AOC LC32K06M, LC42K06M, LC46K06M Schematic

维 修 手 册

客户

机种名

销售地区

AOC LC32K06M
AOC LC42K06M
AOC LC46K06M

中国大陆

中国大陆

中国大陆

E32A22QNDWGA7NNS

1

首次发布日期：

2010/4

目录

1. 技术规格 -------------------------------------------------------------------------------------------------------------- 03

2. 操作说明 -------------------------------------------------------------------------------------------------------------- 05

3. 工厂模式调整 -------------------------------------------------------------------------------------------------------- 20

4. 故障处理流程 -------------------------------------------------------------------------------------------------------- 22

5. 线路图 ----------------------------------------------------------------------------------------------------------------- 27

6. 电气方框图 ----------------------------------------------------------------------------------------------------------- 48

7. BOM -------------------------------------------------------------------------------------------------------------------- 49

2

1. 技术规格

3

预设显示模式

电脑输入信号参照表

将电脑连接到电视后，按照下表，设置电脑中的输出信号

电脑 HDMI 输入信号参照表

1.使用DVI端口时：将视频设备的DVI 端口使用DVI转HDMI线连接到电视后，按照下表，设置视频设备的输出信号。

2.使用电脑 HDMI 端口时：将电脑的 HDMI 端口使用 HDMI 线连接到电视后，按照下表，设置电脑的输出信号。

视频输入信号参照表

1. 将视频设备的分量或HDMI端口连接到电视后，按照下表，设置视频设备的输出信号。

2. 如果电脑显卡可支持视频格式信号，可设置下表输出信号。

4

2. 操作说明

遥控器操作

5

侧面控件和指示灯

6

背板信源接口和侧面插口

7

8

打开和关闭电视

9

语言设置

10

切换输入源

11

频道切换／回看

12

图像设置

13

声音设置

14

功能设置

15

设定设置

16

电脑设置

17

功能设置

18

多媒体功能（USB）

19

3. 工厂模式调整

进行白平衡调整之前，大约需要有 1 小时的时间来对机器进行预热。
进行白平衡调整之前，请先对彩色分析仪 Ca210 进行设置。
Channel 5/6 为大陆向机种使用通道。

Color T emp x y

Normal 0.289 0.010 0.291 0.010

Warm 0.314 0.010 0.319 0.010

Cool 0.278 0.010 0.278 0.010

表 1 白平衡调整 Source 及色温标准

此 AOC 系列机种做 Auto Color,调整白平衡的 R,G,B 参数，整个 Auto Color 的操作过程如下：

1.

先按 MENU 健，出现 User OSD 菜单，再依次按数字键 1 9 9  9，进入工厂模式。

2.用遥控选择“Source”来选择不同 Source 色温调整（COMP/AV/HDMI 等），次机种需要在电脑和分量信
号模式下做 Auto Color,如图 1；

图 1 分量信号

PS:1.若做完 Auto Color 动作后，PQ和色温没达到工程规格，就调整白平衡 R,G,B 参数。选择好要调整的
Source，选择工厂菜单的“Gain”选择调整相应 Source 的色温选项,如图 2 所示：

R、G、B R, G, B 增益调整；

20

图 2 为分量信号调整菜单(gain)

所有 Source 调整 WARM，COOL，NORMAL，其中 VGA timing 为 137，AV timing 为 303 ，YPbPr timing

为 311, HDMI timing 为 353。

在所有色温调整之前，请先做 VGA(timing137,pat42)和 YPbPr(timing311,pat185) 的 Auto Color。如图 1,
图 2 所示。 备注：YPbPr 需要接三根红，绿，蓝线.

21

4. 故障处理流程

4.1 无电（LED 灯不亮）

无电

检测 AC 输入以及是否开电

源

No

电源已开

Yes

检测电源板输出电压是否为

五伏

No

更换电源板

Yes

检测 IR 和 LED 板

更换 IR 板

No

更换主板

22

4.2 无法启动（LED 红灯）

无法启动（LED红灯）

检测电源板输出电压是否为五伏

No

更换电源板

Yes

检测电源按钮是否正常工作

No

更换按钮板

Yes

检测 IR 接收器是否正常工作

No

更换IR板

更换主板

Yes

更换电源板

No

23

4.3 无显示（LED 绿灯）

Yes

无显示（LED 绿灯）

用遥控器或者电源按钮检测是否能开机器?

Yes

检测背后照明是否开着

No

更换主板

No

检测LVDS线

Yes

No

重新安装或者替换LVDS线

检测B/L signal信号

是否正常工作

Yes

No

更换主板

Panel Vcc是否为12V

No

Yes

更换主板

检测电源板输出电压是否为 24V

Yes

更换电源板

No

更换Panel

更换Panel

24

4.4 无声

无声或者声音不正常

检测信号源连接是否正常？

No

重接信号源

Yes

检测电视是否处于静音状态

No

检测喇叭和主板的接线是否正常

那个

Yes

检测喇叭阻抗是否在规格值内

更换接线

No

No

Yes

更换喇叭

更换电源板

25

4.5 遥控器故障

遥控器故障

检测遥控器电池是否有电

替换遥控器

检测IR板是否正常工作

Yes

更换电池

No

Yes

更换遥控器

No

Yes

更换IR板

更换主板

No

26

5. 线路图

5.1 主板 715G3837

D1101

+5V

BAT54C

1

3

C1102

100N 16V

VCC
SCL

WP

8
7
6
5

C1106

33P (NC)

R1102

10K(NC)

R1109

0 OHM(NC)

R1112

0 OHM(NC)

U1101

1

A0

2

A1

3

A2
VSS4SDA

M24C02-WMN6TP

R1110

0 OHM +-5% 1/16W

VGA_SDA 12
ISP1_SDA 11
ISP1_SCL 11
VGA_SCL 12

R1113

0 OHM +-5% 1/16W

VGA5V

2

10KOHM +-5% 1/16W

R1103

C1107

33P (NC)

ZD1101

R1104

10KOHM +-5% 1/16W

R1106

R1107

10R 1/ 16W 5%

10R 1/ 16W 5%

DDCSDA

HS

VS

DDCSCL

ZD1103

1 3

1 3

BZX84-C5V6(NC)

BZX84-C5V6(NC)

R1101

10KOHM +-5% 1/16W

DDCWP_PC 9

R1108

22KOHM +-5% 1/16W

CN1101
DB15

1716

11
12
13
14
15

1
6
2
7
3
8
4
9
5
10

VGA_5V

1 2

FB1101

120R/3000mA

CN4404

CONN(NC)

R1133 0 OHM +-5% 1/16W (N C)

R1134 0 OHM +-5% 1/16W (N C)

1
2
3

R1136 0 OHM +-5% 1/16W (N C )

R1128 0 OHM +-5% 1/16W (N C )

R
G

B

VGA5V

ZD1102

C1101

100N 16V

1 3

BZX84-C5V6(NC)

R1116

75R 1/16W 1%

R1117

75R 1/16W 1%

ISP1_SCL 11
ISP1_SDA 11

TX1 16
RX1 16

FB1102 30R/700mA

1 2

FB1103 30R/700mA

1 2

FB1104 30R/700mA

1 2

C1112

5PF 50V

C1113

5PF 50V

R1118

75R 1/16W 1%

+3V3_STBY

R G

R1105

10K(NC)

+3V3_ESD

3

1 2

CLOSE TO IC

R111168R 1/16W 5%
R111468R 1/16W 5%
R111568R 1/16W 5%

C1114

5PF 50V

R1119

100 OHM +-5% 1/16W

D1102

BAV99(NC)

C1108 10N 16V
C1109 10N 16V
C1110 10N 16V
C1111 4700P 50V

C1115 10N 16V

C1103

100N(NC)

D1103

3

BAV99(NC)

1 2

PC_R_I N 12
PC_G_IN 12

PC_B_IN 12
PC_SOG 12

PC_GND 12

C1104

100N(NC)

B

D1104

3

1 2

BAV99(NC)

C1105

100N(NC)

ZD1104

R1122

1 3

BZX84-C5V6(NC)

2.2KOHM +-5% 1/16W

R1120 100 OHM +-5% 1/16W
R1121 100 OHM +-5% 1/16W

R1123

2.2KOHM +-5% 1/ 16 W

ZD1105

1 3

BZX84-C5V6(NC)

PC_HSY NC 11,12
PC_VSYNC 11,12

FOR AIO VGA IN

CN1703

1
2
3
4
5
6
7
8
9
10
11
12

CONN(NC)

27

FOR AIO OR IPTV BOARD AUDIO IN

R
G
B

VGA_5V

HS
VS

DDCSCL

DDCSDA

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

CN1104

CONN(NC)

絬隔瓜絪腹

>

<
04: D-SUB I N PU T

1
2
3

FB1108

600R/200mA(NC)

1 2

1 2

OEM MOD EL
TPV MO D EL
PCB NAME

Sheet

R1132 10KOHM +-5% 1/16W(NC)

R1130

C1121

330P 50V(NC)

FB1107

600R/200mA(NC)

330P 50V(NC)

<Title> B
<Doc >

419Monday, Januar y 11, 2010

of

12K 1/16W 5%(NC)

R1129 10KOHM +-5% 1/16W(NC)

R1131

C1120

12K 1/16W 5%(NC)

2K10 ATV MT8222 DDR2

AIO_AUL_IN 15

C1122

330P 50V(NC)

AIO_AUR_IN 15

C1123

330P 50V(NC)

Size
Rev

称爹

称爹

>

<

FB1201 30R/700mA1 2

CLOSE TO IC

R120168R 1/16W 5%

C1201 10N 16V

COMP1_Y_IN 12

CN1203

23
1

56
4

89
7

JACK

FOR IPTV BOARD YPbPr

R1205

75R 1/16W 1%

R1206

75R 1/ 16W 1%

FB1202 30R/700mA1 2

FB1203 30R/700mA1 2

15P 50V

R1207

75R 1/16W 1%

FB1204

1 2

600R/200mA

FB1205

1 2

600R/200mA

C1205

15P 50V

C1206

R1223

75R 1/ 16W 1%

C1212

330P 50V

15P 50V

C1207

FB1211

1 2

120R/500mA

R1209

10KOHM +-5% 1/16W

C1210

330P 50V

10KOHM +-5% 1/16W

12K 1/16W 5%

R1211

12K 1/16W 5%

R1210

R1212

100R

R1232

C1234

47pF 50V

R120368R 1/ 16W 5%

R1231 0 OHM +-5% 1/16W

C1211

330P 50V

C1213

330P 50V

C1202 10N 16V

C1203 10N 16V

C1232 4700pF 50V

C1204 10N 16V

C123347N

COMP1_PB_IN 12

COMP1_PR_IN 12

SOY1/FB1 12

COMP1_GND 12

CVBS1_IN 12

COMP1/CVBS1_AUL_IN 15

COMP1/CVBS1_AUR_IN 15

R120268R 1/16W 5%

R1208 100 OHM +-5% 1/16W

CN1204

6
5
4
3
2
1

CONN(NC)

R1215

75R 1/16W 1%(NC)

FB1206 30R/700mA(NC)1 2

FB1207 30R/700mA(NC)1 2

R1219

75R 1/16W 1%(N C )

15P 50V(NC )

R1221

75R 1/16W 1%(N C )

C1208

15P 50V(NC)

C1214

15P 50V(NC)

C1215

100 OHM +-5% 1/16W(NC )

28

CLOSE TO IC

R120468R 1/16W 5%(NC)

T P V ( Top Victory Elec t ronic s C o . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

C1209 10N 16V(NC )
C1216 10N 16V(NC )

R122468R 1/16W 5%(NC)

C1217 10N 16V(N C )

R122568R 1/16W 5%(NC)FB1208 30R/700mA(NC)1 2

R12330 OHM +-5% 1/16W(N C )

C1235 4700pF 50V(NC )

R1222

C1220 10N 16V(N C )

05:YPbPr / CVBS INPUT

COMP2_Y_IN 12
COMP2_PB_IN 12

COMP2_PR_IN 12

COMP2_SOG 12

COMP2_GND 12

OEM MODEL
TPV MO DEL
PCB NAME

Sheet

B

2K10 ATV MT8222 DDR2

519Monday, J anuary 11, 2010

of

Size
Rev

称爹

<

称爹

>

CN1405

JACK

CN1406

CONN(NC)

1
2
3
4

4
2
6

2
1
4
3
6
5

CN1404

DIN JACK

4

12

11

8

SVY1_IN

3
1
5

SVC1_IN

SIDE_CVBS_INPUT 7
SIDE_CVBS_AUL_INPUT 7
SIDE_CVBS_AUR_INPUT 7

R1420 0 OHM +-5% 1/16W (N C )
R1421 0 OHM +-5% 1/16W (N C )

123

1234

5678

657

CN1402

1234

6 5

CONNENTOR

USB1_5V

CN1403

10

CONNNECTOR(NC)

9

1
2

R1404 0 OHM +-5% 1/16W

0 OHM +-5% 1/16W

3
4

1 2

1 2

USB_5V

R1417

FB1401

1 2

120R/500mA

R1401

75R 1/16W 1%

FB1403

1 2

120R/500mA

R1406

75R 1/16W 1%

R1408

75R 1/16W 1%

FB1405

600R/200mA

FB1406

600R/200mA

1

2

U1402

RClamp0520B.TCT(NC)

3

2

U1401

RClamp0520B.TCT(NC)

3

100 OHM +-5% 1/16W

C1401

47pF 50V

100 OHM +-5% 1/16W

C1402

47pF 50V

FB1404

1 2

120R/500mA

R1409 10KOHM +-5% 1/16W

C1415

330P 50V

R1414 10KOHM +-5% 1/16W

C1416

330P 50V

USB1_DP 12
USB1_DN 12

C1412

100N 16V(NC )

C1405

100N 16V

USB_DN 12
USB_DP 12

1

R1402

R1410

12K 1/16W 5%

12K 1/16W 5%

C1404

R1405

C1407

100 OHM +-5% 1/16W

C1403

47pF 50V

R1416

120R/3000mA(NC)

+

C1410

100uF 10V(NC )

120R/3000mA

+

C1406

100uF 10V

Close to IC

47N 16V

SIDE_SVY_IN 12

47N 16V

SIDE_SVC_IN 12

Close to IC

C1408 47N 16VR1407

C1414

330P 50V

C1417

330P 50V

FB1410

12

C1411

22U 10V(NC )

FB1402

12

C1409

22U 10V(NC )

SIDE_CVBS_IN 12

SIDE_CVBS_AUL_IN 15

SIDE_CVBS_AUR_IN 15

USB1_OC 12

t

t

+5V_ON

12

TH1402

8V 0R4(NC)

USB_OC 12

+5V_ON

12

TH1401

8V 0R4

HP_ROUT17

EARP_DET12

HP_LOUT17

1KOHM +-5% 1/16W(N C )

C1238

47nF 16V

CN1102

PHONEJACK

SPDIF_OUT12

T P V ( Top Victory Electronics Co . , Ltd. )

<

絬 隔 瓜 絪 腹

Key Component

絬隔瓜絪腹

06: SIDE I/O

Date

R1418

C1413

47nF 16V

1
2

3

1Kohm 1/16W +/ -1%(N C )

R1216

910 OHM +-5% 1/10W(N C )

1Kohm 1/16W +/ -1%(N C )

>

FB1407 600R/200mA

FB1409 600R/200mA

FB1408 600R/200mA

R1419

1KOHM +-5% 1/16W(N C )

FB1105

600R/200mA

1 2

FB1106

600R/200mA

1 2

R1213

C1223

100N 16V(NC )

R1217

OEM MODEL
TPV MODEL
PCB NAME

Sheet

HPROUT

12

EARPDET

12

HPLOUT

12

R1124 10KOHM +-5% 1/16W

R1125

C1116

330P 50V

12K 1/16W 5%

R1126 10KO H M +-5% 1/16W

R1127
C1118

330P 50V

12K 1/16W 5%

5
4
3
2
7
8
1

CN6404

2SJ1508-001111

C1117

330P 50V

C1119

330P 50V

PC_AUL_IN 15

PC_AUR_IN 15

SPDIF OUT FOR AOC AP MODEL

+5V_ON

R1214

10R 1/16W 5%(NC)

Q1201

BC847C(NC)

C1218 100N 16V(N C )

R1220

180 OHM +-5% 1/10W(N C )

<Title> B
<Doc>

619Monday, J anuary 11, 2010

R1218

75R 1/16W 1%(NC)

2K10 ATV MT8222 DDR2

of

SPDIF_OUTPUT 7

C1219

33P 50V(NC)

Size
Rev

称爹

<

称爹

>

29

AL312

AR312

+5V_ON

0R05 1/10W (N C )

C1506

100N 16V(NC )

1U 6V3(NC )

1U 6V3(NC )

CVBS_OUT12

OP_5V

R1501

POP_MUTE17,18

C6218

10KOHM +-5% 1/16W(NC )

C6219

10KOHM +-5% 1/16W(NC )

+5V_TUNER

C1503

47uF 25V

+

+

C1507

470UF 10V(N C )

R6220 10R 1/16W 5 %(N C )

R6223

C6222

1N8 50V(NC )

R6224

C6223

1N8 50V(NC )

+5V_TUN ER

R1502

10KOHM +-5% 1/16W

R1503

10R 1/16W 5%

R1505

33KOHM +-5% 1/16W

10KOHM +-5% 1/16W(N C )

R7521

10KOHM +-5% 1/16W(N C )

R7522

C1502

100N 16V

Q1502

BC847C

+

C1504 470uF 10V

R1506
150 OHM 1/8W

3

4

PVss

5

SHDN

6

IN_L

U6203

MAX9728AETC+(NC)

7

47pF 50V(NC )

SPDIF_OUTPUT6

R1504

75R 1/16W 1%

C1P

VDD

OUTL

OUTR

SVss

C6220

1UF 6V3(N C )

OP_5V

12
11
10

C6224

47pF 50V(NC )

C6221

1UF 6V3(N C )

2

1

C1N

PGND

SGND

IN R

9

8

R6217 30KOHM 1/16W +/ -5%(N C )

C6214

R6218 30KOHM 1/16W +/ -5%(N C )

CVBS_OUTPUT

C6217

1U 25V(NC )

CN1501

2

1

JACK

C6216

10uF 10V(NC )

R6226

47KOHM(NC)

R6228 10OHM1/10W(NC)
R6229 10OHM1/10W(NC)

R6227

47KOHM(NC)

CN1501

RCA color

CVBS_OUTPUT

SIDE_CVBS_AUL_OUTPUT

SIDE_CVBS_AUR_OUTPUT

C6225

1N8 50V(NC )

C6226

1N8 50V(NC )

For CVBS OUT For SPDIF OUT

Yellow

Black

FOR BBY OR AOC AP MODEL

CN1407

JACK(NC)

23
1

56
4

89
7

SIDE_CVBS_INPUT 6

SIDE_CVBS_AUL_INPUT 6

SIDE_CVBS_AUR_INPUT 6

2K10 ATV MT8222 DDR2

T P V ( Top Victory Electronics Co . , Ltd. )

<

絬隔瓜絪腹

絬 隔 瓜 絪 腹

Key Component

Date

30

>

07: CVBS/AUDIO OUTPUT

OEM MO DEL
TPV MO DEL
PCB NAME

<Title> B

<Doc>

719Monday, J anuary 11, 2010

Sheet

of

Size
Rev

称爹

<

称爹

>

TU1601

TUNER

1

NC

2

NC

3

GND

+B(5V)

RF AGC

GND

SDA
SCL

TU A S

NC
NC
NC
SIF

NC
AUDIO
VIDEO

TH117TH218TH319TH4

20

VS_TUNER

4

TU_AGC

5
6

TU_SDA

7

TU_SCL

8

TU_AS

9
10
11
12
13
14
15
16

TU_CVBS

TU_SIF

C1602

2U2 16V(NC)

0R05 1/16W

R1612

0R05 1/1 6W

R1601

0R(NC)

R1604

R1614

2K2(NC)

C1604

100N 16V

C1605

+

47uF 25V

C1609

22P 50V

R1613

0R05 1/16W

R1615

0R05 1/16W

R1602

10K 1/16W 5%

10R 1/16W 5%

R1609

33K 1/16W

+5V_TUNER

R1603

C1608 10 0N 16V

C1610 10 0N 16V

C1613

10uF 10V

Q1602

BC847C

R1610
150 OHM 1/8W

SIF_P 12

SIF_N 12

L1601

150uH

+

C1603

1000uF 10V

R1606

75R 1/16W 1%

75R 1/16W 1%

R1608

+5V_ON

TU_AVI

R1607

100R 1/16W 5%

C1607

47pF 50V

C1606

47N 16V

C1601

1UF 6 V3

+12V

R1605 15 OH M +-5% 1/4W (N C )
R1611 15 OH M +-5% 1/4W (N C )
R1620 15 OH M +-5% 1/4W (N C )

TV_CVBS 12

Tuner_CVBS_GND 12

C1615

330N 25V(N C )

U1601
L7805CD2T-TR(NC)

1

IN

GND

2

OUT

3

1 2

C1614

100N 25V(NC)

FB1601

120R/6000mA(NC)

+5V_TUNER

R1623

R1626

+5V_ON

Q1601

2N7002

+5V_ON

Q1605

2N7002

OEM MO D E L
TPV MODEL
PCB NAME

Sheet

+3V3

Q1604

2N7002

MT_SCL 11,12,16

+3V3

Q1606

2N7002

MT_SDA 11,12,16

2K10 ATV MT8222 DDR2

<Title> B
<Doc> <RevCode>

of

819Monday , J a nuary 11, 2010

Size
Rev

称爹

称爹

>

<

IIC LEVEL SHIFT

CN1603

1
2
3
4
5
6
7
8

CONN(NC)

FOR AP TUNER MODULE

VS_TUNER
TU_SDA

TU_SCL
TU_SI F

TU_CVBS

31

TU_SCL
TU_SDA

33P 50V

R1624 10R 1/16W 5%
R1625 10R 1/16W 5%

C1621

絬 隔 瓜 絪 腹

Key Component

C1622

33P 50V

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

>

<
08: TUNE R

Date

4.7KOHM +-5% 1/16W

4.7KOHM +-5% 1/16W

21
23

22
20

CN5010

TH2
TH4

TH3
TH1

HDMI

HP DET

GND

DDC DATA

DDC CLK

CE Remote

CK Shield

D0 Shield

D1 Shield

D2 Shield

+5V

CK­CK+

D0+

D1+

D2+

HDMI1_5V

D1706

+5V

1

19
18
17
16
15
14

NC

13
12
11
10
9

D0-

8
7
6

D1-

5
4
3

D2-

2
1

R1701 470K 1/16W 5%

R1703 1Kohm 1/ 16W +/ -1%

R1707 10R 1/ 16W 5%
R1708 10R 1/ 16W 5%

HDMI1_HPD 10

HDMI1_5V

HDMI1_DDC_SDA 10,12
HDMI1_DDC_SCL 10,12

HDMI1_CK- 10,12
HDMI1_CK+ 10, 12

HDMI1_D0- 10,12
HDMI1_D0+ 10,12

HDMI1_D1- 10,12
HDMI1_D1+ 10,12

HDMI1_D2- 10,12
HDMI1_D2+ 10,12

47KOHM +-5% 1/16W

DDCWP_HDMI1

HDMI1_DDC_SCL10,12

HDMI1_DDC_SDA10,12

R1704

47KOHM +-5% 1/16W

R1705

R1706

10KOHM +-5% 1/16W

R1709

100K(NC)

2

BAT54C

3

C1701

100N 16V

U1702

8

VCC

7

WP

6

SCL

5

M24C02-WMN6TP

1

A0

2

A1

3

A2

VSS4SDA

HDMI1_HPD10

HDMI2_HPD10

HDMI3_HPD

R1710 10R 1/ 16W 5%

Q1702

MUN2211TIG

R1715 10R 1/ 16W 5%

Q1705

MUN2211TIG

R1719 10R 1/ 16W 5%(NC )

Q1706

MUN2211TIG(NC)

R1711

10R 1/16W 5%

R1716

10R 1/16W 5%

R1721

10R 1/16W 5%(N C )

HDMI1_HPD_CTL 12

HDMI2_HPD_CTL 12

HDMI3_HPD_CTL 12

RClamp0520B.TCT(NC)

