AOpen AK77400G User Manual

Download

AAKK7777--440000GG // AAKK7777--440000GGNN

AK77-400G / AK77-400GN

DOC. NO.: AK77400GN-OL-E0312C

OOnnlliinnee MMaannuuaal

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

WWhhaatt’’ss iinn tthhiiss mmaannuuaall

TUAK77-400G / AK77-400GNUT ................................................................................................................1

TUWhat’s in this manualUT ......................................................................................................................................................2

TUYou Must NoticeUT..............................................................................................................................................................8

TUBefore You StartUT .............................................................................................................................................................9

TUOverviewUT .......................................................................................................................................................................10

TUFeature HighlightUT .......................................................................................................................................................... 11

TUQuick Installation ProcedureUT ......................................................................................................................................... 14

TUMotherboard MapUT .........................................................................................................................................................15

TUBlock DiagramUT ..............................................................................................................................................................1 6

TUHard ware InstallationUT ...............................................................................................................17

TUAbout “Manufacturer Upgrade Optional” and “User Upgrade Optional”…UT ..................................................................... 18

TUCPU InstallationUT ............................................................................................................................................................19

TUAOpen Overheat Protection (O.H.P.) TechnologyUT ......................................................................................................... 21

TUCPU Over-current ProtectionUT ........................................................................................................................................2 2

TUEnlarged Aluminum HeatsinkUT ........................................................................................................................................23

TUSetting CPU FrequencyUT ................................................................................................................................................24

TUAOpen “Watch Dog ABS”UT .............................................................................................................................................. 26

TUCPU and Housing Fan Connector (with H/W Monitoring)UT ..............................................................................................27

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TUJP14 Clear CMOS Data JumperUT ...................................................................................................................................49

TUJP21 K7 Host Clock SelectionUT ...................................................................................................................................... 50

TUJP28 KB/Mouse Wake-up JumperUT ................................................................................................................................51

TUSTBY LEDUT ....................................................................................................................................................................52

TUAGP Protection Technology and AGP LEDUT ...................................................................................................................53

TUBattery-less and Long Life DesignUT ................................................................................................................................54

TU3300µF

Low ESR CapacitorUT ..........................................................................................................................................55

TUAOConfig UtilityUT ............................................................................................................................................................ 57

TUEzClockUT ........................................................................................................................................................................59

TUPHOENIX-AWARD BIOSUT .............................................................................................................63

TUHow To Use Phoenix-Award™ BIOS Setup ProgramUT ....................................................................................................64

TUHow To Enter BIOS SetupUT.............................................................................................................................................65

TUBIOS Upgrade under Windows environmentUT ................................................................................................................. 66

TUVivid BIOS technologyUT ..................................................................................................................................................68

TUDriver and Utilit yU T .......................................................................................................................69

TUAuto-run Menu from Bonus CDUT .....................................................................................................................................69

TUInstalling VIA 4 in 1 DriverUT ............................................................................................................................................ 70

TUInstalling Audio DriverUT ................................................................................................................................................... 71

TUInstalling LAN Driver in Windows 98SE/ME/2000/XP (for AK77-400GN)UT....................................................................... 72

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TUInstalling USB 2.0 DriverUT ...............................................................................................................................................75

TUGlossar yU T ....................................................................................................................................76

TUAC97 CODECUT ...............................................................................................................................................................76

TUACPI (Advanced Configuration & Power Interface)UT ....................................................................................................... 76

TUACR (Advanced Communication Riser)UT ........................................................................................................................76

TUAGP (Accelerated Graphic Port)UT ...................................................................................................................................77

TUAMR (Audio/Modem Riser)UT ...........................................................................................................................................77

TUATA (AT Attachment)UT..................................................................................................................................................... 77

TUBIOS (Basic Input/Output System)UT ................................................................................................................................78

TUBluetoothUT ......................................................................................................................................................................78

TUCNR (Communication and Networking Riser)UT ............................................................................................................... 79

TUDDR (Double Data Rate) RAMUT ......................................................................................................................................79

TUECC (Error Checking and Correction)UT ........................................................................................................................... 80

TUEEPROM (Electronic Erasable Programmable ROM)UT ................................................................................................... 80

TUEPROM (Erasable Programmable ROM)U T ......................................................................................................................80

TUEV6 BusUT ........................................................................................................................................................................80

TUFCC DoC (Declaration of Conformity)UT ...........................................................................................................................81

TUFC-PGA (Flip Chip-Pin Grid Array)UT ...............................................................................................................................81

TUFC-PGA2 (Flip Chip-Pin Grid Array)UT .............................................................................................................................81

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TUDIMM SocketsUT .............................................................................................................................................................. 28

TUATX Power ConnectorUT...................................................................................................................................................30

TUAC Power Auto RecoveryUT .............................................................................................................................................3 0

TUIDE and Floppy ConnectorUT ............................................................................................................................................ 31

TUATA133 SupportedUT ........................................................................................................................................................33

TUFront Panel ConnectorUT .................................................................................................................................................. 34

TUIrDA ConnectorUT .............................................................................................................................................................35

TUAGP (Accelerated Graphic Port) 8X Expansion SlotUT .....................................................................................................36

TUWOL (Wake on LAN) ConnectorUT ...................................................................................................................................37

TU10/100 Mbps LAN onboard (for AK77-400GN)UT .............................................................................................................. 39

TUS/PDIF (Sony/Philips Digital Interface) ConnectorUT ........................................................................................................ 40

TUSuper 5.1 Channel Audio EffectUT .................................................................................................................................... 41

TUSupport Six USB 2.0 PortUT .............................................................................................................................................42

TUColor Coded Back PanelUT ............................................................................................................................................... 43

TUFront Audio ConnectorUT ..................................................................................................................................................4 4

TUCase Open ConnectorUT ..................................................................................................................................................45

TUCD Audio ConnectorU T .....................................................................................................................................................46

TUAUX-IN ConnectorUT ........................................................................................................................................................47

TUGame Port Bracket SupportedUT ......................................................................................................................................48

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TUFlash ROMUT ...................................................................................................................................................................81

TUHyper ThreadingUT ...........................................................................................................................................................81

TUIEEE 1394UT .................................................................................................................................................................... 82

TUParity BitUT .......................................................................................................................................................................82

TUPCI (Peripheral Component Interface) BusUT ................................................................................................................... 83

TUPDF FormatUT .................................................................................................................................................................. 83

TUPnP (Plug and Play)UT......................................................................................................................................................8 3

TUPOST (Power-On Self Test)U T ..........................................................................................................................................83

TUPSB (Processor System Bus) ClockUT .............................................................................................................................84

TURDRAM (Rambus Dynamic Random Access Memory)UT .................................................................................................84

TURIMM (Rambus Inline Memory Module)UT ........................................................................................................................ 84

TUSDRAM (Synchronous DRAM)UT ......................................................................................................................................84

TUSATA (Serial ATA)UT .........................................................................................................................................................8 5

TUSMBus (System Management Bus)UT .............................................................................................................................. 85

TUSPD (Serial Presence Detect)UT ...................................................................................................................................... 85

TUUSB 2.0 (Universal Serial Bus)UT .....................................................................................................................................85

TUVCM (Virtual Channel Memory)UT ....................................................................................................................................86

TUWireless LAN – 802.11bUT ...............................................................................................................................................86

TUZIP fileUT .......................................................................................................................................................................... 86

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TUTroubleshootingUT ........................................................................................................................87

TUTechnical SupportUT .....................................................................................................................91

TUProduct Registr ationUT .................................................................................................................94

TUHow to Contact UsUT ....................................................................................................................9 5

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

YYoouu MMuusstt NNoottiiccee

Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated. AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc. Intel, the Intel logo, Intel Celeron, Pentium II, Pentium III, Pentium 4 are trademarks of Intel Corporation. Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United

States and/or other countries. All product and brand names used on this manual are used for identification purposes only and may be the registered

trademarks of their respective owners.

All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that may appear in this manual, including the products and software described in it.

This documentation is protected by copyright law. All rights are reserved. No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval system without prior written permission from AOpen Corporation. Copyright

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

BBeeffoorree YYoouu SSttaarrtt

This Online Manual will introduce to the user how this product is installed. All useful information will be described in later chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved

HTUPDF format UTH, we recommend using Adobe Acrobat Reader 5.0 for online viewing, it is included in HTU Bonus CD discUT H or you can

in get free download from

Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer driver.

Thanks for the help of saving our earth.

HTUAdobe web siteU TH .

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

OOvveerrvviieeww

Thank you for choosing AOpen AK77-400G / AK77-400GN motherboard. The AK77-400G / AK77-400GN motherboard is AMDP Socket 462 motherboard based on the ATX form featuring the motherboard, this motherboard comes with AMD

Socket 462 series Athlon™ & Duron™ and AthlonXP™ processor (with CPU

Overheat Protection circuit to Athlon™XP CPU only) and 200/266/333 MHz

HTUVIA KT400A chipsetUTH . As high performance chipset built in the

HTUEV6U TH system bus. In the AGP performance, it has

one AGP slot and supports AGP 8X/4X/2X mode and pipelined spilt-transaction long burst transfer up to 2.1GB/sec. With high bandwidth 266/533MB/s 8-bit V-Link Host Controller,

HTU DDR400UT H, HT UDDR333UT H and H TU DDR266UT H DDR RAM can be applied to this

motherboard and maximum memory size can be up to 3GB. The on-board IDE controller supports Ultra DMA 66/100/133 mode. On the strength of RealTek LAN controller on board, it provides 10/100M bps Ethernet for office and home use. Beside, this motherboard has a S/PDIF connector and an

HTUAC97U TH U CODECU ALC650F

chipset onboard to provide high performance and magic surround stereo sound to let people enjoy working with it. More than that, this motherboard supports

HTU USB 2.0UTH function with a fancy speed of up to

480Mbps. Now, let’s enjoy all features from AOpen AK77-400G / AK77-400GN.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

FFeeaattuurree HHiigghhlliigghhtt

CPU

Supports AMDP Athlon: 600MHz~1.4GHz Duron: 600MHz~1.2GHz AthlonXP: 1500+ (1.33GHz) ~3000+ (2.2GHz)

Socket 462 series CPU with 200/266/333 MHz EV6 Bus designed for Socket 462 technology.

