battery type: Lithium Button Cell
battery size: CR1632
chemical system: Lithium Manganese Dioxide
Conditions
nominal voltage: 3.0 V
open circuit voltage: 3.0...3.4 V new battery
2.9...3.4 V after 1 year storage at 20°C
all measurements at 22 ± 2°C ambient
capacity
rated: 120 mAh continuous discharge at 47kΩ load; 24hours/day
End Voltage (EV): 2.0V
minimum: 110 mAh continuous discharge at 47kΩ load; 24hours/day
End Voltage (EV): 2.0V
Standard discharge time
minimum: 225 h
at 6.8kΩ load
(for QC measurement)
EV: 2.0V
Discharge currents
standard: 0.1 mA
max. recommended current
under continuous discharge: 3 mA
max. recommended current
under pulse discharge: 10 mA
Discharge diagrams:
Discharge Characteristics on Load Discharge Characteristics on Temperature
shelf life: 10 years under proper storage conditions (ta: ≤ 22°C; RH: 60 ± 15%)
operating temperature
range: - 20...60 °C
mechanical specifications:
dimensions in mm
blister card
dimensions:
56 x 71.5mm
weight:
4.1g (incl. battery)
nominal weight: 2.3 g
87
Manufacturer reserves the right to alter or amend the design, model and specification without prior notice
author / date
supplier no.
CR1632 Lithium Button Cell
blister package
1516-0004
702572
TG / 24.06.2015
ANSMANN Specifications for model:
data sheet no. / part no.