CN5011

21

TH2

23

TH4

22

TH3

20

TH1

HDMI

CEC10

3

HP DET

GND

DDC DATA

DDC CLK

CE Remote

CK Shield

D0 Shield

D1 Shield

D2 Shield

U1701

2 Q1704 2N7002

Q1703 2N70029(NC)

1

R1717

0 OHM +-5% 1/16W

19
18

+5V

17
16
15
14

NC

13
12

CK-

11
10

CK+

9

D0-

8
7

D0+

6

D1-

5
4

D1+

3

D2-

2
1

D2+

Q1707 2N7002(NC)

CEC

R1731

0 OHM +-5% 1/16W

+5V_STBY

R1718 0 OHM +-5% 1/16W9(NC)

R1725 470K 1/16W 5%

R1722 1Kohm 1/ 16W +/-1%

R1724 10R 1/ 16W 5%
R1723 10R 1/ 16W 5%

+5V

Q1708 2N7002

R1730

0R(NC)

MCU_CEC 11

HDMI2_HPD 10

HDMI2_5V

HDMI2_DDC_SDA 10,12
HDMI2_DDC_SCL 10,12

HDMI2_CK- 10,12
HDMI2_CK+ 10,12

HDMI2_D0- 10,12
HDMI2_D0+ 10,12

HDMI2_D1- 10,12
HDMI2_D1+ 10,12

HDMI2_D2- 10,12
HDMI2_D2+ 10,12

MT_CEC 12

+5V

47KOHM +-5% 1/16W

R1712

47KOHM +-5% 1/16W

DDCWP_HDMI2
HDMI2_DDC_SCL10,12
HDMI2_DDC_SDA10,12

R1713

R1714

10KOHM +-5% 1/16W

R1720

100K(NC)

FOR AIO MODEL DVI INPUT

HDMI3_HPD

R1411 470K 1/16W 5%(N C )

HDMI3_5V

1Kohm 1/16W +/-1%(N C )

R1413

CEC

HDMI3_5V

2
4
6

8
10
12
14
16
18
20

CN5012

CONN(NC)

HDMI2_5V

D1705

1

2

BAT54C

3

C1702

100N 16V

U1703

8

VCC

7

WP

6

SCL

5

VSS4SDA

M24C02-WMN6TP

R1412 10R 1/ 16W 5%(N C)

1

R1415 10R 1/16W 5%(N C )

3
5
7
9
11
13
15
17
19

A0
A1
A2

1
2
3

HDMI3_CK- 12
HDMI3_CK+ 12
HDMI3_D0- 12
HDMI3_D0+ 12
HDMI3_D1- 12
HDMI3_D1+ 12
HDMI3_D2- 12
HDMI3_D2+ 12

絬 隔 瓜 絪 腹

Key Component

DDCWP_PC4

DDCWP_HDMI1

DDCWP_HDMI2

DDCWP_HDMI3

HDMI3_DDC_SDA 12

HDMI3_DDC_SCL 12

47KOHM +-5% 1/16W(NC)

DDCWP_HDMI3

HDMI3_DDC_SCL12

HDMI3_DDC_SDA12

T P V ( Top Victory Electronics Co . , Ltd. )

09: HDMI INTPUT

Date

D1701 LS4148

D1702 LS4148

D1703 LS4148

D1704 LS4148(NC)

R1728

R1727

47KOHM +-5% 1/16W(NC)

OEM MO D EL
TPV MOD EL

PCB NAME

Sheet

+3V3

R1732

10KOHM +-5% 1/16W

Q1701

BC847C

+5V

1

R1729

10KOHM +-5% 1/16W(NC )

R1726

100K(NC)

2K10 ATV MT8222 DDR2

of

919Monday, J anuary 11, 2010

DDC_WP 12

HDMI3_5V

D1707

2

BAT54C(NC)

3

C1703

100N 16V(NC)

U1704

8

A0

VCC

7

A1

WP

6

A2

SCL

5

VSS4SDA

M24C02-WMN6TP(NC)

1
2
3

Custom

Size

<RevCode>

Rev

称爹

称爹

>

<

32

HDMI1_D2+
HDMI1_D2-

HDMI1_D1+
HDMI1_D1-

U2101 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

HDMI1_D2+ 9,12
HDMI1_D2- 9,12

HDMI1_D1+ 9,12
HDMI1_D1- 9,12

HDMI2_D2+
HDMI2_D2-

HDMI2_D1+
HDMI2_D1-

U2104 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

HDMI2_D2+ 9,12
HDMI2_D2- 9,12

HDMI2_D1+ 9,12
HDMI2_D1- 9,12

HDMI1_D0+
HDMI1_D0-

HDMI1_CK+
HDMI1_CK-

CEC_E
HDMI1_DDC_SCL

HDMI1_DDC_SDA
HDMI1_HPD

U2102 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

U2103 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

HDMI1_D0+ 9,12
HDMI1_D0- 9,12

HDMI1_CK+ 9,12
HDMI1_CK- 9,12

CEC_E

R2101

0 OHM +-5% 1/16W

HDMI1_DDC_SCL 9,12
HDMI1_DDC_SDA 9,12

HDMI1_HPD 9

絬 隔 瓜 絪 腹

Key Component

CEC 9

T P V ( Top Victory Electronics Co . , Ltd. )

Date

<

絬隔瓜絪腹

10: HDMI ESD

>

HDMI2_D0+
HDMI2_D0-

HDMI2_CK+
HDMI2_CK-

HDMI2_DDC_SCL
HDMI2_DDC_SDA

HDMI2_HPD

U2105 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

U2106 RClamp0524P.TCT(NC)

10

OUT1

9

OUT2

7

OUT3

6

OUT4

GND

3

OE M MO DE L
TPV MOD EL
PCB N AME

Sheet

<Title> A

<Doc>

10 19Monday, J anuary 11, 2010

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

1

IN1

2

IN2

4

IN3

5

IN4

GND

8

2K10 ATV MT K DDR2

of

HDMI2_D0+ 9,12
HDMI2_D0- 9,12

HDMI2_CK+ 9,12
HDMI2_CK- 9,12

HDMI2_DDC_SCL 9,12
HDMI2_DDC_SDA 9,12

HDMI2_HPD 9

Size
Rev

称爹

<

称爹

>

33

STANDBY12,19

5V_PWR_SW12,19

RC_IR_3V312,16

MT_INT12

MCU_CEC9
PC_VSYNC4,12
PC_HSY NC4,12

AUD_PWR_SW12,18

LED2_STBY12,16

ISP1_SCL4
ISP1_SDA4

10K 1/16W 5%(N C )

KEY112,16

RXD112,16
TXD112,16

MT_SCL8,12,16
MT_SDA8,12,16

R7517

47R 1/16W 5%(N C )

63383 3P 2.0MM(NC)

MT_SC L8,12,16
MT_SD A8,12,16

EEPROM_WP12

+3V3

Q4109

2N7002(NC)

R4123

R4125

100R 1/16W 5%

CN4106

R4137

10K(NC)

27K 1/16W 5%

3
2
1

+3V3_F

R4101

10K 1/16W 5%

R4138

10K(NC)

100N 16V (NC )

10K(NC)

R4106

R4104

R4105

10K 1/16W 5%

+3V3

12

FB4103

120R/3000mA

R4139

10KOHM +-5% 1/16W

47R 1/16W 5%

Q4101

MUN2211TIG

+3V3_STBY

C4102

+3V3_STBY

10K(NC)

R4107

10K 1/16W 5%(N C )

R4141

U4102

1

GND

3

Vcc

AP1701FWL(NC)

10K(NC)

R4108

R4110

R4109

10KOHM +-5% 1/ 16W

10K 1/16W 5%

RESET

R4111

R4102

100K (NC)

R4112

10K 1/16W 5%

33KOHM +-5% 1/ 16W

2

System E2PROM

U4103

E0

VCC

E1

WC

E2

SCL

VSS

SDA

M24C64-WMN6P

IIC ADRESS "A0"

1
2
3
4

8
7
6
5

R4113

10K 1/16W 5%

RESET_WT

R4114

+3V3_STBY

R4115

R4116

6K8 1/16W 5%

R4121 47R 1/16W 5%(N C )

33KOHM +-5% 1/ 16W

R4117 47R 1/ 16W 5%(N C )
R4118 47R 1/ 16W 5%(N C )
R4119 47R 1/ 16W 5%(N C )

R4127 47R 1/ 16W 5%(N C )
R4128 47R 1/ 16W 5%(N C )
R4129 47R 1/ 16W 5%(N C )
R4130 47R 1/ 16W 5%(N C )
R4131 47R 1/ 16W 5%(N C )
R4132 47R 1/ 16W 5%(N C )
R4133 22R 1/ 16W 5%(N C )
R4134 22R 1/ 16W 5%(N C )
R4135 47R 1/ 16W 5%(N C )
R4136 47R 1/ 16W 5%(N C )

2N7002(NC)

Q4110

+3V3

+3V3

C4107

100N 16V

R4103

10K 1/16W 5%(N C )

4U7 6V3(N C )

120R/3000mA(NC)

D4101LS4148(NC)

C4104

RESET_WT

FB4101

C4103

10U 6V3(NC )

U4101

4

NPST

22

GPIOA0/AD0

21

GPIOA1/AD1

20

GPIOA2/AD2

19

GPIOA3/AD3/IR

12

GPIOB2/IRQ0

11

GPIOB3/IRQ1

10

GPIOB4/VIN

9

GPIOB5/HIN

8

GPIOB6/IRQ2/TXD

7

GPIOB7/IRQ3/RXD

18

GPIOA4/SCL3

17

GPIOA5/SDA3

16

GPIOA6/SCL1

15

GPIOA7/SDA1

14

GPIOB0/SCL2

13

GPIOB1/SDA2

FLASH_WR#12

12

23

1KOHM +-5% 1/10W

R4143

33 OHM +-5% 1/16W

C4101

100N 16V(NC )

24

VDD

32KOSCO

VDD_R TC

32KOSCI

GPIOC1/PWM1
GPIOC0/PWM0

VSS

WT6703F-SG240WT(NC)

3

R4140

+3V3_STBY

R4120

OSCO

1

OSCI

2

R4124 47R 1/ 16W 5%(N C )

5

R4126 47R 1/ 16W 5%(N C )

6

+3V3_F

SPI_CS#12
SPI_SI12

SPISCK12

SPI_SO12

R4142

10K(NC)

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

1
2
3
4

16
15
14
13
12
11
10

9

<

絬隔瓜絪腹

>

11: WT6703F (STAND BY MCU )

33KOHM +-5% 1/ 16W

R4122 33 OH M +-5% 1/16W( NC)

DC_ON_OFF 12,16

RESET_MT8222 12

22P 50V(NC)

Serial Flash

VCC

HOLD#

SCK

SO/SIO1

SI

U4105

HOLD

VCC

8
7
6
5

NC
NC
NC
NC
CS

+3V3_F

SPISCK 12
SPI_SO 12

1
2
3
4
5
6
7
8

U4104

CS#
SO
W#
GND

MX25L3205DM2I-12G(NC)

MX25L6405DMI-12G

SCLK
SI/SIO0
NC
NC
NC
NC
GND
WP

/ACC

C4105

OEM MODEL
TPV MO D EL

PCB NAME

Sheet

1 2

X4101

32.768KHz(NC)

C4108

10uF 10V

SPI_CS# 12

C4106

22P 50V(NC)

C4109

100N 16V

SPI_SI 12

2K10 ATV MT8222 DDR2

<Title> B

<Doc>

of

11 19Monday, J anuary 11, 2010

Size
Rev

称爹

称爹

>

<

34

R4226

100KOHM +-5% 1/16W

R4222

R4230

100KOHM +-5% 1/16W

R4225

DV10

DDRV

RDQ0
RDQ1

RDQ2
RDQ3
RDQ4

RDQ5
RDQ6
RDQ7

RDQS013
RDQM013
RDQM113
RDQS113

RDQ8
RDQ9

RDQ10
RDQ11
RDQ12

RDQ13
RDQ14
RDQ15

RCKE13

RA11
RA9

RA8
RA7
RA6
RA5
RA4

RWE#13
RCAS#13
RRAS#13
RCS#13
RBA013
RBA113

RA0
RA1

RA2
RA3

DV33

VGA_SDA4
VGA_SCL4

R4145

MT_CE C9

IR buffer

RC_IR _3V3 11, 16

C4243

C4242

100N 16V

100N 16V

C4255

C4256

4U7 10V

100N 16V

C4281

100N 16V

GPIO_0
GPIO_1
GPIO_2
GPIO_3

GPIO_4

GPIO_5
GPIO_6

GPIO_7
GPIO_8

GPIO_9

GPIO_10
GPIO_11

RA12

RA10

+3V3

27K 1/16W 5%

C4257

10N 50V

C4282

100N 16V

257

129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192

C4244

100N 16V

C4283

100N 16V

C4258

10N 50V

+3V3

GPIO_11

128

TH1

DVDD10_2
DVDD10_2
RDQ0
RDQ1
VCC2IO_2
RDQ2
RDQ3
RDQ4
VCC2IO_2
RDQ5
RDQ6
RDQ7
VCC2IO_3
RDQS0
VCC2IO_2
RDQM0
DVDD10_2
RDQM1
VCC2IO_2
RDQS1
VCC2IO_2
RDQ8
RDQ9
VCC2IO_2
RDQ10
RDQ11
RDQ12
VCC2IO_2
RDQ13
RDQ14
RDQ15
AVDD12_MEMPLL_1
VCC2IO_1
RCLK0#
RCLK0
VCC2IO_2
RCKE
RA12
RA11
VCC2IO_2
RA9
RA8
RA7
RA6
RA5
RA4
RWE#
RCAS#
RRAS#
RCS#
RBA0
RBA1
RA10
RA0
RA1
DVDD10
RA2
RA3
VCC2IO_1
RVREF0
DVDD10_2
VDD33_2
VGA_SDA
VGA_SCL

193

USB_DN6
USB_DP6

AV33_USB
AV12_USB

R4221

5K1 1/10W 1%

Close to MT8222 As
possible

C4246

C4247

100N 16V

100N 16V

C4259

C4260

3N3 50V

3N3 50V

C4285

C4284

100N 16V

100N 16V

R4202

10KOHM +-5% 1/16W

GPIO_9

GPIO_7

GPIO_8

GPIO_4

GPIO_6

GPIO_5

GPIO_3

GPIO_10

127

120

121

122

123

124

125

126

GPIO3

GPIO4

GPIO5

GPIO6

GPIO7

GPIO8

GPIO9

GPIO10

GPIO11

HDMI_CEC

DVDD10

USB_DP1

USB_DM1

AVDD12_USB

USB_VRT

AVDD33_USB

USB_DP0

USB_DM0

201

200

199

198

197

196

195

194

DV10

AV33_USB

USBVRT

USB1_DP

USB1_DN

R4152

1Kohm 1/16W +/ -1%(N C )

HDMI3_5V

C4248

100N 16V

FB4213

AV12 AV12_LVDS

1 2

120R/3000mA

C4261

10uF/6.3V

C4286

C4287

100N 16V

100N 16V

DV10

DV33

DV10

116

114

115

GPIO0

VDD33_2

DVDD10_3

RX2_C

RX2_CB

HDMI_SCL2

206

207

205

6

6

HDMI3_CK+

HDMI3_CK-

HDMI3_D0-

FB4201

120R/3000mA

10uF/6.3V

C4267

10uF/6.3V

O0N

113

DVDD10_3

RX2_0B

208

HDMI3_D0+

C4238

C4294

100N 16V

O0P

O0N

RX2_0

HDMI3_D1-

112

O0P

RX2_1B

209

R4150

O1N

O1P

O2N

110

109

111

O1P

O1N

RX2_1

RX2_2B

212

210

211

HDMI3_D2-

HDMI3_D1+

HDMI3_D2+

HDMI2_5V

C4268

100N 16V

C4295

100N 16V

AV33_LVDS

O2P

AV33_LVDS

108

107

O2P

O2N

AVDD33_LVDSA

HDMI_SDA1

PWR5V_1

RX2_2

214

213

HDMI2_DDC_SDA

OCKN

106

215

HDMI2_DDC_SCL

AV33_HDMI

C4269

100N 16V

DV33

GPIO_0

GPIO_1

GPIO_2

117

118

119

GPIO1

GPIO2

HDMI_SDA2

PWR5V_2

204

203

202

HDMI3_DDC_SCL

HDMI3_DDC_SDA

1Kohm 1/16W +/ -1%

AV12 AV12_LVDSPLL

1 2

C4293

100N 16V

AV12_LVDS

O4N

O4P

E0N

E1N

E0P

OCKP

O3N

O3P

97

98

99

101

103

105

100

102

104

E0P

E0N

O4P

O3P

O4N

O3N

OCKP

OCKN

AVDD12_LVDS

U4201

MT8222AHMU/B

RX1_1

RX1_2B

RX1_1B

RX1_0

RX1_C

RX1_0B

RX1_CB

AVDD33_HD MI

HDMI_SCL1

224

222

223

221

220

218

219

217

216

HDMI2_D1-

HDMI2_D1+

HDMI2_CK+

HDMI2_CK-

HDMI2_D0-

HDMI2_D2-

HDMI2_D2+

HDMI2_D0+

HDMI1_5V

C4245

100N 16V

FB4214

AV12 AV12_USB

1 2

120R/3000mA

C4270

10uF/6.3V

FB4219

AV12 AV12_MEMPLL

1 2

120R/3000mA

C4288

4U7 10V

ECKN

E2P

E1P

E2N

AV33_LVDS

94

95

96

93

E2P

E1P

E2N

E1N

AVDD33_LVDSB

RX0_CB

HDMI_SCL0

HDMI_SDA0

PWR5V_0

RX1_2

228

227

226

225

HDMI1_CK-

HDMI1_DDC_SDA

HDMI1_CK+

HDMI1_DDC_SCL

R4151

1Kohm 1/16W +/-1%

RST_MT8222

ECKP

91

92

ECKN

RX0_C

229

230

HDMI1_D0-

AV12_LVDSPLL

E4N

E3P

E3N

88

89

90

E3P

E3N

ECKP

RX0_1B

RX0_0

RX0_0B

233

232

231

HDMI1_D1-

HDMI1_D1+

HDMI1_D0+

C4262

10U 6V3

C4296

10uF/6.3V

E4P

87

E4P

E4N

RX0_1

RX0_2B

234

HDMI1_D2-

DV10

86

84

85

TP

DVDD10_4

AVDD12_VPLL

VSYNC

AVDD12_HD MI_3

RX0_2

237

236

235

HDMI1_D2+

VGAVSYNC#

AV12_HDMI

C4263

100N 16V

C4297

100N 16V

UP35

DV33

83

VDD33_1

HSYNC

238

VGAHSYNC#

BLUP

R4238 0 OHM +-5% 1/16W(NC )

R4239 0 OHM +-5% 1/16W

R4235 0 OHM +-5% 1/16W

R4236 0 OHM +-5% 1/16W

R4237 0 OHM +-5% 1/16W

0 OHM +-5% 1/16W

R4253

UP31

U0TX

MT_RC _3V3

U0RX

SPI_SI

UP30

UP34

UP33

SPI_SCK

73

75

77

82

240BP239

VGASOG

+3V3

AV12

AV12

76

UP3078UP3179UP3380UP3481UP35

TXD0

RXD0

SOY1

AVDD33_VGA

COM

SOG

246

245

244RP243

242GP241

Y1P

SOY1

GRNP

REDP

VGAGND

AV33_VGA

Reset buffer

Q4208

2N7002(NC)

FB4215

1 2

120R/3000mA

C4264

10uF/6.3V

FB4220

1 2

120R/3000mA

C4289

4U7 6V3

72

74

71

IR_

INT0_

SPI_CS1

SPI_SCK

PR1P

PB1P

COM1

Y1P

250

249

248

247

PB1P

PR1P

YPBPR1_N

SOY0/FB0

AV12D_RGB

RESET_MT8222 11

AV12_HDMI

C4265

4U7 6V3

AV12A_RGB

C4290

10U 6V3

1KOHM +-5% 1/16W

SPI_SO

ICE

SPI_CS#

68

69

67

70

66

ICE

SPI_SI

PRST#

SPI_SO

SPI_CS0

AVDD33_REFP_AADC

AVDD12_SYSPLL
AVDD12_ADC PLL

PR0P

PB0P

COM0

Y0P

SOY0

255

254

253

252

251

AV12D_RGB

Y0P

YPBPR0_N

PR0P

PB0P

C4266

100N 16V

C4291

100N 16V

AUD_PWR _SW 11,18

LED2_STBY 11,16
STANDBY 11,19

FLASH_WR # 11

5V_PWR_SW 11,19
RC_IR _3V3 11, 16
AC_OFF 17

RST_MT8222

R4207

EEPROM_WP 11

PWM265PWM3

PWM1
PWM0

SPDIF_OUT

RXD1
HW_SCL
HW_SDA

GPIO25
GPIO24
GPIO23
GPIO22
GPIO21
GPIO20

I2S_ADIN

I2S_AOSDATA0

I2S_AOBC LK
I2S_AOLRCK
I2S_AOMCLK

VDD33_1

DVDD10_3

AVICM2

AVDD33_ADAC

AIN_R
AIN_L

VMID

AVDD33_AADC

AVDD12_APLL

AVDD12_PSPLL

AVDD12_DMPLL

XTAL I

XTAL O

AVDD33_XTAL

ADIN5
ADIN4
ADIN3
ADIN2
ADIN1
ADIN0

AVDD33_DI G

MPX1

MPX2_N
MPX2_P

AVDD33_SIF

AVDD33_CVBS
CVBS_BYPASS1
CVBS_BYPASS0

CVBS0P
CVBS0N
CVBS1P
CVBS2P

CVBS3P
CVBS_SY0
CVBS_SC0
CVBS_SY1
CVBS_SC1

AVDD12_RGB

AVDD12_DI G_RGB

256

AV12A_RGB

AV12A_RGB

C4292

3N3 50V

35

+3V3

C4202

100N

R4229

64
63
62
61

R4224 10 OH M +-5% 1/16W

TXD1

60

R4223 10 OH M +-5% 1/16W

59

R4210 10 OH M +-5% 1/16W
R4211 10 OH M +-5% 1/16W

58

GPIO_25

57

GPIO_24

56

GPIO_23

55

GPIO_22

54
53

GPIO_20

52
51

AOSDATA0

50

AOBCK

49

AOLRCK

48

AOMCLK

47

DV33

46

DV10

45
44

AR1

43

AL1

AVICM

42
41

AR2

40

AL2

39

AR3
AL3

AR3 7

38

AL3 7

37

AV33_ADCREF

36

MT_AUD_R

35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1

3K3 1/16W 1%

AV12

R4257

MT_AUD_L

R4258

AUD_VMID
AV33_ADC

AV12_PLL

XTAL I
XTAL O
AV33_XTL
MTK_D C_O N_ OFF

ADIN2
ADIN1
ADIN0
AV33_SIFDI G

R4219 0 OHM +-5% 1/16W

R4213

R4144

6K8 1/16W 5%

ADIN 2

KEY2 16

ADIN 1

R4246 0 OH M +-5% 1/16W (N C )

VGA input

REDP
VGAGND
VGASOG

GRNP

BLUP

VGAHSYNC #

VGAVSYNC#

COMP1 input

SOY0/FB0

Y0P

YPBPR0_N

PB0P

PR0P

For IPTV COMP2 input

SOY1

Y1P

YPBPR1_N

PB1P

PR1P

FB4216

AV12D_RGB

1 2

120R/3000mA

U4202

GND

3

Vcc

RESET

AP1701FWL

+3V3

10KOHM +-5% 1/16W

MTK_TXD1
MTK_RXD1
MTK_SCL
MTK_SDA

OP_MUTE 17

AMP_GAIN1 18
AMP_GAIN0 18
AMP_EN 18

AUDIN_SEL1 15
AUDIN_SEL2 15

DV33
DV10

AV33_DAC
AV33_ADCREF

0 OHM

0 OHM

C4207

AV33_ADC

10U 6V3

AV12_PLL

AV33_XTL

AV33_SIFDI G

SIF_N 8

SIF_P 8

AV33_SIF
AV33_CVBS

CVBS_OUT 7

TV_CVB S 8

Tuner_CVBS_GND 8

SIDE_CVBS_IN 6

CVBS1_IN 5

SIDE_SVY_I N 6
SIDE_SVC_IN 6

+3V3

Q4201

2N7002

PC_R_IN 4
PC_GND 4
PC_SOG 4
PC_G_IN 4
PC_B_IN 4
VGAHSYNC
VGAVSYNC

SOY1/ FB1 5
COMP1_Y_IN 5
COMP1_GND 5
COMP1_PB_IN 5
COMP1_PR_IN 5

COMP2_SOG 5
COMP2_Y_IN 5
COMP2_GND 5
COMP2_PB_IN 5
COMP2_PR_IN 5

C4272

C4271

100N 16V

4U7 6V3

1
2

RST_MT8222

C4201

R4206

4U7(NC)

