Engineer to Engineer Note EE-23

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

4) The same single-buffer TDM frame interface is used

An AD1847/ADSP-2181 loopback
example using a single index
register for SPORT autobuffering

Last Modified: 05/06/97

This Edition of Analog Devices Engineer’s Note will
provide some insight into interfacing the AD1847
SoundPort Codec to an ADSP-2181 using a single index
register for transmitting and receiving data via SPORT
autobuffering ad1847. The code was tested using an
AD1847 codec on our ADSP-21XX EZ-KIT-LITE
Evaluation Board. The example talkthru program uses the
AD1847’s 1 wire mode for transmitting and receiving of
data in slots 0-5. The supplied listing contains the
following for the 1-wire, talkthru example:

ADSP 2181 initialization

both for initialization and operation.

5) The initialization commands now come from program
memory rather than data memory. In a real-time
application, this saves the bother of initializing a data
memory array.

6) Since only the SPORT0 interrupt can be active during
initialization, the control flag is passed in the AF register
rather than in a variable.

7) Only the SPORT0 RX interrupt is used, never the TX.
In addition, the SPORT0 RX interrupt vector is altered
after initialization for maximum speed & flexibility.

ADSP 1847 Codec initialization
Interrupt service routines

Changes from the MIC2OUT.DSP version:

1) The ADI EZ-KIT-LITE version did not set the digital
mix control (a minor bug)

2) This version still takes two index registers to set up,
but only needs one index register to run. The EZ-KIT­LITE version requires three index registers for
initialization and two to run.

3) 1 wire mode is used for the SPORT interface. This
prevents simultaneous tx and rx autobuffer requests,
regardless of bus activity.

A single index interface to the AD1847 works because the
autobuffer transfers are always separated by at least one 16
bit time slot (about 4us at 8 kHz). Transmit autobuffers
happen at the beginning of a time slot, Rx autobuffers at
the end. Since the Tx slots come before the Rx slots,
there is never a conflict.

Note that this does not apply if two or more AD1847's are
cascaded. In such a system, hardware should be added to
allow a dummy time slot between the 6 slots used for
each AD1847. This still allows for up to four AD1847's
on one bus.

Source Code Listing for AD1847drv.dsp

.module/RAM/ABS=0 loopback;

.const IDMA= 0x3fe0;
.const BDMA_BIAD= 0x3fe1;
.const BDMA_BEAD= 0x3fe2;
.const BDMA_BDMA_Ctrl= 0x3fe3;
.const BDMA_BWCOUNT= 0x3fe4;
.const PFDATA= 0x3fe5;
.const PFTYPE= 0x3fe6;

.const SPORT1_Autobuf= 0x3fef;
.const SPORT1_RFSDIV= 0x3ff0;
.const SPORT1_SCLKDIV= 0x3ff1;
.const SPORT1_Control_Reg= 0x3ff2;
.const SPORT0_Autobuf= 0x3ff3;
.const SPORT0_RFSDIV= 0x3ff4;
.const SPORT0_SCLKDIV= 0x3ff5;
.const SPORT0_Control_Reg= 0x3ff6;
.const SPORT0_TX_Channels0= 0x3ff7;
.const SPORT0_TX_Channels1= 0x3ff8;
.const SPORT0_RX_Channels0= 0x3ff9;
.const SPORT0_RX_Channels1= 0x3ffa;
.const TSCALE= 0x3ffb;
.const TCOUNT= 0x3ffc;
.const TPERIOD= 0x3ffd;
.const DM_Wait_Reg= 0x3ffe;
.const System_Control_Reg= 0x3fff;

.var/pm/ram init_cmds[14];

.var/dm/ram/circ buf[6];
.var/dm/ram vol[2];

{-----------------------------------------------------------------------------

Note that the order here seems a little funny. The control field is
where
it is due to buffering in Sport0's transmitter. It is actually the
control
field that will be transmitted in the next frame.

---------------------------------------------------------------------------}
#define left_out buf
#define right_out buf+1
#define control buf+2
#define status buf+3
#define left_in buf+4
#define right_in buf+5

EE-23 Page 2

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

.init init_cmds:
0xc00600, {
Left input control reg
b7-6: 0=left line 1
1=left aux 1
2=left line 2
3=left line 1 post-mixed loopback
b5-4: res
b3-0: left input gain x 1.5 dB
}
0xc10600, {
Right input control reg
b7-6: 0=right line 1
1=right aux 1
2=right line 2
3=right line 1 post-mixed loopback
b5-4: res
b3-0: right input gain x 1.5 dB
}
0xc28800, {
left aux 1 control reg
b7 : 1=left aux 1 mute
b6-5: res
b4-0: gain/atten x 1.5, 08= 0dB, 00= 12dB
}
0xc38800, {
right aux 1 control reg
b7 : 1=right aux 1 mute
b6-5: res
b4-0: gain/atten x 1.5, 08= 0dB, 00= 12dB
}
0xc48800, {
left aux 2 control reg
b7 : 1=left aux 2 mute
b6-5: res
b4-0: gain/atten x 1.5, 08= 0dB, 00= 12dB
}
0xc58800, {
right aux 2 control reg
b7 : 1=right aux 2 mute
b6-5: res
b4-0: gain/atten x 1.5, 08= 0dB, 00= 12dB
}
0xc68000, {
left DAC control reg
b7 : 1=left DAC mute
b6 : res
b5-0: attenuation x 1.5 dB
}
0xc78000, {
right DAC control reg
b7 : 1=right DAC mute
b6 : res

