LCD TV User Manual
LC32H063D
LC42H063D
TÉLÉVISION À HAUTE DÉFINITION
INTERFACE MULTIMÉDIA HAUTE DÉFINITION
1
www.aoc.com
2010 AOC. All Rights Reserved.
This manual provides as an operational guide to user. All statements, technical information, and
recommendations in this manual and in any guides or related documents are believed reliable, but the
accuracy and completeness thereof are not guaranteed or warranted, and they are not intended to be,
nor should they be understood to be, representations or warranties concerning the products described.
1
Table of Contents
IMPORTANT INFORMATION ..............................................................................................................................................3
WARNING ..............................................................................................................................................................................................................................................3
CAUTION ...............................................................................................................................................................................................................................................3
NOTIFICATION ......................................................................................................................................................................................................................................3
IMPORTANT SAFETY INFORMATION ...............................................................................................................................3
USAGE INSTRUCTIONS .....................................................................................................................................................4
Installation ...............................................................................................................................................................................................................................................4
AC Power Cable ......................................................................................................................................................................................................................................4
LCD Screen .............................................................................................................................................................................................................................................5
Wiring .....................................................................................................................................................................................................................................................5
Electric Shock .........................................................................................................................................................................................................................................5
Lightning Storms .....................................................................................................................................................................................................................................5
When Not in Use ....................................................................................................................................................................................................................................5
Overloading ............................................................................................................................................................................................................................................5
Plug the Power Cable on the TV Set ......................................................................................................................................................................................................5
Optional Equipment ................................................................................................................................................................................................................................6
Small Accessories ..................................................................................................................................................................................................................................6
Antennas .................................................................................................................................................................................................................................................6
Batteries ..................................................................................................................................................................................................................................................6
Cleaning ..................................................................................................................................................................................................................................................6
Magnetic Influence ..................................................................................................................................................................................................................................6
Sound .....................................................................................................................................................................................................................................................7
Carrying the TV .......................................................................................................................................................................................................................................7
Ventilation ................................................................................................................................................................................................................................................7
Moisture ...................................................................................................................................................................................................................................................7
Volume Adjustment .................................................................................................................................................................................................................................8
Servicing ..................................................................................................................................................................................................................................................8
CONTENTS IN THE BOX ...................................................................................................................................................9
CONTROLS & CONNECTIONS ....................................................................................................................................... 10
SET-UP ............................................................................................................................................................................ 13
Inserting Batteries into the Remote control ..........................................................................................................................................................................................13
Attaching the Base ................................................................................................................................................................................................................................13
Wall-Mounting ......................................................................................................................................................................................................................................13
CONNECTING TV ............................................................................................................................................................ 14
Cable System or VHF/UHF Antenna System .......................................................................................................................................................................................14
High Definition Interface ........................................................................................................................................................................................................................14
HDMI Connection ..................................................................................................................................................................................................................................14
Component Signal Connection ..............................................................................................................................................................................................................14
Composite/ S-Video Signal Connection ................................................................................................................................................................................................15
PC Connection ......................................................................................................................................................................................................................................15
External sound Connection ...................................................................................................................................................................................................................15
PC INPUT SIGNAL REFERENCE CHART ..................................................................................................................... 16
VIDEO INPUT SIGNAL REFERENCE CHART ............................................................................................................... 16
USING AOC TV ................................................................................................................................................................. 17
Turning the TV On and Off ....................................................................................................................................................................................................................17
Initial Setting ..........................................................................................................................................................................................................................................17
Viewing Mode Selection ........................................................................................................................................................................................................................22
Switching Input Source ..........................................................................................................................................................................................................................23
OSD Manual Setting .............................................................................................................................................................................................................................24
Changing Channel/Flashback ...............................................................................................................................................................................................................25
Changing Volume, Mute and Sound Mode ...........................................................................................................................................................................................26
Adjust Video Setting ..............................................................................................................................................................................................................................27
Adjust Audio Setting .............................................................................................................................................................................................................................28
Adjust PC Setting ..................................................................................................................................................................................................................................29
Feature Setup ........................................................................................................................................................................................................................................30
TROUBLESHOOTING ..................................................................................................................................................... 37
DIMENSIONS & SPECIFICATIONS ................................................................................................................................ 38
INDEX................................................................................................................................................................................ 39
APPENDIX A..................................................................................................................................................................... 40
APPENDIX B..................................................................................................................................................................... 44
2
Important Information
WARNING
Energy Star
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION
RISQUE DE CHOC ELECTRIQUE,
NE PAS OUVRIR
PRECAUCION
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
This symbol is intended to alert the user to the
presence of insinuated “dangerous voltage”
within the TV’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature accompanying
the TV.
To reduce the risk of fire or electric shock, do not expose this TV to
rain or moisture, the TV shall not be exposed to dripping or splashing
and no objects filled with liquids, such as vases, shall be placed on
the TV.
CAUTION
To prevent electric shock, do not use this polarized AC plug with an
extension cord, receptacle or other outlet unless the blades can be
fully inserted to prevent blade exposure.
Use the Wall-Mount bracket or TV stand which was recommended by
AOC, and please consult your dealer for detailed information.
Use with other Wall-Mount Bracket or TV stand may cause instability
and possibly result in injury.
Please keep the factory default settings as shipped, in which the
product can meet Energy Star requirements.
Important Safety Information
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any the ventilation openings. Install in accordance
with the manufacturer’s instructions.
) Do not install near any heat sources such as radiators, heat 8
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
) Do not defeat the safety purpose of the polarized or grounding-9
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and third
grounding prong. The wide blade or third prong is provided for
your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
) Protect the power cord from being walked on or pinched 10
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
) Only use attachments/accessories specified by the 11
manufacturer.
) Use only with a cart, stand, tripod, bracket, or table specified 12
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
NOTIFICATION
FCC Class B Radio Frequency Interference Statement
Warning: (For FCC CERTIFIED MODELS)
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/ TV technician for
help.
Pursuant to FCC regulations, you are cautioned that any changes
or modifications not expressly approved in this manual could void
your authority to operate this equipment.
For details concerning safety precautions, see “Important Safety
Instructions” and “Important Usage Instructions” below.
SAFETY: Lamp Disposal
Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN MERCURY
AND MUST BE RECYCLED OR DISPOSED OF ACCORDING TO
LOCAL, STATE OR FEDERAL LAWS. FOR MORE INFORMATION,
CONTACT THE ELECTRONIC INDUSTRIES ALLIANCE AT WWW.
EIAE.ORG.
) Unplug this apparatus during lightning storms or when unused 13
for long periods of time.
) Refer all servicing to qualified service personnel. Servicing is 14
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or
has been dropped.
) If any liquid or solid object should fall inside the cabinet, unplug 15
the TV immediately and have it checked by qualified service
personnel before operating it further.
) Avoid operating the TV at temperatures below 32°F (0°C).16
) If the TV is transported directly from a cold to a warm location, 17
or if the room temperature changes suddenly, the picture may
be blurred or show poor color due to moisture condensation. In
this case, please wait a few hours to let the moisture evaporate
before turning on the TV.
) The TV shall be connected to a mains socket outlet with a 18
protective earthing connection.
) The mains plug or appliance coupler is used as the disconnect 19
device, the disconnect device shall remain readily operable.
) CAUTION – These servicing instructions are for use by qualified 20
service personnel only. To reduce the risk of electric shock,
do not perform any servicing other than that contained in the
operating instructions unless you are qualified to do so.
3
Usage Instructions
Installation
Placement
It is recommended to watch the TV at a distance of 3 -7 times which
of the screen height, and in moderate brightness. Watching the TV
for too long or in a dark room may cause eye fatigue. To obtain a
clear picture, do not expose the screen to direct illumination or direct
sunlight. It is recommended to use spot lighting directed down from
the ceiling or to cover the windows that face the screen with opaque
drapery. It is desirable to install the TV in a room where the floor and
walls are not of a reflective material.
3h~7h
h
To prevent the TV from toppling over and causing injury, take
measurement to secure the TV to a wall or stand.
The TV should be installed near an easily accessible AC power
outlet.
Observe the following in placing the TV. Otherwise the TV may fall
from the stand or Wall-Mount, causing damage or serious injury.
Place the TV on a stable, level surface.
Do not hang anything on the TV. Do not allow children to climb on
the TV.
Do not install the TV in places subject to extreme temperatures,
such as in direct sunlight, near a radiator, or near a heating vent
or exposed to direct air conditioning.
Never place the TV in hot, oily, humidor excessively dusty places.
Do not install the TV where insects may enter.
Do not install the TV where it may be exposed to mechanical
vibration.
Do not install the TV in a location where it may protrude, such as
on or behind a pillar, or where you might bump your head on it.
Otherwise, it may result in injury.
Outdoor Use
Do not install this TV outdoors. If the TV is exposed to rain, it may
result in a fire or an electric shock. Do not expose the TV to direct
sunlight, it may heat up and become damaged.
Vehicle, Ships and Other Vessels
Do not install this TV in a vehicle.
Bumping of the vehicle may cause the TV to fall down and cause
injury.
Do not install this TV in a ship or vessel. If the TV is exposed to
seawater, it may cause a fire or damage the TV.
Medical institutions
Do not place this TV in a place where medical equipment is in
use.
The interference may cause a malfunction of both TV and the
medical equipment.
Attachments
Do not use attachments not recommended by the manufacturer, as
they may cause hazards.
Wall-Mount
Wall-Mount installation requires the use of a Wall-Mount Bracket.
When installing or removing the TV, using a Wall-Mount Bracket,
be sure to use qualified contractors. If not properly secured during
installation or removal from the Wall-Mount Bracket, the TV may fall
and cause serious injury.
For use only with UL Listed Wall Mount Bracket with suitable weight/
load. Please refer to page 38.
Observe the following when installing the TV using a Wall-Mount
bracket.
123
Be sure to follow the operating instructions supplied with the Wall-
Mount bracket when installing the TV.
Be sure to attach the brackets supplied with the Wall-Mount
bracket.
Don’t hang the TV from the ceiling. It may fall and cause serious
injury.
AC Power Cable
Use the AC power cord specified by AOC and suitable for the
voltage where you use it.
The plug is designed, for safety purposes, to fit into the wall outlet
only one way. If you are unable to insert the plug fully into the
outlet, contact your dealer.
If you will not be using the TV for several days, disconnect the
power by pulling the plug itself. Never pull on the cord.
When disconnecting AC power cord, the power cord should be
easily accessible for disconnection.
TV should be installed near an easily accessible power outlet. Do
not use a poor fitting outlet. Insert the plug fully into the outlet. If it is
loose, it may cause arcing and result in a fire. Contact your electrician
to have the outlet changed.
Observe the followings to prevent the AC power cord from being
damaged. If the AC power cord is damaged, it may result in a fire or
an electric shock. Stop using it and ask your dealer or AOC service
center to exchange it.
Do not place the TV where the power cord is subject to wear or
abuse.
Do not pinch, bend, or twist the cord excessively. The core lines
may be bared and cut, causing a short-circuit, and resulting in a
fire or an electric shock.
Do not convert or damage the power cord.
Do not allow anything to rest on or roll over the power cord.
Do not move the TV with the power cord plugged in.
Keep the power cord away from heat sources.
To unplug power cord, disconnect it from the wall outlet first.
Be sure to grasp the plug when disconnecting the power cord.
Do not pull the power cord.
Do not use the supplied AC power cord on any other equipment.
Use only an original AOC AC power cord, not other brands.
4
LCD Screen
Although the LCD screen is made with high-precision technology
and has effective pixels of 99.99% or more, black dots or bright
points of light (red, blue, or green) may appear constantly on the
LCD screen. This is a structural property of the LCD panel and is
not a malfunction.
The LCD screen is made with high-precision technology and to
achieve a high level of performance and picture quality, this TV’s
backlight setting is set to maximize the brightness of the TV.
However, uneven brightness may be observed when the LCD TV
is viewed in a dark ambient without an input source or a blank
screen. This condition is normal and not a malfunction of the TV.
Changing the Picture mode, Backlight setting, enabling the Light
Sensor, or turning on the Power management will improve this
condition.
Do not expose the LCD screen surface to direct sunlight. Doing so
may damage the LCD panel.
Do not push or scratch the LCD screen, or place objects on top
of the TV. The image may be uneven or the LCD panel may be
damaged.
If the TV is used in a cold place, a smear may occur in the picture
or the picture may become dark. This does not indicate a failure.
These phenomena improve as the temperature rises.
Ghosting may occur when still pictures are displayed continuously.
It should disappear after a few moments.
The screen and cabinet get warm when the TV is in use. This is
not a malfunction.
Avoid spraying insect repellent with volatile material on the
screen.
Avoid prolonged contact with rubber or plastic material.
Broken Pieces
Do not throw anything at the TV. The screen glass may break by the
impact and cause serious injury.