Chipset

The VIA KT400A consists of Host system controller and the VT8235CE highly integrated V-Link Client PCI/LPC controller. The Host system controller provides superior performance between the CPU, RAM, AGP bus, and V-Link interface with pipelined, burst, and concurrent operation. The VT8235CE V-Link Client controller is a highly integrated PCI/LPC controller. Its internal bus structure is based on 66MHz PCI bus that provides 8x bandwidth compare to previous generation PCI/ISA bridge chips. The VT8235CE integrated Client V-Link controller with 266/533MB/s bandwidth between Host/Client V-Link interface, providing a V-Link-PCI and V-Link-LPC controller.

Ultra DMA 66/100/133 Bus Master IDE

Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels, supports Ultra DMA 66/100/133, PIO Modes 3 and 4 and Bus Master IDE DMA Mode 4, and supports Enhanced IDE devices.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

LAN Port (for AK77-400GN)

On the strength of Realtek LAN controller on board, which is a highly integrated Platform LAN Connect device, it provides 10/100 Mbps Ethernet for office and home use.

Expansion Slots

Including five 32-bit/33MHz PCI and one AGP 8X/4X slots. The PCI local bus throughput can be up to 132MB/s. All of them are master PCI slots with arbitration and decoding for all integrated functions and LPC bus. The specification provides a new level of video display sophistication and speed. And the data transfer rate can be up to 2112MB/s.

HTU Accelerated Graphics Port (AGP)UTH

Memory

Provides three 184-pin DDR DIMM sockets that support DDR 400/333/266 composed of an arbitrary mixture of 64, 128, 256, 512 MB or 1GB RAM up to 3 GB maximum.

On-board AC97 Sound

AK77-400G / AK77-400GN uses the HTUAC97 CODECU TH RealTek ALC650F chip, which includes a complete audio recording and playback system.

S/PDIF Connector

S/PDIF (Sony/Philips Digital Interface) is the newest audio transfer file format, which provides impressive quality through optical fiber and allows you to enjoy digital audio instead of analog audio.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Six USB 2.0 Connectors

Provides four ports on the back panel and one HTU USBUT H 2.0 header on board to connect USB interface devices, such as mouse, keyboard, modem, scanner, etc. With fancy speed up to 480Mbps USB 2.0 is 40 times faster than the traditional ones. Except for the speed increase, USB 2.0 supports old USB 1.0/1.1 software and peripherals, offering impressive and even better compatibility to customers.

1MHz Stepping CPU Frequency Adjustment

Provides “1MHz Stepping CPU Frequency Adjustment” function in the BIOS. This magic function allows you adjust CPU H TU FSBUT H frequency from 100~248MHz by 1MHz stepping, and lets your system can get maximum performance.

Watch Dog ABS

Includes AOpen “Watch Dog ABS” function that can auto-reset system in 4.8 seconds when you fail the system overclocking.

Power Management/Plug and Play

AK77-400G / AK77-400GN supports the power management function that confirms to the power-saving standards of the U.S. Environmental Protection Agency (EPA) Energy Star program. It also offers configuration problems, thus making the system much more user-friendly.

HTUPlug-and-PlayU TH , which helps saving users from

Hardware Monitoring Management

Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor module and AOpen Hardware Monitoring Utility.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

QQuuiicckk IInnssttaallllaattiioonn PPrroocceedduurree

This page gives you a quick procedure on how to install your system. Follow each step accordingly.

1. Installing HTUCPUU TH and HT UFanU TH

2. HTUInstalling System Memory (DIMMUT H)

3. HTUConnecting Front Panel CableUT H

4. HTUConnecting IDE and Floppy CableUT H

5. HTUConnecting ATX Power CableUTH

6. HTUConnecting Back Panel CableUT H

7. HTUPower-on and Load BIOS Setup DefaultU TH

8. HTUSetting CPU FrequencyUT H

9. Reboot

10. HT UInstalling Operating System (such as Windows XP)UTH

11. HT UInstalling Driver and UtilityUTH

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Realtek LAN chip

(AK77-400GN only)

2Mb Flash ROM BIOS

Onboard AC’97 CODEC

Game Port Connector

AUX-IN Connector

CD-IN Connector

HTFront Audio ConnectorTH

HTS/PDIF ConnectorTH

32-bit PCI Expansion Slots x5TH

Case Open ConnectorTH

HTIrDA ConnectorTH

USB 2.0 ConnectorTH

HTJP14 CMOS Clear JumperTH

SYSHTFAN2 ConnectorTH

STBY LED

Front Panel ConnectorTH

FDD ConnectorTH

HTATA 66 /100/133

HIDE Connectors x2H

Motherboard Map

HTColored Back Pan elT H

Wake On LAN Connector

HTATX Power ConnectorTH

JP28 Keyboard/Mouse Wakeup

Enable/Disable JumperTH 3300μF Low ESR CapacitorsTH

SYSHTFAN1 ConnectorTH 8x HTAGP SlotT H

462-pin CPU Socket with Voltage and Frequency Auto-Detection that supports AMD

AthlonP

/DuronP (with CPU Overheat Protection circuit to Athlon

VIAP

KT400A and

VIA 8235CE Chipsets

CPUFAN Connector TH

184-pin DIMMsx3 supports DDR 266

JP21 K7 Host Clock Select Jumper

/AthlonP

XP CPU only)

333/400(Max to 3GB

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

BBlloocckk DDiiaaggrraamm

Socket 462

AMD

Athlon/Duron/AthlonXP

CPU

AGP 8X Slot

DDR400/333/266 RAM Up to

DDR RAM Socket x3

200/266/333 MHz System

Bus

AGP Bus

LAN connect Component

Floppy Disk Drive x2

3GB

VIA KT400A

PCI Bus

66/100/133

RealTek

8101L

For AK77-400GN

1stUSB Port

3rdUSB Port

USB connector x6

32-bit PCI Slot x5

ATA

VIA8235CE

Primary Channel

Secondary

Channel

IDE Drive x4

AC’97 Link

Audio CODEC

2MBit Flash EEPROM

Parallel Port

Serial Port x22ndUSB Port

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

HHaarrddwwaarree IInnssttaallllaattiioonn

This chapter describes jumpers, connectors and hardware devices of this motherboard.

Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component.

1. Do not remove a component from its protective packaging until you are ready to install it.

2. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a component. If a wrist strap is not available, maintain contact with the system unit throughout any procedures requiring ESD protection.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAbboouutt ““MMaannuuffaaccttuurreerr UUppggrraaddee OOppttiioonnaall”” aanndd ““UUsseerr UUppg

When you read this online manual and start to assemble your computer system, you may find some of functions are called “Manufacturer Upgrade Optional”, and some are called “User Upgrade Optional”. Though all AOpen motherboards include many amazing and powerful features, in some situations, these powerful features are not used to every user. Hence, we changed some key features as “Manufacturer Upgrade Optional” for you to choose. Some optional functions that can be upgraded by users, we call them “User Upgrade Optional”. As for those optional functions that can’t be upgraded by ourselves, we call them “Manufacturer Upgrade Optional”. If needed, you can contact our local distributors or resellers for purchasing “User Upgrade Optional” components, and again you can visit AOpen official web site:

HTUhttp://english.aopen.com.tw/UTH for more detail information.

grraaddee OOppttiioonnaall””……

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCPPUU IInnssttaallllaattiioonn

This motherboard supports AMDP socket (with CPU Overheat Protection function implemented, the system will be automatically power off when the temperature of CPU reached 97 degree, but works on AthlonXP CPU only).

1. Pull up the CPU socket lever and up to 90-degree angle.

Athlon and Duron Socket 462 series CPU. Be careful of CPU orientation when you plug it into CPU

2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU upper interface. Match Pin 1 and cut edge, then insert the CPU into the socket.

CPU socket

Lever

Note: This picture is for example only; it may not exactly be the same motherboard.

CPU pin 1 and

cut edge

Black dot and

cut edge

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

3. Press down the CPU socket lever and finish CPU installation.

Note: This picture is for example only; it may not exactly be the same motherboard.

CPU cut edge

Note: If you do not match the CPU socket Pin 1 and CPU cut edge well, it ma

damage the CPU.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAOOppeenn OOvveerrhheeaatt PPrrootteeccttiioonn ((OO..HH..PP..)) TTeecchhnnoollooggyy

With AMD platform substantially keeps increasing the speed of its CPU, it inevitably led to the

annoying problem of high CPU operation temperature at the same time. In order to prevent accidental failure of CPU fan, which could cause the burning down of the AthlonXP CPU, we, AOpen, have meticulously developed a new technology, named, O.H.P. (Overheat Protection) Technology to protect them. Thanks to the intelligent monitoring design of AOpen O.H.P. technology, user can now finally set their mind at ease even when fan failed to work without fearing the possible damage of CPU.

Under the circumstances that CPU fan is running properly, AthlonXP temperature should be way below the highest temperature limit of 97℃. However, if CPU fan accidentally becomes malfunction or improperly installed, the CPU temperature would rocket

abruptly, and you may find your system hang up or crying over the smoking CPU if you haven’t installed AOpen O.H.P. previously. With AOpen O.H.P. technology applied, the specific thermal detection pins on AthlonXP CPU would sense voltage difference when processor is overheated with fan failed, and the overheat protection system would immediately send out a signal to abort your system by cutting CPU electricity before any damage is done. Unlike other manufacturers who use BIOS or software to control the power supply of CPU, AOpen O.H.P. Technology is purely hardware-controlled the minute after system boot-up, and occupies no system resource. We are pleasant to phase in this practical function on all AOpen AMD series motherboards to protect customer’s valuable hardware and personal data.

Note: AOpen Overhear Protection Technology only support processors base on 0.13-micron technology in this motherboard.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCPPUU OOvveerr--ccuurrrreenntt PPrrootteeccttiioonn

Over Current Protection has been popularly implemented on ATX 3.3V/5V/12V switching power supply for a while. However, new generation CPU is able to use regulator of different voltages to transfer 12V to CPU voltage (for example, to 2.0V). This motherboard is with switching regulator onboard that supports CPU over-current protection, and it applies to 3.3V/5V/12V power supply for providing full line over-current protection.

ATX Switching Power Supply

Note: Although we have implemented protection circuit try to prevent any human operating mistake, there is still certain risk that CPU, memory, HDD, add-on cards installed on this motherboard may be damaged because of component failure, human operating error or unknown nature reason. AOpen cannot guaranty the protection circuit will always work perfectly.

