AOC LE32H057D Schematic

31.5″LCD TV AOC LE32H057D

Service

Horizontal Frequency

31~68 KHz

Table of Contents

Description Page

Table of Contents………………………………………....1

Description Page

6.1. Main Board….......................................................29

Important Safety Notice……………………………….…2

Revision List…………………………………..…….……3

1. General Specification...............................…….......4

2. Operating Instructions..............................................5

2.1. The Front Control Panel………..............................5

2.2. Connections……………………..............................6

2.3. Remote Control...................................................7

2.4. Instructions for Use..............................................8

2.5. Visualization Menu...............................................15

3. Input /Output Specification..........……………........17

3.1. Input Signal Connector............……....................17

3.2. Factory Preset Display Modes….........................18

4. Mechanical Instruction…………….………….….....19

5. Repair Flow Chart................................................22

6. PCB Layout...……..............................................29

SAFETY NOTICE

ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS

6.2. Power Board…....................................................33

6.3. Key Board…........................................................35

6.4. IR Board………....................................................35

6.5. MEMC Board.......…..........................................36

7. White Balance Adjustment…………………………38

8. Block Diagram….....................................................40

9. Schematic Diagram...……......................................42

9.1. Main Board…………............................................42

9.2. Power Board……….............................................57

9.3. Key Board…........................................................60

9.4. IR Board…...........................................................61

9.5. MEMC Board…...................................................62

10. Exploded View…..................................................68

11. BOM List……….………….………………..............70

AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING

ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.

CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

1

Important Safety Notice

Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service

procedures recommended by AOC and described in this service manual are effective methods of performing service

operations. Some of these service operations require the use of tools specially designed for the purpose. The

special tools should be used when and as recommended.

It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in

order to minimize the risk of personal injury to service personnel. The possibility exists that improper service

methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE

NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in

which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not

undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not

recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the

equipment will be jeopardized by the service method selected.

Hereafter throughout this manual, AOC Company will be referred to as AOC.

WARNING

Use of substitute replacement parts, which do not have the same, specified safety characteristics, might create

shock, fire, or other hazards.

Under no circumstances should the original design be modified or altered without written permission from AOC.

AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.

Servicer assumes all liability.

FOR PRODUCTS CONTAINING LASER:

DANGER-Invisible laser radiations when open AVOID DIRECT EXPOSURE TO BEAM.

CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

CAUTION -The use of optical instruments with this product will increase eye hazard.

TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S

REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF

THIS SERVICE MANUAL.

Take care during handling the LCD module with backlight unit

¾ Must mount the module using mounting holes arranged in four corners.

¾ Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.

¾ Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage

to the panel.

¾ Protect the module from the ESD as it may damage the electronic circuit (C-MOS).

¾ Make certain that treatment person’s body is grounded through wristband.

¾ Do not leave the module in high temperature and in areas of high humidity for a long time.

¾ Avoid contact with water as it may a short circuit within the module.

¾ If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth

may damage the panel.)

2

Revision List

Version Release Date Revision Instructions Customer Model TPV Model

A00 Oct.21,2010 Initial Release LE32H057D E32AATNSWEB56N

3

1. General Specification

Model LE32H057D

Screen Size 32" diagonal (81.28 cm)

Resolution 1920 x 1080

Screen Aspect 16:9 – Normal / Wide / Zoom / Cinema

TV System NTSC_M / PAL_M / PAL_N / ISDB_T

Backlight LED

VHF: 2 to 13

Channel coverage

Speakers 2 x 5W + 10W woofer

Power Supply AC 100V~240V, 50/60Hz

Standby power consumption <1W

Video/Audio inputs

Audio output Earphone, SPDIF

AV INPUT AV x 1, Audio L/R x 1

Component input YPbPr x 1, Audio L/R x 1

HDMI Terminals HDMI x 3, sharing audio with PC input when DVI is supported

VGA Terminals D-Sub x 1

Earphones Stereo mini-jack (3.5 ø)

Size (L x W x H) (with base)(mm) 773 x 210 x 560

UHF: 14 to 69

Cable TV: 1 to 125

Back: AV x 1, Component x 1, PC-VGA

Side: HDMI x 3, USB x 1

Size (L x W x H) (remove base)(mm) 773 x 46 x 521

Weight 10.62 Kg (with base) / 9.02 Kg (no base)

Size of Wall Support VESA 100 mm x 200 mm (Wall Support not included)

Wall Support Accessories Optional accessories are not included in the regular package.

Operation Temperature 40ºC for moderate climate (Maximum environmental temperature)

Equipment:

Storage Temperature -20ºC~40ºC / 4850m

4

2. Operating Instructions

2.1 The Front Control Panel

5

2.2 Connections

Note: Once your equipment is connected, follow this procedure to select the input signal: Press the SOURCE

button to select the desired input. Before connecting any peripheral to the TV unplug the power cables.

6

2.3 Remote Control

Power

Turn the television On or Off.

Note: The TV is never completely

turned off unless the power cable

has been unplugged).

Zoom

Change the zoom mode.

FREEZE

Freeze the picture on the screen.


This allows changes between

pre-defined image profiles.

AUDIO

This activates audio modes, such

as: Stereo, SAP or Mono.

0 to 9 Keys

Select a TV channel.

Return

Press to return the menu screen.

VOL - / VOL +

Press + or – to adjust volume.

CH– / CH+

To change the TV channel Up and

Down.

Source

This changes the information

source.

Mute

Activate or deactivate the sound.

Display

Display date and hour and

information on the selected

channel. With non-TV sources, this

will display information about the

current input.

Service

Access the current channel service

list. This also shows the services

from which the user can choose

when manually entering the

channel number. (e.g.: 5.3 the

number after the dot is the desired

service. This only works for digital

content channels.)

Navigation Ring

Allow navigation between menus.

Options are selected by clicking

the center OK button.

Exit

Press to exit the menu screen.

Menu

Press to open or exit the menu.

Colored Keys

Access the functions shown on the

menu screen.

DVR Keys

Accesses media center functions.

CC

This is a toggle that activates or

deactivates the Closed Captions

(subtitles). You can adjust CC to

Off. / CC On.

Info

Access the current program

synopsis. Only for digital content

channels

Sound

This allows changes between

pre-defined audio profiles.

EPG

Press to show EPG (Electronic

Program Guide).

This contains program information

for the channel you are watching.

The EPG is only displayed for

digital transmissions.

7

2.4 Instructions for Use

2.4.1 Using Menu

1. Press the MENU button for the main menu.

2. Use the navigation ring to select a menu item and enter the

submenu.

3. Press the central button for OK and to enable or disable the

function.

4. Press the MENU or EXIT button to leave the menu.

Colored keys: Red, blue, yellow and green.

2.4.2 First Adjustments

¾ Welcome Initial Setup

This is the first menu displayed. This allows the user to start channel installation before accessing other TV functions.

The user can choose the TV signal source: Antenna or Cable. The user may leave these screens by pressing the

SOURCE key in order to select the desired input source. When the device is turned on, the source selected is TV

and the channel list is empty, these screens will always be displayed.

Check the antenna cable Tuner Mode

The next steps are described in channel installation.

Channel installation Installed channels

8

¾ Main Menu

This is the TV main menu. It allows the user to choose from the options: Channels, Picture, Sound, Parental,

Settings and Media.

Note: If the user attempts to access the Media menu using a non-USB source, the user will be informed that this is

not possible with the current source input.

¾ Picture Menu

The Picture menu in most selection modes is shown below. It provides several items for the adjustment of video.

Picture Mode: Developed for different types of video mode. Select Standard, Cinema, Vivid, Mild, Sport, Game and

Personal mode. It is only possible to make adjustments in Personal mode.

1. Brightness: Adjust luminance of video, use only when

Picture Mode is Personal. Brightness adjustment is from

0~100.

2. Contrast: Adjust contrast of video, use only when Picture

Mode is Personal. Contrast adjustment is from 0~100.

3. Color: Adjust color, use only when Image Mode is

Personal. Color adjustment is from 0~100.

4. Hue: Adjust hue level. This can only be selected with NTSC. Color adjustment is from -50~+50.

5. Sharpness: Adjust video sharpness. Sharpness adjustment is from 0~100.

6. Backlight: Adjust the luminance of the backlight. The adjustment is from 0~100.

7. Color Temperature: There are three user selectable options for color temperature - warm, normal and cool.

Picture Restoration: Allows the restoration of all picture adjustments to their default values. Press the red button on

your remote control.

¾ Sound Menu

The Sound menu in TV mode is shown below.

9

Sound Mode: Developed for different types of sound mode. Select Standard, Voice, Music, Movie, Theatre and

Personal mode. It is only possible to make adjustments in Personal mode.

1. Balance: Balance adjustment is from -50 ~50.

2. Bass: Can only be adjusted in Personal mode.

Bass adjustment is from 0 ~100.

3. Treble: Can only be adjusted in Personal mode.

Treble adjustment is from 0 ~100.

Sound Restoration: Allows the restoration of personal

mode settings to their default values. Press the red

button on your remote control.

¾ Channel Menu

The Channel menu in TV mode is shown below.

Channel Management List:

however, if a channel does not have a digital signal, it will be displayed as analog. Therefore, these analog channels

will only be displayed if the corresponding digital channel is not available.

1. Select Favorites: select the channel you want and press the red button of the remote control. The channel will

display

2. Skip Channel: select the channel you want to exclude during program search and press the green button on the

remote control.

3. Block Channel: select the channel you wish to block and press the yellow button on the remote control. The

channel will display

4. Delete Channel: press the blue button to remove the undesired channel.

♥ next to the number.

List all found channels in channel scan. This list displays only digital channels;

next to the number. It is possible to choose two block modes: Always and Never.

Warning: Some of these functions are password

protected. To access them, you need to enter the

correct password in the TV menu (the default

password is 0000).

10

¾ Channel Block Modes

1. Always: block the selected the channel until the user unblocks it again.

2. Never: Unblock the selected channel. The block icon will be removed from the channel number.

¾ Parental

This allows parent to restrict access to TV program by recommended age. For instance: if 12 years old is selected,

only programs allowed for this age will be accessible, all other will be blocked. If the 10 value is selected only ratings

free programs are accessible.

The values available are: None, 10, 12, 14, 16, and 18 years old. To access and set this option, the password is

required. This option is available for the TV source, but it only works with digital TV channels.

Note: All programs work only after exiting the menu.

¾ Media Menu

In Media mode it is possible to import images and MP3

data through the USB port from a flash pen drive, or an

external Hard Disk, turning the TV into a MP3 player or a

picture slideshow viewer without the need for peripherals

such as cameras, DVD players, etc.

When inserting the USB device, this warning will be

displayed.

Using the red button of the remote control you can

access the media center and navigate amongst the

folders and files to choose those you want.

11

¾ Setting Menu

The Setting menu in TV mode includes the options: General, Channels, Sound, Display and PC.

1. Adjust Date and Time: Select this option to update date and

time.

2. Change Password: Allows the password to be changed.

The factory default password is (0000), to change this it is

necessary to enter the password using the remote control

and then enter a new 4 digit password. Memorize this new

password, it will allow access to several operations on the

TV menus.

3. Color System: can be adjusted to AUTO, PALM, PALN,

NTSC. We recommend the automatic setting because the

color system of each channel is detected when the channels

are scanned.

4. Auto Power off: When Auto Power off is off, the model will

not auto power off without signal; While Auto Power off is on,

the model will auto power off even without signal.

5. MEMC Compensation: When MEMC is on, the dynamic

picture will be much more clear and fluent, better than

normal picture effect, so that the streaking of the Previous

frame Picture will be clarified, the dynamic sharpness of

picture will be enhanced, and the streaking will be decreased

to be acceptable; When MEMC is DEMO, a white vertical

line will be in the middle of the screen; the left side of line will

be MEMC Compensation, and the right side of line will be no

MEMC; When MEMC is off , there is no MEMC. There are

differences in different sources: 1. Under USB source,

MEMC is off, and compensation can not be chosen; 2. Under

PC Source, MEMC has four options:

OFF/ON/DEMO/BYPASS. When is on OFF/ BYPASS,

Compensation can not be chosen, while is ON/DEMO,

Compensation has three options: MILD / MEDIUM /

STRONG; 3. Under other sources, MEMC has three options:

OFF/ON/DEMO. When is on OFF, Compensation can not be

chosen; while is ON/DEMO, Compensation has three

options: MILD/MEDIUM/STRONG;

6. Sleep: To set the time the TV will automatically turn

off .Press the key successively to select 5, 10, 15, 30, 45, 60,

1. Tuner Mode: Select TV sign mode (cable or antenna).

2. Update: Performs a new scan and search for new available channels and updates the information.

3. Reinstall: Reinstall all available channels during the scanning.

4. Services Navigation: Allows changes between channel services using CH+/CH- keys, e.g. primary channels.

The default value is off. This option is available only for digital channels.

90, 120, 180 and 240 minutes.

12

1. SRS/TRU Surround: Allows the user to activate/deactivate this sound system. The default option is on.

2. CC On Mute: Allows the choice for Closed Caption mode to be automatically displayed whenever the TV is on

mute. The default option is on.

3. Mute When Earphone: This option allows the choice for TV speakers to be muted (or not) when the Earphones

are connected. The default option is Mute.

1. Language: Allows the choice of screen menu language: English, Portuguese (default) or Spanish.

2. Exhibition Time: Defines screen menu display time. The times available are: 5, 10, 15 (default) or 30 seconds.

3. Blue Screen: Enables or disables Blue Screen. Default mode is on.

¾ Enable ONE-SEG Content

This function enables the display of ONE-SEG content. The default value is off. The user can adjust this option in

any channel, but it is effective only for ONE-SEG content.

This option is available only for digital channels.

Note:

ONE-SEG is a digital TV transmission for portable devices and mobile phones. This technology enables a TV signal

to be transmitted to portable devices even when they are moving, without interference or signal quality loss.

13

¾ Digital Signal Meter

Indicates signal intensity and quality of the selected channel. This menu does not have automatic off. This option is

available only for digital channels.

¾ PC

Allow some configuration when PC input is selected. The options are: Auto Adjustment, H-Position, and V-Position.

This option is available only in PC mode.

14

¾ Strip

The Strip contains important information on displayed digital channels. In the strip you will find the channel name

and number, closed caption, current date/time, program name, duration, beginning/end, age rating, services and

subtitle and audio.

For analog channels, the strip shows only date/time, channel number, subtitle and audio.

The strip is displayed for a few seconds every time a cable or outside channel is selected, or if the user presses the

display key.

Digital channel strip

Analog channel strip

2.5 Visualization Menu

Mode Normal in 16:9 Screens

The display of a 4:3 screen will be in the center between two empty sidebars. The image will be shown with no

distortion. Wide screen contents, such as 16:9, will be compressed horizontally to fill the 4:3 screen.

Wide Mode (Full Screen) for 16:9 Screens

The content in this mode is stretched horizontally so that at least 95% of the image width is visible.

15

Zoom Mode for 16:9 Screens

For this mode, the image is usually in wide format on 4:3 screen with empty top and bottom bars. For 4:3 content signal

that contains 16:9 images, the internal bars will appear as part of the picture. The Zoom mode will expand the image

evenly in both directions to fill up the entire screen.

Cinema Mode for 16:9 Screens

The Cinema mode is used to visualize anamorphic content in 2.35:1 full screen format (such as that of a StarWars DVD

for example) on 16:9 screens. This allows the user the option to fill the entire screen with the image, with no distortion.

16

3. Input /Output Specification

3.1 Input Signal Connector

VGA Connector

Pin No. Description Pin No. Description Pin No. Description

1 Red Video 6 Red Ground 11 RXD

2 Green Video 7 Green Ground 12 Serial Data for DDC

3 Blue Video 8 Blue Ground 13 H-Sync.

4 TXD 9 No Pin! 14 V-Sync.

5 Ground 10 Sync Ground 15 Serial Clock for DDC

HDMI Connector

Pin No. Description Pin No. Description Pin No. Description

1 TMDS Data2+ 8 TMDS Data0 Shield 15 SCL

2 TMDS Data2 Shield 9 TMDS Data0- 16 SDA

3 TMDS Data2- 10 TMDS Clock+ 17 DDC/CEC Ground

4 TMDS Data1+ 11 TMDS Clock Shield 18 +5V Power

5 TMDS Data1 Shield 12 TMDS Clock- 19 Hot Plug Detect

6 TMDS Data1- 13 CEC

7 TMDS Data0+ 14 NC

1

6

11 15

5

10

USB Connector

Pin No. Description Pin No. Description

1 VCC 3 DATA+

2 DATA- 4 GND

17

3.2 Factory Preset Display Modes

Analog RGB Input Signal Timing

VESA MODES

Mode Resolution Horizontal Freq. (KHz) Vertical Freq. (Hz) Pixel Clock

640x480@60Hz 31.469 59.940 25.175

VGA

SVGA

XGA

WXGA

WSXGA

640x480@72Hz 37.861 72.809 31.500

640x480@75Hz 37.5 75 31.500

720x400@70Hz 31.469 70.087 28.322

800x600@56Hz 35.156 56.25 36.000

800x600@60Hz 37.879 60.317 40.000

800x600@72Hz 48.077 72.188 50.000

800x600@75Hz 46.875 75 49.5

1024x768@60Hz 48.363 60.004 65.000

1024x768@70Hz 56.476 70.069 75.000

1024x768@75Hz 60.023 75.029 78.750

1280x720@60Hz 45 60 74.25

1280x768@60Hz 47.396 59.995 68.25

1280x1024@60Hz 63.981 60.02 108.000

1440x900@60Hz 55.935 59.887 106.5

1680x1050@60Hz 64.674 59.883 119

FHD 1920x1080@60Hz 66.587 59.934 138.500

Video Input Signal Timing

Industry

Code

720P 1280 x 720P* 45 60 74.25 16:9

1080i 1920 x 1080i* 33.75 60 74.25 16:9

480i 720 x480i 15.75 60 13.51 4:3

480P 720 x 483 p 31.47 60 27.00 4:3

1080p 1920 x 1080p 67.5 60 148.50 16:9

Input Format

Horizontal Freq.

(KHz)

Display Performance Descript

Vertical Freq.

(Hz)

Media supported format

Play music (MP3) and view photo (JPEG) for single subarea USB device

Sampling Freq.

(MHz)

ASPECT

18

4. Mechanical Instructions

1. Remove the screws to remove the base.

2. Remove the screws to remove the rear cover.

19

3. Disconnect the connector and remove the screws to remove the AC cover and BKT.

4. Disconnect the connectors and remove the screws to remove the boards.

20

5. Remove the screws to remove the BKTs.

21

p

5. Repair Flow Chart

1. No power

No power (LED “Off”)

Check the AC input and the

ower is “ON”?

Yes

Power board output=5V?

Yes

Check the IR board and LED

Replace the IR board

No

Replace the main board

No

Power “On”

No

Replace the power board

22

2. Can’t start

Power board output＝24V？

Check the power key is under control?

Check the IR receiver is normal?

Replace the main board

Replace the Power board

Can’t start

No

Replace the power board

Yes

Replace the key board

No

Yes

Replace the IR board

No

23

3. Abnormal Display

Abnormal Display

Check the source

Yes

Enter factory mode to do

“EEPROM initial”&“Reset”

No

Reset the source

Check the main board

Yes

Check the LVDS cable

Yes

Check the panel

No

Replace the panel

No

Replace the main board

No

Replace the LVDS cable

24

4. No display

Check TV is under control and power on/off by remote control and power key?

Yes

Check the LVDS cable

Yes

Panel Vcc = 5 V?

Yes

Replace the Panel

No display (LED blue)

Yes

Check the backlight is

“On”?

No

Reinsert or replace the LVDS cable

No

Replace the main board

No

Replace the main board

No

Check the B/L

signal is available?

Yes

Power board output =24 V？

Yes

Replace the Panel

Replace main board

Replace the power board

No

25

5. Sound problem

Check the speaker resistance value is in spec (Remark: The value is marked on the speaker)?

No sound or sound abnormal

Check the audio source connection

and the TV system are correct？

Yes

Check the TV is muted, adjust the

volume or enter the menu to reset?

No

Enter factory mode to do “Reset”

No

Check the cable between the

speakers and main board is

Yes

No

Reinsert the audio cable or change the TV system

No

Replace the cable

No

Yes

Replace the speaker

Replace the main board

26

6. Remote Control malfunction

Remote Control malfunction

Check the remote control battery is not properly placed or no power?

Use the other remote controls

Whether the IR board is

abnormal?

Yes

Replace the battery

No

Yes

Replace the remote control

No

Yes

Replace the IR board

No

Replace the main board

27

7. OSD is unstable or can’t work normally

OSD is unstable or can’t work normally

Key board connected properly?

Yes

No

Reconnect the key board

Buttons are OK?

Yes

Key board is OK?

Yes

Enter factory mode to do “Reset”

No

Replace the main board

No

Replace the button function

Replace the key board

28

6. PCB Layout

6.1 Main Board

715G4243M01000005F

29

30

31

32

6.2 Power Board

715G4078P01W22003H

33

34

6.3 Key Board

715G4531K01000004S

6.4 IR Board

715G4086R01001005F

35

6.5 MEMC Board

715G4242M01000005K

36

37

7. White-Balance Adjustment

Approximately 60 minutes should be allowed for warm up before proceeding white balance adjustment.

Before started adjust white balance, please set the CA210 Channel to 05 Channel and set it’s mode to x, y, Lv mode

Color Temp. Cool (12000) Normal (9300) Warm (6500)

x 272 ± 0.020 285 ± 0.020 313 ± 0.020

AV/HDMI/VGA/Component

Mode

How to setting the CA210 channel, you can reference to CA210 user guide or simple use the “Memory CH” up or

down to set the channel to 05 channel, and use the “Mode” key to set the mode to x, y, Lv.

Enter into the factory mode

Press the “MENU” key and then press number key 1 Æ 9 Æ 9 Æ 9ÆEnter, It will achieve the factory mode. Take the

other model picture for example:

y 278 ± 0.020 293 ± 0.020 329 ± 0.020

Y More than 360cd/cm2 (at full white)

38

In the White Balance you can adjust 3 items.

SCALER GAIN R, G, B Æ R, G, B Gain adjust

Adjust AV Source:

1. Set the pattern generator to timing 307 or PAL-M timing. And Select the item of Current Source and select

composite Source

2. Switch the Ca210 to x, y, Lv-mode (with press “MODE” button)

3. Switch the Ca210 channel to Channel 05 (with up or down “MEMORY CH” button)

4. The LCD-indicator on Ca210 will show x =285, y =293, Lv can adjust to More than 350cd/cm2 (at full white).

5. Enter the item “Color Temp” to select Normal to adjust.

6. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =285, y =293.

Adjust HDMI Source:

1. Set the pattern generator to timing 347 or HDMI-720P@60Hz timing. And Select the item of Current Source and

select HDMI Source

2. Switch the Ca210 to x, y, Lv-mode (with press “MODE” button)

3. Switch the Ca210 channel to Channel 05 (with up or down “MEMORY CH” button)

4. The LCD-indicator on Ca210 will show x =285, y =293, Lv can adjust to More than 350cd/cm2 (at full white).

5. Enter the item “Color Temp” to select Normal to adjust.

6. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =285, y =293.

Adjust VGA Source:

1. Set the pattern generator to timing 137 or 1024*768@60Hz timing. And Select the item of Current Source and

select VGA Source

2. Switch the Ca210 to x, y, Lv -mode (with press “MODE” button)

3. Switch the Ca210 channel to Channel 05 (with up or down “MEMORY CH” button)

4. The LCD-indicator on Ca210 will show x =285, y =293, Lv can adjust to More than 350cd/cm

5. Enter the item “Color Temp” to select Normal to adjust.

6. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =285, y =293.

Adjust Component Source:

1. Set the pattern generator to timing 314 or HDTV-720p@60Hz timing. And Select the item of Current Source and

select Component Source

2. Switch the Ca210 to x, y, Lv -mode (with press “MODE” button)

3. Switch the Ca210 channel to Channel 05 (with up or down “MEMORY CH” button)

4. The LCD-indicator on Ca210 will show x =285, y =293, Lv can adjust to More than 350cd/cm2 (at full white).

5. Enter the item “Color Temp” to select Normal to adjust.

6. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =285, y =293.

7. Enter the item “Color Temp” to select Cool to adjust.

8. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =272, y =278.

9. Enter the item “Color Temp” to select Warm to adjust.

10. Use the item R Gain, G Gain or B Gain to adjust white balance: use 80 IRE (Pattern 141) signal, and adjust the

white balance, until the Ca210 show x =313, y =329

2

(at full white).