If the surface of the TV cracks, do not touch it until you have
unplugged the AC power cord. Otherwise electric shock may result.
Electric Shock
Do not touch the AC power cord or the TV with a wet hand. If you
plug/unplug the AC power cord from the TV with a wet hand, it may
cause electric shock.
Lightning Storms
For added protection for this TV during a lightning storm, or when it
is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna. This will prevent damage
to the TV due to lightning and power line surges.
When Not in Use
If you will not be using the TV set for several days, the TV set should
be disconnected from the AC power outlet for environmental and
safety reasons. The TV set is not disconnected from the AC power
source when the TV set is switched off. To disconnect the TV set
completely, pull the plug from the AC power outlet.
Handling of broken glass and liquid crystal leakage
If the LCD panel gets damaged, crystalline liquid leakage may occur,
or scattered broken glass may result. Do not touch broken glass or
crystalline liquid which is toxic, with bare hands as cuts, poisoning or
skin irritation may occur. Also, do not let glass fragments or leaked
crystalline liquid get into your eyes or mouth. Should either contact
your eyes or mouth, rinse the contacted area thoroughly with water
and consult your doctor.
Wiring
When connecting cables, be sure to unplug the AC power cord for
your safety. Take care not to catch your feet on the cables. It may
damage the TV set.
Overloading
This TV set is designed to operate on a 120 V AC supply only. Take
care not to connect too many appliances to the same AC power
outlet as this could result in a fire or an electric shock.
Plug the Power Cable on the TV Set
When you connect the power cable on your TV set, please make
sure that the power cable was connected well.
5
Optional Equipment
Do not install optional equipment too close to the TV set. Keep
optional equipment at least 11.875 inches (30 cm) away from the TV
set. If a VCR is installed in front of the TV set or beside the TV set,
the picture may become distorted. Picture distortion and/or noisy
sound may occur if the TV set is positioned in close proximity to any
equipment emitting electromagnetic radiation.
Small Accessories
Keep small accessories out of children’s reach.
Antennas
Outdoor antenna grounding
If an outdoor antenna is installed, follow the precautions below.
An outdoor antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where
it can come in contact with such power lines or circuits.
WHEN INSTALLING AN OUTDOOR ANTENNA SYSTEM,
EXTREME CARE SHOULD BE TAKEN TO KEEP FROM
CONTACTING SUCH POWER LINES OR CIRCUITS AS CONTACT
WITH THEM IS ALMOST INVARIABLY FATAL.
Be sure the antenna system is grounded so as to provide some
protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code (NEC) in USA and
Section 54 of the Canadian Electrical Code in Canada provides
information with respect to proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and requirements
for the grounding electrode.
Antenna grounding according to the National Electrical Code,
ANSI/NFPA 70.
Antenna lead-in wire
Antenna lead-in wire
Batteries
Do not dispose of batteries in a fire.
Do not short circuit, disassemble or overheat the batteries.
Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type.
The batteries (batteries installed) shall not be exposed to
excessive heat such as sunshine, fire or the like.
Disposal of used batteries
To preserve our environment, dispose of used batteries according to
your local laws or regulations.
Cleaning
Cleaning the AC power plug
Unplug the AC power plug and clean it regularly. If the plug is
covered with dust and it picks up moisture, its insulation may
deteriorate and result in a fire.
Cleaning the screen surface/ cabinet of the TV set
Unplug the AC power cord to avoid electric shock when cleaning.
Clean the cabinet of the TV with a dry soft cloth. To remove dust
from the screen, wipe it gently with a soft cloth. Stubborn stains
may be removed with a cloth slightly dampened with a solution
of mild soap and warm water. Never use strong solvents such as
thinner or benzine for cleaning.
If using a chemically pretreated cloth, please follow the instruction
provided on the package.
The ventilation holes can accumulate dust over time. To ensure
proper ventilation, we recommend removing the dust periodically
(once a month) using a vacuum cleaner.
Magnetic Influence
This TV contains a strong magnet in the speaker unit that generates
a magnetic field. Keep any items susceptible to magnetic fields away
from the speaker.
Ground clamps
Electric service
equipment
Ground clamps
Power service grounding
electrode system
Grounding conductors
Antenna discharge unit
6
Sound
If a snapping or popping sound from the TV is continuous or frequent
while the TV is operating, unplug the TV and consult your dealer or
service technician. It is normal for some TV’s to make occasional
snapping or popping sounds, particu larly when being turned on or off.
ding~
?
Pong~
Carrying the TV
Carry the TV in the specified manner
To avoid dropping the TV and causing serious injury, be sure to
follow these guidelines:
Before carrying the TV, disconnect all cables.
Carrying the large size TV requires two or more people.
When you carry the TV, place your hand as illustrated and hold it
securely. Do not put stress on the LCD panel.
Install on the wall
4 inches
10 cm
Installed with stand
4 inches
10 cm
11 7/8 inches
30 cm
4 inches
10 cm
11 7/8 inches
30 cm
4 inches
10 cm
Leave at least this space
around the set.
4 inches
10 cm
Leave at least this space
around the set.
When lifting or moving the TV, hold it firmly from the bottom. Place
your palm directly under the panel.
When carrying, do not subject the TV to shocks or vibration, or
excessive force.
Ventilation
The slots and openings in the TV are provided for necessary
ventilation. To ensure reliable operation of the TV and to protect it
from overheating, these slots and openings must never be blocked or
covered.
Unless proper ventilation is provided, the TV may gather dust and get
dirty. For proper ventilation, observe the following:
Do not install the TV face up, down or sideways.
Do not install the TV turned over or upside down.
Never cover the slots and openings with a cloth or other materials.
Never block the slots and openings by placing the TV on a bed,
sofa, rug or other similar surface.
Never place the TV in a confined space, such as a bookcase or
built-in cabinet, unless proper ventilation is provided.
Leave some space around the TV set as shown below. Otherwise,
air-circulation may be inadequate and will cause overheating, which
may cause a fire or damage to the TV set.
4 inches
10 cm
Never install the TV set where Air circulation is blocked.
Objects and ventilation holes
Never push objects of any kind into the TV through the cabinet slots
as they may touch dangerous voltage points or short out parts that
could result in a fire or an electric shock. Do not place any objects on
the TV.
Moisture
Moisture and flammable objects
The TV must not be exposed to dripping or splashing. Do not
place objects filled with liquids, such as vases, on the TV.
Do not use power-line operated TV sets near water— for
example, near a bathtub, washbowl, kitchen sink, or laundry tub,
in a wet basement, or near a swimming pool, etc. It may result in a
fire or an electric shock.
Do not let this TV get wet. Never spill liquid of any kind on the TV.
If any liquid or solid object does fall through, do not operate the
TV. It may result in electric shock or damage to the TV. Have it
checked immediately by qualified personnel.
To prevent fire, keep flammable objects or open flame (e.g.
candles) away from the TV.
7
Volume Adjustment
Adjust the volume so as not to trouble your neighbors. Sound
carries very easily at night. Therefore, closing the windows or using
headphones is suggested.
When using headphones, adjust the volume so as to avoid excessive
levels, as hearing damage may result.
Servicing
Do not attempt to service the TV by yourself since opening the
cabinet may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
Replacement Parts
When replacement parts are required, be sure the service technician
certifies in writing that he/she has used replacement parts specified
by the manufacturer that have the same characteristics as the
original parts.
Unauthorized substitutions may result in a fire, an electric shock or
other hazards.
Dolby License Notice and Trademark
Acknowledgement
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
is a trademark of SRS Labs, Inc.
TruSurround HD technology is incorporated under license from SRS
Labs, Inc.
Canadian notice
This Class B digital apparatus meets all requirements of the
Canadian Interference Causing Equipment Regulations.
Safety Check
Upon completion of any service or repairs to the TV, ask the service
technician to perform routine safety checks (as specified by the
manufacturer) to determine that the TV is in safe operating condition,
and to so certify. Ask a qualified service technician to dispose of the
TV.
Thank you for purchasing this AOC high-definition television. The
quality of the image you see on your AOC TV is only as good as the
quality of the signal it receives. To experience the stunning detail of
your new AOC TV, you need access to HD programming. Your AOC
TV can receive and display HD programming from:
Over-the-air broadcasting via HD-quality antenna
HD cable subscription
HD satellite subscription
Blu-ray Disc™ player or other external equipment
Contact your cable or satellite provider for information on upgrading
to HD programming.
Mobile telephone warning
To avoid disturbances in picture and sound, malfunctioning of your
TV or even damage to the TV, keep away your mobile telephone
from the TV.
End of life directive
We are paying a lot of attention to produce environmental friendly in
green focal areas.
Your new receiver contains materials, which can be recycled and
reused.
At the end of its life, specialized companies can dismantle the
discarded receiver to concentrate the reusable materials and to
minimize the amount of materials to be disposed of.
Please ensure you dispose of your old receiver according to local
regulations.
8
Contents in the Box
After unpack the TV box, please check the TV and all accessories are well presented and undamaged.
32”
42”
Screw x 4
AOC LCD TV
Base
HDMI/PC
LAST
ADD
FAV
PHOTO WIDE
To fix stand to base
Power Cable Remote Control AA Battery x 2
T4
M6
User
Manual
User Manual
QSG Warranty
Card
Quick Start Guide Warranty Card
9
Controls & Connections
Speaker Speaker
AUDIO OUT PC In
Power Indicator
IR Receiver
Volume +
Volume -
Channel
Channel
Menu
Input
Power
1. VOL + Press to increase the sound volume level.
2. VOL - Press to decrease the sound volume level.
3. CH ▲ Press to select the next higher program number.
4. CH ▼ Press to select the next lower program number.
5. MENU
6. INPUT Press to select the input source.
7.
VHF/UHF Cable In
Press to open or exit the OSD (on-screen display)
menu.
Power Press to turn on / off (standby) the TV set.
Headphone Jack
USB/Service
HDMI 4
HDMI 3
HDMI 2
HDMI 1
SPDIF
S-Video
AV in L-Audio-R
Component In
Item Description
Headphone Jack
*
SPDIF
(Optical Digital Audio Out)
AV IN (AV/S-VIDEO) /
L-AUDIO-R
Connects to your headphones. If your headphones do not match the jack, use a suitable plug adapter (not
supplied). While headphones are connected, the TV speakers are muted.
Connect an external sound system with optical cable to the SPDIF out jack on the back of your TV to the SPDIF
IN jack and to the amplifier or receiver.
Connects to the COMPOSITE VIDEO output or S-Video output jack from your video equipment that has
COMPOSITE or S-Video VIDEO, and audio (L/R) jacks can connect audio source to your TV. When connected,
S-Video will take priority over Composite video (Yellow jack).
USB/Service Insert USB storage device to the USB 2.0 port to view photos (JPEG only) or for Time Shift feature.
Connects to the S-VIDEO output jack on your camcorder or other video equipment that has S-VIDEO. The
S-VIDEO Input
S-VIDEO provides better picture quality than composite video. The audio input connector was shared with
COMPOSITE VIDEO IN.
HDMI (High-Definition Multimedia Interface) provides an uncompressed, all-digital audio/video interface between
this TV and any HDMI-equipped audio/video equipment, such as a set-top box, DVD player, Blu-ray Disc player,
A/V receiver as well as PC. HDMI supports enhanced, or high-definition video, plus digital audio.
If the equipment has a DVI jack, connect the DVI jack to the HDMI IN (with DVI-to-HDMI cable or adapter) jack,
and connect the audio jack to the PC AUDIO IN jacks of HDMI IN. (HDMI 1 only)
HDMI IN 1/ 2 / 3 / 4
DVI-to-HDMI cable DVI-to-HDMI adapter
HDMI connection is necessary to view 480i, 480p, 720p, 1080i and 1080p formats.
Be sure to use only an HDMI cable that bears the HDMI logo.
Connects to a personal computer’s video output connector using HD15-HD15 cable (analog RGB). Can also be
connected to other analog RGB equipment. See “PC Input Signal Reference Chart” on page 15 for the signals
PC IN (RGB/AUDIO)
that can be displayed.
For some Apple Macintosh computers, it may be necessary to use an adapter (not supplied). If this is the case,
connect the adapter to the computer before connecting the HD15-HD15 cable.
If the picture is noisy, flickering or not clear, adjust Phase and Pitch of Screen settings.
Component IN
(1080p/1080i/
720p/480p/480i)/
L-AUDIO-R
VHF/UHF/Cable Input
Connects to your TV’s component video (YPbPr ) and audio (L/R) jacks. Component video provides better
picture quality than the S-VIDEO or the composite video connections. Component video (YPbPr) connection is
necessary to view 480i, 480p, 720p, 1080i and 1080p formats.
RF (Radio Frequency or modulated signal design used as the carrier for television broadcasts.) input that
connects to your Cable or VHF/UHF antenna.