5V (Protected by power supply)

3.3V (Protected by power supply)

12V (Protected by power supply)

Onboard Power Regulator

(Over-Current Protection)

CPU Core Voltage

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

EEnnllaarrggeedd AAlluummiinnuumm HHeeaattssiinnkk

Cool down CPU and Chipset is important for system reliability. Enlarged aluminum heat sink provides better heat consumption especially when you are trying to over clocking the CPU.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

SSeettttiinngg CCPPUU FFrreeqquueennccyy

BIOS Setup > Frequency/Voltage Control > CPU Bus Frequency

This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, and no jumpers or switches are needed. The default setting is "table select mode". You can adjust the FSB from "CPU Bus Frequency" for overclocking.

Core Frequency = CPU HTUBusUTH Clock * C PU Rat io

PCI Clock = CPU Bus Clock / Clock Ratio

HTUAGPU TH Clock = PCI Clock x 2

EV6 Bus Speed = CPU external bus clock x 2

CPU Ratio CPU FSB

(By manual Adjustment)

Home

Tip: If your system hangs or fails to boot because of overclocking, simply use

<Home> key to restore the default setting or you can wait till the AOpen “Watch

Dog ABS” reset the system in five seconds and system will auto-detect

hardware again.

From 5.0x to 18.0x step 0.5x

100~191 by 1MHz stepping adjustment technology

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CPU

Athlon 1.33G 1.33GHz 266MHz 10.0x Athlon 1.4G 1.4GHz 266MHz 10.5x AthlonXP 1500+ 1.3GHz 266MHz 10.0x AthlonXP 1600+ 1.4GHz 266MHz 10.5x AthlonXP 1700+ 1.46GHz 266MHz 11.0x AthlonXP 1800+ 1.53GHz 266MHz 11.5x AthlonXP 1900+ 1.6GHz 266MHz 12.0x AthlonXP 2000+ 1.667GHz 266MHz 12.5x AthlonXP 2100+ 1.73GHz 266MHz 13x AthlonXP 2200+ 1.80GHz 266MHz 13.5x AthlonXP 2400+ 2.0GHz 266MHz 15x AthlonXP 2500+ (Barton) 1.833GHz 333MHz 11x AthlonXP 2600+ 2.13GHz 266MHz 16x AthlonXP 2600+ 2.08GHz 333MHz 12.5x AthlonXP 2700+ 2.16GHz 333MHz 13x AthlonXP 2600+ (Barton) 1.917GHz 333MHz 11.5x AthlonXP 2800+ (Barton) 2.083GHz 333MHz 12.5x AthlonXP 3000+ (Barton) 2.167GHz 333MHz 13x

Note: With CPU speed changing rapidly, there might be fastest CPU

on the market by the time you received this installation guide. This table is kindly for your references only.

CPU Core Frequency

EV6 Bus Clock Ratio

Note: VIAP

KT400A chipset supports 200/266/333MHz FSB with performance reaches maximum 333MHz EV6 system bus and supports 66MHz AGP clock, higher clock setting may cause serious system damage.

Warnin g: Supposed you have had adjusted CPU ratio on your current CPU, and you plan to replace it with a new CPU. Please use <Home> key or Clear CMOS to restore the default setting after reinstalling a new CPU.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAOOppeenn ““WWaattcchh DDoogg AABBSS””

HTU FSBUT H frequency by user’s setting that stored in the BIOS. If system failed in BIOS POST, the “Watch Dog ABS” will reset

CPU the system to reboot in five seconds. Then, BIOS will detect the CPU’s default frequency and POST again. With this special feature, you can easily overclock your system to get higher system performance without removing the cover of system housing, and be able to set the jumper to clear CMOS data when your system hanged.

AOpen

Watch Dog ABS

Enable/Disable Signal

With this motherboard, AOpen provides a very special, useful feature for overclockers. When you power-on the system, the BIOS will check last system succeeded, the BIOS will enable “Watch Dog ABS” function immediately, and set the

from BIOS

BIOS

Reset Signal

Clock Generator

Countdown about 5 seconds if fails in POST

CPU

HTUPOSTU TH status. If it

CPU ID Signal

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCPPUU aanndd HHoouussiinngg FFaann CCoonnnneeccttoorr ((wwiitthh HH//WW MMoonniittoorriinngg)

Plug in the CPU fan cable to the 3-pin CPUFAN connector. If you have chassis fan, you can also plug it on SYSFAN1 (FAN1) or SYSFAN2 (FAN2) connector.

SYSFAN2 Connector

GND +12V SENSOR

SYSFAN1 Connector

CPUFAN Connector

Note: Some CPU fans do not have sensor pin, so that cannot support fan monitoring.

)

GND +12V SENSOR

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

DDIIMMMM SSoocckkeettss

This motherboard has three 184-pin DDR HDIMMH sockets that allow you to install HUDDR266UHU/UHU333U HU /400U memory up to 3 GB. Non-ECC DDR RAM is supported. Otherwise, it will cause serious damage on memory sockets or RAM module.

Warning: This motherboard supports DDR RAM. Please do not install the SDRAM on the DDR RAM sockets; otherwise it will cause serious damage on memory sockets or RAM module.

Note: According to the standard DDR400 specification from JEDEC (Joint Electron Device Engineering Council), it is regulated that DDR400 supports only 2x DIMM on the memory module for a maximum 2GB capacity, and DDR333 supports up to 3x DIMM for a maximum of 3GB capacity. Please be noted that KT400A motherboards follow this standard specification on memory as well.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

HHooww ttoo IInnssttaallll MMeemmoorryy MMoodduulleess

Please follow the procedure as shown below to finish memory installation.

1. Make sure the DIMM module’s pin face down and match the socket’s size as depicted below.

2. Insert the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place.

3. Repeat step 2 to finish additional DIMM modules installation.

Tab

Key

40 pins 52 pins

Note: The tabs of the DIMM slot will close-up to hold the DIMM in place when the DIMM touches the slot’s bottom.

Pin 1

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AATTXX PPoowweerr CCoonnnneeccttoorr

The ATX power supply uses 20-pin connector shown below. Make sure you plug in the right direction.

AACC PPoowweerr AAuuttoo RReeccoovveerryy

A traditional ATX system should remain at power off stage when AC power resumes from power failure. This design is inconvenient for a network server or workstation, without an UPS, that needs to keep power-on. This motherboard implements an AC Power Auto Recovery function to solve this problem.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IIDDEE aanndd FFllooppppyy CCoonnnneeccttoorr

Connect 34-pin floppy cable and 40-pin IDE cable to floppy connector and IDE connectors. Be careful of the pin1 orientation. Wrong orientation may cause system damage.

Pin 1

FDD Connector

IDE 1 (Primary)

IDE 2 (Secondary)

Pin 1

ATA 66/100/133

IDE Connector

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IDE1 is also known as the primary channel, IDE2 is known as the secondary channel. Each channel supports two IDE devices that make a total of four devices. In order to work together, the two devices on each channel must be set differently to Master and Slave mode. Either one can be the hard disk or the CDROM. The setting as master or slave mode depends on the jumper on your IDE device, so please refer to your hard disk and CDROM manual accordingly.

Warning: The specification of the IDE cable is a maximum of 46cm (18 inches); make sure your cable does not exceed this length.

Tip:

1. For better signal quality, it is recommended to set the far end side device to master mode and follow the suggested sequence to install your new device. Please refer to above diagram

2. To achieve the best performance of Ultra DMA 66/100/133 hard disks, a special 80-wires IDE cable for Ultra DMA 66/100/133 is required.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AATTAA113333 SSuuppppoorrtteedd

This motherboard supports HTUATA66UT H, HTU ATA100UTH or H TU ATA133UTH IDE devices. Following table lists the transfer rate of IDE PIO and DMA modes. The IDE bus is 16-bit, which means every transfer is two bytes. As the hard drive industry introduces faster and higher capacity hard drives, the current Ultra ATA/100 interface causes a data bottleneck between the drive and the host computer. To avoid this problem, hard disk manufacturers have introduced the new Ultra ATA-133 interface technology. Compared to traditional ATA/100, ATA/133 has up to 33 percent increase in interface speed with transfer rate of 133MB/s. ATA/133 performance is ideal for new operating systems, such as Window XP, that demand more storage space and faster data transfer rates from more responsive computing experiences. To make good use of this new technology and enjoy its best performance, we recommend you to pair your system with a hard disk equipped with ATA/133 technology so that your system's need for speed on this motherboard can be satisfied.

Mode Clock Period Clock Count Cycle Time Data Transfer Rate

PIO mode 0 30ns 20 600ns (1/600ns) x 2byte = 3.3MB/s PIO mode 1 30ns 13 383ns (1/383ns) x 2byte = 5.2MB/s PIO mode 2 30ns 8 240ns (1/240ns) x 2byte = 8.3MB/s PIO mode 3 30ns 6 180ns (1/180ns) x 2byte = 11.1MB/s PIO mode 4 30ns 4 120ns (1/120ns) x 2byte = 16.6MB/s DMA mode 0 30ns 16 480ns (1/480ns) x 2byte = 4.16MB/s DMA mode 1 30ns 5 150ns (1/150ns) x 2byte = 13.3MB/s DMA mode 2 30ns 4 120ns (1/120ns) x 2byte = 16.6MB/s ATA33 30ns 4 120ns (1/120ns) x 2byte x 2 = 33MB/s ATA66 30ns 2 60ns (1/60ns) x 2byte x 2 = 66MB/s ATA100 20ns 2 40ns (1/40ns) x 2byte x 2 = 100MB/s ATA133 15ns 2 30ns (1/30ns) x 2byte x 2 = 133MB/s

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

FFrroonntt PPaanneell CCoonnnneeccttoorr

IDE LED

SPEAKER

Attach the power LED, speaker, power and reset switch connectors to the corresponding pins. If you enable “Suspend Mode” item in BIOS Setup, the ACPI & Power LED will keep flashing while the system is in suspend mode.

Locate the power switch cable from your ATX housing. It is 2-pin female connector from the housing front panel. Plug this connector to the soft-power switch connector marked SPWR.

