Anybus®Wireless Bolt IoT
REST Commands
REFERENCE GUIDE
SCM-1202-156 1.0 en-US ENGLISH
Important User Information
The information in this document is for informational purposes only. Please inform HMS Industrial Networks of any inaccuracies or omissions found in this document. HMS Industrial Networks disclaims any responsibility or liability for any errors that may appear in this document.
HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product development. The information in this document shall therefore not be construed as a commitment on the part of HMS Industrial Networks and is subject to change without notice. HMS Industrial Networks makes no commitment to update or keep current the information in this document.
The data, examples and illustrations found in this document are included for illustrative purposes and are only intended to help improve understanding of the functionality and handling of the product. In view of the wide range of possible applications of the product, and because of the many variables and requirements associated with any particular implementation, HMS Industrial Networks cannot assume responsibility or liability for actual use based on the data, examples or illustrations included in this document nor for any damages incurred during installation of the product. Those responsible for the use of the product must acquire sufficient knowledge in order to ensure that the product is used correctly in their specific application and that the application meets all performance and safety requirements including any applicable laws, regulations, codes and standards. Further, HMS Industrial Networks will under no circumstances assume liability or responsibility for any problems that may arise as a result from the use of undocumented features or functional side effects found outside the documented scope of the product. The effects caused by any direct or indirect use of such aspects of the product are undefined and may include e.g. compatibility issues and stability issues.
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Table of Contents
Page
1 Preface ................................................................................................................................. 3
1.1 About This Document ........................... ............... .......................................................... ... 3
1.2 Trademarks... ............... ........................................... .. ........................................... ........... 3
2 Authentication..................................................................................................................... 4
3 Public REST Commands....................................................................................................... 5
3.1 Read Configuration............................ ............... .......................................................... ......5
3.2 Write Configuration.............. ........................................... ............................................. ....5
3.3 Backup Configuration............... ............... ........................................... .. ............................. 7
3.4 Restore Configuration ........................ .......................................................... ............... ......7
3.5 Factory Reset .................................... ............... .............................. ............. .................... 7
3.6 Info .............................. ............... ........................................... ............... ........................ 8
3.7 Log ... ........................................... ............... ........................................... .. ...................... 9
3.8 SysLogInfo ................................................... ............................................. .................... 10
3.9 Reboot ............... ............. ............................................. ............... ................................. 10
3.10 Ultra Low Power Mode ................... ............... ............................................. .................... 11
3.11 Firmware Update ... .............................. ............. .............................. ............... ................ 12
3.12 DHCP Leases ........................................... ............... ........................................... ............ 12
3.13 Return Values............................. .. ............. .............................. ............... ....................... 12
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
This page intentionally left blank
Preface 3 (14)

1 Preface

1.1 About This Document

This document describes the available REST commands for Wireless Bolt IoT. The reader of this document is expected to be familiar with the product and have a good knowledge of wireless communication and network technology.
For additional related documentation, file downloads and technical support, please visit the Anybus support website at www.anybus.com/support.

1.2 Trademarks

Anybus®is a registered trademark of HMS Industrial Networks. All other trademarks mentioned in this document are the property of their respective holders.
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Authentication 4 (14)

2 Authentication

All http requests to the REST API need to be authenticated using the "Basic HTTP Authentication Scheme" (RFC7617). Basic auth is done by adding a header-parameter to the HTTP-request:
Authorization: Basic <Base64 encoding of user-id:password>
The user-id is always "admin" and the password is the web password currently in use, either the default password shipped with the product, or if it has been changed, the new password. Example:
User-id: admin Password: abc123 String to Base64-encode: admin:abc123 Completed header parameter: Authorization: Basic YWRtaW46YWJjMTIz
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 5 (14)

3 Public REST Commands

3.1 Read Configuration

Read information from a configuration tree and present as JSON data.

3.1.1 Syntax

GET <target_ip>/cgi-bin/readconfigtree.cgi?path=<tree_path>

3.1.2 Query Parameters

Name
target_ip
tree_path A path to the configuration tree or node to read

3.1.3 Return Values

A JSON structure with the requested data.

3.1.4 Examples

Read a single configuration node:
Query: GET http://192.168.0.98/cgi-bin/readconfigtree.cgi?path=web:/ settings/lock Response: {"name":"lock","type":"bool","value":true}
Read a configuration tree:
Query: GET http://192.168.0.98/cgi-bin/readconfigtree.cgi?path=web: Response: {"name":"","type":"tree","children": [{"name":"settings","type":"stem","children": [{"name":"lock","type":"bool","value":true}]}]}
Description
IP address of the Bolt IoT device, e.g. 192.168.0.98

3.2 Write Configuration

Write information to a configuration tree.