* SPDIF
Sony/Philips Digital Interconnect Format. S/PDIF is mostly used to transmit compressed multichannel audio from a media player to an amplifier/receiver.
10
Buttons located at the right side of the TV will operate the same as these buttons on the remote control.
Button Description
POWER Press to turn on and off the TV or target controlled device.
SET Set device code for the device which you want to control.
TV/DVD/STB/
AUX
HDMI/PCHDMI/PC
TV/ AV/ COMP/
HDMI/PC
Press TV, DVD, STB, or AUX to switch the device which you
want to control.
Press TV, AV, COMP or HDMI/PC separately to select the input
directly.
HDMI/PC
LAST
ADD
FAV
PHOTO WIDE
LAST
ADD
FAV
0-9
LAST
Press 0-9 to select a channel; the channel changes after two
seconds.
Press to go back to the previous TV channel or exit from the
OSD when displaying menu items and settings.
VOL +/- Press to adjust the volume.
INPUT
—
MUTE
CH +/-
/ / /
Press to display the list of External Inputs and TV mode. Press
repeatedly to toggle through the inputs.
Use with 0-9 buttons to select digital channels. For example, to
enter 2-1, press
.
Press to mute the sound. Press again or press VOL to restore
the sound.
Press to scan through channels. To scan quickly through
channels, press and hold down either + or -.
Move left, up, down or right to select the available option or
adjust the setting in OSD menu.
OK/ENTER Press to confirm the selected item or setting.
Press to display or close a list of convenient functions and menu
MENU
shortcuts. The OSD (On Screen Display) menu items vary based
on input and content.
Press to close a list of convenient functions and menu shortcuts.
EXIT
The OSD (On Screen Display) menu items vary based on input
and content.
Press once to display the information pertaining to the channel
INFO
and/or program when available. The OSD (On Screen Display)
will time out in a few seconds or press again to immediately turn
off the display.
ADD FAV Press to add channel to Favorite List.
FAV Press to display the Favorite Channel List.
WIDE
Press to display digital program guide in TV mode. It may
GUIDE
show current channel name, program name, time, rating, and
summaries, depending on the information provided by the
broadcaster.
Press repeatedly to step through the Wide Mode settings:
WIDE
Normal Mode, Wide mode, Zoom 1 Mode, Zoom 2 Mode, and
HDMI PC mode (Only available in HDMI Input).
PHOTO Switch the JPEG Viewer Function.
Press repeatedly to cycle through the available sleep timer,
SLEEP*
5, 10, 15, 30, 60, 90, 120 180 and 240 minutes to turn off TV
automatically.
Press repeatedly to cycle through the available picture modes:
PICT
Vivid, Standard, Eco, Movie and Personal. The picture modes
can also be accessed in the Picture settings. For details, see
section- Adjust Picture Setting.
Press repeatedly to cycle through the available sound modes:
AUDIO
Music, Speech and Personal. The sound modes can also be
accessed in the Sound settings. For details, see section- Adjust
Audio Setting.
11
Button Description
CC
Play
Pause
Stop
Replay
Press repeatedly to change the closed caption type as CC Off /
CC On / CC On With Mute.
Execute “Play” function on DVD or other devices. When your
controlled device is TV, there is no function.
Execute “Pause” function on DVD or other devices. When your
controlled device is TV, there is no function.
Execute “Stop” function on DVD or other devices. When your
controlled device is TV, there is no function.
Execute “Replay” function on DVD or other devices. When your
controlled device is TV, there is no function.
Rewind
Fast Forward
Skip Forward Execute skip ahead in your program.
PVR/LIST
Record
* Sleep
You can set a time period for which the TV will be turned off automatically.
Execute “Rewind” function on DVD or other devices. When your
controlled device is TV, there is no function
Execute “Fast Forward” function on DVD or other devices. When
your controlled device is TV, there is no function.
Execute “PVR/LIST” function on STB device. When your
controlled device is TV, there is no function.
Execute “Record” function on STB device. When your controlled
device is TV, there is no function.
12
Set-Up
Inserting Batteries into the Remote control
Insert two size AA batteries (supplied) to the diagram inside the battery compartment of the remote control.
Attaching the Base
IMPORTANT: The Base of the AOC LCD TV must be assembled prior to usage.
Place the TV set facing down on a soft and flat surface (blanket, foam, cloth, etc.) to prevent any 1.
damage to TV set.
Carefully align and insert the Base to the stand2.
Secure the screws on the bottom of the base. 3.
Please refer to the “Important Usage instructions” in the above.4.
Wall-Mounting
Please install on a wall by using a Wall-Mount Bracket (sold separately). Before mounting the TV on a wall, the Stand must be removed from the
TV. Follow the simple steps below to remove the Table-Top Stand:
Disconnect all the cables from the TV.1.
Gently lay the TV, face down, onto a level and stable surface covered with a thick and soft cloth. Make sure the Stand is hanging over the 2.
edge.
Remove the screws as shown in the illustration for your model and pull the Stand out. 3.
Do not remove any other screws from the TV. 4.
Do not remove the Stand for any reason other than to Wall-Mount5. the TV.
Be sure to store the removed screws and Stand in a safe place until you are ready to reattach the Stand. Keep the screws away from small 6.
children.
For bracket installation, refer to the instruction guide provided by the Wall-Mount7. Bracket model for your TV. Sufficient expertise is required in
installing this TV, especially to determine the strength of the wall for withstanding the TV’s weight.
For product protection and safety reasons, AOC strongly recommends that you use the Wall-Mount8. Bracket model designed for your TV and
the Wall-Mounting of your TV should be performed by AOC dealer or licensed contractor.
123
Note: Wall mount bracket & screws (Screws length: 10mm and pitch: 0.7mm) are not included.
Please contact your local distributor.
13
Connecting TV
Cable System or VHF/UHF Antenna System
You can enjoy standard-definition and high-definition digital programming (if available in your area), along with standard-definition analog
programming.
This TV is capable of receiving unscrambled digital programming for both cable and external VHF/UHF antenna.
It is strongly recommended that you connect the antenna/cable input using a 75-ohm coaxial cable to receive optimum picture quality. A 300-ohm
twin lead cable can be easily affected by radio frequency interference, resulting in signal degradation.
Cable or VHF/UHF(or VHF only)
TUNER
75-ohm coaxial
cable (supplled)
Rear of TV
VHF/UHF input
High Definition Interface
You can enjoy high-definition programming by subscribing to a high-definition cable service or a high-definition satellite service. For the best
possible picture, make sure you connect this equipment to your TV via the HDMI or component video (with audio) input on the back of your TV.
HDMI Connection
HDMI IN 1 / 2 / 3 / 4
HDMI
HD Multimedia Interface
HDMI
If the equipment has a DVI jack, connect the DVI jack to the HDMI IN (with DVI-to-HDMI cable or adapter) jack and connect the audio jack to the
PC AUDIO IN jacks. (Only HDMI1 support DVI audio.)
HDMI
HDMI
Component Signal Connection
Component IN
Y Pb Pr
Component Video Input
LRYPbPr LRYPbPr
Audio
14
Composite/ S-Video Signal Connection
AV IN
AV
AV IN
S-VIDEO
S-VIDEOS-VIDEO
Audio
PC Connection
Use the TV as a monitor for your PC shown below with the HD15 to HD15 connection. This TV can also be connected to a PC with DVI or HDMI
output. (Refer to the separate Quick Setup Guide.)
VGA IN
PC
Connect the PC IN jack to the PC using the HD15- HD15 cable with ferrite core (analog RGB) and audio cable.
If the PC is connected to the TV and no signal has been input from the PC for more than 30 seconds, the TV enters the standby mode
automatically.
External sound Connection
Turn off the AOC LCD TV and Sound Device and connect the Audio Out jack or SPDIF jack on the rear of AOC LCD TV.
Connect an audio cable to the audio output connectors associated with the Audio Out (R/L) and SPDIF on the TV Set and connect the other
end to the audio connectors associated with the Audio input of the External Sound.
SPDIF IN
SPDIF
SONY Philips Digital Interface
15
PC Input Signal Reference Chart
After connecting the PC to the TV, set the output signal from the PC according to the chart below.
Presetting PC Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
VESA 640 x 480 31.469 59.94
VESA 800 x 600 37.879 60.317
VESA 1024 x 768 48.363 60.004
VESA 1280 x 720 44.772 59.855
VESA 1280 x 768 47.396 59.995
VESA 1280 x 1024 63.981 60.02
VESA 1440 x 900 55.469 59.901
VESA 1680 x 1050 65.29 59.954
VESA 1920 x 1080 67.5 60
Video Input Signal Reference Chart
After connecting the video input to the TV, set the output signal from the video input according to the chart below.
Presetting Video Mode
Standard Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz)
SD 480i 15.734 60
SD 480P 31.5 60
HD 720P 45 60
HD 1080i 33.75 60
FHD 1080p 67.5 60
Standard Definition Interface
You can also enjoy traditional program by using a DVD player or VCR Player. Connect this equipment to your TV via the Composite Input or
S-Video Input on the back of your TV.
Refer to the Quick Setup Guide (supplied) when connecting other equipment to your TV.
16
USING AOC TV
Turning the TV On and Off
You can turn on the TV by using power switch button on the TV set or on the remote controller.
Initial Wizard (1/8)
Please select language...
English
Spanish
French
Next Cancel
Navigate: Select:
OK
Initial Setting
When you first start up this AOC LCD TV set, please follow the Initial Wizard to your AOC LCD TV.
1. Selecting Language
Select your preferred language: English, Spanish or French
1 Press ▲/▼ to select “Language”, and press OK/ENTER.
2. Selecting Time mode
Initial Wizard (2/8)
Please select Time mode...
Auto
Manual
Previous Cancel
Navigate: Select:
1 Press ▲/▼ to select “Auto” or “Manual” for Time Mode.
17
OK
A. Selecting Time Zone
Inital Wizard (3/8)
Please select Time Zone...
NST MST
AST PST
EST AKST
CST HST
Previous Cancel
Navigate: Select:
1 Press ▲/▼/◄/► to select “Time Zone” which you located then press OK/ENTER.
OK
18
B. Manually enter the time
Initial Wizard (3/8)
Please enter the time...
Month
Day
Time
Previous Cancel
2010Year
Jan
1
12:02 AM
OK
Navigate: Select:
Year
1 Press ▲/▼ to select “Year” then press OK/ENTER.
2
Press ◄/► to adjust then press OK/ENTER.
Month
1 Press ▲/▼to select “Month” then press OK/ENTER.
2
Press ◄/► to adjust then press OK/ENTER.
Day
1 Press ▲/▼ to select “Day” then press OK/ENTER.
OK
2
Press ◄/► to adjust then press OK/ENTER.
Time
1 Press ▲/▼ to select “Time” then press OK/ENTER.
2
3
Press ◄/► to select “Hour”, “Minute” or “AM/PM” then press OK/ENTER.
Press ▲/▼ to adjust then press OK/ENTER.
19
3. Select “Eco” mode or “Vivid” mode
When you turn on TV in the first time, you can choose “Eco” mode to decrease backlight level to save the power consumption or “Vivid” mode to
enhance picture contrast and sharpness.
Initial Wizard (4/8)
Please select Eco/Vivid mode...
Eco
Vivid
Previous Cancel
Navigate: Select:
1 Press ▲/▼ to select “Eco” or “Vivid” for display setting.
4. Select TV RF tuning band
Initial Wizard (5/8)
Please select TV RF tuning band...
Air
Cable
Previous Cancel
Navigate: Select:
ENTER
OK
1 Press ▲/▼ to select “Air” or “Cable” for RF Tuning setting. Press OK/ENTER will execute channel searching.
20
5. Search TV channel
Initial Wizard (6/8)
Please check if RF cable is
connected properly...
Start
Previous Cancel
Navigate: Select: OK
1 Press ▲/▼ to select “Previous” or “Cancel” for RF Tuning setting. Press OK/ENTER will execute channel searching.
Initial Wizard (7/8)
Searching, Please wait...
Searching Analog CH
100%
Cancel
Navigate: Select: OK
1 Press ▲/▼ to select “Cancel” for RF Tuning setting. Press OK/ENTER will execute cancel the channel searching.
Initial Wizard (8/8)
Congratulations, TV Setup is done.
CH 100
66Analog Channels Found
55Digital Channels Found
1 Press EXIT to exit initial setting wizard.
Exit: Cancel
21
Viewing Mode Selection
For TV input with SD programs
Normal Mode
Suitable for viewing conventional 4:3 programs in
their normal format.
Wide Mode
The original content in this mode has to fill the
entire screen of the display.
Zoom1 Mode
Use these aspect modes to zoom in and to reduce
the black bars.
Zoom2 Mode
Use these aspect modes to zoom in and to reduce
the black bars.
For TV input with HD programs
Normal Mode
Suitable for viewing conventional 4:3 programs in
their normal format.
Wide Mode
The original content in this mode has to fill the
entire screen of the display.