Suspend Type ACPI LE D

Power on Suspend (S1) Blinking between green and red

Suspend to RAM (S3) or Suspend to Disk (S4) Blinking between green and red

Power Switch

ACPI & Power LED

RESET

IDE LED IDE LED

SPEAKER

NC NC

+5V

+5V +5V

GND

SPWR GND ACPILEDGND ACPILED+ NC NC GND RESET GND

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IIrrDDAA CCoonnnneeccttoorr

The IrDA connector can be configured to support wireless infrared module, with this module and application software such as Laplink or Windows 98 Direct Cable Connection, the user can transfer files to or from laptops, notebooks, PDA devices and printers. This connector supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).

Install the infrared module onto the IrDA connector and enable the infrared function from BIOS Setup, UART2 Mode, make sure to have the correct orientation when you plug in the IrDA connector.

Pin 1

IR_TX

IrDA Connector

+5V

KEY GND IR_RX

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAGGPP ((AAcccceelleerraatteedd GGrraapphhiicc PPoorrtt)) 88XX EExxppaannssiioonn SSlloott

The AK77-400G / AK77-400GN provides an HTU AGPUTH 8X slot. The AGP 8X is a bus interface targeted for high-performance 3D graphic. AGP supports only memory read/write operation and single-master single-slave one-to-one only. AGP uses both rising and falling edge of the 66MHz clock, for 4X AGP, the data transfer rate is 66MHz x 4bytes x 4 = 1056MB/s. AGP is now moving to AGP 8X mode, which is 66MHz x 4bytes x 8 =2.1GB/s.

Warning: It is strongly recommended not to install a 3.3V AGP card, which is not supported by

Apollo KT400A

VIA chipsets.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

WWOOLL ((WWaakkee oonn LLAANN)) CCoonnnneeccttoorr

To use Wake On LAN function, you must have a network card with chipset that supports this feature, and connect a cable from LAN card to motherboard WOL connector. The system identification information (probably IP address) is stored on network card and because there is a lot of traffic on the Ethernet, you need to install network management software, such as ADM, for the checking of how to wake up the system. Note that, at least 600mA ATX standby current is required to support the LAN card for this function.

+5VSB GND LID

WOL Connector

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

WOL Connector

(Motherboard Side)

Note: This picture is for example only; it may not exactly be the same motherboard.

WOL Connector

(Ethernet Card Side)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

1100//110000 MMbbppss LLAANN oonnbbooaarrdd ((ffoorr AAKK7777--440000GGNN)

On the strength of Realtek LAN controller on board, this motherboard provides 10/100 Mbps Ethernet for office and home use. The Ethernet RJ45 connector is located on top of USB connectors. The orange LED indicates the link mode, it lights when linking to network. The green LED indicates the transfer mode and it lights when data is transferring in 100 Mbps. To enable or disable this function, you may simply adjust it through BIOS.

Green/Transfer

)

Orange/Link

(Op

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

SS//PPDDIIFF ((SSoonnyy//PPhhiilliippss DDiiggiittaall IInntteerrffaaccee)) CCoonnnneeccttoorr

S/PDIF (Sony/Philips Digital Interface) is a latest audio transfer file format that provides impressive quality through optical fiber and allows you to enjoy digital audio instead of analog. Normally there are two S/PDIF outputs as shown, one for RCA connector, the most common one used for consumer audio products, and the other for optical connector with a even better audio quality. Through a specific audio cable, you can connect the S/PDIF connector to a S/PDIF audio module bearing S/PDIF digital output. However, you must have a S/PDIF supported speaker with S/PDIF digital input to make the most of this function.

(RCA)

S/PDIF OUT

S/PDIF IN

S/PDIF OUT

S/PDIF IN

tical)

S/PDIF Module

(User Upgrade Optional)

S/PDIF Cable

Pin 1

+5V NC SPDIFOUT GND SPDIFIN

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

SSuuppeerr 55..11 CChhaannnneell AAuuddiioo EEffffeecctt

This motherboard comes with an ALC650F Codec which supports high quality of 5.1 Channel audio effect, bringing you a brand new audio experience. On the strength of the innovative design of ALC650F, you're able to use standard line-jacks for surround audio output without connecting any external module. To apply this function, you have to install the audio driver in the Bonus Pack CD as well as an audio application supporting 5.1 Channel. Picture below represents the standard location of all speakers in 5.1 Channel sound track. Please connect the plug of your front speakers to the green “Speaker out” port, rear speakers’ plug to the blue “Line in” port and both of the center and subwoofer speakers to the red “MIC in” port.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

SSuuppppoorrtt SSiixx UUSSBB 22..00 PPoorrtt

This motherboard provides six HTU USBUT H 2.0 ports to connect USB devices, such as mouse, keyboard, modem, printer, etc. There are four ports on the PC99 back panel and one header on board. Please note that USB 2.0, with fancy speed up to 480Mbps, is 40 times faster than the traditional ones. Except for the speed increase, USB 2.0 supports old USB 1.0/1.1 software and peripherals, offering impressive and even better compatibility to customers.

Pin 1

USB 2.0 Connector

+5V

SBD2-

SBD2+

GND

KEY

USB 2.0 Connector

+5V SBD3SBD3+ GND NC

Note: Please note that if you would like to use USB devices (Example: keyboard, mouse etc.) under DOS environment, you must install driver that comes with the devices to make it work.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCoolloorr CCooddeedd BBaacckk PPaanneell

The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, serial ports COM1 and COM2, RJ45 LAN Jack, Printer, HTUUSBUT H, AC 97 sound. The view angle of drawing shown here is the back panel of the housing.

PS/2 Keyboard: For standard keyboard, which use PS/2 plug. PS/2 Mouse: For PC-Mouse, which use PS/2 plug. USB Port: Available for connecting USB devices. Parallel Port: To connect with SPP/ECP/EPP printer. COM1/COM2 Port: To connect with pointing devices, modem or others serial devices. Speaker Out: To External Speaker, Earphone or Amplifier. Line-In: Comes from the signal sources, such as CD/Tape player. MIC-In: From Microphone.

PS/2 Mouse

Connector

PS/2 Keyboard

Connector

USB Port

(2.0)

SPP/EPP/ECP

Parallel Port

COM 1 Port COM 2 Por t

(AK77-400GN only)

RJ45 LAN Jack

Line-In

Speaker Out

MIC-In

USB Port

(2.0)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

FFrroonntt AAuuddiioo CCoonnnneeccttoorr

If the housing has been designed with an audio port on the front panel, you’ll be able to connect onboard audio to front panel through this connector. By the way, please remove 5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the cable. Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on the front panel.

Pin 1

AUD_MIC AUD_MIC_BIAS AUD_FPOUT_R

AUD_FPOUT_L

AUD_GND AUD_VCC AUD_RET_R KEY AUD_RET_L

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCaassee OOppeenn CCoonnnneeccttoorr

The “CASE OPEN” header provides chassis intrusion-monitoring function. To make this function work, you have to enable it in the system BIOS, connect this header to a sensor somewhere on the chassis. So, whenever the sensor is being triggered by light or opening of the chassis, the system will send out beep sound to inform you. Please be informed that this useful function only applies to advanced chassis, you may purchase an extra sensor, attach it on your chassis, and make a good use of this function.

Pin 1

Case Open

Sensor Connector

SENSOR

GND

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

CCDD AAuuddiioo CCoonnnneeccttoorr

This connector is used to connect CD Audio cable from CD-ROM or DVD drive to onboard sound.

R GND GND

CD-IN Connector

Note: Though the latest version of Windows supports “Digital Audio” through IDE bus, in order to use Open Jukebox player, which is driven under BIOS, it is a MUST to insert audio cable to CD-IN connector on the motherboard.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAUUXX--IINN CCoonnnneeccttoorr

This connector is used to connect MPEG Audio cable from MPEG card to onboard sound.

R GND GND

AUX-IN Connector

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

+5V

JAB1

JACX

GND GND

JACY

JAB2

+5V

+5V JBB1 JBCX MIDI_TXD JBCY JBB2 MIDI_RXD KEY

GGaammee PPoorrtt BBrraacckkeett SSuuppppoorrtteedd

This motherboard comes with a game port (Joystick-Midi) for you to connect any midi devices or joysticks. To use this function you have to have a joystick module and connect it with a game port cable to this port on the motherboard.

Note: This picture is for example only; it may not exactly look the same with the motherboard you purchased.

Joystick Module

(User Upgrade Optional)

Pin1

(

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Clear

CMOS

Tip: When should I Clear CMOS?

1. Boot fails because of overclocking…

2. Forget password…

3. Troubleshooting…

JJPP1144 CClleeaarr CCMMOOSS DDaattaa JJuummppeerr

You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedures below.

1. Turn off the system and unplug the AC power.

2. Remove ATX power cable from connector PWR2.

3. Locate JP14 and short pins 2-3 for a few seconds.

4. Return JP14 to its normal setting by shorting pin 1 & pin 2.

5. Connect ATX power cable back to connector PWR2.

Pin 1

Normal default)

(

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

JJPP2211 KK77 HHoosstt CClloocckk SSeelleeccttiioonn

This jumper is used to specify the relationship of PCI and HFSBH clock. Generally speaking, if you are not an over-clocker, we recommend you to set it to the default setting. Additionally, this motherboard also provides “1MHz Stepping Adjustment” feature for overclockers to adjust CPU FSB frequency via BIOS setup program. If you fix the CPU FSB frequency by JP21, the “1MHz Stepping Adjustment” range will be changed according to what type of CPU you use.

JP 21 CPU FSB Range

1-2

(default)

2-3 / 100-129 MHz

133 MHz 130-160 MHz 166 MHz 161-191 MHz 200 MHz 200-248 MHz

Pin 1

JP21 K7 Host Clock

Select Jumper

Auto detect

default)

100MHz

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

JJPP2288 KKBB//MMoouussee WWaakkee--uupp JJuummppeerr

This motherboard provides keyboard / mouse wake-up function. You can use JP28 to enable or disable this function, which could resume your system from suspend mode with keyboard or mouse installed. The factory default setting is set to “Disable” (1-2), and you may enable this function by setting the jumper to pin2-3.

JP28 KB/Mouse

Wake-up Jumper

Disable

(Default)

Enable

Pin 1

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

SSTTBBYY LLEEDD

STBY LED is AOpen’s considerate design that aims at providing you friendly system information. The STBY LED will light up when power is provided to the motherboard. This is a convenient indication for you to check the system power status in many circumstances such as power on/off, stand-by mode and RAM power status during Suspend to RAM mode.

