31.5Ǝ& 38.5ƎLCD TV AOC LE32A0320-LE39A0320
Service
Service
Service
31~68 KHz
Description Page Description Page
Table of Contents.......……....................................…........1
Important Safety Notice.......................................……......2
Revision List…………………………………………………3
1. General Specification..............................……...…........4
2. Operating Instructions………………...…….……….......5
2.1 The Use of Remote Control…….…..……….…….......5
2.2 To Use the Menus….....………………….…..…….......6
2.3 How to Connect……..……………….…….……….....13
2.4 Front Panel Control Knobs…….………….……….....15
3. Input/Output Specification…………....................…....16
4. Mechanical Instructions…………………….................18
5. Repair Flow Chart ……………………….…….…….....24
6. PCB Layout ………………..…………………....….......31
6.1 Main Board…………..……………...…….…….......31
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
Horizontal Frequency
TABLE OF CONTENTS
6.2 Power Board……...…………..….…….……….......32
6.3 Key Board……………………….……..……….......33
6.4 IR Board………………………….……..……….......33
7. Adjustment..............................................................34
7.1 ADC Adjustment……………………..……...………34
7.2 FW Upgrade.………………………………...………35
8. Block Diagram.……........................................... ......36
9. Schematic Diagram…..…………....………………...37
9.1 Main Board…………………………………...….......37
9.2 Power Board…………..….….……...………….......38
9.3 Key Board……………….……….…………….........42
9.4 IR Board……………….……….…………….........43
10. Exploded View………………………………….…...44
11. BOM List……………….………………….………….48
SAFETY NOTICE
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
1
英华家电维修资料软件专用 购买QQ:505966338
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performin g service
operations. Some of these service operations require the use of tools specially designed for the purpose. The
special tools should be used when and as recommended.
It is important to note that this manual contains vario us CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics might create
shock, fire, or other hazards.
Under no circumstances should the original design be modified o r altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiations when open AVOID DIRECT EXPOSURE T O BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in da mage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)
2
英华家电维修资料软件专用 购买QQ:505966338
Revision List
Version Release Date Revision Instructions Customer Model TPV Model
LE32A0320 E32C21NSCQE7NNX
A00 Oct.17,2012 Initial release
LE39A0320 E39C21NSCQE6NNX
3
英华家电维修资料软件专用 购买QQ:505966338
1. General Specification
Nota:
• Los diseños y las especificaciones están sujetos a cambios sin aviso previo.
• Este modelo podría no ser compatible con funciones y/o especificaciones que se introduzcan en el futuro.
4
英华家电维修资料软件专用 购买QQ:505966338
2. Operating Instructions
2.1 The Use of Remote Control
5
英华家电维修资料软件专用 购买QQ:505966338
2.2 To Use the Menus
6
英华家电维修资料软件专用 购买QQ:505966338
7
英华家电维修资料软件专用 购买QQ:505966338
8
英华家电维修资料软件专用 购买QQ:505966338
9
英华家电维修资料软件专用 购买QQ:505966338
10
英华家电维修资料软件专用 购买QQ:505966338
11
英华家电维修资料软件专用 购买QQ:505966338
12
英华家电维修资料软件专用 购买QQ:505966338
2.3 How to Connect
13
英华家电维修资料软件专用 购买QQ:505966338
14
英华家电维修资料软件专用 购买QQ:505966338
2.4 Front Panel Control Knobs
15
英华家电维修资料软件专用 购买QQ:505966338
3. Input / Output Specification
3.1 Signal Input (The main board is not produce by TPV)
16
英华家电维修资料软件专用 购买QQ:505966338
3.2 Compatible Mode Table
17
英华家电维修资料软件专用 购买QQ:505966338
4. Mechanical Instructions
LE32A0320
1. Remove the screws to remove BASE.
2. Remove the screws to remove REAR COVER.
18
英华家电维修资料软件专用 购买QQ:505966338
3. Remove the screws to remove MAIN BOARD , POWER BOARD and SPEAKERS.
4. Remove the screw to remove BKT and DECO.
19
5.The PANEL.
英华家电维修资料软件专用 购买QQ:505966338
6.The DECO.
20
英华家电维修资料软件专用 购买QQ:505966338
LE39A0320
1. Remove the screws to remove BASE.
2. Remove the screws to remove REAR COVER.
21
英华家电维修资料软件专用 购买QQ:505966338
3. Remove the screws to remove MAIN BOARD , POWER BOARD and SPEAKERS.
4. Remove the screw to remove BKT and DECO.
22
5. The PANE L.
英华家电维修资料软件专用 购买QQ:505966338
6.The DECO.
23
英华家电维修资料软件专用 购买QQ:505966338
5. Repair Flow Chart
1. Sin Energía
Sin Energía (LED “Apagado”)
Revise la entrada AC. ¿La
energía está en “encendida”?
Si
Salida Power board =5.2V?
Si
Revise IR board y LED
No
Reemplace IR board
No
No
Enciéndalo
No
Reemplace power board
Reemplace main board
24
英华家电维修资料软件专用 购买QQ:505966338
2. No Enciende
(Chequee tecla power del control remoto, si
equipo no responde significa que es anormal).
No inicia (LED naranjo)
Salida Power board᧹12V᧻
Si
Revise si el botón de power funciona
No
Revise si el receptor IR es normal
No
No
Reemplace power board
Si
Reemplace key board
Si
Reemplace IR board
Reemplace main board
No
Reemplace la Power board
25
3. Imagen Anormal
Entre al menú modo de fábrica para hacer
英华家电维修资料软件专用 购买QQ:505966338
Imagen Anormal
No
Revise la fuente
Si
“EEPROM initial”&“Reset”
No
Reinicie la fuente
Revise main board
Si
Revise el cable LVDS
Si
Revise el panel
No
Reemplace panel
No
Reemplace main board
No
Reemplace LVDS cable
26
英华家电维修资料软件专用 购买QQ:505966338
4. Sin Imagen
Revise si el TV funciona, si enciende/apaga
vía control remoto y botón de power.
Si
Revise cable LVDS
Si
Panel Vcc = 5.2V?
Sin imagen (LED verde)
Si
Revise si la luz del panel está
encendida= “On”
No
Vuelva a insertar o
Reemplace el cable LVDS
No
No
Reemplace main board
No
Revise señal L/P si
está disponible
Si
Salida de Power board᧹12V᧻
Reemplace main board
No
No
Si
Reemplace the Panel
Reemplace main board
27
Si
Reemplace Panel
Reemplace power board
英华家电维修资料软件专用 购买QQ:505966338
5. Problema de Sonido
Revise la conexión de la fuente de audio y si norma de
Sin sonido o sonido anormal
TV es correcto (NTSC-PAL N/M/ISTB)
Si
Revise si TV está mudo (muted), ajuste el volume o
entre al modo menú para reinicio?
No
Entre al modo menú de fábrica para reinicar
No
Revise el cable entre los parlantes y main
board si están OK
Si
No
Vuelva a insertar el cable de audio o cambie
la norma del TV
No
Reemplace cable
Revise los valores de Resistencia en el p arlante que se encue ntran en
las especificaciones (Nota: El valor está marcado en el parlante)
Si
Reemplace parlante
28
Reemplace main board
No
英华家电维修资料软件专用 购买QQ:505966338
6. Control Remoto - mal funcionamiento
Control remoto - mal funcionamiento
Revise la batería del control remoto si está
bien colocada o no tiene energía
No
Use otros controles remotos, ¿funciona?
Si
Reemplace batería
Si
Reemplace el control remoto
No
¿Es anormal la IR board?
No
Reemplace main board
Si
Reemplace IR board
29
英华家电维修资料软件专用 购买QQ:505966338
7. OSD es inestable o no trabaja de forma normal
OSD es inestable o no trabaja normalmente
La botonera está conectada correctamente?
Si
Los botones están OK?
Si
Botonera está OK?
Si
No
No
No
Reconecte el key board
Reemplace la función del botón
Reemplace la botonera
Entre al modo menú de fábrica para reinicar
No
Reemplace el main board
30
英华家电维修资料软件专用 购买QQ:505966338
6. PCB Layout
6.1 Main Board (The main board is not produce by TPV)
31
英华家电维修资料软件专用 购买QQ:505966338
6.2 Power Board
715G5654P01001002S
32
英华家电维修资料软件专用 购买QQ:505966338
6.3 Key Board
715G5711K01000004S
6.4 IR Board
715G5471R02000004S
33
英华家电维修资料软件专用 购买QQ:505966338
7. Adjustment
7.1 ADC Adjustment
(The main board is not produce by TPV)
34
英华家电维修资料软件专用 购买QQ:505966338
7.2 FW Upgrade
Step 1: Ready for F/W Upgrade
1.1 Prepare a U-disk. the file system of FAT is the best choice.
1.2 Copy the software from your computer to the U-disk root directory.
Step 2: F/W Upgrade
2.1 Plug the USB memory to the USB port of TV.
2.2 AC ON TV .
2.3 Press the power key on the Remote Control or the right side of TV to turn on TV.
2.4 When TV detect the USB memory and TV will upgrade automatically.
Notes: When Upgrade on the process, please don’t Power-Off!