100K

10KOHM +-5% 1/16W

BRIGHTNESS_PWM 19

SPDIF _OUT 6

AV33_DAC

C4203

4U7 6V3

C4204

4U7 6V3

C430310uF 6. 3V

C4304 10uF 6.3V

C4208

100N 16V

C4214

33P 50V

R4203

1K 1/16W 1%(NC )

KEY

KEY1 11,16

+3V3

R4201

D4201

LS4148(NC)

+3V3

10KOHM +-5% 1/16W( N C )

R4215

U0TX16
U0RX16

+3V3

C4205

820KOHM +-5% 1/10W

10uF 10V

100N 16V

AUD_R 15
AUD_L 15

10KOHM +-5% 1/16W(NC )

X4201

10KOHM +-5% 1/16W(NC)

27MHz

12

R4217

C4215

27P 50V

LIGHT_SENSOR 16

10KOHM +-5% 1/16W(NC )

10KOHM +-5% 1/16W(NC )

10KOHM +-5% 1/16W(NC )

MTK_DC_ON_OFF

HDMI1_D0+
HDMI1_D0­HDMI1_D1+
HDMI1_D1­HDMI1_D2+
HDMI1_D2­HDMI1_CK+

HDMI1_CK­HDMI1_DD C_SCL
HDMI1_DD C_SDA

HDMI2_D0+

HDMI2_D0-

HDMI2_D1+

HDMI2_D1-

HDMI2_D2+

HDMI2_D2-

HDMI2_CK+

HDMI2_CK­HDMI2_DD C_SCL
HDMI2_DD C_SDA

HDMI3_D0+
HDMI3_D0­HDMI3_D1+
HDMI3_D1­HDMI3_D2+
HDMI3_D2­HDMI3_CK+

HDMI3_CK­HDMI3_DDC_SCL
HDMI3_DDC_SDA

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

Serial Flash IF

SPISCK11
SPI_SI11
SPI_SO11
SPI_CS#11

R4214

10KOHM +-5% 1/16W

10KOHM +-5% 1/16W(NC )

VGAHSYNC

R4212

10K(NC)

10KOHM +-5% 1/16W(NC )

VGAVSYNC

R4216

10KOHM +-5% 1/16W

R4228 22R 1/16W 5%
R4231 22R 1/16W 5%
R4232 22R 1/16W 5%
R4233 22R 1/16W 5%

C4299

C4298

100N 16V

R4242

MTK_TXD1

R42540 OHM +-5% 1/16W

R4241

MTK_RXD1

R4259 0 OHM +-5% 1/16W

R4247

MTK_SCL

R42510 OHM +-5% 1/16W

R4248

MTK_SDA

R42520 OHM +-5% 1/16W

R4243

R4249 0 OHM +-5% 1/16W

HDMI input

HDMI1_D0+ 9,10
HDMI1_D0- 9,10
HDMI1_D1+ 9,10
HDMI1_D1- 9,10
HDMI1_D2+ 9,10
HDMI1_D2- 9,10

HDMI1_CK+ 9,10

HDMI1_CK- 9,10
HDMI1_DD C_SCL 9,10
HDMI1_DD C_SDA 9,10

HDMI2_D0+ 9,10

HDMI2_D0- 9,10

HDMI2_D1+ 9,10

HDMI2_D1- 9,10

HDMI2_D2+ 9,10

HDMI2_D2- 9,10
HDMI2_CK+ 9,10

HDMI2_CK- 9,10
HDMI2_DD C_SCL 9,10
HDMI2_DD C_SDA 9,10

HDMI3_D0+ 9

HDMI3_D0- 9

HDMI3_D1+ 9

HDMI3_D1- 9

HDMI3_D2+ 9

HDMI3_D2- 9

HDMI3_CK+ 9

HDMI3_CK- 9
HDMI3_DD C_SCL 9
HDMI3_DD C_SDA 9

<

絬隔瓜絪腹

>

12: MTK8222

R4250 100R 1/16W 5%

SPI_SI
SPI_SO
SPI_CS#

R4220 0R(NC )

U0TX16

R4227 0R(NC )

U0RX16

+3V3

R4255

R4260 0 OHM +-5% 1/16W

R4256

R4261 0 OH M +-5% 1/16W

U4203

1

SDIN

2

DEM/SCLK

3

LRCK

4

MCLK
VQ5FILT+

CS4344-CZZ

+3V3

TX,RX buffer

2N7002(NC)

Q4203

TXD1 11,16

+3V3

Q4204

2N7002(NC)

RXD1 11,16

+3V3

IIC buffer

Q4205

2N7002(NC)

MT_SCL 8, 11,16

+3V3

Q4206

2N7002(NC)

MT_SDA 8,11,16

+3V3

DC ON/OFF buffer

Q4207

2N7002(NC)

SPI_SCK

R4244

1K 1/16W 5%(NC )

TXD1 11,16
RXD1 11, 16

H,V SYNC buffer

Q4209

2N7002(NC)

PC_HSYN C 4,11

+3V3

Q4210

2N7002(NC)

PC_VSYN C 4,11

10

MAIN_AOR 17

AOUTR

9

VA

8

GND

7

AOUTL

MAIN_AOL 17

6

C4300

10uF 10V

+3V3

1 2
120R/3000mA

DC_ON_OF F 11,16

C4229

4U7 10V

FB4208

+3V3

1 2

120R/3000mA

C4236

10U 6V3

FB4210

+3V3 AV33_USB

1 2

120R/3000mA

C4249

10U 6V3

FB4217

+3V3

1 2

120R/3000mA

C4273

4U7 6V3

OEM MODEL
TPV MOD E L
PCB NAME

2K10 ATV MT8222 DDR2

<Title> C
<Doc>

of

Sheet

12 19Thursday, F ebruar y 04, 2010

LVDS INTERFACE

C4301

100N 16V

10uF 10V

FB4202

+

C4209
C4206

4U7 10V

100uF 10V

+3V3

C4217

4U7 10V

+3V3

+3V3 AV33_DAC

+3V3

FB4207

+3V3

1 2

120R/3000mA

AV33_ADC

C4233

C4234

10U 6V3

100N 16V

C4250

C4251

10U 6V3

100N 16V

AV33_XTL

C4275

C4274

100N 16V

10U 6V3

O0N
O0P
O1N
O1P
O2N
O2P
OCKN
OCKP
O3N
O3P
O4N
O4P

E0N
E0P
E1N
E1P
E2N
E2P
ECKN
ECKP
E3N
E3P
E4N
E4P

1 2

C4302

DV33

C4210

100N 16V

FB4203

1 2

120R/3000mA

FB4204

1 2

120R/3000mA

C4221

4U7 6V3

FB4205

1 2

120R/3000mA

C4222

4U7 6V3

FB4206

1 2

120R/3000mA

C4226

4U7 6V3

+3V3

1 2

+3V3

1 2

1 2

FB4221

120R/3000mA

C4211

100N 16V

AV33_VGA

AV33_SIF

AV33_CVBS

AV33_LVDS

C4230

10U 6V3

FB4209

120R/3000mA

FB4211

120R/3000mA

FB4218

120R/3000mA

Size
Rev

称爹

RXO0- 14
RXO0+ 14
RXO1- 14
RXO1+ 14
RXO2- 14
RXO2+ 14
RXOC- 14
RXOC+ 14
RXO3- 14
RXO3+ 14
RXO4- 14
RXO4+ 14

RXE0- 14
RXE0+ 14
RXE1- 14
RXE1+ 14
RXE2- 14
RXE2+ 14
RXEC- 14
RXEC+ 14
RXE3- 14
RXE3+ 14
RXE4- 14
RXE4+ 14

OPS_5V

C4212

100N 16V

C4216

10U 6V3

C4219

10U 6V3

C4224

10U 6V3

C4227

10U 6V3

C4231

100N 16V

AV33_HDMI

C4235

4U7 6V3

AV33_SIFDI G

C4252

4U7 6V3

AV33_ADCREF+3V3

C4276

4U7 6V3

<

称爹

>

C4213

100N 16V

C4218

100N 16V

C4220

100N 16V

C4225

100N 16V

C4228

100N 16V

C4232

100N 16V

C4237

100N 16V

C4253

100N 16V

C4277

100N 16V

PANEL_PWR_CTL19

ODSEL14
HDMI1_HPD_CTL9
HDMI2_HPD_CTL9
HDMI3_HPD_CTL9

DDC_WP9

51KOHM +-5% 1/16W

USB_OC6

MT_INT11

INVERTER_ON_OF F19

51KOHM +-5% 1/16W

USB1_OC6

EARP_DET6

LED1_ON16

RDQ[15..0]13

AV12_MEMPLL

RCLK0#13
RCLK013

RA[12..0]13

MEM_VR EF

C4223

100N 16V

+3V3

Q4202

R4240

R4245 0 OHM +-5% 1/16W(NC )

DV10

C4241

C4240

100N 16V

100N 16V

FB4212

1 2

120R/3000mA

DDRV

C4279

100N 16V

2N7002(NC)

AV12_PLLAV12

C4280

100N 16V

10KOHM +-5% 1/16W(NC )

MT_RC_3V3

C4239

4U7 10V

C4254

4U7 10V

C4278

4U7 10V

R4146

DDRV

1Kohm 1/1 6W +/-1 %(N C )

1Kohm 1/ 16W +/- 1%

R4147

100uF 10V

DDRV

C5111

4.7uF 6. 3V

MEM_R A0
MEM_R A1
MEM_R A2
MEM_R A3
MEM_R A4
MEM_R A5
MEM_R A6
MEM_R A7
MEM_R A8
MEM_R A9
MEM_R A10
MEM_R A11
MEM_R A12

MEM_BA0
MEM_BA1

MEM_RCLK0

MEM_R C LK0#

MEM_C S#
MEM_CKE
MEM_RAS#

MEM_C AS#

MEM_WE#

MEM_D QM1
MEM_D QM0

DDRV

C5124

+

C5112

100N 16V

U4106

M8
M3
M7
N2
N8
N3
N7
P2
P8
P3
M2
P7
R2

L2
L3
L1

J8

K8

L8
K2
K7

L7
K3
K9

B3
F3

R3
R7

NT5TU32M16CG-25C

C5121

3N3 50V

1Kohm 1/16W +/-1%

C5113

100N 16V

J9

R1

J1

VDDA1VDDE1VDD

VDDM9VDD

VDDL

C5115

100N 16V

VDDQA9VDDQC3VDDQC7VDDQC9VDDQE9VDDQG1VDDQG3VDDQG7VDDQ

VSSQ

A7

MEM_VR EF

C5122

3N3 50V

C5116

3N3 50V

A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12

BA0
BA1
NC

CK
CK#
CS
CKE
RAS
CAS
WE
ODT

UDM
LDM

NC
NC

VSS

VSSE3VSSJ3VSSN1VSSP9VSSDLJ7VSSQB2VSSQB8VSSQD2VSSQD8VSSQE7VSSQF2VSSQF8VSSQH2VSSQ

A3

1Kohm 1/16W +/-1%

R4148

R4149

C5114

100N 16V

DDRV

MEM_DQ0 RDQ0

C1

VDDQ

C5118

3N3 50V

G9

VREF

DQ10
DQ11
DQ12
DQ13
DQ14
DQ15

UDQS
UDQS

LDQS
LDQS

H8

C5119

3N3 50V

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8
DQ9

NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC

J2

G8
G2
H7
H3
H1
H9
F1
F9
C8
C2
D7
D3
D1
D9
B1
B9

B7
A8
F7
E8

A2
E2
R8
AA1
AA2
AA3
AA4
AA6
AA7
AA8
AA9

C5120

3N3 50V

MEM_VREF

MEM_DQ6
MEM_DQ2
MEM_DQ4
MEM_DQ0
MEM_DQ1
MEM_DQ7
MEM_DQ3
MEM_DQ5
MEM_DQ13
MEM_DQ10
MEM_DQ15
MEM_DQ8
MEM_DQ9
MEM_DQ14
MEM_DQ11
MEM_DQ12

MEM_DQS1

MEM_DQS0

MEM_VR EF

C5101

100N 16V

MEM_DQ1 RDQ1
MEM_DQ2 RDQ2
MEM_D Q3 RDQ3

MEM_DQ4 RDQ4

MEM_DQ5 RDQ5

MEM_DQ6 RDQ6

MEM_DQ7 RDQ7

RDQS0MEM_DQS0

RDQS0 12

RDQM0MEM_DQM0

RDQM0 12

RDQM1MEM_DQM1

RDQM1 12

RDQS1MEM_DQS1

RDQS1 12

MEM_DQ8 RDQ8

MEM_DQ9 RDQ9

MEM_DQ10 RDQ10

MEM_DQ11 RDQ11

MEM_DQ12 RDQ12

MEM_DQ13 RDQ13

MEM_DQ14 RDQ14

MEM_DQ15 RDQ15

MEM_WE#

MEM_CAS#

MEM_RAS#

MEM_CS#

MEM_BA0

MEM_BA1

MEM_RA10 RA10

MEM_RA4

MEM_RA5

MEM_RA6

MEM_RA7

MEM_R A12

MEM_R A11
MEM_RA9
MEM_RA8

MEM_RA0

MEM_RA1

MEM_RA2

MEM_R A3

MEM_RCLK0

MEM_RCLK0#

RP5102

5
6
7
8

22OHM1/16W

RP5103

5
6
7
8

22OHM1/16W

RP5104

8
7
6
5
22OHM1/16W

RP5105

5
6
7
8

22OHM1/16W

RP5106

5
6
7
8

22OHM1/16W

R5111

100R 1/16W 1%

R5113

22R 1/16W 5%

R5114

22R 1/16W 5%

R5112

22R 1/16W 5%

RWE#

4

RCAS#

3
2
1

4
3
2
1

1
2
3
4

4
3
2
1

4
3
2
1

RRAS#

RCS#
RBA0
RBA1

RA4
RA5
RA6
RA7

RA12
RA11
RA9
RA8

RA0
RA1
RA2
RA3

RCLK0

RCLK0#

RCKEMEM_CKE

RWE# 12
RCAS# 12
RRAS# 12

RCS# 12
RBA0 12
RBA1 12

RCLK0 12

RCLK0# 12

RCKE 12

RDQ[15..0] 12

RA[12..0] 12

2K10 ATV MT8222 DDR2

T P V ( Top Victory Electronics Co . , Ltd. )

<

絬隔瓜絪腹

絬 隔 瓜 絪 腹

Key Component

Date

>

13: DDR2 MEMORY

OEM MO DEL
TPV MODEL

PCB NAME

<Title> B
<Doc>

Sheet

of

13 19Monday, J anuary 11, 2010

Size
Rev

称爹

称爹

>

<

36

C5201

47uF 25V

PANEL_VCC

+

RXE4+12
RXE3+12

RXEC+12

RXE2+12
RXE1+12
RXE0+12

RXO4+12
RXO3+12

RXOC+12
RXO2+12

RXO1+12
RXO0+12

R5201

10K(NC)

PANEL_HIGH

R5202

2K7 OHM 1/16W 5%

PANEL_HIGH

RXE4+
RXE3+ RXE3-

RXEC+

RXE2+
RXE1+
RXE0+

RXO4+
RXO3+

RXOC+
RXO2+
RXO1+
RXO0+

C5406

100N 16V

39
37
35
33
31
29
27
25
23
21
19
17
15
13
11

9
7
5
3
1

41 42

CN4201

40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2

60949(NC)

PANEL_VCC

RXE4-

RXEC-

RXE2­RXE1­RXE0-

RXO4­RXO3-

RXOC-

RXO2­RXO1­RXO0-

RXE4- 12
RXE3- 12

RXEC- 12
RXE2- 12

RXE1- 12
RXE0- 12

RXO4- 12
RXO3- 12

RXOC- 12
RXO2- 12

RXO1- 12
RXO0- 12

ODC

PANEL_HIGH

R5210

0 OHM(NC)

ODSEL 12

R5211

0 OHM(NC)

31

CONN

CN4205

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
3032

RXO3+ 12
RXO3- 12

RXOC+ 12
RXOC- 12

RXO2+ 12
RXO2- 12

RXO1+ 12
RXO1- 12

RXO0+ 12
RXO0- 12

R5209 0R (NC )
R5208 0R (NC )
R5207 0R (NC )
R5206 0R (NC )

PANEL_VCC

PANEL_HIGH

PANEL_HIGH

2K10 AT V MTK DDR2

T P V ( Top Victory Electronics Co . , Ltd. )

<

絬隔瓜絪腹

絬 隔 瓜 絪 腹

Key Component

Date

37

>

14: PANEL I / F

OEM MO DEL
TPV MO D E L
PCB NAME

<Title> B
<Doc>

of

14 19Monday, January 11, 2010

Sheet

Size
Rev

称爹

称爹

>

<

+5V_ON

R6101

2.2KOHM +-1% 1/16W

AIO_AUL_IN4
PC_AUL_IN6

COMP1/CVBS1_AUL_IN5

SIDE_CVBS_AUL_IN6

AIO_AUR_IN4
PC_AUR_IN6

COMP1/CVBS1_AUR_IN5

SIDE_CVBS_AUR_IN6

C6105 1UF 6V3(N C )
C6103 1U F 6V3
C6104 1U F 6V3
C6106 1U F 6V3
C6111 1UF 6V3(N C )
C6108 1U F 6V3
C6109 1U F 6V3
C6110 1U F 6V3

+5V_ON

R6125 10KOHM +-5% 1/16W

AUDIN_SEL112

+5V_ON

R6127 10KOHM +-5% 1/16W

AUDIN_SEL212

Q6101

MUN2211TIG

Q6103

MUN2211TIG

22U 10V

R6114 470K 1/ 16W 5%(N C )
R6118 470K 1/ 16W 5%
R6119 470K 1/ 16W 5%
R6120 470K 1/ 16W 5%
R6129 470K 1/ 16W 5%(N C )
R6130 470K 1/ 16W 5%
R6131 470K 1/ 16W 5%
R6132 470K 1/ 16W 5%

+5V_ON

C6119

C6123

100N 16V

U6101

74HC4052D
12
14
15
11

1
5
2
4

10

9
6
7

16

X0
X1
X2
X3

Y0
Y1
Y2
Y3

A
B

EN
VEE

VDD

C6101

R6103

2.2KOHM +-1% 1/16W

470K 1/16W 5%

R6109

13

X

3

Y

GND

8

1UF 6V3

R6110

470K 1/16W 5%

AUD_R 12
AUD_L 12

Audio input

PC_AU_IN

COMP1/CVBS1_AU_IN

SIDE_AU_IN
AIO_AU_IN

AUDIN_SEL1 AUDIN_SEL2

1
0

0
1
11

00

T P V ( Top Victory Electronics Co . , Ltd. )

絬隔瓜絪腹

>

絬 隔 瓜 絪 腹

Key Component

38

<
15: AUDIO SW

Date

OEM MO D EL
TPV MO D E L
PCB N AME

Sheet

2K10 ATV MT82 22 DDR2

<Title> B
<Doc>

of

15 19Monday, J anuary 11, 2010

Size
Rev

称爹

称爹

>

<

For Compair I/ F

R4263

+5V_ON

R4262

51KOHM +-5% 1/16W(N C )

R4234

100KOHM +-5% 1/16W(N C )

1
2
3
4

1
2

CN4405

CONN(NC)

CN4406

CONN(NC)

For I P TV BOARD COM

R541910R 1/16W 5%(N C )

RX14

TX14

TXD111,12

RXD111,12
U0TX12
U0RX12

R5403 22R 1/ 16W 5%(NC)
R5405 22R 1/ 16W 5%(NC)

RC_IR_3V311,12

LED2_STBY11,12

LED1_ON12

KEY111,12

KEY212

DC_ON_OFF11,12

R5421 10R 1/16W 5%

R5422 10R 1/16W 5%

R5423 100 OHM +-5% 1/16W
R5424 100 OHM +-5% 1/16W

ZD5403

1 3

ZD5404

BZX84-C5V6(NC)

+3V3_STBY

Q5402

RC_IR

2N7002

ZD5406

1 3

1 3

R542010R 1/16W 5%(NC)

BZX84-C5V6(NC)

BZX84-C5V6(NC)

U0RX 12

CN4402

1
2
3

ZD5405

1 3

BZX84-C5V6(NC)

U0TX 12

U0TX 12

U0RX 12

CONN

47K(NC)

C5408

10N 16V

C5401

100N 16V

+3V3_STBY

R5406

100N 16V

C5405

MT_SC L8,11,12

R5416

47K(NC)

C5407

10N 16V

R5404 4.7 OHM +-5% 1/16W
R5408 4. 7 OH M +-5% 1/16W

LIGHT_SENSOR12

MT_SD A8,11,12

TXD111,12

RXD111,12

R5414 100R 1/ 16W 5%

R5407 100R 1/ 16W 5%

R5426 10R 1/ 16W 5%(N C )

R5427 10R 1/16W 5%(N C )

R5425 10R 1/16W 5%(N C )

R5428 10R 1/16W 5%(N C )

C5403

100N 16V(NC )

RC_IR

Q4213

2N7002(NC)

R5415 100R 1/16W 5%

R5417 47 OH M 1/16W

+3V3_STBY

+5V_STBY

C5402

100N 16V

10KOHM +-5% 1/16W(N C )

R4265

10KOHM +-5% 1/16W(N C )

Q4212 2N7002(NC)

+24V

+12V

Q4211

2N7002(NC)

R4264

10KOHM +-5% 1/16W(N C )

FB4222

1 2

120R/6000mA(NC)

FB4223

1 2

120R/6000mA(NC)

For Keypad and IR Board

CN4403

1
2
3
4
5
6
7
8

9
10
11
12
13

CONN

T P V ( Top Victory Elec t ronic s C o . , Ltd. )

絬隔瓜絪腹

>

絬 隔 瓜 絪 腹

Key Component

39

<

16: KEY, IR , & Compair I/F

Date

OEM MO D E L
TPV MODEL
PCB NAME

Sheet

2K10 ATV MT8222 DDR2

<Title> B

<Doc>

of

16 19Wednesday , January 27, 2010

Size
Rev

称爹

称爹

>

<

+24V_SW

1 2

FB6201

120R/3000mA

C6202

1U 50V

+5V_ON

R6206

0R05 1/10W (N C )

IN3OUT

R6208

0R05 1/10W (NC )

1

U6202

GND

L78L05ACU-TR

2

OPS_5V

+

C6201

470UF 10V

C6204

10uF 10V

+5V_ON

R6202

100R 1/10W 5%

ZD6201

BZX84C3V6

1 3

R6205

470 OHM +-5% 1/10W

R6203

1K8 1/10W 5%

Q6201

BC847C

Q6203

MUN2211TIG

R6219

10KOHM +-5% 1/16W

OP_MUTE12

AC_OFF 12

R6204

100R 1/10W 5%

R6207

1.8KOHM +-5% 1/10W

D6201 LS4148

D6202 LS4148

C6203

100N(NC)

R6216

10KOHM +-5% 1/16W

POP_MUTE

Q6202

BC847C

POP_MUTE 7,18

C1P

SVss

VDD

OUTL

OUTR

C6211

47pF 50V

C6208

1UF 6V3

12
11
10

OPS_5V

C6213

1U 25V

C6205

10uF 10V

R6211

10 OHM +-5% 1/10W

R6214

10 OHM +-5% 1/10W

HP_LOUT 6

AUD_LOUT 18
AUD_ROUT 18

HP_ROUT 6

T P V ( Top Victory Electronics Co . , Ltd. )

