ITEM
A
u
NO. PART NO. DESCRIPTION
1 23196
Housing Assembly
QTY.
REQ'D
1
ITEM
NO. PART NO. DESCRIPTION
(Includes Upper housing Switch Actuator,
and Housing Screws, Lower Housing,
Housing Sleeve, LED lens, and Screw)
2 23197
Mounting Bracket Assembly
(Includes Mounting Bracket, Adjuster Arm,
1
Washer, and Screws, Tension Spring, Blade
3 23198
4 23199
Guide)
Motor Assembly
(Includes Motor, Cam, and Motor Mounting
Screws)
Battery/Switch Assembly
1
1
(Includes Battery, Foam, Switch, Power
Jack, LED, and Wiring)
5 Adapter
22916
22914
Adapter
Adapter
1
1
IMPORTANT INFORMATION
When ordering repair parts, include part number, part name and model of trimmer. For best performance, trimmer blades should be CLEANED and OILED with
Clipper Oil before and after use, If repair is necessary, return to any Andis Authorized Repair Service Station, or to Andis Company, 1800 Renaissance Blvd., St
Wisconsin, 53177 U.S.A.. Pack carefully, mail either Insured Parcel Post, or U.P.S. , attach a letter to outside of package explaining difficulty.
