battery type: Alkaline Manganese (Mercury free)
battery size: IEC: LR6; JIS: AM-3; ANSI: AA; MN1500; Mignon
chemical system: Zn / KOH-H2O / MnO
2
Conditions
nominal voltage: 1.5 V
open circuit voltage: 1.57...1.62 V new battery
1.55...1.62 V after 1 year storage at 20°C
capacity all measurements at 20°C ambient
rated: 3000 mAh discharge at 10mA load; 24hours/day
End Voltage (EV): 0.8V
2800 mAh discharge at 75ohms load; 24hours/day
End Voltage (EV): 0.8V
minimum: 2650 mAh discharge at 35mA constant current
End Voltage (EV): 0.8V
900 mAh discharge at 1000mA constant current
End Voltage (EV): 0.8V
typical service output (new batteries)
≥500 cycles discharge at 1000mA; EV: 0.9V
discharge 10s/m 1h/d
≥ 93
h
discharge at 43Ω resistive load; EV: 0.9V
discharge 4h/d
≥ 8.1
h
discharge at 3.9Ω resistive load; EV: 0.8V
discharge 1h/d
≥ 19.5 h
discharge at 10Ω resistive load; EV: 0.9V
discharge 1h/d
≥ 7.8 h discharge at 250mA; EV: 0.9V
discharge 1h/d
internal resistance: ≤ 0.2 Ω at 1kHz, sine wave measurement
according to IEC 896-2
shelf life: 7 years under proper storage conditions
leakage resistance
over discharge: no leakage 10ohms continuous discharge for 48h; ta: 20°C; RH: 60±15%
high temperature: no leakage store 20days at ta: 60°C; RH:90±5%
ambient temperature
range: - 10...50 °C
recommended storage
conditions: 5....25 °C ambient temperature
45...75 % rel. humidity
mechanical specifications
cell dimensions
diameter d1: 14.4 - 0.5 mm
diameter d2: 5.4 - 0.5 mm
height h1: 50.4 - 0.5 mm
height h2: 1.7 - 0.5 mm
weight: 23 ± 2 g
blister card
dimensions: 120 x 85 mm
weight (incl. batteries): 98 ± 5 g
102
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice
author / date
supplier no.
Ansmann XPower Alkaline battery
AA - size 4pcs blister
5015663
703385
TG / 10.02.2016
ANSMANN Specifications for model:
data sheet no. / part no.
