8)
AWARD BIOS
Slot 1 INTA INTB INTC INTD Slot 2 INTB INTC INTD INTA Slot 3 INTC INTD INTA INTB Slot 4 INTD INTA INTB INTC Slot 5 (if any) INTD INTA INTB INTC
PNP/PCI Configuration à Used MEM Base Addr
Used MEM base addr
N/A C800 CC00 D000 D400 D800 DC00
This item, in conjunction with the "Used MEM Length", lets you set a memory space for non-PnP compatible ISA card. This item specifies the memory base (start address) of the reserved memory space. The memory size is specified in the "Used MEM Length".
PNP/PCI Configuration à Used MEM Length
Used MEM Length
8K 16K 32K 64K
If your ISA card is not PnP compatible and requires special memory space to support its function, specify the memory size in this parameter to inform the PnP BIOS to reserve the specified memory space for installed legacy ISA card.
3-25
AWARD BIOS
3.7 Load Setup Defaults
The "Load Setup Defaults" option loads optimized settings for optimum system performance. Optimal settings are relatively safer than the Turbo settings. We recommend you to use the Optimal settings if your system has large memory size and fully loaded with add-on card (for example, a file server using double-sided 8MB SIMM x4 and SCSI plus Network card occupying the PCI and ISA slots).
Optimal is not the slowest setting for this mainboard. If you need to verify a unstable problem, you may manually set the parameter in the "BIOS Features Setup" and "Chipset Features Setup" to get slowest and safer setting.
3.8 Load Turbo Defaults
The "Load Turbo Defaults" option gives better performance than Optimal values. However, Turbo values may not be the best setting of this mainboard but these values are qualified by the AOpen RD and QA department as the reliable settings especially if you have limited loading of add-on card and memory size (for example, a system that contains only a VGA/Sound card and two SIMMs).
To attain the best system performance, you may manually set the parameters in the "Chipset Features Setup" to get proprietary setting. Make sure that you know and understand the functions of every item in Chipset Setup menu. The performance difference of Turbo from Optimal is normally around 3% to 10%, depending on the chipset and the application.
3-26
AWARD BIOS
3.9 Integrated Peripherals
The following screen appears if you select the option "Integrated Peripherals" from the main menu. This option allows you to configure the I/O features.
Integrated Peripherals à IDE HDD Block Mode
IDE HDD Block Mode
Enabled Disabled
This feature enhances disk performance by allowing multisector data transfers and eliminates the interrupt handling time for each sector. Most IDE drives, except with old designs, can support this feature.
3-27
AWARD BIOS
Integrated Peripherals à IDE Primary Master PIO Integrated Peripherals à IDE Primary Slave PIO Integrated Peripherals à IDE Secondary Master PIO Integrated Peripherals à IDE Secondary Slave PIO
IDE Primary Master PIO
Auto Mode 1 Mode 2 Mode 3 Mode 4
Setting this item to Auto activates the HDD speed auto-detect function. The PIO mode specifies the data transfer rate of HDD. For example: mode 0 data transfer rate is 3.3MB/s, mode 1 is 5.2MB/s, mode 2 is 8.3MB/s, mode 3 is 11.1MB/s and mode 4 is 16.6MB/s. If your hard disk performance becomes unstable, you may manually try the slower mode.
Caution: It is recommended that you connect the first IDE device of each channel to the endmost connector of the IDE cable. Refer to section 2.3 "Connectors" for details on how to connect IDE device(s).
Integrated Peripherals à IDE Primary Master UDMA Integrated Peripherals à IDE Primary Slave UDMA Integrated Peripherals à IDE Secondary Master UDMA Integrated Peripherals à IDE Secondary Slave UDMA
IDE Primary Master UDMA
Auto Disabled
This item allows you to set the Ultra DMA/33 mode supported by the hard disk drive connected to your primary IDE connector.
Integrated Peripherals à On-Chip Primary PCI IDE Integrated Peripherals à On-Chip Secondary PCI IDE
On-Chip Primary PCI IDE
Enabled Disabled
3-28
This parameter lets you enable or disable the IDE device connected to the primary IDE connector.
