AOpen AP5VM-AMI User Manual

Chapter 3

AMI BIOS

This chapter tells how to configure the system by setting the BIOS parameters.

3.1 Entering the AMI BIOS Setup

To enter the AMI BIOS Setup, press . The AMI BIOS Setup Main Menu
appears as shown below.

The AMI BIOS is in Windows form. You can use either the keyboard or a
mouse to move between the items.

To select among the Setup menu groups, use to highlight the selected
group or simply click on the icon of the selected Setup menu.

To select among the options, you can either use the arrow keys to move the
highlight bar or simply click on the icon of the desired option.

3-1

AMI BIOS Utility

After making your selection, press or double-click on the icon to open
the selected menu option.

You may press to perform the following:

• Resolve an address conflict due to an IRQ
address assigned to multiple slots. For more
information on IRQ assignment, see the section

3.2.3 (Chipset Features Setup).

• Return to the BIOS default settings if the PnP
BIOS does not recognize the hardware
modifications under Windows 95.

To meet the PC market demands, ongoing hardware
and software enhancements are done on the system.
Therefore, it is possible that BIOS screens may be
changed without notice.

3-2

AMI BIOS Utility

3.2 Setup Menu

The figure below shows the Setup window. Use the arrow keys to highlight an
option.

3.2.1 Standard Setup

The following screen appears if you select Standard from the Setup
options:

You can input configuration values such as date, time and disk types in this
menu.

PRIMARY MASTER AND SLAVE/

SECONDARY MASTER AND SLAVE

These parameters allow you to configure the hard disks and the IDE devices
connected to your IDE connectors. To configure the hard disk connected to
the master port of the primary IDE connector, select Primary Master

and press . The following screen appears:

3-3

AMI BIOS Utility

To configure the hard disk connected to the slave port of the primary IDE
connector, select Primary Slave.

The secondary IDE connector also supports two IDE devices. To configure the
hard disk or the IDE device connected to the master port, select

Secondary Master. Choose Secondary Slave to configure the

device connected to the slave port.
The following are the parameters that you need to set to configure your hard

disks or the IDE devices:

3-4

AMI BIOS Utility

Type

This parameter lets you set the IDE device type that your system supports.
The options are User, Auto, CD-ROM, Type 1-46, and Not

Installed. Select Auto to automatically configure the installed hard

disk or IDE device. Select CD-ROM if you have a CD-ROM installed in your
system. If you have an old type HDD installed, you may need to enter the
HDD parameters manually. To do this, you must set this parameter to User.
Select Not Installed to bypass the function.

LBA/Large Mode

This enhanced IDE feature allows the system to use a hard disk with a
capacity of more than 528 MB. This is made possible through the Logical
Block Address (LBA) mode translation. Set the parameter to Off to disregard

the feature.

This parameter becomes non-configurable when the HDD Type parameter is
set to Auto.

Block Mode

This function enhances disk performance depending on the hard disk in use.
If enabled, it allows data transfers in block (multiple sectors) by increasing the
data transfer rate to 256 bytes/cycle. However, if your hard disk does not
support this function, set this parameter to Off.

This parameter becomes non-configurable when the HDD Type parameter is
set to Auto.

3-5

AMI BIOS Utility

32-bit Mode

Enabling this parameter improves system performance by increasing the hard
disk access to 32-bit mode. However, make sure that your hard disk supports
this function before you enable the parameter. Otherwise, set this parameter
to Off.

PIO Mode

Setting this parameter to On allows the system to use a faster hard disk drive.
If your hard disk does not support the PIO mode feature, set this parameter to

Off.

This parameter becomes non-configurable when the HDD Type parameter is
set to Auto.

HARD DISK TYPES

After you have set all the necessary parameters, press . A list of the
HDD drive parameters appears:

Select your hard disk type. Press or to move among the selections.
After you have made your selection, press .

If you cannot find your hard disk drive type on the list, select User. This
allows you to enter the disk parameters manually.

DATE/TIME

To set the date and time, highlight Date/Time and press . The
following screen appears:

3-6

AMI BIOS Utility

Select the arrow keys to move among the items. Press or click on or to
set the current time and date. Press or double-click on the Control

menu box at the upper-left corner of the window.

FLOPPY DRIVES A AND B

To configure the first floppy drive, select Floppy A. The following values
appear on screen:

After selecting the proper setting, press .
Select Floppy B and follow the same procedure to configure the second

floppy drive.

3.2.2 Advanced CMOS Setup

The following screen appears if you select the option Advanced from the
Setup menu:

3-7

AMI BIOS Utility

The first screen does not show all the parameters of the Advanced
Configuration menu. To scroll down the rest of the parameters, press .
Press or to highlight the desired parameter.

3-8

AMI BIOS Utility

Do not change the settings of the Advanced
Setup parameters if you are not a qualified
technician. Doing so may cause fatal system
failure.

Quick Boot

During boot up, the system performs power-on self test (POST) routines.
Enable the parameter if you want to skip some POST routines during the boot
process. Set this to Disabled to let the system perform all the POST

routines and follow the specified boot-up sequence.

Boot-up Sequence

The boot-up sequence allows you to specify the system search sequence.
The selections are C:, A:, CD-ROM , A:, C:, CD-ROM and

CD-ROM, A:, C:. If you have a bootable CD-ROM installed, you may

set the CD-ROM as the first priority. The default is A:, C:, CD-ROM.

Boot-up Numlock

Setting this parameter to On enables the numeric function of the numeric
keypad. Set this parameter to Off to disable the function. Disabling the
numeric function allows you to use the cursor control numeric keypad. The

default setting is Off.

3-9

AMI BIOS Utility

Floppy Drive Swap

This parameter allows you to swap floppy drives. For example, if you have two
floppy drives (A and B), you can assign the first drive as drive B and the
second drive as drive A or vice-versa. Disable the parameter to bypass the
function. The default is Disabled.

Floppy Drive Seek

When enabled, BIOS detects whether there is a floppy disk drive installed in
the system. Disable the parameter to skip the function.

Typematic Rate

This parameter allows you to control the speed at which the system registers
repeated keystrokes.

System Keyboard

Set this parameter to Present if there is a keyboard connected to the
system. If none, select Absent.

Primary Display

This function specifies the VGA type in use. The selections are VGA/EGA,

CGA 40 x 25, CGA 80 x 25, Mono, and Absent. The

default setting is VGA/EGA.

Password Check

This parameter lets you set when to check for the password. When set to

Always, a password prompt appears every time you turn on the computer

and when you enter Setup. When set to Setup, the password prompt
appears when you try to enter setup. The Optimal and Turbo default setting is

Setup.

OS/2 Compatible Mode

Enable the parameter if your system is utilizing an OS/2 operating system and
has a memory size of more than 64 MB. Otherwise, set this to Disabled.

The default setting is Disabled.

3-10