2.6 When upgrade Success, remove the U-disk and restart it
2.7 Check the F/W version
35
英华家电维修资料软件专用 购买QQ:505966338
36
8. Block Diagram
(The main board is not produce by TPV)
英华家电维修资料软件专用 购买QQ:505966338
37
9. Schematic Diagram
9.1 Main Board (The main board is not produce by TPV)
CN9902
GDZJ30B
D9602
BAV70
ZD9603
1 2
2
R9601
1K OHM 1%
R9602
+24V aduio
+5.2V
0.1UF 50V
C9311
270UF 25V
C9310
+
L9301
3.5uH
C9309
470UF 25V
+
5.2V
470PF
C9308
330UF 16V
C9307
+
R9313
R9314
100 OHM 1/4W
D9305
FMEN-2308
100 OHM 1/4W
B+
HV
D9801
1N5408G-04_NC
T9301
POWER X'FMR
12345
R9301
0.1R
D9802
FMNS-1106S_NC
10
12
FB9903
BEAD
123
7
9
D9302
PR1007
R9303
100K 1%
R9305
100K 1%
R9302
100K 1%
R9304
100K 1%
D9301
PR1007
1M5 1/4W 1%
R9306
C9810
150uF 450V
+
680K OHM 1% 1/4W _N C
R9809
C9802
2200PF_NC
Q9801
STP10NK60ZFP_NC
PFC_ZCD
L9801
300UH_NC
1
12
2 6
D9803
SS0520_NC
R9801
10 OHM 1/8W_NC
1UF 450V_NC
C9801
+5.2V
+12V
+5.2V
5.2V
VCC
D9304
1N4148
D9303
PR1007
R9312
4R7 1/4W 5%
5
8
VCC
D/ST7D/ST
IC9301
A6069H
S/OCP1BR2GND3FB/OLP
C9301
1NF
1M5 1/4W 1%
R9307
R9810
PFC_ZC D
4
R9311
4.7M 5% 1/8W
1M5 1/4W 1%
R9308
680K OHM 1% 1/4W_NC
680K OHM 1% 1/4W _N C
R9811
R9805
470R 1%_NC
1
4
3
2
R9804
0.15R_NC
R9803
10K 1% 1/8W_NC
R9802
33R 1/8W 5%_N C
CS
INV
RAMP
COMP
LD7591GS_NC
IC9801
ZCD5GND6OUT7VCC
8
VCC_ON
R9813
47K OHM_NC
3
1 2
1
GDZJ6.2B
ZD9602
1 2
GDZJ20B
ZD9601
D9601
1N4148
R9319
6.2K OHM +-1% 1/8W
C9312
220NF 50V
R9317
3.3K 1% 1/8W
R9316
3.3K 1% 1/8W
R9315
470R 1%
12
43
100uF/50V
C9306
+
C9305
10UF 50V
+
GDZJ30B
ZD9301
1 2
0.1UF 50V
C9304
C9303
10nF50V
R9310
1R2 5% 2W
0.47UF 50V
C9302
620K 1/8W 1%
R9309
13K OHM 1%_NC
R9812
C9809
100PF 50V_NC
33K OHM_NC
R9807
1NF_NC
C9808
R9808
10K 1% 1/8W_NC
C9807
0.1uF 50V_NC
C9806
0.22uF 50V_NC
100N 50V_NC
C9805
10UF 50V_NC
C9804
+
47PF 50V_NC
C9803
4.7K OHM_NC
R9806
1K OHM 1%
C9601
1UF 50V
Q9601
BCR1002N3
123
R9318
5.6K OHM 1%
IC9303
AS431AZTR-E1
PC123X8YFZOF
IC9302
C9121
100PF
R9132
R9131
220 OHM 1/4W
220 OHM 1/4W
1
2
HS9103
HEAT SINK
123
4
HS9801
HEAT SINK
FOR Q9801 D9802
CONN
101112
13
+12V
ON/OFF
DIM
+36V
L9101
3.5uH
D9104
FMX-23S
1
HS9102
HEAT SINK
+24 LED
C9120
330UF 50V
+
C9119
330UF 50V
+
C9107
330UF 50V
+
123
2
R9113
100 OHM 1/4W
642
R9101
0R1 5% 2W
HV
L9102
+24VS
C9108
470PF
R9114
D9105
100 OHM 1/4W
89101112
R9102
82KOHM +-5% 2WS
C9114
1NF
CN9903
CONN_NC
123456789
+24 LED
+5.2V
PS_ON
+24V aduio
+24V aduio
0.1uF 50V
C9112
5.6K
R9115
330UF 35V
C9122
+
D9107
SR506
5.6K
R9116
5.6K
R9117
0.1uF 50V
C9123
330UF 35V
C9111
+
3.5uH
+
1000UF 35V
C9110
+
1000UF 35V
C9109
FMXA-2202S
123
R9118
100 OHM 1/4W
7
T9101
POWER X'FMR
123
HS9101
HEAT SINK
FOR Q9101
D9101
PR1007
R9103
0R05 1/4W
C9101
2.2NF
22R 1/8W 1%
+
R9106
VCC_ON
123456789
101112
DIM
+12V
ON/OFF
+5.2V
+12V
1.5K OHM
R9401
R9123
1.5K OHM
R9122
1.5K OHM
R9121
0.1uF 50V
C9117
680UF 25V
C9116
+
L9103
3.5uH
1000UF 25V
C9115
+
C9113
470PF
D9106
FMEN-220A
R9119
C9103
10UF 50V
C9102
20K OHM
123
100 OHM 1/4W
Q9101
STP10NK70ZFP
4
R9130
10K 1% 1/8W
D9102
SS052012R9108
R9109
33 OHM 1/8W
6
8
5
7
OUT
OVP
VCC
GND
LD7523GS
IC9101
BNO1COMP2NC3CS
4
0.1UF 50V
+12V
R9112
0R33 5% 2W
R9111
10K 1% 1/8W
R9110
470R 1%
1N 50V
C9105
C9104
0.1UF 50V
R9107
2K 1/8W 1%
英华家电维修资料软件专用 购买QQ:505966338
FOR BD9901
1
+
BD9901
TS6B06G-01
2
-
4
1
2
HS9901
HEAT SINK
3
12
L1N
CN9904
CONN
2
1 2
BEAD
FB9911
BEAD
FB9910
DSPL201M-A21F _NC
SG9904
L9902
13MH
4
3
C9904
470NF 305V
1
2
DSPL201M-A21F_NC
SG9903
DSPL201M-A21F_NC
SG9902
R9906
510K 1/4W_NC
R9903
C9903
470PF 250V
4
1
C9902
470PF 250V
510K 1/4W
5
8
L9901
13MH
3
R9902
510K 1/4W
2
C9901
470NF 305V
R9901
510K 1/4W
DSPL201M-A21F_NC
SG9901
7
D26D2
NC
NC
NC
R9905
510K 1/4W_NC
IC9901
NC1D12D13NC
4
NTCR
R9904
510K 1/4W_NC
NR9901
1 2
t
BEAD
FB9902
12
C9905
C9907
NC
RV9901
FB9901
BEAD
1 2
NC
Varistor
C9908
NC
CN9901
SOCKET
1 2
F9901
FUSE
1 2
3 4
C9906
470pF 250V
FB9907
BEAD
C9909
NC
FB9909
NC
1 2
〠⡩
<>
180*240*25mm
Size
Rev
〠⡩
R9403
10K 1% 1/8W
R9404
2SD1624T-TD -E
Q9401
12
43
C9911
10K 1% 1/8W
of
OEM MODE L
T P V ( Top Victory Electronics Co . , Ltd. )
PCB NAME
TPV MOD E L
02.POWER 715G5654-P0E-001-0020
C
㎜䳄⬌㎚㞩
Key Component
23
Sheet
Wednesday , July 18, 2012
Date
38
0.1UF 50V
C9401
Q9402
PMBS3904
1 2
GDZJ16B
ZD9401
+
C9402
10UF 50V
VCC_ON
R9129
2.26K 1%
R9134
C9118
0.47UF 50V
62K 1%_NC
R9126
3K3 1/8W 1%
IC9103
R9125
22K 1% 1/8W
NC
FB9906
BEAD
C9912
AS431AZTR-E1
GDZJ16B
ZD9101
1 2
PC123X8YFZOF
IC9102
12
470PF 250V
PS_ON
R9402
330R 1%
12
43
PC123X8YFZ OF
IC9401
10K 1% 1/8W
VCC
120K
R9133
+36V
56K OHM 1%
R9128
+24 LED
24K OHM 1%
R9127
+12V
R9124
1K 1/8W 1%
10nF 50V
C9106
12
B+
C9910
220PF 250V
12
FB9908
BEAD
9.2 Power Board
715G5654P01001002S (32” PLTVCL621UXE6)
180*240*25mm
Size
OEM MO D E L
〠⡩
<>
Rev
〠⡩
of
33
Sheet
PCB NAME
TPV MODEL
03. LED DRI VER 715G5654-P0E-001-0020
Wednesday , July 18, 2012
CN8901
LED-SOURCE
C8109
47UF 100V
+
L8102
5uH
C8108
47UF 100V
+
47UF 100V
C8107
+
C8110
D8103
FME-220B
2
3
1
+36V
2
L8101
33UH
1
Q8101
AOTF454FL
1
2
HS8101
HEAT SINK
3
4
12
D8101
SS0520
470PF_NC
10K 1% 1/8W
R8106
R8105
33 OHM
R8109
CONN
101112
LED-1
LED-SOURCE
0R1 5% 2W
R8107
470R 1%
DIM
123456789
LED-1
LED-SOURCE
R8212
10K 1% 1/8W
+12V
R8211
100K 1% 1/8W
FB
R8208
75K 1%
英华家电维修资料软件专用 购买QQ:505966338
Q8203
P0420ATF
LED-1
DTA144WN3/S
Q8201
R8210
R8214
75K 1%
R8213
20R 1%
R8205
20R 1%
R8204
20R 1%
R8203
20R 1%
R8202
20R 1%
R8201
20R 1%
R8207
10K 1% 1/8W
IC8201
AS431AN-E1
+12V
+
10UF 50V
C8101
FB
EN
100K 1% 1/8W
R8209
100K 1% 1/8W
DTC 144WN3/S
Q8202
R8104
33 OHM 1/4W
R8103
10K 1% 1/4W
C8102
0.1UF 50V
6
5
8
DIM
DRV7VCC
GND
LD7400GS
FB1COMP2RFW3CS
EN
R8306
ON/OFF
IC8101
4
30K OHM
R8101
NC