<

絬隔瓜絪腹

絬 隔 瓜 絪 腹

Key Component

Date

>

17: AUD IO BU F FER

OEM MO D E L
TPV MO D EL

PCB NA ME

Sheet

2K10 ATV MT8222 DDR2

<Title> B

<Doc>

17 19Monday , J anuary 11, 2010

of

Size
Rev

称爹

<

称爹

>

C6206

1UF 6V3

1

2

3

C1N

4

POP_MUTE

R6209 10R 1/ 16W 5%

MAIN_AOL12

MAIN_AOR12

C6207

1U 6V3

C6215

1U 6V3

R6210

10KOHM +-5% 1/16W

C6209

1N8 50V(NC )

R6212

10KOHM +-5% 1/16W

C6210

1N8 50V(NC )

10KOHM +-5% 1/16W

R7518

10KOHM +-5% 1/16W

R7519

PVss

5

SHDN

6

IN_L

U6201

MAX9728AETC+

PGND

SGND

IN R

9

7

8

R6213 30KOH M 1/16W +/-5%

C6212 47pF 50V

R6215 30KOH M 1/16W +/-5%

40

470 OHM 1/10W(N C )

AUD_LOUT17

AUD_ROUT17

+24V_SW

R6323

330 OHM 1/10W (N C )

ZD6302

BZX84-C20(NC)

1 3

R6315

R6146 10OHM1/16W

R6139 10OHM1/16W

1 2

120R/6000mA

+

C6320

470uF 35V

R6316

47K 1/10W( N C )

Q6306

BC847C(NC)

FB6303

AMP_GAIN112

C6140

33P 50V(NC)

C6138

33P 50V(NC)

+24V_AMP

+5V_ON

R6325

1.8K OHM 1/ 10W 5%

R6324 10OHM1/16W

Q6304

BC847C(NC)

C6120 2.2U10V

C6132 2.2U10V

+3V3

R6144 10K(NC)R6145 0R(NC)

R6143 0R(NC)

R6142 10K(NC)

POP_MUTE7,17

AMP_EN12

D6203

LS4148

AMP_GAIN012

+24V_AMP

C6133

47UF 50V

C6137

R6157

6K8 1/10W 1%

D6204

LS4148

C6135

2.2U10V

R6148

10 OHM 1/4W

+

C6139

100N 50V

R6156

1U 25V

3.32KOHM +-1% 1/10W

C6136

2.2U10V

1

2

3

4

5

6

7

8

9

10

11

12

13

14

U6301

SDZ

FAULTZ

LINP

LINN

GAIN0

GAIN1

AVCC

AGND

GVDD

PLIMIT

RINN

RINP

NC

PBTL

TPA3110D2

Ther m a l P a d

PVCCL

PVCCL

BSPL

OUTPL

PGND

OUTNL

BSNL

BSNR

OUTNR

PGND

OUTPR

BSPR

PVCC

PVCC

29

28

C6126

100N 50V

27

C6129

100N 50V

26

C6130

220N 25V

25

24

23

22

C6134

220N 25V

21

C6152

220N 25V

20

19

18

17

C6153

220N 25V

16

100N 50V

15

100N 50V

C6154

C6155

+24V_AMP

+

R6140

10OHM1/16W

R6149

10OHM1/16W

R6147

10OHM1/16W

R6141

10OHM1/16W

+24V_AMP

+

C6128

470uF/50V

C6131

1N 50V

C6156

1N 50V

C6157

1N 50V

C6158

1N 50V

C6127

470uF/50V

AUD_PWR_SW11,12

FB6106 120R/6000mA(NC)

FB6107 120R/6000mA(NC)

FB6108 120R/6000mA(NC)

FB6109 120R/6000mA(NC)

12

L6101

47uH

C6159

12

L6102

47uH

C6160

12

L6103

47uH

C6161

12

L6104

47uH

C6162

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

Q6303

LOUT+

C6150

1000PF50V(NC)

LOUT-

C6142

1000PF50V(NC)

ROUT-

C6141

1000PF50V(NC)

ROUT+

C6149

1000PF50V(NC)

<

絬隔瓜絪腹

>

18: AUDIO/AMP

+3V3

R6303

47K(NC)

MUN2211TIG(NC)

330N 50V

330N 50V

330N 50V

330N 50V

R6301

56K(NC)

R6304

18K(NC)

1
2
3
4

CN6101

CONN

+24V

R6302 470K(NC)

C6301

470N(NC)

Q6302

10KOHM +-5% 1/10W

MUN2211TIG(NC)

OEM MO D EL
TPV MOD EL
PCB NAME

Sheet

FB6301

1 2

120R/6000mA

Q6301

2
3
4 5

81
7
6

SI4835DDY(NC)

C6303

+

R6305

2K10 ATV MT8222 DDR2

<Title> B

18 19Tuesday , January 19, 2010

of

10UF/50V

C6302

100N 50V

D6301

S3D

Size
Rev

称爹

+24V_SW

称爹

>

<

41

CN7101

CONN

+5V_STBY

C7123

47uF 25V(NC)

+5V

1
2
3
4
5
6
7
8
9
10
11
12
13

+

C7124

4U7 10V(N C )

15KOHM +-5% 1/10W

5V_PWR_SW11,12

MUN2211TIG

FB7116

1 2

120R/6000mA

C7153

47uF 25V

C7102

R7147

100N 50V

2K 1/10W 5%

FB7101

120R/6000mA

+

IN
GND
EN

LS4148(NC)

MUN 2211TIG

C7160

10U 6V3

+12V

C7142

470UF 10V

R7126

D7106

Q7107

1 2

1 2

FB7108

120R/6000mA

U7101

TPS62203DBVRG4(NC)
1
2
3

15KOHM +-5% 1/10 W

+3V3_STBY

R7129

Q7108

R7144 10KOHM +-5% 1/1 0W
R7139 10KOHM +-5% 1/1 0W

100N 16V

+

C7149

+5V_ON

C7108

470uF 25V

STANDBY 11,12

SW

+5V_STBY

+5V_STBY

R7121

1K 1/10W 5%

Q7101

BC847C

C7107

4U7

+

C7110

100N 50V

+5V_STBY

C7115

100N 50V

L7101

5

35uH(NC)

4

FB

0 OHM +-5% 1/16W ( N C )

100K(NC)

R7130

100K 1/10W 5%

R7140

10KOHM +-5% 1/10W

R7103

47K 1/10W 5%

R7145

470R 1/10W 5%

R7104 1KOHM +-5% 1/10W
C7122

10N 50V(NC)

FB7107

1 2

120R/6000mA

R7119

R7120

FB7117

8
7
6
5

C7125

33P(NC)

C7129

180P 50V(NC )

120R/6000mA

Q7106

SI4835DDY

2
3
4 5

C7137

47N 16V

GND

VEN

ADJ

POK
VPP
VIN

TH1

9

VO
VO

INVERTER_ON_OFF 12

BRIGHTNESS_PWM 12

+24V

+

C7113

C7112

470uF 35V

100N 50V

+3V3_STBY

100N 16V(NC)

C7127

C7126

10uF 10V(NC)

+5V

12

FB7112

120R/6000mA(NC)

1 2

81

1 2

7

FB7113 120R/6000mA

6

R7146

10KOHM +-5% 1/10W

1

R7142 4K7 OHM 1/10W 1%

2
3
4

R7141

1K5 1/10W 1%

1 2

+

C7128

47uF 25V(NC)

+5V_ON

FB7118

120R/6000mA

C7159

100N 16V

+3V3

+3V3U7106 G973-120ADJF11U

D7101

S1D-E3

+

C7158

47uF 25V

+5V_ON

FB7102

1 2

120R/6000mA

PANEL_PWR_CTL12

+5V

+3V3

C7103

100uF 10V

+12V

1 2

120R/6000mA(NC)

47uF 25V(NC)

MUN2211TIG(NC)

FB7114

1 2

120R/6000mA

C7138

470UF 10V

FB7103

120R/6000mA(NC)

1 2

+

C7104

100N 25V

22R 1/10W 1%

FB7119

+

C7151

+3V3

R7122

15K(NC)

Q7105

+

C7140

100N 25V

U7102 G9084T43U

VIN3VOUT

ADJ

1

R7110

R7107 100R 1/ 10W 1%

R7108

22R 1/10W 1%

C7133

100N(NC)

R7114

100K(NC)

C7132

Q7104

MUN2211TIG(NC)

100N(NC)

R7132

100K 1/10W 5%

C7143

100N 25V

+3V3

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

DDRV

2

C7105

100N 25V

C7134

100N(NC)

R7111

3K(NC)

3KOHM +-5% 1/10W

R7133

C7141

100N 25V

FB7110

1 2

120R/6000mA

C7144

100uF 10V

<

絬隔瓜絪腹

>

19: DC-DC POWER

R7134

+

+

C7106

470UF 10V

PANEL_PWR_CTL12

12K 1/10W 1%(NC )

R7118

AME5106AIHAADJZ(NC)

R7116

2K2 1/10W 1%(NC )

C7139

100N 25V

820R 1/10W 1%

1

FB

2

EN

3

OCSET
IN4SW

AME5106AIHAADJZ

R7137

2K2 1/10W 1%

U7104 G912T63U

C7148

100N 50V

120R/3000mA

3K3 1/10W 5%

MUN 2211TIG

C7135

100N(NC)

U7103

1

FB

GND

2

EN

GND

3

OCSET
IN4SW

R7135

5.1KOHM +-5% 1/10W

U7105

8

GND

7

GND

6

SW

5

VI3VO

GND

1

OEM MO D EL
TPV MOD E L

PCB NAME

Sheet

+12V

R7105

Q7103

R7115

5K1(NC)

8
7
6

SW

5

L7104

35uH

1 2

2

<Doc >

+5V_STBY

12

FB7109

LS4148(NC)

ZD7103

SSA34

100N 25V

C7145

100N 50V

<Title> B

19 19Monday, J anuary 11, 2010

12

FB7104

120R/3000mA(NC)

Q7102

2
3

D7107

4 5

ZD7101

SSA34(NC)

C7136

100N(NC)

AV12

+

100uF 10V

SI4835DDY

1 2

120R/6000mA

+

C7147

470uF 10V

C7150

FB7115

R7106

100K 1/10W 5%

C7111

100N 50V

L7103

35uH(NC)

1 2

C7146

2k10 ATV MT8222 DDR2

of

81
7
6

FB7111

1 2

120R(NC)

+

C7152

470UF 10V(N C )

DV10

FB7105

120R/6000mA

R7109

10KOHM +-5% 1/10W

C7109 100N 50V

PANEL_VCC

R7117

10K 1/10W 5%(NC )

R7138

10KOHM +-5% 1/10W

Size
Rev

<

称爹

称爹

PANEL_VCC

12

>

42

5.2 电源板 32 寸
715G3811

FB901

1 2

BEAD

C910
1uF/520V

R910
NC

VCC

C913

+

C914

0.1uF 50V
47uF/50V

1

BD901

+

KBJ408G

D901

3

1N4007-E3/73

!

-

4

1M5 1/4W 1%

L902

!

124

13mH

C904C902

C903
680pF

!

R902

!

R903
330K 1/4W

!

L901

!

124

13mH

!

RV901
varistor

!

CN904

3

SOCKET

330K 1/4W

!

!

2

CN903

2

N

1

L

CONN

3

!

680pF

!

330K 1/4W

R901

!

3

C901

12

NR901
NTCR

t

F901

5A 250V

1 2

!

R904

126

8

R911
20K 1/4W

R917
15K 1/8W

1M5 1/4W 1%

ACD

B+_390V

1M5 1/4W 1%

82K 5%

C916
NC

R9101

1M5 1/4W 1%

R9102

1M5 1/4W 1%

R9103

MTZJ T-72

R9104

5

7

56P 50V

R905

ZD9101

D904

IN5408

L906

310uH

!

1R 1/8W 5%

R932

C912

R912
NC

6

5

8

7

ZCD

VCC

GND

GATE

IC901
FAN6961SZ

INV1COMP2MOT3CS

4

R918

10KOHM +-5% 1/8W

C917
47N 50V

1M5 1/4W 1%

1MOHM +-1% 1/4W

1M 1/4W 1%

1M 1/4W 1%

13K 1/8W 1%

ALL NC

12

10KOHM +-5% 1/8W

51K +-5% 1/8W

R909

R924

R925

R926

R985

R9105

D902

FMY-1106S

D907

IN5408

D905
1N4148

10 OHM +-5% 1/6W

R913

R914

10KOHM +-5% 1/8W

R915
470 OHM 1/4W

C915
220P 50V

C918

0.47uF 50V

C921

0.1uF 50V

B+_390V

C943
47N 50V

10KOHM +-5% 1/8W

10KOHM +-5% 1/8W

100K 1/8W

R9106

R906
560K 1/8W 1%

R941
NC

FB

NC

R9107

R9108

R9109

Q9101
2N3904S-RTK/PS

C919
NC

R942

Q901
2SK4101LS

!

R916

0R12 5% 2W

IC903

1

BNO

2

COMP

3

NC
CS4GND

LD7523GS

VCC

IC9101

1

2 3

EL817M(X)
Q9102

2N3906S-RTK/PS

R919
NC

10KOHM +-5% 1/8W

OVP
VCC
OUT

+5V

!

R801

R947

8
7
6
5

C944
220P 50V

4

R9110

16.2K +-1% 1/4W

R9111
33K +-1% 1/4W

!

C920

+

100uF M 450V

R920
680K OHM +-1% 1/4W

VCC

R921
680K OHM +-1% 1/4W

R922
680K OHM +-1% 1/4W

R923
13K 1/8W 1%

B+

VCC

C942
100N 50V

R933

1R 1/4W 5%

R945

1K 1/4W

ACD

FB902

1 2

BEAD

100K 1/4W

C935

0.1NF2KV

D940

PR1007

C941

+

10uF/50V

D906
1N4148

R943

10OHM +-5% 1/8W

R948

0.1 ohm

C925
10NF1KV

+

C937
10uF/50V

MTZJ T-72 16B

R996

R998

100K 1/4W

!

R944
10KOHM +-5% 1/8W

ZD930

100K 1/4W

100K 1/4W

1 2

C907
100N 50V

R997

R999

Q903
2SK4101LS

R946
0R36 5% 2W

!

C905

470pF/250V

B+_390V

B+

Q921

KTD1691/P

C939
10N 50V

5

4

3

B+

R939
10K 1/4W

3
2
1

2.2 OHM 1/4W
R908

!

T902

POWER X'FMR

FB

IC970
EL817M(X)

R962

4.7M OHM +-5% 1/4W

IC902

FB/OLP4VCC
GND
BR

D/ST

S/OCP

D/ST

A6069H

R907

2.2 OHM 1/4W

9

8
10

11

R974
1K 1/4W

1234

!

R976

10K 1/4W

IC971
AS431AZTR-E1

10uF/50V

5
7

8

C933

+

R973
100 OHM 1/4W

R970

100 OHM 1/4W

D973

3

YG865C10RSC

2

1

3

1

R977

100 OHM 1/4W

R951

100 OHM 1/4W

R975
3K9 +-5% 1/8W

C976

330N 50V

C924

0.001uF/250V

100K 1/4W

C932

0.1NF2KV
R992

100K 1/4W

D930

PR1007

D903

1N4148

C908
100N 50V

D972

YG865C10R SC

2

R991

C957

1N 500V

100K 1/4W

100K 1/4W

C934
100N 50V

C970

1N 500V

+

C973
470uF 35V

C952

1N 500V

1.8K 1/4W

FB903

1 2

BEAD

R993

R994

D931

AU02Z

R986

470pF/250V

C972

1N 500V

+

C906

R931

2.2 OHM 1/4W

C931

+

C945
470uF 35V

L980

L

L951

L

R965

1.8K 1/4W

1

2

3
4

5

T901

POWER X'FMR

!

IC950
EL817M(X)

C909
1N 50V

+

C975
470uF 35V

+

C946

R967

1.8K 1/4W

R980
NC

!

6
7

9
10

1234

1.8K 1/4W
R971

1.8K 1/4W

R978

R979
2KOHM +-1% 1/8W

47 OHM 1/4W

R954
100 OHM 1/4W

C955
220N 50V

1K 1/4W

IC952

AS431AZTR-E1

R988

R950

R952

3

1

R956

47 OHM 1/4W
D950

SBT15006JST

2

R955
1K 1/8W

R987
27K 1/8W 1%

R959
NC

R972

1.8K 1/4W

6.8K 1/4W

C950
1N 500V

C951

L950

1N 500V

L

R957
8K2 1/8W 1%

R958
7K5 1/8W +/-1%

+24V

+12V

6.8K 1/4W

C954

+

470uF 16V

R960
1K 1/4W

IC951
EL817M(X)

1234

!

Q950
PMBS3904

ZD970

+24V

MTZJ T-72 30B

ZD952

+12V

MTZJ T-72 15B

A5V

Q970
PMBS3904

R968

R969

6.8K 1/4W

C953

+

330uF 16V

A5V

C949
100N 50V

C948
100N 50V

R966

12

12

6.8K 1/4W

C956
100N 50V

R984

D971

1N4148

D951

1N4148

1K 1/8W

C947
100N 50V

R983

R961

10KOHM +-5% 1/8W

R963

10KOHM +-5% 1/8W

C978
100N 50V

+5V

R981

100OHM +-5% 1/8W

R982
1K 1/8W

PS_ON

CN902

1
2

ON/OFF

3

PDIM

4

+12V

5
6
7
8

+24V

9

10

PS_ON

11
12

+5V

13

ACD

CONN

Title

<Title>

Size Document Number Rev

<Doc> <RevC ode>

Custom

Date: Sheet

43

of

11Friday, J anuary 29, 2010

电源板 42_46 寸
715G3885

BD901
42" : TS10P06G
46" : TS15P06G

BD901
TS10P06G

2

C904 0.47uF

! !

C901
680pF

C903 0.47uF

R901

330K 1/4W

330K 1/4W

RV901 NC

!

CN901
SOCKET

NOTES:
This schematic,we can not guarantee the accuracy of this information,
after the date of publication and disclaims liability for changes ,
errors or ommissions.

HS2

HEAT SINK (D911)

1
2

HS5

HEAT SINK (Q902,Q903)

1
2

1

+

-

4

2

3

1

4

2

3

1

4

2

3

1

4

R902

!

3

3

L903

20.0MH

!

!

L902

2.0MH

!

C906
680pF

L901

20.0MH

!

R903
330K 1/4W

12

033G8105 3A X *2

HEAT SINK (IC901)

HEAT SINK (D903,D 906,D 907)

BO

12

t

CN902
CONN

2

N

1

L

R941

22 OHM 1/4W

5K1 +-5% 1/8W

NR901
NTCR

F901
FUSE

HS3

1
2

HS6

1
2

C931
1uF/520V

R932

0.1 OHM 3W

R934

0.1 OHM 3W

R940
20K +-5% 1/8W

R943

C940
10N 50V

R904

0.1 ohm

B+

!

R909

30K 1/8W 1%

!

HS4

HEAT SINK (Q901)

1
2

FB903
BEAD

1 2

C902

!

470pF/250V

1 2

FB904
BEAD

D909 1N5408-P

1212

11

!

L906
600uH 10%

12

VCC1

+

C936

47uF 25V

IC906
ICE2PCS02G

1

GND

2

ICOMP

3

ISENSE
VINS4VCOMP

C941

C942

1N 50V

4N7 50V

R905

2Mohm 1/4W +/-1%

R906

2Mohm 1/4W +/-1%

R907

2Mohm 1/4W +/-1%

C908

10uF/50V

C907
1N 50V

HS1

HEAT SINK (BD901,D 901)

1
2

1211

GATE

VSENSE

C926
1N 50V

L908
600uH 5%

C937
100N 50V

VCC

+

100N 50V

VCC1

C909

51OHM +-5% 1/8W

8
7
6
5

C938

0.47uF 50V

0.47uF 50V

1K 1/8W 1%

FB905

BEAD

1 2

1 2

FB901

BEAD

R933

R942

51K +-5% 1/8W

C914

R921

D910

1N4148

R936

33 OHM 1/8W

C939
1U25V

VCC1

2Kohm 1/4W +/-5%

FB

IC904

SSC9502S

1
2
3
4
5
6
7
8

D905 EG01A

C917

1U 25V

R922
150OHM +-5% 1/8W

!

C944

470pF/250V

!

C929

470pF/250V

D901

FMXA-1106S

1

R938

10K OHM +-5% 1/8W

R908

Vsen

NC

Vcc

NC

FB

VGH

GND

VS

Css

VB

OC

NC

RC

NC

Reg

VGL

RV9COM

C932

2

STW20NM60

3

C943
1N 50V

MTZJ T-72 15B

47OHM +-5% 1/8W

18
17
16
15
14
13
12
11
10

R919

7.5 OHM 1/4W

C919
22pF/3KV

!

C964

470pF/250V

NC

Q901

ZD902

D902

1N4148

R910

47OHM +-5% 1/8W

C916
1N 50V

1 2

R935
1M 1/4W 1%

R939
1M 1/4W 1%

R944
1M 1/4W 1%

22KOHM 1/8W +-1%

Q904
KTD1691/P

1 2

10K OHM +-5% 1/8W

C918

1U25V

D904
1N4148

R916

C920

22pF/3KV

FB902

BEAD

C905

10NF1KV

R945

R946

1K OHM +-5% 1/8W

R975

0R051/8W

R911

12

ZD901

MTZJ T-72 15B

R976

0R051/8W

10K OHM +-5% 1/8W

R931
1K2 /8W 1%

43

IC905

EL817MA

Q903

STP10NK60ZFP

Q902

STP10NK60ZFP

R917

C924

100PF 2KV

24K 1/8W 1%

4.7uF 50V

+

BO

!

R925

C928

C933
100uF M 450V

620K 1/8W 1%

Vcc

R947

220OHM +-5% 1/8W

12

Q905

PMBS3904

+

B+

1 2

+

C934
100uF M 450V

R958

1M5 1/4W 1%

R961

1M5 1/4W 1%

R964

1M5 1/4W 1%

R967

3
4

6
7

C915

0.033uF 5% 1000V

C927

100N 50V

FB906
BEAD

C933,C934
42" : 82u
46" : 100u

C960

220N 50V

5V

R949

2K +-5% 1/8W

!

T902

POWER X'FMR

R950

4.7 OHM 1W

R963

4.7M OHM +-5% 1/4W

12

9
8

14

11
10

13

FB

R923
0R05OHM1/8W

IC902

EL817MA

!

R968
1R2 5% 2W

2K7 +-5% 1/8W

C945
100N 50V

3

1

43

C948
NC

IC901

1
2
3

A6069H

R948

D906
SBT15006JST

2

12

B+_1

S/OCP
BR
GND
FB/OLP4VCC

+

R924
4K7 1/8W 1%

IC903
AS431AZTR-E1

R951

100K /4W

R953

100K /4W

D/ST
D/ST

C955

100N 50V

PS_ON

3

1

3

1

C921
1000uF25V

R926
3K 1/8W +/-1%

100N 50V

SARS01-V1

8
7

5

4N7 50V

D903
V40100C-E3/4W

2

C910

1000UF 35V

2

D907
V40100C-E3/4W

L905

3.5uH

C930

R952
100K /4W

R954
100K /4W

D913

+

C958
10uF/50V

C959

+

D920

1N4148

Q907

PMBS3906

R929
5K1 1/8W 1%

D916
1N4148

+

C922
470UF/25V

R955

3.3 OHM 1/4W

D914
PR1007

ZD906
MTZJ T- 7 2

C911

1000UF 35V

+

C946

0.1NF2KV

C947

0.1NF2KV

+

Vcc

C956
100uF/50V

1 2

L904

3.0uH +-10%

470UF M 35V

C923
100N 50V

R937
33K 1/8W 5%

C925
220N 50V

NC

!

T901

1

POWER X'FMR

6

2

7
9

3

10

4

5

C954

NC

12

43

IC907

EL817MA

!