Integrated Peripherals à USB Legacy Support
AWARD BIOS
USB Legacy Support
Enabled Disabled
This item lets you enable or disable the USB keyboard driver within the onboard BIOS. The keyboard driver simulates legacy keyboard command and let you use USB keyboard during POST or after boot if you don't have USB driver in the operating system.
Caution: You can not use both USB driver and USB legacy keyboard at the same time. Disable "USB Legacy Support" if you have USB driver in the operating system.
Integrated Peripherals à USB IRQ Released
USB IRQ Released
Yes No
USB device is default to use PCI INTD#, the same as PCI slot4. If you installed PCI card on slot4 and require to use INTD#, set this item to Yes. The USB device will then be disabled.
Note: Normally, PCI VGA does not need PCI interrupt, you may put PCI VGA on slot4.
Integrated Peripherals à Onboard FDC Controller
Onboard FDC Controller
Enabled Disabled
Setting this parameter to Enabled allows you to connect your floppy disk drives to the onboard floppy disk connector instead of a separate controller card. Change the setting to Disabled if you want to use a separate controller card.
3-29
AWARD BIOS
Integrated Peripherals à Onboard Serial Port 1 Integrated Peripherals à Onboard Serial Port 2
Onboard Serial Port 1
Auto 3F8/IRQ4 2F8/IRQ3 3E8/IRQ4 2E8/IRQ3 Disabled
This item allow you to assign address and interrupt for the board serial port. Default is Auto.
Note: If you are using an network card, make sure that the interrupt does not conflict.
Integrated Peripherals à Onboard UART 2 Mode
Onboard UART 2 Mode
Standard HPSIR ASKIR
This item is configurable only if the "Onboard UART 2" is enabled. This allows you to specify
the mode of serial port2. The available mode selections are:
Standard - Sets serial port 2 to operate in normal mode. This is the
default setting.
HPSIR - Select this setting if you installed an Infrared module in your
system via IrDA connector (refer to section 2.3 "Connectors"). This setting allows infrared serial communication at a maximum baud rate of 115K baud.
ASKIR - Select this setting if you installed an Infrared module via IrDA
connector (refer to section 2.3 "Connectors"). This setting allows infrared serial communication at a maximum baud rate of 19.2K baud.
3-30
Integrated Peripherals à Onboard Parallel Port
AWARD BIOS
Onboard Parallel Port
3BC/IRQ7 378/IRQ7 278/IRQ5 Disabled
This item controls the onboard parallel port address and interrupt.
Note: If you are using an I/O card with a parallel port, make sure that the addresses and IRQ do not conflict.
Integrated Peripherals à Parallel Port Mode
Parallel Port Mode
SPP EPP ECP ECP + EPP
This item lets you set the parallel port mode. The mode options are SPP (Standard Parallel Port), EPP (Enhanced Parallel Port) and ECP (Extended Parallel Port). SPP is the IBM AT and PS/2 compatible mode. EPP enhances the parallel port throughput by directly writing/reading data to/from parallel port without latch. ECP supports DMA and RLE (Run Length Encoded) compression and decompression.
Integrated Peripherals à ECP Mode Use DMA
ECP Mode Use DMA
3 1
This item lets you set the DMA channel of ECP mode.
Integrated Peripherals à CPU Thermal (Temp.)
CPU Thermal (Temp.)
Ignore Monitor
This function lets you control the Thermal Detection function. When you set this option to Monitor and the temperature of CPU exceeds predefined value, then:
1. The PC speaker will beep 5 times.
2. The CPU cycle timer will descend about 35%.
Note:The CPU cycle timer won't be restored to the original status until you reset the system.
3-31
AWARD BIOS
3.10 Password Setting
Password prevents unauthorized use of your computer. If you set a password, the system prompts for the correct password before boot or access to Setup.