C8103
Q8302
300K 1/4W
2N7002
R8304
10K 1% 1/8W
3
2
300K OHM
R8102
1nF 50V
C8106
C8105
470PF 50V
0.1UF 5 0V
C8104
300K OHM
R8305
1nF 50V
C8301
BCR1002N3
Q8301
1
C8302
1uF
T P V ( Top Victory Electronics Co . , Ltd. )
Date
C
㎜䳄⬌㎚㞩
Key Component
39
R8206
5.1K OHM
DIM
+12V
LED-SOURCE
ZD8301
GDZJ30B
R8301
82K OHM 1%
1 2
R8302
0 OHM 1/8W
R8303
1K OHM 1%
〠⡩
CN9902
GDZJ30B
D9602
BAV70
ZD9603
1 2
+24V aduio
+5.2V
0.1UF 50V
C9311
270UF 25V
C9310
+
L9301
3.5uH
C9309
470UF 25V
+
5.2V
470PF
C9308
330UF 16V
C9307
+
R9313
R9314
100 OHM 1/4W
D9305
FMEN-2308
100 OHM 1/4W
123
7
9
T9301
POWER X'FMR
1
2
345
D9302
PR1007
R9303
100K 1%
R9305
100K 1%
R9302
100K 1%
R9304
B+
R9301
0.1R
100K 1%
D9301
PR1007
1M5 1/4W 1%
R9306
+5.2V
+12V
+5.2V
5.2V
VCC
D9303
PR1007
R9312
4R7 1/4W 5%
IC9301
A6069H
C9301
1NF
R9311
4.7M 5% 1/8W
1M5 1/4W 1%
1M5 1/4W 1%
R9307
R9308
2
1 2
1
GDZJ6. 2B
ZD9602
1 2
GDZJ20B
ZD9601
R9319
6.2K OHM +-1% 1/8W
R9315
470R 1%
100uF/50V
C9306
+
D9304
1N4148
C9305
10UF 50V
+
GDZJ30B
ZD9301
1 2
0.1UF 50V
C9304
8
5
VCC
D/ST7D/ST
S/OCP1BR2GND3FB/OLP
4
R9310
1R2 5% 2W
0.47UF 50V
C9302
R9309
620K 1/8W 1%
R9601
1K OHM 1%
R9602
3
D9601
1N4148
C9312
220NF 50V
R9317
3.3K 1% 1/8W
R9316
3.3K 1% 1/8W
12
43
C9303
10nF50V
1K OHM 1%
C9601
1UF 50V
Q9601
BCR1002N3
123
R9318
5.6K OHM 1%
IC9303
AS431AZTR-E1
PC123X8YFZOF
IC9302
C9121
100PF
R9131
R9132
220 OHM 1/4W
220 OHM 1/4W
1
2
HS9103
HEAT SINK
CONN
101112
13
+12V
ON/OFF
DIM
+24V aduio
D9107
+36V
L9101
3.5uH
D9104
FMX-23S
+24 LED
C9120
330UF 50V
+
C9119
330UF 50V
+
C9107
330UF 50V
+
123
L9102
+24VS
C9108
470PF
R9113
R9114
D9105
FMXA-2202S
100 OHM 1/4W
100 OHM 1/4W
7
89101112
6
4
2
CN9903
CONN_NC
123456789
+24 LED
+5.2V
PS_ON
+24V aduio
0.1uF 50V
C9112
5.6K
R9115
330UF 35V
C9122
+
SR506
5.6K
R9116
5.6K
R9117
0.1uF 50V
C9123
330UF 35V
C9111
+
3.5uH
+
1000UF 35V
C9110
+
1000UF 35V
C9109
C9113
123
R9118
R9119
100 OHM 1/4W
T9101
POWER X'FMR
123
HS9101
HEAT SINK
123456789
101112
DIM
+12V
ON/OFF
R9403
10K 1% 1/8W
R9404
2SD1624T-TD-E
Q9401
12
43
10K 1% 1/8W
0.1UF 50V
C9401
Q9402
PMBS3904
1 2
GDZJ16B
ZD9401
+
C9402
10UF 50V
VCC_ON
R9129
2.26K 1%
C9118
R9134
0.47UF 50V
62K 1%_NC
R9126
3K3 1/8W 1%
IC9103
R9125
22K 1% 1/8W
AS431AZTR-E1
GDZJ16B
ZD9101
1 2
PC123X8YFZOF
IC9102
PS_ON
R9402
330R 1%
+5.2V
+12V
1.5K OHM
R9123
1.5K OHM
R9122
1.5K OHM
R9121
0.1uF 50V
C9117
680UF 25V
C9116
+
L9103
3.5uH
1000UF 25V
C9115
+
470PF
D9106
FMEN-220A
123
100 OHM 1/4W
Q9101
STP10NK70ZFP
R9112
4
0R33 5% 2W
R9130
10K 1% 1/8W
12
43
PC123X8YFZOF
IC9401
R9401
10K 1% 1/8W
VCC
120K
R9133
+36V
56K OHM 1%
R9128
+24 LED
24K OHM 1%
R9127
+12V
R9124
1K 1/8W 1%
+12V
180*240*25mm
Size
OEM MODEL
T P V ( Top Victory Electronics Co . , Ltd. )
<>
Rev
PCB NAME
TPV MODEL
02.POWER 715G5654-P0E-001-0020
C
㎜䳄⬌㎚㞩
Key Component
〠⡩
of
23
Sheet
Thursday, July 19, 2012
Date
40
D9101
C9810
150uF 450V
HV
D9801
英华家电维修资料软件专用 购买QQ:505966338
BD9901
2
+
680K 1% 1/4W 500V
680K 1% 1/4W 500V
R9809
R9810
C9802
D9802
FMNS-1106S
2200PF_NC
Q9801
STP10NK60ZFP
R9805
470R 1%
PFC_ZCD
L9801
300UH
1
10
2 6
IN5408G-04
C9801
105 450V
12
BEAD
FB9903
1
+
TS6B06 G-01
3
-
4
1
2
HS9901
HEAT SINK
12
R9804
0.15R
R9803
10K 1% 1/8W
12
D9803
SS0520
R9802
33R 1/8W 5%
VCC_ON
R9801
10 OHM 1/8W
PFC_ZCD
L1N
CN9904
CONN
2
1 2
BEAD
FB9911
L9902
13MH
4
1
BEAD
FB9910
13K OHM 1%
R9812
680K 1% 1/4W 500V
C9809
100PF 50V
R9811
33K OHM
R9807
1NF
C9808
1
4
2
3
CS
R9808
INV
RAMP
COMP
10K 1% 1/8W
IC9801
LD7591GS
8
R9813
20K OHM
DSPL201M-A21F _NC
SG9904
3
C9904
470NF 305V
2
DSPL201M-A21F _NC
SG9903
C9807
0.1uF 50V
ZCD5GND6OUT7VCC
C9806
0.22uF 50V
0.1UF 50V
C9805
10UF 50V
C9804
+
47PF 50V
C9803
3.3K OHM
R9806
DSPL201M-A21 F_NC
SG9902
C9903
470PF 250V
L9901
13MH
4
3
1
2
C9902
470PF 250V
DSPL201M-A21 F_NC
SG9901
123
HS9801
HEAT SINK
R9906
R9903
510K 1/4W
NC
C9901
470NF 305V
R9905
R9902
510K 1/4W
NC
R9904
R9901
510K 1/4W
NC
t
4
7
8
NC
IC9901NCNC1D12D13NC
NTCR
NR9901
1 2
1
2
HS9102
HEAT SINK
R9101
0R1 5% 2W
BEAD
FB9902
12
5
C9907
NC
D26D2
NC
RV9901
Varistor
4
FB9901
BEAD
1 2
PR1007
R9103
0R05 1/4W
R9102
C9101
2.2NF
82KOHM +-5% 2WS
C9114
1NF
HV
C9905
NC
C9908
NC
F9901
D9102
SS052012R9108
22R 1/8W 1%
R9109
33 OHM 1/8W
R9111
10K 1% 1/8W
5
7
6
8
R9110
470R 1%
OUT
OVP
VCC
GND
1N 50V
LD7523GS
IC9101
BNO1COMP2NC3CS
0.1UF 50V
C9103
10UF 50V
C9102
+
R9106
20K OHM
VCC_ON
CN9901
SOCKET
1 2
FUSE
1 2
3 4
C9105
4
C9104
0.1UF 50V
R9107
2K 1/8W 1%
C9906
470pF 250V
12
FB9907
BEAD
C9909
NC
FB9908
FB9909
NC
1 2
10nF 50V
C9106
C9911
NC
B+
C9910
220PF 250V
12
BEAD
12
FB9906
BEAD
C9912
470PF 250V
715G5654P01001002S (39” PLTVCL801UXE7)
180*240*25mm
OEM MO D E L Size
T P V ( Top Victory Electronics Co . , Ltd. )
〠⡩
<>
〠⡩
Rev
of
33
Sheet
PCB NAME
TPV MODEL
03. LED DRI VER 715G5654-P0E-001-0020
Thursday , J uly 19, 2012
Date
C
㎜䳄⬌㎚㞩
Key Component
CN8901
LED-SOURCE
C8109
47UF 100V
+
L8102
5uH
C8108
47UF 100V
+
47UF 100V
C8107
+
C8110
D8103
FME-220B
2
HS8101
1
Q8101
AOTF454FL
1
2
HEAT SINK
3
4
12
D8101
SS0520
R8104
33 OHM 1/4W
3
1
+36V
R8212
10K 1% 1/8W
+12V
IC8201
AS431AN-E1
2
L8101
33UH
470PF_NC
10K 1% 1/8W
R8106
R8105
33 OHM
R8109
R8103
CONN
101112
LED-1
LED-SOURCE
0R1 5% 2W
R8107
470R 1%
DIM
10K 1% 1/4W
300K OHM
R8102
123456789
LED-1
LED-SOURCE
1nF 50V
C8106
C8105
470PF 50V
0.1UF 50V
C8104
300K OHM
R8305
1nF 50V
C8301
BCR1002N3
Q8301
1
C8302
1uF
+12V
+
10UF 50V
C8101
C8102
0.1UF 50 V
5
8
6
DIM
DRV7VCC
GND
LD7400GS
FB1COMP2RFW3CS
FB
EN
EN
R8306
ON/OFF
IC8101
4
300K 1/4W
R8304
30K OHM
R8101
NC
C8103
Q8302
2N7002
10K 1% 1/8W
3
2
R8210
100K 1% 1/8W
R8211
100K 1% 1/8W
FB
R8214
750K 1%
R8208
82K OHM 1%
R8213
6.8R 1%
R8205
6.8R 1%
R8204
6.8R 1%
R8203