R912,R913,R914,R915

5.1K 1/4W

+

R912

C912

R928
56K 1/8W +/-1%

R930
2KOHM +-1% 1/8W

T P V ( Top Victory Elec t r onic s C o . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

R962
220R 1/8W 5%

R970

2K 1/8W 5%

IC908
AS431AZTR-E1

R913

12V

3

D911
SBT15006JST

2

1

R956

47 OHM 1/4W

R957

47 OHM 1/4W

R966
1K OHM +-5% 1/8W

C961
220N 50V

R914

R915

R918

3K3 +-5% 1/8W

R920

3K3 +-5% 1/8W

24V

R927
20K5 1/8W 1%

G3196-1-X-X-2-090424

02.Adapter

C949

2N2 500V

R965
2K4 1/8W 1%

R971
2K2 1/8W 1%

L907

3.5uH

+

+

C950

C951

330uF 16V

1000uF 16V

ZD905

ZD903

NC

MTZJ T-72 27B

1 2

1 2

D919

D917

NC

1N4148

Q906
PMBS3904

C963
100N 50V

24V

C913
1U 50V

12V

PS_ON

5V

CN904

1
2
3
4
5
6
7
8

9
10
11
12
13

CONN

24V

OEM MOD E L Size
TPV MODEL

ADTV82421AAD J

PCB NAME

715G3885

Sheet

of

12Monday, January 18, 2010

C952
100N 50V

24V

ZD904
MTZJ T-72 15B

1 2

D918
1N4148

R969
100OHM +-5% 1/8W

R972
1K OHM +-5% 1/8W

CN903

1
2
3
4
5
6
7
8

9
10
11
12
13

CONN

CN905

1

2

3

4

5

6

7

8

9
10
11
12

CONN

5V

12V

Custom

Rev

称爹

称爹

>

<

44

5.3 升压板 32 寸

B+_390V

PDIM

R801

R830

240K 1/8W 5%

R831

150K 1/8W 5%

R801 0.1 ohm

ON/OFF

DR1

SCS0520P

R845 NC

R846

1MOHM +-5% 1/4W

C812
1N 50V

D801

62K 1%

C805

2.2uF 25V X7R

1 2

DR2

R832

1 2

C813
330P 50V

NC

T802

1 9

POWER X'FMR

D802

SCS0520P

+12V

R834

!

R833

3.3M 1/4W

54

7
10

C814
4N7 50V

D803

SCS0520P

D804

SCS0520P

R803

100OHM +-5% 1/8W

R835

NC

12

R802
100R 1/8 W 5%

12

10KOHM +-5% 1/8W

C810

+

DR1

R814
51OHM +-5% 1/8W

R816
10KOHM +-5% 1/8W

Q802AOTF12N50

R817

C803

0.001uF/1KV

C811
100N 50V

IC801

1

DRV1

2

GND

3

ZCS

4

RT1

5

CT

6

LCT

7

PDIM

SSTCMP

VSEN8ISEN

OZ9976GN-C-0-TR

!

DRV2
VREF

TIMER

!

Q801
AOTF12N50

C804

VIN

ENA

ADIM

0.001uF/1KV

16
15
14
13
12
11
10
9

ISEN

C801

1uF/450V

C802

1uF/450V

22N 50V

C815

DR2

6

6

POWER X''FMR

ENA

T803

POWER X'FMR

T801

!

VREF

R840
1M5 1/8W 5%

C816

1U 25V

11

71

7

111

R841

51K +-5% 1/8W

CN801

1

L

2

N

CONN

10K 1/4W

R839

100K 1/4W

C817
1U 25V

51K +-5% 1/8W

R838

R842

C818

4N7 50V

C819

2.2uF 25 V X7R

CN803

CONN

5

VS

4

IS1

3
2

IS2

1

C824
NC

D807

2

3

1

BAV70

R810

NC

C822
680P 50V

R811
240 OHM +-1% 1/8W

R836

ISEN

Q804
PMBS3904

Q805
PMBS3904

1K 1/4W

1M 1/8W

Q803
RK7002FD5T116

R837

C821

1N5 50V

C820

1N5 50V

VS

VREF

R820

100K 1/8W

D805

IS1

1N4148

D806

IS2

1N4148

C830
47N 50V

C831
47N 50V

R821

68K +-5% 1/8W

R824

68K +-5% 1/8W

R823

1M 1/8W

R826

1M 1/8W

R843

1.2K 1/4 W

R844

9.1KOHM +-1% 1/8W

45

R812
NC

R825

510 OHM +-1% 1/4W

R827

510 OHM +-1% 1/4W
C823
680P 50V

R813
240 OHM +-1% 1/8W

Title

Size Document Number Rev

B

Date: Sheet of

IS1

IS2

<Title>

<Doc> <RevCode>

11Wednes day , J anua ry 20, 20 10

5.4 按键板
715G3838

POWER

C0103

100N 25V

SW0107

TACT SW FWRD H1.5MM

CN0101

CONN

Menu

VOL+

65

1
2
3
4

KEY 2
KEY 1

C0102

100N 25V

C0101

100N 25V

VOL-

CH-

CH+

INPUT

R0103

5K6 +-5% 1/8W

R0104

470OHM +-5% 1/8W

R0105

2K2 +-5% 1/8W

R0101

5K6 +-5% 1/8W

R0102

470OHM +-5% 1/8W

R0106

2K2 +-5% 1/8W

SW0103

TACT SW FWRD H1.5MM

SW0104

TACT SW FWRD H1.5MM

SW0105

TACT SW FWRD H1.5MM

SW0101

TACT SW FWRD H1.5MM

SW0102

TACT SW FWRD H1.5MM

SW0106

TACT SW FWRD H1.5MM

<

A

称爹

>

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

02.KEY board

Wednesday , Oc t ober 14, 2009

OEM MODEL
TPV MOD EL

PCB NAME

Sheet

46

2K10 AOC key booar

of

22

Size
Rev

称爹

5.4 IR Board
715G3839

VCC_STBY

CN2001

78

CONN

R2002

1.2KOH M 1/10W

Q2002

BC847C

R2001

10K 1/10W

FB2002

600R/200mA

1 2

LED2_STBY

1
2
3
4
5
6

LED1_ON

1 2

FB2003

600R/200mA

1 2

FB2004

600R/200mA

100N 16V

C2003

1 2

FB2001

600R/200mA

VCC_STBY

C2004

100N 16V

C2005

100N 16V

R2005 3.3KOHM 1/1 0W

C2001

100P 50V

3

2

1

R2008 3.3KOHM 1/ 10W

1

G

R2003

1.2KOHM 1/10W

3

1

3

R

2

LED2001

Q2001

2

BC847C

EMI_GND

R2004

10K 1/10W

VCC_STBY

R2006

10K 1/10W

R2007

220OHM 1/10W

C2002

10uF 10V

ZD2001

BZX84-C5V1

1 3

KSM-603TM2E

3

VCC

2

GND

1

VOUT

U2001

47

OEM MODEL
TPV MO DE L

PCB N AME

Sheet

2K10 AOC I R board Knight A

22Wednes day , August 19, 2009

of

T P V ( Top Victory Electronics Co . , Ltd. )

絬 隔 瓜 絪 腹

Key Component

Date

02. IR BOAR D

Size
Rev

称爹

<

称爹

>

6. 电气方框图

HDMI1

HDMI2

USB

LVDS OUT

FOR AIO MOEL

PC INPUT

TUNER

CVBS1 &YPbPr

IPTV Board YPbPr

2nd USB

HDMI3

VGA IN

MT8222H

IIC

IIS

512Mb DDR2

WT6703F

CPU

24C64

8M FLASH

CS4344

SPDIF OUT FOR AOC AP

CVBS OUT

MAX9728

TPA3110D2
AUDIO AMP

EARPHONE

SPEAKERS

SIDE CVBS2 & S-VIDEO

AUDIO SW

MAX9728

CVBS/AUDIO OUTPUT FOR BBY/AOC AP MODEL

48

7. BOM

LC32K06M E32A22QNDWGA7NNS

Item Parts Code Description

1 705TZ93450A bezel assy

6 705TZ93451A rear cover assy

10 P33T0155AED 1T0100 KEY_CONTROL

11 Q37T0177011 2K10-32Hinge

12 Q15T0717101 BASE SUPPORT BKT UDM

13 Q15T0716201 PANEL_SUPPORT _BKT_R

14 Q15T0715201 PANEL_SUPPORT _BKT_L

15 Q15T0720101 32_VESA_BKT_TOP

16 P15T0678101 BRACKET_IO_SIDE

17 P15T0679101 BRACKET_SIDE_BTM

18 Z11G0028 1 PCB-support

19 Q02G7021 2 BOLT

20 Q02G7022 3 SCREW-STOPPER

21 0Q1G1840 8120 SCREW

22 Q45T 99609 61 EPE COVER

23 0Q1T 930 8 47 CR3 SCREW

24 0Q1T 940 8 47 CR3 SCREW

25 0Q1T 940 16 47 CR3 SCREW

26 0M1T1140 6120 SCREW 4*6MM

27 0M1T 330 6 47 CR3 SCREW

28 0M1T 940 12 47 CR3 SILICON

29 0M1T1740 16 47 CR3 screw

30 0M1T1730 8120 SCREW

31 N02T6008 1 SCREW

32 Q44GJ065624 1B CARTON

33 Q44GJ065101 CUSHION_TL

34 Q44GJ065201 CUSHION_TR

35 Q44GJ065301 CUSHION_BL

36 Q44GJ065401 CUSHION_BR

38 P52T 53002 cable tie

41 P51T 11001 GLUE JETMELT 3748-V0-TC

1050 750TVV315B6131N000 PANEL TPT315B6L01 C1C FQ TPV

1056 098GRABD1NCACD REMOTE CONTROL 90-364100T4402

1057 092TB1JX1A31GM PEONY A1KALINE LR03

1172 089G214A18N IS POWER CORD 1.8M FA37B201312180TP

1185 078G0050A01 D SPEAKER 16R 5W 125*32*35.5 L12532-0051

8801 095G179W30NA10 FFC CABLE 30P 500mm P1.0 WDK09112405

8802 095G801313DA37 HARNESS 13P-13P 100mm FQE094802HZ

8803 095G8013 4DA04 HARNESS 4P-2*(2*PAST) 500mm+230mm

8804 095G801413DA78 HARNESS 13P-6P+4P 600+700mm FQE094765HZ

8805 095G8021 3D904 HARNESS 3P-3P+2P 290mm FQE92155I

026T 800700 1A BARCODE LABEL
040T 581689 4A S/N LABEL

49

0M1T1730 6120 SCREW 3*6MM
705TZA4104A DFU ASSY
P16G0021 1 GASKET 15*60*8t
P33T0156AEDA1L0100 KEY_PLATE
P40G5000813 1A Hi-pot label
P40TD000813 9A family sheet
P45G 77001 LLDPE WRAP
Q40G2010 32003 Side lable
Q40G2010 32102 IO LABEL
Q44GJ065624 1B CARTON
Z07G0079 1 PALLET (885X1138X120mm)
Z40G 32061501A RATING LABEL
Z44G600281381A PAPER BOARD (1120x790x5t)
Z44G9505180 CARD BOARD(50*50*1800*5t)

1051 CBPFA2QDZ1 Scaler Board Assembly

C1101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1102 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1108 065G040210332K A CAP 0402 10NF 50V X7R

C1109 065G040210332K A CAP 0402 10NF 50V X7R

C1110 065G040210332K A CAP 0402 10NF 50V X7R

C1115 065G040210332K A CAP 0402 10NF 50V X7R

C1201 065G040210332K A CAP 0402 10NF 50V X7R

C1202 065G040210332K A CAP 0402 10NF 50V X7R

C1203 065G040210332K A CAP 0402 10NF 50V X7R

C1204 065G040210332K A CAP 0402 10NF 50V X7R

C1405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1502 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1604 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1608 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1610 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1701 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1702 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4107 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4109 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4202 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4205 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4208 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4210 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4211 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4212 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4213 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4218 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4220 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4223 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4225 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

50

C4228 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4231 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4232 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4234 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4240 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4241 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4242 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4243 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4244 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4245 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4246 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4247 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4248 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4251 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4253 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4256 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4263 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4266 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4268 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4269 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4272 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4275 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4277 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4279 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4280 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4281 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4282 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4283 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4284 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4285 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4286 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4287 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4291 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4293 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4294 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4295 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4297 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4298 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4301 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5112 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5113 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5114 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5115 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5402 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

51

C5406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5407 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C5408 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C6123 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C6127 067G 305471 7K EC 470uF 50V PF 10x20mm

C6128 067G 305471 7K EC 470uF 50V PF 10x20mm

C6131 065G040210232K A CAP 0402 1NF K 50V X7R

C6156 065G040210232K A CAP 0402 1NF K 50V X7R

C6157 065G040210232K A CAP 0402 1NF K 50V X7R

C6158 065G040210232K A CAP 0402 1NF K 50V X7R

C7113 067G 305471 6E EC 470uF 35V RGA 10x16mm

C7149 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C7159 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

CN1101 088G 35315F HD D-SUB CONN F ATTACHED SCREW

CN1102 088G 30265C PHONE JACK 3P GREEN

CN1203 088G 78 13 5C RCA JACK

CN1402 088G 352 21CL USB CONN TYPE A

CN1404 088G 100 11 CL MINI DIN JACK 4P+ SWITCH

CN1405 088G 78 13934 C RCA JACK 1*3 Y/W/R AV3-8.4-13-1

CN1501 088G 78 8A01 CL RCA JACK 1P YELLOW AV1-8.4-11-3

CN4205 033G801930F E JS FFC CONNECTOR 30P 1.0PITCH

CN4402 033G3802 3H WAFER 3P RIGHT ANGLE

CN4403 033G380213B Y CONNECTOR

CN6101 033G3278 4D 2.5mm Pitch Wafer

CN6404 088G 302A12 YG PHONE JACK 3.5mm 7P BLACK

CN7101 033G327813D CONNECTOR

L1601 073G 253920 H CHOKE COIL 150uH+/-10% 50mohm DR10*8

L6101 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6102 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6103 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6104 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L7104 073G 253900 H CHOKE COIL 35uH+/-10% 82mohm DR10*8

Q1502 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1601 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1602 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1604 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1605 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1606 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1701 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1702 057G 761 15 PDTC114ET SOT23

Q1704 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1705 057G 761 15 PDTC114ET SOT23

Q1708 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q4101 057G 761 15 PDTC114ET SOT23

Q4201 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q5402 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q6101 057G 761 15 PDTC114ET SOT23

52

Q6103 057G 761 15 PDTC114ET SOT23

Q6201 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6202 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6203 057G 761 15 PDTC114ET SOT23

Q7101 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q7102 057G 763912 MOSFET SI4835DDY SO-8

Q7103 057G 761 15 PDTC114ET SOT23

Q7106 057G 763912 MOSFET SI4835DDY SO-8

Q7107 057G 761 15 PDTC114ET SOT23

Q7108 057G 761 15 PDTC114ET SOT23

R1101 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1103 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1106 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1107 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1108 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN

R1110 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1111 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1113 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1114 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1115 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1116 061G04027509FT RST CHIP 75R 1/16W 1%

R1117 061G04027509FT RST CHIP 75R 1/16W 1%

R1118 061G04027509FT RST CHIP 75R 1/16W 1%

R1119 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1120 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1121 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1122 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1123 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1124 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1125 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1126 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1127 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1201 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1202 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1203 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1205 061G04027509FT RST CHIP 75R 1/16W 1%

R1206 061G04027509FT RST CHIP 75R 1/16W 1%

R1207 061G04027509FT RST CHIP 75R 1/16W 1%

R1208 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1209 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1210 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1211 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1212 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1223 061G04027509FT RST CHIP 75R 1/16W 1%

R1231 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1232 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

53

R1401 061G04027509FT RST CHIP 75R 1/16W 1%

R1402 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1404 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1405 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1406 061G04027509FT RST CHIP 75R 1/16W 1%

R1407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1408 061G04027509FT RST CHIP 75R 1/16W 1%

R1409 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1410 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1414 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1416 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1417 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1502 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1503 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1504 061G04027509FT RST CHIP 75R 1/16W 1%

R1505 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1506 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1602 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1603 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1604 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1606 061G04027509FT RST CHIP 75R 1/16W 1%

R1607 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1608 061G04027509FT RST CHIP 75R 1/16W 1%

R1609 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1610 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1612 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1613 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1615 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1623 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

R1624 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1625 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1626 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

R1701 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1703 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1704 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1705 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1706 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1707 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1708 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1710 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1711 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1712 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1713 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1714 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1715 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1716 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1717 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

54

R1722 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1723 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1724 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1725 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1731 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1732 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R2101 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4101 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4105 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4110 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4111 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4112 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4113 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4114 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4115 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4116 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4120 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4125 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4139 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4140 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R4141 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R4143 061G0402330 JT RST CHIP 33R 1/16W 5% TZAI YUAN

R4144 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4145 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4146 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4148 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4149 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4150 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4151 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4202 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4206 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

R4207 061G0402102 JT RST CHIP 1K 1/16W 5% TZAI YUAN

R4210 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4211 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4213 061G04023301FT RST CHIP 3K3 1/16W 1%

R4214 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4215 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4216 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4217 061G0603824 JT RST CHIP 820K 1/10W 5% TZAI YUAN

R4219 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4221 061G06035101FT RST CHIP 5K1 1/10W 1%

R4222 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

R4223 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4224 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4226 061G0402513 JT RST CHIP 51K 1/16W 5% TZAI YUAN

R4228 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

55

R4229 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4231 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4232 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4233 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4235 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4236 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4237 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4239 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4249 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4250 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4251 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4252 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4253 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4254 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4257 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4258 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4259 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4260 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4261 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R5111 061G04021000FT RST CHIP 100R 1/16W 1%

R5112 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5113 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5114 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5202 061G0402272 JT RST CHIP 2K7 1/16W 5% TZAI YUAN

R5404 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5408 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5414 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5415 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5417 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R5421 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R5422 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R5423 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5424 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R6101 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6103 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6109 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6110 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6114 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6118 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6119 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6120 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6125 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6127 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6129 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6130 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6131 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

56

R6132 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6139 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6140 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6141 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6146 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6147 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6148 061G1206100 JT RST CHIPR 10 OHM +-5% 1/4W TZAI YUAN

R6149 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6156 061G06036801FT RST CHIP 6K8 1/10W 1%

R6157 061G06036801FT RST CHIP 6K8 1/10W 1%

R6202 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN

R6203 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R6204 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN

R6205 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN

R6207 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R6209 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6210 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6211 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R6212 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6213 061G0402303 JT RST CHIP R 30Kohm 1/16W +/-5% TZAI YUAN

R6214 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R6215 061G0402303 JT RST CHIP R 30Kohm 1/16W +/-5% TZAI YUAN

R6216 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6219 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6305 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R6324 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6325 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R7103 061G0603473 JT RST CHIP 47K 1/10W 5% TZAI YUAN

R7104 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R7105 061G0603332 JT RST CHIPR 3.3KOHM 1/10W TZAI YUAN

R7106 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7107 061G06031000FT RST CHIP 100R 1/10W 1%

R7108 061G06032209FT RST CHIP 22R 1/10W 1%

R7109 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7110 061G06032209FT RST CHIP 22R 1/10W 1%

R7121 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R7126 061G0603153 JT RST CHIPR 15KOHM 1/10W TZAI YUAN

R7129 061G0603153 JT RST CHIPR 15KOHM 1/10W TZAI YUAN

R7130 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7132 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7133 061G0603302 JT RST CHIPR 3KOHM 1/10W TZAI YUAN

R7134 061G06038200FT RST CHIP 820R 1/10W 1%

R7135 061G0603512 JT RST CHIPR 5.1KOHM +-5% 1/10W TZAI YUAN

R7137 061G06032201FT RST CHIP 2K2 1/10W 1%

R7138 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7139 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7140 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

57

R7141 061G06031501FT RST CHIP 1K5 1/10W 1%

R7142 061G06034701FT RST CHIP 4K7 1/10W 1%

R7144 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7145 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN

R7146 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7147 061G0603202 JY RST CHIPR 2K +-5% 1/10W YAGEO

R7518 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R7519 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

RP5102 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5103 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5104 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5105 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5106 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

TH1401 061G 52902 PTC CHIP 8V 0R4 KMC4S075RY

TU1601 094GNPAL MN 3G TUNER NTSC+PAL TAFT-Z716D

U1101 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U1702 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U1703 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U4106 056G 615 67 IC NT5TU32M16CG-25C 512MB BGA-84

U4201 056G 562312 IC Scaler MT8222AHMU/B LQFP256

U4202 056G 643906 IC APX809-26SAG-7 SOT23

U4203 056G 638601 CS4344-CZZ

U6101 056G 614 1 74HC4052D S016 PHLIPS

U6201 056G 616916 IC MAX9728AETC+ TQFN-EP-12

U6202 056G 133902 IC L78L05ACU-TR SOT-89

U6301 056G 616 54 IC TPA3110D2 15W TSSOP-28

U7102 056G 563 93 IC G9084T43U TO-252

U7104 056G 563146 IC G912T63U 1A/1.2V SOT-223

U7105 056G 563956 IC AME5106AIHAADJZ SOP8

U7106 056G 563962 IC G973-120ADJF11U SOP-8

1052 ADTV92414AAW ADAPTER BOARD G3811-P01-X-X-1-100319

BD901 093G 50460925 BRIDGE DIODE TS6B06G-01 KBJ

C801 063G213J105GFC CAP MPE 1UF J 450V

C802 063G213J105GFC CAP MPE 1UF J 450V

C803 065G 1K1021AT CK45-R3AD102K-NR 1000PF / 1KV R-type P

C804 065G 1K1021AT CK45-R3AD102K-NR 1000PF / 1KV R-type P

C805 065G080522522K T CAP CHIP 0805 2.2UF K 25V X7R

C810 067G215A1017KT EC 100uF 50V 8*12mm

C811 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C812 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%

C813 065G080533131J A MLCC 0805 330pF 50V NPO +/-5% SAMSUNG

C814 065G080547232K Y CAP CHIP 0805 4700PF K 50V X7R

C815 065G080512332K Y CAP CHIP 0805 12N 50V X7R +/-10%

C816 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

C817 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

58

C818 065G080547232K A CAP CHIP 0805 4700pF K 50V X7R

C819 065G080522522K T CAP CHIP 0805 2.2UF K 25V X7R

C820 065G080515232K A CAP CHIP 0805 1500pF K 50V X7R

C821 065G080515232K A CAP CHIP 0805 1500pF K 50V X7R

C822 065G080568131J Y CAP CHIP 0805 680PF J 50V NPO

C823 065G080568131J Y CAP CHIP 0805 680PF J 50V NPO

C830 065G080547332K A CAP CHIP 0805 47nF K 50V X7R

C831 065G080547332K A CAP CHIP 0805 47nF K 50V X7R

C901 063G107K474 US 0.47UF +-10%

C902 065G306M6812B3 Y1 CAP 680pF +-20% 250VAC CD SERIES

C903 065G306M6812B3 Y1 CAP 680pF +-20% 250VAC CD SERIES

C904 063G107K474 US 0.47UF +-10%

C905 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C906 065G306K4712B3 Y1 CAP 470pF +-10% 250VAC CD SERIES

C907 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C908 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C909 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C910 063G210K105HCJ CAP MPH 1UF 500V 10%

C912 065G080556031J A CAP CHIP 0805 56PF J 50V NPO

C913 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C914 067G215Y4707KT 47uF 50V

C915 065G080522132K A CAP CHIP 0805 220pF K 50V X7R

C917 065G080547332K A CAP CHIP 0805 47nF K 50V X7R

C918 065G080547432K A CAP CHIP 0805 0.47UF K 50V X7R

C920 067G 42Z82015K EC 82uF M 450V 18*36mm

C921 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C924 065G306M1022BP 1000PF Y1.CAP

C925 065G 1K103 2E6921 CAP CER 10NF K 1KV Y5U

C931 067G215A1017KT EC 100uF 50V 8*12mm

C932 065G 2K102 2T6921 CAP CER 1000pF 2KV K Y5P

C933 067G215Y1007KT KY50VB10M-TP5 5*11.5

C934 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C935 065G 2K102 2T6921 CAP CER 1000pF 2KV K Y5P

C937 067G215Y1007KT KY50VB10M-TP5 5*11.5

C939 065G080510332K A CAP CHIP 0805 10nF K 50V X7R

C941 067G215Y1007KT KY50VB10M-TP5 5*11.5

C942 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C943 065G080547332K A CAP CHIP 0805 47nF K 50V X7R

C944 065G080522132K A CAP CHIP 0805 220pF K 50V X7R

C945 067G215A4716KV EC 470uF 35V M 10*16mm

C946 067G215A4714KV EC 470uF 25V 10*16mm

C947 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C948 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C949 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C950 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

