Anker A7910 Pocket Bluetooth Speaker

f

A

Package Contents

Anker A7910 Pocket Bluetooth Speaker
Micro USB charging cable (2.3 ft)
AUX to Micro USB audio cable (2.3 ft)
Welcome Guide

Product Features

● Ring-box size profile fits easily into your pocket, or the small side pocket of your backpack.

● Impressively full sound powered by a powerful 3 watt audio driver.

● 12 hours o

● Non-Bluetooth devices enjoy unhampered compatibility with the provided

audio cable.

● NFC compatibility enables easier pairing.

● Connects automatically to the last-connected device once powered on.

play time significantly outlasts other Bluetooth speakers.

UX to Micro USB

Specifications

Product Model A7910
Bluetooth Standard 3.0
Product Weight 90 ± 5g / 3.2 ± 0.2oz
Product Size 45 × 45 × 45mm / 1.8 × 1.8 × 1.8in
Play Time 12 hours
Charge Time 1.5 hours
Input 5V / 1A
Operating Range 10m / 33ft
Speaker Output Power 3W
Audio Cable Type AUX to Micro USB audio cable
Supported Bluetooth
Profiles

A2DP, AVRCP

Product Overview

Power button
LED indicator
Micro USB charging & audio 2-in-1 port
NFC chip location

How to Turn On / Off the Speaker

Press the power button for 3 seconds to turn the speaker on or off.

How to Pair with Your Device

1. Press the power button for 3 seconds. The speaker will turn on and automatically enter pairing mode
indicated by the flashing blue LED.

2. Activate your device’s Bluetooth function and search for the device.

3. Once the Bluetooth speaker has been detected, select the product name “Anker A7910” to connect.
(For devices with Bluetooth versions below 3.0, press “Yes” to confirm pairing. Enter a passkey or PIN
code “0000” (4 zeros), then press the “Yes” or “OK” key to finish pairing.)

4. When the Bluetooth speaker and your device are successfully paired, the blue LED will go on and
remain on while connected.

How to Pair with a NFC-Supportive Device

1. Press the power button for 3 seconds. The speaker will turn on and the indicator will start flashing

blue.

2. Enable your device’s NFC function.

3. Put your device near the NFC chip location.

4. Click “Yes” on your device’s screen to confirm Bluetooth connection.

5. When the Bluetooth speaker and your device are successfully paired, the blue indicator will go on
and remain on while connected.

Note: When turning on the speaker, it will automatically connect to the last-connected device
(Bluetooth function needs to be enabled). When pairing with an additional device, disable the
Bluetooth function on the previous device, the speaker will automatically return to pairing mode. Then,
repeat the pairing process.

How to Recharge

When the speaker’s battery is low, the speaker will announce “Battery low”, and the red battery
indicator will flash for about 10 minutes.

1. Plug the Micro USB cable into the speaker’s Micro USB charging port.

2. Insert the remaining end of the USB power wire into (a) a USB AC adapter (not included) connected
to a wall socket, or (b) a charging computer USB port. A steady red battery indicator will show that it is
charging.

3. The red battery indicator will go off when the speaker is fully charged.

LED Indicator Instructions

LED indicator Meaning

Blue indicator rapidly flashing Pairing mode

Steady blue indicator Connected to a device

Red indicator flashing Low Battery

Steady red indicator Charging

Red indicator goes off Fully charged

Usage Tips

1. Power off the speaker when not in use and before storing.

2. The operational range of the speakers may be influenced by obstructions, such as walls, pillars, etc.
To ensure a stable connection, we recommend avoiding such obstructions whenever possible and/or
shortening the distance during use.

3. To protect the long-term performance of the battery, please do not place the speaker in high
temperatures above 140°F/60℃, such as in a hot vehicle or under direct sunlight.

4. Do not expose the speaker or any of its supplied parts to water or liquids.

FAQ and Solutions

1. Why can’t the speaker connect to my device?

a. Check to ensure your device’s Bluetooth function is enabled.
b. Make sure your device is within 3ft/1m of the speaker.
c. Delete the pairing record(s) on the speaker or your device.

2. Can I use the speaker to play music while charging?

To protect the long-term performance of the battery, it is better to charge it when the speaker is turned
off, especially when the battery is low.

3. Can I make or answer phone calls through the speaker?

No. The speaker does n ot feature a built-in microphone.
