AOC CQ32G1 User Manual

www.aoc.com

QUAD HD

AOC 1700R Curved Monitor

Features

FreeSync Technology

AMD FreeSync technology synchronizes the GPU and the monitor so frames are displayed when ready: no tearing or stuttering.

Why FreeSync is better

● High performance solution with all the benefits of variable refresh

rate technology

● Based on industry standards, not expensive proprietary solutions

● Cheaper and easier to implement: no additional monitor

hardware, no license fees

144Hz Refresh Rate and 1ms Response Time

Ultra-fast 144Hz refresh rate and 1ms response time enables the sharpest responses.

Traditional 60Hz 144Hz

LOW INPUT LAG

CURVED DISPLAY

With larger displays, the curved screen wraps around you for a more immersive

experience that puts you at the center of the action.

Low Blue Mode

AOC Low Blue Mode filters harmful short-wave blue light, with 4 levels that suit different

Low Blue Light

viewing situations.

Low Input Lag

Decreased delay between video source and display. With special Low Input Lag control, the C24G1 will ensure you hit the target the first time.

Multimedia-Ready with HDMI and DisplayPort inputs

HDMI (High-Definition Multimedia Interface) is the digital video and sound standard for connecting the latest consumer electronics like Blu-ray players and game consoles. DisplayPort is designed to be the future digital video and sound connection standard, capable of higher performance and convenience than older formats.

QUAD HD

DIAL POINT

Flicker Free Technology

Most LED monitors use PWM (pulse width modulation) to control brightness; the pulsing creates flicker that may cause discomfort, headaches and eye strain, especially in low-light environments. Flicker Free technology uses a smooth DC (direct current) backlight system.

Ordinary Monitor

AOC Monitor

QHD Resolution

At 2560 x 1440 resolution, Quad HD (QHD) offers superior picture quality, sharper images and finer details than conventional Full HD displays, while retaining the common 16:9 widescreen aspect ratio.

DialPoint

The “Dial Point” function places an aiming indicator in the center of the screen, to help gamers to play First Person Shooter (FPS) games with an accurate and precise aiming.

Game Color

20 Levels

With AOC Game Color, adjust color saturation and grey level with 20 levels of detail for a better game experience.

Game Mode

AOC Game Mode allows fast changes to image settings & game presets.

Narrow Bezel, Narrow Black Border

2mm ultra narrow bezel with 5mm black screen border.

2mm

5mm

Specifications

Model Name

Panel Size

Pixel Pitch (mm)

Effective Viewing Area (mm)

Brightness (typical)

Contrast Ratio

Smart Response

Viewing Angle

Color Gamut

Optimum Resolution

Display Colors

Signal Input

Power Supply

Smart Power Mode: Typical

Built-in Speakers

Regulatory Approvals

Wall-Mount

Cabinet Color

Adjustable Stand

Product with Stand (mm)

Packaging (mm)

Weight (Net/Gross) kg

HDMI × 2

DisplayPort

CQ32G1

31.5"

0.2724 (H) × 0.2724 (V)

697.344 (H) × 392.256 (V)

300 cd/m²

3000 : 1 (Typical) 80 Million : 1 (DCR)

1ms (MPRT)

178° (H) / 178° (V) (CR>10)

NTSC 103% (CIE1976) / sRGB 124% (CIE1931)

2560 × 1440 @ 144Hz – DisplayPort, HDMI #2

2560 × 1440 @ 75Hz – HDMI #1

16.7 Million

HDMI 1.4 × 2, DisplayPort 1.2 × 1

100 - 240V ~ 1.5A, 50 / 60Hz

37W

BSMI / KC / KCC / e-Standby / RCM /

MEPS / CE / VCCI / J-Moss / FCC

100mm x 100mm

Black & Red

Tilt: -5° ~ 23°

530.34 (H) × 713.11 (W) × 244.86 (D)

551 (H) × 807 (W) × 242 (D)

7.28 / 10.32