System

Power LED

Warning: Do not install or remove the DIMM module or others devices when the STBY LED lights on.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAGGPP PPrrootteeccttiioonn TTeecchhnnoollooggyy aanndd AAGGPP LLEEDD

With the outstanding R&D ability of AOpen and its specially developed circuit, this model implements a blend new technology to protect your motherboard from being damaged by over-voltage of AGP card. When AGP Protection Technology is implemented, this motherboard will automatically detect the voltage of AGP card and prevent your chipsets from being burnt out. Please note that if you install a AGP card with 3.3V, which is not supported, the AGP LED on the motherboard will light up to warn you the possible damage of the exceeding voltage. You may contact your AGP card vendor for further support.

Warning: It is strongly recommended not to install a 3.3V AGP card, which is not supported. When you do so, the AGP LED on the motherboard will light up to warn you the possible damage.

AGP LED

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Auto Sw itc h

RTC

CMOS

Battery

Auto switching to ATX standby power as long as AC power line is plugged. This smart design can increases battery life if you still had battery plugged on motherboard.

Backup by EEPROM

BBaatttteerryy--lleessss aanndd LLoonngg LLiiffee DDeessiiggnn

This Motherboard implements HTUFlash ROMUT H and a special circuit that allows you to save your current CPU and CMOS Setup configurations without using the battery. The RTC (real time clock) can also keep running as long as the power cord is plugged. If you lose your CMOS data by accident, you can just reload the CMOS configurations from Flash ROM and the system will recover as usual.

Flash

ROM

ATX Stand-by Power

(Real Time Clock)

00:00:00

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

3333000

The quality of low ESR capacitor (Low Equivalent Series Resistance) during high frequency operation is very important for the stability of CPU power. The idea of where to put these capacitors is another know-how that requires experience and detail calculation.

Not only that, this motherboard implements 3300μF capacitor, which is much larger than normal capacitor (1000 or 1500μF) and it provides better stability for CPU power.

LLooww EESSRR CCaappaacciittoorr

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

The power circuit of the CPU core voltage must be checked to ensure system stability for high speed CPUs (such as the Pentium IV, or when overclocking). A typical CPU core voltage is 2.0V, so a go od design should control voltage between 1.860V and 2.140V. That is, the transient must be below 280mV. Below is a timing diagram captured by a Digital Storage Scope, it shows the voltage transient is only 143mv even when maximum 60 current is applied.

Note: This diagram for example only; it may not exactly be the same motherboard.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

AAOOCCoonnffiigg UUttiilliittyy

AOpen always dedicated to provide users a much friendlier computer environment. We now bring

you a comprehensive system detective utility. AOconfig is a Windows based utility with user-friendly interface that allows users to obtain information of the operation system and hardware such as motherboard, CPU, memory, PCI devices and IDE devices. The powerful utility also displays the version of BIOS and firmware for your convenience of maintenance.

Moreover, AOconfig allows users to save information in *.BMP or *.TXT format which users may collect the system information in detail and send them to AOpen directly for technical support or further diagnosis of system problem.

1. The system page shows the detail information of the motherboard, the operating system, the processor, and BIOS version.

2. The PCI device page shows the configurations of all PCI devices installed on your motherboard.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

NOTE: AOconfig can be used in Windows 98SE/ME, NT4.0/2000, or Windows XP. Please be informed that

Oconfig can only be operated in a system equipped with an AOpen motherboard. Meanwhile, all applications must

be closed before starting AOconfig.

3. This page presents the IDE devices information, such as the serial number, the manufacturer, the firmware version, and capacity.

4. From this page, users may obtain the technical support information of AOpen.

Moreover, detailed information could be saved in .bmp or .txt format.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

EEzzCClloocckk

Have you ever thought how great it would be if you can adjust the frequency setting on your motherboard under Windows environment and be a real master of your system? Everybody knows that the ratio and frequency setting are key factors to influence the system performance; however, it’s absolutely not an easy task for an amateur to adjust the setting value. On most traditional motherboards, you have to get into BIOS screen for the frequency and reboot the system again and again. But from now on, you don’t surfer the boring stuffs anymore.

With brand-new and user-friendly EzClock that AOpen specially designs for his users, you can adjust those important values as you please and think of suitable. This tailor-made EzClock allows you to set the voltage and frequency of CPU, VGA, PCI and memory under Windows environment as well as in BIOS setting page; even better, those settings will be displayed real-time. Having this handy EzClock, you can monitor the system when you’re fine-tuning the performance of your system. It provides you detailed and necessary information. Now let’s take a look how it works on utility, BIOS and POST.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

How You Adjust the Settings in EzClock Utility

In EzClock utility, you can adjust CPU Front Side Bus (FSB), the voltage and frequency of VGA, AGP, PCI and DRAM. Besides, the CPU related information such as CPU voltage, temperature and CPUFAN rotation speed will also be displayed on this utility.

CPU Color Bars:

The color bar will light on and show different colors as values change. On default values, it will show green.

On the right part of the panel is the section that you adjust the settings of VGA, AGP, PCI and memory. To adjust the voltage and clock frequency of those installments, you can press “-“ or “+” on corresponding items. The color parts represent the situation of values. The higher value you set, the light on the color bar goes to right and turns red. After finishing those value settings, you can press “Apply” button on the upper right hand corner to save changes to CMOS.

VGA, AGP, PCI and DRAM Voltage / Clock Area:

Pressing “_” and “+” buttons, you can adjust the voltage and clock frequency values of onboard VGA, AGP, PCI and DRAM.

On the left circle area shows Ratio, FSB and frequency information about CPU. When the values are set to factory default, the light on the top and bottom of the circle will show green and it will vary as you change these CPU settings.

CPU Ratio, FSB and frequency displaying area: You can adjust CPU FSB here by entering preferred value.

Control buttons:

“_” button allows you to minimize the utility and “X” button to close the utility. Pressing “Apply” button you can save the changes to CMOS.

grey

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

On the bottom rectangular panel represents CPU fan speed, CPU voltage and CPU temperature. The three color bars on the right hand side will light on according to operation temperature. Please refer to the picture shown above.

CPU Color Bars: The color bars will light on according to CPU operation

erature.

tem

CPU Fan, Voltage and Temperature:

representing CPU fan speed, CPU voltage and CPU temperature in Celsius and Fahrenheit degrees.

How You Adjust the Settings in BIOS

Apart from EzClock utility, the voltage and frequency values of CPU, PCI and memory can also be adjusted on BIOS page. By pressing “+”, “-“, “PgUp” or “PgDn” keys, you can adjust the frequency values of CPU Bus, PCI Bus and DRAM.

Also, the same keys help you adjust the voltage of CPU and DDR settings. Some values may change while you adjust the settings. You can press “F10” to save the changes you’ve made.

Function Keys Description

Note: The items provided by EzClock

Utility vary in different motherboards. The unavailable function in your motherboard will present in

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

How Your Boot Screen Looks Like

After you finish setting BIOS, these setting values will be displayed on the boot screen like the shown picture here.

Every time you boot your system, both default and current settings will pop up on the screen. Your personal settings that had been adjusted earlier will be highlighted; thus, you can have clear idea how your system functions and monitor your system more easily.

Current values of your system

NOTE: Due to BIOS versions are updated in an extremely fast speed, it's strongly recommended to download the latest version of EzClock from our website for best compatibility.

Default settings of this motherboard

The highlighted setting value you manually

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

PPHHOOEENNIIXX--AAWWAARRDD BBIIOOSS

System parameters can be modified by going into HTUBIOSU TH Setup menu, this menu allows you to configure the system parameters and save the configuration into the 128 bytes CMOS area, (normally in the RTC chip or in the main chipset).

The Phoenix-Award BIOS™ that installed in the BIOS. The BIOS provides critical low-level support for standard devices such as hard disk drives, serial and parallel ports.

Most BIOS setting of this motherboard had been optimized by AOpen’s R&D engineering team. But, the default setting of BIOS still can’t fine-tune the chipset controlling entire system. Hence, the rest of this chapter is intended to guide you through the process of configuring your system using setup.

Currently there are two kinds of beep sound when system fails to boot at POST. The first type of beep sound consists of a single long beep and two short beeps, indicating a video error has failed BIOS from initializing video screen for displaying any additional information. The 2 occurred. You may look over the indicated error according to different beep significances.

HTUTo enter to BIOS setup menuUTH, press <Del> when HTUPOST (Power-On Self Test)UTH screen is shown on your monitor.

type of beep sound is a single long beep that beeping repeatedly, signaling a DRAM error has

Note: Because the BIOS code is the most often changed part of the motherboard design, the BIOS information contained in this manual may be different with actual BIOS that come with your motherboard.

HTU Flash ROM UTH of the motherboard is a custom version of an industry standard

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

HHooww TToo UUssee PPhhooeenniixx--AAwwaarrdd™™ BBIIOOSS SSeettuupp PPrrooggrraamm

Generally, you can use arrow keys to highlight items that you want to choose, then press <Enter> key to select, and use the <Page Up> and <Page Down> key to change setting values. You can press <Esc> key to quit Phoenix-Award™ BIOS setup

program. The following table provides details about how to use keyboard in the Phoenix-Award BIOS setup program.

Key Description

Page Up or + Changing setting to next value or increase the value. Page Down or - Changing setting to previous value or decrease value. Enter Select the item. Esc 1. In main menu: Quit and don’t save any change.

2. In sub menu: Exit current menu to main menu. Up Arrow Highlight previous item. Down Arrow Highlight next item. Left Arrow Move the light bar to left side of menu. Right Arrow Move the light bar to right side of menu. F6 Load Setup Default setting value from CMOS. F7 Load turbo setting value from CMOS. F10 Save changed setting and exit setup program.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

HHooww TToo EEnntteerr BBIIOOSS SSeettuupp

After you finish the setting of jumpers and connect correct cables. Power on and enter the BIOS Setup, press <Del> duringHTU

POST (Power-On Self Test)UT H. Choose "HT ULoad Setup Defaults"UT H for recommended optimal performance.