3.2.1 Syntax

GET <target_ip>/cgi-bin/writeconfigtree.cgi?path=<tree_ path>&value=<new_value>&type=<type>
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 6 (14)

3.2.2 Query Parameters

Name
target_ip
tree_path A path to the tree and node to operate on
new_value A value to write to the config tree
type
Note: if type is bool, then new_value must be either true or false.

3.2.3 Configuration Paths

The following configuration paths can be modified by the user:
Path
router:/settings/ipAddr
router:/settings/netMask
router:/settings/dhcpEnable
router:/settings/auth
router:/settings/authUser
router:/settings/authPass
router:/settings/dhcpRangeStart
router:/settings/dhcpRangeStop
router:/settings/apn
router:/settings/rat
web:/settings/lock
web:/settings/password
Description
IP address of the Bolt IoT device, e.g. 192.168.0.98
Must be one of bool, int, float, or string
Type
string
string
bool Enable internal DHCP server: true or false
bool Enable APN authenticaion: true or false
string
string
string
string
string
string
bool Configuration lock: true or false
string
Description
IP address
Subnet mask
APN authenticaion: user
APN authenticaion: password
DHCP start address: 1..254
DHCP stop address: dhcpRangeStart..254
Access Point Name (APN)
Radio Access Technology (RAT): auto, lte-m1, lte-nb1 or gsm
Web and REST API password (valid characters a-z, A-Z, 0-9,
- and _ )

3.2.4 Return Values

{"success":<value>}
Value
true
false Request failed or validation error or config locked.

3.2.5 Example

Query: GET http://192.168.0.98/cgi-bin/writeconfigtree.cgi?path=router:/ settings/apn&value=my_apn.company.com&type=string Response: {"success":true}
Description
Request completed successfully.
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 7 (14)

3.3 Backup Configuration

Create and return a file with a backup of all settings in the device.

3.3.1 Syntax

GET <target_ip>/cgi-bin/backup.cgi

3.3.2 Query Parameters

None

3.3.3 Examples

Query: GET http://192.168.0.98/cgi-bin/backup.cgi Response: <octet stream containing the backup>

3.4 Restore Configuration

Restore all settings in the device from a file.

3.4.1 Syntax

POST <target_ip>/cgi-bin/restore.cgi

3.4.2 Query Parameters

None

3.4.3 Post Data

The backup file contents.

3.4.4 Return Values

{"success":<value>}
Value Description
true
false Request failed or validation error or config locked.
Request completed successfully.

3.4.5 Examples

Query: POST http://192.168.0.98/cgi-bin/restore.cgi Response: {"success":true}

3.5 Factory Reset

Restore all settings in the device to factory default values.
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 8 (14)

3.5.1 Syntax

GET <target_ip>/cgi-bin/factoryreset.cgi

3.5.2 Query Parameters

None

3.5.3 Return Values

{"success":<value>}
Value Description
true
false Request failed or config locked.
Request completed successfully.

3.5.4 Examples

Query: GET http://192.168.0.98/cgi-bin/factoryreset.cgi Response: {"success":true}

3.6 Info

Get runtime information.

3.6.1 Syntax

GET <target_ip>/cgi-bin/info.cgi

3.6.2 Query Parameters

None

3.6.3 Return Values

A JSON structure with the following information.
Value
uptime
time
radio_power Radio module power state
sim
signal_quality Signal quality (0..5)
signal_strength Signal strength (dBm)
cell_id Serving Cell Identifier
lac Location Area Code of the serving cell
tac
rat
Description
Device uptime in seconds
System time (UTC)
0: Off
1: On
SIM card status
Tracking Area Code of the serving cell (LTE only)
Currently used Radio Access Technology
0: Unknown
1: GSM
®
Anybus
Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 9 (14)
Value Description
4: LTE
operator
status
amplifier_temp Amplifier temperature in degrees Celcius
controller_temp Controller temperature in degrees Celcius
connection_state Data session state
voltage Voltage (mV)
iotbolt_version Bolt IoT version
modem_version Modem FW version
pri
apn
rat_specific Access technology of the serving cell
imsi
imei
Currently used operator
Network registration status
0: Not registered and not searching
1: Registered to home network
2: Searching for new operator
3: Registration denied
4: Registered to roaming network
5: Unknown state
0: Disconnected
1: Authenticating
2: Connected
3: Suspending
4: Incoming (MT-PDP context request)
Carrier name and version
Currently used APN
0: GSM
7: CAT-M1
9: NB-IoT
International Mobile Subscriber Identity
International Mobile Equipment Identity

3.6.4 Examples

Query: GET http://192.168.0.98/cgi-bin/info.cgi Response: {"uptime":"4287","time":"2019-11-19 13:35:48","radio_ power":"1","sim":"2","signal_quality":"1","signal_strength":"­109","cell_ id":"26269452","lac":"4294967295","tac":"0x85","rat":"4","opera­tor":"TELIA S","status":"4","amplifier_temp":"35","controller_ temp":"35","connection_state":"2","voltage":"3807","iotbolt_ version":"1.00.20-dev","modem_version":"SWI9X06Y_
02.16.06.00","pri":"GENERIC_001.028_001","apn":"","rat_ specific":"9","imsi":"238208700452254","imei":"352653090129735"}

3.7 Log

Get system log.