39

8. Block Diagram

Panasonic Tuner

HDMI 1

HDMI 2

HDMI 3

IF

TC90517F

YP b P r +A udi o IN

CVBS+Audio IN

SII9187ACNU

VGA RGB +Audio IN

TS Stream

HDMI

HIDTV_PRO_SX27

IIS

STA339BWTR Audio Speaker Amp

APA2176

Headphone Amp

SPDIF out

SPEAKER

2.1Ch

BD8012FVJ U701 power

USB

64Mx16_DDR2

MX25L4005 SPI Flash

40

NAND Flash 512Mb

Panel

CN700

24V

12V

5VSB

R632

NC

D602

?A:71G 56G301 EA

FB701

R630 NC

?A:71G 56K121 M

FB112

R507 NC

FB702

NC

93G 64 42 PP

D100

R633

680

56T 563146

U715

56G 659501

U701

BD8012FVJ

56G 563514

U705

AIC1117-33PY

30V/7A/40A:AO4449

Q700

57G 763 79

PANEL_ON

5V

PANEL_ON

5V

POWER_ON

R1060

57G 763 79

VGA_VCC

+1.2VSB

PD_MUTE

R/L

PD_MUTE

CEC

VGA EDID pull up

PD_MUTE

按键AD上拉

VCCH1

?A:71G 56G301 EA

93G 64S3PH

BAS32L

56G 563 30

AZ1084S-3.3TREI

回路

输出回路

回路

57G 763 79

Q701

30V/7A/40A:AO4449

回路

56G 563964

U105

SC4215HSETRT

回路

Q701

30V/7A/40A:AO4449

回路

Pin1

CN701

3VSB

FB703

D711

U700

3.3V

STA339BW13TR

VCC2: Pin8 VCC1: Pin11

PANEL_VCC

FB227

FB110

5V_TUNER

PANEL_VCC

CN603 SPDIF VCC

U701 USB OC

SX DSDA/DSCL

HP_MUTE

CN706 MEMC

FB119

FB111

?A:71G 56K121 M

FB401

?A:71G 56K121 M

FB208

U704

上拉

供电

PVDD:16

U602

VDD:8

APA2176A

FB205

FB220

FB221

FB206

56G 563143

U706

G1084T43Uf

FB502

FB103

56G 616518

U603

?A:71G 59D121 TA

?A:71G 57G301 MB

56G 563513

APW7080KAITRG

56T 616516

?A:71G 56K121 M

+1.2V

?A:71G 56K121 M

?A:71G 57G301 MB

TV_CVBS

输出

TUNER PIN10

TUNER PIN2

TUNER PIN17

CN401 Pin5/6 IR

HDMI_CEC/HDMI_IIC_SW/HDMI SBVCC

MCU_JTAG_TCK

U711

Pin5

U712

Q200/Q201 LED

U402

HP_TESTCON

上拉

SX MCU

大部份

U202

SX AVDD33

供电

SX VDDF

?A:71G 56K121 M

HP_VCC1V

FB223

56G 563122

U707

PANEL_PWM

SX TXD/RXD/SCLM2/SDAM2/CN705

SX GPIO0-9/MIPS_JTAG 56G 563246

U703

SX NAND FLASH I/O

SX AVDD33_SP

SX AVDD33OUTBUF

SX AVCC33RX

SX VDDA33

FB607

FB105

FB107

+3.3VO

FB102

及

Key

供电

上拉

56G4LVCG17 TI

SN74LVC1G17DBVR

供电

56G1133923

MX25L4005AM2C-12G

I/O

上拉

56G 643 27

G692L293TCUF

VDDL

HP_VCC_25

上拉

AZ1084S2-ADJG1

上拉

?A:71G 56K121 M

?A:71G 57G301 MB

SX VDDL

SX VDDC

上拉

HP_VDDM/HP_VC_18

VCC33_AMP

Pin5

U709/u710

U106

VDDS:Pin13/35

Pin49/64

U106 SDA/SCL/XSEL1/XSEL0

?A:71G 59D121 TA

FB1805

?A:71G 57G301 MB

FB101

?A:71G 57G301 MB

FB104

?A:71G 57G301 MB

FB106

?A:71G 57G301 MB

FB108

?A:71G 56K121 M

FB222

?A:71G 56K121 M

FB210

?A:71G 56K121 M

FB211

?A:71G 56K121 M

FB214

?A:71G 56K121 M

FB216

?A:71G 56K121 M

FB217

?A:71G 56K121 M

FB209

?A:71G 56K121 M

FB212

?A:71G 56K121 M

FB204

?A:71G 56K121 M

FB207

?A:71G 56K121 M

FB213

?A:71G 56K121 M

FB215

?A:71G 56K121 M

FB218

?A:73G253S 94 M1

R240

?A:71G 56K121 M VDD:Pin12/37

FB400

?A:71G 59C300

FB613

?A:71G 59C300

FB608

?A:71G 59C300

R693

56T1133111

VDDC:Pin16/36/56/63

U106

DR1VDD:Pin34/48

TC90517FG

56G4LVCG17 TI SN74LVC1G17DBVR

56T1133111

TC90517FG

等上拉

ETH_VCC_25

VDDI_25

VCC_FLASH

PLL_Vdd

HD3V3

CN707 RJ-45 Debug

AD_DVDD: Pin32

DR2VDD: Pin43

AD_AVDD: Pin22

PLLVDD: Pin20

TC90517FG

?A:71G 56K121 M

VDDI_25

FB219

SX VCC25A

SX VCC25D

SX VCC25HP

SX VCC25A_BG

SX VCC25A_TX

SX VDDP

SX LVDS_VDD

SX PAVDDLLPLL

SX AVDDPLL

SX AVCC

SX PVCC

SX REGVCC

SX AVDD25_ADC1

SX VDDR1/2

SX VDDM

VDDQ/VDD

U400/U401

VDDL VREF

SX MVREF1/2

U403

PD_MUTE

上拉

VDD_DIG:Pin36

U603

VDD_DIG:Pin21

VDD_PLL:Pin24

STA339BWTR

56G 634 25

VCC33:Pin9/27/64

U505

SII9187ACNU

U106

SX VDDI25

SX AVDD_MCK2

56G 615505

NT5TU64M16DG-BE

56T1133111

NAND512W3A2DN6E

41

9. Schematic Diagram

9.1 Main Board

715G4243M01000005F

TS1_D[0..7]

TS1_CLK

TS1_SYNC

TS1_DEN

TS1_CLK

TS1_D0

TS1_SYNC

TS1_DEN

T1_SIF

C207

20P 50V

5 6

TS1_D0

7 8

RP101

8P4R 33 OHM +-5% 1/16W

NC 8P4R 33 OH M +-5% 1/16W

5V

R204 R205

4.7K 1/10W

CVBS1_IN

PC_R_IN PC_G_IN

PC_B_IN PC_HS_IN PC_VS_IN

Y1_IN

PB1_IN

PR1_IN

TV_C VBS

C206

100N 50V

1M 1/10W

R207

24MHz

X200

12

4 3 2 1

RP106

5 6 7 8

HDMI_RX0HDMI_RX0+ HDMI_RX1HDMI_RX1+ HDMI_RX2HDMI_RX2+ HDMI_RXCHDMI_RXC+

HDMITX_5V

R208 33 OHM 1/10W

C208 20P 50V

4 3 2 1

TS1_D0 TS1_D1 TS1_D2 TS1_D3 TS1_D4 TS1_D5 TS1_D6 TS1_D7

C205 100N 50V

AE5 AF5 AF6

AE6 AD6 AC6 AB6 AF7 AE7 AC7 AD7

AF2 AF3 AE3 AD3 AF4 AE4 AD4 AC4 AC5 AB5 AD5

AD1 AC3 AD2 AE1

D10

A10

B10

C10

ANT SIF

D2 D1 E2 E1 F2 F1 C2 C1

B1 B3 A1 B2

B5 A3 A2

B9 B8

D4 C4

B7

D8

A7

D9

C8

C9

D7

C6 D5

D6 C5

A4 B4

A6 B6

T1

R1

E3 E4

TS1D 0 TS1D 1 TS1D 2 TS1D 3 TS1D 4 TS1D 5 TS1D 6 TS1D 7 TS1CLK TS1SY N C TS1D EN

TS2D 0 TS2D 1 TS2D 2 TS2D 3 TS2D 4 TS2D 5 TS2D 6 TS2D 7 TS2CLK TS2SY N C TS2D EN

TSS_CLK TSS_DI TSS_SYNC TSS_DEN

RX0RX0+ RX1RX1+ RX2RX2+ RXCRXC+

ANTS TO PWR5V DSDA DSCL

CVBS1 CVBS_OUT1 CVBS_OUT2

PCR PCG PCB PCHS PCVS

YG1 PBB1 PRR1

YG2 PBB2 PRR2

YG3 PBB3 PRR3

C

FS1 FB1

FS2 FB2

FS3 FS4

SIFN SIFP

XTLI24M XTLO24M

INTN RSTO

RESET_Demo_#

U200A

HiDTV-Pro_SXB

(1/5)

TS_IN

HDMI_IN ANALOG_IN LVDS_OUT

I2S PORT

I2C PORT

UART PORT USB PORT

ADC

MISC

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

42

HIDTV

*****

04:HiDPRO SX-1

USBPPON

RREF EXT

I2SCLKIN

PC

AV

YPBPR

Side

SCART2

TESTCON TESTMOD

MASTSEL

TA1M TA1P TB1M

TB1P TC1M TC1P TD1M TD1P TE1M

TE1P

TCLK1M

TCLK1P

TA2M

TA2P TB2M

TB2P TC2M TC2P TD2M TD2P TE2M

TE2P

TCLK2M

TCLK2P

USBOC

TXD2 RXD2

SCKIN WSI2S

SDI2S

I2SCLK

SPDIF MUTE

SCLM1

SDAM1

SCLM2

SDAM2

SPKOR

SPKOL

HPHOR

HPHOL

AOR1

AOL1

AOR2

AOL2

TXD RXD

SCK

SD1 SD2 SD3

AR1

AR2

AR3

AR4

AR5

A15 B15 C16 C15 B16 A16 C18 C17 B18 A18 A17 B17

A19 B19 C20 C19 B20 A20 C22 C21 B22 A22 A21 B21

AC1

DP

AB1

DN

AB3 AB2 AC2

AF20 AF21

Y1 AA1

AA3 AA4 AB4

AC21 AD21

WS

AF22 AE22 AD22

AF23 AA2

AE21 D21

Y3 Y2

C24 A23

B11 A11

AL1

D11 C11

AL2

C12 D12

AL3

A12 B12

AL4

B13 A13

AL5

B14 A14 D17 D16 D14 C14 D15 E14

M3

HP_TESTCON HP_TESTMOD

M2

HP_MASTSEL

B24

R201 6.04K +-1% 1/10W

HID_TXD HID_RXD

3.3V

R275 10K 1/10W

R247 10K 1/10W

C203 1uF 25V C204 1uF 25V

3VSB

OEM MO DEL Size

G4243-D-X-X-2-100726

TPV MO DEL

***** 01

715G4243-M0A-000-0050

PCB NAME

418Monday, J uly 26, 2010

Sheet

of

HP_SPDIF

SCL_MST1 SDA_MST1

R200

4.7K 1/10W

R202 0R05 1/10W

I2S_CLK

HID_TXD HID_RXD

PULL DOWN : LED PULL HIGH: JTAG

TX0AN TX0AP TX1AN TX1AP TX2AN TX2AP TX3AN TX3AP TX4AN TX4AP TXCKAN TXCKAP

TX0BN TX0BP TX1BN TX1BP TX2BN TX2BP TX3BN TX3BP TX4BN TX4BP TXCKBN TXCKBP

USB_DP USB_DN USB_PPON USB_OC

HID_TXD HID_RXD

I2S_CK I2S_WS I2S_SD

R287

2K 1/10W

PC_RI N PC_LIN AV_RIN AV_LIN HD_RIN HD_LI N

AX_HP_OUTR AX_HP_OUTL

3.3V

CN705

1 2 3 4

NC

3.3V

R288

2K 1/10W

HDMI_SCL

HDMI_SDA

Custom

Rev

<

称爹

>

4.7K 1/ 10W

AMP_SD

AMP_MUTE

HP_MUTE

HDMITX_INT HDMI_I2C_SW SW_AMP_RSTN

RESET_FRC

V18_SW

MEMC 5V_S W

V105DLL_SW

DRC_EN

FRA[ 19..22]

3.3V

R220

FRD[0..7]

FRA13 FRA14

FRA18

FRA23

FOE# FWE# GCS0

GCS2

4.7K 1/10W R236

R222 NC 4. 7K 1/10W

R226 4.7K 1/10W

R246 4.7K 1/10W

R1840 0R05 1/10W

SF_SI SF_SO SF_WP# SF_HOLD# SF_CS SF_SCK

3.3V

U200B HIDTV

FRD0 FRD1 FRD2 FRD3 FRD4 FRD5 FRD6 FRD7

FRA13 FRA14

FRA18 FRA19 FRA20 FRA21 FRA22 FRA23

R278 4.7K 1/ 10W

R277 4.7K 1/ 10W

R276 4.7K 1/ 10W

R279 4.7K 1/ 10W

AC9 AF10 AD10 AB10 AE11 AC11 AF12 AD12

AB9 AC10 AE10 AF11 AD11 AB11 AE12 AB12

AF9 AF18 AB17 AC17 AD17 AE17 AF17 AB16 AD15 AE15 AF15 AB14 AC14 AD14 AE14 AF14 AF13 AC16 AD16 AC15 AB15 AE16 AB13 AC13 AD13

AD9 AF16

AE9

AE2

AF1 AC12

AE23 AD23

AB7

AF8

AE8

AD8

AC8

AB8

AE18 AF19 AB18 AD18

F3 G1 G2 G3 G4 H1 H2 H3 H4

J4 J3 J2 J1

FRD0/PODD0 FRD1/PODD1 FRD2/PODD2 FRD3/PODD3 FRD4/PODD4 FRD5/PODD5 FRD6/PODD6 FRD7/PODD7 FRD8/PODA0 FRD9/PODA1 FRD10/PODA2 FRD11/PODA3 FRD12/PODA10 FRD13/PODA11 FRD14/PODA12 FRD15/PODA13

FRA0 FRA1/PODWE FRA2/PODIORD FRA3/PODIOWR FRA4/PODREG FRA5 FRA6 FRA7 FRA8 FRA9/PODOE FRA10 FRA11 FRA12 FRA13 FRA14 FRA15 FRA16 FRA17 FRA18 FRA19 FRA20 FRA21 FRA22 FRA23 FRA24 FOE# FWE# GCS0 GCS1 GCS2 BOOTCS

GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GPIO5 GPIO6 GPIO7 GPIO8 GPIO9 GPIO10 GPIO11 GPIO12 GPIO13 GPIO14

POD_A4 POD_A5 POD_A6 POD_A7 POD_A8 POD_A9

POD_IR EQ POD_RST POD_VS1 POD_WAI T

HiDTV-Pro_SXB

(2/5)

FLASH INTERFACE

GPIO PORT

SF_HOLDN

HP_DETECT

POD_VCC_EN

POD_VCC_ENB

POD_VPP_EN

POD_VPP_ENBPOD_OVERLOAD

SF_SI

SF_SO

SF_WPN

SF_C ES SF_SC K

TD0 TMS TCK

TRS TN

LED

KYBR D

LGSEN

CEC

PWRO N AVLINK1 AVLINK2

STB_RSTO

RXIP RXIN TXOP TXON

RSET_BG

H_BK_LITE

PWM0 PWM1

BOOST

BKLGON

TCO N_ON

FSOURCE

HPD

STB_GP0 STB_GP1 STB_GP2 STB_GP3 STB_TXD STB_RXD

STB_EN

SPI_EN

STB_SDA STB_SCL

RSTN

ET_LED1 ET_LED2

PLL_TEST

POD_CE2

POD_CE1 POD_CD2 POD_CD1

TDI

IR

NC

L3 L2 L1 K5 L4 L5

W4 W3 W2 W1 Y4

K1 K2 N1 P1 K4 P5 N3 N2 K3

U2 U1 V1 V2 T3

D24 B23 C23 D23 E23 D22 E22 C3 D3

P2 P3 P4 R3 N5 N4

M4 M5

T4 U4

M1

V3 V4 T2

AE13

AD19 AE19 AE20 AC18

AC19 AC20 AB19 AD20AB20

MIPS_JTAG_TDI MIPS_JTAG_TDO MIPS_JTAG_TMS MIPS_JTAG_TCK MIPS_JTAG_TRSTN

IR_D KYBR D

12K4 1/10W 1%

HP_STB_EN

HP_SPI_EN

HP_RESET#

LED_STB

LAN_RXIN+

LAN_RXINLAN_TXIN+

LAN_TXIN-

R218

MCU _TXD MCU _R XD

876

123

R1834

NC 0R 05 1/10W

4.7K 1/ 10W

R231

4.7K 1/10W

R1836

0R05 1/10W

5

4

R223

RP103

4.7 K 1/1 6W

3VSB

LED_R

0R05 1/10W

LED_STB

R224

4.7K 1/10W

C212

10N 50V

LED

R1835

3VSB

R227

R253

4.7K 1/10W

MIP S_J TAG_TC K MIP S_J TAG_TD O MIP S_J TAG_TMS MIP S_J TAG_TR STN MIP S_J TAG_TD I

LED

33 OHM 1/10W

R211

4.7K 1/10W

R1837 NC 0R05 1/10W

R1839 NC 0R05 1/10W R1838 0R05 1/10W

R219

4.7K 1/ 10W

R228

4.7K 1/10W

3VSB

10K 1/10W R225

1

GND

2

RESET

IC G692L293TCUf

R1144

R244

STB_SDA STB_SCL

3VSB

R214

4.7K 1/ 10W

10K 1/10W

VCC

MR

U20 2

MIPS _JTA G_TR STN

0R05 1/10W

NC

CN201

10

8 6 4 2

MCU_JTAG_TDO IR_D KYBR D PW_KEY

HDMI_CEC

STB_HS_DET STB_VS_DET

AUX_POWER _ON# LED_B

BL_ADJ PANEL_PWM

BL_ON# PANEL_ON PHONE_D ET

MCU_JTAG_TDI MCU_JTAG_TMS MCU_JTAG_TCK

POWER_ON

3VSB

R245

10K 1/10W

1 2 3 4

3VSB

SW101

4 3

NC

R210

9 7 5 3 1

CN702

NC

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

Date

05:HiD PRO SX-2

43

OEM MO DE L Size

TPV MOD EL

PCB NAME

G4243-D-X-X-2-100726

***** 01

715G4243-M0A-000-0050

Sheet

of

518Monday, August 09, 2010

Rev

称爹

<

Custom

>

HP_MD[0..31]

HP_WDQS[0..3] HP_RDQS[0..3]

HP_MD0 HP_MD1 HP_MD2 HP_MD3 HP_MD4 HP_MD5 HP_MD6 HP_MD7 HP_MD8 HP_MD9 HP_MD10 HP_MD11 HP_MD12 HP_MD13 HP_MD14 HP_MD15 HP_MD16 HP_MD17 HP_MD18 HP_MD19 HP_MD20 HP_MD21 HP_MD22 HP_MD23 HP_MD24 HP_MD25 HP_MD26 HP_MD27 HP_MD28 HP_MD29 HP_MD30 HP_MD31

HP_WDQS0 HP_RDQS0 HP_WDQS1 HP_RDQS1 HP_WDQS2 HP_RDQS2 HP_WDQS3 HP_RDQS3

U200C HIDTV

AF25

MD 0

AF26

MD 1

AE25

MD 2

AE26

MD 3

AC24

MD 4

AB24

MD 5

AB25

MD 6

AB26

MD 7

AA25

MD 8

AA26

MD 9

HiDTV-Pro_SXB

Y25

MD 10

Y26

MD 11

W24

MD 12

V24

MD 13

V25

MD 14

V26

MD 15

K24

J24 J25

J26 G26 G25 G24 F25 E24 E25 E26 D26 B25 B26 A25 A26

AD26 AD25

W25 W26

H25 H24 C26 C25

MD 16 MD 17 MD 18 MD 19 MD 20 MD 21 MD 22 MD 23 MD 24 MD 25 MD 26 MD 27 MD 28 MD 29 MD 30 MD 31

WDQS0_DQS0 RDQS0_DQS0# WDQS1_DQS1 RDQS1_DQS1# WDQS2_DQS2 RDQS2_DQS2# WDQS3_DQS3 RDQS3_DQS3#

DDR2 INTERFACE

(3/5)

MAA0 MAA1 MAA2 MAA3 MAA4 MAA5 MAA6 MAA7 MAA8

MAA9 MAA10 MAA11 MAA12

BA0 BA1 BA2

DQM0 DQM1 DQM2 DQM3

MC LK0

MCLK0#

MVR EF 2 MVR EF 1

CAS RAS

WE CS0 CKE ODT

MZQ

MR ES

L26 P24 K26 L24 N24 P25 N26 M25 N25 M24 K25 L25 U23

U26 T26 R24

AC25 Y24 H26 D25

R26 P26

A24 AD24

U25 U24 R25 T24 T25 M26

AF24 F26

402ohm 1/ 10W +/-1%

HP_MA0 HP_MA1 HP_MA2 HP_MA3 HP_MA4 HP_MA5 HP_MA6 HP_MA7 HP_MA8 HP_MA9 HP_MA10 HP_MA11 HP_MA12

HP_BA0 HP_BA1 HP_BA2

HP_DQM0 HP_DQM1 HP_DQM2 HP_DQM3

HP_MVREF2 HP_MVREF1

R239

HP_MVREF2

C214

100N 50V

Near to IC

HP_MVREF1

C317

100N 50V

Near to IC

1K1/10W

R237

R238

R255

1K1/10W

HP_VCC_18

R254

HP_MA[0. .12] HP_BA[0..2] HP_DQM[0..3]

HP_MCLK0 HP_MCLK0#

C213 100N 50V

C216 100N 50V

HP_VCC_18

HP_CAS# HP_RAS# HP_WE# HP_CS0# HP_CKE HP_ODT

C319 100N 50V

C318 100N 50V

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

*****

06:H iDPR O SX-3

44

OEM MO D EL Size

TPV MOD EL

PCB NAME

Sheet

G4243-D-X-X-2-100726

***** 01

715G4243-M0A-000-0050

of

618Thursday , July 08, 2010

Rev

称爹

Custom

称爹

<

>

this GND should be connect to Cleanly GND

HP_VCC_25

120OHM

FB210

1 2

120OHM

FB211

1 2

120OHM

FB214

1 2

120OHM

FB216

1 2

120OHM

FB217

1 2

120OHM

VDDI_25

FB219

1 2

120OHM

FB220

3.3V

1 2

120OHM

3.3V

FB205

1 2

3VSB

1 2

FB208

120OHM

0R05 1/10W

9/1 at shanghai

R273

R274

C270

10uF 6.3V

2.2U25V

10uF 6.3V

C239

10uF 6.3V

C249

10uF 6.3V

C253

10uF 6.3V

C259

10uF 6.3V

C263

10uF 6.3V

C224

C221

C222

C233

C237

AGND_LAN

3.3V POWER FOR ADC OUTPUT BUFFER

120OHM

3.3V

FB221

1 2

3.3V FOR TMDS RECEIVER

C272

100N 50V

AVDD33_OUTBUF

C271

100N 50V

C273 10uF 16V

C219

100N 50V

C226 100N 50V

C223 100N 50V

C234 100N 50V

C238 100N 50V

C240 100N 50V

C250 100N 50V

C254 100N 50V

C260 100N 50V

C264 100N 50V

AVSSOUTBUF

AVCC33RX

U200D HIDTV

H5

AVDD33_SP

J6

R4

R2

C13

F13

D13

F14

E12

J13

E13

J14

E15

F15

T5

U5

U3

V6

AC22

AB21

E6

F7

K6

AGND_LAN

3.3V Analog Power for ADC AFE

AVDD33_SP

AVDD33

3.3V Analog Power for STANDBY

AVSS33

VCM_ADC

VCM for ADC

VSS25_AUDIO_AD C

VCM_DAC

VCM for DAC

VSS25_AUDIO_D AC

VCC25A

2.5V Analog Power for Audio CODEC

VSS25A

2.5V Power for Switch Circuits in ADC and DAC.

