Voltikus PSU
Audiophile grade Power supply
User’s Manual
1
1
Contents
1. Safety Notes ................................................................................................................................ 7
2. Introduction ................................................................................................................................... 8
3. Features ....................................................................................................................................... 8
4. Quick Start ................................................................................................................................... 9
5. Front Panel Explained .................................................................................................................... 9
6. Rear Panel Explained ................................................................................................................... 10
7. Replacing a fuse .........................................................................................................................11
8. In the box ................................................................................................................................... 12
9. Technical Specifi cations ............................................................................................................. 12
1
3
1. Safety Notes
!
To reduce the risk of electrical shocks, fi re, and related hazards:
● Do not remove screws, cover, or cabinet. There are no user serviceable parts inside. Refer
servicing to qualifi ed service personnel.
● Do not expose this device to rain, moisture or spillover of liquid of any kind.
● Should any form of liquid or a foreign object enter the device, do not use it. Switch off the
device and then unplug it from the power source. Do not operate the device again until the
foreign object is removed or the liquid has completely dried and its residues fully cleaned up.
● Make sure the device is switched off when plugging/unplugging it to/from the power source.
● Avoid placing things on the cabinet or using the device in a narrow and poorly ventilated place
which could affect its operation or the operation of other closely located components.
● If anything goes wrong, turn off the device fi rst and then unplug the power. Do not attempt to
repair the device yourself: consult authorized service personnel or your dealer.
● Do not install near any heat sources such as radiators, stoves, or other apparatus that pro-
duces substantial heat.
● Do not use harsh chemicals to clean your Unit.
● Connect all your devices before powering your Unit.
1
5
2. Introduction
Congratulations! You are now the proud owner of the Voltikus audiophile grade ultra low noise
power supply, the perfect companion to your Zodiac DAC.
THE POWER THAT MAKES THE DIFFERENCE
Voltikus is a sleek heavy-duty Power Supply Unit (PSU) designed to perfectly match your Zodiac
DAC. Carefully tailored to deliver uncompromised power, Voltikus helps Zodiac achieve the punch
and sonic richness of deep lows, a full range of mids, and tightly defi ned highs. This degree of
performance is accomplished by incorporating a hefty, custom-wound, electrostatically shielded
toroidal transformer followed by a unique concept of three cascaded power regulators. A precision
laser-trimmed voltage reference (LT1021) serves as the backbone of this discrete design, achieving
the stability impossible with off-the-shelf voltage regulators. Voltikus is a true engineering breakthrough from Antelope’s respected team of high-end audio experts.
Enjoy your music all over again with the new Voltikus!
All the best,
The Antelope Team
3. Features
● Audiophile grade PSU perfectly matching Zodiac DACs in aesthetics and performance
● Unique multi-stage linear regulator topology achieves vastly superior stability
● Toroidal transformer with custom electrostatic shield suppresses power line disturbances
● Ground / Lift switch helps eliminate hum and buzz caused by ground loops
● Wide (90-250V) input voltage range ensures dependable operation under varying line condi-
tions
● Advanced discrete design dispenses with the need for noisy off-the-shelf voltage regulators
● Robust sturdy construction with custom machined aluminum front panel
1
100 - 240 VAC
2
1
3
Regulator Stage 1 Regulator Stage 2
2
4
5
Precision voltage ref.
Regulator Stage 3
3
4
1. Input Voltage - 100-240 VAC
2. Custom Design Transformer with Electrostatic Shield
3. Precision Voltage Reference with Ultra-low Drift and Noise
4. Three Stage Regulation
1
6
4. Quick Start
It only takes a few moments to harness the benefi ts of the Voltikus PSU. Follow these simple steps
to connect Voltikus to your Zodiac DAC:
1. Plug the supplied IEC power cable into the AC Input socket (4) on the rear panel of the
unit and connect the other end to an AC power outlet.
2. Connect the DC power cable to the 18 VDC Output (6) on the rear panel and the other
end to the 18 VDC input socket on your Zodiac DAC Unit.
3. Press the power switch (3) on the rear panel to power up. The power light (1) on the front
panel of the Voltikus illuminates to indicate that it is powered up.
4. The Ground/ Lift switch (5) provides the option of lifting your Voltikus PSU to make it ‘fl oat-
ing’ or keep it grounded.
See more on www.antelopeaudio.com ‒ support area.
5. Front Panel Explained
1
1. Power light
When lit, this indicates that the Voltikus is powered up.
1
7
6. Rear Panel Explained
2
3
5
4
2. Fuse compartment
Takes two fuses: 0.8A, 250 VAC, 5 mm x 20 mm, Type T.
3. Power switch
Toggles power on/off.
4. IEC AC Input C14 Male Connector
For use with AC Power cable.
5 . Ground/Lift switch
Toggles grounded or lifted state.
6
6. 18 VDC Output
For use with supplied Antelope DC Power cable only.
1
8
7. Replacing a fuse
If the power light is not illuminated and the Voltikus is plugged into a working AC power outlet with
the power switch in the on position, the fuse may need to be replaced.
1. Disconnect the power cord from the electrical outlet.
2. Insert a fl at blade screwdriver into the notch (8) at the bottom edge of the fuse holder (7)
to release it.
3. Remove the fuses from the fuse holder. Replace them with 0.8A, 250VAC, 5 mm x 20
mm, Type T (Time Lag).
4. Re-insert the fuse holder into its position in the rear panel. Press the fuse holder gently
until it clicks into place.
1
9
8. In the box
● VOLTIKUS audiophile grade ultra low noise power supply
● Owner‘s Manual
● DC Power cable
9. Technical Specifi cations
Input Power
- Nominal 100-120/220-240 VAC, 50 or 60Hz
- Actual 90-264 VAC, 50 or 60Hz
Fuses 0,8A, 250 VAC, 5 mm x 20 mm, Type F
Input Power Cord 3-Wire grounded / Lifted option
Terminals C14 panel mounted male connector (inlet)
Output
Voltage 18 VDC
Power (maximum) 18 W
Terminals Mini XLR
Safety Features
Overload / short circuit protection Automatic power limit / short circuit protection
Input Line Protection Fuse on both hot and neutral
Environmental
Operating Temperature 0-50°C / 32-122°F
Dimensions Width - 106,5 mm / 4,2”
Height - 111,5 mm / 4,4”
Depth - 168,0 mm / 6.6”
Weight 2,0 kg / 4,4 lb
1
10
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate
collection systems)
This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government offi ce, for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contact. This product should not be mixed with other commercial wastes for disposal.