Zoom1 Mode
Use these aspect modes to zoom in and to reduce
the black bars.
Zoom2 Mode
Use these aspect modes to zoom in and to reduce
the black bars.
Note:
HDMI PC Mode (Only available in HDMI input)
Displays an image with the same number of pixels on the screen without over scan
22
Switching Input Source
On AOC TV, you can choose signal source on the remote control directly, or press “Source” to choose the signal source on the display menu.
When choosing signal source on the remote control1. directly: Press the following keys to switch input source.
HDMI/PCHDMI/PC
ADD
FAV
PHOTO WIDE
HDMI/PC
LAST
When using 2. INPUT key to choose signal source:
Source List
0. TV
1. AV
2. Component
3. VGA
4. HDMI 1
5. HDMI 2
6. HDMI 3
7. HDMI 4
OK
Move Select Exit
ENTER
EXIT
1 Press INPUT to call out source menu.
2
3
Press ▲/▼ to select input source: TV, AV, Component, VGA, HDMI 1 / 2 / 3 / 4.
Press OK/ENTER to enter.
LAST
ADD
FAV
PHOTO WIDE
HDMI/PC
23
OSD Manual Setting
Channel Search
CHANNEL
Tuning Band
Channel Strength
Auto CH Search
Add on CH Search
Channels List
Channel Labels
FAV Channel Setting
Move Select Return Exit
1 Press MENU to call out MENU.
2
3
OK
ENTER
Press ▲/▼ to select “Channel” , and press OK/ENTER.
Press ▲/▼ to select “Auto CH Search”, and then press OK/ENTER.
Cable
EXIT
The submenu of CHANNEL menu in TV mode shows as below.
1) Tuning Band: Select TV source signal from the Air (antenna) or Cable (CATV).
2) Channel Strength: Show the intensity of the received DTV signal.
3) Auto CH Search: Automatically scan all NTSC / ATSC TV channels and then store in the channel table. In channel scan process, the OSD
4) Add on CH Search: Add channels which are new found.
5) Channels List: Show the Channels List. User can edit (add/delete) the channel numbers.
6) Channel Labels: Show the NTSC /ATSC TV Channel Labels menu for user modifying channel labels specifically.
7) FAV Channel Settings: Show the Favorite Channel List. User can edit (add/delete) the favorite channels.
can display the number of channels which had been found.
24
Changing Channel/Flashback
On AOC TV, you can change channel on the remote control directly, or press CH ▲/▼ on the side of the TV to choose the channel.
Press the number keys directly to change the channel.1.
Press the 2. CH ▲/▼ to change channel.
Press 3. LAST to go to the previous channel.
LAST
25
Changing Volume, Mute and Sound Mode
Press 1. VOL+/- to change the volume.
Press 2. MUTE to mute the TV.
Press 3. AUDIO to change surround mode: Music, Speech and Personal.
For more details, please refer to “Adjust Audio Setting”.
26
Adjust Video Setting
VIDEO
Picture Mode
Brightness
Contrast
Sharpness
Color
Tint
Color Temp
Move Select Return Exit
1 Press MENU to call out MENU.
2
3
OK
ENTER
Press ▲/▼ to select “VIDEO” , and press OK/ENTER.
Press ▲/▼ to select Video Settings: Picture Mode, Brightness, Contrast, Sharpness, Color, Tint, Color Temp, Noise
Reduction, Adaptive Contrast, DCR, Backlight, Aspect Ratio, Preset, and press OK/ENTER to enter.
Eco
48
48
50
63
0
Cool
EXIT
4
5
Picture Setting Items Description
Picture Mode
Brightness Brightens or darkens the picture.
Contrast Increases or decreases picture contrast.
Sharpness Sharpens or softens the picture.
Color Increases or decreases color saturation.
Tint Increases or decreases the green tones.
Color Temp.
Noise Reduction
Adaptive Contrast Choose On or Off to adjust the gamma after analyzing the input signal automatically.
DCR Dynamic Contrast Ratio (DCR) auto adjusts the backlight of the screen.
Backlight Backlight strength adjustment, the tuning range is 0 ~ 30.
SMP SMP (Smart Motion Plus), gives four motion effect degrees, such as: Low, Mid, High, and Off.
Aspect Ratio Choose the display aspect.
Preset Restore the default video settings.
Press ◄/► to adjust.
Press EXIT to exit.
Vivid For Enhances picture contrast and sharpness.
Standard For standard picture settings. Recommended for home entertainment.
Eco Decrease backlight level to save the power consumption.
Movie For viewing film-based content. Most suitable for viewing in a theater-like environment.
Personal The user can set their favorite setting.
Preset for all inputs can also be accessed by pressing PICT on the remote control to directly toggle the modes.
Cool Gives the white colors a bluish tint.
Warm Gives the white colors a reddish tint.
Normal Gives the white color a nature tint.
Reduces the noise level of connected equipment, and the VHF/UHF/CABLE input.
Gives four NR effect degrees, such as: Low, Mid, High and Off.
27
Adjust Audio Setting
AUDIO
Sound Mode
Bass
Treble
Balance
Audio Source
SPDIF
Speaker
Move Select Return Exit
1 Press MENU to call out MENU.
2
3
OK
ENTER
Press ▲/▼ to select “Audio” , and press OK/ENTER.
Press ▲/▼ to select Audio Settings˖Sound Mode, Bass, Treble, Balance, Audio Source, Audio Language, SPDIF,
Speaker, Multi Language, AVL, SRS, Preset, and press OK/ENTER to enter.
Personal
32
32
0
Stereo
PCM
On
EXIT
4
5
Audio Setting Items Description
Sound Mode
Bass Increases or decreases lower-pitched sounds.
Treble Increases or decreases higher-pitched sounds.
Balance Emphasizes left or right speaker balance.
Audio Source Select the audio source from Mono, Stereo, or SAP. (This function works in ATV only.)
Audio Language
SPDIF
Speaker
Multi Language To choose the multi-language in DTV.
AVL Enable or disable Automatic Volume Level.
SRS
Preset Restore the default audio settings.
Press ◄/► to adjust.
Press EXIT to exit.
Music: Enhances treble and bass.
Speech: Enhances treble and keep bass in middle.
Personal: Adjust sound mode as personal favorite.
Sound Mode can also be accessed by pressing AUDIO on the remote control.
Change the audio language setting on ATSC TV programs. The number of the supported audio languages
(English / Français / Español)
Digital audio output format. Select from RAW and PCM. The difference between SPDIF PCM or RAW:
SPDIF PCM: It will only output as a PCM 44.1Khz digital no matter what the recording is in the media.
SPDIF RAW: It will output the stream as it is digitally recorded, i.e. DTS recording as a DTS or a Dolby as a Dolby, or
a native 48 or 96Khz.
Choose to turn on / off the TV internal speaker. The digital audio output signals and earphone output signals will not
be turned off even though the TV speaker is off. The default setting is On.
Solution of processing surround sound effect for playback over two speakers. Select On for optimizing bass/ treble
performance and intelligibility. Select Off for keeping current audio performance level.
28
Adjust PC Setting
This setting is only available in PC mode.
VGA
H-Position
V-Position
Clock
Phase
Auto Adjust
Preset
Move Select Return Exit
1 Press MENU to call out MENU.
2
3
OK
ENTER
Press ▲/▼ to select “PC” , and press OK/ENTER.
Press ▲/▼ to select PC Settings: H. Position, V. Position, Clock, Phase, Auto Adjust, Preset, and press OK/
ENTER to enter.
17
13
8
2
EXIT
4
5
PC Setting Description
H. Position Adjusts the Horizontal positioning.
V. Position Adjusts the Vertical positioning.
Clock Adjusts the Clock frequency on VGA signal.
Phase Adjusts the Phase frequency on VGA signal.
Auto Adjust
Preset Restore the default PC settings.
Press ◄/► to adjust.
Press EXIT to exit.
Auto sync. PC timing to fit full screen display.
For detail supported timing, please refer PC Input Signal Reference Chart on page 16.
29
Feature Setup
FEATURE
Menu Language
Time
Password Setting
Parental Control
Closed Captions
Analog Captions
Digital Captions
Move Select Return Exit
1 Press MENU to call out MENU.
2
3
OK
ENTER
Press ▲/▼ to select “Feature” , and press OK/ENTER.
Press ▲/▼ to select Setting items: Menu language, Time, Password Setting, Parental Control, Closed Captions,
Analog Captions, etc. and press OK/ENTER to enter.
English
Off
CC1
SERVICE1
EXIT
4
5
The submenu of FEATURE mode in TV mode shows as below.
Menu Language:1. Adjust the language setting for this TV unit. (English / Français / Español)
1 Press ◄/► to select: English / Français / Español, and press OK/ENTER.
Time:2. Set current time. The sub-menu includes Time Mode, Time Zone, and Daylight Savings.
FEATURE Time
Move Select Return Exit
Press ◄/► to adjust.
Press EXIT again to exit.
Time Mode
Time Zone
Daylight Savings
Year
Month
Day
Time
OK
ENTER
Auto
HST
On
2010
Jan
1
12:02 AM
EXIT
1 Scroll to Time and press OK/ENTER to enter the menu for Time adjustment.
2
Press ◄/► to adjust Auto or Manual setting for Time Mode and press OK/ENTER.
30
3 Press ▲/▼ to select “Time Zone”. Press ◄/► to adjust Time Zone which you located and press OK/ENTER.
4
5
6
Press ▲/▼ to select “Daylight Savings”. Press ◄/► to on/off Daylight Savings and press OK/ENTER.
For manually Time Mode setting, press ▲/▼ to select “Year”, “Month”, “Day”, and “Time”. Press ◄/► to adjust
“Year”, “Month”, “Day”, and “Time”, and press OK/ENTER.
Press EXIT to exit.
Password Setting:3.
Change the 4-numeral parental control password. Three steps are required for changing the password:
Step 1:
Enter Old Password
Press Number Key to enter the old password.
Step 2:
Enter New Password
Press Number Key to enter the New password.
Step 3:
Confirm New Password
Press Number Key to enter the New password.
Note: This item is only available in TV, Composite and S-Video source modes. The default password is [0 0 0 0].
Parental Control: 4.
FEATURE Parental Control
Button Lock
Block Unrated TV
USA Parental Locks
Canadian Parental Locks
Open V-Chip
Move Select Return Exit
ENTER
OK
Off
Off
EXIT
Provide the Parental Control (V-chip) function setting. Before entering the Parental Control sub-menu, user has to key in the password first.
Enter the Parental Lock item, then the user can modify the restricted table about MPAA or TV Rating respectively. While exiting the sub-menu,
the parental control function is working. The inhibitive channels or source signals can be unlock through pressing the V-CHIP key on the remote
control and then key in the correct password.
Note: This feature is only available in TV, Composite and S-Video source modes. (The default password is: 0 0 0 0.)
Parental Control: Description
Button Lock
Select On or Off to lock or unlock the control buttons on the side panel of the TV. When this function enables,
the control buttons on your TV will be locked and TV will be controlled by remote control only.
Block Unrated TV When Block Unrated TV is set to on, your TV will block unrated program.
USA Parental Locks Set the parental control level by MPAA or TV Rating.
Canadian Parental Locks Set the parental control level by English Rating or French Rating.
Open V-Chip
Open V-Chip is an advanced V-Chip rating system for digital channels that are received. The rating table will be
updated by downloading the RRT5 data for blocking.
31
Closed Captions5. : Select a closed caption option. (Off / On / With Mute)
Analog Captions:6. Select an analog caption option. (CC 1-4 / TEXT 1-4)
Digital Captions:7. Select a digital caption option. (SERVICE 1-6)
Digital Captions Setup:8. Provide numerous options for setting the digital closed caption style in the sub-menu.
Items Description
Set to Automatic or Customer mode. If Custom mode is selected, user can modify the detail styles described
Style
below. The setting result will be shown immediately on the bottom of the submenu OSD.
Note: This feature is only available in Digital TV (ATSC) mode.
Size Digital closed caption font size, which can be set as Automatic, Small, Normal, or Large.
Font Digital closed caption font style, which can be chosen as Automatic, Default, or Font 1 ~ 7.
Text Color Automatic / White / Red / Green / Blue / Yellow / Magenta / Cyan / Black.
Text Opacity Automatic / Solid / Flashing / Transparent / Translucent.
Background Color Automatic / Black / White/ Red / Green / Blue / Yellow / Magenta / Cyan.
Background Opacity Automatic / Solid / Flashing / Transparent / Translucent.
Edge Effect Automatic / None / Raised / Depressed / Uniform / Left Shadow / Right Shadow.
Edge Color Automatic / Red / Green / Blue / Yellow / Magenta / Cyan / Black / White.
HDMI CEC:9. Set the HDMI Control to ON and this feature will enable the HDMI CEC function and your AOC LCD TV will discover and
communicate automatically with other compatible HDMI interfaced devices. Select Off to disable this option.