VCC25D

VSS25D

VCC25HP

2.5V Power for Head Phone

VSS25HP

VCC25A_BG

2.5V Analog Power for Ethernet BG

GNDA

VCC25A_TX

2.5V Analog Power for Ethernet TX

GNDA_TX

AVDD_MCK2

2.5V Analog Power for MCLK2 PLL

AVSS_MCK2

AVDD33OUTBUF

AVSSOUTBUF

AVCC33RX

3.3V Analog Power for OUTBUF

3.3V Analog power for T MDS receiver

HiDTV-Pro_SXB

2.5V LDO out for PLL & Analog core

3.3V for LDO & USB Analog Core

1.8V power shielding for MVREF1

1.8V power shielding for MVREF2

2.5V Analog power for LVDS PLL

(4/5)

2.5V Analog powr for LVDS

2.5V Analog powr for ANAPLL/APLL

2.5V Analog power for PLL

2.5V Power for ADCs

2.5V Analog power for T MDS receiver

PAVDDLLPLL

AVDD25_ADC 1

AVDD25_ADC 2

AVDD25_ADC 3

AVDD25_ADC 4

2.5V for TMDS PLL

2.5V for Audio PLL

VDDREG

AGNDREG

VDDA33

VDDR1 VDDR2 VSSR1 VSSR2

VDDP

GNDP

LVDS_VDD LVDS_VDD

LVDS_GND LVDS_GND

PAVSSLLPLL

AVDDPLL

AVSSPLL

AVSSADC1

INN1

AVSSADC2

INN2

AVSSADC3

INN3

AVSSADC4

INN4

AVCC AVCC

AGND AGND

PVCC

DGND

REGVCC

AA5

W6

AA6

AC23 G22 AE24 F22

E16

F16

D20 E20

F20 F21

E11 F12

R5 U6

E7 F8 A5 E9 F10 A8 E10 F11 A9 E8 F9 C7

F4 G5

G6 H6

F5

F6

E5

100N 50V

C220

HP_VDDP_USB

C227

100N 50V

C231

100N 50V

HP_LVDS_VDDP

C235 100N 50V

HP_LVDS_VDD

C241

100N 50V

PAVDDLLPLL PAVSSLLPLL AVDDPLL AVSSPLL

AVDD25_ADC 1

INN1 AVDD25_ADC 2

INN2 AVDD25_ADC 3

INN3 AVDD25_ADC 4

INN4

AVCC

PVCC

REGVCC

C242

100N 50V

C225 10uF 6.3V

C228 10uF 6.3V

C232 100N 50V

C236 10uF 6.3V

C243

100N 50V

C255 100N 50V

C258 100N 50V

C261 100N 50V

C262 100N 50V

C244

100N 50V

AVSSADC1 INN1_GND

AVSSADC2 INN2_GND

AVSSADC3 INN3_GND

AVSSADC4 INN4_GND

C245

10uF 6.3V

AVDD25_ADC 1

120OHM

FB206

1 2

HP_VCC_18

HP_VCC_25

120OHM FB209

1 2

120OHM FB212

1 2

10uF 6.3V

3.3V

C246

ANALOG PLL 2.5V POWER

PAVDDLLPLL

PAVSSLLPLL

C217

100N 50V

PLL 2.5V POWER

AVDDPLL

AVSSPLL

C229

100N 50V

HDMI Analog 2.5V POWER

AVCC

C247

100N 50V

2.5V FOR HDMI PLL

PVCC

C251

100N 50V

HDMI AUDIO PLL 2.5V

REGVCC

C256

100N 50V

C265

C266

100N 50V

C267

100N 50V

C218 10uF 6.3V

C230 10uF 6.3V

C248 10uF 6.3V

C252 10uF 6.3V

C257 10uF 6.3V

C268 22uF 10V

120OHM

FB204

120OHM

FB207

1 2

120OHM

FB213

1 2

120OHM

FB215

1 2

FB218

1 2

120OHM

HP_VCC_25

12

2.2uH R240

C269 22uF 10V

HP_VCC_25

45

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

07:HiDPRO SX-4

Date

OEM MOD EL Size

G4243-D-X-X-2-100726

TPV MODEL

***** 01

715G4243-M0A-000-0050

PCB NAME

718Thursday, July 08, 2010

of

Sheet

Custom

Rev

<

称爹

>

10uF 6.3V

C296

10uF 6.3V

HP_VCC _25

HP_VCC1V

C274

HP_VCC _18

HP_VCC1V

D18 D19 E17 E18 E19 F17 F18 F19

AA10 AA11 AA12 AA13 AA14 AA15 AA16

AA9

AA17

H21

J21

V21

W21

U21 K21

3VSB

E21

W5

AA7

AA8 AA18 AA19 AA20

10uF 6.3V

C297

100NF 25V

120OHM FB222

1 2

L6 M6 N6

R6

T6

J5

V5

Y5 Y6

C275

U200E

VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC

VDDF VDDF VDDF VDDF VDDF VDDF VDDF VDDF VDDF VDDF VDDF

VDDI _25

VDDC: 1.0V, core power

VDDF: 3.3V I/O power

C276

10uF 6.3V

C298

100NF 25V

VDDI_25

F24

AA24

AB23

F23

VDDI 25

G23

G21

H22

VDDM

VDDI25: 2.5V digital power for memory

VSS

J10

C279

J11

J12

J15

C302 100NF 25V

J16

J17

100NF 25V

VSS

J18K9K10

C280

VSS

AC26

100NF 25V

C299

10uF 6.3V

C278

10uF 6.3V

VDDI _25

J9

100NF 25V

C300

H23

J22

J23

K22

K23

L22

L23

M22

M23

N22

N23

P22

P23

R22

R23

T22

T23

U22

V22

V23

W22

Y21

Y22

W23

VDDM

VDDM: 1.8V, memory I/O power

HiDTV-Pro_SXB

(5/5)

POWER/GROUND

VSS

K11

K12

K13

K14

K15

K16

K17

K18L9L10

L11

L12

L13

L14

L15

L16

L17

L18M9M10

M11

M12

100NF 25V

C303

100NF 25V

HP_VCC 1V

C281

100NF 25V

C304

100NF 25V

1 2

C282

100NF 25V

120OHM FB223

C305

C283

10N 16V

C306

10uF 6.3V

C284

3VSB

VDDM

VSS

Y23

M13

VDDL

VDDM

VSS

AA21

VDDM

VSS

M14

HP_VCC_18

AA23

AB22

AA22

P21

N21

M21

L21P6T21

VDDM

VDDL: 1.0V, DLL and DDR Delay Line

VSS

M15

M16

M17

M18N9N10

N11

N12

N13

N14

N15

C285

C286

10N 16V

C307 100NF 25V

10N 16V

C308

100NF 25V

N16

C287

VSS

N17

VSS

VDDL

P9

R21

VSS

P10

VDDL

VSS

P11

P12

P13

C288

10N 16V

C309

100NF 25V

N18

VSS

P14

VSSL

VSS

P15

VSS

P16

P17

P18

C289

10N 16V

C310

100NF 25V

VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS VSS

HIDTV

C290 10N 16V

100NF 25V

C311

V18 V17 V16 V15 V14 V13 V12 V11 V10 V9 U18 U17 U16 U15 U14 U13 U12 U11 U10 U9 T18 T17 T16 T15 T14 T13 T12 T11 T10 T9 R18 R17 R16 R15 R14 R13 R12 R11 R10 R9

C320 10uF 16V

C312

100NF 25V

R269

NC 3. 3K 1/10W

R265

0R05 1/10W

3.3V

3.3K 1/10W

R270

R266

NC 0R 05 1/10W

R256

NC

R260

0R05 1/10W

No

1

2

3

4

5

6

7

8

NC

R271

R267

0R05 1/10W

3.3V

3.3K 1/10W

R261

NC 0R 05 1/10W

USB_PPON

FRA19/GCS0

FWE

FOE

FRA20

FRA21

FRA22

FRA23

NC

R264

R268

0R05 1/10W

NC 3. 3K 1/10W

R258

R257

R262

0R05 1/10W

Con figu re P in

ROM SIZE

VCO _ PC_ H W [1 :0]

EEPRO M_ BUR N

EJT AG_ SEL

CONM_SN

SYNC_MODE

PA RR_EN

I2C_8051_ SEL

R249

NC

R272 0R05 1/10W

R259 NC 3. 3K 1/10W

4.7 KOHM +-5% 1/16W RP104

4 3 2 1

R263

0R05 1/10W

R241 4.7K 1/10W

R248 4.7K 1/10W

R250 4.7K 1/10W

R251 4.7K 1/10W

R252 4.7K 1/10W

FRA19

5 6

FRA20 FRA21

7

FRA22

8

USB_PPON

FRA23

FWE#

GCS0

FOE#

FRA[ 19..22]

Description & Setting(* as default setting)

0 : 8bit(* ) 1 : 16bit

00 : aut o (fro m proc ess dete cto r) 01 : ss corn er(*) 10 : tt corner 11 : ff corner

0 : normal fu nc tion 1 : bu rn cod e for eep rom(*)

0 : non-daisy chain mode(*) 1 : daisy chain mode

0 : Slav e 8051 1 : M as ter 8051 (* )

0 : ASYNC mode (*) 1 : SYNC mode

0 : SPI Ena bled 1 : Parr allel FLA SH Ena bled (*)

0 : Disa ble Slav e I2C/Ena ble 8051 1 : Enab le Slave I2C/Disa ble 8051(*)

C291

10uF 6.3V

C293

100N 50V

C294

100N 50V

C315

10uF 6.3V

C316 100N 50V

46

T P V ( Top Victory Electronics Co . , Ltd. )

Date

*****

08:HiDPRO SX-5

絬隔瓜絪腹

Key Component

OEM MODEL Size

G4243-D-X-X-2-100726

TPV MOD EL

***** 01

PCB NAME

715G4243-M0D-000-0050

818Thursday , July 08, 2010

Sheet of

Rev

称爹

<

Custom

称爹

>

HP_WDQS[0..3] HP_RDQS[0..3]

HP_DQM[0..3]

HP_BA[0.. 2]

HP_VDDM

HP_MD[0..31]

HP_VDDM

HP_MCLK0

HP_MCLK0#

HP_RAS#

HP_CAS#

HP_WE#

HP_CS0#

HP_ODT

HP_CKE

HP_MCLK0 HP_MCLK0#

HP_WDQS1 HP_RDQS1

HP_WDQS0 HP_RDQS0

HP_DQM1 HP_DQM0

DDR_MVREF

HP_RAS#

HP_CAS#

HP_WE#

HP_CS0#

HP_ODT

HP_CKE

HP_BA2

G9G7G3G1E9C9C7C3C1A9J9R1E1

U400

VDDQ

J8

K8

F7 E8

B7 A8

F3 B3

J2

K7

L7

K3

L8

K9

K2

A2 E2

L1 R3 R7 R8

VDDQ

CK CK#

LDQS LDQS#

UDQS UDQS#

LDM UDM

VREF

RAS#

CAS#

WE#

CS#

ODT

CKE

NC_A2 NC_E2 BA2 NC_R3 NC_R7 NC_R8

VSSQ

H2F8F2E7D8D2B8B2A7N1J3E3A3

H8

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

A1

J1

M9P9

VDDVSS

VDD

VDDL

DQ0 DQ1 DQ2 DQ3 DQ4 DQ5 DQ6 DQ7

DQ8

DQ9 DQ10 DQ11 DQ12 DQ13 DQ14 DQ15

A0 A1 A2 A3 A4 A5 A6 A7 A8

A9 A10 A11 A12

BA0 BA1

VSS

VSSDL

J7

HP_MD14

G8 G2

HP_MD9

H7

HP_MD15

H3

HP_MD11

H1

HP_MD8

H9

HP_MD13

F1

HP_MD10

F9

HP_MD12

HP_MD5

C8 C2

HP_MD1

D7

HP_MD6

D3

HP_MD2

D1

HP_MD3

D9

HP_MD7

B1

HP_MD0

B9

HP_MD4

M8

HP_MA0 HP_MA1

M3 M7

HP_MA2

N2

HP_MA3 HP_MA4

N8

HP_MA5

N3 N7

HP_MA6

P2

HP_MA7

P8

HP_MA8

P3

HP_MA9

M2

HP_MA10

P7

HP_MA11

R2

HP_MA12

L2

HP_BA0

L3

HP_BA1

NT5TU64M16DG-BE

HP_MA[0. .12]

HP_MCLK0 HP_MCLK0#

HP_WDQS2 HP_RDQS2

HP_WDQS3 HP_RDQS3

HP_DQM2 HP_DQM3

DDR_MVREF

HP_RAS#

HP_CAS#

HP_WE#

HP_CS0#

HP_ODT

HP_CKE

HP_BA2

HP_VDDM

G9G7G3G1E9C9C7C3C1A9J9R1E1

U401

VDDQ

J8 K8

F7 E8

B7 A8

F3 B3

J2

K7

L7

K3

L8

K9

K2

A2 E2

L1 R3 R7 R8

VDDQ

CK CK#

LDQS LDQS#

UDQS UDQS#

LDM UDM

VREF

RAS#

CAS#

WE#

CS#

ODT

CKE

NC_A2 NC_E2 BA2 NC_R3 NC_R7 NC_R8

VSSQ

H2F8F2E7D8D2B8B2A7N1J3E3A3

H8

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

VDDQ

VSSQ

A1

J1

M9P9

VDDVSS

VDD

VDDL

VSS

VSSDL

J7

G8

DQ0

G2

DQ1

H7

DQ2

H3

DQ3

H1

DQ4

H9

DQ5

F1

DQ6

F9

DQ7

C8

DQ8

C2

DQ9

D7

DQ10

D3

DQ11

D1

DQ12

D9

DQ13

B1

DQ14

B9

DQ15

M8

A0

M3

A1

M7

A2

N2

A3

N8

A4

N3

A5

N7

A6

P2

A7

P8

A8

P3

A9

M2

A10

P7

A11

R2

A12

L2

BA0

L3

BA1

NT5TU64M16DG-BE

HP_MD22 HP_MD19 HP_MD20 HP_MD18 HP_MD16 HP_MD23 HP_MD17 HP_MD21

HP_MD28 HP_MD26 HP_MD29 HP_MD24 HP_MD25 HP_MD31 HP_MD27 HP_MD30

HP_MA0 HP_MA1 HP_MA2 HP_MA3 HP_MA4 HP_MA5 HP_MA6 HP_MA7 HP_MA8 HP_MA9 HP_MA10 HP_MA11 HP_MA12

HP_BA0 HP_BA1

C415

47uF/16V

HP_VDDM

+

HP_VDDM

47uF/16 V

C416

10uF 16V

C400

+

C431

10uF 16V

C405

10uF 16V

C417

100NF 25 V

C406

10uF 16V

C418

100NF 25 V

C407

100NF 2 5V

C419

100NF 25V

C408

100NF 25V

C420

100NF 2 5V

C409

100NF 25 V

C421

10N 50V

C410

100NF 25V

C422

10N 50V

C411

10N 50V

C423

10N 50V

C412

C424

10N 50V

C413

10N 50V

C414

10N 50V

DDR_MVREF

47

R400

1K 1/16W 1 %

R401

1K 1/16W 1 %

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

C402

100NF 25V

*****

09:GDDR2

C401 100NF 25 V

C403

100NF 2 5V

C430

100NF 25V

HP_MCLK0#

75R 1/16W 1%

R403

75R 1/16 W 1%

C404

10N 50V

OEM MODEL Size

TPV MODEL

PCB NAME

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

918Thursday , July 08, 2010

Sheet

of

HP_MCLK0

R402

Rev

称爹

<

Custom

称爹

>

D502

HDMI2_5V

10R 1/10W

10R 1/10W R573

3.3K 1/10W

R574

R572

R4H6

R4H1

3.3K 1/10W

1

2

BAV70

D503

1

2

BAV70

R4H2

3.3K 1/10W

3

3.3K 1/10W

C529 1UF16V

HDMI_5V_DET

R4H3

C534 1UF16V

C530 1UF16V

HDMI1_5V

HDMI3_5V

CN502

GND

HP DET

HDMI

GND

HP DET

HDMI

CN504

D2+

D2D1+

D1D0+

D0-

CK+

CK-

NC

GND

+5V

D2+

D1+

D0+

CK+

CK-

+5V

D2+

D1+

D0+

CK+

CK-

+5V

D2-

D1-

D0-

NC

CN503

D2-

D1-

D0-

NC

HDMI2

1

HDMI1_D2P

2 3

HDMI1_D2N

4

HDMI1_D1P

5 6

HDMI1_D1N

7

HDMI1_D0P

8

HDMI1_D0N

9 10

HDMI1_CLKP

11

HDMI1_CLKN

12 13

CEC

14 15

DDC1_SCL

16

DDC1_SDA

17 18 19

HDMI1PW HDMI_HPD1

R556

47K 1/10W

HDMI1_5V

HDMI3

R554

47K 1/10W

HDMI2_5V

1

HDMI2_D2P

2 3

HDMI2_D2N C1052

4

HDMI2_D1P

5

HDMI2_D1N

6 7

HDMI2_D0P

8

HDMI2_D0N

9

HDMI2_CLKP

10 11

HDMI2_CLKN

12

CEC

13 14

DDC2_SCL

15 16

DDC2_SDA

17 18 19

HDMI2PW HDMI_HPD2

HDMI4

R545

47K 1/10W

HDMI3_5V

1

HDMI3_D2P

2

HDMI3_D2N

3 4

HDMI3_D1P

5 6

HDMI3_D1N

HDMI3_D0P

7 8

HDMI3_D0N

9 10

HDMI3_CLKP

11 12

HDMI3_CLKN

13

CEC

14

DDC3_SCL

15

DDC3_SDA

16 17 18 19

HDMI3PW HDMI_HPD3

R559 47K 1/10W

R555 47K 1/10W

R544 47K 1/10W

120 OHM FB511

1 2

C533 100N 50V

120 OHM FB510

1 2

C532 100N 50V

120 OHM FB508

1 2

C521 100N 50V

HDMI1PW

HDMI1_5V

HDMI2PW

HDMI2_5V

HDMI3_5V

10R 1/10W

HDMI3PW

20

TH1

22

TH3

D2 Shield

D1 Shield

D0 Shield

CK Shield

CE Remote

DDC CLK

DDC DATA

23

TH4

21

TH2

20

TH1

22

TH3

D2 Shield

D1 Shield

D0 Shield

CK Shield

CE Remote

DDC CLK

DDC DATA

23

TH4

21

TH2

20

TH1

22

TH3

D2 Shield

D1 Shield

D0 Shield

CK Shield

CE Remote

DDC CLK

DDC DATA

23

TH4

HP DET

21

TH2

HDMI

4.7K 1/10W R203

HDMITX_5V

C528 100N 50V

HDMI SWITCH

3.3V

120 OHM FB502

1 2

DDC2_SDA DDC2_SCL HDMI2_CLKN HDMI2_CLKP HDMI2_D0N HDMI2_D0P HDMI2_D1N HDMI2_D1P HDMI2_D2N HDMI2_D2P HDMI_HPD2

DDC3_SDA DDC3_SCL HDMI3_CLKN HDMI3_CLKP HDMI3_D0N HDMI3_D0P HDMI3_D1N HDMI3_D1P HDMI3_D2N HDMI3_D2P HDMI_HPD3

10uF 16V

C523

DDC1_SDA DDC1_SCL HDMI1_CLKN HDMI1_CLKP HDMI1_D0N HDMI1_D0P HDMI1_D1N HDMI1_D1P HDMI1_D2N HDMI1_D2P HDMI_HPD1

100N 50V

C514

29 30 65 66 67 68 69 70 71 72 31 32

33 34

1 2 3 4 5 6 7

8 35 36

39 40 11 12 13 14 15 16 17 18 41 42

43 44 19 20 21 22 23 24 25 26 45 46

100N 50V

C516

U505

DSDA0 DSCL0 R0XCR0XC+ R0X0R0X0+ R0X1R0X1+ R0X2R0X2+ CBUS_HPD0 R0PWR5V

DSDA1 DSCL1 R1XCR1XC+ R1X0R1X0+ R1X1R1X1+ R1X2R1X2+ CBUS_HPD1 R1PWR5V

DSDA2 DSCL2 R2XCR2XC+ R2X0R2X0+ R2X1R2X1+ R2X2R2X2+ CBUS_HPD2 R2PWR5V

DSDA3 DSCL3 R3XCR3XC+ R3X0R3X0+ R3X1R3X1+ R3X2R3X2+ CBUS_HPD3 R3PWR5V

NC 1K OH M 1/16W

HD3V3

C515

100N 50V

9

27

64

VCC33

SII9187ACNU

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

Date

5VSB

R507

1UF16V

NC 2N 7002

Q502

C525

38

SBVCC

CEC

MICOM

37

MICOM_VCC33

48

3VSB

R1820

NC 27K 1/ 10W

R510

NC 1M 1/16W 5%

HDMI_CEC

3VSB

R564 NC

R4PWR5V

DSCL4

DSDA4

CEC_D

CEC_A

CSCL CSDA

TPWR/CI2CA

SBMODE

RSVD

2N7002

CSDA

Q501

OEM MO DEL Size

TPV MODEL

PCB NAME

VGA_VCC

R553 10R 1/10W

C522 1UF16V

R548 100 OH M 1/10W

49 48 47

R549 100 OH M 1/10W

57 56 59 58 61 60 63 62

51

R561

50

6.8K 1/10W

54

R560

53

0R05 1/10W

55

52

10

28

73

Q709

PMBS3904

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

10 18Thursday, J uly 08, 2010

of

MIC OM

0R05 1/10W

CSDA

C1094

NC 18P 50V

R543 0R05 1/10 W R546 0R05 1/10 W R547 4.7K 1/1 0W C526 NC

3VSB

R552

4.7K 1/10W

HDMI_SDA 7

HDMI_RX2HDMI_RX2+ HDMI_RX1HDMI_RX1+ HDMI_RX0HDMI_RX0+ HDMI_RXCHDMI_RXC+

TX2+

TX1+

TX0+ TXC-

TXC+

ePAD

Sheet

TX2-

TX1-

TX0-

INT

C524 100N 50V

NC 18P 50V

VGA_SCL VGA_SDA

R557

R558

NC 0R05 1/10W

R580

1K 1/10W

HDMI_SCL 7 HDMI_SDA 7

HD3V3

R541

4.7K 1/10W

HDMITX_INT

R542

NC 33 OHM 1/10W

HDMI_I2C_SW

Rev

称爹

<

Custom

称爹

8

>10:HDMI SWITCH

RX

VGA_SDA

VGA_HIN

VGA_VIN

VGA_SCL

1 2

BLU

3 4

DB15P

U100

I/O1

I/O4

GND

VDD

I/O2 I/O3

AZC199-04S

100OHM1/16W

R1001

R1005

CN103

1716

1

11

12

13

14

15

6 5

RED

6

RED_GND GRN

2

GRN_GN D

7 3

BLU

8

BLU_GND

4 9 5 10

1 2

VGA_SDA

VGA_SCL

ZD100 MLVG0402

VGA_5V

U101

AZC199-04 S

RX

VGA_HIN

R/G/B : 75 Ohm Trac e

1234

I/O1

I/O2I/O3

GND

VDD

I/O4

5

6

VGA_VCC

GRN

R1004

75 OHM 1/10W

GRN_GN D

RED

R1009

75 OHM 1/10W

RED_GND

0R05 1/10W

R1002

C1000

NC 180pF 50V

0R05 1/10W

R1007

C1004

NC 180pF 50V

100OHM1/16W

C1002

NC 180pF 50V

C1005

NC 180pF 50V

R1003

100OHM1/16W

R1008

100N 50V

C1001

100N 50V C1003

HID_RXD

HID_TXD

PC_G_IN

PC_R_IN

CN101

PHONEJACK

Near to IC

PC_HS_IN

PC_VS_IN

3VSB

U711

SN74LVC1G17DBVR

3 5

R1102 NC 1K 1/ 10W

C1006 100N 50V

1K 1/10W R1101

C1093 NC 22P 50V

Rev

称爹

PC_B_IN

VGA_SCL VGA_SDA

STB_HS_DET

Custom

<

称爹

>

1K 1/10W R1100

NC 180pF 50V

1K 1/10W R1071

0R05 1/10 W

C1007

C1100

NC 22P 50V

C1075

NC 22P 50V

R1010

STB_VS_DET

C1109 NC 22P 50V

C1008

NC180pF 50V

OEM MOD EL Size

TPV MOD EL

PCB NAME

D100

1

2

BAV70

R1025

180K 1/10W

R1026

100K 1/10W

3

10K 1/10W

R1024

2.2K 1/10W

VGA_VIN

R1021

2.2K 1/10W

180K 1/10W

R1023

VGA_VCC

R1017

4.7uF K 25V

C1011

C1013

4.7uF K 25V

R1027

100K 1/10W

R1016 10K 1/10W

VGA_HSYN_I N

C1012 22P 50V

C1010 22P 50V

PC_RI N

PC_LIN

100N 50V

C433

100N 50V

VGA_VIN

C436

2 4

3.3V

U710

2 4

SN74LVC1G17DBVR

3 5

C434

3.3V

SN74LVC1G17DBVR

3 5

2 4

VGA_5V

5VSB

120 OHM

FB100

1 2

1

VGA_AUR_O

2

3

VGA_AUL_O

BLU

R1012

75 OHM 1/10W

BLU_GND

U709

1K 1/10W R1020

3VSB

SN74LVC1G17DBVR

U712

3 5

R1103 NC 1K 1/10W

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

11:ANALOG _VGA

Date

100OHM1/16W

R1011

C435

100N 50V

VGA_HSYN_I N

Sheet

2 4

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

11 18Thursday, July 08, 2010

of

49

4.7K 1/10 W

3.3V

VCC_F LASH

R413

120OHM FB400

1 2

SPI_IO1 SPI_IO2

NAND_WP#

3VSB

U402

1

VCC

CS#

2

HOLD#

SO

3 4

SCK

W#

SI

GND

MX25L4005AM2C-12G

FRA18 FOE# GCS2

VCC_F LASH

FRA13 FRA14 FWE#

FRA13 FRA14

120OHM FB401

1 2

8

SPI_IO3

7 6

SPI_SCK SPI_IO0

5

4.7K 1/ 10W

0R05 1/ 10W

R415

VCC_F LASH

100N 50V

C425

3V_SF

4.7K 1/10 W

R411 33 OH M 1/10W

VCC_F LASH

R414

4.7K 1/ 10W R405

R404

R412 33 OH M 1/10W

U403

1

NC

2

NC

3

NC

4

NC

5

NC

6

NC

7

RB

8

R

9

E

10

NC

11

NC

12

VDD

13

VSS

14

NC

15

NC

16

CL

17

AL

18

W

19

WP

20

NC

21

NC

22

NC

23

NC

24 25

NC NC

NAND512W3A2CN6E

NC NC NC

NC I/O7 I/O6 I/O5 I/O4

NC

VDD

VSS

NC

NC I/O3 I/O2 I/O1 I/O0

NC

4.7K 1/ 10W R406

48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26

R407

4.7K 1/ 10W

NC

VCC_F LASH

NC

R410

R409

FRD7 FRD6 FRD5 FRD4

FRD3 FRD2 FRD1 FRD0

R408 33 OH M 1/10W

SF_HOLD # SF_SCK SF_SI

SF_WP# SF_SO

SF_C S

FRD[0..7]