6.8R 1%
R8202
6.8R 1%
英华家电维修资料软件专用 购买QQ:505966338
LED-1
Q8201
R8201
6.8R 1%
Q8203
P0420ATF
R8207
10K 1% 1/8W
DTA144WN3/S
R8209
100K 1% 1/8W
DTC 144WN3/S
Q8202
41
R8206
5.1K OHM
+12V
DIM
LED-SOURCE
ZD8301
GDZJ30B
R8301
120K
1 2
R8302
0 OHM 1/8W
R8303
1K OHM 1%
Custom
〠⡩
<>
Size
Rev
〠⡩
of
22Friday, April 27, 2012
2.48V~2.72V
VOL+
SW01
TACT SW FWRD H1.5MM
R01
2.04V~2.22V
VOL-
SW02
TACT SW FWRD H1.5MM
7K5 1/8W +/-1%
R02
1.58V~1.79V
CH+
SW03
TACT SW FWRD H1.5MM
2K7 1/8W 1%
R03
1.24~1.45V
CH-
SW04
TACT SW FWRD H1.5MM
1K8 +/-1% 1/8W
R04
0.85V~1.02V
MENU
SW05
TACT SW FWRD H1.5MM
1K 1/8W 1%
R05
0.47V~0.63V
Source Select
SW06
TACT SW FWRD H1.5MM
750OHM +-1% 1/8W
Power ON/OFF
SW07
77G 607 2 FD
TACT SW FWRD H1.5MM
Sheet
PCB NAME
OEM MO DEL
TPV MO D E L
02-Keypad
Date
T P V ( Top Victory Electronics Co . , Ltd. )
A
㎜䳄⬌㎚㞩
Key Component
42
R06
750OHM +-1% 1/8W
FUNC_KEY
R07
750OHM +-1% 1/8W
PWR-SW
英华家电维修资料软件专用 购买QQ:505966338
PWR-SW
FUNC_KEY
123
4
65
9.3 KEY Board
715G5711K01000004S
CN01
CONN
33G8032 4F HR
A
A
IR
Size
37mm
Top View
Dip LED
16 mm
Rev
〠⡩
<>
〠⡩
of
22Wednesday , January 18, 2012
715G5471-R0A-000-0040
GND1GND2OUT3VCC
U201
081G 14 24 EL
1
23
RED
LED201
4
英华家电维修资料软件专用 购买QQ:505966338
BLUE
R202 220 OHM 1/10W
LED_R
LED
VCC
R203 220 OHM 1/10W
LED_B
IRM-H636M3/TR2
4
R201 15K 1/10W
C201
0.1uF 50V
IR
Sheet
PCB N AME
OE M MO DE L
TPV MODEL
43
02-IR&LED
T P V ( Top Vict ory Electronic s C o . , Ltd. )
㎜䳄⬌㎚㞩
Date
Key Component
033G8032 5F HR
9.4 IR Board
715G5471R02000004S
12345
67
CN201
CONN
英华家电维修资料软件专用 购买QQ:505966338
44
10. Exploded View
LE32A0320
11
SCREW MAIN BOARD-BOLT/MAIN BOARD-BKT_IO-PANEL/
BKT_IO-PANEL/POWER BOARD-PANEL
Item Part No. Description Q’ty
英华家电维修资料软件专用 购买QQ:505966338
2 DECO_BEZEL
3 SPEAKER
4 PANEL
5 BKT_STAND
6 COVER_STAND
7 KEY
8 REAR_COVER
9 BASE
10 KEY BOARD
11 IR BOARD
12 MAIN BOARD
13 BKT_IO
14 POWER BOARD
15 BOLT 22 0M1G1030 8 47 CR3 SCREW REAR COVER-PANEL 8
16 BKT_BTM 23 0M1G1030 8 47 CR3 SCREW REAR COVER-DECO_BEZEL 6
17 INSULATING SHEET 24 0M1G1730 8120
18 BOLT 25 0M1G1740 10225 CR3 SCREW BKT_STAND-PANEL 4
19 CABLE TIE 26 0Q1G 940 8 47 CR3 SCREW REAR COVER-DECO_BEZEL 2
20 FOOT PAD 27 0Q1G 940 12 47 CR3 SCREW REAR COVER-DECO_BEZEL 4
21 BKT_STAND 28 0M1G1740 16225 CR3 SCREW BASE-STAND 4
Item Description
29 STAND 30 0M1G1740 10225 CR3 SCREW REAR COVER-BKT_STAND 4
45
LE32A0320
英华家电维修资料软件专用 购买QQ:505966338
46
LE39A0320
Item Part No. Description Q‘ty
英华家电维修资料软件专用 购买QQ:505966338
2 PANEL
3 DECO_BEZEL
4 DECO_BEZEL
6 IR BOARD
9 SPEAKER
10 COVER_STAND
11 BKT_STAND
13 INSULATING SHEET 5 0M1G1730 6120 SCREW DECO_BEZEL-PANEL/IR BOARD-DECO_BEZEL 5
14 POWER BOARD 12 0M1G 940 6125 SCREW BKT_STAND-PANEL 4
16 BOLT 15 0M1G1730 8120 SCREW POWER BOARD-PANEL 4
17 BOLT 19 0M1G1730 8120 SCREW BKT_IO-PANEL 1
18 BKT_IO 22 0M1G1730 8120 SCREW MAIN BOARD-BOLT-PANEL 1
20 MAIN BOARD 23 0M1G1730 8120 SCREW BKT_IO-MAIN BOARD-PANEL 1
21 BKT_BTM 24 0M1G1730 8120 SCREW MAIN BOARD-PANEL 1
25 BKT_HINGE 27 0Q1G1030 6120 SCREW BKT_HINGE-STAND 1
26 STAND 30 0Q1G 130 6120 XL SCREW BASE-BKT_BASE 2
28 BASE 31 0M1G1740 10225 CR3 SCREW BKT_BASE-STAND 4
29 BKT_BASE 33 0M1G1740 10225 CR3 SCREW BKT_HINGE-BKT_STAND 4
32 FOOT PAD 37 0M1G1030 6 47 CR3 SCREW REAR COVER-PANEL 8
34 KEY 38 0Q1G 940 10 47 CR3 SCREW REAR COVER-DECO_BEZEL 4
35 KEY BOARD 39 0Q1G 940 8 47 CR3 SCREW REAR COVER-DECO_BEZEL-COVER_STAND 2
Item Description
36 REAR_COVER 40 0M1G1730 8120 SCREW REAR COVER-AC SOCKET 1
47
LE39A0320
英华家电维修资料软件专用 购买QQ:505966338
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice.
Please go to http://cs.tpv.com.cn/hello1.asp
E32C21NSCQE7NNX
Location Part No. Description Remark
M03502-02 X35T8022001J1C01TS DECO_BEZEL
M04403 X44GJA663010FS CUSHION-BL
052G 1185 1 BIG TAPE(Y1200141)
052G 1186 SMALL TAPE
052G 2191 A PAPER TAPE
ECN1 095G801313RY04 HARNESS 13P-13P 350MM
0M1G1030 8 47 CR3 SCREW
0M1G1030 8 47 CR3 SCREW
0M1G1030 8 47 CR3 SCREW
0M1G1730 8120 SCREW 3X8
0M1G1730 8120 SCREW 3X8
0M1G1740 10225 CR3 SCREW M1-MACHINE SCREW X10.0
0M1G1740 10225 CR3 SCREW M1-MACHINE SCREW X10.0
0Q1G 930 8 47 CR3 SCREW
0Q1G 940 8 47 CR3 SCREW 4X8
0Q1G 940 12 47 CR3 SCREW 4X12
0Q1G1030 6120 SCREW 3X6
317GAAMB045TYA MAIN BOARD T.MS18VG.76B
378G0110567YAN 16 OHM 11W 132*34 0 NO
ECNA1 395G801304LY44 HARNESS 4P-B&R+B&W 700/500
ECN8 395G801410DY24 HARNESS 10P-5P+4P 400/550
ECN8 395G801410RY24 HARNESS 10P-5P+4P 400/550 2nd Source
ECN21 395G801840DY13 LVDS CABLE 30P-40P 380
ECN21 395G801840FY13 LVDS CABLE 30P-40P 380 2nd Sou rce
IRPFCXAD IR BOARD
CN201 033G8032 5F B CONN 1.25MM 5P R/A 11.2MM 5.7MM
CN201 033G8032 5F X WAFER 5P 1.25MM S1315-05RVB-S03-K
R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO
R202 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
C201 065G060310432K F CAP CHIP 0603 0.1UF K 50V X7R
LED201 081G 14 24 EL CHIP LED BLUE/DARK RED
U201 356GS927072 IR RECEIVER IRM-H638M3/TR2 38 KHZ
709T54710XS001 COMSUPTIVE ASS'Y
E715 715G5471R02000004S IR BOARD PCB
E715 715G5471R02000004X IR BOARD PCB 2nd Source
KEPFCXAE KEY BOARD
CN01 033G8032 4F B CONN 1.25MM 4P R/A 9.95MM 5.7MM
CN01 033G8032 4F X WAFER 4P 1.25MM
R04 061G08051001FT RST CHIP 1K 1/8W 1%
R03 061G08051801FY RST CHIP R 1K8 +/-1% 1/8W
R02 061G08052701FY RST CHIP 2K7 1/8W 1%
R06 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R05 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R07 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R01 061G08057501FY RST CHIP R 7K5 1/8W +/-1%
SW04 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW03 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
for the latest information.