C951 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

C952 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

59

C953 067G204V331 3K CS CAP 330uF 16V 10*12 mm

C954 067G215A4713KV EC 470uF 16V M 10*12mm

C955 065G080522432K A CAP CHIP 0805 0.22UF K 50V X7R

C956 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C957 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

C970 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

C972 065G120610272K Y CAP CHIP 1206 1NF K 500V X7R

C973 067G215A4716KV EC 470uF 35V M 10*16mm

C975 067G215A4716KV EC 470uF 35V M 10*16mm

C976 065G080533432K A CAP CHIP 0805 0.33uF K 50V X7R

C978 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

CN801 033G8029 3A 3PIN (2PIN NC)

CN803 033G3802 5B Y CONNECTOR 5P 2.0

CN901 087G 501 47 DL AC SOCKET 2PIN + 3 SCREW Hole

CN901 006G 31500 EYELET(2.0) FOR ITEM CN901(AC SOCKET)

CN902 033G327813D CONNECTOR

D801 093G 60S 5 T SCS0520P SOD-123

D802 093G 60S 5 T SCS0520P SOD-123

D803 093G 60S 5 T SCS0520P SOD-123

D804 093G 60S 5 T SCS0520P SOD-123

D805 093G 64 1152T 1N4148

D806 093G 64 1152T 1N4148

D807 093G 64 42 PP BAV70 SOT-23

D901 093G 5212T52T DIODE 1N4007 DO-41

D902 093G 52 65 DIODE FMY-1106S 10A/600V TO-220F

D903 093G 64 1152T 1N4148

D904 093G 52 73 DIODE 1N5408 3A/1000V DO-201AD

D905 093G 64 1152T 1N4148

D906 093G 64 1152T 1N4148

D930 093G 6026T52T RECTIFIER DIODE FR107

D931 093G 5250S52T DIODE AU02Z-V1 SANKEN

D940 093G 6026T52T RECTIFIER DIODE FR107

D950 093G 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS)

D951 093G 64 1152T 1N4148

D971 093G 64 1152T 1N4148

D972 093G 60329 DIODE FMEN-220A 20A/100V TO-220

D973 093G 60329 DIODE FMEN-220A 20A/100V TO-220

F901 084G 41 11 L FUSE 5A 250V

FB901 071G 55 26 S FERRITE CORE

FB902 071G 55 23 BEAD

FB903 071G 55 26 S FERRITE CORE

HS1 P90G0027201 HEAT SINK

HS10 090G6084 1 HEAT SINK

HS5 P90G0027301 HEAT SINK

HS6 090G6064 1 HEAT SINK

HS7 090G6084 1 HEAT SINK

HS8 Q90G0206 1 Heat Sink

60

HS9 090G6084 1 HEAT SINK

IC801 056G 379122 IC OZ9976GN-C-0-TR SOP-16

IC901 056G 379164 IC FAN6961SZ SOP-8

IC902 056G 379121 IC STR- A6069H DIP-8

IC903 056G 379175 IC LD7523GS SOP-8

IC950 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC951 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC952 056G 158 10 T IC AS431AZTR-E1 TO-92

IC970 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC971 056G 158 10 T IC AS431AZTR-E1 TO-92

JR902 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR903 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR904 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

JR905 061G1206000 JT RST CHIPR MAX0R05 1/4W TZAI YUAN

L901 073G 174106 L LINE FILTER 13mH LF-008108

L902 073G 174106 L LINE FILTER 13mH LF-008108

L906 073G 174160 N PFC CHOKE 253uH 5% YUVA-1253

L950 073G 253 91 L CHOKE BY LI TA

L951 073G 253 91 L CHOKE BY LI TA

L980 073G 253 91 L CHOKE BY LI TA

NR901 061G 58030 WL RST NTCR 3 OHM +-20% 5A THINKING

Q801 057G 611903 MOSFET AOTF12N50 TO-220F

Q802 057G 611903 MOSFET AOTF12N50 TO-220F

Q803 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q804 057G 417 12 T KEC 2N3904S-RTK/PS

Q805 057G 417 12 T KEC 2N3904S-RTK/PS

Q901 057G 667 49 FET 2SK4086LS 11.5A/600V TO-220FI(LS)

Q903 057G 667 51 FET 2SK4101LS 7A/650V TO-220FI(LS)

Q921 057G 761 7 KTD1691P

Q950 057G 417 12 T KEC 2N3904S-RTK/PS

Q970 057G 417 12 T KEC 2N3904S-RTK/PS

R801 061G 30310852T GP FUSE RESISTOR

R802 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R803 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R811 061G08052400FF RST CHIPR 240 OHM +-1% 1/8W FENGHUA

R813 061G08052400FF RST CHIPR 240 OHM +-1% 1/8W FENGHUA

R814 061G0805510 JF RST CHIPR 51OHM +-5% 1/8W FENGHUA

R816 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R817 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R820 061G0805104 JF RST CHIPR 100KOHM +-5% 1/8W FENGHUA

R821 061G0805683 JF RST CHIPR 68KOHM +-5% 1/8W FENGHUA

R823 061G0805105 JF RST CHIPR 1M OHM +- 5% 1/8W FENGHUA

R824 061G0805683 JF RST CHIPR 68KOHM +-5% 1/8W FENGHUA

R825 061G12065100FF RST CHIPR 510 OHM +-5% 1/4W FENGHUA

R826 061G0805105 JF RST CHIPR 1M OHM +- 5% 1/8W FENGHUA

R827 061G12065100FF RST CHIPR 510 OHM +-5% 1/4W FENGHUA

R830 061G0805244 JT RST CHIP 240K 1/8W 5% TZAI YUAN

61

R831 061G0805154 JT RST CHIP 150K 1/8W 5% TZAI YUAN

R832 061G12066202FF RST 1206 62K 1% 1/4W FENGHUA

R833 061G1206335 JT RST CHIPR 3.3 MOHM +-5% 1/4W TZAI YUAN

R836 061G1206102 JF RST CHIPR 1KOHM +-5% 1/4W FENGHUA

R837 061G0805105 JF RST CHIPR 1M OHM +- 5% 1/8W FENGHUA

R838 061G1206103 JF RST CHIPR 10KOHM +-5% 1/4W FENGHUA

R839 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R840 061G0805155 JF RST CHIPR 1M5 +/-5% 1/8W FENGHUA

R841 061G0805513 JF RST CHIPR 51KOHM +-5% 1/8W FENGHUA

R842 061G0805513 JF RST CHIPR 51KOHM +-5% 1/8W FENGHUA

R843 061G1206122 JF RST CHIPR 1.2KOHM +-5% 1/4W FENGHUA

R844 061G08059101FF RST CHIPR 9.1KOHM +-1% 1/8W FENGHUA

R846 061G1206105 JT RST CHIPR 1MOHM +-5% 1/4W TZAI YUAN

R901 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R902 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R903 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R904 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R905 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R906 061G08055603FF RST CHIPR 560KOHM +-1% 1/8W FENGHUA

R907 061G1206229 JF RST CHIPR 2.2 OHM +-5% 1/4W FENGHUA

R908 061G1206229 JF RST CHIPR 2.2 OHM +-5% 1/4W FENGHUA

R909 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R911 061G1206203 JF RST CHIPR 20KOHM +-5% 1/4W FENGHUA

R913 061G 60210052T TZ RST CFR 10R 1/6W 5%

R914 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R915 061G1206471 JF RST CHIPR 470 OHM +-5% 1/4W FENGHUA

R916 061G152M12852T RST MOFR 0.12 OHM +-5% 2WS

R917 061G0805153 JF RST CHIPR 15K +-5% 1/8W FENGHUA

R918 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R920 061G12066803FF RST CHIPR 680KOHM +-1% 1/4W FENGHUA

R921 061G12066803FF RST CHIPR 680KOHM +-1% 1/4W FENGHUA

R922 061G12066803FF RST CHIPR 680KOHM +-1% 1/4W FENGHUA

R923 061G08051302FF RST CHIPR 13KOHM +-1% 1/8W FENGHUA

R924 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R925 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R926 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R931 061G1206229 JF RST CHIPR 2.2 OHM +-5% 1/4W FENGHUA

R932 061G0805100 JF RST CHIPR 10 OHM +-5% 1/10W FENGHUA

R933 061G1206109 JF RST CHIPR 1 OHM +-5% 1/4W FENGHUA

R939 061G1206103 JF RST CHIPR 10KOHM +-5% 1/4W FENGHUA

R943 061G0805100 JF RST CHIPR 10 OHM +-5% 1/10W FENGHUA

R944 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R945 061G1206102 JF RST CHIPR 1KOHM +-5% 1/4W FENGHUA

R946 061G152M36852T RST MOF 0R36 5% 2W

R947 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R948 061G 30310852T GP FUSE RESISTOR

R950 061G1206470 JF RST CHIPR 47 OHM +-5% 1/4W FENGHUA

62

R951 061G1206101 JF RST CHIPR 100 OHM +-5% 1/4W FENGHUA

R952 061G1206470 JF RST CHIPR 47 OHM +-5% 1/4W FENGHUA

R954 061G1206101 JF RST CHIPR 100 OHM +-5% 1/4W FENGHUA

R955 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R956 061G1206102 JF RST CHIPR 1KOHM +-5% 1/4W FENGHUA

R957 061G08058201FF RST CHIPR 8.2KOHM +-1% 1/8W FENGHUA

R958 061G08057501FF RST CHIPR 7.5KOHM +-1% 1/8W FENGHUA

R960 061G1206102 JF RST CHIPR 1KOHM +-5% 1/4W FENGHUA

R961 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R962 061G1206475 JF RST CHIPR 4.7 MOHM +-5% 1/4W FENGHUA

R963 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R965 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R966 061G1206682 JF RST CHIPR 6.8KOHM +-5% 1/4W FENGHUA

R967 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R968 061G1206682 JF RST CHIPR 6.8KOHM +-5% 1/4W FENGHUA

R969 061G1206682 JF RST CHIPR 6.8KOHM +-5% 1/4W FENGHUA

R970 061G1206101 JF RST CHIPR 100 OHM +-5% 1/4W FENGHUA

R971 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R972 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R973 061G1206101 JF RST CHIPR 100 OHM +-5% 1/4W FENGHUA

R974 061G1206102 JF RST CHIPR 1KOHM +-5% 1/4W FENGHUA

R975 061G0805392 JF RST CHIPR 3.9KOHM +-5% 1/8W FENGHUA

R976 061G1206103 JF RST CHIPR 10KOHM +-5% 1/4W FENGHUA

R977 061G1206101 JF RST CHIPR 100 OHM +-5% 1/4W FENGHUA

R978 061G08052402FF RST CHIPR 24KOHM +-1% 1/8W FENGHUA

R979 061G08052001FF RST CHIPR 2KOHM +-1% 1/8W FENGHUA

R981 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R982 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R983 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R984 061G1206682 JF RST CHIPR 6.8KOHM +-5% 1/4W FENGHUA

R985 061G08051302FF RST CHIPR 13KOHM +-1% 1/8W FENGHUA

R986 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R987 061G08052702FF RST CHIPR 27KOHM +-1% 1/8W FENGHUA

R988 061G1206182 JF RST CHIPR 1.8KOHM +-5% 1/4W FENGHUA

R991 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R992 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R993 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R994 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R996 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R997 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R998 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R999 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

T801 080GL32P 1 N POWER X'FMR 6mH 25% YUVA-1187

T802 080GL26T 15 N X'FMR 840uH MIN YUVA-1094

T901 080GL52T 5 N X'FMR 1.0mH YUVA-1068

T902 080GL37T 19 L X'FMR 550uH 5% PT-010923-3

ZD930 093G 3916752T MTZJ T-72 16B

63

ZD952 093G 39G 5 DIODE MTZJ15B DO-34

ZD970 093G 3917152T MTZJ T-72 30B

1055 INTV9LCCXAA9 INVERTER BOARD G3652-1-X-X-1-090903

C8801 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%

C8802 065G 6J1006ET 10PF 5% SL 6KV

C8803 065G 6J1006ET 10PF 5% SL 6KV

C8804 065G 6J1006ET 10PF 5% SL 6KV

C8805 065G 6J1006ET 10PF 5% SL 6KV

C8806 065G 6J1006ET 10PF 5% SL 6KV

C8807 065G 6J1006ET 10PF 5% SL 6KV

C8808 065G 6J1006ET 10PF 5% SL 6KV

C8809 065G 6J1006ET 10PF 5% SL 6KV

C8810 065G 6J1006ET 10PF 5% SL 6KV

C8811 065G 6J1006ET 10PF 5% SL 6KV

C8812 065G 6J1006ET 10PF 5% SL 6KV

C8813 065G 6J1006ET 10PF 5% SL 6KV

C8814 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8815 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8816 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8817 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8818 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C8819 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C8820 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8821 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8822 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8823 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8824 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

C8825 065G080518332K A MLCC 0805 18nF 50V X7R +-10% SAMSUNG

CN8801 095G 825 6D901 HARNESS 6P(SCN)-5P 300mm FQE092368HY

CN8802 033G3802 3B Y CONNECTOR

CN8803 033G3802 2B Y CONNECTOR

D8801 093G 64 1152T 1N4148

D8802 093G 64 1152T 1N4148

D8804 093G 64 1152T 1N4148

D8805 093G 64 1152T 1N4148

D8806 093G 3919552T DIODE MTZJ T-72 5.1B 500mW/5.1V DO-34

D8807 093G 64 1152T 1N4148

D8808 093G 6433S DIODE BAV99 SEMTECH

D8809 093G 6433S DIODE BAV99 SEMTECH

D8811 093G 6433S DIODE BAV99 SEMTECH

D8812 093G 6433S DIODE BAV99 SEMTECH

D8813 093G 6433S DIODE BAV99 SEMTECH

D8814 093G 6433S DIODE BAV99 SEMTECH

D8815 093G 6433S DIODE BAV99 SEMTECH

D8817 093G 6433S DIODE BAV99 SEMTECH

64

D8818 093G 6433S DIODE BAV99 SEMTECH

D8819 093G 6433S DIODE BAV99 SEMTECH

D8820 093G 64 1152T 1N4148

D8821 093G 64 1152T 1N4148

D8822 093G 64 1152T 1N4148

R8801 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R8802 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R8803 061G08053902FF RST CHIPR 39KOHM +-1% 1/8W FENGHUA

R8804 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R8805 061G0805104 JF RST CHIPR 100KOHM +-5% 1/8W FENGHUA

R8806 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R8807 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R8808 061G0805104 JF RST CHIPR 100KOHM +-5% 1/8W FENGHUA

R8809 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R8810 061G0805511 JF RST CHIPR 510OHM +-5% 1/8W FENGHUA

R8811 061G0805511 JF RST CHIPR 510OHM +-5% 1/8W FENGHUA

R8812 061G0805511 JF RST CHIPR 510OHM +-5% 1/8W FENGHUA

R8813 061G0805512 JF RST CHIPR 5.1KOHM +-5% 1/8W FENGHUA

R8814 061G0805511 JF RST CHIPR 510OHM +-5% 1/8W FENGHUA

R8815 061G0805511 JF RST CHIPR 510OHM +-5% 1/8W FENGHUA

R8816 061G08053902FF RST CHIPR 39KOHM +-1% 1/8W FENGHUA

R8817 061G0805512 JF RST CHIPR 5.1KOHM +-5% 1/8W FENGHUA

R8818 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R8819 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R8820 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R8821 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R8822 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R8823 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

RJ8801 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

T8801 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8802 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8803 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8804 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8805 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8806 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8807 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8808 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8809 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8810 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8811 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

T8812 080GL32T 14 DN INVERTER X'FMR 182uH TK.6518A.101 VOC

1053 IRPFAZA1 IR Board Assembly

SortStrng Component Object description

C2001 065G060310131J A CAP CHIP 0603 100PF J 50V NPO SAMSUNG

C2002 065G0805106A5K T CHIP 10uF 10V X5R 0805

65

C2003 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C2004 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C2005 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

CN2001 033G8032 6F X WAFER 6P 1.25MM

FB2001 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2002 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2003 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2004 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

LED2001 081G 12 6C GP LED RED/GREEN

Q2001 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q2002 057G 477900 T TRA SIG SM BC847C (KEC0) R

R2001 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2002 061G0603221 JF RST CHIPR 220 OHM +-5% 1/10W FENGHUA

R2003 061G0603221 JF RST CHIPR 220 OHM +-5% 1/10W FENGHUA

R2004 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2005 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

R2006 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2007 061G0603221 JT RST CHIPR 220OHM 1/10W TZAI YUAN

R2008 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

U2001 056G 627911 IR 38KHZ KSM-603TM2M

ZD2001 093G 39S 66 DIO REG SM BZX84-C5V1 (PHSE)R

1054 KEPFAZA1 Keypad Assembly

C0101 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C0102 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C0103 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

CN0101 033G8032 4F X WAFER 4P 1.25MM

R0101 061G0805562 JT RST CHIPR 5K6 +-5% 1/8W TZAI YUAN

R0102 061G0805471 JT RST CHIPR 470OHM +-5% 1/8W TZAI YUAN

R0103 061G0805562 JT RST CHIPR 5K6 +-5% 1/8W TZAI YUAN

R0104 061G0805471 JF RST CHIPR 470 OHM +-5% 1/8W FENGHUA

R0105 061G0805222 JF RST CHIPR 2.2KOHM +-5% 1/8W FENGHUA

R0106 061G0805222 JF RST CHIPR 2.2KOHM +-5% 1/8W FENGHUA

SW0101 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0102 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0103 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0104 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0105 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0106 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0107 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

66

LC42K06M E42AM2QNDWGA7NNS

Item Parts Code Description

1 705TZA3413A front bezel assy

6 705TZA3414A rear cover assy

10 P34T0413AED 1L0100 COVER_STAND

11 P33T0155AED 1T0100 KEY_CONTROL

12 P33T0156AEDA1L0100 KEY_PLATE

13 A15T0943201 42-bkt-panel-top

14 A15T0945101 42-bkt-pb

15 A15T0946201 42-BRK-STAND

16 A15T0947101 42-bkt-mb_l

17 A15T0948101 42-bkt-mb_r-auo

18 P15T0678101 BRACKET_IO_SIDE

19 P15T0679101 BRACKET_SIDE_BTM

20 Q37T0180011 STAND ASSM-1

21 0Q1G1840 8120 SCREW

22 0Q1T 940 30 47 CR3 SCREW

23 0Q1T 940 16 47 CR3 SCREW

24 0M1T 940 12 47 CR3 SILICON

25 0Q1T 930 8 47 CR3 SCREW

26 0M1T1140 6120 SCREW 4*6MM

27 0M1T1730 8120 SCREW

28 0M1T 330 6 47 CR3 SCREW

29 N02T6008 1 SCREW

30 Q44GN042624 1B CARTON

31 Q44GN042101 CUSHION_TL

32 Q44GN042201 CUSHION_TR

33 Q44GN042301 CUSHION_BL

34 Q44GN042401 CUSHION_BR

35 Q45T 99609 71 EPE COVER

36 Z52G1801007 mylar

37 Z07G0101 1 PALLET(1140*1080*120mm)

38 P44T9505140 CARD BOARD (1400x50x50x5t)

39 Z44G600281379A 52PER BOARD (1120X1000X5mm)

40 P45G 77001 LLDPE WRAP

41 P40TD000813 9A family sheet

44 P51T 11001 GLUE JETMELT 3748-V0-TC

45 Q11T5005 1 WIRE SADDLE

46 Z11G0010 1 Wire Saddle Clip

48 Q40G2010 32102 IO LABEL

49 Q40G2010 32003 Side lable

50 040T 581689 4A S/N LABEL

51 Z40G 42061501A RATING LABEL

52 P40G5000813 1A Hi-pot label

53 026T 800700 1A BARCODE LABEL

54 705TZA4104A DFU ASSY

55 Z41G320161503B USER'S MANUAL

67

56 Q45T 76 28 RN R pe bag

57 Z41G783061511B warranty card

58 041T780062415A certificate card

1050 750TVM420H2111N000 PANEL V420H2-L01 TW CMO

1056 098GRABD1NCACD REMOTE CONTROL 90-364100T4402

1057 092TB1JX1A31GM PEONY A1KALINE LR03

1172 089G214A18N IS POWER CORD 1.8M FA37B201312180TP

1185 078G0100A01 D SPEAKER 16R 10W 160*42*41 L16042-0011

8801 095G801851XA00 HARNESS 40P-51P 600mm

8802 095G801313XA38 HARNESS 12P-13P 350mm

8803 095G8013 4XA05 HARNESS 4P-2*(2*PAST) 650/350mm

8804 095G801413XA79 HARNESS 13P-4P+6P 950+800mm LCDXXTA1217

8805 095G801313XA39 HARNESS 13P-14P 370mm

P16G0021 1 GASKET 15*60*8t
Z52T 59013 Aluminum foil (80x40mm）

1051 CBPFA2QDZ2 Scaler Board Assembly

C1101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1102 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1108 065G040210332K A CAP 0402 10NF 50V X7R

C1109 065G040210332K A CAP 0402 10NF 50V X7R

C1110 065G040210332K A CAP 0402 10NF 50V X7R

C1111 065G040247232K A CAP CHIP 0402 4700P 50V X7R +/-10%

C1112 065G040250931J A CAP 0402 5PF J 50 NPO

C1113 065G040250931J A CAP 0402 5PF J 50 NPO

C1114 065G040250931J A CAP 0402 5PF J 50 NPO

C1115 065G040210332K A CAP 0402 10NF 50V X7R

C1116 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1117 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1118 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1119 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1201 065G040210332K A CAP 0402 10NF 50V X7R

C1202 065G040210332K A CAP 0402 10NF 50V X7R

C1203 065G040210332K A CAP 0402 10NF 50V X7R

C1204 065G040210332K A CAP 0402 10NF 50V X7R

C1205 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1206 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1207 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1210 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1211 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1212 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1213 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1232 065G040247232K A CAP CHIP 0402 4700P 50V X7R +/-10%

C1233 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1234 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1238 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

68

C1401 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1402 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1403 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1404 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1406 067G 3051012CT EC 100uF 10V KM 5x11mm

C1407 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1408 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1413 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1414 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1415 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1416 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1417 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1502 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1503 067G 3054704KT 47UF

C1504 067G305S4712CT EC 470uF 10V KW 8x9mm

C1601 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C1603 067G 5151022CT EC 1000uF 10V GF 10x16mm

C1604 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1605 067G 3054704KT 47UF

C1606 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1607 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1608 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1609 065G040222031J A CAP 0402 22PF J 50V NPO

C1610 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1613 065G0805106A5K T CHIP 10uF 10V X5R 0805

C1621 065G040233031J A CAP 0402 33PF J 50V NPO

C1622 065G040233031J A CAP 0402 33PF J 50V NPO

C1701 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1702 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4107 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4108 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4109 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4202 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4203 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4204 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4205 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4206 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4207 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4208 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4209 067G 3051012CT EC 100uF 10V KM 5x11mm

C4210 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4211 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4212 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4213 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4214 065G060333031J A CAP 0603 33PF 50V NPO

C4215 065G040227031J A CAP 0402 27PF J 50V NPO

69

C4216 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4217 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4218 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4219 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4220 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4221 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4222 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4223 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4224 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4225 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4226 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4227 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4228 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4229 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4230 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4231 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4232 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4233 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4234 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4235 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4236 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4237 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4238 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4239 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4240 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4241 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4242 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4243 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4244 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4245 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4246 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4247 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4248 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4249 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4250 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4251 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4252 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4253 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4254 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4255 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4256 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4257 065G060310332K A CAP chip 0603 10nF K 50V X7R

C4258 065G060310332K A CAP chip 0603 10nF K 50V X7R

C4259 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4260 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4261 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4262 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

70

C4263 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4264 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4265 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4266 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4267 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4268 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4269 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4270 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4271 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4272 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4273 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4274 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4275 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4276 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4277 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4278 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4279 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4280 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4281 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4282 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4283 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4284 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4285 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4286 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4287 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4288 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4289 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4290 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4291 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4292 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4293 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4294 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4295 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4296 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4297 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4298 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4299 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4300 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4301 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4302 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4303 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4304 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C5101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5111 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C5112 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5113 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5114 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

71

C5115 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5116 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5118 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5119 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5120 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5121 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5122 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5124 067G 3051012CT EC 100uF 10V KM 5x11mm