C426

10uF 16V

C427

100N 50V

C428

100N 50V

C429 100N 50V

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

*****

12:HP_SX_ROM/FLASH

50

OEM MODEL Size

TPV MODEL

PCB N AME

Sheet

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

of

12 18Friday , July 23, 2010

Rev

称爹

Custom

称爹

<

>

3-RF AGC Monitor

TH2

TH3

TH4

222324

25

5V_TUNER

C752

+

220uF/10V

BT Monitor

9-SIF out

11-Video out

16-IF AGC

19-IFD out 1 20-IFD out 2

21-IF Monitor

TH1

10-VB

12-NC 13-SCL 14-SDA

15-AFT

17-+B

18-NC

TU100 TUNER

1-NC 2-BB

4-NC 5-NC

7-NC 8-NC

C1066

10uF 16V

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21

100N 50V

A5V-A

SIF A5V-B TV_VI DE O

A5V-C

100N 50V

C1065

C1041

82K 1%

R1061

C1043

18P 50V

100N 50V

MT_SI F

10K1/10W

A5V-C

C1045

R1062

+

C1040 100N 50V

R1093

300 OHM

FB110

1 2

C1042

10uF/50V

RFAGC

MTSCL

MTSDA

C1044

18P 50V

MTDI FON

MTDI FOP

100N 50V C1053

5

NC

6

VO

7

FB

8

GND

SC4215HSETRT

6.8KOHM +-1% 1/10W

5V_TUNER

C1047 100N 50V

1 2

C1046

+

10uF/50V

R1051

47 OHM 1/10W

9

TH1

U105

100N 50V

MTIF AGC

300 OHM

FB111

NC

VIN

EN NC

C1038

C1048 100N 50V

4.7K 1/10W

100 OHM 1/10W

R1029

R1030

100 OHM 1/10W

0R05 1/10W

4 3 2 1

3.3V

10uF/50V

C1039

1K 1/10W

R1033

+3.3V O

R1041

5V_TUNER

0R05 1/10W

R1056

R1059

C1057 47P 50V

5V

+

1K 1/10W

R1028

120OHM

FB112

R1060 10K 1/10W

FB103

300 OHM

1 2

300 OHM

FB109

1 2

R1042

4.7K 1/10W

R1148

1.2K 1/10W

C1054

18P 50V

L100

NC

12

C1021

220uF/16V

5V_TUNER

TNSC L

TNSD A

5VSB

R1049 1M 1/10W

20P 16MHZ

X100

1 2

C1061

NC

HP_VCC_25

C1064

10uF 16V

+

AGCCNTI

AGCCNTR

C1049 100N 50V

R1034

10K 1/10W

SLADRS1

SLADRS0

C1055

18P 50V

C1062

1UF16V

C1063

1UF16V

+3.3VO

C1050 100N 50V

MT_CVBS

C1029

100N 50V

300 OHM

FB101

1 2

300 OHM FB104

1 2

300 OHM FB106

1 2

300 OHM FB108

1 2

R1077

10K 1/10W

R1031

R1032 NC R1035 10K 1/10W

R1036

NC

R1037 10K 1/10W

R1038 10K 1/10W

R1039 20K 1/ 10W

R1040 20K 1/ 10W

R1043 10K 1/ 10W

C10561.5nF 50V

100N 50V

C323

+

10uF/16V

10uF 16V

C1014

1uF 25V

C1022

1uF 25V

C1030

1uF 25V

C1035

1uF 25V

51

C1058100N 50V

C1059100N 50V

C1060100N 50V

C1084100N 50V

C1085100N 50V

C1814

+3.3VO

C322

R1078 10K 1/10W

U106-1

1

TSMDO

2

3

5

6

7

8

9

10

11

12

14

18

19

21

24

25

26

27

28

29

30

R234 22K 1/10W

0R05 1/10W

R233 22K 1/10W

C1015 100N 50V

C1023 100N 50V

C1031 100N 50V

C1036 100N 50V

SRCK

XSEL1

SRDT

XSEL0

SBYTE

PBVAL

SLADRS1

SLADRS0

RSEORF

AGC1

RLOCK

S_INFO

RERR

AGCCNTI

FLOCK

AGCCNTR

STSFLG0

CKI

TNSC L

TNSD A

XO

SDA

SCL

XI

FIL

AD_VREFP

AV_VREFN

AD_VREF

SYRSTN

ADQ_AIN

TSMD1

ADQ_AIP

DTMB

ADI_AIN

DTCLK

ADI_AIP

STSFLG1

TC90517FG

R232

R230 75OHM +-5% 1/10W

R235 NC 0R 05 1/10W

C1037

1nF 50V

U106-2

32

AD_DVDD

31

AD_DVSS

43

DR2VDD

22

AD_AVDD

23

AD_AVSS

20

PLLVDD

17

PLLVSS

TC90517FG

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

SRCK_ORR

61

SRDT_ORR

60

59

SBYTE_ORR

58

PBVAL_ORR

0R05 1/10W

R1099

55

54

RLOCK_ORR

RERR_ORR

53

SLOCK_ORR

52

51

STSFLG0_ORR

46 45

42

41

40

39

STSFLG1_ORR

38

FB227

1 2

120R/600mA

2SC2412KR Q202

0R05 1/10W

DR1VDD DR1VDD

*****

13:Demodulator/ TUNER

100 OHM 1/10W

R1055 10K 1/10W

R1058 10K 1/10W

R1094

VDDS VDDS VDDS VDDS

VDDC VDDC VDDC VDDC

VSS VSS VSS VSS VSS VSS VSS VSS VSS

13 35 49 64

16 36 56 63

48 34

4 15 33 37 44 47 50 57 62

R1048

R1050

5 6 7 8

RP100

8P4R 33 OHM +-5% 1/16W

8 7

STSFLG1_ORR

6

SLADRS0

5

SLADRS1

8P4R 33 OHM +-5% 1/16W

R1046

OEM MOD EL Si ze

TPV MODEL

PCB NAME

Sheet

R1047

4.7K 1/10W

+3.3VO

R1057 10K 1/10W

C1068

4.7uF K 25V

L101

0R05 1/10W

C1018

C1017

100N 50V

C1025 100N 50V

C1033 100N 50V

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

of

13 18Thursday, July 08, 2010

5V_TUNER

+3.3VO

4.7K 1/10W

R1053

4.7K 1/10W

C1016 100N 50V

C1024 100N 50V

C1032 100N 50V

4 3 2 1

RP102

0 OHM 1/10W

R1054

C1067 NC 220pF 50V

C1026 100N 50V

TS1_D 0

TS1_D 1 TS1_D 2 TS1_D 3 TS1_D 4

1

TS1_D 5

2 3

TS1_D 6 TS1_D 7

4

100 OHM 1/10W

R280

1uF 25V

C1020

C1019 100N 50V

C1027 100N 50V

C1034

1uF 25V

SDA_MST1 SCL_MST1

RESET_Demo_#

100N 50V

C1051

FB102

300 OHM

0 OHM FB105

C1028

1uF 25V

FB107 0 OHM

Rev

称爹

T1_SIF

12

TS1_C LK

TS1_S YN C TS1_D EN

TS1_D[0..7]

TV_CVBS

+3.3VO

+1.2V

12

<

Custom

称爹

>

VCC33_AMP

C1616

47uF/16V

AMP_SD

C652

100N 16V

2R2 +-5% 1/8W R693

R694 0R051/8W

3.3V

+

AMP_MUTE

1 2

C1605

100N 50V

1uF 25V

5V

PHONE_D ET 7

PLL_Vdd

120OHM

FB607

C1613

R636 NC

10K 1/10W

C653

100N 16V

R638

C654

NC

I2S_CLK

I2S_CK

I2S_WS

I2S_SD

SW_AMP_RSTN

HDMI_SDA7 HDMI_SCL7

VCC33_AMP

100N 50V

C1615

VCC33_AMP

C655

4N7 50V

SW_AMP_RSTN

1 2

C666 100N 16V

10uF/50V

C1614

1

2

3

4

C1610

1uF 25V

BAS32L

D711

R1619

5.1K 1/10W

C1609

NC

R634

10K 1/10W

D604 LL4148

C6A1 Q604 MMBT3904

NC

R642 NC

R644 10K 1/10W

FB608

1 2

30 OHM

C647 100N 16V

R6472.2KOHM 1/10W

R1104 100 OHM 1/10W R1105 100 OHM 1/10W R1106 100 OHM 1/10W R1107 100 OHM 1/10W

FB613

30 OHM

0402

5V

+

16

15

/LSD

PVDD

CP+

APA2176A

PGND

CP-

NC

CVSS

VSS

567

0402

C656

680pF 50V

R650 100R 1/10W 1%

R652 100R 1/10W 1% R654 100R 1/10W 1%

C668

330P 50V

MUTE_PHONE

13

14

U602

APA2176

NC

GND

12

RIN

11

/RSD

10

LIN

9

ROUT

LOUT

VDD

8

C1607

100N 50V

R1617 20K 1/10W

PD_MUTE

VCC33_AMP

R640

NC

R646

NC

C649 330P 50V

PLL_FILTER PLL_GND

C1631

100N 50V

C1611 1uF 25V

C1612 1uF 25V

100N 50V

R641

10K 1/10W

Q606 NC

C1608

A_ONSEL A_GAIN

C665

100N 16V

0402

47K 1/10W

PLL_Vdd

R1628

Q607

C641

NC

U60 3

20

TWAR N/ OU T4B

21

VDD_DIG

22

GND_DIG

23

PWRDN

24

VDD_PLL

25

FILTER_PLL

26

GND_PLL

27

XTI

28

BICKI

29

LRCKI

30

SDI

31

RESET

32

INT_LINE

33

SDA

34

SCL

35

GND_DIG

36

VDD_DIG

37

Thermal Pad

STA3 39 BW1 3TR

PMBS3904

470OHM1/10W

C676

100N 50V

+

R1629

20K 1/10W

C638

100N 50V

OUT3AEAPD/OU T4A OUT3B

CONFIG

GND_REG

OUT1A

GND1

VCC1 OUT1B OUT2A

VCC2

GND2 OUT2B

VCC_REG

TEST_MODE

GND_SUB

C1096 10uF/50V

R1611

R1610

24V

R661

C670

0.47UF 50V

24V

R629

51K 1/10W

HEAT SI NK P90T0051-101

3.4KOHM +-1% 1/10W

R665

3.4KOHM +-1% 1/10W

R668

3.4KOHM +-1% 1/10W

R669

C658 1N 50V

C662 1N 50V

C664 1N 50V

+

C634 330uF 35V

D603 LL4148

R635

22KOHM 1/10W

2.8 +- 0.1mm

38.5 +- 0.15mm

C640 1N 50V

C644 NC/1N

C646 1N 50V

R675 NC/0R051/8W

R678 NC/0R051/8W

WSPK+

WSPK-

R676 NC/0R051/8W

LSPK-

4R677 0R051/8W 3 2 1

33G3278 4D

4P S/T 2.5mm

RSPK-

WSPK+ WSPK-

CN602

CONN

2 1

L+ L-

R+ R-

CN604 CONN

L

R

Woofer

24V

PD_MUTE

+

C672 330uF 35V

LSPK-

C674 330uF 35V

24V

+

Satellite

3 +- 0.1mm

40 +- 0.15mm

OEM MO DEL Size

G4243-D-X-X-2-100726

TPV MOD EL

***** 01

715G4243-M0D-000-0050

PCB NAME

Sheet

14 18Thursday, July 08, 2010

of

C673 330uF 35V

C675 330uF 35V

RSPK-

Custom

Rev

<

称爹

>

称爹

47uH L601

C639

100N 50V

C642

100N 50V

C648 100N 50V

C651

100N 50V

C660

100N 50V

C669

100N 50V

24V

12V

R632

R630

NC

R637

1K 1/10W

2.8 +- 0.1m m

R645

6.2 OHM +-5% 1/4W

C695

NC

C643

0.47UF 50V

R649

6.2 OHM +-5% 1/4W

R653

C661

0.47UF 50V

6.2 OHM +-5% 1/4W

R656

6.2 OHM +-5% 1/4W

24V

12

D602

RB160M-60TE25

5VSB

R628

10K 1/10W

R633

680OHM +-5% 1/10W

U605

C635

AS4 31AN- E1

100N 50V

O=2- 2 m m

3.6 +- 0 .1mm

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

14:AD5 2582

Date

47uH L603

47uH L604

R663

NC/22 OHM

C694

NC/330P

47uH L602

C657 100N 50V

C667 100N 50V

R662

HP_MUTE

PHONEJ ACK

CN601

22 OHM 1/4W

C671

330P 50V

C645

330P 50V

R643

22 OHM 1/4W

R651

22 OHM 1/4W

C663

330P 50V

AX_HP_OUTR

AX_HP_OUTL

24V

C6A3

C6A2

1U50V

1819 17 16 15

VDD

14 13 12 11 10 9 8 7 6 5 4

VSS

3 2

SA

1

R1630

3.3K 1/10W

1 2

1U50V

24V

C650 100N 50V

C659 100N 50V

BAS32L

D707

0R05 1/10W

ZD606

NC RLZ3.3B

R1615

1K 1/10W

R1616

1K 1/10W

R1634

+

5V

5 4 3 2 6 7 1

C636 330uF 35V

LOUT+

LOUTROUT+

ROUT-

52

USB_PPON

USB_OC

USB_DN USB_DP

PANEL POWER 1:ON ; 0:OFF

4.7K 1/ 10W

5VSB

R1155

1K 1/10W

NC RClam p0524P. TCT

U702

1

IN1

2

IN2

4

IN3

5 6

IN4 OUT4

GND

3

8

12V

PANEL_ON8

NC 4. 7K 1/10W

R702

10

OUT1

9

OUT2

7

OUT3

GND

FB701300 OHM 1 2

FB702NC 300 OHM 1 2

R704

USB_POW

4.7K 1/ 10W

R706

4.7K 1/ 10W

1UF1 6V C701

R703

BD8012F VJ

U701

1

GND

2

VIN

3

VIN

4 5

EN OC

USB_POW

VCC5_PAN EL_IN

R705

180K 1/10W

Q702

PMBS3904

OUT

OUT OUT

NC 0 OHM FB119

FB120 0 OHM

100K 1/10W

R1818

C704

0.22pF 25V

8

7 6

1 2 3 4

12

CONN

CN701

5V_2

5V

R701

10K 1/10W

1234

6 5

5VSB

1

S

2

S

3

S

4

G

AO4449 -7A/-30V

100N 50V

C702

DRC_EN

D D D D

Q701

VCCH1

100uF 16V

8 7 6 5

C705

100N 50V

+

C703

R2088

0R05 1/10 W

Panel Power

R707 NC 1K 1/ 10W

TX0AP TX1AP TX2AP

TXCKAP

TX3AP

4.7K 1/ 10W

R2084

PANEL_VC C

3.3V

+

C706

*****

15:Peripheral1

TX4AP

TX0BP TX1BP TX2BP

TXCKBP

TX3BP TX4BP

BL_ADJ

R2072

NC

SELLVDS

R2073

NC

3.3V

R2085

NC

PANEL_VC C

220uF/ 25V

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

CN704

43

2 4 6

8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42

R20870R05 1/ 10W R743 4.7K 1/ 10W

3VSB

NC

CN703

9 7 5 3 1

10 8 6 4 2

R710

1K 1/10W

OEM MO D EL Size

TPV MO D EL

PCB NAME

Sheet

1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41

CONN

44

R708

1K 1/10W

R709 NC

G4243-D-X-X-2-100726

715G4243-M0D-000-0050

of

15 18Friday , July 23, 2010

SELLVDS

0R05 1/ 10W

R2086

MCU_JTAG_TCK

MCU_JTAG_TDO

MCU_JTAG_TMS

MCU_JTAG_TDI

Rev

称爹

TX0AN TX1AN TX2AN

TXCKAN

TX3AN TX4AN

TX0BN TX1BN TX2BN

TXCKBN

TX3BN

TX4BN

PANEL_VCC

PANEL_PW M

01

称爹

<

3.3V

Custom

>

53

5VSB

+

C722 10N 50V

AZ1084S-3. 3TREI

U700

1

AIC1117- 33PY

C734 100N 50V

C739 100N 50V

C721

100N 50V

47uF/16V

5V

C735

47uF/16V

C738

3.3V

Linear equation: Vout=1.25v *(1+Rdow n/Rup)

SYS_PW Normal: High Stand_By: Low

POWER _ON

10K 1/10W

R713

VOUTVI N VOUT

ADJ

U705

AGND

G1084T43Uf

U706

1

10R 1/10W 5%

23 4

10N 50V

VOUTVI N

ADJ

C736 100N 50V

C740

+

100uF 16V

R714

AZ1084S2-AD JG1

U703

OUTPUTINPUT

ADJ/GN D

1

3VSB

+

+1.2V

C741 100N 50V

5VSB

R715 100KOHM 1/10W

Q704

PMBS3904

23

R733

100 OHM 1% 1/10W

R741

47 OHM +-1% 1/10W

Vout=1.25v*( 1+Rdown/Rup)=1.25*(1+4.7k/10k)=1.837V

24V

C737 47uF/16V

12V

5V

C742 100N 50V

NC 100K 1/ 10W

R1819

0.47UF

C708

3.3V HP_VDDM

C723

C724 100N 50V

4

23

4

VOUTVIN

VSS

1

470OHM1/10W

R729

23

R730

22K 1/10W

1K 1/10W

R716

NC 0 OHM FB121

FB122 NC

C743

10N 50V

AO4449 -7A/-30V

1 2 3 4

C709 NC 4.7uF K 25V

R740 NC

C725 100N 50V

12 12

U707

3 2

VIN VOUT

GND

1

Q700

8

S

D

7

S

D

6

S

D

5

G

D

C744

100N 50V

5V

HP_VCC _18

+

C707

100uF 16V

+

C726 47uF/16V

CN710

56

1 2 3 4

HP_VCC _25

+

C745 47uF/16V

R721

4.7K 1/10 W

1K 1/10W

R723

Q707

PMBS3904

NC 4. 7K 1/10W

1

4.7K 1/10W

2 3

R728

9.1KOHM +-1% 1/10W

5V

FB704

R719

R720

NC 4.7K 1/ 10W

R738

R724

1K 1/10W

120 OHM

1 2

C748

100pF 50V

R727

3K +-% 1/10W

C730 150pF 50V

C729

10uF 16V

3.3V

4.7K 1/10W

R734

NC 4. 7K 1/10W

Q708

NC PMBS3904

R742

0R05 1/10W

R722

5V

HP_VCC1V

+

3.3V

R744 NC 4.7K 1/ 10W

0 OHM 1/10W

R739

NC 1K 1/ 10W

C731 470uF/16V

3.3V

R737

AUX_POWER_ON#

R736

4.7K 1/10W

BL_ON#

BL_ADJ

0 OHM

5V_1

FB113

12 11 10 9 8 7

R655 10 0R 1/10W 1%

6

R657 10 0R 1/10W 1%

5 4 3 2 1

CN706

CONN

13 14

1 2 3 4 5 6 7 8 9 10 11

NC

CONN CN700

100N 50V

0 OHM

5V

1 2

C732

100N 50V

C700

FB703

12

C717

100uF/16V

5VSB

+

1U 25V

+

C718

FB114 0 OHM

100N 50V

C714

220uF/25V

R726

10K 1/10W

5V

12 12

HDMI_SCL HDMI_SDA

V18_SW MEMC5 V_SW V105DLL_SW RESET_FRC

C713

POWER_ON /OFF

C719 1U 25V

24V

100N 50V

+

C712 47uF 35V

APW7080KAITRL

U704

1

VIN

2

EN

3

UGND

4 5

VCC LX

C720 1U 25V

Vout = 0.8x(1+ R727/R728) =1.066V

20100419:G5627 Change to 7080!