48
英华家电维修资料软件专用 购买QQ:505966338
SW06 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW02 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW05 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW01 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW07 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW07 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW05 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW04 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW01 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW06 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW03 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW02 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
709T57110XS001 COMSUMPTIVE ASSY
Q05G6054 1 SHEET
Q09G6012 1 PIN
E715 715G5711K01000004S KEY BOARD PCB
E715 715G5711K01000004X KEY BOARD PCB 2nd Source
E750 LCV315TAT01AD8011X PANEL TPT315B5-TAT01 C1C XM TPV
P12G6311010 RUBBER PAD SILICONE
P33T0408ADT01L0100 KEY
P34T12010GMY3K01BA REAR_COVER
P34T1203ADT01L01BA BASE
P34T1204ADT01L0100 STAND
P34T12050GM01K0100 COVER_STAND
PLTVCL621UXE6 ADAPTER BOARD
Z40G0002ALL01A SFIS LABEL 35MM*9MM
CN8901 033G380212B YH WAFER 12P 2.0 DIP
IC9102 056G 139 3B PC123Y82FZOF SHARP
IC9302 056G 139 3B PC123Y82FZOF SHARP
IC9401 056G 139 3B PC123Y82FZOF SHARP
IC9301 056G 379121 IC STR- A6069H DIP-8
Q8203 057G 600948 MOSFET P0420ATF 4A 200V TO-220F
RV9901 061G 46621 P VARISTOR 620V 10% 16*7
NR9901 061G 58309MEW NTCR 3R 20% 3.6W SCK15037MMY502
C9904 063G107K474 EM CAP X2 470NF 10% 305V
C9901 063G107K474 EM CAP X2 470NF 10% 305V
FB9911 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9902 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9910 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9901 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
L9902 073G 174106 X LINE FILTER 13MH MIN 3LFT201110-133M
L9901 073G 174106 X LINE FILTER 13MH MIN 3LFT201110-133M
L9101 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9102 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9301 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9103 073G 253 91 V CHOKE COIL 3.5UH+-10%
L8102 073G 253203 X CHOKE COIL 5UH 15% --
T9301 080GL52P 54 H X'FMR 1000UH 10% 40UH EQ30 BCK-13026-HA
CN9901 087G 50147D HC AC SOKET R/A 2P 12DEGREE H=12.8
D9107 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
CN9901 0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
CN9902 311GW250B13BBX WAFER 2.5MM 13P R/A 35MM 7MM
C9810 367G315X151PKZ000S EC 150UF 20% 450V 18*45 3000 HR 1200MA -
L8101 373G0253249CP0 BOOST CHOKE 33UH 10% EQ25 0.5A L020692-6
49
英华家电维修资料软件专用 购买QQ:505966338
T9101 380GL32P106N00 X'FMR 750UH 10% 18UH ER28 YUVA-2016-4
705TXC57330 Q9101 ASSY
Q9101 057G 667 21 MOSFET STP10NK70ZFP 8.6A 700V TO-220FP
0M1G1730 8120 SCREW 3X8
HS9101 Q90G0087 7 HEAT SINK ÆÄËÛ/OTHER
705TXC57331 Q8101 & D8103 ASSY
D8103 093G 60258 DIODE FME-220B TO-220 SANKEN
0M1G1730 8120 SCREW 3X8
Q8101 357G0600980 MOSFET AOTF454L 13A 150V 41W TO-220F
HS8101 Q90T0237 1 HEAT SINK
705TXC84040 F9901 ASSY
EF9901 084G 34 10 FUSE CLIP
EF9901 084G 34 14 FUSE -- -- --
F9901 084G 41 3 C FUSE 3.15A 250V, TIME LAG FUSE
705TXC93969 BD9901 ASSY
HS9901 090G6064 1 HEAT SINK
BD9901 093G 50460925 BRIDGE TS6B06G-01 6A 800V KBJ
0M1G1730 8120 SCREW 3X8
705TXC93970 D9104 & D9105 ASSY
HS9102 090G6064 1 HEAT SINK
D9105 093G 52 57 RECTIFIER FMXA-2202S 20A 200V TO-220F
D9104 093G 52909 RECTIFIER SFF1006G 10A 400V ITO-220AB
D9104 093G 220 24 DIODE FMX-23S SANKEN
0M1G1730 8120 SCREW 3X8
705TXC93971 D9106 & D9305 ASSY
HS9103 090G6064 1 HEAT SINK
D9106 093G 60329 DIODE FMEN-220A 20A/100V TO-220
D9305 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF
0M1G1730 8120 SCREW 3X8
IC8201 056G 158501 IC AS431AN-E1 SOT23
IC9101 056G 379175 IC LD7523GS SOP-8
IC8101 056G 700 40 LED DRIVER LD7400GS SOP-8
Q9402 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q9401 057G 419912 T TRANSISTOR 2SD1624T-TD-E PCP
Q8302 057G 759 2A HF TANSISTOR 2N7002H SOT-23
Q8201 057G 760 4A DTA144WN3/S SOT-23
Q8202 057G 760 5A DTC 144WN3/S SOT-23
Q8301 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23
Q9601 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23
R8302 061G0805000 JI RST 0805 MAX0.05R 5% 1/8W TA-I
R9602 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R8303 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R9601 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R9124 061G08051001FT RST CHIP 1K 1/8W 1%
R8212 061G08051002FI RST 0805 10K 1% 1/8W
R9111 061G08051002FI RST 0805 10K 1% 1/8W
R9404 061G08051002FI RST 0805 10K 1% 1/8W
R9401 061G08051002FI RST 0805 10K 1% 1/8W
R8106 061G08051002FI RST 0805 10K 1% 1/8W
R9130 061G08051002FI RST 0805 10K 1% 1/8W
R9403 061G08051002FI RST 0805 10K 1% 1/8W
R8304 061G08051002FI RST 0805 10K 1% 1/8W
R8207 061G08051002FI RST 0805 10K 1% 1/8W
R8211 061G08051003FI RST 0805 100K 1% 1/8W
50
英华家电维修资料软件专用 购买QQ:505966338
R8210 061G08051003FI RST 0805 100K 1% 1/8W
R8209 061G08051003FI RST 0805 100K 1% 1/8W
R9107 061G08052001FT RST CHIP 2K 1/8W 1%
R9125 061G08052202FI RST 0805 22K 1% 1/8W
R9108 061G08052209FT RST 0805 22R 1% 1/8W
R9129 061G08052261FY RST 0805 2.26K 1% 1/8W RC0805FR-07 2K26L
R9127 061G08052402FI RST CHIPR 24 KOHM +-1% 1/8W
R8101 061G0805303 JI RST CHIPR 30 KOHM +-5% 1/8W
R8305 061G0805304 JI RST CHIPR 300K OHM +-5% 1/8W
R8102 061G0805304 JI RST CHIPR 300K OHM +-5% 1/8W
R9109 061G0805330 JF RST CHIPR 33 OHM +-5% 1/8W FENGHUA
R8105 061G0805330 JI RST CHIPR 33 OHM +-5% 1/8W 0805
R9317 061G08053301FI RST 0805 3.3K 1% 1/8W
R9316 061G08053301FI RST 0805 3.3K 1% 1/8W
R9126 061G08053301FT RST CHIP 3K3 1/8W 1%
R9311 061G0805475 JT RST CHIP 4.7M 5% 1/8W
R9318 061G08055601FI RST CHIPR 5.6 KOHM +-1% 1/8W 0805
R9128 061G08055602FI RST CHIPR 56 KOHM +-1% 1/8W 0805
R9319 061G08056201FT RST CHIPR 6.2KOHM +-1% 1/8W TZAI YUAN
R9309 061G08056203FT RST CHIP 620K 1/8W 1%
JR902 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR901 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR802 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR903 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR803 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR906 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
JR905 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
R9103 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
R8103 061G12061002FI RST 1206 10K 1% 1/4W
R9304 061G12061003FT RST CHIP 100K 1/4W 1%
R9302 061G12061003FT RST CHIP 100K 1/4W 1%
R9303 061G12061003FT RST CHIP 100K 1/4W 1%
R9305 061G12061003FT RST CHIP 100K 1/4W 1%
R9119 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9114 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9314 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9113 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9313 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9118 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9133 061G1206124 JT RST CHIP 120K 5% 1/4W
R9121 061G12061501FT RST 1206 1.5K 1% 1/4W
R9122 061G12061501FT RST 1206 1.5K 1% 1/4W
R9123 061G12061501FT RST 1206 1.5K 1% 1/4W
R9308 061G12061504FT RST CHIP 1M5 1/4W 1%
R9307 061G12061504FT RST CHIP 1M5 1/4W 1%
R9306 061G12061504FT RST CHIP 1M5 1/4W 1%
R8205 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R8202 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R8201 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R8203 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R8213 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R8204 061G12062009FI RST 1206 20R 1% 1/4W TA-I
R9106 061G1206203 JI RST 20K OHM 5% 1/4W TA-I
R9131 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN
51
英华家电维修资料软件专用 购买QQ:505966338
R9132 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN
R8306 061G1206304 JI RST 1206 300K 5% 1/4W
R8104 061G1206330 JI RST 1206 33R 5% 1/4W
R9402 061G12063300FT RST 1206 330R 1% 1/4W
R9110 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R8109 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R9315 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R9312 061G1206479 JT RST 1206 4.7R 5% 1/4W
R9902 061G12065103FT RST CHIPR 510 KOHM +-1% 1/4W TZAI YUAN
R8206 061G1206512 JI RST 5.1K OHM 5% 1/4W TA-I
R9901 061G1206514 JF RST CHIPR 510KOHM +-5% 1/4W FENGHUA
R9903 061G1206514 JF RST CHIPR 510KOHM +-5% 1/4W FENGHUA
R9115 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R9116 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R9117 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R8214 061G12067502FT RST CHIPR 75K 1/4W +/-1% TZAI YUAN
R8208 061G12067502FT RST CHIPR 75K 1/4W +/-1% TZAI YUAN