FEATURE HDMI CEC
HDMI Control
Device Auto Off
TV Auto On
Root Menu
Device List
Move Select Return Exit
ENTER
OK
1 Press MENU to call out MENU.
2
3
4
Press ▲/▼ to select “Feature” , and press OK/ENTER.
Press ▲/▼ to select Setting item: HDMI Control and press OK to enter.
Press ▲/▼ to select Setting item: HDMI Control, Device Auto Off, TV Auto On, Root Menu, Device List, and press
OK/ENTER to enter.
On
Off
Off
EXIT
5
6
Press ◄/► to adjust.
Press EXIT to exit.
Items Description
HDMI Control Enable or Disable HDMI Control.
Device Auto Off
Enable of Disable Device Auto Off.
When you turn off the TV, all active CEC enabled devices on the HDMI inputs will go to Standby.
Enable or Disable TV Auto On
TV Auto On
Pressing the “Play” button on the CEC enabled device will commend the device to play, turn the TV on and the
HDMI input, that the device is connected to, will become the active input source for the TV.
Root Menu Accesses the menu of connected HDMI CEC-compatible device with your TV remote control.
Device List List the device which enabled the HDMI CEC function.
Note: Not all devices with an HDMI connection have the CEC feature. Consult the instruction manuals for the device you are trying to control to
confirm whether or not CEC is available.
32
Input Labels:10. User can edit the input labels.
Component Setting:11. This option only shows and is available in component mode, which provides fine tuning component display.
[Phase] – Adjust Picture Phase to reduce Horizontal-Line noise. The tuning range is from 0 to 100.
[Preset] – Restore the default component setting values.
MultiMedia Menu: 12.
[JPEG Viewer] – This option shows the settings for the photo play function from USB storage device.
Select item MultiMedia in Feature menu (this item will be disabled when USB thumb drive was not plugged in), then select JPEG Viewer to •
enter the sub menu.
1 Press MENU to call out MENU.
2
3
4
5
6
7
After plugging USB storage device into USB port, Multimedia List menu will display, or press “Photo” on the remote control after you •
plugging USB storage device.
Press ▲/▼ to select “Feature” , and press OK.
Press ▲/▼ to select Setting item: MultiMedia Menu and press OK to enter.
Press ▲/▼ to select Setting item: Time Shift and press OK to enter.
Press ▲/▼ to select Setting item: USB Disk Storage Format or Start. and press OK to enter.
Press ◄/► to adjust.
Press EXIT to exit.
Image Delay Normal
Start Slide Show
Rotate Photo
Filename\.. Filename
Filename
Back To Upper Folder
Back To Root Folder
Exit
1 Press OK to enter JPEG Viewer.
2
3
Press ▲/▼/◄/► to select, and press OK/ENTER to enlarge the selected photo (orange frame) browser.
Press MENU to display control menu.
FilenameFilename
33
Multimedia List
1. JPEG Viewer
Exit
JPEG Viewer Control: Description
Image Delay Set display time for each picture in slide show. There are three options: Fast, Slow, and Normal.
Start Slide Show Enter Slide Show mode.
Rotate Photo Rotate selected picture. (0/90/180/270).
Back to Upper Folder Return to the upper folder.
Back to Root Folder Return to root folder.
Back To Browser Return to Browser mode. (Photo page with control menu.)
Exit Exit JPEG Viewer and return to original source. (Browser with Control menu.)
Note: a. File number is limited to 1000 files
b. This model is only supported JPEG format.
c. JPEG sizes are limited up to 10928x6144 for WXGA and 15360x8640 for FULL-HD panel.
[Time Shift] –
Main menu setting•
Select item MultiMedia in Feature menu (this item will be disabled in non-DTV source or USB thumb drive was not plugged in), then select
Time Shift to enter the sub menu.
FEATURE Time Shift
USB Disk Storage Format
Start Time Shift Recording
Move Select Return Exit
OK
ENTER
EXIT
1 Press MENU to call out MENU.
2
3
4
5
Press ▲/▼ to select “Feature” , and press OK/ENTER.
Press ▲/▼ to select Setting item: MultiMedia Menu and press OK/ENTER to enter.
Press ▲/▼ to select Setting item: Time Shift and press OK/ENTER to enter.
Press ▲/▼ to select Setting item: USB Disk Storage Format or Start Time Shift Recording and press OK/
ENTER to enter.
6
7
Press ◄/► to adjust.
Press EXIT to exit.
34
Time Shift Control: Description
USB Disk Storage Format Format USB disk and locate a fix area for Time shift feature used.
Start Time Shift Recording Start time shift function, freeze video and start record DTV Function.
USB Disk Storage Format: •
FEATURE Format
Format USB Disk.
It Will Erase All The Current Data ! Continue ?
Yes
Move Select Return Exit
OK
ENTER
No
EXIT
1 Press ◄/► to select “Yes” or “No” to format the USB Disk.
Note: This Time Shift function only supports the USB Disk Size between 512M to 32GB.
Warning: The data in the USB disk will be erased.
FEATURE Format
Do not Plug out USB or Switch off Power
During the Formatting process ! Continue ?
Yes
Move Select Return Exit
OK
ENTER
No
EXIT
1 Press ◄/► to select “Yes” or “No” to format the USB Disk.
Note:
Format process will take at least 2 minutes. Please Do Not turn off the power and remove the USB disk.
During format process, it will also do the speed test on your USB disk. If it shows failed, your USB disk may not support Time Shift
function.
Start Time Shift Recording:• Start time shift function, freeze video and start record DTV Function.
FEATURE Time Shift
USB Disk Storage Format
Start Time Shift Recording
Move Select Return Exit
OK
ENTER
EXIT
1 Press ▲/▼ to select Start Time Shift Recording and press OK/ENTER to enter.
Note: The initial process may take a few seconds. Please wait a few seconds.
35
Time Shift operation was shown as below: •
Time Shift
12:20:50 / 12:32:40
13:00:00
Definition
• 12:20:50 Present the video time (play point). Synchronized to Timer icon.
• 12:32:40 Present the live time (record point). Synchronized to Orange bar.
• 13:00:00 Present the predict time. The point all buffer is just occupied.
• If the predict time is crossed day line to start time. A “+” will be added to tail. See below case.
Time Shift
23:40:20 / 23:49:40
00:30:00+
Pause (Also be used to Start recording).
Play
Stop and terminate time shift
Fast-forward
Rewind
Note:
The operation Fast-forward/Rewind will only be available in the Orange bar.
In usually 4G memory buffers will offer 180 minutes for 480i contents and 30 minutes for 1080i contents.
The buffer size will be limited in 4G no matter how large sizes USB disk do you use.
When run out buffer: •
Time Shift
13:58:00 / 14:17:30
14:17:3013:17:30
When the memory buffer is running out, the recording will not be stopped. Mean while the video content before start time would be
replaced.
Limitation:•
1. When Time Shift feature take action, only play/pause/fast-forward/rewind/volume/mute hot key and some basic operation key (OK/Exit/
Move) can work. Any unavailable key pressed, the following dialog will display.
This Key Is Unavailable During Time Shift Operation !
OK
2. The video might get judder or unsmooth when USB recording speed is under requirement (some FHD format).
3. The video might get some limited mosaic when Video bit rate is too low (some Music channel).
4. Do not unplug USB or switch off DC/AC power during Time Shift.
5. Do not remove signal during Time Shift. It will abort the process once the signal lost.
6. No quickly operation between play/pause/fast-forward/rewind.
7. No CC (Closed Captions) setting when Time Shift is in process. CC must be set before Time Shift engaged.
8. Sleep timer will be terminated if set before Time Shift.
9. Time Shift will not take action if the channel is scramble or audio only.
10. Only 5 predefined USB drive recommend. For other 4G or 8G high speed USB drive could be useful, but this is not guaranteed.
11. This feature is not available for all TV programs. It is depended on program’s situation.
Reset to Default:13. Restore all the default settings.
36
Troubleshooting
Condition Explanation / Solution
No picture
No picture Check the Power Saving settings.
Cannot receive any channels
TV is locked to one channel Perform Auto Program to add receivable channels that are not present in the TV’s memory.
Cannot receive or select
The TV turns off
No picture from some video
Poor picture
The quality of the images is not
as good as what I saw at the
store
Double images or ghosts
Only snow and noise appear on
the screen
Dotted lines or stripes
No color/Dark picture/Color is not
correct/The picture is too bright
Noisy picture
No sound/Noisy sound
Make sure the power cord is connected securely. Turn on the power of the TV.
Check antenna/cable connections. Make sure the Cable setting is correct for your TV signal source.
Perform Auto Program to add receivable channels that are not present in the channels TV’s memory.
To receive or select cable channels, make sure that Cable in the Channel settings is set to On. To
receive or select UHF channels over an antenna, make sure Cable is set to Off.
Check if Sleep Timer is activated, or confirm the Duration setting of Timer automatically.
Check PC Power Management in General Settings.
Check the connection between the optional video equipment and the TV Sources.
Press INPUT on the remote control.
Select your desired input from the External Inputs list.
Picture quality depends on the signal content. See Quick Setup Guide (supplied) to display the best
possible picture for that signal.
Check antenna/cable connections.
Check the antenna location and direction.
Check if the antenna is broken or bent; Check if the antenna has reached the end of its serviceable life.
(3-5 years in normal use, 1-2 years at the seaside.)
Keep the TV away from noise sources such as cars, motorcycles, or hair-dryers.
If using 300 ohm twin lead, move the excess lead away from the TV or try using 75 ohm coaxial cable
instead.
Press PICTURE to select the desired Picture Mode; Adjust the Picture Mode options in the Picture
settings.
Make sure that the antenna is connected using a 75-ohm coaxial cable.
Keep the antenna cable away from other connecting cords.
To avoid TV interference, make sure to use an undamaged antenna cable.
Check the volume control. Press MUTE or VOL + so that
Good picture, no sound
Audio noise
PC Input
No Picture / No Signal
Poor Picture Adjust the resolution. Adjust Pitch and Phase.
Wide Mode changes
automatically
Suddenly the picture gets smaller
“Black box” on screen
Black bands appear at the edges
of the screen
Condition Explanation / Solution
PC Input
Certain programs on DVD or
other digital sources display a
loss of detail, especially during
fast-motion or dark scenes
Remote control does not operate
Disconnect your headphones.
For HDMI equipment, confirm that the audio output setting of the connected equipment is set to PCM.
This TV's HDMI inputs support PCM 32, 44.1 and 48 kHz, 16, 20 and 24bits.
Make sure that the antenna is connected using a 75-ohm coaxial cable.
Keep the antenna cable away from other connecting cords.
To avoid TV interference, make sure to use an undamaged antenna cable.
Confirm the PC is correctly connected to the TV with either the PC IN (with an HD15 cable) or with the HDMI IN.
Ensure the output signal from the PC is one of the formats listed on page 18.
Turn the PC off. Confirm the PC connection and restart the PC. Plug and play will auto-detect the TV
and correctly set up PC timing.
Verify PC Power Management is activated.
The current Wide Mode setting is automatically replaced with the 4:3
Default setting when you change the channel or video input, if 4:3 Default in the Screen settings is set
to other than Off. If you want to lock in Wide Mode selected with WIDE on the remote control, set 4:3
Default to Off in the Screen settings.
Check the Auto Wide option in the Screen settings.
The picture gets smaller during the commercials, this is due to the method the provider broadcasts their
contents. When HD content channels switch to SD definition content (commercials), the picture may be
small with a black border.
You have selected a text option and no text is available. To turn off this feature, set the CC Display
option to Off. If you were trying to select closed captioning, select CC1 instead of Text1-4.
Some wide screen programs are filmed in aspect ratios that are greater than 16:9 (this is especially
common with theatrical releases). Your TV will show these programs with black bands at the top and
bottom of the screen. For more details, check the documentation that came with your DVD (or contact
your program provider). Programs in 4:3 aspect ratio will have bands on left and right sides of the
screen.
This is due to the digital compression of the source content used by certain digital broadcasts and
DVDs which may cause your TV’s screen to display less detail than usual, or cause artifacts (small
blocks or dots, pixilation) to appear on your screen. These signal compressions are more visible and are
dependent on the clarity and resolution of the television.
Check the polarity of the batteries or replace the batteries.
Point the remote control at the remote control sensor located at the front of the TV.
Fluorescent lamps can interfere with your remote control operation; try turning off the fluorescent lamps.
Keep the remote control sensor area clear from obstacles.
disappears from the screen.
37
Dimensions & Specifications
Model LC32H063D/LC42H063D
Panel size
Resolution 1920 x 1080
TV System
Channel coverage
Speaker
Antenna impedance 75Ω
Power source 120V
Standby power consumption <1W
Video/Audio Terminals Rear AV x1: S-Video/Video/Audio Input/Audio output.