C5201 067G 3054704KT 47UF

C5401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5402 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5407 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C5408 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C6101 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6103 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6104 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6105 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6106 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6108 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6109 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6110 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6111 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6119 065G1206226A5K T CAP CHIP1206 22uF K 10V X5R

C6120 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6123 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C6126 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6127 067G 305471 7K EC 470uF 50V PF 10x20mm

C6128 067G 305471 7K EC 470uF 50V PF 10x20mm

C6129 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6130 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6131 065G040210232K A CAP 0402 1NF K 50V X7R

C6132 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6133 067G 5154707CT EC 47UF 50V GF 6.3*11mm

C6134 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6135 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6136 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6137 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

C6139 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6141 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6142 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6149 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6150 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6152 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6153 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6154 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

72

C6155 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6156 065G040210232K A CAP 0402 1NF K 50V X7R

C6157 065G040210232K A CAP 0402 1NF K 50V X7R

C6158 065G040210232K A CAP 0402 1NF K 50V X7R

C6201 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C6202 065G080510537Z T CAP CHIP 0805 1UF Z 50V Y5V

C6204 065G0805106A5K T CHIP 10uF 10V X5R 0805

C6205 065G0805106A5K T CHIP 10uF 10V X5R 0805

C6206 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6207 065G060310512K T CAP CHIP 0603 1UF K 16V X7R

C6208 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6211 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C6212 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C6213 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

C6215 065G060310512K T CAP CHIP 0603 1UF K 16V X7R

C6302 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C6303 067G 3051007KT EC 10UF/50V PF 5*11mm

C6320 067G 3054716ET EC 470uF 35V RGA 10x16mm

C7102 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7103 067G 3051012CT EC 100uF 10V KM 5x11mm

C7104 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7105 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7106 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7107 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C7108 067G 2154714CT EC 470uF 25V GF 10x12mm

C7109 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7110 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7111 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7112 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7113 067G 305471 6E EC 470uF 35V RGA 10x16mm

C7115 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7137 065G060347332K A CAP 0603 47NF K 50V X7R

C7138 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7139 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7140 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7141 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7142 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7143 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7144 067G 3051012CT EC 100uF 10V KM 5x11mm

C7145 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7146 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7147 067G 2154712CT EC 470uF 10V GF 8x12mm

C7148 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7149 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C7150 067G 3051012CT EC 100uF 10V KM 5x11mm

C7153 067G 3054704KT 47UF

C7158 067G 3054704KT 47UF

73

C7159 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C7160 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

CN1101 088G 35315F HD D-SUB CONN F ATTACHED SCREW

CN1102 088G 30265C PHONE JACK 3P GREEN

CN1203 088G 78 13 5C RCA JACK

CN1402 088G 352 21CL USB CONN TYPE A

CN1404 088G 100 11 CL MINI DIN JACK 4P+ SWITCH

CN1405 088G 78 13934 C RCA JACK 1*3 Y/W/R AV3-8.4-13-1

CN1501 088G 78 8A01 CL RCA JACK 1P YELLOW AV1-8.4-11-3

CN4201 033G8033 40 X CON. V 2*20P M 1.25 SM S1312-40SVA-1R

CN4402 033G3802 3H WAFER 3P RIGHT ANGLE

CN4403 033G380213B Y CONNECTOR

CN5010 088G 34019E AT HDMI HEADER 19P H:11.38mm

CN5011 088G 34019E AT HDMI HEADER 19P H:11.38mm

CN6101 033G3278 4D 2.5mm Pitch Wafer

CN6404 088G 302A12 YG PHONE JACK 3.5mm 7P BLACK

CN7101 033G327813D CONNECTOR

D1101 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D1701 093G 64S522SEM LL4148

D1702 093G 64S522SEM LL4148

D1703 093G 64S522SEM LL4148

D1705 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D1706 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D6201 093G 64S522SEM LL4148

D6202 093G 64S522SEM LL4148

D6203 093G 64S522SEM LL4148

D6204 093G 64S522SEM LL4148

D6301 093G 52S902 T DIODE 3A/100V S3B DO-214AB

D7101 093G1020 PH DIODE S1D-E3 VISHAY

FB1101 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB1102 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1103 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1104 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1105 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1106 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1201 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1202 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1203 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1204 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1205 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1211 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1401 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1402 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB1403 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1404 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1405 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1406 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

74

FB1407 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1408 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1409 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB4103 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4201 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4202 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4203 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4204 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4205 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4206 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4207 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4208 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4209 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4210 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4211 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4212 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4213 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4214 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4215 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4216 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4217 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4218 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4219 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4220 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4221 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB6201 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB6301 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB6303 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7101 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7102 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7105 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7107 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7108 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7109 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB7110 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7113 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7114 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7115 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7116 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7117 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7118 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

L1601 073G 253920 H CHOKE COIL 150uH+/-10% 50mohm DR10*8

L6101 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6102 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6103 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6104 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L7104 073G 253900 H CHOKE COIL 35uH+/-10% 82mohm DR10*8

75

Q1502 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1601 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1602 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1604 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1605 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1606 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1701 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1702 057G 761 15 PDTC114ET SOT23

Q1704 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1705 057G 761 15 PDTC114ET SOT23

Q1708 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q4101 057G 761 15 PDTC114ET SOT23

Q4201 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q5402 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q6101 057G 761 15 PDTC114ET SOT23

Q6103 057G 761 15 PDTC114ET SOT23

Q6201 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6202 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6203 057G 761 15 PDTC114ET SOT23

Q7101 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q7102 057G 763912 MOSFET SI4835DDY SO-8

Q7103 057G 761 15 PDTC114ET SOT23

Q7106 057G 763912 MOSFET SI4835DDY SO-8

Q7107 057G 761 15 PDTC114ET SOT23

Q7108 057G 761 15 PDTC114ET SOT23

R1101 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1103 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1106 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1107 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1108 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN

R1110 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1111 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1113 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1114 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1115 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1116 061G04027509FT RST CHIP 75R 1/16W 1%

R1117 061G04027509FT RST CHIP 75R 1/16W 1%

R1118 061G04027509FT RST CHIP 75R 1/16W 1%

R1119 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1120 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1121 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1122 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1123 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1124 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1125 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1126 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

76

R1127 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1201 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1202 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1203 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1205 061G04027509FT RST CHIP 75R 1/16W 1%

R1206 061G04027509FT RST CHIP 75R 1/16W 1%

R1207 061G04027509FT RST CHIP 75R 1/16W 1%

R1208 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1209 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1210 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1211 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1212 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1223 061G04027509FT RST CHIP 75R 1/16W 1%

R1231 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1232 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1401 061G04027509FT RST CHIP 75R 1/16W 1%

R1402 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1404 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1405 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1406 061G04027509FT RST CHIP 75R 1/16W 1%

R1407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1408 061G04027509FT RST CHIP 75R 1/16W 1%

R1409 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1410 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1414 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1416 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1417 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1502 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1503 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1504 061G04027509FT RST CHIP 75R 1/16W 1%

R1505 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1506 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1602 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1603 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1604 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1606 061G04027509FT RST CHIP 75R 1/16W 1%

R1607 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1608 061G04027509FT RST CHIP 75R 1/16W 1%

R1609 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1610 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1612 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1613 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1615 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1623 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

R1624 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1625 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1626 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

77

R1701 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1703 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1704 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1705 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1706 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1707 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1708 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1710 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1711 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1712 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1713 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1714 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1715 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1716 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1717 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1722 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1723 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1724 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1725 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1731 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1732 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R2101 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4101 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4105 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4110 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4111 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4112 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4113 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4114 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4115 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4116 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4120 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4125 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4139 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4140 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R4141 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R4143 061G0402330 JT RST CHIP 33R 1/16W 5% TZAI YUAN

R4144 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4145 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4146 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4148 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4149 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4150 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4151 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4202 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4206 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

78

R4207 061G0402102 JT RST CHIP 1K 1/16W 5% TZAI YUAN

R4210 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4211 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4213 061G04023301FT RST CHIP 3K3 1/16W 1%

R4214 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4215 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4216 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4217 061G0603824 JT RST CHIP 820K 1/10W 5% TZAI YUAN

R4219 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4221 061G06035101FT RST CHIP 5K1 1/10W 1%

R4222 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

R4223 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4224 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4226 061G0402513 JT RST CHIP 51K 1/16W 5% TZAI YUAN

R4228 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4229 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4231 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4232 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4233 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4235 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4236 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4237 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4239 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4249 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4250 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4251 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4252 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4253 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4254 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4257 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4258 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4259 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4260 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4261 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R5111 061G04021000FT RST CHIP 100R 1/16W 1%

R5112 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5113 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5114 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5202 061G0402272 JT RST CHIP 2K7 1/16W 5% TZAI YUAN

R5404 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5408 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5414 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5415 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5417 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R5421 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R5422 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

79

R5423 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5424 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R6101 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6103 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6109 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6110 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6114 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6118 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6119 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6120 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6125 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6127 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6129 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6130 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6131 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6132 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6139 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6140 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6141 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6146 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6147 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6148 061G1206100 JT RST CHIPR 10 OHM +-5% 1/4W TZAI YUAN

R6149 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6156 061G06035601FT RST CHIP 5K6 1/10W 1%

R6157 061G06036801FT RST CHIP 6K8 1/10W 1%

R6202 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN

R6203 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R6204 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN

R6205 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN

R6207 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R6209 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6210 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6211 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R6212 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6213 061G0402303 JT RST CHIP R 30Kohm 1/16W +/-5% TZAI YUAN

R6214 061G0603100 JT RST CHIP 10R 1/10W 5% TZAI YUAN

R6215 061G0402303 JT RST CHIP R 30Kohm 1/16W +/-5% TZAI YUAN

R6216 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6219 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6305 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R6324 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6325 061G0603182 JT RST CHIPR 1.8KOHM 1/10W TZAI YUAN

R7103 061G0603473 JT RST CHIP 47K 1/10W 5% TZAI YUAN

R7104 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R7105 061G0603332 JT RST CHIPR 3.3KOHM 1/10W TZAI YUAN

R7106 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7107 061G06031000FT RST CHIP 100R 1/10W 1%

80

R7108 061G06032209FT RST CHIP 22R 1/10W 1%

R7109 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7110 061G06032209FT RST CHIP 22R 1/10W 1%

R7121 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R7126 061G0603153 JT RST CHIPR 15KOHM 1/10W TZAI YUAN

R7129 061G0603153 JT RST CHIPR 15KOHM 1/10W TZAI YUAN

R7130 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7132 061G0603104 JT RST CHIP 100K 1/10W 5% TZAI YUAN

R7133 061G0603302 JT RST CHIPR 3KOHM 1/10W TZAI YUAN

R7134 061G06038200FT RST CHIP 820R 1/10W 1%

R7135 061G0603512 JT RST CHIPR 5.1KOHM +-5% 1/10W TZAI YUAN

R7137 061G06032201FT RST CHIP 2K2 1/10W 1%

R7138 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7139 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7140 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7141 061G06031501FT RST CHIP 1K5 1/10W 1%

R7142 061G06034701FT RST CHIP 4K7 1/10W 1%

R7144 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7145 061G0603471 JT RST CHIPR 470OHM +-5% 1/10W TZAI YUAN

R7146 061G0603103 JT RST CHIP 10K 1/10W 5% TZAI YUAN

R7147 061G0603202 JY RST CHIPR 2K +-5% 1/10W YAGEO

R7518 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R7519 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

RP5102 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5103 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5104 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5105 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

RP5106 061G 1262208JY RST CHIP AR 8P4R 22 OHM +-5% 1/16W

TH1401 061G 52902 PTC CHIP 8V 0R4 KMC4S075RY

TU1601 094GNPAL MN 3G TUNER NTSC+PAL TAFT-Z716D

U1101 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U1702 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U1703 056G1133918 IC AT24C02BN-SH-T 8-SOIC

U4105 056G1133946 IC MX25L6405DMI-12G SOP16

U4106 056G 615 67 IC NT5TU32M16CG-25C 512MB BGA-84

U4201 056G 562312 IC Scaler MT8222AHMU/B LQFP256

U4202 056G 643906 IC APX809-26SAG-7 SOT23

U4203 056G 638601 CS4344-CZZ

U6101 056G 614 1 74HC4052D S016 PHLIPS

U6201 056G 616916 IC MAX9728AETC+ TQFN-EP-12

U6202 056G 133902 IC L78L05ACU-TR SOT-89

U6301 056G 616 54 IC TPA3110D2 15W TSSOP-28

U7102 056G 563 93 IC G9084T43U TO-252

U7104 056G 563146 IC G912T63U 1A/1.2V SOT-223

U7105 056G 563956 IC AME5106AIHAADJZ SOP8

U7106 056G 563962 IC G973-120ADJF11U SOP-8

X4201 093G 22S920 C CRYSTAL 27MHz 20P SMD-49

81

ZD6201 093G 39S 47 BZX84C3V6 SOT-23

ZD7103 093G 60S801 DIODE SSA34 VISHAY
705TZA5604A EEPROM Assembly

1052 ADTV92421SA1 power board Assembly

BD901 093G 50460 35 BRIDGE GBJ1008 10A/800V GBJ

C901 065G306K6812BP Y1 680PF M 250VAC

C902 065G306K4712BP 470pF Y1-CAP

C903 063G107K474 UM CAP X2 470NF 10% 275VAC MPX

C904 063G107K474 UM CAP X2 470NF 10% 275VAC MPX

C905 065G 1K103 2E6921 CAP CER 10NF K 1KV Y5U

C906 065G306K6812BP Y1 680PF M 250VAC

C907 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C908 067G215Y1007KT KY50VB10M-TP5 5*11.5

C909 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C910 067G215S102 6K EC CAP 105 1000uF 35v

C911 067G215S102 6K EC CAP 105 1000uF 35v
C912 067G215S471 6K 105 度 470UF.M.35V

C913 065G080510537Z T CAP CHIP 0805 1UF Z 50V Y5V

C914 065G080547432K A CAP CHIP 0805 0.47UF K 50V X7R

C915 063G211J333 5C C 0.033uF 5% 1000V P=15mm

C916 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C917 065G080510522K Y CAP CHIP 0805 1UF K 25V X7R

C918 065G080510522K Y CAP CHIP 0805 1UF K 25V X7R

C919 065G 3J2206ET 22PF 5% SL 3KV TDK

C920 065G 3J2206ET 22PF 5% SL 3KV TDK
C921 067G215S1024KV EC 105℃ CAP 1000UF M 25V
C922 067G215D4714KV E.C 105℃ CAP 470UF M 25V ED SERIES

C923 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C924 065G 2K101 5T 100pF 10% 2KV Y5P

C926 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%

C927 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C928 067G 3154797KT EC 4.7uF 50V M 5*11mm

C929 065G306K4712BP 470pF Y1-CAP

C930 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C931 063G210K105HCU CAP MPH 1UF 500V 10%

C933 067G 42Z82015K EC 82uF M 450V 18*36mm

C934 067G 42Z82015K EC 82uF M 450V 18*36mm

C936 067G215A4704KT EC 47uF 25V 5*11mm

C937 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C938 065G080547432K A CAP CHIP 0805 0.47UF K 50V X7R

C939 065G080510522K Y CAP CHIP 0805 1UF K 25V X7R

C940 065G080510332K A CAP CHIP 0805 10nF K 50V X7R

C941 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

C942 065G080547232K Y CAP CHIP 0805 4700PF K 50V X7R

C943 065G080510232K A CAP CHIP 0805 1000pF K 50V X7R

82

C944 065G306K4712BP 470pF Y1-CAP

C945 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C946 065G 2K102 2T6921 CAP CER 1000pF 2KV K Y5P

C947 065G 2K102 2T6921 CAP CER 1000pF 2KV K Y5P

C949 065G120622272K Y CAP CHIP 1206 2200PF K 500V X7R

C950 067G204V331 3K CS CAP 330uF 16V 10*12 mm

C951 067G215A1023KV EC 1000uF 16V M 10*20mm

C952 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C955 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C956 067G215D1017KT EC CAP 100uF 50V 8*12mm

C958 067G215Y1007KT KY50VB10M-TP5 5*11.5

C959 065G080547232K Y CAP CHIP 0805 4700PF K 50V X7R

C960 065G080522432K A CAP CHIP 0805 0.22UF K 50V X7R

C961 065G080522432K A CAP CHIP 0805 0.22UF K 50V X7R

C963 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C964 065G306K4712BP 470pF Y1-CAP

CN901 087G 501 47 DL AC SOCKET 2PIN + 3 SCREW Hole

CN901 006G 31500 EYELET(2.0) FOR ITEM CN901(AC SOCKET)

CN903 033G327813D CONNECTOR

CN905 033G327812D WAFER 12P PLUG

D901 093G 220 33 DIODE FMXA-1106S

D902 093G 64 1152T 1N4148

D903 093G 60324 DIODE FMWN-2308 30A/80V TO-220

D904 093G 64 1152T 1N4148

D905 093G 52 6452T DIODE EG01A 0.5A/600V AXIAL-LEAD

D906 093G 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS)

D907 093G 60324 DIODE FMWN-2308 30A/80V TO-220

D909 093G 52 73 DIODE 1N5408 3A/1000V DO-201AD

D910 093G 64 1152T 1N4148

D911 093G 60298 DIODE SBT15006JST 15A/60V TO-220ML(LS)

D913 093G 6026T52T RECTIFIER DIODE FR107

D914 093G 6026T52T RECTIFIER DIODE FR107

D916 093G 64 1152T 1N4148

D917 093G 64 1152T 1N4148

D918 093G 64 1152T 1N4148

E715 715G3885P02W30003U TV POWER PCB CEM-1 200x230x1.6MM SS

F901 084G 41 11 L FUSE 5A 250V

FB901 071G 55 29 FERRITE BEAD

FB902 071G 55 9 T FERRITE BEAD 3.5*6*0.8-T52

FB903 071G 55 29 FERRITE BEAD

FB904 071G 55 29 FERRITE BEAD

FB905 071G 55 29 FERRITE BEAD

FB906 071G 55 9 T FERRITE BEAD 3.5*6*0.8-T52

HS5 Q90G0099 2 HEAT SINK

IC901 056G 379121 IC STR- A6069H DIP-8

IC902 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC903 056G 158 10 T IC AS431AZTR-E1 TO-92

83

IC904 056G 379112 IC SSC9502S -TL SOP-18

IC905 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC906 056G 379104 IC ICE2PCS02H PG-DSO-8

IC907 056G 139 9 IC EL817M(X) photocoupler DIP-4

IC908 056G 158 10 T IC AS431AZTR-E1 TO-92

JR901 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR902 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR903 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR904 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR905 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR907 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR908 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR909 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

JR910 061G1206000 JF RST CHIPR MAX0R05 1/4W FENGHUA

L901 073L 174 49 LG LINE FILTER

L902 073L 174 52 LG CHOKE COIL

L903 073L 174 49 LG LINE FILTER

L904 073G 253150 H IND CHOKE 3.0uH+-10% DADON

L905 073G 253 91 L CHOKE BY LI TA

L906 073G 174148 H PFC CHOKE 600uH 10% GL-14205 HA

L906 006G 31 4 1.7MM RIVET

L907 073G 253 91 L CHOKE BY LI TA

NR901 061G 58030 WL RST NTCR 3 OHM +-20% 5A THINKING

Q901 057G 667 25 STW20NM60

Q902 057G 667 49 FET 2SK4086LS 11.5A/600V TO-220FI(LS)

Q903 057G 667 49 FET 2SK4086LS 11.5A/600V TO-220FI(LS)

Q904 057G 761 7 KTD1691P

Q905 057G 417 12 T KEC 2N3904S-RTK/PS

Q906 057G 417 12 T KEC 2N3904S-RTK/PS

R901 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R902 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R903 061G1206334 JF RST CHIPR 330KOHM +-5% 1/4W FENGHUA

R904 061G 30310852T GP FUSE RESISTOR

R905 061G12062004FF RST CHIPR 2MOHM 1% 1/4W FENGHUA

R906 061G12062004FF RST CHIPR 2MOHM 1% 1/4W FENGHUA

R907 061G12062004FF RST CHIPR 2MOHM 1% 1/4W FENGHUA

R908 061G1206202 JF RST CHIPR 2KOHM +-5% 1/4W FENGHUA

R909 061G08053002FF RST CHIPR 30KOHM +-1% 1/8W FENGHUA

R910 061G0805470 JF RST CHIPR 47OHM +-5% 1/8W FENGHUA

R911 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R912 061G1206512 JF RST CHIPR 5.1KOHM +-5% 1/4W FENGHUA

R913 061G1206512 JF RST CHIPR 5.1KOHM +-5% 1/4W FENGHUA

R914 061G1206512 JF RST CHIPR 5.1KOHM +-5% 1/4W FENGHUA

R915 061G1206512 JF RST CHIPR 5.1KOHM +-5% 1/4W FENGHUA

R916 061G0805470 JF RST CHIPR 47OHM +-5% 1/8W FENGHUA

R917 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R919 061G1206759 JF RST CHIPR 7.5 OHM +-5% 1/4W FENGHUA

84

R921 061G08051001FF RST CHIPR 1KOHM +-1% 1/8W FENGHUA

R922 061G0805151 JF RST CHIPR 150 OHM +-5% 1/8W FENGHUA

R923 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

R924 061G08054701FF RST CHIPR 4.7KOHM +-1% 1/8W FENGHUA

R925 061G08052402FT RST CHIP 24K 1/8W 1%

R926 061G08053001FF RST CHIPR 3KOHM +-1% 1/8W FENGHUA

R927 061G08052052FF RST CHIPR 20.5KOHM +-1% 1/8W FENGHUA

R928 061G08055602FF RST CHIPR 56KOHM +-1% 1/8W FENGHUA

R929 061G08055101FF RST CHIPR 5.1KOHM +-1% 1/8W FENGHUA

R930 061G08052001FF RST CHIPR 2KOHM +-1% 1/8W FENGHUA

R931 061G08051201FF RST CHIPR 1.2KOHM +-1% 1/8W FENGHUA

R932 061G153M108 59 SY RST MOFR 0.1 OHM +-5% 3WS FUTABA

R933 061G0805510 JF RST CHIPR 51OHM +-5% 1/8W FENGHUA

R934 061G153M108 59 SY RST MOFR 0.1 OHM +-5% 3WS FUTABA

R935 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R936 061G0805330 JF RST CHIPR 33 OHM +-5% 1/8W FENGHUA

R938 061G0805103 JF RST CHIPR 10K OHM +-5% 1/8W FENGHUA

R939 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R940 061G0805203 JF RST CHIPR 20KOHM +-5% 1/8W FENGHUA

R941 061G1206221 JF RST CHIPR 220 OHM +-5% 1/4W FENGHUA

R942 061G0805513 JF RST CHIPR 51KOHM +-5% 1/8W FENGHUA

R943 061G0805512 JF RST CHIPR 5.1KOHM +-5% 1/8W FENGHUA

R944 061G12061004FF RST CHIPR 1 MOHM +-1% 1/4W FENGHUA

R945 061G08052202FF RST CHIPR 22KOHM +-1% 1/8W FENGHUA

R946 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R947 061G0805221 JF RST CHIPR 220 OHM +-5% 1/8W FENGHUA

R948 061G0805272 JF RST CHIPR 2.7KOHM +-5% 1/8W FENGHUA

R949 061G0805202 JF sST CHIPR 2KOHM +-5% 1/8W FENGHUA

R950 061G 30347852T SY RST FUSER 0.47 OHM +-5% 1W

R951 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R952 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R953 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R954 061G1206104 JF RST CHIPR 100KOHM +-5% 1/4W FENGHUA

R955 061G1206339 JF RST CHIPR 3.3 OHM +-5% 1/4W FENGHUA

R956 061G1206470 JF RST CHIPR 47 OHM +-5% 1/4W FENGHUA

R957 061G1206470 JF RST CHIPR 47 OHM +-5% 1/4W FENGHUA

R958 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R961 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R962 061G0805221 JF RST CHIPR 220 OHM +-5% 1/8W FENGHUA

R963 061G1206475 JF RST CHIPR 4.7 MOHM +-5% 1/4W FENGHUA

R964 061G12061504FF RST CHIPR 1.5MOHM 1% 1/4W FENGHUA

R965 061G08052401FF RST CHIPR 2.4KOHM +-1% 1/8W FENGHUA

R966 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R967 061G08056203FF RST CHIPR 620KOHM +-1% 1/8W FENGHUA