5V_2

GND

COMP

LX

9

C710

FB

NC 0 OHM FB115

FB116

NC 0 OHM

8 7 6

5V_1

12V

12 12

+

4.7K 1/10 W

C728

3.3nF 25V

D701 SM340A

BL_ON/OF F

C715

100N 50V

C711

220uF/25V

R718

Q706

PMBS3904

R725 33K 1/10W 5%

C716

22pF 50V

L700 10uH

10uF 16V

5VSB

C727

54

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

Date

16:Power

OEM MODEL Size

G4243-D-X-X-2-100726

TPV MODEL

***** 01

715G4243-M0D-000-0050

PCB NAME

Sheet

16 18Monday, J uly 26, 2010

of

Rev

称爹

<

Custom

称爹

>

JACK

CN102

A

B

C

0R05 1/10W

Y

MLVG0402

2

1

4

3

6

5

MLVG0402

PB_GND

MLVG0402

ZD101

Y_GND

PB

ZD102

PR

ZD104

PR_GND

1 2

R1065 75 OHM 1/10W

R1068 75 OHM 1/10W

R1072 75 OHM 1/10W

R1063

0R05 1/10W

R1066

0R05 1/10W

R1069

C1071 NC

C1074 NC

C1078 NC

R1064

0R05OHM1/16W

R1067

0R05OHM1/16 W

R1070

0R05OHM1/16W

Near to IC

C1069

100N 50V

C1072

100N 50V

C1076

100N 50V

Y1_I N

PB1_IN

PR1_IN

C1102

100N 50V

CONNNECTOR

5V

22 OHM 1/8W

R1110

CN603

5

Shield

GND

4

Vcc

123

GND

Shield

Vin

10N 50V C1077

22 OHM 1/8W

R1079

C1101 100P 50V

HP_SPDI F

JACK

B

A

CN104

PHONEJ ACK

CN105

2 5 4 3 1

CVBS & R/L

AV_R AV_L

CVBS1

HP_VCC_25

CVBS1

ZD105

MLVG0402

AV_L

AV_R

82K 1/10W

R1074

R1073

82K 1/10W

1 2

R1075

100K 1/10W

2.2uH L102

R1081 75 OHM 1/10W

CVBS1_GND

R1091

82K 1/10W

R1092

82K 1/10W

R1076

100K 1/10W

R1095

100K 1/10W

3

COM_AUR

4

1

COM_AUL

2

4U7 10V

C1080

C1079

4U7 10V

100OHM1/16W

R1080

C1083 220pF 50V

R1096

100K 1/10W

100N 50V

C1082

C1091

4U7 10V

C1092

4U7 10V

HD_RIN

HD_LIN

CVBS1_IN

AV_LIN

AV_RIN

LAN_RXIN+ LAN_TXIN+ LAN_RXIN-

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

*****

17:ANALOG_VI DEO

Date

1 2

ETH_VCC_25

NC

R1808

NC

C1810

NC

FB1805

C1812

NC

C1805

OEM MODEL Size

TPV MODEL

PCB N AME

Sheet

ETH_VCC_25

C1813 NC

CN707

R1R2R3R4R5R6R7R8L1L2L3

1234567891011

C1806

NC

R1809

NC

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

17 18Friday, July 23, 2010

of

NC

R1811

NC

C1811

NC

For Debug Use

NC

FB1809

1 2

FB1810

GND_ETH

NC

1413

TH2TH1

L4

12

GND_ETH

C1807

C1808

NC

R1810

NC

LAN_TXIN-

Rev

称爹

<

Custom

>

55

3VSB

5VSB

C751

47uF/16V

NC

CN402

23

IR_D

C215 100N 50V

4.7K 1/10W

1

R215

4.7K 1/10W

R212

IR_D

LED_R

LED_B

PW_KEY

KYBR D

LED_R

LED_B

R216

3VSB

Q200

PMBS3906

R217 10K 1/10W

C210 100N 50V

+1.2VSB

23

1

Q201

R229

10K1/10W

120OHM

1 2

ZD611 RLZ5.6B

1 2

C277 100N 50V

1 2

FB201

1 2

ZD610 RLZ5.6B

1 2

120OHM FB225

1 2

120OHM

ZD609 RLZ5.6B

R221

1K 1/10W

+1.2 VSB

C747 100N 50V

3VSB

C292 100N 50V

STB_SDA STB_SCL

ZD608

RLZ5.6B

L_B

RLZ5.6B

L_R

ZD612

1 2

U715

3 2

VI VO

+

C749 100N 50V

L_R

3

L_B

2 1

CN401

CONN

GND

1

47uF/16V

1 2 3 4 5 6 7 8 9 10 11 12 13

+

C750

L_R L_B

R551 100 OHM 1/10W R550 100 OHM 1/10W

1K 1/10W

1 2

FB202

120OHM

1 2

FB224

R213

120OHM

FB200

PMBS3906

1K 1/10W

R209

10K1/10W

C209

100N 50V

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

*****

18:KEY AND IR IN TERFACE

56

OEM MODEL Size

TPV MODEL

PCB NAME

Sheet

G4243-D-X-X-2-100726

***** 01

715G4243-M0D-000-0050

of

18 18F riday , July 23, 2010

Rev

称爹

Custom

称爹

<

>

9.2 Power Board

715G4078P01W22003H

SG904 EM230X

R901

330K 1/4W

C902

220pF +-10%

C901

220pF +-10%

F901 5A 250V

t

NR901

NTCR

L902 8mH

3

C904

0.47UF

R902

330K 1/4W

L901 8mH

3

C903

0.47UF

CN901 CONN

t

NR902

12

NTCR

SG903

EM230X

142

R903

330K 1/4W

C906

220pF +-10%

142

C905

220pF +-10%

1

2

L

N

BO

2

BD901

FB902

KBJ1008G-F

+

-

1

4

3

0.47uF 520V

R998 43K 1/8W

C937

R9100

10KOHM +-5% 1/8W

C957

47N 50V

1 2

BEAD

IC930

1

INV

2

COMP

3

RAMP

4 5

CS ZCD

LD7591GS

VCC OUT

GND

C956

0.47UF 50V

8 7 6

68P 50V

C942

R9125 13K 1/8W 1%

C948 1N 50V

D921 1N5408-E3/73

D922 3A/600V

R981 20K 1/4W

R990 2K 1/8W 5%

BO

B1+

R9180

1MOHM +-5% 1/4W

C975

0.1uF 50V

1 2

VCC1

+

47UF 50V

R995 13K 1/8W 1%

PR1007

R9179

1MOHM +-5% 1/4W

FB904

BEAD

R978

10 OHM +-5% 1/8W

C944

D930

1MOHM +-5% 1/4W

+

C938 39uF 450V

1N4148-B4006

R979

33 OHM +-5% 1/4W

C943 100N 50V

C949 220P 50V

R9146

1M5 1/4W 1%

R9121

1 2 3 4 5

+

C939 39uF 450V

D923

R9173

10K 1/4W

R993 470OHM +-5% 1/8W

1M5 1/4W 1%

IC919

BNO

OVP

COMP

VCC

NC

OUT

CS GND

LD7523GS

R9147

8 7 6

+

C9101 39uF 450V

Q921 14A/600V

R980 0R1 5% 2W

1M5 1/4W 1%

VCC1

+

R9150

C977

10UF 50V

C9102 39uF 450V

B+

R982 680K OHM +-1% 1/4W

R985 680K OHM +-1% 1/4W

R989 680K OHM +-1% 1/4W

C979

0.1uF 50V

R9127 10K 1/8W

C983 220P 50V

R9137

0.47 OHM +-5% 1W

C986 10nF

C993 220N 50V

C969

2200PF2KV

10 OHM 1/8W

470 OHM 1/8W

R9122

R9132

R9138 100K 1/4W

R9142 100K 1/4W

1R2 5% 2W

R9152 560K 1/8W 1%

R9113 100K 1/4W

R9115 100K 1/4W

R9124

22 OHM 1/8W

R9153

D929

SCS0520P

R9129

10K 1/8W

0R36 5% 2W

R9139 100K 1/4W

R9143 100K 1/4W

PR1007

12

D931

R9114 100K 1/4W

R9116 100K 1/4W

D928 PR1007

R9134

C985 2200PF2KV

R9149

4.7 MOHM +-5% 1/4W

IC922

A6069H

1

S/OCP

2

BR

3

GND

4 5

FB/OLP VCC

C995

1N 50V

T902

YUVA-1427

6

7 8

9

10

Q925 8A/800V

D/ST D/ST

100N 50V

T903

YUVA-1426

10

9

8 7

6

VCC

R9151 2R2 +-5% 1/4W

D935

PR1007 D934 1N4148

8 7

C996

5

4 3

2 1

3

1

3

1

+

C994

10UF 50V

100 OHM 1/4W

2

D926

FME-210B

D927 FMEN-220A

2

R9119 100 OHM 1/4W

R9120

100 OHM 1/4W

R9107

R9108

+

C997

100UF 50V

+

C965 1000uF 35V

R9140

47 OHM 1/4W

1

R9144

47 OHM 1/4W

2 3

D932

3

FMWN-2308

5 4

2

1

12

43

IC923

PC123X8YFZ OF

C999 220N 50V

IC925

AS431AZTR-E1

L907 5uH

+

L908 5uH

+

C970 1000uF 35V

1KOHM +-5% 1/8W

C967 150UF 35V

+

C971 100UF 50V

2200pF

+

470uF 10V

R9154 470 OHM 1/4W

R9155

3.3KOHM +-5% 1/8W

R9161

C968

0.1uF 50V

C972

0.1uF 50V

C988

C990

R9156

8.2K +-1% 1/8W

+24V

+12V

+

470uF 10V

C991

5V

L909 5uH

C992 470uF 16V

R9166 7K5 1/8W +/-1%

+

2N3904S-RTK/PS

Q926

R9111

1.5K 1/4W

R9117

1.5K 1/4W

5V

C9100 100N 50V

R9181

5.1K 1/4W

+12V +24 V

1 2

+24V

R9112

1.5K 1/4W

+12V

R9118

1.5K 1/4W

R9182

5.1K 1/4W

ZD908 MTZJ T-72 1 6B

D937 1N4148

R9159 1KOHM +-1% 1/8W

R9162

1KOHM +-1% 1/8W

ZD910 MTZJ T-7 2 30B

1 2

D938 1N4148

R9183

5.1K 1/4W

+80V

1 2

R9184

5.1K 1/4W

ZD911 MTZJ T-7 2 30B

D939 1N4148

+24V

C987

470pF/250V

C981

470pF/250V

FB903

1 2

BEAD

R9123 2K 1/4W

12

43

C976

10N 50V

FB906

C984

R9104 1K 1/8W

12

IC918

PC123X8YFZOF

Q924 2N3904S-RTK/PS

470pF/250V

C962

100N 50V

1 2

BEAD

R9105

10K OHM 1/8W

R9106 10K OHM 1/8W

PS_ON

VCC1

+

10UF 50V

Q923

KTD1691/P

C961

R9103 10K 1/8W

ZD905 MTZJ T- 72 16B

1 2

5V

VCC

43

IC920

PC123X8YFZOF

R9133

10K 1/8W

IC921 AS431AZTR-E1

R9128

3.9K 1/8W

C982

0.33uF 50V

+12V

R9130 24KOHM +-1% 1/8W

R9135 2KOHM +-1% 1/8W

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

02.AC input

Date

+24V

R9131

27K +-1% 1/8W

R9136 NC

OEM MOD EL Si ze

TPV MODEL

PCB NAME

Sheet

77Thursday, May 20, 2010

of

PS_ON

ON/OFF

DIM

+12V

+24V

5V

CONN

13 12 11 10

9 8 7 6 5 4 3 2 1

CN904

A2

Rev

1.0

<

称爹

>

称爹

57

B+

C925 1N 50V

R948

0.1 ohm

R962

2Mohm 1/4W +/-1%

R964 27K 1/8W 1%

B1+

R952

2Mohm 1/4W +/-1%

R953

2Mohm 1/4W +/-1%

VCC1

R949

10R 1/8W 5%

D914 UF4007

C914 1U 25V

IC914

1

Vsen

NC

2

Vcc

NC

3

FB

VGH

4

GND

VS

5

Css

VB

6

OC

NC

7

RC

NC

8

Reg

VGL

9 10

RV COM

SSC9502S

C922

10pF/3KV

18 17 16 15 14 13 12 11

VBoot

C915 1U 25V

12

ZD902

MTZJ T-72 15B

47OHM +-5% 1/8W

10KOHM +-5% 1/8W

47OHM +-5% 1/8W

10KOHM +-5% 1/8W

D915

1N4148

R950

D918 1N4148

R960

R951

R961

VBoot

Q919

9.5A/ 500V

Q920

9.5A/ 500V

VBoot

T901

YU VA-1428

12 11

8 7

C928

0.027uF 5% 1000V

+

C912 12UF 160V

80V

C921 NC

80V1

L904 5uH

SF35G

D917

6 5

4 3

2 1

D919

SF35G

+

C916 120UF 160V

+

C918 120UF 160V

12UF 160V

C917

+

C919

100N 50V

+

C920

10UF 50V

R963 2K43 1/8W 1%

C924

4.7UF 50V

C923 100N 50V

C927

4.7UF 16V

43

R965 NC

680P 50V

R969

4.3KOHM +-5% 1/8W

12

IC915 PC123X8YFZ OF

IC916 AS431AZTR-E1

R966

680OHM +-5% 1/8W

C929

ZD907

MTZJ T-72 30B

1 2

R970

3.3KOHM +-1% 1/8W

R967 200R 1/8W 1%

MTZJ T-72 30B

C933 NC

C934 220NF 50V

ZD903

1 2

R973

9.1K 1/8W

R975 43K 1/8W 1%

C926

100PF1KV C930 1N 50V

ZD904

MTZJ T-72 30B

1 2

R968

47KOHM +-1% 1/8W

C936 68P 50V

C931

NC

R971

47KOHM +-1% 1/8W

VFB

R974 2K4 1/8W 1%

C935

470pF/250V

80V1

FB901

1 2

BEAD

80V

R972 100K 1/8W 1%

R976 27K 1/8W 1%

+80V

58

R955

R954 100K 1/4W

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

03.MAINPOW ER

Date

100K 1/4W

47Thursday , May 13, 2010

R958 100K 1/4W

of

R956 100K 1/4W

R957 100K 1/4W

OEM MO DE L S ize

TPV MO DEL

PCB NA ME

Sheet

R959 100K 1/4W

Rev

称爹

B

1.0

<

称爹

>

VCON

R904

3.3K 1/4W

IC901

AZ432ANTR-G1

10OHM 1% 1/4W

VCON

R910

3.3K 1/4W

IC907

AZ432ANTR-G1

10OHM 1% 1/4W

R916

R922

LED1

LED7

Q907 12A/500V

R9222 10OHM 1% 1/4W

Q901 12A/500V

R9216 10OHM 1% 1/4W

VCON

R905

3.3K 1/4W

IC902

AZ432ANTR-G1

10OHM 1% 1/4W

VCON

R911

3.3K 1/4W

IC908

AZ432ANTR-G1

R923

10OHM 1% 1/4W

R917

Q902 12A/500V

R9217 10OHM 1% 1/4W

Q908 12A/500V

R9223 10OHM 1% 1/4W

VCON

R906

3.3K 1/4W

IC903

AZ432ANTR-G1

10OHM 1% 1/4W

VCONLED8

R912

3.3K 1/4W

IC909

AZ432ANTR-G1

R924

10OHM 1% 1/4W

IC906 AZ432ANTR-G1

R921

IC912

AZ432ANTR-G1

R927

LED6

Q906 12A/500V

R9221 10OHM 1% 1/4W

LED12

Q912 12A/500V

R9227 10OHM 1% 1/4W

LED10

LED1

ON/OFF

+12V

LED2

1

2

3

D901 BAV70

LED3

LED4

LED5

2

1

2

D902 BAV70

3

Q913 2N3904S-RTK/ PS

LED6

1

D903 BAV70

3

R929

10K 1/8W

R930 10KOHM +-5% 1/8W

LED7

2

LED short protector

LED8

1

3

2N3906S-RTK/ PS

D904 BAV70

C907 NC

Q914

LED9

2

3

R931

20K 1/8W

1

D905 BAV70

R928

100K 1/8W

LED11

2

1 2

LED12

3

1 2

ZD909 MTZJ T-72 36 B

VCON

1

D906 BAV70

ZD901 MTZJ T-72 36B

Q905 12A/500V

R9220 10OHM 1% 1/4W

Q911 12A/500V

R9226 10OHM 1% 1/4W

VCON

R909

3.3K 1/4W

10OHM 1% 1/4W

VCON

R915

3.3K 1/4W

10OHM 1% 1/4W

LED3

Q903 12A/500V

R9218 10OHM 1% 1/4W

R918

LED9

Q909 12A/500V

R9224 10OHM 1% 1/4W

R907

3.3K 1/4W

AZ432ANTR-G 1

10OHM 1% 1/4W

VCON

R913

3.3K 1/4W

AZ432ANTR-G 1

10OHM 1% 1/4W

IC904

IC910

LED4VCON

Q904 12A/500V

R9219 10OHM 1% 1/4W

R919

LED10

Q910 12A/500V

R925

R9225 10OHM 1% 1/4W

VCON

R908

3.3K 1/4W

IC905

AZ432ANTR-G 1

R920

10OHM 1% 1/4W

VCON

R914

3.3K 1/4W

IC911

AZ432ANTR-G 1

10OHM 1% 1/4W

LED5LED2

LED11

R926

+12V

R936 1K 1/8W

AS431AZTR-E1

R941

5.6K 1/8W

LED1 LED2

2

3

Q917

2N3904S-RTK/PS

IC913

10K 1/8W

DIM

12 channel self-feedback balance loops

D910 BAW56

LED9

2

LED10

1

3

1 2 3 4 5

D911 BAW56

IC926

1OUT 1IN1IN+ GND 2I N+

LM258D

LED11

D913

1N4148

VCC

2OUT

2IN-

LED12

2

1

D912 BAW56

3

VDECT

R9175 10K 1/8W

+12V

R935

C909

10K 1/8W

NC

8 7 6

C989 2U2 25V

VFB

Q915

2N7002

LED5

D908 BAW56

C910

10UF 50V

LED6

2

1

3

R937

10K 1/8W

R943

9.1KOHM +-1% 1/8W

R945 22KOHM +-1% 1/8W

LED4

LED3

2

R939

10K 1/8W

C913 NC

1

3

+

1

D907 BAW56

R947

D909 BAW56

LED8

LED7

2

1

3

R940

100KOHM +-5% 1/4W

R944

10K 1/8W

R946

C911

NC

100N 50V

ON/OFF

R942

220R 1/8W 5%

R9177 91KOHM +-5% 1/8W

R9178 1M 1/8W 5%

Balance Circuit controller

LED12 LED11 LED10

LED9 LED8 LED7

Q918 2N7002

R938

100R 1/8W 5%

80V

CN902

13 12 11 10

9 8 7 6 5 4 3 2 1

CONN

R932 100K 1/8W

R9172 10KOHM +-5% 1/8W

LED6 LED5 LED4

LED3 LED2 LED1

R934 10K 1/8W

Q916 200mA/40V

R9176 10K 1/8W

80V

CN905

12 11 10

9 8 7 6 5 4 3 2 1

CONN

80V

Output Compensation

Titl e

<Title>

Size Document Number Rev

C

Date: Sheet

57Tuesday , May 11, 2010

of

59

9.3 Key Board

715G4531K01000004S

Buttons

CHMENU Input Power VOL+ VOLCH+

220 OHM 1/10W 5%

T02 T07 T01 T06 T05 T04 T03

R010

VCC

1

BlueRed

2

3

R011 330 OHM 1/10W

VCC

C001

100N 16V

R012 NC

R013 NC

R014 0R05 1/16W

LED001

12-22/BHR6C -C31/ 2C

C002

1uF 25V

1

SI[ 0]

2

SI[ 1]

3

SI[ 4]

4

SI[ 5]

5

SI[ 6]

6

SI[ 7]

7

SI[ 8]

8

SI[ 11]

293031

32

33

SENSE[ 1]

SENSE[ 2]

PWMO_EN

PWM O_SLT

Thermal Pad

TEST

INT

MTM

SLOW_MOD E_N

9101112131415

27

28

VDD

VSS

25

26

OUT[ 1]

OUT[ 0]

SENSE[ 0]

PWMO[0]

PWMO[1]

WIN_CTL

OUT[ 11]

OUT[ 8]

5701-UG320WT

16

U001

OUT[4] OUT[5]

SCL

SDA

OUT[6] OUT[7]

R007

20K 1/10W

R006

10K1/10W

24 23 22 21 20 19 18 17

0.901V MENU

0.603V Input

0.012V Power

I2C_SCL I2C_SDA

R002

R009

R016

NC

I2C_SDA

KEY_I N

PKEY_OU T

VCC

Q003

NC

R015 0R05 1/16W

R001

NC

VCC

KEY_IN PKEY _OUT I2C_SCL I2C_SDA_X LED_B LED_R

I2C_SDA_X

VCC

R008

NC

10

9 8 7 6 5 4 3 2 1

CN001

CONN

CH-

CH+

VOL-

VOL+

0.012V

0.304V

0.606V

0.901V

100R 1/10W 1%

R003

3K3 1/10W 1%

R005

6.8KOHM +-1% 1/10W

R004

20K 1/10W

100R 1/10W 1%

Q001 LMBT3904LT1G

LED_B

Q002 LMBT3904LT1G

LED_R

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

2.0. key

60

OEM MODEL Size

TPV MOD EL

PCB NAME

Sheet

xxxx E

of

22Wednesday , May 05, 2010

Rev

称爹

<

A

称爹

>

9.4 IR Board

715G4086R01001005F

CN201

CONN

3

IRRV

2 1

4 5

33G8032 3F HR

IRRX

VCC

R202 0R 05 1/10W

R201 15K 1/10W

C201

0.1uF 50V

VCC

R205 NC 1K 1/10W

R203

NC 4.7K 1/10W

R204 NC 1K 1/10W

C202

NC 100pF 50V

IRRX

U201

1

VOUT

2

GND

3

VCC

KSM-603TM2M

56G 627911

Q201 NC PMBS3904

IRRV

R206 NC 1K 1/10W

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

G 4086-R0C-000-0040-100210

02-IR

OEM MOD EL Size

TPV MODEL

PCB NAME

Sheet

X

TV2469W-8AD C

715G4086

of

11Wednesday , June 02, 2010

61

Rev

称爹

<

A

称爹

>

9.5 MEMC Board

715G4242M01000005K

U2401E

DRAM_TEST_D2

DRAM_TEST_AN

DRAM_DQS2

DRAM_DQS2_N

DRAM_DQS3

DRAM_DQS3_N

DRAM_DQS0

DRAM_DQS0_N

DRAM_DQS1

DRAM_DQS1_N

DRAM_CK_N

DRAM_CAS_N

DRAM_RAS_N

DRAM_WE_N

DRAM_CS_N

FRC9459S

DRAM_DQ16 DRAM_DQ17 DRAM_DQ18 DRAM_DQ19 DRAM_DQ20 DRAM_DQ21 DRAM_DQ22 DRAM_DQ23 DRAM_DQ24 DRAM_DQ25 DRAM_DQ26 DRAM_DQ27 DRAM_DQ28 DRAM_DQ29 DRAM_DQ30 DRAM_DQ31

DRAM_DM2 DRAM_DM3

DRAM_DQ0 DRAM_DQ1 DRAM_DQ2 DRAM_DQ3 DRAM_DQ4 DRAM_DQ5 DRAM_DQ6 DRAM_DQ7 DRAM_DQ8

DRAM_DQ9 DRAM_DQ10 DRAM_DQ11 DRAM_DQ12 DRAM_DQ13 DRAM_DQ14 DRAM_DQ15

DRAM_DM0

DRAM_DM1

DRAM_A0 DRAM_A1 DRAM_A2 DRAM_A3 DRAM_A4 DRAM_A5 DRAM_A6 DRAM_A7 DRAM_A8

DRAM_A9 DRAM_A10 DRAM_A11 DRAM_A12

DRAM_BA0 DRAM_BA1 DRAM_BA2

DRAM_CK

DRAM_ODT

DRAM_CKE

W12

W6

R2061 NC R2062 NC

W7

R2063 NC

W5

AB2

DRAM_VREF

V2 AA2 V3 U1

DRAM _TEST_D1

AB6 W3 AA6 Y5 W2 Y4 AA1 W1 Y6 Y1 AA5

Y3 AA3 AA4 AB4

AB1 Y2

V20 Y17 V21 AA20 AB16 U21 AA17 W22 W20 AA18 AB21 AA19 Y18 W21 AB18 Y21

AB20 AA21 AB22 AA22

Y20 Y19

AA9 AB8 AA8 Y9 Y8 AA7 Y7 AA14 Y14 Y15 AA15 AA16 Y16

AA11 Y11 Y10

AA10 AB10

AA12 Y13 Y12 AB14 AA13 AB12

VDD18

100N 16V

C2040

C2041

100P 50V

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

1

8

2

7

3

6

4

5

R2027 62R 1/ 16W 5% R2028 62R 1/ 16W 5% R2029 62R 1/ 16W 5% R2030 62R 1/ 16W 5% R2031 62R 1/ 16W 5% R2032 62R 1/ 16W 5% R2033 62R 1/ 16W 5% R2034 62R 1/ 16W 5% R2035 62R 1/ 16W 5% R2036 62R 1/ 16W 5% R2037 62R 1/ 16W 5% R2038 62R 1/ 16W 5% R2039 62R 1/ 16W 5%

R2040 62R 1/ 16W 5% R2041 62R 1/ 16W 5% R2042 62R 1/ 16W 5%

R2044 33 OHM 1/16W R2045 33 OHM 1/16W

R2046 62R 1/ 16W 5% R2047 62R 1/ 16W 5% R2048 62R 1/ 16W 5% R2049 62R 1/ 16W 5% R2050 62R 1/ 16W 5% R2051 62R 1/ 16W 5%

R2002

1K 1/16W 1%

R2003 1K 1/16W 1%

DRAM_DQ0 DRAM_DQ1 DRAM_DQ2 DRAM_DQ3 DRAM_DQ4 DRAM_DQ5 DRAM_DQ6 DRAM_DQ7 DRAM_DQ8 DRAM_DQ9 DRAM_DQ10 DRAM_DQ11 DRAM_DQ12 DRAM_DQ13 DRAM_DQ14 DRAM_DQ15

DRAM_DQS0_P DRAM_DQS0_N DRAM_DQS1_P DRAM_DQS1_N

DRAM_DM0 DRAM_DM1

RP2302

1 KOHM +-5% 1/16W

RP2303

1 KOHM +-5% 1/16W

RP2304

1 KOHM +-5% 1/16W

RP2305

1 KOHM +-5% 1/16W

RP2306

1 KOHM +-5% 1/16W

RP2307

1 KOHM +-5% 1/16W

DRAM_A0 DRAM_A1 DRAM_A2 DRAM_A3 DRAM_A4 DRAM_A5 DRAM_A6 DRAM_A7 DRAM_A8 DRAM_A9 DRAM_A10 DRAM_A11 DRAM_A12

DRAM_BA0 DRAM_BA1 DRAM_BA2

DRAM_CK_P DRAM_CK_N

DRAM_ODT DRAM_CAS DRAM_CKE DRAM_RAS DRAM_WE DRAM_CS

R2052

330 OHM 1/10W

1K 1/16W 1%

R2005

1K 1/16W 1%

R2004

VDD18

10uF 16V

100P 50V

C2094

VDD18

C2064

VDD18

330pF 50V

DRAM_CK_P DRAM_CK_N

100N 16V

C2063

VDD18

C2057

DRAM_DQS0_N

DRAM_DQS1_N

C2042

330pF 50V

C2051

330pF 50V

DRAM_DQS0_P

DRAM_DQS1_P

DRAM_DM0 DRAM_DM1

DDR_MVREF1

DRAM_RAS

DRAM_CAS

DRAM_WE

DRAM_CS

DRAM_ODT

DRAM_CKE

DRAM_BA2

1N 50V

C2044

1N 50V

C2053

R3 R7 R8

100N 16V

C2058

100N 16V

VDD18

G9G7G3G1E9C9C7C3C1A9J9R1E1

U2004

VDDQ

J8 K8

F7 E8

B7 A8

F3 B3

J2

K7

L7

K3

L8

K9

K2

A2 E2 L1

100N 16V

C2052

VDDQ

CK CK#

LDQS LDQS#

UDQS UDQS#

LDM UDM

VREF

RAS#

CAS#

WE#

CS#

ODT

CKE

NC_A2 NC_E2 BA2 NC_R3 NC_R7 NC_R8

VSSQ

H2F8F2E7D8D2B8B2A7N1J3E3A3

H8

C2043

VDD18

C2059

330pF 50V

VDD18

C2048

330pF 50V

C2066

100P 50V

DRAM_DQ10 DRAM_DQ11 DRAM_DQ12 DRAM_DQ13 DRAM_DQ14 DRAM_DQ15

DRAM_DQ0 DRAM_DQ1 DRAM_DQ2 DRAM_DQ3 DRAM_DQ4 DRAM_DQ5 DRAM_DQ6 DRAM_DQ7

DRAM_DQ8 DRAM_DQ9

DRAM_A0 DRAM_A1 DRAM_A2 DRAM_A3 DRAM_A4 DRAM_A5 DRAM_A6 DRAM_A7 DRAM_A8

DRAM_A9 DRAM_A10 DRAM_A11 DRAM_A12

DRAM_BA0

DRAM_BA1

1N 50V

C2050

C2062

100N 16V

C2049

100N 16V

C2065

100N 16V

A1

J1

M9P9

VDDVSS

VDD

VDDQ

VSSQ

VDD18

C2045

330pF 50V

VDD18

C2054

330pF 50V

C2060

100N 16V

VDDL

G8

DQ0

G2

DQ1

H7

DQ2

H3

DQ3

H1

DQ4

H9

DQ5

F1

DQ6

F9

DQ7

C8

DQ8

C2

DQ9

D7

DQ10

D3

DQ11

D1

DQ12

D9

DQ13

B1

DQ14

B9

DQ15

M8

A0

M3

A1

M7

A2

N2

A3

N8

A4

N3

A5

N7

A6

P2

A7

P8

A8

P3

A9

M2

A10

P7

A11

R2

A12

L2

BA0

L3

BA1

VSS

VSSDL

J7

NT5TU64M16DG-BE

1N 50V

C2047

C2046

100N 16V

1N 50V

C2056

C2055

100N 16V

VDD18

C2061

330pF 50V

62

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

18:KEY AND IR INTERFACE

Date

OEM MO DEL Size

G4242-C-X-X-2-100726

TPV MO DEL

***** 01

PCB NAME

715G3787-M01-000-0050

18 18Monday, July 26, 2010

Sheet

of

Custom

Rev

<

称爹

>

300 OHM

5V

FB2012

1 2

1U 25V

+

C2096

C2097

100uF/16V

Vout = 0.8x(1+ R2055/R2053)=1.066V

5V_SW

205mA

FB2013

33 OHM

C2118

2U2 16V

5V

FB2014

33 OHM

VDD105DLL_S W

C2110 100N 16V

5V_SW

+

C2107

47uF/16V

MEMC5V_ SW

NC 10K 1/10W

R2043

C2098 1U 25V

VDD105_SW

U2704

4

VINENLX

R2076

1A

10K 1/10W

1

VFB

GND

G5628ADJT1U

2

VO=0.6(1+R1/R2)=1.8

Max 150mA, Normal: 100mA

2U2 16V C2122

4

R2077

NC 10K 1/10W

1

G5628ADJT1U

VO=0.6(1+R1/R2)=1.05

OUTPUT 400mA

5V_SW

3 2

VIN VOUT

C2111

10N 50V

OUTPUT 100mA

AIC1117-33PY

U2702

C2106 100N 16V

10K 1/10W

R2078

APW7080KAITRL

U2701

1

VIN

GND

2

EN

3

UGND

COMP

4 5

VCC LX

LX

C2095

9

1U 25V

OUTPUT 1.12A

L2002 2.2uH

3

C2115 NC

R2057

5

20K 1/10W

R2059 10K +-1% 1/10W

OUTPUT 100mA

U2705

3

L2003 2.2uH

VINENLX

C2119 NC

1A

5

VFB

GND

2

U2703

GND

1

C2212

100N 16V

4

23

4

VOUTVIN

VSS

1

C2108 100N 16V

22K 1/10W

1K 1/10W

R2081

8 7

FB

6

C2117

10uF 16V

R2058

7.5K +-1% 1/10W

R2060 10K +-1% 1/10W

+

C2113 47uF/16V

3V3

+

R2079

500mA

2V5

C2109 47uF/16V

5V

R208033KOHM 1/10W

Q2704

PMBS3904

R2054 33K 1/10W 5%

C2100

3.3nF 25V

D2001 SM340A

LOW ESR

C2104

22pF 50V

L2001 10uH

VDD1V8

+

C2116

100uF/16V

500mA

C2121

10uF 16V

100N 16V

100K 1/10W

R1819

C2076

C2080

C2084

100N 16V

C2088

100N 16V

+

LOW ESR

100N 16V

C2214

V105AN

100N 16V

C2120

100uF/16V

1 2

R2053

9.1KOHM +-1% 1/10W

C2103

10uF 16V

C2067

120OHM FB2005

C2075

100N 16V

120OHM FB2007

1 2

C2079

100N 16V

120OHM FB2009

1 2

100N 16V

120OHM FB2011

1 2

AO4449 -7A/-30V

1

S

2

S

3

S

4

G

R2055

3K +-% 1/10W

C2102 150pF 50V

120OHM FB2001

1 2

100N 16V

C2074

100N 16V

VDDLZ25

VDDLXY25

C2083

Q2701

C2069

VDD33OSC

3V3DIG

D D D D

VCC105

C2112

100N 16V

R2056

0R05 1/10W

C2105

+

10uF 16V

VDD18

C2068

100N 16V

120OHM FB2002

1 2

C2070

100N 16V

120OHM FB2004

1 2

CLOSE TO CHIP

C2078

100N 16V

C2082

100N 16V

C2086

100N 16V

C2087

100N 16V

5V_SW

8 7

+

6

C2213

5

100uF/16V

120OHM FB2015

1 2

100N 16V

C2099

470UF 16V

VDD105PLL

CLOSE TO CHIP

VDD105DLL

CLOSE TO CHIP

C2073

100N 16V

120OHM FB2006

1 2

100N 16V

120OHM FB2008

1 2

100N 16V

120OHM FB2010

1 2

C2123

100N 16V

C2077

C2081

VDD33

VDD105

1 2

C2072

VDDLZ25PLL

CLOSE TO CHIP

VDDLXY25PLL

CLOSE TO CHIP

C2085

100N 16V

63

120OHM FB2003

VDD105MPLL

CLOSE TO CHIP

C2071

100N 16V

5V

R2075

10K 1/10W

VDD105DLL_SW

Q2712

PMBS3904

VDD105MPLL

VDD105

C2009

100N 16V

VDD105

C2014

100N 16V

VDD105

C2019

100N 16V

VDD105DLL

VDD18

C2025

100N 16V

VDDLXY25

VDDLXY25PLL

VDDLXY25

VDDLXY25PLL

VDD33OSC

VDD33

0 OHM FB2020

CONN

12 11 10 9 8 7 6 5 4 3 2 1

CN2005

13 14

12

MEMC_ SC L MEMC_ SD A MEMC5 V_S W V105_SW V105DLL_SW RESET_FRC

T P V ( Top Victory Electronics Co . , Ltd. )