S-Video Input*
Video/Audio Input
Component Input
HDMI Terminals
VGA Terminals
Headphone Audio Output: Mini-jack for stereo (3.5Ø )
SPDIF Output Optical Digital Audio Out jack.
Size (W x H x D)
(with base and stand) (mm)
Weight
Wall mount size
Wall-Mount accessory Optional accessory and not included in standard package
Equipment:
Operation Temperature
Storage Temperature
LC32H063D: 800 mm diagonal (31.5” viewable)
LC42H063D: 1067 mm diagonal (42” viewable)
NTSC standard
ATSC standard (8-VSB, Clear-QAM)
VHF: 2 through 13
UHF: 14 through 69
Cable TV:
Mild band (A - 8 through A - 1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 125)
LC32H063D: 10 W x 2
LC42H063D: 12 W x 2
60Hz, 150W
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 500mv (rms)
Rear Component x1:
Y: 1V(p-p), 75 ohm, including sync.
Pr/Cr: ±0.35V(p-p), 75 ohm
Pb/Cb: ±0.35V(p-p), 75 ohm
AUDIO: 500mv (rms)
HDMI INPUT: Side HDMI x4
HDCP compliant
E-EDID compliant
VGA INPUT:
Rear VGA (D-SUB 15 Pin) Input x1
E-EDID compliant
Audio Input: Mini-jack for stereo (3.5Ø )
LC32H063D: 778.51 x 552.20 x 250.5
LC42H063D: 1011.4 x 698.2x x 278.2
LC32H063D: 12.13 Kg (with stand) / 10.53 Kg (w/o stand and base)
LC42H063D: 18.8 Kg (with stand) / 16.5 Kg (w/o stand and base)
LC32H063D: 200 x 200 mm (Wall mount kit is not included)
LC42H063D: 400 x 200 mm (Wall mount kit is not included)
35 ºC for moderate climates (Maximum ambient temperature)
-20 ºC~50 ºC
* S-Video Input
You can connect your TV set to a high-resolution video source (such as Super VHS videocassette recorder, Laser Disc player, and DVD Home
Theater Set) in order to provide maximum consumer viewing satisfaction.
Note:
Designs and specifications are subject to change without notice.
This model may not be compatible with features and/or specifications that may be added in the future.
38
Index
A
Adaptive Contrast, 27
Antenna, 6, 38
Aspect Ratio, 27
Audio, 26, 28, 37
Audio Language, 28
Audio Setting, 26, 28
Audio Source, 28
Auto Adjust, 29
Auto Search, 24
AVL, 28
B
Backlight, 27
Balance, 28
Bass, 28
B/L control, 30
Brightness, 27
C
Channel, 24, 25, 37
Clock, 29
Closed Captions, 30, 32
Color, 27, 37
Color Temp., 27
COMP, 11
Component, 10, 14
Contrast, 27
D
DCR, 27, 30
Device Auto Off, 32
Device List, 32
Dimensions, 38
E
Eco, 11, 20, 27
EXIT, 11
F
Feature, 30
Frequency, 16
H
HDMI, 10
HDMI Control, 32
Headphone Jack, 10
H. Position, 29
I
INFO, 11
INPUT, 11, 23
Input Source, 23
L
LAST, 11
M
MENU, 11, 24
Menu Language, 30
Menu timeout, 30
MPAA, 31
Multi Language, 28
Music, 26
MUTE, 11, 26
N
Noise Reduction, 27
P
Panel size, 38
PC Connection, 15
PC Setting, 29
Personal, 26
Phase, 10, 29, 37
PICTURE, 11
Picture Mode, 37
Picture Setting, 27
Power, 4, 5, 37, 38
Preset, 16, 27
Presetting PC Mode, 16
Presetting Video Mode, 16
R
Remote Control, 11, 17, 23, 25, 27, 37
Reset All, 30
Resolution, 16, 38
Root Menu, 32
S
SAP, 28
Setting, 37
Setup, 15, 16, 30, 37
Set-Up, 13
Sharpness, 27
Signal, 10, 14, 15, 16, 29, 37
Size, 38
Sleep, 11
Sleep Timer, 30, 37
SMP, 27
Sound, 7, 8, 11, 26
Sound Mode, 28
Source, 23, 37
SPDIF, 10, 15, 28, 38
Speaker, 28, 38
Specifications, 38
Speech, 26
SRS, 28
Standard, 11, 16, 27
S-Video, 10, 1
T
Time Shift, 33, 34
Tint, 27
Treble, 28
Troubleshooting, 37
TV Auto On, 32
V
Video, 10, 16, 27, 38
Vivid, 11, 20, 27
VOL, 11, 26, 37
Volume, 8, 26
V. Position, 29
W
Wall-Mount, 3, 4, 13, 38
WIDE, 11
Y
YPbPr, 10, 11
5, 16, 31, 38
39
Appendix A
Introduction:
Welcome to use AOC LCD TV! This LCD TV also included one universal remote control and allows you to control up to 4 home theater devices
with one easy to use, compact remote control. Just install batteries and follow the instructions in “Programming Device Control” to program the
universal remote to control your equipment.
PROGRAMMING DEVICE CONTROL
To program this remote to control home theater devices, follow the steps below.
Before proceeding, find the codes for the devices you want to program in “Manufacturer’s Codes” on the right side of this page and write them
down or highlight them.
Turn on the device (for example, DVD player) and, if needed, load media (for example, a DVD). 1.
Press a device key on the remote that you wish to program (TV, DVD, STB, or AUX). 2.
Press and hold SET until the red LED blinks twice, and then release. 3.
Enter the first five-digit code for the device and brand that you wish to program. The LED blinks once as each digit is entered. If the code is 4.
valid, the LED blinks twice.
NOTE: If the LED does not blink twice, repeat steps 2 to 4 and try entering the code again.
Aim the remote at the device and press POWER. The device should turn off. If it does not, repeat steps 3–5, trying each code for your brand 5.
until you find one that works. If you cannot find a code that works, see Searching for Your Code”.
Repeat steps 1 to 5 for the other devices you want to control. For future reference, write down each working device code in the following 6.
chart:
TV Code:
□□□□□
DVD Code:
□□□□□
STB Code:
□□□□□
AUX Code:
□□□□□
SEARCHING FOR YOUR CODE
If your device does not respond to the remote after trying all codes listed for your brand, or if your brand is not listed, try searching for your code:
Turn the device you wish to control on.1.
Press the desired device key once. 2.
Press and hold SET until the red LED blinks twice, and then release. 3.
Enter 9 9 1. The LED blinks twice. 4.
Press the device group number for your device type (see table below).5.
Code Device Group
0
1 TV (TVs)
2 VCR (VCRs, DVD players)
3
Aim the remote at the device and press Power. The remote sends IR codes from its library to the selected device, starting with the most 6.
popular code first. If the device responds, go to step 8.
If the device does not respond, press CH+ and the remote will test the next code for that device type. Continue to press CH+ until the device 7.
turns off.
Note: Press CH- to try the previous code.
Now that you have found the correct code, press SET to save the code that worked for your device. The LED blinks twice to indicate that the 8.
code has been saved. To search for other device codes, repeat steps 1 to 8.
Cable (Cable Converters, Video
Accessories, Satellite Receivers)
Audio (Audio Amplifiers, Audio Amp/
Tuners, CD players)
CHECKING THE CODES
If you have set up the remote using the procedure in “Searching for Your Code”, you may need to find out which five-digit code is operating your
equipment.
For example, to find out which code is assigned to your TV:
Press TV once. 1.
Press and hold SET until the red LED blinks twice, and then release. 2.
Enter 9 9 0. The LED blinks twice. 3.
To view the code for the first digit, press 1. Count the red LED blinks (for example, three blinks = 3), and write down the number in the 4.
appropriate code listing at the top of this column.
NOTE: If a code digit is 0, the LED does not blink.
Repeat step 4 for the four remaining digits, using 2 for the second digit, 3 for the third digit, 4 for the fourth digit, and 5 for the fifth digit. 5.
To check for other device codes, repeat steps 1—5, substituting the device key the desired mode you would like to check. 6.
40
USING LEARNING
This universal remote control includes a Learning feature (some models may not include Learning) so you can add functions that are unique to
your home entertainment devices (e.g.,VCR Tracking Up or Down). However, there are some considerations.
Learning Precautions
Your original remote controls must be in working order for learning to work properly.
Learned keys are mode-specific, so each one can store a unique function for each mode.
Do not use the following keys for learning: Device Keys, SET, or Record (•).
Learning capacity is approximately 42 to 75 keys, depending on the code being learned.
Certain device functions are not learnable including multi-frequency types, some high frequency functions, and other unusual formats.
For optimum learning, avoid high levels of ambient light such as natural sunlight or energy-efficient fluorescent lights.
NOTE: Please have your original remote controls handy before programming learning.
Programming a Learned Key
NOTE: If more than 10 seconds pass between key presses, the remote exits pro-gramming.
Place the Nova head-to-head (about 2” apart) from your original remote control. Also locate the key (on your original remote control) that you 1.
want the Nova to learn. Press the mode key you wish to learn functions on.
Press and hold SET until the LED blinks twice, then release.2.
Enter 9 7 5. The LED blinks twice.3.
NOTE: If the LED displays one long flash instead, either your batteries are low, or the Nova has a memory fault. In either case, the remote
cannot learn a new key.
Press the key on the remote you wish to learn onto. The feedback LED stays lit for three seconds, suggesting the remote is ready to learn.4.
On the original remote, press and hold the key to be learned. Continue holding the key on the original remote until the Nova’s LED blinks 5.
twice.
NOTE: If the red LED displays one long blink, a learning error has occurred. Try repeating this step again until a successful capture occurs.
If the function is still not captured, press and hold SET to exit programming and review the “Learning Precautions” above. If needed, also see
“Trouble-shooting” below. After reviewing, start programming again at step 1.
Repeat steps 4 through 5 for another key you would like to learn onto. Once you have completed learning all keys, press and hold SET until 6.
the LED blinks twice to save all data learned.
Deleting a Single Learning Key
This process returns the key to its original programming for the mode you select. You can also delete learned programming by teaching a
different function to the key (see “Programming a Learned Key”).
NOTE: If more than 10 seconds pass between key presses, the remote exits pro-gramming.
Press the mode key that you wish to remove the learned key from.1.
Press and hold SET until the LED blinks twice, then release.2.
Enter 9 7 6. The LED blinks twice.3.
Press the key containing the learned function to be deleted twice. The LED blinks twice and exits from programming.4.
Deleting All Learned Keys in a Specific Mode
NOTE: If more than 10 seconds pass between key presses, the remote exits programming.
Press and hold SET until the LED blinks twice, then release.1.
Press 9 7 6. The LED blinks twice.2.
Press a mode key twice (i.e., TV, DVD, STB, or AUX) to clear all the learned keys for that mode. The LED blinks twice and exits from 3.
programming.
CHANGING VOLUME LOCK
The AOC universal remote control comes preset to allow independent volume control of each selected device (Global Volume Unlock). However,
you may change the Volume Lock setting to Global Volume Lock so that one device’s volume controls volume in all other modes. After that,
you can perform Individual Volume Unlock on a selected device to set its volume control for independent operation or Global Volume Unlock to
remove all volume locking.
Locking Volume Control to One Mode (Global Volume Lock)
Press and hold SET until the red LED blinks twice, and then release. 1.
Enter 9 9 3, the LED blinks twice. 2.
Press the mode key for the device you want to control (for example, TV). 3.
The LED blinks twice. Now when you press VOL+, VOL-, or Mute, the selected device (for example, TV) controls the volume regardless of 4.
the current mode.
Unlocking All Volume Control (Restoring Global Unlock)
Press and hold SET until the red LED blinks twice, and then release. 1.
Enter 9 9 3, the LED blinks twice. 2.
Press VOL+. The LED blinks four times. Volume is independently controlled for all programmed devices.3.
Unlocking a Single Device’s Volume Control
Press the desired device mode key (TV, DVD, STB, or AUX).1.
Press and hold SET until the red LED blinks twice, and then release. 2.
Enter 9 9 3. The LED blinks twice.3.
Then press VOL-. The red LED blinks four times. Volume is independently controlled for the selected devices. 4.
41
PROGRAMMING CHANNEL LOCK
Channel control can be locked so that the Nova remote controls a single device’s channel-changing functions, regardless of operating mode. This
is often enabled by users who watch all broadcast TV through one device (e.g., a cable set-top box). The affected keys are 1 through 0, CH+,
CH-, and LAST. Locking All Channel Controls to One Device
To lock all channel-control functions to a specific device, follow these steps:
Press the mode key that relates to the device that you use for channel- changing control. 1.
Press and hold SET until the mode LED blinks twice, then release.2.
Enter 9 7 3.The mode LED blinks twice.3.
Press CH+ once. The mode LED blinks twice.4.