R8301 061G12068202FT RST CHIPR 82KOHM +-1% 1/4W TZAI YUAN
C8106 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C8301 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9105 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C9303 065G080510332K A CAP CHIP 0805 10NF K 50V X7R
C9106 065G080510332K F CAP 0805 10NF K 50V X7R
C9123 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C9117 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C9112 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C8104 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9311 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C8102 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9304 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9103 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9104 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9401 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9601 065G080510532K A CAP 0805 1UF 10% 50V X7R
C8302 065G080510532K M CAP 0805 1UF 10% 50V X7R
C9312 065G080522432K T CAP 0805 220NF K 50V X7R
C8105 065G080547131J A CAP 0805 470PF 5% 50V NP0
C9302 065G080547432K T CAP CHIP 0805 0.47UF K 50V X7R
C9118 065G080547432K T CAP CHIP 0805 0.47UF K 50V X7R
D9602 093G 64 42SEM SWITCHING BAV70 215MA 75V SOT-23
D8101 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
D9102 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
CN9901 006G 31500 EYELET
IC9103 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92
IC9303 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92
R9301 061G 30310852T SY RST FUSE 0.1R 5% 1W
R9101 061G152M10852T SY RST MOF 0R1 5% 2W
R8107 061G152M10852T SY RST MOF 0R1 5% 2W
R9310 061G152M12952T SY RST MOF 1R2 5% 2W
R9112 061G152M33852T SY RST MOF 0R33 5% 2W
R9102 061G152M82352T SY RST MOFR 82KOHM +-5% 2WS FUTABA
C9121 065G 1K1019ST CAP CER 100PF 10% 1KV R
C9114 065G 1K10293T CAP CER 1NF 10% 1KV R
C9301 065G 1K1029ST CAP CER 1NF 10% 1KV R
52
英华家电维修资料软件专用 购买QQ:505966338
C9101 065G 1K22293S CAP CER 2.2NF 10% 1KV R TAPING
C9307 065G 1K4719ST CAP CER 470PF 10% 1KV R
C9113 065G 1K4719ST CAP CER 470PF 10% 1KV R
C9108 065G 1K4719ST CAP CER 470PF 10% 1KV R
C9910 065G306K2212SR CAP Y1 220PF 10% 250V Y5P
C9906 065G306K47123R CAP Y1 470PF 10% 250V Y5P
C9912 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9903 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9902 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9402 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9305 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9102 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C8101 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9107 067G 5151018KT EC 100UF 20% 63V EV1J101MPN1012RSU
C9119 067G 5151018KT EC 100UF 20% 63V EV1J101MPN1012RSU
C9111 067G 5153316KT EC 330UF 20% 35V 10*12 5000 HR
C9122 067G 5153316KT EC 330UF 20% 35V 10*12 5000 HR
C8107 067G 5154709KT EC 47UF 20% 100V 10*12
C8109 067G 5154709KT EC 47UF 20% 100V 10*12
C8108 067G 5154709KT EC 47UF 20% 100V 10*12
C9308 067G204S3313KT CAP CS 330UF 20% 16V 10*7 2000 HR
C9306 067G215D1017KT EC CAP 100UF 50V 8*12MM
C9115 067G215H1024KT EC 1000UF 20% 25V 10*20
C9310 067G215P2714KT EC 270UF 20% 25V 10*9
C9309 067G215P4714KT EC 470UF 20% 25V 10*16
FB9906 071G 55 9 T BEAD 3.5*0.8*6.0MM 110R HF
FB9903 071G 55 9 T BEAD 3.5*0.8*6.0MM 110R HF
ZD9401 093G 3954752T ZENER MTZJ16B 16V 0.5W DO-35
ZD9101 093G 3954752T ZENER MTZJ16B 16V 0.5W DO-35
ZD9602 093G 3957752T GDZJ6.2B
ZD8301 093G 3995652T DIODE GDZJ30B DO-35
ZD9603 093G 3995652T DIODE GDZJ30B DO-35
ZD9301 093G 3995652T DIODE GDZJ30B DO-35
ZD9601 093G 3996052T DIODE GDZJ20B DO-35
D9601 093G 6451652T 1N4148
D9304 093G 6451652T 1N4148
ZD9401 093G 39G 8 ZENER GDZJ16B 16 0.5 DO-35
ZD9101 093G 39G 8 ZENER GDZJ16B 16 0.5 DO-35
D9303 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9101 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9301 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9302 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
J927 095G 90 23 JUMP WIRE - J804 095G 90 23 JUMP WIRE - J925 095G 90 23 JUMP WIRE - J920 095G 90 23 JUMP WIRE - J802 095G 90 23 JUMP WIRE - J805 095G 90 23 JUMP WIRE - J807 095G 90 23 JUMP WIRE - J917 095G 90 23 JUMP WIRE - J919 095G 90 23 JUMP WIRE - J801 095G 90 23 JUMP WIRE - J929 095G 90 23 JUMP WIRE - J910 095G 90 23 JUMP WIRE - -
53
英华家电维修资料软件专用 购买QQ:505966338
J803 095G 90 23 JUMP WIRE - J921 095G 90 23 JUMP WIRE - -
FB9908 095G 90 23 JUMP WIRE - -
J903 095G 90 23 JUMP WIRE - J905 095G 90 23 JUMP WIRE - J907 095G 90 23 JUMP WIRE - J912 095G 90 23 JUMP WIRE - -
FB9907 095G 90 23 JUMP WIRE - -
J928 095G 90 23 JUMP WIRE - J918 095G 90 23 JUMP WIRE - J913 095G 90 23 JUMP WIRE - J902 095G 90 23 JUMP WIRE - J922 095G 90 23 JUMP WIRE - J911 095G 90 23 JUMP WIRE - J923 095G 90 23 JUMP WIRE - J909 095G 90 23 JUMP WIRE - J926 095G 90 23 JUMP WIRE - J901 095G 90 23 JUMP WIRE - J930 095G 90 23 JUMP WIRE - -
J906 095G 90 23 JUMP WIRE - C9120 367G415X3317KT EC 330UF 20% 50V 12.5*12
C9116 367G415X6814KT EC 680UF 20% 25V 12.5*12
C9110 367G515C102GKT EC 1000UF 20% 35V 12.5*20 6000HRS
C9109 367G515C102GKT EC 1000UF 20% 35V 12.5*20 6000HRS
E715 715G5654P01001002M POWER BOARD PCB
E715 715G5654P01001002S POWER BOARD PCB
Q02G7060001001 BOLT
M00201 Q02G706100200100HX BOLT
M00201 Q02G706100200100XL BOLT
Q11G701027000L PCB-SUPPORT
Q12G6300 25 3 FOOT PAD
Q16G0001 10 12 EVA WASHER
Q16G0001 20 8 EVA
Q36T 600 30 12 NONWOVEN FABRIC
Q36T 600 37 26 GP NON-WOVEN FABRIC
Q44T3121510562 PU FOAM
Q45G 77511 PROTECT BAG
Q45G88010TV03500HW PROTECT BAG
Q45G99010TV03900WN PROTECT BAG
Q50G 4 10 TIE (Y1900221)
Q50G 500 TV005 CABLE TIE
Q52G1501150523 W INSULATING PLATE
Q52G18010TV08200ZA INSULATING SHEET
X15T841210100000Z1 BKT_STAND
X15T841310100000Z1 BKT_STAND
X15T8490101000GMBL BKT_IO
X15T8491101000GMBL BKT_BTM
X40G000261590A OTHER LABEL --ECO LABEL
X40G2012032X57 IO LABEL
X40G2012032X58 SIDE LABEL
X44GJA6661502A ARTWORK CARTON AOC LE32A0320/30
089G 17356C554 AUDIO CABLE 1800MM
089G204A15N JR AC POWER CORD 1500 FOR EUROPE
092GB1JX1A3EGC BATTERY 1.5V LR03 AAA£¨LR03£© ALKALI
54
英华家电维修资料软件专用 购买QQ:505966338
E398 098GRABD6NEACD REMOTE AOC 90-364100T4425
0M1G1740 16225 CR3 SCREW M1-MACHINE SCREW X16.0
E398 398GRABDFNEACC REMOTE AOC RL76E ENGLISH
Q41G780061532G SHEET-FLYER SA CENTER LIST
Q45G2010M0101A PE BAG FOR MANUAL
Q45T 76 28NV2 R PE BAG FOR BASE SCREW SZ02742
X41G32MV67312B MANUAL LE32A0320/LE39A0320 SA
X41G78DV61503C WARRANTY CARD SA ALL REGION
X41G78SV67314A QSG LE32A0320/LE39A0320 EPI SA
040G 58162435A MANUAL P/N LABEL
Q40G 581689 4B SN LABEL(58X35MM)
Q40G0001624 5A CARTON LABEL
X40G0001624 2A LABEL FOR SCREW PE BAG
X40G032061546A RATING LABEL --LE32A0320
P34T1202ADT01L01BG DECO_BEZEL
M04402 X44GJA662010FS CUSHION-TR
M03502-01 X35T8022001J1C01XD DECO_BEZEL
M04401 X44GJA661010FS CUSHION-TL
M04404 X44GJA664010FS CUSHION-BR
M04403 X44GJA663010SY CUSHION-BL
M04402 X44GJA662010SY CUSHION-TR
M04401 X44GJA661010SY CUSHION-TL
M04404 X44GJA664010SY CUSHION-BR
E39C21NSCQE6NNX
Location Part No. Description Remark
0M1G1730 6120 SCREW 3X6
ECNA1 395G801304LY44 HARNESS 4P-B&R+B&W 700/500
E750 LCM390J1L02AD1010X PANEL TPT390J1-HJ1L02 C1D XM TPV
X41G32MV67312B MANUAL LE32A0320/LE39A0320 SA
M04404 X44GTA074010FS CUSHION-BR
036T 600 18111 NONWOVEN FABRTC
052G 1185 1 BIG TAPE(Y1200141)
052G 1186 SMALL TAPE
052G 2191 A PAPER TAPE
ECN1 095G801313RY04 HARNESS 13P-13P 350MM
0M1G 940 6125 SCREW M1-MACHINE SCREW X6.0
0M1G1030 6 47 CR3 SCREW
0M1G1030 6 47 CR3 SCREW
0M1G1740 10225 CR3 SCRE W M1-MACHINE SCREW X10.0
0Q1G 130 6120 XL SCREW 3X6
0Q1G 930 8 47 CR3 SCREW
0Q1G 940 8 47 CR3 SCREW 4X8
0Q1G 940 10 47 CR3 SCREW 4X1 0
0Q1G1030 6120 SCREW 3X6
317GAAMB046TYA MAIN BOARD T.MS18VG.76B
E37801 378G0110567YAD 16 OHM 11W 132X34 0 NO
ECN8 395G801410DY25 HARNESS 10P-5P+4P 450/600 2nd Source
ECN8 395G801410RY25 HARNESS 10P-5P+4P 450/600
ECN21 395G801851DZ08 LVDS CABLE 51P-40P 350
ECN21 395G801851XZ08 LVDS CABLE 51P-40P 350 2nd Source
IRPFCXAD IR BOARD
55
英华家电维修资料软件专用 购买QQ:505966338
CN201 033G8032 5F B CONN 1.25MM 5P R/A 11.2MM 5.7MM
CN201 033G8032 5F X WAFER 5P 1.25MM S1315-05RVB-S03-K
R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO
R202 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
C201 065G060310432K F CAP CHIP 0603 0.1UF K 50V X7R
LED201 081G 14 24 EL CHIP LED BLUE/DARK RED
U201 356GS927072 IR RECEIVER IRM-H638M3/TR2 38 KHZ
709T54710XS001 COMSUPTIVE ASS'Y
E715 715G5471R02000004S IR BOARD PCB
E715 715G5471R02000004X IR BOARD PCB
KEPFCXAE KEY BOARD
CN01 033G8032 4F B CONN 1.25MM 4P R/A 9.95MM 5.7MM
CN01 033G8032 4F X WAFER 4P 1.25MM
R04 061G08051001FT RST CHIP 1K 1/8W 1%
