Ansen Electronics Co 0642TX User Manual
®
ROY AL
OPERATIONAL
MANUAL
WS10
thermometer
OUT
WS 10
INSTRUCTION MANUAL
Congratulations on purchasing the Royal WS 10 Thermosolutions Thermometer.
This model features Indoor Temperature and Outside Temperature. Outside
Temperature is provided with the 434 MHz cable free temperature sensor. No
wire installation is required. For additional convenience, a magnetic backing has
been used for placement on kitchen refrigerators.
Please read all the instructions to ensure understanding of the features.
The WS 10 uses a liquid crystal display. On occasion the display has an
appearance of being damaged. This is especially true when first receiving
the unit or when moving the unit. It is recommended leaving the unit on a
flat table for 10 minutes. The liquid in the display will fill all the voided
areas.
WS 10
2
Fig. 1 1. IN/OUT Toggle
8
7
IN OUT
6
4
3
5
2. Inside Indicator
3. Outside Indicator
4. Temperature
5. Celsius (oC) / Fahrenheit (oF)
6. Antenna icon
1
7. Battery low indicator
8. Channel (at the back)
REMOTE UNIT
Fig.2
A. Test button
C
B
B. LED light
ROYAL
A
C. Display
BEFORE YOU BEGIN
For best operation:
* Insert the remote unit batteries before inserting the batteries into the main
unit.
* Place the main unit as close as possible next to the remote unit. This will
ensure easier synchronization between the transmission and reception of the
signals.
* Position the remote unit and main unit within the effective transmission range,
which, in usual circumstances, is 75 to 100 feet.
WARNING: When attaching the WS 10 to a metal object such as a refrigerator the
transmission distance from the remote is reduced to 50 feet.
NOTE: Building materials and where the main and remote units are positioned
vastly affect the transmission range. Try various locations for best results.
1
INSTALLATION OF THE BATTERY IN THE REMOTE UNIT
The remote unit uses AA x 2 batteries. To install or replace the batteries, please
follow these steps:
Fig.3
* Unscrew the screw on the back of the compartment and remove the cover.
* Insert the batteries, observing the correct polarity.
* Replace the battery cover on unit and seal by re-screwing tightly.
It is recommended replacing the batteries in both units on an annual basis to
ensure optimum accuracy. If the low battery indicater illuminates on the base unit,
while the outside temperature is displayed, it is time to replace the batteries in the
remote.
NOTE:
After changing the batteries in the Transmitter or Base unit, both units must be
completely reset as per the Setting Up instructions.
INSTALLATION OF THE BATTERIES IN THE MAIN UNIT
The WS 10 uses two "AA" batteries. Should the LCD become dimmer or the low
battery indicater illuminates , then the batteries in this unit should be changed.
To install or replace the batteries, please follow these steps:
Fig.4
AA
AA
* Slide the battery door cover off in the direction of the arrow.
* Insert 2 AA batteries, following the polarity shown inside the battery
compartment.
* Replace battery cover.
2