*****

絬隔瓜絪腹

Key Component

18:KEY AND IR INTERF ACE

Date

R2074

100 OHM 1/10W

C2020

330pF 50V

C2024

100N 16V

VDDLZ25PLL

5V

VDD105PLL

+

C2008

100N 16V

C2013

100N 16V

C2018

100N 16V

C2021

VDDLZ25

C2124

100uF/16V

5V

VDD105_SW

Q2710

V105DLL_SW

PMBS3904

C2001

330pF 50V

100N 16V

330pF 50V

C2002

100N 16V

C2003

C2004

100N 16V

C2007

C2005

C2006

100N 16V

C2010

C2012

C2011

100N 16V

C2015

C2016

100N 16V

C2017

100N 16V

C2023

C2022

100N 16V

C2026

100N 16V

C2027

100N 16V

C2029

C2028

100N 16V

C2030

100N 16V

C2032

C2031

100N 16V

C2033

100N 16V

C2034

C2035

100N 16V

C2037

C2036

100N 16V

OEM MOD EL S ize

G4242-C-X-X-2-100726

TPV MODEL

***** 01

PCB NAME

715G3787-M01-000-0050

Sheet

18 18Monday, J uly 26, 2010

R2070

10K 1/10W

R4

T4

T9

T10

G7 G8

G9 G14 G15 G16

H7

H8

H9 H14 H15 H16

J16

J8

J9 J10 J13 J14 J15

K9

K10 K13 K14

N9

N10 N13 N14

P8

P9

P10 P13 P14 P15

R7 R8 R9

R14 R15 R16

T7 T14 T16

J7

G10

T13

R13

P7

T8 T12 T15

P16

V4

J4

C5

H4

G3

D12 D16

C13

D14

C17

H19 M19

F20

K19

L20

P4

N4

D7 D8 M4

C7

of

U2401F

VDD105PLL

VSS105PLL

VDD105MPLL

VSS105MPLL

VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105 VDD105_S

VSS

VDD105DLL

VSS

VDD18 VDD18 VDD18 VDD18 VDD18

VSS

VDDLZ25

VSS

VDDLZ25PLL

VSS

VDDLX25 VDDLX25

VSS

VDDLX25PLL

VSS

VDDLY25 VDDLY25

VSS

VDDLY25PLL

VSS

VDD33OSC

VSS33OSC

VDD33 VDD33 VDD33

VSS

FRC9459S

R2071

100 OHM 1/10W

VSS_S

V105_SW

C6

VSS

C8

VSS

C9

VSS

C10

VSS

C11

VSS

C12

VSS

C14

VSS

C15

VSS

C16

VSS

C18

VSS

C19

VSS

C20

VSS

D3

VSS

D4

VSS

D5

VSS

D6

VSS

D9

VSS

D10

VSS

D11

VSS

D13

VSS

D15

VSS

D20

VSS

E3

VSS

E4

VSS

E19

VSS

E20

VSS

F3

VSS

F4

VSS

G19

VSS

G20

VSS

H3

VSS

D17

VSS

H20

VSS

J3

VSS

D18

VSS

J19

VSS

J20

VSS

K3

VSS

D19

VSS

K20

VSS

L3

VSS

L4

VSS

F19

VSS

M20

VSS

N20

VSS

P19

VSS

P20

VSS

R20

VSS

T19

VSS

T20

VSS

U20

VSS

U22

VSS

V19

VSS

W9

VSS

W11

VSS

W14

VSS

W16

VSS

W18

VSS

G11

VSS

G12

VSS

G13

VSS

H10

VSS

H11

VSS

H12

VSS

H13

VSS

J11

VSS

J12

VSS

K16

VSS

K8

VSS

K11

VSS

K12

VSS

K15

VSS

L7

VSS

L8

VSS

L9

VSS

L10

VSS

L11

VSS

L12

VSS

L13

VSS

L14

VSS

L15

VSS

L16

VSS

M7

VSS

M8

VSS

M9

VSS

M10

VSS

M11

VSS

M12

VSS

M13

VSS

M14

VSS

M15

VSS

M16

VSS

N7

VSS

N8

VSS

N11

VSS

N12

VSS

N15

VSS

N16

VSS

P11

VSS

P12

VSS

R10

VSS

R11

VSS

R12

VSS

T11

VSS

T2

VSS

T3

VSS

U2

VSS

U3

VSS

L19

VSS

N19

VSS

R19

VSS

U19

VSS

W19

VSS

W17

VSS

W15

VSS

W13

VSS

W10

VSS

W8

VSS

W4

VSS

U4

VSS

K4

VSS

G4

VSS

K7

Custom

Rev

称爹

>

<

称爹

U2401A

MSC L

MSD A

SSCL

SSDA

TC LK

TRS T_N

XOU T

RESET_N

GPIO00 GPIO01 GPIO02 GPIO03 GPIO04 GPIO05 GPIO06 GPIO07 GPIO08 GPIO09 GPIO10 GPIO11 GPIO12

FRC 9459S

TMS

TD I

TDO

XI N

TM

PWM

3V3DIG

R20202K 1/10W R20212K 1/10W

N3

M3

N1

N2

B4

A5

A4

A3

B5

R2024 NC

R1

X2201

27MHz

P1

B6 A6

A11 B10 A10 B9 A9 B8 A8 B7 A7 P2 P3 R2 R3

B11 A12

V

B12

H

10K 1/10W

12

R2026

10K 1/10W

R2066

R2067

C2089 18P 50V

WP

R2022 R2023

2KOHM 2KOHM

C209018P 50V

3V3DIG

C2091

10N 50V

C2039

100N 16V

10K 1/10W

R2064

R2065

10K 1/10W

3V3DIG

10K 1/10W R2001

0R05 1/10 W

WP

4.7K 1/ 10W

R2088

for External I2C

R2084 0R05 1/ 10W

1

GND

2

RESET

U200 3

NC G692L2 9 3 TCUf 2 .91V

3V3DIG

R2025

0R05 1/ 10W

R2082

R2083

0R05 1/ 10W

RESET_FRC

3V3DIG

4

VCC

3

MR

NC TACT SW FWRD H1.5MM

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

C2038 220N F 25V

U2002

8

VCC

7

WC

6

SCL

M24512_RMN6TPA

3V3DIG

SCL SDA

SW2101

1

E0

2

E1

3

E2

45

VSSSDA

CN200 6

1 2 3 4

*****

18:KEY AND IR INTERFACE

64

3V3DIG

R2068

0 OHM 1/10W

Q25012N7002

2N7002

56

NC

Q2502

R2069

0 OHM 1/10W

3V3DIG

OEM MODEL Size

TPV MO D EL

PCB NAME

Sheet

G4242-C-X-X-2-100726

***** 01

715G3787-M01-000-0050

of

18 18Monday, July 26, 2010

MEMC _SC L

MEMC _SD A

Rev

称爹

Custom

称爹

<

>

U2401C

P_ XA _T X0_ N

P_ XA _T X0_ P

P_ XA _T X1_ N

P_ XA _T X1_ P

P_ XA _T X2_ N

P_ XA _T X2_ P

P_XA_CLK_N

P_XA_CLK_P

P_ XA _T X3_ N

P_ XA _T X3_ P

P_ XA _T X4_ N

P_ XA _T X4_ P

P_ XB _T X0_ N

P_ XB _T X0_ P

P_ XB _T X1_ N

P_ XB _T X1_ P

P_ XB _T X2_ N

P_ XB _T X2_ P

P_XB_CLK_N

P_XB_CLK_P

P_ XB _T X3_ N

P_ XB _T X3_ P

P_ XB _T X4_ N

P_ XB _T X4_ P

FRC 9459S

A13 B13

A14 B14

A15 B15

A16 B16

A17 B17

A18 B18

A19 B19

A20 B20

A22 A21

B22 B21

C22 C21

D22 D21

TX0AN _OA TX0AP_ OA

TX1AN _OA TX1AP_ OA

TX2AN _OA TX2AP_ OA

TXCKAN_OA TXCKAP_OA

TX3AN _OA TX3AP_ OA

TX4AN _OA TX4AP_ OA

TX0BN _OA TX0BP_ OA

TX1BN _OA TX1BP_ OA

TX2BN _OA TX2BP_ OA

TXCKBN_OA TXCKBP_OA

TX3BN _OA TX3BP_ OA

TX4BN _OA TX4BP_ OA

DRC_EN

PANEL_VC C

PANEL_PW M_OUT

100N 16V

PANEL_VC C

C2092

TX0AP_OB TX1AP_OB TX2AP_OB

TXCKAP_OB TX3AP_OB TX4AP_OB

TX0BP_OB TX1BP_OB TX2BP_OB

TXCKBP_OB

TX3BP_OB TX4BP_OB

TX0AP_OA TX1AP_OA TX2AP_OA

TXCKA P_OA TX3AP_OA TX4AP_OA

TX0BP_OA TX1BP_OA TX2BP_OA

TXCKB P_OA TX3BP_OA TX4BP_OA

+

C2093

100uF 25V

CONN

2 4 6

8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40

37

2 4 6

8 10 12 14 16 18 20 22 24 26 28 30 32 34 36

38

CN 4004

CN 4001

1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35

CONN

1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39

TX0AN _OA TX1AN _OA TX2AN _OA

TXCK AN_ OA TX3AN _OA TX4AN _OA

TX0BN _OA TX1BN _OA TX2BN _OA

TXCK BN_ OA TX3BN _OA TX4BN _OA

LVDS_SEL

PANEL_PW M

TX0AN _OB TX1AN _OB TX2AN _OB

TXCKA N_OB TX3AN _OB TX4AN _OB

TX0BN _OB TX1BN _OB TX2BN _OB

TXCKB N_OB

TX3BN _OB TX4BN _OB

PANEL_VC C

3V3

R2016

NC

R2017

NC

U2401D

P_YA_TX0_N

P_YA_TX0_P

P_YA_TX1_N

P_YA_TX1_P

P_YA_TX2_N

P_YA_TX2_P

P_Y A_CLK_N

P_YA_C LK_P

P_YA_TX3_N

P_YA_TX3_P

P_YA_TX4_N

P_YA_TX4_P

P_YB_TX0_N

P_YB_TX0_P

P_YB_TX1_N

P_YB_TX1_P

P_YB_TX2_N

P_YB_TX2_P

P_Y B_CLK_N

P_YB_C LK_P

P_YB_TX3_N

P_YB_TX3_P

P_YB_TX4_N

P_YB_TX4_P

FRC9459S

E22 E21

F22 F21

G22 G21

H22 H21

J22 J21

K22 K21

L22 L21

M22 M21

N22 N21

P22 P21

R22 R21

T22 T21

TX0AN _OB TX0AP _OB

TX1AN _OB TX1AP _OB

TX2AN _OB TX2AP _OB

TXCK AN_ OB TXCK AP_O B

TX3AN _OB TX3AP _OB

TX4AN _OB TX4AP _OB

TX0BN _OB TX0BP _OB

TX1BN _OB TX1BP _OB

TX2BN _OB TX2BP _OB

TXCK BN_ OB TXCK BP_O B

TX3BN _OB TX3BP _OB

TX4BN _OB TX4BP _OB

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

*****

18:KEY AN D I R I NTERF ACE

65

OE M MOD E L Si ze

TPV MO D EL

PCB NAME

Sheet

G4242-C-X-X-2-100726

***** 01

715G3787-M01-000-0050

18 18Monday, July 26, 2010

of

Rev

称爹

Custom

称爹

<

>

TX0AP_I N TX1AP_I N TX2AP_I N

TXCKAP _IN

TX3AP_I N TX4AP_I N

TX0BP_I N TX1BP_I N TX2BP_I N

TXCKBP _IN

TX3BP_I N TX4BP_I N

DRC_EN

PANEL_VCC

PANEL_PW M_OUT

R2019100OHM1/16W R2018100OHM1/16W R2015100OHM1/16W R2014100OHM1/16W R2013100OHM1/16W TX1AP_I N R2012100OHM1/16W R2011100OHM1/16W R2010100OHM1/16W R2009100OHM1/16W R2008100OHM1/16W R2007100OHM1/16W R2006100OHM1/16W

CN4003

43

2 4 6

8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42

1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41

PANEL_PW M

TX0AN _I N TX1AN _I N TX2AN _I N

TXCKAN_I N

TX3AN _I N TX4AN _I N

TX0BN _I N TX1BN _I N TX2BN _I N

TXCKBN_I N

TX3BN _I N TX4BN _I N

PANEL_VC C

TX0AN _I N TX0AP_I N

TX1AN _I N

TX2AN _I N TX2AP_I N

TXCKAN _I N TXCKAP_IN

TX3AN _I N TX3AP_I N

TX4AN _I N TX4AP_I N

TX0BN _I N TX0BP_I N

TX1BN _I N TX1BP_I N

TX2BN _I N TX2BP_I N

TXCKBN _I N TXCKBP_IN

TX3BN _I N TX3BP_I N

TX4BN _I N TX4BP_I N

A2 A1

B2 B1

C2 C1

D2 D1

E2 E1

F2 F1

G2 G1

H2 H1

J2 J1

K2 K1

L2 L1

M2 M1

U2401B

FRC9459S

P_ZA_R X0_N P_ZA_R X0_P

P_ZA_R X1_N P_ZA_R X1_P

P_ZA_R X2_N P_ZA_R X2_P

P_ZA_C LK_N P_ZA_C LK_P

P_ZA_R X3_N P_ZA_R X3_P

P_ZA_R X4_N P_ZA_R X4_P

P_ZB_R X0_N P_ZB_R X0_P

P_ZB_R X1_N P_ZB_R X1_P

P_ZB_R X2_N P_ZB_R X2_P

P_ZB_C LK_N P_ZB_C LK_P

P_ZB_R X3_N P_ZB_R X3_P

P_ZB_R X4_N P_ZB_R X4_P

CONN

44

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

Key Component

Date

*****

18:KEY AND IR INTERFACE

66

OEM MODEL Size

TPV MODEL

PCB NAME

Sheet

G4242-C-X-X-2-100726

***** 01

715G3787-M01-000-0050

of

18 18Monday , J uly 26, 2010

Rev

称爹

<

A

称爹

>

12V

NC

FB2021

12

NC

C2216

NC

C2217

5V

L2004

C2218

NC

U2006

9

GND

8

SW

7

VIN

6

GND

+

NC

BS NC NC

FBEN

1 2 3 45

1 2

D2002 NC

NC

R2092

R2090 NC

R2091 NC

+

C2220

NC

C2219

NC

12V

CN2008

56

1 2 3 4

NC

vout= 1.222*(1+R2090/(R2091+R2092))=5.08V

Tit le

Size Document Number Rev

Date: Sheet

A

11Monday, J uly 26, 2010

of

67

10. Exploded View

68

Explode Parts List

No.

Description

No.

Description

1

2

3

4

5

7

8

9

10

11

12

13

14

15

Screw List

No. Part No. Description QTY.

DECO_BEZEL

DECO_TV32WSL

BEZEL_TV32WSL-AOC1

IR BOARD

SPEAKER

COVER_FUNCTION

LABEL FOR KEY

KEY BOARD 23 MEMC BOARD

BRACKET_HOLDER_FIX 24 HINGE ASSY

BRACKET_HOLDER_FIX-AUO 25 BASE_TV32WSL-AOC1

PANEL

POWER BOARD 42 BKT-MEMC-L

MAIN BOARD

MAIN BRACKET L

16

17

18

19

20

21

22

26

43

MAIN BRACKET R

BRACKET_VESA

BRACKET_STAND

IO BRACKET-RIGHT

IO BRACKET-BOTTOM

REAR_COVER_TV32WSL-10b

AC COVER

BRACKET

BKT-MEMC-R

27 0Q1G1030 6120 SCREW for BEZEL & DECO_BEZEL 2

28 0Q1G 930 6120 SCREW for BRACKET_HOLDER_FIX & BEZEL 8

29 0M1G1730 6120 SCREW for BRACKET_HOLDER_FIX & PANEL 8

30 0M1G1730 6120 SCREW for POWER BOARD & PANEL 5

31 0M1G1740 6120 SCREW for POWER BOARD & PANEL 1

32 0M1G1730 6120 SCREW for MAIN/MEMC BOARD & PANEL 8

33 0M1G 130 6120 SCREW for MAIN BRACKET & PANEL 4

34 0M1G1840 8120 SCREW for BKT-MEMC & MAIN BRACKET 4

35 0M1G 940 6120 SCREW for BRACKET_STAND & PANEL 4

36 0Q1G 940 12 47 CR3 SCREW for REAR COVER & BEZEL 14

37 0M1G 940 6 47 CR3 SCREW for REAR COVER & BRACKET_STAND 1

38 0M1G 940 6 47 CR3 SCREW for AC COVER & BRACKET_STAND 1

39 0M1G 940 6 47 CR3 SCREW for COVER STAND & BRACKET_STAND 2

40 0Q1G 130 8120 SCREW for BRACKET & HINGE ASSY 6

41 0Q1G 940 12 47 CR3 SCREW for BRACKET & BASE 4

69

11. BOM List

Note: The parts information listed below are for reference only, and are subject to change without notice. Please go

to http://cs.tpv.com.cn/hello1.asp

E32AATNSWEB56N

Location Part No. Description Remark

040G 581689 4A BARCODE LABEL FOR 1

045G 77500 BARCODE RIBBON

045G 77501 BARCODE RIBBON

052G 1186 SMALL TAPE

052G 2191 A PAPER TAPE

SP01L 078G0100 21 ML SPK 8 OHM 10W 165X32.4 210 HIBOX

SP01R 078G0100 21 MR SPK 8 OHM 10W 165X32.4 400 HIBOX

089G 17356C553 AUDIO CABLE 1800MM

ECN105 089G 17356C583 RCA CABLE 200MM

ECN105 089G 17356G583 RCA CABLE 200MM 2nd source

089G 725CAA DB D-SUB CABLE

for the latest information.

E08901 089G424A18NCX4 F1 AC POWER CORD 1800 2nd source

E08901 089G424A18NHL4 F1 AC POWER CORD 1800+140MM

ECN706 095G801412D933 HARNESS 12P-12P 260mm FQE91463I

ECN706 095G801412X933 HARNESS 12P-12P 260mm LCDXXTF0364 2nd source

ECN902 095G801413D960 HARNESS 13P-13P 100mm FQE100901I

ECN401 095G801413DH12 HARNESS 13P-3P+8P 600MM 2nd source

ECN700 095G801413LH09 HARNESS 13P(A2008H)-12P(2506) 350MM 2nd source

ECN700 095G801413WH09 HARNESS 13P(A2008H)-12P(2506) 350MM

ECN401 095G801413WH12 HARNESS 13P-3P+8P 600MM

ECN902 095G801413X960 HARNESS 13P-13P 100mm 2nd source

ECN4001 095G801841D507 HARNESS 41P-30P 470mm

ECN4001 095G801841L507 HARNESS 41P-30P 470mm 2nd source

ECN704 095G801842D500 LVDS CABLE 42P-42P 400MM 2nd source

ECN704 095G801842L500 LVDS CABLE 42P-42P 400MM

ECN4004 095G801851D561 HARNESS 51P-40P 440mm

ECN4004 095G801851L561 HARNESS 51P-40P 440mm 2nd source

0M1G 130 6120 SCREW M3X6

0M1G 330 6 47 CR3 SCREW 42-D005390

0M1G 940 6 47 CR3 SCREW

0M1G 940 6120 SCREW (M4X6)

0M1G1730 5120 SCREW

0M1G1730 6120 SCREW,42-D020523

70

0M1G1740 6120 SCREW

0M1G1840 8120 SCREW

0Q1G 130 8120 SCREW 42A9930011

0Q1G 330 6 47 CR3 SCREW

0Q1G 930 6120 SCREW 3X6MM

0Q1G 940 12 47 CR3 SCREW

0Q1G1030 6120 SCREW

E750 750TVU315W5112N000 LCD T315HW05 V1 SZ AUO 2nd source

756TQACB TS026 01 MAIN BOARD-CBPFAT1SQ4C

SMTF-U403 100TATAK004S11 FLASH ASSY-056T1133111

SMTF-U402 100TATAM006S21 MCU ASS'Y-056G1133923 1

756TQAPT TS007 00 MEMC BOARD-PTPFAQA3C

SPTP-U2002 100TATAM007S11 EEPROM ASSY-056G1133528

A15T1297101CKD BRACKET

A15T1298101CKD BRACKET_STAND

A15T1300101CKD BRACKET_HOLDER_FIX

A15T1307301CKD MAIN BRACKET R

A15T1307401CKD MAIN BRACKET L

A15T1316101CKD BRACKET_HOLDER_FIX-AUO

A15T1326101CKD BRACKET_VESA

A33T0907ADT 1A0100 AC COVER

A33T0999ADT 1T0100 COVER_FUNCTION

A34T2004AFLA1L0130 BEZEL_TV32WSL-aoc1

A34T2005ADT 3T0100 REAR_COVER_TV32WSL-10b

A34T2006AFL 1L0100 BASE_TV32WSL-aoc1

A34T2007AHYA1C0100 DECO_TV32WSL

A34T2159ADT 1T0100 COVER_STAND

040G 45762412B CBPC LABEL

CN604 033G3278 2D WAFER 2.5MM 2P

CN602 033G3278 4D 2.5mm Pitch Wafer

CN700 033G327812D WAFER 12P PLUG

CN401 033T380213B Y L CONNECTOR 13P 2.0

C634 067G215S3316KV EC 330uF M 35V 10*12mm

C636 067G215S3316KV EC 330uF M 35V 10*12mm

C672 067G215S3316KV EC 330uF M 35V 10*12mm

C673 067G215S3316KV EC 330uF M 35V 10*12mm

C674 067G215S3316KV EC 330uF M 35V 10*12mm

C675 067G215S3316KV EC 330uF M 35V 10*12mm

C706 067G215V221 4N KY25VB220-M-CC3 8*11.5MM

C711 067G215V221 4N KY25VB220-M-CC3 8*11.5MM

C714 067G215V221 4N KY25VB220-M-CC3 8*11.5MM

CN104 088G 78 13 74 YG RCA JACK 1*2 W/R 2nd source

71

CN102 088G 78 13 75 YG RCA JACK 1*3 G/B/R 2nd source

CN104 088G 78 1374C RCA JACK 1*2 W/R

CN102 088G 78 1375C RCA JACK 1*3 G/B/R

CN101 088G 302 65 YG PHONE JACK 3P GREEN 2nd source

CN601 088G 30211K PHONE JACK 7PIN

CN105 088G 302506 C PHONE JACK 4P GREEN -

CN101 088G 30265C PHONE JACK 3P GREEN

CN601 088G 302A11 YG PHONE JACK 3.5¦µ 7PIN BLACK CKX3.507B-01 2nd source

CN701 088G 352 21CL USB CONN TYPE A

CN701 088G 352 2L YG USB CONNECTOR USB4-03 Au=1u'' 2nd source

CN603 088G 359 6 JT FIBER-OPTIC 3PIN JST1226

CN103 088G353B15FHSD D-SUB CONN SCREWED 15P BLUE - 2nd source

CN103 088G353B15FHSX D-SUB CONN SCREWED 15P BLUE -

TU100 094GNPALALL 7M TUNER Brazil ENG36F16KF

709T4243 QM002 CONSUMPTIVE ASS'Y

055G 23524 WELDING FLUX WITHOUT PB

Q55G 100620500 TIN STICK(Sn-0.5Ag)

C323 067G 3051007CT EC 10UF/50V KM 5*11mm

C1039 067G 3051007CT EC 10UF/50V KM 5*11mm

C1042 067G 3051007CT EC 10UF/50V KM 5*11mm

C1046 067G 3051007CT EC 10UF/50V KM 5*11mm

C1096 067G 3051007CT EC 10UF/50V KM 5*11mm

C1614 067G 3051007CT EC 10UF/50V KM 5*11mm

C1614 067G 3051007KT EC 10UF/50V PF 5*11mm

C1096 067G 3051007KT EC 10UF/50V PF 5*11mm

C1046 067G 3051007KT EC 10UF/50V PF 5*11mm

C1042 067G 3051007KT EC 10UF/50V PF 5*11mm

C1039 067G 3051007KT EC 10UF/50V PF 5*11mm

C323 067G 3051007KT EC 10UF/50V PF 5*11mm

C740 067G 3051013CT EC 100uF 16V KM 6.3x11mm

C717 067G 3051014CT EC 100uF 25V KM 6.3x11mm

C717 067G 3051014PT EC 100UF 20% 25V 6.3*11

C1021 067G 3052214CT EC 220UF/25V KM 8*11mm

C1021 067G 3052214ET EC 220uF 25V RGA 8x11mm

C751 067G 3054704CT EC 47uF 25V KM 5x11mm

C750 067G 3054704CT EC 47uF 25V KM 5x11mm

C745 067G 3054704CT EC 47uF 25V KM 5x11mm

C738 067G 3054704CT EC 47uF 25V KM 5x11mm

C737 067G 3054704CT EC 47uF 25V KM 5x11mm

C735 067G 3054704CT EC 47uF 25V KM 5x11mm

C726 067G 3054704CT EC 47uF 25V KM 5x11mm

C415 067G 3054704CT EC 47uF 25V KM 5x11mm

C400 067G 3054704CT EC 47uF 25V KM 5x11mm

72

C1616 067G 3054704CT EC 47uF 25V KM 5x11mm

C400 067G 3054704KT 47UF

C1616 067G 3054704KT 47UF

C415 067G 3054704KT 47UF

C726 067G 3054704KT 47UF

C735 067G 3054704KT 47UF

C737 067G 3054704KT 47UF

C738 067G 3054704KT 47UF

C745 067G 3054704KT 47UF

C750 067G 3054704KT 47UF

C751 067G 3054704KT 47UF

C712 067G 3054706CT EC CAP 47UF M 35V

C731 067G 3054713PT NO-SUGGEST CAP 105C 470UF M 16V 8*12

C731 067G 3054713XT EC 470UF 20% 16V 8*11.5

C707 067G215Y1013KT LOW ESR EC 100uF 16V 6.3*11mm

C703 067G215Y1013KT LOW ESR EC 100uF 16V 6.3*11mm

C752 067G215Y2212KT LOW ESR EC 220uF 10V 6.3*11mm

CN706 033G803212F S HR CONNECTOR 1.25pitch 12p

U605 056G 158501 IC AS431AN-E1 SOT23

U200 056G 562F03 SCALER IC HIDTV PRO-SX 27*27 BGA

U700 056G 563 30 DC/DC CONVERTER -- -- -- --

U707 056G 563122 IC G1084-25TU3Uf TO-263T

U706 056G 563143 IC G1084T43Uf TO-252

U703 056G 563246 LDO AZ1084S2-ADJG1 TO-263-2 5A/Adj

U704 056G 563513 IC LDO APW7080KAITRG SOP-8P

U705 056G 563514 IC AZ1117H-3.3TRG1 1A/3.3V SOT223

U105 056G 563964 IC SC4215HSTRT SO-8

U106 056G 575515 DECODER TC90517FG£¨BS,DRY) LQFP-64

U603 056G 593 39 IC STA339BWTR PowerSSO36

U401 056G 615505 DRAM NT5TU64M16DG-BE(7-7-7)1066 1G BGA84

U400 056G 615505 DRAM NT5TU64M16DG-BE(7-7-7)1066 1G BGA84

U505 056G 634 25 IC SII9187ACNU QFN-72

U202 056G 643 27 IC G692L293TCUf 2.91V SOT-143

U701 056G 659501 USB IC BD8012FVJ TSSOP-B8J

U100 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L

U101 056G 662502 IC ESD AZC199-04S.R7G SOT23-6L

U402 056G1133923 IC MX25L4005AM2C-12G SOP-8

U402 056G1133923 1 IC MX25L4005AM2I-12G SOP-8

U709 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23

U710 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23

U711 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23

U712 056G4LVCG17 TI IC SN74LVC1G17DBVR STO-23

U715 056T 563146 IC G912T63U 1A/1.2V SOT-223

73

U602 056T 616516 IC APA2176AQBITRG TQFN3X3-16

U403 056T1133111 IC NAND512W3A2DN6E TSOP-48

Q607 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q702 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q704 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q706 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q707 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q709 057G 417 4 PMBS3904/PHILIPS-SMT(04)