Now, regardless of what mode you select, the channel keys will only change channels on the assigned device.
Unlocking Channel Locks
To unlock Channel Lock and thus allow the channel control functions to work with the device associated to the active operating mode, follow
these steps:
Press and hold SET until the mode LED blinks twice, then release.1.
Enter 9 7 3. The mode LED blinks twice.2.
Press CH- once. The mode LED blinks four times.3.
Now the channel functions will correlate to the active mode (e.g., press CH+ in TV mode and the TV changes channel accordingly).
USING KEYMOVER
Your Nova universal remote control includes a Keymover feature that allows you to map (or copy) keys from one mode (i.e., source mode) to
another mode (i.e., destination mode) or to a different key in the same mode.
NOTE: Do not use any of the Device Keys, POWER, RECORD, or SET as a source or destination key.
Moving Keys in the Same Device Mode
Press the desired device key (TV, DVD, STB, or AUX).1.
Press and hold SET until the LED blinks twice, then release.2.
Press 9 9 4. The LED blinks twice.3.
Press the key you want to move.4.
Press the new key that should perform the function. The LED blinks twice.5.
Repeat steps 1-5 to move additional keys.6.
Moving Keys to a Different Device Mode
This lets you, for example, control DVD functions while in TV mode. You would move the transport key functions (Play, Stop, etc.) from DVD
mode to TV mode, as follows:
Press and hold SET until the LED blinks twice, then release.1.
Press 9 9 4. The LED blinks twice.2.
Press the device key that contains the function you want to move (e.g., DVD).3.
Press the key you want to move (e.g., Play).4.
Press the device key that you want to move the function to. (e.g., TV).5.
Press the key in the new mode that should perform the function (e.g., Play). The LED blinks twice.6.
Repeat steps 1-6 to move additional keys.7.
Restoring All Keymoved Data in a Specific Mode
Press and hold SET until the LED blinks twice, then release.1.
Press 9 9 4. The LED blinks twice.2.
Press the device key you wish to remove all keymoved data from twice. The LED blinks twice.3.
Repeat for each device you want to resto4. re.
Restoring Original Key Function
Press the device key for which you wish to remove the keymoved data from a specific key.1.
Press and hold SET until the LED blinks twice, then release. 2.
Enter 9 9 4. The LED blinks twice.3.
Press the key you wish to remove the keymoved data from twice. The LED blinks twice.4.
Repeat steps 1-4 for additional keys you wish to remove.5.
PROGRAMMING MACROS
Your Nova universal remote control includes the ability to program any key (other than the SET key) with a Macro function. Each one can be
set up to perform a pre-programmed set of sequential key presses with the press of one key. A macro can be used to control a home theater
operation, to set a favorite channel, or for other multiple functions you would like to control with one key press. Moreover, each Macro Key can
hold up to 15 key presses total.
NOTE: Programming a new macro over an existing one erases the original macro.
Programming a Mode-Independent Macro
Press and hold SET until the red LED blinks twice, and then release.1.
Press 9 9 5. The LED blinks twice.2.
Press the key you wish to assign a macro on.3.
42
Enter the series of commands you want the macro to execute (up to 15 commands).4.
Press and hold SET until the red LED blinks twice, and then release.5.
Now, when you press the preset macro key , the remote sends the series of commands you have entered, regardless of what mode you are in.
For example, you could program a macro key to turn on both your TV and cable box and select a particular channel.
To clear the macro, repeated steps 1-5 above, but do not enter a series of commands at step 4.
Programming a Mode-Dependent Macro
Press the device mode key (TV, DVD, STB, or AUX).1.
Press and hold SET until the LED blinks twice, then release.2.
Press 9 7 8. The LED blinks twice.3.
Press the key you wish to assign a macro on.4.
Enter the series of commands you want the macro to execute (up to 15 commands).5.
Press and hold SET until the red LED blinks twice, and then release.6.
Now, when you press the macro key, the remote sends the series of commands you have entered, but only if you are in the mode you selected in
step 1. For example, you could program the macro key to turn on both your TV and cable box and select a particular channel, but only if you are
in TV mode. If you are in DVD mode, this key does not execute the macro you set up in TV mode.To clear the macro, repeat steps 1-6 above, but
do not enter a series of commands at step 5.
TROUBLESHOOTING
PROBLEM SOLUTION
LED does not blink when you press a key.
LED blinks when you press a key, but device does not respond.
LED blinks one long blink while in SET mode.
Remote does not control devices or commands are not working
properly.
No volume on a device.
Channels do not change properly when directly entering digits to
change channels.
Try pressing different keys. Replace the batteries with 2 new AA
batteries.
Make sure the remote is aimed at your device and is not more than 40
feet away.
An entry error has occurred (for example, wrong key). Try entering the
sequence again.
Try all listed codes for the device. Make sure the device operates with an
infrared remote control.
See “Changing Volume Lock” and make sure the volume is not locked to
a different mode already.
If the original remote control required you to press Enter to change
channels, press Enter on this remote after entering the channel number.
43
Appendix B
MANUFACTURER’S CODES
Setup Codes for Audio Amplifiers
Adcom 30577, 31100
Anthem 32220
Bose 30674
Carver 30892
Durabrand 31561
Elan 30647
GE 30078
Harman/Kardon 30892
JVC 30331
Left Coast 30892
Lenoxx 31561
Marantz 30892
McIntosh 30251
Modulaire 30395
NEC 30264
Optimus 30395, 30823
Philips 30892
Pioneer 30823
Polk Audio 30892
RadioShack 30395
RCA 30823
Realistic 30395
Shure 30264
Sony 30689, 30815
Soundesign 30078
Victor 30331
Wards 30078
Yamaha 30354, 30133
Setup Codes for Audio Accessories
Accurian 31106
Altec Lansing 30607, 31056
Apple 31115
Creative 30872
DLO 31155
GPX 32113
Griffin 31891
iDeck 31106
iHome 32152
iLive 32113
Imerge 31491
iPort 31917
Klipsch 31339
Marantz 31491
Memorex 32119
Monitor Audio 31106
Motorola 31464
Omnifi 31605
Roku 31828
Sonance 31917
Yamaha 31809, 31810, 32021
Setup Codes for Audio Receivers
ADC 30531
Adcom 30616
Aiwa 31405, 30189, 30121, 31089, 31388, 31641
Akai 30244, 31512
Alco 31390
AMC 31077
Amphion Media Works 31563
AMW 31563
Anam 31609, 31074
Anthem 31185
Apex Digital 31257, 31430, 31774
Arcam 31189
Audiotronic 31189
Audiovox 31390
B & K 30702, 30820, 30840
BK 30702
Bose 31229, 30639, 31253, 31629, 31841,31933
Cairn 30189
Cambridge Soundworks 31370
44
Capetronic 30531
Carver 31189, 30189, 30121, 31089, 31289
Coby 31389
Curtis Mathes 30014
Daewoo 31250
Denon 31360, 30121, 31104, 31142, 31306, 32857
Emerson 30531
Fisher 31801
Garrard 30463
Grundig 30189
Harman/Kardon 30110, 30189, 30891, 31289, 31304, 31306, 32241
Hitachi 31273, 31801
iLive 32013
Inkel 30491
Insignia 31030, 31077, 31893, 32169, 32175
Integra 30135, 30842, 31298, 31320, 31805
iSymphony 32258
JBL 30110, 31306
JVC 31058, 30074, 31374, 31495, 31871, 32239
Kawasaki 31390
Kenwood 31313, 31570, 30077, 30186, 31027
KLH 31390, 31412, 31428
Koss 31366, 31497
Lexicon 31076
LG 31293, 32197
Linn 30189
Liquid Video 31497
Magnavox 31189, 31269, 30189, 30391, 30531, 31089, 31266, 31514
Marantz 31189, 31269, 30189, 30891, 31089, 31289
McIntosh 31289
Micromega 31189, 30189
Mitsubishi 31393
Musicmagic 31089
Myryad 31189
Nakamichi 31313, 30097, 31555
Norcent 31389
Nova 31389
Onkyo 30135, 30842, 31298, 31320, 31531, 31805, 31905
Optimus 31023, 30074, 30014, 30121, 30186, 30531, 31074
Oritron 31366, 31497
Outlaw 30391
Panasonic 31308, 31518, 30367, 31275, 31288, 31316, 31548, 31633, 31763, 31764
Philips 31189, 31269, 30189, 30391, 30891, 31089, 31266
Pioneer 31023, 30014, 30150, 30244, 30531, 30630, 31123, 31384, 31935
Polaroid 31508
Polk Audio 30189, 31289
Proscan 31254
RadioShack 31609
RCA 31023, 31609, 31254, 30531, 31074, 31123, 31390, 31511
Realistic 31609, 30121, 30186
Revox 30189
Rio 31869
Samsung 31295, 31304, 31500
Sangean 32165
Sansui 31189, 30189, 31089
Sanyo 31251, 31469, 31801
Sharp 30186, 31286
Sharper Image 31556
Sherwood 30491, 31077, 31653, 31905, 32169
Sherwood Newcastle 32169
Sonic Blue 31869
Sonic Frontiers 31185
Sony 31058, 31441, 31258, 31759, 31622, 30474, 31158, 31406, 31558, 31658, 31758, 31822, 31858
Stereophonics 31023
Sunfire 31313
Teac 30463, 31074, 31390, 31528
Technics 31308, 31518, 31633
Thorens 31189
Toshiba 30135, 30842, 31123, 31788
Venturer 31390
Victor 30074
Wards 30189, 30014
XM 31406
Yamaha 31023, 30176, 30186, 30376, 31176, 31276, 31331, 31375, 31376, 31476, 31815, 32061
Zenith 30857, 31293
45
Setup Codes for Cable Converters
A-Mark 00008, 00144
ABC 00237, 00003, 00008
Accuphase 00003
Acorn 00237
Action 00237
Active 00237
ADB 02586
Americast 00899
Amino 01602, 01822
Archer 00237
BCC 00276
Bell South 00899
British Telecom 00003
Century 00008
Cisco 01877, 00877, 01982
Clearmaster 00883
ClearMax 00883
Cool Box 00883
Coolmax 00883
Digeo 01187, 02187
Director 00476
Fosgate 00276
GE 00144
General Instrument 00476, 00810, 00276, 00003
Gibralter 00003
GMI 00883
GoldStar 00144
Hamlin 00009, 00273
Hitachi 00003, 00008, 00009
i3 Micro 01602
Insight 00476, 00810
Jerrold 00476, 00810, 00276, 00003
Memorex 00000
Mitsubishi 00003
Motorola 01376, 00476, 00810, 00276, 01187, 01106, 01982
Multitech 00883
Myrio 01602, 01822
Nova Vision 00008
Novaplex 00008
Pace 01877, 00877, 00237, 00008, 01982
Panasonic 00000, 00008, 00144, 00107, 01982
Paragon 00000, 00008, 00525
Penney 00000
Philips 01305, 00317
Pioneer 01877, 00877, 00144, 00533
Pulsar 00000
Quasar 00000
RadioShack 00883
RCA 01256
Regal 00276, 00279, 00273
Runco 00000
Samsung 00003, 00144, 01982
Scientific Atlanta 01877, 00877, 00477, 00237, 00003, 00000, 00008, 01982
Sejin 01602
Sony 01006
Sprucer 00144
Starcom 00003
Supercable 00276
Supermax 00883
Thomson 01256
Torx 00003
Toshiba 00000
Tristar 00883
United Cable 00276, 00003
US Electronics 00276, 00003, 00008
V2 00883