R03 061G08051801FY RST CHIP R 1K8 +/-1% 1/8W
R02 061G08052701FY RST CHIP 2K7 1/8W 1%
R05 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R07 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R06 061G08057500FF RST CHIPR 750 OHM +-1% 1/8W FENGHUA
R01 061G08057501FY RST CHIP R 7K5 1/8W +/-1%
SW02 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW05 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW07 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW01 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW04 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW03 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW06 077G 607 2 FD CHIP TACT SW BY FORWARD SFKQGMA2125T-PL
SW01 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW06 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW07 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW05 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW02 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW03 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
SW04 077G 607 2 HC TACT SW 4P 1.5MM 160G TS-4402-1.58B-01
709T57110XS001 COMSUMPTIVE ASSY
Q05G6054 1 SHEET
Q09G6012 1 PIN
E715 715G5711K01000004S KEY BOARD PCB
E715 715G5711K01000004X KEY BOARD PCB 2nd Source
P12G6311010 RUBBER PAD SILICONE
P33T0408ADT01L0100 KEY
P34T1188ADT01L01BD DECO_BEZEL
P34T11890GMZ3K01BA REAR_COVER
P34T11900GM01K0100 COVER_STAND
P34T1191ADT01L0100 BASE
P34T1192ADT01L0100 STAND
PLTVCL801UXE7 ADAPTER BOARD
Z40G0002ALL01A SFIS LABEL 35MM*9MM
CN8901 033G380212B YH WAFER 12P 2.0 DIP
IC9102 056G 139 3B PC123Y82FZOF SHARP
IC9401 056G 139 3B PC123Y82FZOF SHARP
IC9302 056G 139 3B PC123Y82FZOF SHARP
IC9301 056G 379121 IC STR- A6069H DIP-8
56
英华家电维修资料软件专用 购买QQ:505966338
Q8203 057G 600948 MOSFET P0420ATF 4A 200V TO-220F
RV9901 061G 46621 P VARISTOR 620V 10% 16*7
NR9901 061G 58309MEW NTCR 3R 20% 3.6W SCK15037MMY502
C9901 063G107K474 EM CAP X2 470NF 10% 305V
C9904 063G107K474 EM CAP X2 470NF 10% 305V
FB9901 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9902 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9910 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
FB9911 071G 55 21 H1 BEAD 6.0*10 700R 25% BF-I60100R-706B
L9901 073G 174106 X LINE FILTER 13MH MIN 3LFT201110-133M
L9902 073G 174106 X LINE FILTER 13MH MIN 3LFT201110-133M
L9801 073G 174124 L PFC CHOKE 300UH 10% PT-009584 1 33
L9101 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9103 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9301 073G 253 91 V CHOKE COIL 3.5UH+-10%
L9102 073G 253 91 V CHOKE COIL 3.5UH+-10%
L8102 073G 253203 X CHOKE COIL 5UH 15% -T9301 080GL52P 54 H X'FMR 1000UH 10% 40UH EQ30 BCK-13026-HA
CN9901 087G 50147D HC AC SOKET R/A 2P 12DEGREE H=12.8
D9801 093G 52918 RECTIFIER 1N5408G-04 X0 3A 1000V DO2 01AD
D9107 093G 60334 SCHOTTKY SR506-44 5A 60V DO-201AD
CN9901 0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
CN9902 311GW250B13BBX WAFER 2.5MM 13P R/A 35MM 7MM
C9801 363G210J105GHN CAP MPP 1UF 5% 450V 18*9.1*12.5 --
C9810 367G315X151PKZ000S EC 150UF 20% 450V 18*45 3000 HR 1200MA -
L8101 373G0253249CP0 BOOST CHOKE 33UH 10% EQ25 0.5A L020692-6
T9101 380GL32P106N00 X'FMR 750UH 10% 18UH ER28 YUVA-2016-4
705TXC57330 Q9101 ASSY
Q9101 057G 667 21 MOSFET STP10NK70ZFP 8.6A 700V TO-220FP
0M1G1730 8120 SCREW 3X8
HS9101 Q90G0087 7 HEAT SINK ÆÄËÛ/OTHER
705TXC57331 Q8101 & D8103 ASSY
D8103 093G 60258 DIODE FME-220B TO-220 SANKEN
0M1G1730 8120 SCREW 3X8
Q8101 357G0600980 MOSFET AOTF454L 13A 150V 41W TO-220F
HS8101 Q90T0237 1 HEAT SINK
705TXC57883 Q9801/D9802 ASS'Y
Q9801 057G 667 50 TRA STP10NK60ZFP 10A/600V TO-220FP
D9802 093G 52905 DIODE FMNS-1106S TO-220
0M1G1730 8120 SCREW 3X8
HS9801 Q90G6241 1 GP HEAT SINK
705TXC84040 F9901 ASSY
EF9901 084G 34 10 FUSE CLIP
EF9901 084G 34 14 FUSE -- -- --
F9901 084G 41 3 C FUSE 3.15A 250V, TIME LAG FUSE
705TXC93969 BD9901 ASSY
HS9901 090G6064 1 HEAT SINK
BD9901 093G 50460925 BRIDGE TS6B06G-01 6A 800V KBJ
0M1G1730 8120 SCREW 3X8
705TXC93970 D9104 & D9105 ASSY
HS9102 090G6064 1 HEAT SINK
D9105 093G 52 57 RECTIFIER FMXA-2202S 20A 200V TO-220F
D9104 093G 52909 RECTIFIER SFF1006G 10A 400V ITO-220AB
D9104 093G 220 24 DIODE FMX-23S SANKEN
57
英华家电维修资料软件专用 购买QQ:505966338
0M1G1730 8120 SCREW 3X8
705TXC93971 D9106 & D9305 ASSY
HS9103 090G6064 1 HEAT SINK
D9106 093G 60329 DIODE FMEN-220A 20A/100V TO-220
D9305 093G 60987 SCHOTTKY FMEN-2308 30A 80V TO-22OF
0M1G1730 8120 SCREW 3X8
IC8201 056G 158501 IC AS431AN-E1 SOT23
IC9801 056G 379172 IC LD7591GS SOP-8
IC9101 056G 379175 IC LD7523GS SOP-8
IC8101 056G 700 40 LED DRIVER LD7400GS SOP-8
Q9402 057G 417 4 PMBS3904/PHILIPS-SMT(04)
Q9401 057G 419912 T TRANSISTOR 2SD1624T-TD-E PCP
Q8302 057G 759 2A HF TANSISTOR 2N7002H SOT-23
Q8201 057G 760 4A DTA144WN3/S SOT-23
Q8202 057G 760 5A DTC 144WN3/S SOT-23
Q9601 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23
Q8301 057G 769900 SMALLTRAN BCR1002N3 0.2A 50V SOT23
R8302 061G0805000 JI RST 0805 MAX0.05R 5% 1/8W TA-I
R9801 061G0805100 JF RST CHIPR 10 OHM +-5% 1/8W FENGHUA
R8303 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R9601 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R9602 061G08051001FI RST CHIPR 1KOHM +-1% 1/8W TA-I
R9124 061G08051001FT RST CHIP 1K 1/8W 1%
R8106 061G08051002FI RST 0805 10K 1% 1/8W
R8212 061G08051002FI RST 0805 10K 1% 1/8W
R9401 061G08051002FI RST 0805 10K 1% 1/8W
R9403 061G08051002FI RST 0805 10K 1% 1/8W
R9111 061G08051002FI RST 0805 10K 1% 1/8W
R8304 061G08051002FI RST 0805 10K 1% 1/8W
R9130 061G08051002FI RST 0805 10K 1% 1/8W
R9404 061G08051002FI RST 0805 10K 1% 1/8W
R8207 061G08051002FI RST 0805 10K 1% 1/8W
R9808 061G08051002FI RST 0805 10K 1% 1/8W
R9803 061G08051002FI RST 0805 10K 1% 1/8W
R8210 061G08051003FI RST 0805 100K 1% 1/8W
R8211 061G08051003FI RST 0805 100K 1% 1/8W
R8209 061G08051003FI RST 0805 100K 1% 1/8W
R9812 061G08051302FI RST CHIPR 13KOHM +-1% 1/8W TA-I
R9107 061G08052001FT RST CHIP 2K 1/8W 1%
R9125 061G08052202FI RST 0805 22K 1% 1/8W
R9108 061G08052209FT RST 0805 22R 1% 1/8W
R9129 061G08052261FY RST 0805 2.26K 1% 1/8W RC0805FR-07 2K26L
R9127 061G08052402FI RST CHIPR 24 KOHM +-1% 1/8W
R8101 061G0805303 JI RST CHIPR 30 KOHM +-5% 1/8W
R8102 061G0805304 JI RST CHIPR 300K OHM +-5% 1/8W
R8305 061G0805304 JI RST CHIPR 300K OHM +-5% 1/8W
R9109 061G0805330 JF RST CHIPR 33 OHM +-5% 1/8W FENGHUA
R8105 061G0805330 JI RST CHIPR 33 OHM +-5% 1/8W 0805
R9802 061G0805330 JT RST CHIP 33R 1/8W 5% TZAI YUAN
R9317 061G08053301FI RST 0805 3.3K 1% 1/8W
R9316 061G08053301FI RST 0805 3.3K 1% 1/8W
R9126 061G08053301FT RST CHIP 3K3 1/8W 1%
R9806 061G0805332 JI RST CHIPR 3.3KOHM +-5% 1/8W 0805
R9807 061G0805333 JI RST CHIPR 33KOHM +-5% 1/8W 0805
58
英华家电维修资料软件专用 购买QQ:505966338
R9311 061G0805475 JT RST CHIP 4.7M 5% 1/8W
R9318 061G08055601FI RST CHIPR 5.6 KOHM +-1% 1/8W 0805
R9128 061G08055602FI RST CHIPR 56 KOHM +-1% 1/8W 0805
R9319 061G08056201FT RST CHIPR 6.2KOHM +-1% 1/8W TZAI YUAN
R9309 061G08056203FT RST CHIP 620K 1/8W 1%
JR901 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR902 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR802 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR803 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
JR903 061G1206000 JI RST 1206 MAX0R05 5% 1/4W
R9103 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
JR905 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
JR906 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN
R8103 061G12061002FI RST 1206 10K 1% 1/4W
R9304 061G12061003FT RST CHIP 100K 1/4W 1%
R9303 061G12061003FT RST CHIP 100K 1/4W 1%
R9302 061G12061003FT RST CHIP 100K 1/4W 1%
R9305 061G12061003FT RST CHIP 100K 1/4W 1%
R9313 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9314 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9119 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9113 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9114 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R9118 061G1206101 JT RST CHIPR 100 OHM +-5% 1/4W TZAI YUAN
R8301 061G1206124 JT RST CHIP 120K 5% 1/4W
R9133 061G1206124 JT RST CHIP 120K 5% 1/4W
R9121 061G12061501FT RST 1206 1.5K 1% 1/4W
R9123 061G12061501FT RST 1206 1.5K 1% 1/4W
R9122 061G12061501FT RST 1206 1.5K 1% 1/4W
R9307 061G12061504FT RST CHIP 1M5 1/4W 1%
R9308 061G12061504FT RST CHIP 1M5 1/4W 1%
R9306 061G12061504FT RST CHIP 1M5 1/4W 1%
R9813 061G1206203 JI RST 20K OHM 5% 1/4W TA-I
R9106 061G1206203 JI RST 20K OHM 5% 1/4W TA-I
R9132 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN
R9131 061G1206221 JT RST CHIPR 220 OHM +-5% 1/4W TZAI YUAN
R8306 061G1206304 JI RST 1206 300K 5% 1/4W
R8104 061G1206330 JI RST 1206 33R 5% 1/4W