Del

Warning: Please avoid of using "Load Turbo Defaults", unless you are sure your system components (CPU, RAM, HDD, etc.) are good enough for turbo setting.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

BBIIOOSS UUppggrraaddee uunnddeerr WWiinnddoowwss eennvviirroonnmmeenntt

With outstanding R&D ability of AOpen, we now bring you a whole new BIOS Flash wizard ---- EzWinFlash. With an eye to users convenience, EzWinFlash combines the

BIOS binary code and flash module together, so the only thing you have to do is just clicking on the utility you downloaded from web and let it helps you complete the flash process automatically. EzWinFlash detects your motherboard and checks the BIOS version cleverly to prevent your system from any possible failure. Moreover, EzWinFlash has been taken into consideration to go with any windows platform you might be using, no matter if you’re using Windows 95/98, 98SE/ME, NT4.0/2000, or Windows XP.

In the meanwhile, in order to provide a much more user-friendly operating environment, AOpen EzWinFlash is natively designed to have multi-language function to provide easier way for users’ usage in changing BIOS setting.

Note: The model name on this BIOS picture is for reference only. It may not be the exact model name.

TCaution: T By updating your motherboard, you

are taking a risk of BIOS flash failure. If your motherboard is working stable, and there are no major bugs that had been fixed by a latter BIOS revision, we recommend that you DO NOT try to upgrade your BIOS.

If you intent on upgrading, PLEASE BE SURE to get the right BIOS revision for the right motherboard model to avoid any possibility failure.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

You may accomplish BIOS upgrade procedure with EzWinFlash by the following steps, and it’s STRONGLY RECOMMENDED to close all the applications before you start the upgrading.

1. Download the new version of BIOS package

2. Unzip the download BIOS package (ex: WAK77400GN102.ZIP) with WinZip ( environment.

3. Save the unzipped files into a folder, for example, WAK77400GN102.EXE & WAK77400GN102.BIN.

4. Double click on the WAK77400GN102.EXE, EzWinFlash will detect the model name and BIOS version of your motherboard. If you had got the wrong BIOS, you will not be allowed to proceed with the flash steps.

5. You may select preferred language in the main menu, then click [Start Flash] to start the BIOS upgrade procedure.

6. EzWinFlash will complete all the process automatically, and a dialogue box will pop up to ask you to restart Windows. You may click [YES] to reboot Windows.

7. Press <Del> at POST to

It is strongly recommended NOT to turn off the power or run any application during FLASH PROCESS.

Warning: The new BIOS upgrade will permanently replace your original BIOS’s settings when flashing. You may need to reconfigure your BIOS setting so that your system can go back to work as normal.

HTUenter BIOS setupU TH , choose "Load Setup Defaults", then “Save & Exit Setup”. Done!

HzipH file from AOpen official web site. (ex: HUhttp://english.aopen.com.tw/UH)

HUhttp://www.winzip.comUH) in Windows

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

VViivviidd BBIIOOSS tteecchhnnoollooggyy

Unlike earlier graphic POST screen that could occupy the whole screen and mask text information during POST, AOpen VividBIOS deals with graphics and texts separately, and makes them running simultaneously during POST. With this innovative design, VividBIOS now brings you a beautiful and sleek 256 colours screen without missing any important information shown on POST screen.

In addition, the limited space of BIOS ROM is another big issue. When all of the traditional BIOS can only show space-consuming and uncompressed Bitmap, AOpen has considerately tuned the BIOS to next generation, to recognize the smaller-sized GIF format and even dynamic-showing GIF animation.

Vivid BIOS shares the same fundamental technology with Open JukeBox CD Player, you may use the same EzSkin utility to

change your Vivid BIOS screen or to download your favourite Open JukeBox skin. If you see this little logo your model name on the BIOS download page, supports this innovative feature!

Have you been fed up with the conservative and immutable POST screen? Let’s rule out the tradition idea that POST screen are stiff and frigid, and let AOpen show you the newly developed VividBIOS to experience the lively vivid colourful POST screen!

shown beside

HTU http://download.aopen.com.tw/downloadsUTH, it is assured that your motherboard

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

DDrriivveerr aanndd UUttiilliittyy

There are motherboard drivers and utilities included in AOpen Bonus CD. You don’t need to install all of them in order to boot your system. But after you finish the hardware installation, you have to install your operation system first (such as Windows XP) before you can install any drivers or utilities. Please refer to your operation system’s installation guide.

AAuuttoo--rruunn MMeennuu ffrroomm BBoonnuuss CCDD

You can use the auto-run menu of Bonus CD. Choose the utility and driver and select model name.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IInnssttaalllliinngg VVIIAA 44 iinn 11 DDrriivveerr

You can install the VIA 4 in 1 driver (HT UIDE Bus masterU TH (For Windows NT use), VIA ATAPI Vendor Support Driver, VIA HTUAGPUTH , IRQ Routing Driver (For Windows 98 use), VIA Registry (INF) Driver) from the Bonus Pack CD auto-run menu.

Warning: To take advantage of ATA133, it is a must to install the latest version of VIA 4in1 driver in the Bonus CD. For Windows2000, it cannot support ATA133 even after installing the latest version of VIA 4-in-1 driver until the new release of Service-Pack 3 from Microsoft.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IInnssttaalllliinngg AAuuddiioo DDrriivveerr

This motherboard comes with RealTek ALC650F HT UAC97U TH HTU CODECUT H and the sound controller is in VIA South Bridge chipset. You can find the audio driver from the Bonus Pack CD auto-run menu.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IInnssttaalllliinngg LLAANN DDrriivveerr iinn WWiinnddoowwss 9988SSEE//MMEE//22000000//XXPP ((f

This motherboard comes with RealTek controller on board, which is a highly integrated Platform LAN connecting device providing 10/100 Mbps Ethernet for office and home use. You can install the LAN driver form the Bonus Pack CD auto-run menu.

foorr AAKK7777--440000GGNN))

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Installing LAN Driver in Windows 95 / NT 4.0

[Windows 95 (Golden version), Win95A and OSR2]

Installing driver procedure on Microsoft Windows 95:

--------------------------------------------------------------------

1. Ask you to select which driver you want to install, select "Driver from disk provided by hardware manufacturer".

2. Specify the setup file pathname [CD-ROM]:\Driver\LAN\RTL8100\Windows\95\WIN95A (for Windows 95 and Win95A) or [CD-ROM]:\Driver\LAN\RTL8100\Windows\95\W95OSR2 (for Windows 95 OSR2).

3. Windows 95 will appear some messages to insert Windows 95 system disk to complete setup step.

4. Windows 95 will finish the other installation procedure automatically, and then you restart the system.

[Windows NT 3.5, 3.51 & 4.0]

Installing driver procedure on Microsoft Windows NT:

--------------------------------------------------------------------When you are in Windows NT:

1. In the Main group of NT, select the "Control Panel" icon.

2. In the Control Panel window, choose the "Network" icon.

3. In the Network Settings dialog box, choose the "Add Adapter" button. The Add Network Adapter dialog box appears.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

4. In the list of network cards, select "<other> requires disk from manufacturer", and then press <Enter> button.

5. Enter drive and pathname [CD-ROM]:\Driver\LAN\RTL8100\Windows\NT (for NT 4.0) that is the path where the setup files OEMSETUP.INF is located, and

then chooses the OK button.

6. The screen will appear "Select Line Speed" dialog box that is provided by RTL8139.SYS driver. The default value is "auto" so that the RTL8139 PCI Fast Ethernet adapter and its driver RTL8139.SYS will auto-detect the line speed, 10 MB or 100MB, while the RTL8139.SYS is loading. The other values, "10" or "100", are only used when you want to forced RTL8139 PCI Fast Ethernet adapter to 10Mb or 100Mb.

7. The screen will appear "Input Ethernet ID" dialog box that is provided by RTL8139.SYS driver. This option is only required when you have more than one Realtek RTL8139 PCI Fast Ethernet adapters on this computer. Select "SKIP" if only one adapter is installed on this computer.

8. "Bus Location" display in next screen. Your machine contains more than one hardware bus; please select the Bus Type and Bus number on which your network adapter card is installed.

9. NT will then perform the binding process. If any additional network software options were installed, you may be prompted for specific information for these packages.

10. Restarting your system you will acquire network service.

NOTES:

---------* Installing Multiple LAN Adapters: Enter Windows NT and follow above setup procedure step 2, in the "Network Settings" dialog

box, choose the "Configure" button. The "Input Ethernet ID" dialog box appears and input adapter's Ethernet ID. Last step is to select OK and close NETWORK SETUP. Select SKIP if only one adapter is installed on this computer.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IInnssttaalllliinngg UUSSBB 22..00 DDrriivveerr

This motherboard comes with USB 2.0 function. You can install USB 2.0 Driver under Windows 98SE, Windows ME, Windows 2000 and Windows XP from the Bonus Pack CD auto-run menu.

Note: After installing USB 2.0 driver under WinME, there would be a "green question mark" on "VIA USB 2.0 Enhanced Host Controller" item. Please rest assured that it is not an error message. You may just ignore it.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

GGlloossssaarryy

AACC9977 CCOODDEECC

Basically, AC97 CODEC is the standard structure of PCI sound card. As we know, computer is digital-based, but music is based on analog-based. Therefore, there must be a process to turn digital into analog during the last stage processing of sound in computer. Hence, the component on sound card that play this important task is what we called CODEC.

Audio CODEC 97 (briefly called AC97) is the specification regulated by Intel, and it’s about the structure of audio conversion. The special place about CODEC is that it is separated from sound card (CODEC is an independent chipset). Therefore, PCI sound card could possess with 90db and do other application process as well. We called CODEC that meets this structure AC97 CODEC.

AACCPPII ((AAddvvaanncceedd CCoonnffiigguurraattiioonn && PPo

ACPI is the power management specification of PC97 (1997). It intends to save more power by taking full control of power management to operating system and bypass to operating system (such as Windows 98). This is a bit similar as the power switch to control the power state transition.

AACCRR ((AAddvvaanncceedd CCoommmmuunniiccaattiioonn RRiisseerr)

Building on the PC motherboard riser architecture, ACR slot is backward compatible with AMR but beyond the limitation of it. The ACR specification is designed to support modem, audio, Local Area Network (LAN) and Digital Subscriber Line (DSL).

owweerr IInntteerrffaaccee))

)

HTU BIOSUT H. The chipset or super I/O chip needs to provide standard register interface

HTUPnPU TH register interface. ACPI defines ATX momentary soft

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

)

AAGGPP ((AAcccceelleerraatteedd GGrraapphhiicc PPoorrtt)

The main function of AGP simply put is to tell monitor what screen information had to be shown, a visual transmission device actually. With the rapid developing of AGP card, we can see that it had been developed from single colorful AGP card to 2D and 3D graphic. AGP supports only memory read/write operation and single-master single-slave one-to-one only. Though AGP and PCI share the same algorithm of 32-bit, its frequencies are 66MHz and 33MHz respectively. AGP interface had been developed from 2X to 8x.

