AOpen MX3WE2L User Manual
Specifications and Main Features
- Motherboard type: Intel® Socket 370 micro ATX
- Chipset: Intel® i810E2
- Supported Processor: Intel® Socket 370 P3 & Celeron™ Series CPUs; 66/100/133MHz FSB clock frequencies are supported and installed.
- Memory Slots:
- Two SDRAM DIMM 168-pin sockets.
- Size constraints: Maximum memory size: 512MB.
- SDRAM PC-100 Sawtooth Compatible.
- Support Hardware: The Split Transaction, Split Burst Transfer model expects an increase of up to 1066MB/sec and can operate in AGP 1x/2x mode.
- IDE controller:
- Integrated PCI bus master IDE-controller.
- Modes of UDMA 33/66/100 are supported
- Up to one hundred megabytes per second is the transfer speed.
- Sound:
- The motherboard has an on-board high-fidelity surround sound stereo audio codec
- Chipset: AD1885 AC97 CODEC
- Back panel connectors:
- Three pcs 32-bit/33Mhz PCI slots.
- One CNR expansion slot.
- Usb changes for the better:
- Back panel includes dual USB ports.
- For front panel connection, two USB ports are available.
- Power saving techniques:
- It meets all the requirements set forth by ACPI standards.
- Wake on:
- Wake on modem (WOM).
- Wake on LAN (WOL).
- Hardware monitoring :
- It manages the status of the CPU and System fans, the sources of power and the temperature
- Other information:
- Micro ATX Form Factor
- Dimensions of the micro ATX The device conforms to all standard micro ATX device dimensions.
- Ports and Expansion Cards:
- Includes a PS/2, USV, serial, parallel, AC97 sound socket, and VGA outputs on the back panel
- Integrates an infrared module facilitating wireless communications
- Smart Card Reader – It is used as a security device for the system
Frequently Asked Questions
Q1: What kind of processors can be used on MX3W-E2 Series motherboard?
A1: It can use the Intel socket 370 series of Pentium III and Celeron processors.
Q2: How much maximum memory is it possible to install on this motherboard?
A2: This motherboard can use a maximum memory of 512MB.
Q3: Is it possible to connect USB devices to the motherboard?
A3: It has four USB ports and so it is possible.
Q4: Under these conditions, what is the maximum throughput of the IDE controller?
A4: The maximum throughput speed of an IDE Controller can go upto 100MB per second.
Q5: Is there an integrated audio circuitry on it?
A5: Yes, it has an integrated AD1885 AC97 CODEC chip for Audio .
Q6: Is it possible to boot up the modem using a modem?
A6: Yes, Wake-On Modem (WOM) features are incorporated in the motherboard.
Q7: What kinds of expansion slots are found on the motherboard?
A7: It has three PCI slots and one CNR slot for expansion
Q8: Are there any hardware monitoring features present?
A8: It does, it monitors the CPU and system fan, temperature and voltage.
Q9: Are the MX3W-E2 Series Motherboards supported by the Windows Operating System?
A9: The MX3W-E2 Series Motherboards are offered support for Windows Operating Systems including Windows 95, 98, ME, NT and 2000.
Q10: How is the motherboard powered?
A10: The Motherboard is powered by connecting to a standard ATX with a 20 pin connector.