R9402 061G12063300FT RST 1206 330R 1% 1/4W
R9805 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R9110 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R8109 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R9315 061G12064700FI RST 1206 470R 1% 1/4W TA-I
R9312 061G1206479 JT RST 1206 4.7R 5% 1/4W
R9902 061G12065103FT RST CHIPR 510 KOHM +-1% 1/4W TZAI YUAN
R8206 061G1206512 JI RST 5.1K OHM 5% 1/4W TA-I
R9903 061G1206514 JF RST CHIPR 510KOHM +-5% 1/4W FENGHUA
R9901 061G1206514 JF RST CHIPR 510KOHM +-5% 1/4W FENGHUA
R9117 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R9115 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R9116 061G1206562 JT RST 1206 5.6K 5% 1/4W TZAI YUAN
R9809 061G12066803FF E RST 1206 680K 1% 1/4W
R9810 061G12066803FF E RST 1206 680K 1% 1/4W
R9811 061G12066803FF E RST 1206 680K 1% 1/4W
59
英华家电维修资料软件专用 购买QQ:505966338
R8201 061G12066808FT RST 1206 6.8R 1% 1/4W
R8202 061G12066808FT RST 1206 6.8R 1% 1/4W
R8213 061G12066808FT RST 1206 6.8R 1% 1/4W
R8205 061G12066808FT RST 1206 6.8R 1% 1/4W
R8204 061G12066808FT RST 1206 6.8R 1% 1/4W
R8203 061G12066808FT RST 1206 6.8R 1% 1/4W
R8208 061G12067503FI RST 1206 750K 1% 1/4W
R8214 061G12068202FT RST CHIPR 82KOHM +-1% 1/4W TZAI YUAN
C9809 065G080510131J F CAP CHIP 0805 100PF J 50V NPO
C9808 065G080510231J F CAP 0805 1NF 5% 50V NPO
C8106 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C8301 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9105 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C9303 065G080510332K A CAP CHIP 0805 10NF K 50V X7R
C9106 065G080510332K F CAP 0805 10NF K 50V X7R
C9807 065G080510432K A CAP CHIP 0805 0.1UF K 50V X7R
C9117 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C9112 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C9123 065G080510432K F CAP CHIP 0805 0.1UF K 50V X7R
C8102 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9304 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9401 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9311 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9103 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9805 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9104 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C8104 065G080510432K T 0.1UF K 50V X7R TAIYO YUDEN
C9601 065G080510532K A CAP 0805 1UF 10% 50V X7R
C8302 065G080510532K M CAP 0805 1UF 10% 50V X7R
C9806 065G080522432K A CAP 0805 220NF 10% 50V X7R
C9312 065G080522432K T CAP 0805 220NF K 50V X7R
C9803 065G080547031J F CAP CHIP 0805 47PF J 50V NPO
C8105 065G080547131J A CAP 0805 470PF 5% 50V NP0
C9118 065G080547432K T CAP CHIP 0805 0.47UF K 50V X7R
C9302 065G080547432K T CAP CHIP 0805 0.47UF K 50V X7R
D9602 093G 64 42SEM SWITCHING BAV70 215MA 75V SOT-23
D9102 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
D9803 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
D8101 393G060S93400T00HF HF SS0520_R1_00001 0.5A 20V SOD-123
CN9901 006G 31500 EYELET
IC9303 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92
IC9103 056G 158 10 T DC/DC AS431AZTR-E1 150MA 40V TO-92
R9301 061G 30310852T SY RST FUSE 0.1R 5% 1W
R8107 061G152M10852T SY RST MOF 0R1 5% 2W
R9101 061G152M10852T SY RST MOF 0R1 5% 2W
R9310 061G152M12952T SY RST MOF 1R2 5% 2W
R9804 061G152M15852T SY RST MOFR 0.15R 5% 2WS FUTABA
R9112 061G152M33852T SY RST MOF 0R33 5% 2W
R9102 061G152M82352T SY RST MOFR 82KOHM +-5% 2WS FUTABA
C9121 065G 1K1019ST CAP CER 100PF 10% 1KV R
C9114 065G 1K10293T CAP CER 1NF 10% 1KV R
C9301 065G 1K1029ST CAP CER 1NF 10% 1KV R
C9101 065G 1K22293S CAP CER 2.2NF 10% 1KV R TAPING
C9307 065G 1K4719ST CAP CER 470PF 10% 1KV R
60
英华家电维修资料软件专用 购买QQ:505966338
C9113 065G 1K4719ST CAP CER 470PF 10% 1KV R
C9108 065G 1K4719ST CAP CER 470PF 10% 1KV R
C9910 065G306K2212SR CAP Y1 220PF 10% 250V Y5P
C9906 065G306K47123R CAP Y1 470PF 10% 250V Y5P
C9903 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9902 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9912 065G306K4712SR CAP Y1 470PF 10% 250V Y5P
C9804 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C8101 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9402 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9305 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9102 067G 3151007KB A EC 10UF 20% 50V 6.3*7 3000 HR
C9122 067G 5153316KT EC 330UF 20% 35V 10*12 5000 HR
C9111 067G 5153316KT EC 330UF 20% 35V 10*12 5000 HR
C8109 067G 5154709KT EC 47UF 20% 100V 10*12
C8108 067G 5154709KT EC 47UF 20% 100V 10*12
C8107 067G 5154709KT EC 47UF 20% 100V 10*12
C9308 067G204S3313KT CAP CS 330UF 20% 16V 10*7 2000 HR
C9306 067G215D1017KT EC CAP 100UF 50V 8*12MM
C9115 067G215H1024KT EC 1000UF 20% 25V 10*20
C9310 067G215P2714KT EC 270UF 20% 25V 10*9
C9309 067G215P4714KT EC 470UF 20% 25V 10*16
FB9903 071G 55 9 T BEAD 3.5*0.8*6.0MM 110R HF
FB9906 071G 55 9 T BEAD 3.5*0.8*6.0MM 110R HF
ZD9101 093G 3954752T ZENER MTZJ16B 16V 0.5W DO-35
ZD9401 093G 3954752T ZENER MTZJ16B 16V 0.5W DO-35
ZD9602 093G 3957752T GDZJ6.2B
ZD8301 093G 3995652T DIODE GDZJ30B DO-35
ZD9301 093G 3995652T DIODE GDZJ30B DO-35
ZD9603 093G 3995652T DIODE GDZJ30B DO-35
ZD9601 093G 3996052T DIODE GDZJ20B DO-35
D9304 093G 6451652T 1N4148
D9601 093G 6451652T 1N4148
ZD9101 093G 39G 8 ZENER GDZJ16B 16 0.5 DO-35
ZD9401 093G 39G 8 ZENER GDZJ16B 16 0.5 DO-35
D9303 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9101 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9301 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
D9302 093G110050152T DIODE PR1007 1A/1000V 500NS DO-41
J929 095G 90 23 JUMP WIRE - J918 095G 90 23 JUMP WIRE - J906 095G 90 23 JUMP WIRE - J919 095G 90 23 JUMP WIRE - J928 095G 90 23 JUMP WIRE - J911 095G 90 23 JUMP WIRE - J921 095G 90 23 JUMP WIRE - J807 095G 90 23 JUMP WIRE - J925 095G 90 23 JUMP WIRE - J804 095G 90 23 JUMP WIRE - J922 095G 90 23 JUMP WIRE - J924 095G 90 23 JUMP WIRE - J913 095G 90 23 JUMP WIRE - J902 095G 90 23 JUMP WIRE - J801 095G 90 23 JUMP WIRE - -
61
英华家电维修资料软件专用 购买QQ:505966338
J805 095G 90 23 JUMP WIRE - J910 095G 90 23 JUMP WIRE - J802 095G 90 23 JUMP WIRE - J901 095G 90 23 JUMP WIRE - J920 095G 90 23 JUMP WIRE - J930 095G 90 23 JUMP WIRE - J909 095G 90 23 JUMP WIRE - -
FB9908 095G 90 23 JUMP WIRE - -
J926 095G 90 23 JUMP WIRE - J917 095G 90 23 JUMP WIRE - J803 095G 90 23 JUMP WIRE - J923 095G 90 23 JUMP WIRE - J903 095G 90 23 JUMP WIRE - J905 095G 90 23 JUMP WIRE - J907 095G 90 23 JUMP WIRE - J912 095G 90 23 JUMP WIRE - -
FB9907 095G 90 23 JUMP WIRE - -
C9119 367G415X3317KT EC 330UF 20% 50V 12.5*12
C9120 367G415X3317KT EC 330UF 20% 50V 12.5*12
C9107 367G415X3317KT EC 330UF 20% 50V 12.5*12
C9116 367G415X6814KT EC 680UF 20% 25V 12.5*12
C9109 367G515C102GKT EC 1000UF 20% 35V 12.5*20 6000HRS
C9110 367G515C102GKT EC 1000UF 20% 35V 12.5*20 6000HRS
E715 715G5654P01001002M POWER BOARD PCB 2nd Source
E715 715G5654P01001002S POWER BOARD PCB
Q02G7060001001 BOLT
M00201 Q02G706100200100HX BOLT
M00201 Q02G706100200100XL BOLT
Q12G6300 25 3 FOOT PAD
Q36T 600 49 7 NON-WOVEN FABRIC
Q45G 77511 PROTECT BAG
M04502 Q45G88010TV03500HW PROTECT BAG
M04502 Q45G88010TV03500X1 PROTECT BAG
M04501 Q45G99010TV04100HW PROTECT BAG
M04501 Q45G99010TV04100WN PROTECT BAG
Q50G 4 10 TIE (Y1900221)
Q50G 500 TV005 CABLE TIE
Q52G1501150523 W INSULATING PLATE
Q52G18010TV08200ZA INSULATING SHEET
X15T841710100000Z1 BKT_STAND
X15T841810100000Z1 BKT_HINGE
X15T841910200000AJ BKT_BASE
X15T8490101000GMBL BKT_IO
X15T8491101000GMBL BKT_BTM
M03502 X35T8023001B1C01MX DECO_BEZEL
M03502 X35T8023001B1C01XD DECO_BEZEL
X40G000261591A OTHER LABEL --ECO LABEL
X40G2012032X5700ZA IO LABEL
X40G2012039X0500ZA SIDE LABEL
X44GTA0761502A ARTWORK CARTON EPI LE39A0320
089G 17356C554 AUDIO CABLE 1800MM
089G202A15N IS AC POWER CORD 1500MM
092GB1JX1A3EGC BATTERY 1.5V LR03 AAA£¨LR03£© ALKALI
E398 098GRABD6NEACD REMOTE AOC 90-364100T4425
62
英华家电维修资料软件专用 购买QQ:505966338
0M1G1740 10225 CR3 SCRE W M1-MACHINE SCREW X10.0
E398 398GRABDFNEACC REMOTE AOC RL76E ENGLISH
Q41G780061532G SHEET-FLYER SA CENTER LIST
Q45G2010M0101A PE BAG FOR MANUAL
Q45T 76 28NV2 R PE BAG FOR BASE SCREW SZ02742
X41G78DV61503C WARRANTY CARD SA ALL REGION
X41G78SV67314A QSG LE32A0320/LE39A0320 EPI SA
040G 58162435A MANUAL P/N LABEL
Q40G 581689 4B SN LABEL(58X35MM)
X40G0001624 2A LABEL FOR SCREW PE BAG
X40G039061504A RATING LAB E L --LE39A0320
E750 LCM390J1L01AD1010X TPT390-J1L01 C1E XM TPV
Q16G0001 20 38 EVA
M04401 X44GTA071010FS CUSHION-TL
0M1G1730 8120 SCREW 3X8
M04403 X44GTA073010FS CUSHION-BL
M04402 X44GTA072010FS CUSHION-TR
M04401 X44GTA071010SY CUSHION-TL
M04402 X44GTA072010SY CUSHION-TR
M04403 X44GTA073010SY CUSHION-BL
M04404 X44GTA074010SY CUSHION-BR
63
Loading...