1X AGP, data transfer rate is 66MHz x 4byte x 1 = 264MB/s 2X AGP, data transfer rate is 66MHz x 4byte x 2 = 528MB/s 4X AGP, data transfer rate is 66MHz x 4byte x 4 = 1056MB/s. 8X AGP, data transfer rate is 66MHz x 4byte x 8 = 2112MB/s.

AAMMRR ((AAuuddiioo//MMooddeemm RRiisseerr)

The CODEC circuit of AC97 sound/modem solution can be put on motherboard or put on a riser card (AMR card) that connects to motherboard through AMR connector.

)

AATTAA ((AATT AAttttaacchhmmeenntt)

Before talking about ATA (AT Attachment), we must understand DMA (Direct Memory Access), which allows devices to skip the CPU devices and access memory directly. DMA specification could not only eliminate the workload of CPU, but also accelerate the transmission of data. DMA begins with a data transfer rate of 16.6MB/Sec, but afterward developed to new data rate of

33.3MB/Sec, which is twice the data rate and we called it Ultra DMA. ATA details power and data signals between the drive

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

and integrated drive controller and the computer's motherboard. Two drives (master and slave) are supported. The ATA specification allows the drive to connect directly to the ISA bus on the computer. ATA transfer rate then had been developed to 133MHz/Sec and would come out with fastest rate later (please refer toHTU Serial ATAUTH ).

DMA, data transfer rate is 16.6MHz/s. Ultra DMA, data transfer rate is 16.6MHz x 2 = 33MB/s. ATA/66, data transfer rate is 16.6MHz x 4 = 66MB/s. ATA/100, data transfer rate is 16.6MHz x 6 = 100MB/s. ATA/133, data transfer rate is 16.6MHz x 8 = 133MB/s.

(ATA/133 uses both rising edge and falling edge as ATA/66 but clock cycle time is reduced to 30ns.)

)

BBIIOOSS ((BBaassiicc IInnppuutt//OOuuttppuutt SSyysstteemm)

BIOS, is a set of assembly routine/program that reside in HTU EPROMUTH or HT UFlas h ROMU TH . BIOS controls Input/output devices and other hardware devices of motherboard. In general, to provide hardware independent portability, operation system and drivers is required to access BIOS without directly access hardware devices.

BBlluueettooootth

Bluetooth is a wireless transferring technology that enables short-range wireless connections between desktop and laptop computers, personal digital assistants (PDAs), cellular phones, printers, scanners, digital cameras and even home appliances. The principle of Bluetooth (a chipset) is to transfer information and voices at the frequency of ISM Band. Every Bluetooth technology devices do come with a standard address for you to connect one-to-one or one-to-seven (to form a Pico-net), with transferring range up to 10 meters (100 meters to follow), using low power radio. Bluetooth do not only possess

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

high transfer rate of 1MB/s, it also could be encrypted with pin code. With hopping rate of 1600 hops per second, it’s difficult to be intercepted and are less interrupted by electromagnetic wave.

)

CCNNRR ((CCoommmmuunniiccaattiioonn aanndd NNeettwwoorrkkiinngg RRiisseerr)

The CNR specification provides the PC industry the opportunity to deliver a flexible and cost reduced method of implementing LAN, home networking, DSL, USB, wireless, audio and modem subsystems widely used in today's "connected PCs". The CNR specification is an open industry specification and is supported by OEMs, IHV card manufacturers, silicon supplier and Microsoft.

DDDDRR ((DDoouubbllee DDaattaa RRaattee)) RRAAM

DDR RAM utilizes the existing HTUSDRAMUT H (For ex, PC-100, PC-133) infrastructure and technology while doubling the nominal bandwidth available to systems in an easy to design and simple to adopt way. Based on FSB frequency, DDR RAM on the market are DDR200, DDR266 and DDR333 with more coming around soon.

DDR200, transfer bandwidth up to 200x64/8=1600MB/s (PC1600) DDR266, transfer bandwidth up to 266x64/8=2100MB/s (PC2100) DDR333, transfer bandwidth up to 333x64/8=2700MB/s (PC2700) DDR400, transfer bandwidth up to 400x64/8=3200MB/s (PC3200)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

EECCCC ((EErrrroorr CChheecckkiinngg aanndd CCoorrrreeccttiioonn))

The ECC mode needs 8 ECC bits for 64-bit data. Each time memory is accessed; ECC bits are updated and checked by a special algorithm. The ECC algorithm has the ability to detect double-bit error and automatically correct single-bit error while parity mode can only detect single-bit error.

EEEEPPRROOMM ((EElleeccttrroonniicc EErraassaabbllee PPrrooggrraammmmaabbllee RROOMM)

Also known as EP technology is different. Size of EEPROM is much smaller than flash ROM.

EEPPRROOMM ((EErraassaabbllee PPrrooggrraammmmaabbllee RROOMM)

Traditional motherboard stores BIOS code in EPROM. EPROM can only be erased by ultra-violet (UV) light. If BIOS has to be upgraded, you need to remove EPROM from motherboard, clear by UV light, re-program, and then insert back.

EEVV66 BBuus

EV6 Bus is the technology of Alpha processor from Digital Equipment Corporation. EV6 bus uses both rising and falling clock edge to transfer data, similar as DDR RAM or ATA/66 IDE bus. EV6 Bus Speed = CPU external bus clock x 2.

200 MHz EV6 bus, 200MHz = 100 MHz external bus clock x 2

PROM. Both EEPROM andHTU Flash ROMU TH can be re-programmed by electronic signals, but the interface

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

)

FFCCCC DDooCC ((DDeeccllaarraattiioonn ooff CCoonnffoorrmmiittyy)

The DoC is component certification standard of FCC EMI regulations. This standard allows DIY component (such as motherboard) to apply DoC label separately without a shielding of housing.

)

FFCC--PPGGAA ((FFlliipp CChhiipp--PPiinn GGrriidd AArrrraayy)

FC means Flip Chip, FC-PGA is a package of Intel for Pentium III for 0.18µm process CPU, which can be plugged into SKT370 socket.

FFCC--PPGGAA22 ((FFlliipp CChhiipp--PPiinn GGrriidd AArrrraayy)

After FC-PGA, FC-PGA2 is the package for 0.13µm process CPU developed by Intel, which can be plugged into SKT423/478 socket as well.

FFllaasshh RROOM

Flash ROM can be re-programmed by electronic signals. It is easier for BIOS to upgrade by a flash utility, but it is also easier to be infected by virus. Because of increase of new functions, BIOS size is increased from 64KB to 512KB (4M bit).

HHyyppeerr TThhrreeaaddiinng

Hyper-Threading technology is an innovative design from Intel that enables multi-threaded software applications to process threads in parallel within each processor resulting in increased utilization of processor execution resources. As a result, an average improvement of ~40% in CPU resource utilization yields higher processing throughput.

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

IIEEEEEE 1133994

IEEE 1394, which also called Firewire, is a serial data transfer protocol and interconnection system. The main feature of the Firewire that assures its adoption for the digital video and audio (A/V) consumer application is its low cost. Fire wire interface is capable of supporting various high-end digital A/V applications, such as consumer A/V device control and signal routing, Digital Video (DV) editing, home networking, and more than 32 channels of digital mixing. Gone are those days of expensive video capture cards. Firewire allows for video capture from both newer DV camcorders with Firewire ports and older analog equipment using A/V to Firewire converters.

The advantages of the IEEE1394: High data transfer rate – Start from 400 Mbps, (with 800/1600/3200 Mbps coming soon), which is about 30 times faster than

USB 1.1. Supports up to 63 devices (16 - daisy chained) with cable length up to about 4.5 m (14 feet). Hot-pluggable (like USB). No need to turn of your device to connect or disconnect, and you don't need to reboot your PC. Also,

it is a plug-and-play bus. IEEE1394 is very easy to connect (Like USB1.1/2/0).

PPaarriittyy BBiit

The parity mode uses 1 parity bit for each byte, normally it is even parity mode, that is, each time the memory data is updated, parity bit will be adjusted to have even count "1" for each byte. When next time, if memory is read with odd number of "1", the parity error is occurred and this is called single bit error detection.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

PPCCII ((PPeerriipphheerraall CCoommppoonneenntt IInntteerrffaaccee)) BBuus

Developed by Intel, Peripheral Component Interconnect (PCI) is a local bus standard. A bus is a channel used to transfer data to (input) and from (output) a computer and to or from a peripheral device. Most PCs have a PCI bus usually implemented at 32-bits providing a 33 MHz clock speed with a throughput rate of 133 MBps.

PPDDFF FFoorrmmaat

With PDF file, it is easy to do universal document exchange. Virtually any document may be converted in Portable Document Format (PDF). Contents in PDF documents are exactly the same as the original file, including fonts and graphics, and they can be distributed by e-mail or stored on the World Wide Web, an intranet, a file system, or a CD-ROM for other users to view on any platforms. You may download Acrobat Reader in order to read PDF file from its website (

PPnnPP ((PPlluugg aanndd PPllaayy)

Oversimplified, Plug-and-Play automatically tells the software (device drivers) where to find various pieces of hardware (devices) such as modems, network cards, sound cards, etc. Plug-and-Play's task is to match up physical devices with the software (device drivers) that operates them and to establish channels of communication between each physical device and its driver.

PPOOSSTT ((PPoowweerr--OOnn SSeellff TTeesstt)

The BIOS self-test procedure after power-on, sometimes, it is the first or the second screen shown on your monitor during system boot.

)

HTUwww.adobe.comUTH ).

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

PPSSBB ((PPrroocceessssoorr SSyysstteemm BBuuss)) CClloocck

PSB Clock means the external bus clock of CPU. CPU internal clock = CPU PSB Clock x CPU Clock Ratio

RRDDRRAAMM ((RRaammbbuuss DDyynnaammiicc RRaannddoomm AAcccceessss MMeemmoorryy)

A DRAM technology developed by Rambus Corporation*, to achieve high speed of memory through the use of multiple channels in parallel by 16-bits. Basically, RDRAM uses new structure of Multibank, which is quite different from FPM, EDO, SDRAM. Using different memory module as well, RDRAM uses “RIMM” with transfer rate of 600/700/800MHz, providing bandwidth as high to 1.6GB.