To set a password:
1. At the prompt, type your password. Your password can be up to 8 alphanumeric characters. When you type the characters, they appear as asterisks on the password screen box.
2. After typing the password, press <Enter> key.
3. At the next prompt, re-type your password and press again to confirm the new password. After the password entry, the screen automatically reverts to the main screen.
To disable the password, press when prompted to enter the password. The screen displays a message confirming that the password has been disabled.
3.11 IDE HDD Auto Detection
If your system has an IDE hard drive, you can use this function to detect its parameters and enter them into the "Standard CMOS Setup" automatically.
This routine only detects one set of parameters for your IDE hard drive. Some IDE drives can use more than one set of parameters. If your hard disk is formatted using different parameters than those detected, you have to enter the parameters manually. If the parameters listed do not match the ones used to format the disk, the information on that disk will not be accessible. If the auto-detected parameters displayed do not match those that used for your drive, ignore them. Type N to reject the values and enter the correct ones
manually from the Standard CMOS Setup screen.
3.12 Save & Exit Setup
This function automatically saves all CMOS values before leaving Setup.
3-32
AWARD BIOS
3.13 Exit without Saving
Use this function to exit Setup without saving the CMOS value changes. Do not use this option if you want to save the new configuration.
3.14 NCR SCSI BIOS and Drivers
The NCR 53C810 SCSI BIOS resides in the same flash memory chip as the system BIOS. The onboard NCR SCSI BIOS is used to support NCR 53C810 SCSI control card without BIOS code.
The NCR SCSI BIOS directly supports DOS, Windows 3.1 and OS/2. For better system performance, you may use the drivers that come with the NCR SCSI card or with your operating system. For details, refer to the installation manual of your NCR 53C810 SCSI card.
3-33
AWARD BIOS
3.15 BIOS Flash Utility
The BIOS Flash utility allows you upgrade the system BIOS. To get the AOpen Flash utility and the upgrade BIOS file, contact your local distributor or visit our homepage at http://www.aopen.com.tw. Please make sure that you have the correct BIOS ready, the BIOS filename is normally like AP5TC110.BIN, which means model AP5TC BIOS revision 1.10.
There are two useful programs, Checksum utility CHECKSUM.EXE and AOpen Flash utility AOFLASH.EXE. Follow the procedures below to upgrade your BIOS.
[CHECKSUM.EXE] This utility will help you to determine if the BIOS has been downloaded
correctly or not.
1. Execute
C:> CHECKSUM Biosfile.bin
(Where Biosfile.bin indicates the file name of the BIOS code.)
2. The utility will show "Checksum is ssss".
3. Compare the "ssss" with original checksum posted on Web or BBS. If they
are different, please do not proceed any further and try to download the BIOS again.
[AOFLASH.EXE] This utility will try to check the mainboard model, BIOS version and Super/Ultra
IO chip model. To ensure the correct BIOS file for the correct mainboard and IO chip. This utility will permanently replace your original BIOS content after flashing.
1. Bootup the system from DOS prompt without loading any memory manager
(HIMEM, EMM386, QEMM386, ...).
2. Execute
C:> AOFLASH Biosfile.bin
(Where Biosfile.bin indicates the file name of the BIOS code.)
3. After loading the new BIOS code, the utility will prompt you to save original
BIOS code into your HDD or floppy. Please press "Y" to store it as "BIOS.OLD".
4. After the old BIOS has been successfully saved, press "Y" to replace BIOS.
3-34
AWARD BIOS
5. DO NOT turn off the power during "FLASHING".
6. Reboot the system by turn off the power after "FLASHING".
7. Press "DEL" key to enter BIOS setup during POST.
8. Reload the "BIOS SETUP DEFAULT" and reconfigure other items as
previous set.
9. Save & Exit. Done!
Warning: DO NOT turn off the power during "FLASHING". If the BIOS programming is not successfully finished, the system will not be boot again, and you may need to physically replace the BIOS chip.
Tip: You may load back original BIOS "BIOS.OLD" by the same procedure.
3-35
Loading...