Q201 057G 417 6 PMBS3906/PHILIPS-SMT(06)

Q200 057G 417 6 PMBS3906/PHILIPS-SMT(06)

Q604 057G 417511 MMBT3904

Q700 057G 763 79 FET AO4449 -7A/-30V SOIC-8

Q701 057G 763 79 FET AO4449 -7A/-30V SOIC-8

Q501 057G 763904 TRA FET 2N7002 SOT-23 PHILIPS

Q202 057G 765 1 2SC2412K

RP102 061G 125330 8Y NO-SUGGEST RST CHIP AR 8P4R 33 OHM +-5%

RP101 061G 125330 8Y NO-SUGGEST RST CHIP AR 8P4R 33 OHM +-5%

RP100 061G 125330 8Y NO-SUGGEST RST CHIP AR 8P4R 33 OHM +-5%

RP103 061G 1254728JF RST CHIP AR 8P4R 4.7 KOHM +-5% 1/16W

RP104 061G 1254728JF RST CHIP AR 8P4R 4.7 KOHM +-5% 1/16W

R1064 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W

R1067 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W

R1070 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W

R401 061G04021001FY RST CHIP 1K 1/16W 1%

R400 061G04021001FY RST CHIP 1K 1/16W 1%

R1001 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R1003 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R1005 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R1008 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R1011 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R1080 061G0402101 JF RST CHIPR 100 OHM +-5% 1/16W FENGHUA

R402 061G04027509FT RST CHIP 75R 1/16W 1%

R403 061G04027509FT RST CHIP 75R 1/16W 1%

R210 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R232 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R260 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R262 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R263 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R265 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R267 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R268 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R272 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R273 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

74

R274 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R415 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R543 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R546 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R557 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R560 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R739 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R742 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1837 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R2088 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

L101 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1002 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1007 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1010 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1054 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1056 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1059 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1063 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1066 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1069 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1094 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1099 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1634 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1835 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1836 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R1840 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R202 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R2086 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R2087 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R730 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R574 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R573 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R572 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R553 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R650 061G06031000FT RST CHIP 100R 1/10W 1%

R652 061G06031000FT RST CHIP 100R 1/10W 1%

R654 061G06031000FT RST CHIP 100R 1/10W 1%

R655 061G06031000FT RST CHIP 100R 1/10W 1%

R657 061G06031000FT RST CHIP 100R 1/10W 1%

R733 061G06031000FT RST CHIP 100R 1/10W 1%

R237 061G06031001FY RST CHIPR 1KOHM +-1% 1/10W YAGEO

R238 061G06031001FY RST CHIPR 1KOHM +-1% 1/10W YAGEO

R254 061G06031001FY RST CHIPR 1KOHM +-1% 1/10W YAGEO

75

R255 061G06031001FY RST CHIPR 1KOHM +-1% 1/10W YAGEO

R229 061G06031002FY RST CHIPR 10KOHM +-1% 1/10W YAGEO

R209 061G06031002FY RST CHIPR 10KOHM +-1% 1/10W YAGEO

R1062 061G06031002FY RST CHIPR 10KOHM +-1% 1/10W YAGEO

R551 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R550 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R549 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R548 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R280 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1107 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1106 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1105 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1104 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1050 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1048 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1030 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1029 061G0603101 JF RST CHIPR 100 OHM +-5% 1/10W FENGHUA

R1020 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1028 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R724 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R723 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R716 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R710 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R708 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R702 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R637 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R580 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R221 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1033 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1071 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1100 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1101 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1615 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1616 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R213 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R216 061G0603102 JY RST CHIPR 1KOHM +-5£¥ 1/10W YAGEO

R1055 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1043 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1038 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1037 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1035 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1034 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1031 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

76

R1017 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1016 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R726 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R713 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R701 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R644 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R641 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R638 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R634 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R628 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R275 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R247 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1057 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1058 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1060 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1077 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1078 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R217 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R225 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R244 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R245 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R1026 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1027 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1075 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1076 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1095 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1096 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1818 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R715 061G0603104 JF RST CHIPR 100KOHM 5% 1/10W FENGHUA

R1049 061G0603105 JF RST CHIPR 1M OHM +-5% 1/10W FENGHUA

R207 061G0603105 JF RST CHIPR 1M OHM +-5% 1/10W FENGHUA

R1148 061G0603122 JF RST CHIPR 1.2KOHM 5% 1/10W FENGHUA

R218 061G06031242FY RST CHIP 12K4 1/10W 1%

R705 061G0603184 JF RST CHIPR 180KOHM 5% 1/10W FENGHUA

R1025 061G0603184 JF RST CHIPR 180KOHM 5% 1/10W FENGHUA

R1023 061G0603184 JF RST CHIPR 180KOHM 5% 1/10W FENGHUA

R287 061G0603202 JF RST CHIPR 2K OHM +-5% 1/10W FENGHUA

R288 061G0603202 JF RST CHIPR 2K OHM +-5% 1/10W FENGHUA

R1617 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA

R1611 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA

R1610 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA

R1040 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA

R1039 061G0603203 JF RST CHIPR 20K OHM +-5% 1/10W FENGHUA

77

R1021 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

R1024 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

R647 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

R233 061G0603223 JF RST CHIPR 22KOHM 5% 1/10W FENGHUA

R234 061G0603223 JF RST CHIPR 22KOHM 5% 1/10W FENGHUA

R635 061G0603223 JF RST CHIPR 22KOHM 5% 1/10W FENGHUA

R714 061G0603223 JF RST CHIPR 22KOHM 5% 1/10W FENGHUA

R412 061G0603330 JY NO-SUGGEST RST CHIPR 33 OHM 1/10W YAGEO

R411 061G0603330 JY NO-SUGGEST RST CHIPR 33 OHM 1/10W YAGEO

R408 061G0603330 JY NO-SUGGEST RST CHIPR 33 OHM 1/10W YAGEO

R208 061G0603330 JY NO-SUGGEST RST CHIPR 33 OHM 1/10W YAGEO

R1144 061G0603330 JY NO-SUGGEST RST CHIPR 33 OHM 1/10W YAGEO

R727 061G06033301FF RST CHIPR 3.3KOHM +-1% 1/10W FENGHUA

R727 061G06033301FY RST CHIP 3K3 1/10W 1%

R1630 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R257 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R270 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R4H1 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R4H2 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R4H3 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R4H6 061G0603332 JF RST CHIPR 3.3KOHM 5% 1/10W FENGHUA

R725 061G0603333 JT RST CHIP 33K 1/10W 5% TZAI YUAN

R661 061G06033401FY RST CHIPR 3.4KOHM +-1% 1/10W YAGEO

R665 061G06033401FY RST CHIPR 3.4KOHM +-1% 1/10W YAGEO

R668 061G06033401FY RST CHIPR 3.4KOHM +-1% 1/10W YAGEO

R669 061G06033401FY RST CHIPR 3.4KOHM +-1% 1/10W YAGEO

R239 061G06034020FT RST CHIP R 402ohm 1/10W +/-1%

R1051 061G0603470 JY NO-SUGGEST RST CHIPR 47 OHM 1/10W YAGEO

R741 061G06034709FF RST CHIPR 47 OHM +-1% 1/10W FENGHUA

R729 061G0603471 JF RST CHIPR 470OHM +-5% 1/10W FENGHUA

R1629 061G0603471 JF RST CHIPR 470OHM +-5% 1/10W FENGHUA

R212 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R214 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R215 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R219 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R220 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R223 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R224 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R226 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R227 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R228 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R231 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R236 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

78

R1041 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1042 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1046 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1047 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1053 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1155 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R200 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R203 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R204 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R205 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R2084 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R211 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R407 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R413 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R414 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R541 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R547 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R552 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R703 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R706 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R718 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R720 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R721 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R722 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R736 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R743 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R241 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R246 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R248 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R250 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R251 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R252 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R253 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R276 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R277 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R278 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R279 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R404 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R405 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R406 061G0603472 JY NO-SUGGEST RST CHIPR 4.7KOHM £«-5£¥ 1/1

R1628 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R544 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R545 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

79

R554 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R555 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R556 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R559 061G0603473 JY NO-SUGGEST RST CHIPR 47KOHM 1/10W YAGEO

R1619 061G0603512 JY NO-SUGGEST RST CHIPR 5.1KOHM +-5% 1/10W

R629 061G0603513 JF RST CHIPR 51K OHM +-5% 1/10W FENGHUA

R201 061G06036041FF RST CHIPR 6.04KOHM +-1% 1/10W FENGHUA

R1093 061G06036801FF RST CHIPR 6.8KOHM +-1% 1/10W FENGHUA

R633 061G0603681 JF RST CHIPR 680OHM +-5% 1/10W FENGHUA

R561 061G0603682 JY RST CHIP 6K8 1/10W 5% YAGEO

R1072 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1004 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1009 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1012 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1065 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1068 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1081 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R230 061G0603750 JY NO-SUGGEST RST CHIPR 75 OHM +-5% 1/10W Y

R1061 061G06038202FI TEST ONLY RST 0603 82K 1% 1/10W TA-I

R1073 061G0603823 JF RST CHIPR 82KOHM 5% 1/10W FENGHUA

R1092 061G0603823 JF RST CHIPR 82KOHM 5% 1/10W FENGHUA

R1091 061G0603823 JF RST CHIPR 82KOHM 5% 1/10W FENGHUA

R1074 061G0603823 JF RST CHIPR 82KOHM 5% 1/10W FENGHUA

R728 061G06039101FF RST CHIPR 9.1KOHM +-1% 1/10W FENGHUA

FB114 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

FB113 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

FB703 061G0805000 JY RST CHIPR MAX 0R05 OHM 1/8W YAGEO

R677 061G0805000 JY RST CHIPR MAX 0R05 OHM 1/8W YAGEO

R694 061G0805000 JY RST CHIPR MAX 0R05 OHM 1/8W YAGEO

R1079 061G0805220 JF RST CHIPR 22 OHM +-5% 1/8W FENGHUA

R1110 061G0805220 JF RST CHIPR 22 OHM +-5% 1/8W FENGHUA

R693 061G0805229 JF RST CHIPR 2R2 +-5% 1/8W FENGHUA

FB105 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

FB107 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

FB120 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

R662 061G1206220 JF RST CHIPR 22 OHM +-5% 1/4W FENGHUA

R651 061G1206220 JF RST CHIPR 22 OHM +-5% 1/4W FENGHUA

R643 061G1206220 JF RST CHIPR 22 OHM +-5% 1/4W FENGHUA

R645 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN

R649 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN

R653 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN

R656 061G1206629 JT RST CHIPR 6.2 OHM +-5% 1/4W TZAI YUAN

R645 061G1206629 JY RST CHIPR 6.2 OHM +-5% 1/4W YAGEO

80

R649 061G1206629 JY RST CHIPR 6.2 OHM +-5% 1/4W YAGEO

R653 061G1206629 JY RST CHIPR 6.2 OHM +-5% 1/4W YAGEO

R656 061G1206629 JY RST CHIPR 6.2 OHM +-5% 1/4W YAGEO

C1101 065G040210131J Y CAP CHIP 0402 100P 50V NPO +/-5%

C664 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%

C662 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%

C658 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%

C646 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%

C640 065G040210232K Y CAP CHIP 0402 1N 50V X7R +/-10%

C283 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C284 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C285 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C286 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C287 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C288 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C289 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C290 065G040210312K Y CAP CHIP 0402 10N 16V X7R +/-10%

C404 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C411 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C412 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C413 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C414 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C421 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C422 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C423 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C424 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C666 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C665 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C653 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C652 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C647 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C311 065G040210425K M CAP 0402 100NF 10% 25V X5R

C312 065G040210425K M CAP 0402 100NF 10% 25V X5R

C401 065G040210425K M CAP 0402 100NF 10% 25V X5R

C402 065G040210425K M CAP 0402 100NF 10% 25V X5R

C403 065G040210425K M CAP 0402 100NF 10% 25V X5R

C407 065G040210425K M CAP 0402 100NF 10% 25V X5R

C408 065G040210425K M CAP 0402 100NF 10% 25V X5R

C409 065G040210425K M CAP 0402 100NF 10% 25V X5R

C302 065G040210425K M CAP 0402 100NF 10% 25V X5R

C303 065G040210425K M CAP 0402 100NF 10% 25V X5R

C304 065G040210425K M CAP 0402 100NF 10% 25V X5R

C305 065G040210425K M CAP 0402 100NF 10% 25V X5R

81

C307 065G040210425K M CAP 0402 100NF 10% 25V X5R

C308 065G040210425K M CAP 0402 100NF 10% 25V X5R

C309 065G040210425K M CAP 0402 100NF 10% 25V X5R

C298 065G040210425K M CAP 0402 100NF 10% 25V X5R

C297 065G040210425K M CAP 0402 100NF 10% 25V X5R

C282 065G040210425K M CAP 0402 100NF 10% 25V X5R

C281 065G040210425K M CAP 0402 100NF 10% 25V X5R

C280 065G040210425K M CAP 0402 100NF 10% 25V X5R

C279 065G040210425K M CAP 0402 100NF 10% 25V X5R

C278 065G040210425K M CAP 0402 100NF 10% 25V X5R

C310 065G040210425K M CAP 0402 100NF 10% 25V X5R

C430 065G040210425K M CAP 0402 100NF 10% 25V X5R

C420 065G040210425K M CAP 0402 100NF 10% 25V X5R

C419 065G040210425K M CAP 0402 100NF 10% 25V X5R

C418 065G040210425K M CAP 0402 100NF 10% 25V X5R

C417 065G040210425K M CAP 0402 100NF 10% 25V X5R

C410 065G040210425K M CAP 0402 100NF 10% 25V X5R

C309 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C308 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C307 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C305 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C304 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C303 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C302 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C298 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C297 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C282 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C281 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C280 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C279 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C278 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C310 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C430 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C420 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C419 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C418 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C417 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C410 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C409 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C408 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C407 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C403 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C402 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

82

C401 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C312 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C311 065G040210425K T CAP 0402 0.1uf 10% 25V X5R

C1012 065G040222031J Y CAP CHIP 0402 22P 50V NPO +/-5%

C1010 065G040222031J Y CAP CHIP 0402 22P 50V NPO +/-5%

C748 065G060310131J Y CAP CHIP 0603 100P 50V NPO +/-5%

C1037 065G060310232K A CAP CHIP 0603 1000pF K 50V X7R

C1077 065G060310332K Y CAP CHIP 0603 10N 50V X7R +/-10%

C212 065G060310332K Y CAP CHIP 0603 10N 50V X7R +/-10%

C722 065G060310332K Y CAP CHIP 0603 10N 50V X7R +/-10%

C723 065G060310332K Y CAP CHIP 0603 10N 50V X7R +/-10%

C743 065G060310332K Y CAP CHIP 0603 10N 50V X7R +/-10%

C264 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C262 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C261 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C260 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C258 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C256 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C255 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C254 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C251 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C265 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C266 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C267 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C271 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C272 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C277 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C292 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C293 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C294 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C250 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C226 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C223 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C220 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C219 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C217 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C216 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C215 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C214 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C213 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C210 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C209 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C206 065G060310432K Y CAP 0603 100NF 10% 50V X7R

83

C227 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C247 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C244 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C243 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C242 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C241 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C240 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C238 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C235 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C234 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C232 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C231 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C229 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C638 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C428 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C427 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C425 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C322 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C319 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C318 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C317 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C316 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C639 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C642 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C648 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C650 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C429 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C533 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C532 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C528 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C524 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C521 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C516 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C515 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C514 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C436 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C435 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C434 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C433 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C651 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C724 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C725 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C749 065G060310432K Y CAP 0603 100NF 10% 50V X7R

84

C747 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C744 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C742 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C741 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C739 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C736 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C734 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C732 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C635 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C721 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C657 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C659 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C660 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C667 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C669 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C676 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C700 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C702 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C705 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C710 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C713 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C715 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C205 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1045 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1041 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1040 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1038 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1036 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1033 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1032 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1031 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1029 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1027 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1026 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1025 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1024 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1023 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1019 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1018 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1017 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1016 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1015 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1006 065G060310432K Y CAP 0603 100NF 10% 50V X7R

85

C1003 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1001 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1631 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1615 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1608 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1607 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1605 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1102 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1085 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1084 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1082 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1076 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1072 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1047 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1048 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1049 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1050 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1051 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1053 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1058 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1059 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1060 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1065 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1069 065G060310432K Y CAP 0603 100NF 10% 50V X7R

C1062 065G060310512K T CAP 0603 1UF 10% 16V X7R

C1063 065G060310512K T CAP 0603 1UF 10% 16V X7R

C522 065G060310512K T CAP 0603 1UF 10% 16V X7R

C525 065G060310512K T CAP 0603 1UF 10% 16V X7R

C529 065G060310512K T CAP 0603 1UF 10% 16V X7R

C530 065G060310512K T CAP 0603 1UF 10% 16V X7R

C534 065G060310512K T CAP 0603 1UF 10% 16V X7R

C701 065G060310512K T CAP 0603 1UF 10% 16V X7R

C204 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C203 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1613 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1612 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1611 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1610 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1035 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1034 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1030 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1028 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1022 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

86

C1020 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C1014 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

C275 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C276 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C291 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C296 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C299 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C218 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C274 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C270 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C263 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C259 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C257 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C253 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C252 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C249 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C248 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C246 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C245 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C239 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C237 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C236 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C230 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C228 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C225 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C224 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C221 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C300 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C306 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C315 065G060310605M Y CAP CHIP 0603 10uF 6.3V X5R +/-20%

C730 065G060315131J Y CAP CHIP 0603 150PF J 50V NPO

C1056 065G060315232K 3 CAP 0603 1.5NF 10% 50V X7R

C1055 065G060318031J Y CAP CHIP 0603 18P 50V NPO +/-5%

C1054 065G060318031J Y CAP CHIP 0603 18P 50V NPO +/-5%

C1044 065G060318031J Y CAP CHIP 0603 18P 50V NPO +/-5%

C1043 065G060318031J Y CAP CHIP 0603 18P 50V NPO +/-5%

C208 065G060320031J Y CAP CHIP 0603 20P 50V NPO +/-5%

C207 065G060320031J Y CAP CHIP 0603 20P 50V NPO +/-5%

C716 065G060322031J F CAP CHIP 0603 22PF J 50V NPO

C1083 065G060322131J A CAP CHIP 0603 220PF J 50V NPO

C704 065G060322422K T CAP CHIP0603 220NF K 25V X7R

C649 065G060333131J Y CAP CHIP 0603 330P 50V NPO +/-5%

C663 065G060333131J Y CAP CHIP 0603 330P 50V NPO +/-5%

87

C645 065G060333131J Y CAP CHIP 0603 330P 50V NPO +/-5%

C671 065G060333131J Y CAP CHIP 0603 330P 50V NPO +/-5%

C668 065G060333131J Y CAP CHIP 0603 330P 50V NPO +/-5%

C728 065G060333231J F CAP CHIP 0603 3.3NF J 50V NPO

C1057 065G060347031J Y CAP CHIP 0603 47P 50V NPO +/-5%

C655 065G060347232K Y CAP CHIP 0603 4N7 50V X7R +/-10%

C708 065G060347412K Y CAP CHIP 0.47uF 16V +/-10% X7R

C656 065G060368131J Y CAP CHIP 0603 680pF J 50V NPO

C718 065G080510522K Y CAP CHIP 0805 1U 25V X7R +/-10%

C719 065G080510522K Y CAP CHIP 0805 1U 25V X7R +/-10%

C720 065G080510522K Y CAP CHIP 0805 1U 25V X7R +/-10%

C6A2 065G080510537Z T CAP CHIP 0805 1uF Z 50V Y5V

C6A3 065G080510537Z T CAP CHIP 0805 1uF Z 50V Y5V

C523 065G080510615K T CHIP 10uF 16V X5R 0805

C431 065G080510615K T CHIP 10uF 16V X5R 0805

C426 065G080510615K T CHIP 10uF 16V X5R 0805

C416 065G080510615K T CHIP 10uF 16V X5R 0805

C406 065G080510615K T CHIP 10uF 16V X5R 0805

C405 065G080510615K T CHIP 10uF 16V X5R 0805

C320 065G080510615K T CHIP 10uF 16V X5R 0805

C273 065G080510615K T CHIP 10uF 16V X5R 0805

C1066 065G080510615K T CHIP 10uF 16V X5R 0805

C1064 065G080510615K T CHIP 10uF 16V X5R 0805

C523 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C431 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C426 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C416 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C406 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C405 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C320 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C273 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C1066 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C1064 065G080510615K Y CAP CHIP 0805 10uF K 16V X5R

C222 065G080522522K T CAP 0805 2.2uF 10% 25V X7R

C233 065G080522522K T CAP 0805 2.2uF 10% 25V X7R

C643 065G080547432K M MLCC 0805 0.47UF 50V X7R

C661 065G080547432K M MLCC 0805 0.47UF 50V X7R

C670 065G080547432K M MLCC 0805 0.47UF 50V X7R

C1068 065G080547525K T CAP MLCC 0805 4.7uF K 25V X5R

C1013 065G080547525K T CAP MLCC 0805 4.7uF K 25V X5R

C1011 065G080547525K T CAP MLCC 0805 4.7uF K 25V X5R

C1079 065G0805475A2K Y CAP CHIP 0805 4.7UF K 10V X7R

C1080 065G0805475A2K Y CAP CHIP 0805 4.7UF K 10V X7R

88

C1091 065G0805475A2K Y CAP CHIP 0805 4.7UF K 10V X7R

C1092 065G0805475A2K Y CAP CHIP 0805 4.7UF K 10V X7R

C729 065G120610612K A MLCC 1206 10UF 16V X7R +-10% Samsung

C727 065G120610612K A MLCC 1206 10UF 16V X7R +-10% Samsung

C1814 065G120610612K A MLCC 1206 10UF 16V X7R +-10% Samsung

C729 065G120610612K M MLCC 1206 CAP 10uF 16V X7R

C727 065G120610612K M MLCC 1206 CAP 10uF 16V X7R

C1814 065G120610612K M MLCC 1206 CAP 10uF 16V X7R

C268 065G1206226A5K T CAP CHIP1206 22uF K 10V X5R

C269 065G1206226A5K T CAP CHIP1206 22uF K 10V X5R

FB701 071G 56G301 EA CHIP BEAD T1201209G301NP100

FB215 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB216 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB217 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB218 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB219 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB220 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB221 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB222 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB223 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB224 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB225 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB400 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB401 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB607 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB214 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB112 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB200 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB201 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB202 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB204 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB205 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB206 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB207 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB208 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB209 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB210 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB211 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB212 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB213 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF

FB111 071G 57G301 MB BEAD 1206 300ohm 4A

FB110 071G 57G301 MB BEAD 1206 300ohm 4A

FB109 071G 57G301 MB BEAD 1206 300ohm 4A

89

FB108 071G 57G301 MB BEAD 1206 300ohm 4A

FB106 071G 57G301 MB BEAD 1206 300ohm 4A

FB104 071G 57G301 MB BEAD 1206 300ohm 4A

FB103 071G 57G301 MB BEAD 1206 300ohm 4A

FB102 071G 57G301 MB BEAD 1206 300ohm 4A

FB101 071G 57G301 MB BEAD 1206 300ohm 4A

FB704 071G 59B121 TB160808B

FB511 071G 59C121 B FCM1608C-121T03 SMD

FB510 071G 59C121 B FCM1608C-121T03 SMD

FB508 071G 59C121 B FCM1608C-121T03 SMD

FB502 071G 59C121 B FCM1608C-121T03 SMD

FB100 071G 59C121 B FCM1608C-121T03 SMD

FB608 071G 59C300 CHIP BEAD

FB613 071G 59C300 CHIP BEAD

FB227 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

L700 073G253S 57 H SMD CHOKE 10uH 4A

L604 073G253S 83 T SMD CHOKE 47uH 1.4A SLF7055-470M1R2-3PF

L603 073G253S 83 T SMD CHOKE 47uH 1.4A SLF7055-470M1R2-3PF

L602 073G253S 83 T SMD CHOKE 47uH 1.4A SLF7055-470M1R2-3PF

L601 073G253S 83 T SMD CHOKE 47uH 1.4A SLF7055-470M1R2-3PF

R240 073G253S 94 M1 SMD CHOKE 2.2UH 20% 400mA

L102 073T 6322910M CHIP INDUCTOR 0603 2.2uH 10%

CN502 088G 34019E AT DMI HEADER 19P H:11.38mm

CN503 088G 34019E AT DMI HEADER 19P H:11.38mm

CN504 088G 34019E AT DMI HEADER 19P H:11.38mm

CN502 088G 34019E AV HDMI HEADER 19P BLACK - 2nd source

CN503 088G 34019E AV HDMI HEADER 19P BLACK - 2nd source

CN504 088G 34019E AV HDMI HEADER 19P BLACK - 2nd source

D100 093G 64 42 PP BAV70 SOT-23

D502 093G 64 42 PP BAV70 SOT-23

D503 093G 64 42 PP BAV70 SOT-23

D603 093G 6432P LL4148

D604 093G 6432P LL4148

X200 093G 22S503 H CRYSTAL HSX840GA 24MHZ 30ppm 18PF

X100 093G 22S910 H CRYSTAL HSX840GA 20P 16.00MHZ

ZD612 093G 39S 24 T RLZ 5.6B LLDS

ZD611 093G 39S 24 T RLZ 5.6B LLDS

ZD610 093G 39S 24 T RLZ 5.6B LLDS

ZD609 093G 39S 24 T RLZ 5.6B LLDS

ZD608 093G 39S 24 T RLZ 5.6B LLDS

D602 093G 60S 15 T DIODE RB160M-60TE25 SOD-123 ROHM

D711 093G 64S3PH BAS32L

D707 093G 64S3PH BAS32L

90

ZD100 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ

ZD101 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ

ZD102 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ

ZD104 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ

ZD105 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ

D701 093G3004 3 SM340A

CN704 311GW125A42ACH WAFER 1.25mm 42P

709T4243 QS002 CONSUMPTIVE ASS'Y

052G 2191 A PAPER TAPE

052G6026 2 MESH PRINTTING PAPER

055G 23520 IPA

055G 100610 TIN CREAM W/O PB

E715 715G4243M01000005F MAIN PCB

E715 715G4243M01000005K MAIN PCB 2nd source

P90T0051101 Heat Sink 40X38.5X10 FOR U603

Q90T0202 1 HEAT SINK FOR U200

IRPFAQG9C IR BOARD

U201 056G 627911 IR 38KHZ KSM-603TM2M

709T4086 QM002 CONSUMPTIVE ASS'Y

CN201 033G8032 3F HR CONNECTOR 3P 1.25

R202 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA

R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO

C201 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

065G060310432K A CONSUMPTIVE ASS'Y

052G6026 2 MESH PRINTTING PAPER

715G4086R01001005F IR PCB

KEPFAQF9C KEY BOARD G4531-A-X-X-1-100728

CN001 033G8032 8F S HR WAFER 1.25mm 8P

U001 056G 669 7 IC touch key 5701-UG320WT QFN-32(5*5 mm)