RRIIMMMM ((RRaammbbuuss IInnlliinnee MMeemmoorryy MMoodduullee)

184-pin memory module that supports HTURDRAMUTH memory technology. A RIMM memory module may contain up to maximum of 16 RDRAM devices.

SSDDRRAAMM ((SSyynncchhrroonnoouuss DDRRAAMM))

SDRAM is one of the DRAM technologies that allow DRAM to use the same clock as the CPU host bus (EDO and FPM are asynchronous and do not have clock signal). It is similar as PBSRAM to use burst mode transfer. SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V, and have been gradually replaced by DDR RAM.

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

)

SSAATTAA ((SSeerriiaall AATTAA)

The Serial ATA specification is designed to overcome speed limitations while enabling the storage interface to scale with the growing media rate demands of PC platforms. Serial ATA is to replace parallel systems and drivers, adding performance headroom for years to come. It is developed with data transfer rate of 150 Mbytes/second, and 300M/bs, 600M/bs to come. It reduces voltage and pins count requirements and can be implemented with thin and easy to route cables.

SSMMBBuuss ((SSyysstteemm MMaannaaggeemmeenntt BBuuss)

SMBus is also called IP For example, set clock of clock generator for jumper-less motherboard. The data transfer rate of SMBus is only 100Kbit/s, it allows one host to communicate with CPU and many masters and slaves to send/receive message.

SSPPDD ((SSeerriiaall PPrreesseennccee DDeetteecctt)

SPD is a small ROM or HTUEEPROMU TH device resided on the DIMM or HTURIMMU TH . SPD stores memory module information such as DRAM timing and chip parameters. SPD can be used by

UUSSBB 22..00 ((UUnniivveerrssaall SSeerriiaall BBuuss)

A Universal Serial Bus (USB) is an external bus (an interconnection) standard that supports data transfer rates of 12 Mbps. A single USB port can be used to connect up to 127 peripheral devices, such as mouse, modems and keyboards. Introduced in 1996, USB has completed replaced serial and parallel ports. It also supports plug-and-play installations and hot plugging Plug-and-play is the ability to add and remove devices to a computer while the computer is running and have the operating

HTU ATAUTH with the compatibility with existing operating

)

C bus. It is a two-wire bus developed for component communication (especially for semiconductor IC).

)

HTU BIOSUT H to decide best timing for this DIMM or RIMM.

)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

system automatically recognize the change. USB 2.0, which supports data transfer rates of 480 Mbps, has been widely used in motherboard these days.

)

VVCCMM ((VViirrttuuaall CChhaannnneell MMeemmoorryy)

NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements. VCM increases memory bus efficiency and performance of any DRAM technology by providing a set of fast static registers between the memory core and I/O pins. Using VCM technology results in reduced data access latency and reduced power consumption.

WWiirreelleessss LLAANN –– 880022..1111b

802.11 is a specification developed by IEEE and Wireless LAN technology, which is an interface between a wireless client and a base station or between two wireless clients.

802.11 family includes the following specifications and with more coming:

802.11 = 1 or 2 Mbps transmission in the 2.4 GHz band, using either frequency hopping spread spectrum (FHSS) or direct sequence spread spectrum (DSSS)).

802.11a = 54 Mbps in the 5GHz band, using orthogonal frequency division multiplexing)

802.11b (11 Mbps transmission in the 2.4 GHz band, using direct sequence spread spectrum (DSSS).

ZZIIPP ffiille

A compressed file format to reduce file size. To unzip file, run shareware PKUNZIP (HTUhttp://www.pkware.com/UTH) for DOS and other operating system or WINZIP (

HTU http://www.winzip.com/UTH) for windows environment.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TTrroouubblleesshhoooottiinngg

If you encounter any trouble to boot you system, follow the procedures accordingly to resolve the problem.

Start

Turn off the power and unplug the AC power cable, then remove all of the

add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and

printer.

Make sure if all jumper settings are correct.

Clear CMOS, then plug the ATX power cord correctly

(For P4 system, please also plug the 4pin (+12V)

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Continue

Install the VGA card. Then connect your monitor and keyboard.

Turn on the power

and check if the power

supply and CPU fan work

properly.

The problem is probably caused by

power supply or motherboard failure. Please contact your reseller or local distributor for repairing.

No Yes

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

Press <Ctrl> and <Alt> key at the same time, hold

them and then press <Del> to reboot the system.

Continue

Check if there is display?

Yes

Check if the system

reboots?

Yes

Perhaps your VGA card or monitor is defective.

It is very possible that your keyboard is defective.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

During system rebooting, press <Del> to enter BIOS

setup. Choose “Load Setup Default”.

Turn off the system and re-connect IDE cable.

Re-install the operating system such as Windows 98.

Continue

Check if the system can

reboot successfully?

Yes

End

The problem should be caused by the IDE cable or HDD itself.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

TTeecchhnniiccaall SSuuppppoorrtt

Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we

receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us. With your help, we can then continue to provide the best quality service to more customers.

Thanks very much for your understanding! AOpen Technical Supporting Team

Online Manual: To download manual, please log on and then select your preferred language. Under “Type” directory, choose “Manuals” to go to our manual database. You can also find the manual and EIG in AOpen Bonus Pack.

HTUhttp://do wnload.aopen.com.tw/downloadsU TH

Test Report: We recommend you to choose board/card/device from the compatibility test reports for assembling your PC. It may prevent incompatibility problems.

HHTU http://english.aopen.com.tw/tech/report/default.htmU TH H

FAQ: Here we list problems that users often encounter and FAQ (Frequently Asked Questions). You may select your preferred language after log on and find a solution to your problem.

HUhttp://club.aopen.com.tw/faqU HU /U

Download Software: After log on and having language selected, you may get the latest updated BIOS/utility and drivers you need under “Type” directory. In most case, newer versions of drivers and BIOS have solved earlier bugs or

compatibility problems.

HTUhttp://do wnload.aopen.com.tw/downloadsU TH

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

eForum: AOpen eForum is provided to discuss our products with other users, in which your problem probably had

PPaarrtt NNuummbbeerr aanndd SSeerriiaall NNuummbbeerr

The Part Number and Serial number are printed on bar code label. You can find this bar code label on the outside packing, or on component side of PCB. For example:

P/N: 91.88110.201 is part number, S/N: 91949378KN73 is serial number.

been discussed before or will be answered. After log on, you may select your preferred language under “Multi-language”.

HUhttp://club.aopen.com.tw/forumU HU /U

Contact Distributors/Resellers: We sell our products through resellers and integrators. They should know your system configuration very well and should be able to solve your problem efficiently and provide important reference for you.

Contact Us: Please prepare detail system configuration and error symptom before contacting us. The part number, serial number and BIOS version are also very helpful.

Part No.

Part No. Serial No.

Serial No.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

MMooddeell nnaammee aanndd BBIIOOSS vveerrssiioonn

Model name and BIOS version can be found on upper left corner of first boot screen (HTUPOSTU TH screen). For example:

AK77-400GN R1.00 Aug. 01.2003 AOpen Inc.

AK77-400GN is model name of motherboard, R1.00 is BIOS version.

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

PPrroodduucctt RReeggiissttrraattiioonn

TTT hank you for choosing AOpen product. AOpen encourages you to spend few minutes in completing the following product

registration. To register your product will ensure the high quality of services from AOpen. After the registration, you will:

• Have opportunities to play online slot machine and win a prize from AOpen by accumulating your bonuses for later prize

exchange.

• Be upgraded to gold membership of Club AOpen program.

• Receive email notification about product safety alerts. Its purpose is to alert consumers quickly and conveniently when

products contain technical issues.

• Receive email notification about latest product's announcements.

• Be able to personalize your AOpen web pages.

• Receive e-mail notification about latest BIOS/Driver/Software release information.

• Have opportunities to participate special product promotional programs.

• Enjoy higher service priority to receive technical assistance provided by AOpen specialists worldwide.

• Be able to join the discussions of web-based news groups.

AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or companies. Further, AOpen will not disclose any of information you submitted under any conditions. Please consult our

privacy policyUTH for further information on our company policy.

TNote: TIf registering products purchased from different dealers/retails and/or purchased on different dates, please

submit a separate form for each product.

HTU online

AAKK7777--440000NN // AAKK7777--440000GGNN OOnnlliinnee MMaannuuaall

HHooww ttoo CCoonnttaacctt UUss

Please do not hesitate contact us if you have any problem about our products. Any opinion will be appreciated.

Pacific Rim AOpen Inc. Tel: 886-2-3789-5888 Fax: 886-2-3789-5899

China 艾爾鵬國際貿易(上海)有限公司 Tel: 86-21-6225-8622 Fax: 86-21-6225-7926

Web Site: HTUwww.aopen.comUT H E-mail: Send us email by going through the contact form below. English Japanese H TU http://www.aopen.co.jp/tech/default.htmUTH Chinese H TU http://www.aopen.com.tw/tech/default.htmUTH German HTUhttp://www.aopencom.de/tech/default.htmUT H Simplified Chinese HTU http://www.aopen.com.cn/tech/default.htmUTH

HTUhttp://english.aopen.com.tw/te ch/default.htmU TH

Europe AOpen Computer b.v. Tel: 31-73-645-9516 Email: Support@AOpen.NL

Germany AOpen Computer GmbH. Tel: 49-2131-1243-710 Fax: 49-2131-1243-999

America AOpen America Inc. Tel: 1-408-232-1200 Fax: 1-408-232-1280

Japan AOpen Japan Inc. Tel: 81-048-290-1800 Fax: 81-048-290-1820

AOpen AK77400G User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

AK77-400G / AK77-400GN

Chipset

Ultra DMA 66/100/133 Bus Master IDE

LAN Port (for AK77-400GN)

Expansion Slots

Memory

On-board AC97 Sound

S/PDIF Connector

1MHz Stepping CPU Frequency Adjustment

Watch Dog ABS

Power Management/Plug and Play

Hardware Monitoring Management

Motherboard Map

IrDA Connector

AUX-IN Connector