Videoway 00000
Viewmaster 00883
Vision 00883
Vortex View 00883
Zenith 00000, 00525, 00899
46
Setup Codes for Cable/PVR Combos
Americast 00899
Amino 01822
Cisco 01877, 01982
Digeo 01187, 02187
General Instrument 00810
Jerrold 00810
Motorola 01376, 00810, 01187, 01106, 01982
Myrio 01822
Pace 01877, 00237, 01982
Pioneer 01877
RCA 01256
Scientific Atlanta 01877, 01982
Sony 01006
Supercable 00276
Thomson 01256
Zenith 00899
Setup Codes for CD Players
Acoustic Research 30420
Aiwa 30157
Arcam 30157
Audio Research 30157
Burmester 30420
Cairn 30157
California Audio Labs 30029
Cambridge Soundworks 30157
Carver 30157
Curtis Mathes 30032
Denon 30034
DKK 30000
DMX Electronics 30157
Fisher 30000
Garrard 30393, 30420
Genexxa 30032
Grundig 30157
Hafler 30173
Harman/Kardon 30100, 30157, 30173
Hitachi 30032
Inkel 30157, 30180
Integra 30101
JVC 30032, 30072
Kenwood 30626, 30000, 30029, 30028, 30190
KLH 31318 , 31711
Krell 30157
Linn 30157
Magnavox 30157, 30038, 30274
Marantz 30626, 30029, 30157, 30038, 30180, 30435
Matsui 30157
McIntosh 30256, 30290, 30660
MCS 30029
Memorex 30000, 30032, 30420
Micromega 30157
Miro 30000
Mission 30157
Modulaire 30000, 30032, 30087, 30180, 30420
MTC 30420
Myryad 30157
NSM 30157
Onkyo 31327, 30101
Optimus 30000, 30032, 30087, 30393, 30420
Panasonic 30029, 30388, 30752
Parasound 30420
Penney 30029
Philips 30626, 30157, 30274
Pioneer 31062, 30032, 31087
Polk Audio 30157
Proceed 30420
Proton 30157
QED 30157
Quad 30157
Quasar 30029
RadioShack 30000, 30032, 30180, 30420
RCA 31062, 30032, 30053, 30420
Realistic 30000, 30032, 30087, 30180, 30420
Revox 30157
Roksan 30435
47
Rotel 30157, 30420
SAE 30157
Sansui 30000, 30157
Sanyo 30000, 30087
Sharp 30180
Sherwood 30180
Sonic Frontiers 30157
Sony 30490, 30000, 30100, 31364, 30185
Sugden 30157
Sylvania 30157
Symphonic 30180
TAG McLaren 30157
Tandy 30032
Tascam 30393, 30420
Teac 30490, 30180, 30393, 30420
Technics 30029
Thule Audio 30157
Victor 30072
Wards 30032, 30157, 30053, 30087
Yamaha 30490, 30036, 31292
Yorx 30000
Setup Codes for DVD Players
3D LAB 20503, 20539
Accurian 20675, 21072, 21416
Advent 21016
Afreey 20698
Aiwa 20641
Akai 20695, 20705, 20770, 20899, 21089
Alba 20672, 20717
Alco 20790
Allegro 20869
Amphion Media Works 20872
AMW 20872
Apex Digital 20533, 20672, 20717, 20755, 20794, 20796, 20797, 20830, 21004, 21020, 21056, 21061, 21100
Arrgo 21023
Aspire Digital 21168, 21407
Astar 21489
Audiovox 20717, 20790, 21041, 21071, 21072, 21121, 21122
Axion 21071, 21072
B & K 20655, 20662
BBK 21224
Bel Canto Design 21571
Blaupunkt 20717
Blue Parade 20571
Blue Sky 20695
Bose 21895, 22023
Brandt 20651
Broksonic 20695, 20868
California Audio Labs 20490
Celestial 21020
Centrex 20672, 21004
Cinea 20831
CineVision 20876, 20833, 20869
Citizen 21003, 20695, 21277
Clairtone 20571
Coby 20778, 21077, 21086, 21107, 21177
Craig 20831
Creative 20503, 20539
Curtis Mathes 21087
CyberHome 20816, 20874, 21023, 21024, 21117, 21129, 21502, 21537
Cytron 20705
Daewoo 20784, 20705, 20770, 20833, 20869, 21169, 21172, 21234, 21242
Dansai 20770
Daytek 20872
Decca 20770
Denon 20490, 20634, 22258
Denver 20778
Desay 21407
DigitalMax 21738
Digitrex 20672
Disney 20675, 21270
DiViDo 20705
Dual 20675, 21068, 21085
Durabrand 21127
DVD2000 20521
Electrohome 21003
48
Emerson 20591, 20675, 20821, 21268
Enterprise 20591
Entivo 20503, 20539
Enzer 20770
ESA 20821, 21268
Firstline 20651
Fisher 20670
Funai 20675, 21268, 21334
Gateway 21073, 21077, 21158
GE 20522, 20815, 20717
Go Video 20573, 20744, 20717, 20715, 20741, 20783, 20833, 20869, 21044, 21075, 21099, 21158, 21304, 21730
Go Vision 21071, 21072
GoldStar 20741, 20869
Goodmans 20790
Gradiente 20490, 20651
Greenhill 20717
Grundig 20539, 20705
Harman/Kardon 20582, 20702
Hello Kitty 20831
Hitachi 20573, 20664, 21247
Hiteker 20672
Humax 21500, 21588
iLo 21348
Initial 20717
Insignia 21268
Integra 20571, 20627, 21769
IRT 20783
JBL 20702
Jensen 21016
JMB 20695
JVC 20558, 20623, 20867, 21164, 21275, 21550
Kawasaki 20790
Kenwood 20490, 20534
KLH 20717, 20790, 21020, 21149
Kloss 20533
Koss 20651, 21061
Lasonic 20627, 20798
Lecson 21533
Lenoxx 21127
LG 20591, 20741, 20869
LiteOn 21058, 21158, 21416, 21440, 21656, 21738
Loewe 20511, 20741
Logix 20783
Magnasonic 20651, 20675
Magnavox 20503, 20539, 20646, 20675, 20821, 21268, 21354, 21506
Marantz 20503, 20539, 20675
McIntosh 21533, 21273
Medion 20651
Memorex 20695, 20831, 21270
Microsoft 20522, 22083
Minato 20752
Mintek 20839, 20717
Mitsubishi 21521, 20521
NAD 20741
Naiko 20770
NEC 20785, 20869
Nesa 20717
NexxTech 21402
Norcent 21003, 20872, 21107, 21265
Onkyo 20503, 20627, 21769
Oppo 20575, 21224
Optimus 20571
Oritron 20651
Palsonic 20672
Panasonic 20503, 20490, 20571, 20632, 20703, 21362, 21462, 21490, 21641, 21762
Philco 20675
Philips 20503, 20539, 20646, 20675, 20854, 21260, 21267, 21340, 21354, 22056, 22084
PianoDisc 21024
Pioneer 20525, 20571, 20142, 20631, 20632, 21460, 21512, 21571
Polaroid 21020, 21061, 21086
Polk Audio 20539
Portland 20770
Presidian 20675, 21072, 21738
Prima 21016
Proceed 20672
49
Proscan 20522
ProVision 20778
Qwestar 20651
Radionette 20741
RadioShack 20571
RCA 20522, 20571, 20717, 20790, 20822, 21022, 21132, 21769
Realistic 20571
Reoc 20752
Rio 20869
Rotel 20623, 21178
Rowa 20823, 21004
Saba 20651
Sampo 20698, 20752
Samsung 20490, 20573, 20744, 20199, 20820, 20899, 21044, 21075
Sansui 20695
Sanyo 20670, 20675, 20695, 20873, 21334
Schneider 20783
Schwaiger 20752
Sensory Science 21158
Sharp 20630, 20675, 20752, 21256, 22250
Sharper Image 21117
Sherwood 20770, 21043, 21077
Sherwood Newcastle 21077
Shinsonic 20533, 20839
Slim Art 20784
Sonic Blue 20573, 20715, 20783, 20869, 21099
Sony 20533, 21533, 20864, 21033, 21070, 21431, 21516
Sova 21122
Superscan 20821
SVA 20717
Sylvania 20675, 20821, 21268
Symphonic 20675, 20821, 21268, 21334
Tatung 20770
Teac 20571, 20717, 20790
Technics 20490, 20703
Technika 20770
Terapin 21031
Tevion 20651
Theta Digital 20571
Thomson 20522, 20511
Tivo 21503, 21512, 21588
Toshiba 20503, 20573, 20539, 20695, 21045, 21154, 21503, 21510, 21588, 21769
Unimax 20770
Universum 20591
Urban Concepts 20503, 20539
US Logic 20839
V 21064, 21226
Venturer 20790
Vizio 21064, 21226
Xbox 20522, 22083
Yamaha 20490, 20539, 20545
Yamakawa 20872
Zenith 20503, 20591, 20741, 20869
Zeus 20784
Zoece 21265
Setup Codes for DVD Players (Blu Ray and HD-DVD)
Denon 22258
Integra 21769
LG 20741
Microsoft 22083
Onkyo 21769
Panasonic 21641
Philips 22084
Pioneer 20142
RCA 21769
Samsung 20199
Sharp 22250
Sony 21516
Toshiba 21769
Xbox 22083
50
Setup Codes for DVD/PVR Combos
Controlled by the DVD
Go Video 21730
Humax 21500, 21588
LG 20741
Panasonic 20490
Philips 21340
Pioneer 20631, 21512
RCA 20522
Sharp 21256
Sony 21033, 21070
Sylvania 20675
Tivo 21512
Toshiba 21503, 21510, 21588
Setup Codes for Home Automation
Accutek 31215
Amana 31716
Bionaire 30846, 31215, 31861
Da-Lite 31794
Draper 32190
Frigidaire 31333
GE 30240
GoldStar 31537
Holmes 31215
Kenmore 31537
Lasko 30846, 31890
LG 31537
Lightolier 30184
Lutron 30597, 30318, 31239, 31597
Marmitek 30167
One For All 30167
PCS 30184
RadioShack 30240
Screen Research 32097
Security System 30167
Sharper Image 30846
SmartLinc 30184
Universal 30167
Universal X10 30167
Whirlpool 31332
Windmere 31215
X10 30167
Satellite Receivers and DVR/PVR Systems
Setup Codes for Satellite Receivers
AlphaStar 00772
Bell ExpressVu 00775, 01170
Chaparral 00216
Coolsat 01806
Crossdigital 01109
DirecTV 01377, 00392, 00566, 00639, 01639, 01142, 00247,
00749, 01749, 00819, 01856, 01076, 01108, 00099,
01109, 01392, 01414, 01442, 01443, 01444, 01609, 01640
Dish Network System 01505, 00775, 01170, 01775
Dishpro 01505, 00775, 01775
Echostar 01505, 00775, 01170, 01775
Expressvu 00775, 01775
Fortec Star 01821
Funai 01377
GE 00392, 00566
General Instrument 00869
GOI 00775, 01775
Hitachi 00749, 00819
Houston 00775
HTS 00775, 01775
Hughes Network Systems 01142, 00749, 01749, 01442, 01443, 01444
Humax 01790
Innova 00099
Jerrold 00869
JVC 00775, 01170, 01775
LG 01226, 01414
Magnavox 00722
McIntosh 00869
Mitsubishi 00749
Motorola 00869
Netsat 00099
51
Next Level 00869
Panasonic 00247, 00701
Pansat 01807
Philips 01142, 00749, 01749, 00775, 00819, 01076, 00722, 00099, 01442
Primestar 00869
Proscan 00392, 00566
RadioShack 00566, 00775, 00869
RCA 00392, 00566, 01142, 00775, 00855, 00143, 01392, 01442
Samsung 01377, 01142, 01276, 01108, 01109, 01442, 01609
SKY 00099
Sony 00639, 01639, 01640
Star Choice 00869
Star Trak 00772, 00869
Thomson 00392, 00566
Tivo 01142, 01442, 01443, 01444
Toshiba 00749, 01749, 00790, 01285
UltimateTV 01392, 01640
Ultrasat 01806
Uniden 00722
Voom 00869
Zenith 01856
Setup Codes for PVRs
ABS 21972
Alienware 21972
CyberPower 21972
Dell 21972
DirecTV 20739
Gateway 21972
Go Video 20614
Hewlett Packard 21972
Howard Computers 21972
HP 21972
Hughes Network Systems 20739
Humax 20739
Hush 21972
iBUYPOWER 21972
Linksys 21972
Media Center PC 21972
Microsoft 21972
Mind 21972
Niveus Media 21972
Northgate 21972
Panasonic 20614, 20616
Philips 20618, 20739
RCA 20880
ReplayTV 20614, 20616
Samsung 20739
Sonic Blue 20614, 20616
Sony 20636, 21972
Stack 9 21972
Systemax 21972
Tagar Systems 21972
Tivo 20618, 20636, 20739
Toshiba 21008, 21972, 21996
Touch 21972
Viewsonic 21972
Voodoo 21972
ZT Group 21972
Setup Codes for DVR/PVR Systems
Controlled by the Satellite
Bell ExpressVu 00775, 01170
DirecTV 01377, 00392, 00639, 01142, 01076, 00099, 01392, 01442, 01443, 01444, 01640
Dish Network System 01505, 00775
Dishpro 01505, 00775
Echostar 01505, 00775, 01170
Expressvu 00775
Hughes Network Systems 01142, 01442, 01443, 01444
JVC 01170
Motorola 00869
Philips 01142 , 01442
Proscan 00392
RCA 01392
Samsung 01442
Sony 00639, 01640
Star Choice 00869
Tivo 01142, 01442, 01443, 01444
52
Controlled by the VCR
DirecTV 20739
Hughes Network Systems 20739
Philips 20739
Samsung 20739
Tivo 20739
CARE
Keep the remote dry. If it gets wet, wipe it dry immediately.
Use and store the unit only in normal temperature environments.
Handle the remote gently and carefully. Don’t drop it.
Wipe the remote with a damp cloth to keep it looking like new.
Modifying or tampering with the internal parts can cause damage and invalidate the warranty. If your remote is not performing as it should, please
contact us at: www.uei.com.
53
Loading...