3.7.1 Syntax

GET <target_ip>/cgi-bin/log.cgi
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 10 (14)

3.7.2 Query Parameters

None

3.7.3 Return Values

Plain text log file.

3.7.4 Examples

Query: GET http://192.168.0.98/cgi-bin/log.cgi Response: Oct 9 10:03:18 Legato: INFO | Version: 1.00.18-dev Oct 9 10:03:18 Legato: INFO | Boot reason: Power-on Jan 6 00:00:23 Legato: INFO | eth0 IP address: 192.168.0.98 - netmask:
255.255.254.0 Jan 6 00:00:23 Legato: INFO | eth0 DHCP server: on Jan 6 00:00:23 Legato: INFO | APN auth is: off Jan 6 00:00:23 Legato: INFO | DHCP range start - stop: 192.168.0.100 -
192.168.0.200 Jan 6 00:00:24 Legato: INFO | IP address/netmask set to: 192.168.0.98/
255.255.254.0 Jan 6 00:00:24 Legato: INFO | Setting no auth for APN Jan 6 00:00:24 Legato: INFO | Setting configured RAT: "gsm": 0x01 Jan 6 00:00:24 Legato: INFO | Data connection requested Oct 17 12:02:43 Legato: INFO | Data connected, interface 'rmnet_data0' Oct 17 12:02:43 Legato: INFO | Restarting DHCP/DNS services

3.8 SysLogInfo

Create and return an archive of all system logs.

3.8.1 Syntax

GET <target_ip>/cgi-bin/sysloginfo.cgi

3.8.2 Query Parameters

None

3.8.3 Examples

Query: GET http://192.168.0.98/cgi-bin/sysloginfo.cgi Response: <octet stream containing the archive>

3.9 Reboot

Reboot the device.
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 11 (14)

3.9.1 Syntax

GET <target_ip>/cgi-bin/reboot.cgi

3.9.2 Query Parameters

None

3.9.3 Return Values

{"success":<value>}
Value Description
true
false Request failed
Request completed successfully.

3.9.4 Examples

Query: GET http://192.168.0.98/cgi-bin/reboot.cgi Response: {"success":true}

3.10 Ultra Low Power Mode

Put the device in Ultra Low Power Mode for a specified duration.

3.10.1 Syntax

GET <target_ip>/cgi-bin/ulpm.cgi?duration=<time in seconds>

3.10.2 Query Parameters

Name
duration Number of seconds (60-86400) to remain in ULPM before

3.10.3 Return Values

{"success":<value>,"message":"<additional info>"}
Value Description
true
false Request failed or validation error

3.10.4 Examples

Description
waking up again
Request completed successfully.
Enter ULPM and sleep for 300 seconds (5 minutes):
Query: GET http://192.168.0.98/cgi-bin/ulpm.cgi?duration=300 Response: {"success":true,"message":"sleeping for 300 s"}
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
Public REST Commands 12 (14)

3.11 Firmware Update

Update the device firmware.

3.11.1 Syntax

POST <target_ip>/cgi-bin/update.cgi

3.11.2 Query Parameters

None

3.11.3 Post Data

The contents of a firmware (.fws) file.

3.11.4 Return Values

Raw HTML output of the firmware update process. Searching this for the strings "SUCCESS" or "FAILED" will give the result.

3.11.5 Examples

Query: POST http://192.168.0.98/cgi-bin/update.cgi Response: Trying to update... Unpacking: 0% FAILED: error code 2

3.12 DHCP Leases

Return a list of active DHCP leases.

3.12.1 Syntax

GET <target_ip>/cgi-bin/dhcpleases.cgi

3.12.2 Query Parameters

None

3.13 Return Values

Raw text output with DHCP leases in dnsmasq.leases format.

3.13.1 Examples

Query: GET http://192.168.0.98/cgi-bin/dhcpleases.cgi Response: 1573275080 00:e0:4c:34:92:e9 192.168.0.168 LT-5Q1XWT2 01:00: e0:4c:34:92:e9
Anybus®Wireless Bolt IoT™Reference Guide
SCM-1202-156 1.0 en-US
This page intentionally left blank
last page
© 2020 HMS Industrial Networks
Box 4126 300 04 Halmstad, Sweden
info@hms.se SCM-1202-156 1.0 en-US / 2020-04-23 / 18195