Q001 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

R014 061G0402000 JF RST CHIPR MAX0R05 1/16W FENGHUA

R015 061G0402000 JY NO-SUGGEST RST CHIPR MAX 0R05 OHM 1/16W

R002 061G06031000FY RST CHIP 100R 1% 1/10W

R009 061G06031000FY RST CHIP 100R 1% 1/10W

R006 061G06031002FY RST CHIPR 10KOHM +-1% 1/10W YAGEO

R004 061G06032002FF RST CHIPR 20KOHM +-1% 1/10W FENGHUA

R007 061G06032002FF RST CHIPR 20KOHM +-1% 1/10W FENGHUA

R010 061G0603221 JY RST 0603 220R 5% 1/10W

R003 061G06033301FY RST CHIP 3K3 1/10W 1%

R005 061G06036801FF RST CHIPR 6.8KOHM +-1% 1/10W FENGHUA

C001 065G040210412K Y CAP CHIP 0402 100N 16V X7R +/-10%

C002 065G060310522K T CAP CHIP 0603 1uF K 25V X7R

LED001 081G 15 3 EL LED SMD Blue/Red 12-22/BHR6C-C31/2C

91

709T4531 QS001 CONSUMPTIVE ASS'Y

052G6026 2 MESH PRINTTING PAPER

715G4531K01000004S KEY PCB

PLTVAL658AA6 POWER BOARD G4078-P01-W22-0030-3-100802

040G 45762412B CBPC LABEL

009G6005 1 GP GROUND TERMINAL

CN905 033G380212H WAFER 2.0mm 12P

CN904 033G380213B YH WAFER 2.0mm 13P 2nd source

CN904 033G380213B YH L WAFER 2.0MM 13P

CN904 033G380213B YH W WAFER 2.0mm 13P 2nd source

CN902 033G380213H WAFER 13P RIGHT ANGLE PITCH

CN901 033G8029 3A H B2P3S-VH

IC923 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC920 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC918 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC915 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC915 056G 139 3B IC PC123Y82FZ0F

IC918 056G 139 3B IC PC123Y82FZ0F

IC920 056G 139 3B IC PC123Y82FZ0F

IC923 056G 139 3B IC PC123Y82FZ0F

IC922 056G 379121 IC STR- A6069H DIP-8

Q919 057G 611 9 MOSFET 2SK4097LS-MG5 9.5 500 TO-220FI

Q920 057G 611 9 MOSFET 2SK4097LS-MG5 9.5 500 TO-220FI

Q919 057G 667914 MOSFET TK10A50D TO220

Q920 057G 667914 MOSFET TK10A50D TO220

Q923 057G 761 7 KTD1691P

Q923 057G 761502 SMALLTRAN BTD1805AD3 5A 60V TO-126ML

Q923 057G 761909 T SMALLTRAN KSD1691YSTU 5A 60V TO-126

NR901 061G 58509MEW NTCR 5R 5A SCK13055MMY506

NR902 061G 58509MEW NTCR 5R 5A SCK13055MMY506

C903 063G107M47410M CAP X2 470NF 20% 275V

C904 063G107M47410M CAP X2 470NF 20% 275V

C904 063G107M474AUM CAP X2 470NF 20% 305V

C903 063G107M474AUM CAP X2 470NF 20% 305V

C937 063G210K474 BC 10 CAP MPP 470NF 10% 520V

C937 063G210K474BCC MPP CAP 0.47UF 10% 520V

C928 063G211J273 5C 10 CAP MPP 27NF 5% 1KV

C928 063G211J2735HU CAP MPPB 27NF 5% 1KV

C974 065G 2K331 2A CAP CER 330PF 10% 2KV Y5P

C922 065G 3J1006ET GP 10PF 5% SL 3KV TDK

C901 065G306K2212B3 Y1 CAP 220pF +-10% 250VAC

C902 065G306K2212B3 Y1 CAP 220pF +-10% 250VAC

C905 065G306K2212B3 Y1 CAP 220pF +-10% 250VAC

92

C906 065G306K2212B3 Y1 CAP 220pF +-10% 250VAC

C901 065G306K2212BM CAP Y1 220PF 10% Y5P 250VAC KX

C902 065G306K2212BM CAP Y1 220PF 10% Y5P 250VAC KX

C905 065G306K2212BM CAP Y1 220PF 10% Y5P 250VAC KX

C906 065G306K2212BM CAP Y1 220PF 10% Y5P 250VAC KX

C935 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C981 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C984 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C987 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C935 065G306K4712BP 470pF Y1-CAP

C981 065G306K4712BP 470pF Y1-CAP

C984 065G306K4712BP 470pF Y1-CAP

C987 065G306K4712BP 470pF Y1-CAP

C9101 067G 42Z39015K EC 39uF M 450V 18*36mm

C9102 067G 42Z39015K EC 39uF M 450V 18*36mm

C938 067G 42Z39015K EC 39uF M 450V 18*36mm

C939 067G 42Z39015K EC 39uF M 450V 18*36mm

C939 067G 42Z39015L EC 39UF 10% 450V 10*50

C938 067G 42Z39015L EC 39UF 10% 450V 10*50

C9102 067G 42Z39015L EC 39UF 10% 450V 10*50

C9101 067G 42Z39015L EC 39UF 10% 450V 10*50

C991 067G204V471 2K CS CAP 470uF 10V 8*8 mm

C990 067G204V471 2K CS CAP 470uF 10V 8*8 mm

C991 067G204V471 2L CAP CS 470uF 20% 10V 8*8

C990 067G204V471 2L CAP CS 470uF 20% 10V 8*8

C994 067G215C1007KV EC 10UF 20% 50V EM 8*9

C977 067G215C1007KV EC 10UF 20% 50V EM 8*9

C961 067G215C1007KV EC 10UF 20% 50V EM 8*9

C920 067G215C1007KV EC 10UF 20% 50V EM 8*9

C910 067G215C1007KV EC 10UF 20% 50V EM 8*9

C944 067G215C4707KV EC 47UF 20% 50V EM 8*9

C992 067G215C4713KV LOW ESR EC 470uF 16V 8*9mm

C992 067G215C4713LV EC 470uF 20% 16V RXY 8*9

C924 067G215C4797KV EC 4.7UF 20% 50V EM 8*9

C965 067G215Z102 6K LOW ESR EC 1000uF M 35V 10*35mm

C970 067G215Z102 6K LOW ESR EC 1000uF M 35V 10*35mm

C965 067G215Z102 6L EC 1000uF 20% 35V RZW 10*35

C970 067G215Z102 6L EC 1000uF 20% 35V RZW 10*35

C916 067G415Z121 9K EC 120UF 20% 100V EJ 8*35

C918 067G415Z121 9K EC 120UF 20% 100V EJ 8*35

C916 067G415Z121 9L EC 120UF 20% 100V RPL 8*35

C918 067G415Z121 9L EC 120UF 20% 100V RPL 8*35

L901 073G 174159 H LINE FILTER 8mH MIN LCL-11611 HA

93

L902 073G 174159 H LINE FILTER 8mH MIN LCL-11611 HA

L901 073G 174159 L LINE FILTER 8mH MIN CC-013105

L902 073G 174159 L LINE FILTER 8mH MIN CC-013105

L910 073G 174194 L PFC CHOKE 294uH 10% CC-013601

L910 073G 174194 N PFC CHOKE 294uH 10% YUVA-1422

L904 073G 253203 H CHOKE COIL 5uH 15% 15mOHM DR8*10

L907 073G 253203 H CHOKE COIL 5uH 15% 15mOHM DR8*10

L908 073G 253203 H CHOKE COIL 5uH 15% 15mOHM DR8*10

L909 073G 253203 H CHOKE COIL 5uH 15% 15mOHM DR8*10

L909 073G 253203 S CHOKE COIL 5uH 15% 15mOHM DR8*10

L908 073G 253203 S CHOKE COIL 5uH 15% 15mOHM DR8*10

L907 073G 253203 S CHOKE COIL 5uH 15% 15mOHM DR8*10

L904 073G 253203 S CHOKE COIL 5uH 15% 15mOHM DR8*10

T903 080GL32P 30 L X'FMR 1.6MH 15% 30UH PT-013600

T903 080GL32P 30 N X'FMR 1.6MH 15% 30UH YUVA-1426

T902 080GL32P 31 L X'FMR 700UH 15% 7UH PT-013599

T902 080GL32P 31 N X'FMR 700UH 10% 7UH YUVA-1427

T901 080GL32P 50 N X'FMR 500UH 10% 105UH YUVA-1522

D921 093G 52 70 1 1N5408-E(Short pin) 3A/1000V DO-201AD

D922 093G 52 72 DIODE RY3AV4 3A/600V AXIAL-LEAD

D921 093G 5255L52T DIDOE 1N5408-E3/73 3A/1000V DO-201AD

D921 093G 52910 DIODE 1N5408-11 3A/1000V DO-201AD

D917 093G 60945 DIODE SF35G-05 DO-201AD

D919 093G 60945 DIODE SF35G-05 DO-201AD

705TQA57014 Q925 ASS'Y

Q925 057G 600 35 STP8NK80ZFP

Q925 057G 667 22 FQPF8N80C TO-220F

0M1G1730 8120 SCREW

Q90T0195 1 HEAT SINK

705TQA57019 Q901/Q902 ASS'Y

Q901 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q902 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q902 057G 611903 MOSFET AOTF12N50 TO-220F

Q901 057G 611903 MOSFET AOTF12N50 TO-220F

0M1G1730 8120 SCREW

Q90T0194 3 HEAT SINK

705TQA57020 Q905/Q906 ASS'Y

Q905 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q906 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q906 057G 611903 MOSFET AOTF12N50 TO-220F

Q905 057G 611903 MOSFET AOTF12N50 TO-220F

0M1G1730 8120 SCREW

Q90T0194 3 HEAT SINK

94

705TQA57021 Q907/Q908 ASS'Y

Q907 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q908 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q908 057G 611903 MOSFET AOTF12N50 TO-220F

Q907 057G 611903 MOSFET AOTF12N50 TO-220F

0M1G1730 8120 SCREW

Q90T0194 3 HEAT SINK

705TQA57022 Q911/Q912 ASS'Y

Q911 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q912 057G 611901 MOSFET 12A/500V FMA12N50E TO-220F

Q912 057G 611903 MOSFET AOTF12N50 TO-220F

Q911 057G 611903 MOSFET AOTF12N50 TO-220F

0M1G1730 8120 SCREW

Q90T0194 3 HEAT SINK

705TQA57027 Q921 ASS"Y

Q921 057G 667 55 FET 2SK4087LS 14A/600V TO-220FI(LS)

0M1G 930 5120 SCREW

Q90T0220 1 HEAT SINK

705TQA93024 BD901 ASS'Y

BD901 093G 50460916 BRIDGE KBJ1008G-F 10A 800V KBJ

BD901 093G 50460932 BRIDGE TS10B06G-04 X0 10A 800V KBJ

0M1G1730 8120 SCREW

Q90T0194 1 HEAT SINK

705TQA93025 D926/D927 ASS'Y

D926 093G 60239 FME-210B T0-220

D927 093G 60329 DIODE FMEN-220A 20A/100V TO-220

D927 093G 60331 SCHOTTKY YG865C10RSC 20A 100V TO-220F

D926 093G 60903 Diode MBRF10150CT TSC

D927 093G 60935 DIODE MBRF20100CT ITO-220AB

0M1G1730 8120 SCREW

Q90T0194 3 HEAT SINK

705TQA93026 D932 ASS'Y

D932 093G 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS)

D932 093G 60931 DIODE MBRF1560CT ITO-220AB

0M1G1730 8120 SCREW

Q90T0195 1 HEAT SINK

709T4078 QM001 COMSUPTIVE ASS'Y

055G 23520 IPA

055G 23524 WELDING FLUX WITHOUT PB

Q49G 51100 CLEANER

Q51G 6 4509 GLUE_RTV

Q55G 100625 TIN STICK_LOW ARGENTUM

IC926 056G 192 31 IC OP AMPLIFIER LM258DT SOP-8

95

IC926 056G 192 32 OP AMP LM2904DR2G SOIC-8

IC930 056G 379172 IC LD7591GS SOP-8

IC919 056G 379175 IC LD7523GS SOP-8

IC914 056G 379176 IC SSC9512S-TL SOP-18

IC908 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC911 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC912 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC907 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC901 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC902 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC905 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

IC906 056G 563242 IC DC/DC AZ432ANTR-G1 SOT-23

Q926 057G 417 12 T KEC 2N3904S-RTK/PS

Q916 057G 417 12 T KEC 2N3904S-RTK/PS

Q924 057G 417 12 T KEC 2N3904S-RTK/PS

Q917 057G 417 12 T KEC 2N3904S-RTK/PS

Q913 057G 417 12 T KEC 2N3904S-RTK/PS

Q914 057G 417 13 T KEC 2N3906S-RTK/PS

Q914 057G 417517 TRA LMBT3906LT1G -200mA/-40V SOT-23 LRC

Q916 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

Q913 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

Q917 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

Q924 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

Q926 057G 417518 TRA LMBT3904LT1G 200mA/40V SOT-23 LRC

Q915 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q918 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q918 057G 763511 MOSFET SRK7002LT1G SOT-23 LRC

Q915 057G 763511 MOSFET SRK7002LT1G SOT-23 LRC

Q915 057G 763904 TRA FET 2N7002 SOT-23 PHILIPS

Q918 057G 763904 TRA FET 2N7002 SOT-23 PHILIPS

R9122 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA

R949 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA

R978 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA

R978 061G0805100 JT RST CHIP 10R 1/8W 5% TZAI YUAN

R9122 061G0805100 JY RST CHIPR 10OHM +- 5% 1/8W YEGAO

R949 061G0805100 JY RST CHIPR 10OHM +- 5% 1/8W YEGAO

R9104 061G08051001FT RST CHIP 1K 1/8W 1%

R9159 061G08051001FT RST CHIP 1K 1/8W 1%

R9161 061G08051001FT RST CHIP 1K 1/8W 1%

R9162 061G08051001FT RST CHIP 1K 1/8W 1%

R936 061G08051001FT RST CHIP 1K 1/8W 1%

R936 061G08051001FY RST CHIP 1K 1/8W 1%

R9162 061G08051001FY RST CHIP 1K 1/8W 1%

96

R9161 061G08051001FY RST CHIP 1K 1/8W 1%

R9159 061G08051001FY RST CHIP 1K 1/8W 1%

R9104 061G08051001FY RST CHIP 1K 1/8W 1%

R961 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R951 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R947 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R944 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R939 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R937 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R935 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R934 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R930 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R929 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9100 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9103 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9105 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9106 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9127 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9129 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9133 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9175 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R9176 061G08051002FF RST CHIPR 10KOHM +-1% 1/8W FENGHUA

R929 061G08051002FY RST CHIP 10K 1/8W 1%

R9176 061G08051002FY RST CHIP 10K 1/8W 1%

R9175 061G08051002FY RST CHIP 10K 1/8W 1%

R9133 061G08051002FY RST CHIP 10K 1/8W 1%

R9129 061G08051002FY RST CHIP 10K 1/8W 1%

R9127 061G08051002FY RST CHIP 10K 1/8W 1%

R9106 061G08051002FY RST CHIP 10K 1/8W 1%

R9105 061G08051002FY RST CHIP 10K 1/8W 1%

R9103 061G08051002FY RST CHIP 10K 1/8W 1%

R9100 061G08051002FY RST CHIP 10K 1/8W 1%

R961 061G08051002FY RST CHIP 10K 1/8W 1%

R951 061G08051002FY RST CHIP 10K 1/8W 1%

R947 061G08051002FY RST CHIP 10K 1/8W 1%

R944 061G08051002FY RST CHIP 10K 1/8W 1%

R939 061G08051002FY RST CHIP 10K 1/8W 1%

R937 061G08051002FY RST CHIP 10K 1/8W 1%

R935 061G08051002FY RST CHIP 10K 1/8W 1%

R934 061G08051002FY RST CHIP 10K 1/8W 1%

R930 061G08051002FY RST CHIP 10K 1/8W 1%

R928 061G08051003FF RST CHIPR 100KOHM +-1% 1/8W FENGHUA

R932 061G08051003FF RST CHIPR 100KOHM +-1% 1/8W FENGHUA

97

R932 061G08051003FY RST CHIP 100K 1/8W 1%

R928 061G08051003FY RST CHIP 100K 1/8W 1%

R938 061G0805101 JF RST 0805 100R 5% 1/8W

R938 061G0805101 JT RST CHIP 100R 1/8W 5% TZAI YUAN

R9172 061G0805103 JI RST 0805 10K 5% 1/8W

R9172 061G0805103 JY RST CHIPR 10KOHM +-5% 1/8W YAGEO

R9178 061G0805105 JF RST CHIPR 1M OHM +- 5% 1/8W FENGHUA

R9178 061G0805105 JT RST CHIP 1M 1/8W 5% TZAI YUAN

R9125 061G08051302FF RST CHIPR 13KOHM +-1% 1/8W FENGHUA

R995 061G08051302FF RST CHIPR 13KOHM +-1% 1/8W FENGHUA

R9125 061G08051302FY RST CHIP 13K 1/8W 1%

R995 061G08051302FY RST CHIP 13K 1/8W 1%

R945 061G08051432FF RST CHIPR 14.3KOHM +-1% 1/8W FENGHUA

R967 061G08052000FF RST CHIPR 200 OHM +-1% 1/8W FENGHUA

R967 061G08052000FY RST CHIP 200R 1/8W 1%

R9135 061G08052001FF RST CHIPR 2KOHM +-1% 1/8W FENGHUA

R9135 061G08052001FY RST CHIP 2K 1/8W 1%

R971 061G08052002FF RST CHIPR 20KOHM +-1% 1/8W FENGHUA

R971 061G08052002FT RST CHIP 20K 1/8W 1%

R990 061G0805202 JF RST CHIPR 2KOHM +-5% 1/8W FENGHUA

R990 061G0805202 JT RST CHIP 2K 1/8W 5% TZAI YUAN

R931 061G0805203 JF RST CHIPR 20KOHM +-5% 1/8W FENGHUA

R931 061G0805203 JY RST CHIPR 20KOHM +-5% 1/8W

R9124 061G0805220 JF RST CHIPR 22 OHM +-5% 1/8W FENGHUA

R9124 061G0805220 JT RST CHIPR 22OHM +-5% 1/8W TZAI YUAN

R974 061G08052201FF RST CHIPR 2.2KOHM +-1% 1/8W FENGHUA

R974 061G08052201FT CHIP 2K2 1/8W 1%

R942 061G0805221 JF RST CHIPR 220 OHM +-5% 1/8W FENGHUA

R942 061G0805221 JT RST CHIP 220R 1/8W 5% TZAI YUAN

R9130 061G08052402FF RST CHIPR 24KOHM +-1% 1/8W FENGHUA

R9130 061G08052402FY RST CHIP 24K 1/8W 1%

R963 061G08052431FF RST CHIPR 2.43KOHM +-1% 1/8W FENGHUA

R963 061G08052431FY RST CHIP 2K43 1/8W 1%

R9131 061G08052702FF RST CHIPR 27KOHM +-1% 1/8W FENGHUA

R964 061G08052702FF RST CHIPR 27KOHM +-1% 1/8W FENGHUA

R9131 061G08052702FY RST CHIP 27K 1/8W 1%

R964 061G08052702FY RST CHIP 27K 1/8W 1%

R970 061G08053301FF RST CHIPR 3.3KOHM +-1% 1/8W FENGHUA

R970 061G08053301FT RST CHIP 3K3 1/8W 1%

R968 061G08053302FF RST CHIPR 33KOHM +-1% 1/8W FENGHUA

R933 061G08053302FF RST CHIPR 33KOHM +-1% 1/8W FENGHUA

R968 061G08053302FT RST CHIP 33K 1/8W 1%

R933 061G08053302FT RST CHIP 33K 1/8W 1%

98

R9155 061G0805332 JF RST CHIPR 3.3KOHM +-5% 1/8W FENGHUA

R9155 061G0805332 JY RST CHIPR 3K3 +-5% 1/8W YAGEO

R9128 061G0805392 JF RST CHIPR 3.9KOHM +-5% 1/8W FENGHUA

R9128 061G0805392 JY RST CHIPR 3K9 +-5% 1/8W YAGEO

R969 061G0805432 JF RST CHIPR 4.3KOHM +-5% 1/8W FENGHUA

R969 061G0805432 JY RST CHIPR 4.3KOHM +-5% 1/8W YAGEO

R998 061G0805433 JF RST CHIPR 43KOHM +-5% 1/8W FENGHUA

R998 061G0805433 JI RST CHIPR 43 KOHM +-5% 1/8W 0805

R950 061G0805470 JF RST CHIPR 47OHM +-5% 1/8W FENGHUA

R960 061G0805470 JF RST CHIPR 47OHM +-5% 1/8W FENGHUA

R960 061G0805470 JT RST CHIPR 47OHM +-5% 1/8W TZAI YUAN

R950 061G0805470 JT RST CHIPR 47OHM +-5% 1/8W TZAI YUAN

R976 061G08054702FF RST CHIPR 47KOHM +-1% 1/8W FENGHUA

R976 061G08054702FT RST CHIP 47K 1/8W 1%

R9132 061G0805471 JF RST CHIPR 470 OHM +-5% 1/8W FENGHUA

R993 061G0805471 JF RST CHIPR 470 OHM +-5% 1/8W FENGHUA

R993 061G0805471 JY RST CHIPR 470OHM +-5% 1/8W YAGEO

R9132 061G0805471 JY RST CHIPR 470OHM +-5% 1/8W YAGEO

R9152 061G08055603FF RST CHIPR 560KOHM +-1% 1/8W FENGHUA

R9152 061G08055603FY RST CHIP 560K 1/8W 1%

R941 061G0805562 JF RST CHIPR 5.6kOHM +-5% 1/8W FENGHUA

R941 061G0805562 JY RST CHIPR 5K6 +-5% 1/8W YAGEO

R966 061G0805681 JF RST CHIPR 680OHM +-5% 1/8W FENGHUA

R966 061G0805681 JT RST CHIPR 680OHM +-5% 1/8W TZAI YUAN

R9166 061G08057501FF RST CHIPR 7.5KOHM +-1% 1/8W FENGHUA

R9166 061G08057501FY RST CHIP R 7K5 1/8W +/-1%

R9156 061G08058201FF RST CHIPR 8.2KOHM +-1% 1/8W FENGHUA

R9156 061G08058201FY RST CHIP 8K2 1/8W 1%

R943 061G08059101FF RST CHIPR 9.1KOHM +-1% 1/8W FENGHUA

R943 061G08059101FY RST CHIP 9K1 1/8W 1%

R973 061G0805912 JF RST CHIPR 9.1KOHM +-5% 1/8W FENGHUA

R973 061G0805912 JT RST CHIPR 9.1 KOHM +-5% 1/8W 0805

R9177 061G0805913 JF RST CHIPR 91KOHM +-5% 1/8W FENGHUA

JR901 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR902 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR903 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR904 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR905 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR906 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR907 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR907 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR906 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR905 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

99

JR904 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR903 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR902 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR901 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

R9173 061G12061002FF RST CHIPR 10KOHM +-1% 1/4W FENGHUA

R9173 061G12061002FT RST CHIPR 10KOHM +-1% 1/4W 1206

R972 061G12061003FF RST CHIPR 100KOHM +-1% 1/4W FENGHUA

R972 061G12061003FT RST CHIP 100K 1/8W 1%

R9180 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R9179 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R9121 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R9180 061G12061004FY RST CHIP 1M 1/4W 1%

R9179 061G12061004FY RST CHIP 1M 1/4W 1%

R9121 061G12061004FY RST CHIP 1M 1/4W 1%

R9113 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9114 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9115 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9116 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9138 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9139 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9142 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9143 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R954 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R955 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R956 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R957 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R958 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R959 061G1206104 JT RST CHIPR 100KOHM +-5% 1/4W TZAI YUAN

R9115 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9114 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9113 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9116 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9138 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9139 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9142 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R957 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R958 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R956 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R955 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R954 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9143 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R959 061G1206104 JY NO-SUGGEST RST CHIPR 100KOHM 5% 1/4W YAG

R9118 061G12061501FF RST CHIPR 1.5KOHM +-1% 1/4W FENGHUA

100

AOC LE32H057D Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
