Safety
National Conventions
The following subsections describe notational conventions used in this document.
Notes, Cautions, and Warnings
Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These
blocks are notes, cautions, and warnings, and they are used as follows:
NOTE: A NOTE indicates important information that helps you make better use of your computer system.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates the potential for bodily harm and tells you how to avoid the problem.Some warnings
may appear in alternate formats and may be unaccompanied by an icon. In such cases, the specic presentation of the
warning is mandated by regulatory authority.
1
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the
type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will t
only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an
electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of
the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the
monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in re or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate congured
receptacles marked between 100-240V AC, Min. 5A.
The wall socket shall be installed near the equipment and shall be easily accessible.
2
Installation
Installed with stand
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use
mounting accessories recommended by the manufacturer. A product and cart combination should be moved with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a re or electric
shock. Never spill liquids on the monitor.
Do not place the front of the product on the oor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a re or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on the
stand:
Installed with stand
4 inches
10cm
12 inches
30cm
4 inches
10cm
Leave at lease this
space around the set
4 inches
10cm
3
Cleaning
Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent
which will cauterize the product cabinet.
When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it
will scratch the screen surface.
Please disconnect the power cord before cleaning the product.
4
Other
If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a
Service Center.
Make sure that the ventilating openings are not blocked by a table or curtain.
Do not engage the LCD monitor in severe vibration or high impact conditions during operation.
Do not knock or drop the monitor during operation or transportation.
5
Setup
Contents in Box
*
CD Manual Warranty card Stand Screws Base Hand Screw
Power Cable DP Cable HDMI Cable USB Cable Micphone Cable
*
*
*
*
*
Not all signal cables (DP, HDMI, USB and Micphone cables) will be provided for all countries and regions. Please
check with the local dealer or AOC branch ofce for conrmation.
6
Setup Stand & Base
Please setup or remove the base following the steps as below.
Setup:
Remove:
7
Adjusting Viewing Angle
-5° ~ 23°
For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own
preference.
Hold the stand so you will not topple the monitor when you change the monitor’s angle.
You are able to adjust the monitor as below:
NOTE:
Do not adjust the viewing angle over 23 degrees in order to avoid damage.
8
Connecting the Monitor
4
3
2
5
1
7
8
9
6
Cable Connections In Back of Monitor and Computer:
1. Microphone in
2. Earphone (Combined with Microphone)
3. USB3.0 downstream + fast charging(BC1.2)
4. USB3.0 downstream
5. USB3.0 upstream
6. DP
7. HDMI
8. Microphone out (Connect to PC)
9. AC in
To protect equipment, always turn off the PC and LCD monitor before connecting.
1. Connect the power cable to the AC port on the back of the monitor.
2. (Optional – Requires a video card with HDMI port) - Connect one end of the HDMI cable to the back of the monitor
and connect the other end to the computer’s HDMI port.
3. (Optional–Requires a video card with DP port) –Connect one end of the DP cable to the back of the monitor and
connect the other end to the computer’s DP port.
4. Turn on your monitor and computer.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
G-system function
Compatible Graphics Card: GeForece GTX 650 Ti Boost or higher (for a list of compatible graphics cards,
please visit www.nividia.com/G-sync)
Driver: GeForece 331.58 or higer OS: Windows 7/8/8.1
9
Adjusting
Setting Optimal Resolution
Windows 10
For Windows 10:
• Right click START.
• Click “CONTROL PANEL”.
• Click “DISPLAY”.
10
• Click on the “Change display settings” button.
• Set the resolution SLIDE-BAR to Optimal preset resolution.
11
Windows 8
For Windows 8:
• Right click and click All apps at the bottom-right of the screen.
• Set the “View by” to “Category”.
• Click “Appearance and Personalization”.
12
• Click “DISPLAY”.
• Set the resolution SLIDE-BAR to Optimal preset resolution
13
Windows 7
For Windows 7:
• Click START.
• Click “CONTROL PANEL”.
• Click “Appearance”.
• Click “DISPLAY”.
14
• Click on the “Change display settings” button.
• Set the resolution SLIDE-BAR to Optimal preset resolution
15