R968 061G152M12952T SY RST MOF 1R2 5% 2W

R969 061G0805101 JF RST CHIPR 100 OHM +-5% 1/8W FENGHUA

R970 061G0805202 JF sST CHIPR 2KOHM +-5% 1/8W FENGHUA

85

R971 061G08052201FF RST CHIPR 2.2KOHM +-1% 1/8W FENGHUA

R972 061G0805102 JF RST CHIPR 1K OHM +-5% 1/8W FENGHUA

R975 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

R976 061G0805000 JF RST CHIPR 0 OHM +-5% 1/8W FENGHUA

T901 080GL52T 5 N X'FMR 1.0mH YUVA-1068

T902 080GL42T 14 L X'FMR 600uH PT-009533

T902 006G 31502 1.5MM RIVET

ZD901 093G 39G 5 DIODE MTZJ15B DO-34

ZD902 093G 39G 5 DIODE MTZJ15B DO-34

ZD903 093G 39G 9 DIODE MTZJ30B DO-34

ZD904 093G 3954752T DIODE MTZJ16B SEMTECH

ZD906 093G 3958352T ZENER GDZJ13B BY PANJIT

1053 IRPFAZA1 IR Board Assembly

SortStrng Component Object description

C2001 065G060310131J A CAP CHIP 0603 100PF J 50V NPO SAMSUNG

C2002 065G0805106A5K T CHIP 10uF 10V X5R 0805

C2003 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C2004 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C2005 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

CN2001 033G8032 6F X WAFER 6P 1.25MM

FB2001 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2002 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2003 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB2004 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

LED2001 081G 12 6C GP LED RED/GREEN

Q2001 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q2002 057G 477900 T TRA SIG SM BC847C (KEC0) R

R2001 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2002 061G0603221 JF RST CHIPR 220 OHM +-5% 1/10W FENGHUA

R2003 061G0603221 JF RST CHIPR 220 OHM +-5% 1/10W FENGHUA

R2004 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2005 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

R2006 061G0603103 JF RST CHIPR 10K OHM +-5% 1/10W FENGHUA

R2007 061G0603221 JT RST CHIPR 220OHM 1/10W TZAI YUAN

R2008 061G0603222 JF RST CHIPR 2.2K OHM +-5% 1/10W FENGHUA

U2001 056G 627911 IR 38KHZ KSM-603TM2M

ZD2001 093G 39S 66 DIO REG SM BZX84-C5V1 (PHSE)R

1054 KEPFAZA1 Keypad Assembly

C0101 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C0102 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C0103 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

CN0101 033G8032 4F X WAFER 4P 1.25MM

R0101 061G0805562 JT RST CHIPR 5K6 +-5% 1/8W TZAI YUAN

86

R0102 061G0805471 JT RST CHIPR 470OHM +-5% 1/8W TZAI YUAN

R0103 061G0805562 JT RST CHIPR 5K6 +-5% 1/8W TZAI YUAN

R0104 061G0805471 JF RST CHIPR 470 OHM +-5% 1/8W FENGHUA

R0105 061G0805222 JF RST CHIPR 2.2KOHM +-5% 1/8W FENGHUA

R0106 061G0805222 JF RST CHIPR 2.2KOHM +-5% 1/8W FENGHUA

SW0101 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0102 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0103 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0104 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0105 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0106 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

SW0107 077G 607 2 FD TACT SW BY FORWARD SFKQGMA2125T-PL

LC46K06M E46AA2QNDWGA7NNS

Item Parts Code Description

1 705TZA3419A front bezel assy

5 705TZA3420A rear cover assy

8 P34T0418AED 1L0100 COVER_STAND

9 P33T0155AED 1T0100 KEY_CONTROL

10 P33T0156AEDA1L0100 KEY_PLATE

11 P15T0637101 MAIN_FRAME_TOP

12 P15T0638101 MAIN_FRAME_BTM

13 P15T0639101 MAIN_FRAME_SUPPORT

14 P15T0640101 MAIN_FRAME_MID

15 P15T0641101 BRACKET_VESA_SUPPORT

16 P15T0642101 BRACKET_VESA

17 P15T0643101 BRACKET_POWER

18 P15T0644101 BRACKET_PCB_SUPPORT_TOP

19 P15T0645101 BRACKET_PCB_SUPPORT_MID

20 P15T0646101 BRACKET_PCB_SUPPORT_BTM

21 P15T0647101 BRACKET_PCB_SUPPORT_L

22 P15T0648101 BRACKET_PCB_SUPPORT_R

23 P15T0649101 BRACKET_HOLDER_AUO

24 P15T0678101 BRACKET_IO_SIDE

25 P15T0679101 BRACKET_SIDE_BTM
26 P37T0088011 HINGE_ASS¡¯Y

27 0M1G 950 6120 SCREW

28 0Q1G1840 8120 SCREW

29 0Q1T 940 12 47 CR3 T4X12 SCREW

30 0Q1T 940 16 47 CR3 SCREW

31 0M1T 940 8 47 CR3 SCREW

32 0Q1T 930 8 47 CR3 SCREW

33 0M1T1140 6120 SCREW 4*6MM

34 0M1T1730 8120 SCREW

35 N02T6008 1 SCREW

36 0M1T 130 8120 SCREW

37 Q45T 99609 83 EPE COVER FOR MONITOR

87

38 Q44GP010624 1B CARTON

39 Q44GP010101 CUSHION_TL

40 Q44GP010201 CUSHION_TR

41 Q44GP010301 CUSHION_BL

42 Q44GP010401 CUSHION_BR

43 Q11T5005 1 WIRE SADDLE

48 P51T 11001 GLUE JETMELT 3748-V0-TC

49 Q40G2010 32102 IO LABEL

50 Q40G2010 32003 Side lable

51 040T 581689 4A S/N LABEL

52 Z40G 46061501A RATING LABEL

53 P40G5000813 1A Hi-pot label

54 026T 800700 1A BARCODE LABEL

55 705TZA4104A DFU ASSY

55 Z41G320161503B USER'S MANUAL

56 Q45T 76 28 RN R pe bag

57 Z41G783061511B warranty card

58 041T780062415A certificate card

60 Z07G0044 1 Pallet

61 P44G9505160 CARD BOARD (1600x50x50x5t)

62 P44T6002813 8A paper board

63 P45G 77001 LLDPE WRAP

64 P40TD000813 9A family sheet

65 P52T 59020 AL FOIL 80x40

66 P16G0021 1 GASKET 15*60*8t

67 P85T 86052 GASKET 100*5*2
68 Z16G0001016 Gasket 12mm*50mm*4mm

69 0M1T 330 6 47 CR3 SCREW

1050 750TVU460W7211N000 PANEL T460HW07 V2 TW AUO

1051 CBPFA2QDZ3 Scaler Board Assembly

1052 ADTV92428SA1 power board Assembly

1053 IRPFAZA1 IR Board Assembly

1054 KEPFAZA1 Keypad Assembly

1056 098GRABD1NCACD REMOTE CONTROL 90-364100T4402

1057 092TB1JX1A31GM PEONY A1KALINE LR03

1172 089G214A18N IS POWER CORD 1.8M FA37B201312180TP

1185 078G0100A01 D SPEAKER 16R 10W 160*42*41 L16042-0011

8801 095G801851XA50 LVDS CABLE 51P-42P 700mm S-LVDSXTA0362

8802 095G801313XA40 HARNESS 13P-12P 290mm S-LCDXXTD9625

8803 095G8013 4XA06 HARNESS 4P-2*(2*PAST) 700+350mm

8804 095G801413XA44 HARNESS 11P-6P+4P 950+1150mm

8805 095G801314XA20 HARNESS 13P-14P 400mm S-LCDXXTA1221

1051 CBPFA2QDZ3 Scaler Board Assembly

C1101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1102 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

88

C1108 065G040210332K A CAP 0402 10NF 50V X7R

C1109 065G040210332K A CAP 0402 10NF 50V X7R

C1110 065G040210332K A CAP 0402 10NF 50V X7R

C1111 065G040247232K A CAP CHIP 0402 4700P 50V X7R +/-10%

C1112 065G040250931J A CAP 0402 5PF J 50 NPO

C1113 065G040250931J A CAP 0402 5PF J 50 NPO

C1114 065G040250931J A CAP 0402 5PF J 50 NPO

C1115 065G040210332K A CAP 0402 10NF 50V X7R

C1116 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1117 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1118 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1119 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1201 065G040210332K A CAP 0402 10NF 50V X7R

C1202 065G040210332K A CAP 0402 10NF 50V X7R

C1203 065G040210332K A CAP 0402 10NF 50V X7R

C1204 065G040210332K A CAP 0402 10NF 50V X7R

C1205 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1206 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1207 065G040215031J A CAP CHIP 0402 15PF J 50V NPO

C1210 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1211 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1212 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1213 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1232 065G040247232K A CAP CHIP 0402 4700P 50V X7R +/-10%

C1233 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1234 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1238 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1401 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1402 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1403 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1404 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1406 067G 3051012CT EC 100uF 10V KM 5x11mm

C1407 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1408 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1413 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1414 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1415 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1416 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1417 065G040233131J A CAP CHIP 0402 330PF 50V J NPO

C1502 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1503 067G 3054704KT 47UF

C1504 067G305S4712CT EC 470uF 10V KW 8x9mm

C1601 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C1603 067G 5151022CT EC 1000uF 10V GF 10x16mm

C1604 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1605 067G 3054704KT 47UF

89

C1606 065G040247312K A CAP CHIP 0402 47nF K 16V X7R

C1607 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C1608 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1609 065G040222031J A CAP 0402 22PF J 50V NPO

C1610 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1613 065G0805106A5K T CHIP 10uF 10V X5R 0805

C1621 065G040233031J A CAP 0402 33PF J 50V NPO

C1622 065G040233031J A CAP 0402 33PF J 50V NPO

C1701 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C1702 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4107 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4108 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4109 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4202 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4203 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4204 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4205 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4206 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4207 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4208 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4209 067G 3051012CT EC 100uF 10V KM 5x11mm

C4210 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4211 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4212 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4213 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4214 065G060333031J A CAP 0603 33PF 50V NPO

C4215 065G040227031J A CAP 0402 27PF J 50V NPO

C4216 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4217 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4218 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4219 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4220 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4221 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4222 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4223 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4224 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4225 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4226 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4227 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4228 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4229 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4230 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4231 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4232 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4233 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4234 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4235 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

90

C4236 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4237 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4238 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4239 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4240 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4241 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4242 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4243 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4244 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4245 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4246 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4247 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4248 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4249 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4250 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4251 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4252 065G0603475A5K T CAP CHIP 0603 4.7UF K 10V X5R

C4253 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4254 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4255 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4256 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4257 065G060310332K A CAP chip 0603 10nF K 50V X7R

C4258 065G060310332K A CAP chip 0603 10nF K 50V X7R

C4259 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4260 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4261 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4262 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4263 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4264 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4265 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4266 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4267 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4268 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4269 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4270 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4271 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4272 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4273 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4274 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4275 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4276 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4277 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4278 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4279 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4280 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4281 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4282 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

91

C4283 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4284 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4285 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4286 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4287 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4288 065G0805475A2K T CAP CHIP 4U7 10V X7R 10%

C4289 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C4290 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4291 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4292 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C4293 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4294 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4295 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4296 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4297 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4298 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4299 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4300 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4301 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C4302 065G0805106A5K T CHIP 10uF 10V X5R 0805

C4303 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C4304 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

C5101 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5111 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C5112 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5113 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5114 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5115 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5116 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5118 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5119 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5120 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5121 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5122 065G040233232K A CAP CHIP 0402 3.3NF K 50V X7R

C5124 067G 3051012CT EC 100uF 10V KM 5x11mm

C5201 067G 3054704KT 47UF

C5401 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5402 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5405 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5406 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C5407 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C5408 065G040210332K Y CAP CHIP 0402 10N 50V X7R +/-10%

C6101 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6103 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6104 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6105 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6106 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

92

C6108 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6109 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6110 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6111 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6119 065G1206226A5K T CAP CHIP1206 22uF K 10V X5R

C6120 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6123 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C6126 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6127 067G 305471 7K EC 470uF 50V PF 10x20mm

C6128 067G 305471 7K EC 470uF 50V PF 10x20mm

C6129 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6130 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6131 065G040210232K A CAP 0402 1NF K 50V X7R

C6132 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6133 067G 5154707CT EC 47UF 50V GF 6.3*11mm

C6134 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6135 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6136 065G0603225A5K T CAP CHIP 0603 2.2uF K 10V X5R

C6137 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

C6139 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6141 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6142 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6149 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6150 065G120633432K Y CER 1206 330N 50V X7R +/-10%

C6152 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6153 065G060322422K A MLCC 0603 220nF 25V X7R +/-10% SAMSUNG

C6154 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6155 065G080510432K A CAP CHIP 0805 100nF K 50V X7R

C6156 065G040210232K A CAP 0402 1NF K 50V X7R

C6157 065G040210232K A CAP 0402 1NF K 50V X7R

C6158 065G040210232K A CAP 0402 1NF K 50V X7R

C6201 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C6202 065G080510537Z T CAP CHIP 0805 1UF Z 50V Y5V

C6204 065G0805106A5K T CHIP 10uF 10V X5R 0805

C6205 065G0805106A5K T CHIP 10uF 10V X5R 0805

C6206 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6207 065G060310512K T CAP CHIP 0603 1UF K 16V X7R

C6208 065G0402105A5K T CAP CHIP 0402 1uF K 10V X5R

C6211 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C6212 065G040247031J A CAP CHIP 0402 47PF J 50V NPO

C6213 065G080510522K T CAP CHIP 0805 1UF K 25V X7R

C6215 065G060310512K T CAP CHIP 0603 1UF K 16V X7R

C6302 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C6303 067G 3051007KT EC 10UF/50V PF 5*11mm

C6320 067G 3054716ET EC 470uF 35V RGA 10x16mm

C7102 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7103 067G 3051012CT EC 100uF 10V KM 5x11mm

93

C7104 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7105 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7106 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7107 065G0603475A5K A CAP 0603 4.7UF 10V X5R K

C7108 067G 2154714CT EC 470uF 25V GF 10x12mm

C7109 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7110 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7111 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7112 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7113 067G 305471 6E EC 470uF 35V RGA 10x16mm

C7115 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7137 065G060347332K A CAP 0603 47NF K 50V X7R

C7138 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7139 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7140 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7141 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7142 067G 3054712CT EC 470UF 10V KM 8*11.5mm

C7143 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7144 067G 3051012CT EC 100uF 10V KM 5x11mm

C7145 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7146 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7147 067G 2154712CT EC 470uF 10V GF 8x12mm

C7148 065G060310432K A CAP CHIP 0603 100nF K 50V X7R

C7149 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C7150 067G 3051012CT EC 100uF 10V KM 5x11mm

C7153 067G 3054704KT 47UF

C7158 067G 3054704KT 47UF

C7159 065G040210412K A CAP CHIP 0402 100nF K 16V X7R

C7160 065G060310605M T MLCC 0603 10UF 6.3V X5R +-20%

CN1101 088G 35315F HD D-SUB CONN F ATTACHED SCREW

CN1102 088G 30265C PHONE JACK 3P GREEN

CN1203 088G 78 13 5C RCA JACK

CN1402 088G 352 21CL USB CONN TYPE A

CN1404 088G 100 11 CL MINI DIN JACK 4P+ SWITCH

CN1405 088G 78 13934 C RCA JACK 1*3 Y/W/R AV3-8.4-13-1

CN1501 088G 78 8A01 CL RCA JACK 1P YELLOW AV1-8.4-11-3

CN4201 033G8033 40 X CON. V 2*20P M 1.25 SM S1312-40SVA-1R

CN4402 033G3802 3H WAFER 3P RIGHT ANGLE

CN4403 033G380213B Y CONNECTOR

CN5010 088G 34019E AT HDMI HEADER 19P H:11.38mm

CN5011 088G 34019E AT HDMI HEADER 19P H:11.38mm

CN6101 033G3278 4D 2.5mm Pitch Wafer

CN6404 088G 302A12 YG PHONE JACK 3.5mm 7P BLACK

CN7101 033G327813D CONNECTOR

D1101 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D1701 093G 64S522SEM LL4148

D1702 093G 64S522SEM LL4148

94

D1703 093G 64S522SEM LL4148

D1705 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D1706 093G 60518SEM DIODE BAT54C-HAF 300mA/30V SOT-23

D6201 093G 64S522SEM LL4148

D6202 093G 64S522SEM LL4148

D6203 093G 64S522SEM LL4148

D6204 093G 64S522SEM LL4148

D6301 093G 52S902 T DIODE 3A/100V S3B DO-214AB

D7101 093G1020 PH DIODE S1D-E3 VISHAY

FB1101 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB1102 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1103 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1104 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1105 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1106 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1201 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1202 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1203 071G 59K300 TA CHIP BEAD 0603 30R/700mA TAI-TECH

FB1204 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1205 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1211 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1401 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1402 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB1403 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1404 071G 59D121 TA CHIP BEAD 120R/600mA FCM1608KF-121T06

FB1405 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1406 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1407 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1408 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB1409 071G 59C601 TA CHIP BEAD 600R/200mA FCM1608K-601T02

FB4103 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4201 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4202 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4203 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4204 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4205 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4206 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4207 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4208 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4209 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4210 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4211 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4212 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4213 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4214 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4215 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4216 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

95

FB4217 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4218 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4219 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4220 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB4221 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB6201 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB6301 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB6303 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7101 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7102 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7105 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7107 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7108 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7109 071G 59A121 TA CHIP BEAD 120R/3000mA HCB1608KF-121T30

FB7110 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7113 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7114 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7115 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7116 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7117 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

FB7118 071G 56K121 TA CHIP BEAD 120R/6000mA HCB2012KF-121T60

L1601 073G 253920 H CHOKE COIL 150uH+/-10% 50mohm DR10*8

L6101 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6102 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6103 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L6104 073G 253924 H CHOKE COIL 47uH 10% 1.5A L470B HA DADON

L7104 073G 253900 H CHOKE COIL 35uH+/-10% 82mohm DR10*8

Q1502 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1601 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1602 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1604 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1605 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1606 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1701 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q1702 057G 761 15 PDTC114ET SOT23

Q1704 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q1705 057G 761 15 PDTC114ET SOT23

Q1708 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q4101 057G 761 15 PDTC114ET SOT23

Q4201 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q5402 057G 759 2 RK7002FD5T116 SOT-23 BY ROHM

Q6101 057G 761 15 PDTC114ET SOT23

Q6103 057G 761 15 PDTC114ET SOT23

Q6201 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6202 057G 477900 T TRA SIG SM BC847C (KEC0) R

Q6203 057G 761 15 PDTC114ET SOT23

Q7101 057G 477900 T TRA SIG SM BC847C (KEC0) R

96

Q7102 057G 763912 MOSFET SI4835DDY SO-8

Q7103 057G 761 15 PDTC114ET SOT23

Q7106 057G 763912 MOSFET SI4835DDY SO-8

Q7107 057G 761 15 PDTC114ET SOT23

Q7108 057G 761 15 PDTC114ET SOT23

R1101 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1103 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1106 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1107 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1108 061G0402223 JT RST CHIP 22K 1/16W 5% TZAI YUAN

R1110 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1111 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1113 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1114 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1115 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1116 061G04027509FT RST CHIP 75R 1/16W 1%

R1117 061G04027509FT RST CHIP 75R 1/16W 1%

R1118 061G04027509FT RST CHIP 75R 1/16W 1%

R1119 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1120 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1121 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1122 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1123 061G0402222 JT RST CHIP 2K2 1/16W 5% TZAI YUAN

R1124 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1125 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1126 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1127 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1201 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1202 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1203 061G0402680 JT RST CHIP 68R 1/16W 5% TZAI YUAN

R1205 061G04027509FT RST CHIP 75R 1/16W 1%

R1206 061G04027509FT RST CHIP 75R 1/16W 1%

R1207 061G04027509FT RST CHIP 75R 1/16W 1%

R1208 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1209 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1210 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1211 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1212 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1223 061G04027509FT RST CHIP 75R 1/16W 1%

R1231 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1232 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1401 061G04027509FT RST CHIP 75R 1/16W 1%

R1402 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1404 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1405 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1406 061G04027509FT RST CHIP 75R 1/16W 1%

97

R1407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1408 061G04027509FT RST CHIP 75R 1/16W 1%

R1409 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1410 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1414 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1416 061G0402123 JT RST CHIPR 12KOHM +-5% 1/16W TZAI YUAN

R1417 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1502 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1503 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1504 061G04027509FT RST CHIP 75R 1/16W 1%

R1505 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1506 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1602 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1603 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1604 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1606 061G04027509FT RST CHIP 75R 1/16W 1%

R1607 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R1608 061G04027509FT RST CHIP 75R 1/16W 1%

R1609 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R1610 061G0805151 JT RST CHIPR 150OHM +-5% 1/8W TZAI YUAN

R1612 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1613 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1615 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1623 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

R1624 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1625 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1626 061G0402472 JT RST CHIP 4K7 1/16W 5% TZAI YUAN

R1701 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1703 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1704 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1705 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1706 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1707 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1708 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1710 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1711 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1712 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1713 061G0402473 JT RST CHIP 47K 1/16W 5% TZAI YUAN

R1714 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R1715 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1716 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1717 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R1722 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R1723 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1724 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R1725 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R1731 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

98

R1732 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R2101 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4101 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4104 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4105 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4110 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4111 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4112 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4113 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4114 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4115 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4116 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4120 061G0402333 JT RST CHIP 33K 1/16W 5% TZAI YUAN

R4125 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4139 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4140 061G0603102 JT RST CHIP 1K 1/10W 5% TZAI YUAN

R4141 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R4143 061G0402330 JT RST CHIP 33R 1/16W 5% TZAI YUAN

R4144 061G0402682 JT RST CHIP 6K8 1/16W 5% TZAI YUAN

R4145 061G0402273 JT RST CHIP 27K 1/16W 5% TZAI YUAN

R4146 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4148 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4149 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4150 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4151 061G04021001FT RST CHIP R 1Kohm 1/16W +/-1%

R4202 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4206 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

R4207 061G0402102 JT RST CHIP 1K 1/16W 5% TZAI YUAN

R4210 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4211 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4213 061G04023301FT RST CHIP 3K3 1/16W 1%

R4214 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4215 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4216 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4217 061G0603824 JT RST CHIP 820K 1/10W 5% TZAI YUAN

R4219 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4221 061G06035101FT RST CHIP 5K1 1/10W 1%

R4222 061G0402104 JT RST CHIP 100K 1/16W 5% TZAI YUAN

R4223 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4224 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R4226 061G0402513 JT RST CHIP 51K 1/16W 5% TZAI YUAN

R4228 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4229 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R4231 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4232 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4233 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R4235 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

99

R4236 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4237 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4239 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4249 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4250 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R4251 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4252 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4253 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4254 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4257 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4258 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4259 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4260 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R4261 061G0402000 JT RST CHIPR MAX0R05 1/16W TZAI YUAN

R5111 061G04021000FT RST CHIP 100R 1/16W 1%

R5112 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5113 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5114 061G0402220 JT RST CHIP 22R 1/16W 5% TZAI YUAN

R5202 061G0402272 JT RST CHIP 2K7 1/16W 5% TZAI YUAN

R5404 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5407 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5408 061G0402479 JT RST CHIP 4R7 1/16W 5% TZAI YUAN

R5414 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5415 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5417 061G0402470 JT RST CHIP 47R 1/16W 5% TZAI YUAN

R5421 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R5422 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R5423 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R5424 061G0402101 JT RST CHIP 100R 1/16W 5% TZAI YUAN

R6101 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6103 061G04022201FT RST CHIPR 2K2 +-1% 1/16W TZAI YUAN

R6109 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6110 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6114 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6118 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6119 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6120 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6125 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6127 061G0402103 JT RST CHIP 10K 1/16W 5% TZAI YUAN

R6129 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6130 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6131 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6132 061G0402474 JT RST CHIP 470K 1/16W 5% TZAI YUAN

R6139 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6140 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6141 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

R6146 061G0402100 JT RST CHIP 10R 1/16W 5% TZAI YUAN

100