EE-23 Page 3

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

b5-0: attenuation x 1.5 dB
}
0xc85000, {
data format register
b7 : res
b5-6: 0=8-bit unsigned linear PCM
1=8-bit u-law companded
2=16-bit signed linear PCM
3=8-bit A-law companded
b4 : 0=mono, 1=stereo
b0-3: 0= 8.
1= 5.5125
2= 16.
3= 11.025
4= 27.42857
5= 18.9
6= 32.
7= 22.05
8= .
9= 37.8
a= .
b= 44.1
c= 48.
d= 33.075
e= 9.6
f= 6.615
(b0) : 0=XTAL1 24.576 MHz; 1=XTAL2 16.9344 MHz
}
0xc90900, {
interface configuration reg
b7-4: res
b3 : 1=autocalibrate
b2-1: res
b0 : 1=playback enabled
}
0xca0000, {
pin control reg
b7 : logic state of pin XCTL1
b6 : logic state of pin XCTL0
b5 : master - 1=tri-state CLKOUT
slave - x=tri-state CLKOUT
b4-0: res
}
0xcc0000, {
miscellaneous information reg
b7 : 1=16 slots per frame, 0=32 slots per frame
b6 : 1=2-wire system, 0=1-wire system
b5-0: res
}
0xcd0000, { digital mix control reg
b7-2: attenuation x 1.5 dB
b1 : res
b0 : 1=digital mix enabled

EE-23 Page 4

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

}

0xaf0000; { else set done flag and }

{******************************************************************************
*
* Interrupt vector table
*
******************************************************************************}
jump start; rti; rti; rti; {00: reset }
rti; rti; rti; rti; {04: IRQ2 }
rti; rti; rti; rti; {08: IRQL1 }
rti; rti; rti; rti; {0c: IRQL0 }
rti; rti; rti; rti; {10: SPORT0 tx }
vrx0: jump frame_int; {14: SPORT0 rx }
rti; rti; rti;
jump irqe; rti; rti; rti; {18: IRQE }
rti; rti; rti; rti; {1c: BDMA }
rti; rti; rti; rti; {20: SPORT1 tx or IRQ1 }
rti; rti; rti; rti; {24: SPORT1 rx or IRQ0 }
rti; rti; rti; rti; {28: timer }
rti; rti; rti; rti; {2c: power down }

{******************************************************************************
*
* ADSP 2181 initialization
*
******************************************************************************}
start:

i1=^buf;
l1=%buf;

i4=SPORT0_Autobuf;
l4=0;

m1 = 1;

m7=1;

{================== S E R I A L P O R T #0 S T U F F ==================}
dm(i4,m7)=b#0000001010010111; { - single index

---------------1 rx autobuffer

--------------1- tx autobuffer

------------01-- rmreg = M1

---------010---- rireg = I2

-------01------- tmreg

----010--------- tireg

---0------------ biasrnd for mac

--0-------------

-0-------------- clk dis
0--------------- }

dm(i4,m7)=0; { SPORT0_RFSDIV }

EE-23 Page 5

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

dm(i4,m7)=0; { SPORT0_SCLKDIV }
dm(i4,m7)=b#1000011000001111; { SPORT0_Control_Reg

------------1111 16b word

----------00---- format

------­ ||| |!|+------- receive framing logic 0=pos, 1=neg
||| |!+-------- transmit data valid logic 0=pos, 1=neg
||| |+========= RFS 0=ext, 1=int
||| +---------- multichannel length 0=24, 1=32 words
||+-------------- | frame sync to occur this number of clock
|| | cycle before first bit
|| |
|| |
|+--------------- ISCLK 0=ext, 1=int
+---------------- multichannel 0=disable, 1=enable

-------------------------------------------------------}
{ Sport0 multi channel enables }

dm(i4,m7)=b#0000000000000111; { tx 15..0 }
dm(i4,m7)=b#0000000000000111; { tx 31..16 }
dm(i4,m7)=b#0000000000111000; { rx }
dm(i4,m7)=b#0000000000111000;

{============== S Y S T E M A N D M E M O R Y S T U F F ==============}
ax0 = b#0000111111111111; dm (DM_Wait_Reg) = ax0;
{ |+-/+-/+-/+-/+-/- ! IOWAIT0
|| | ! | !
|| | ! | !
|| | ! +------ | IOWAIT1
|| | ! |
|| | ! |
|| | +--------- ! IOWAIT2
|| | !
|| | !
|| +------------ | IOWAIT3
|| |
|| |
|+=============== ! DWAIT
| !
| !
+---------------- 0
}

ax0 = b#0001000000000000; dm (System_Control_Reg) = ax0;
{ +-/!||+-----/+-/- | program memory wait states
| !|+----------- SPORT1 1=serial port, 0=FI, FO, IRQ0, IRQ1,..
| !+------------ SPORT1 1=enabled, 0=disabled
| +============= SPORT0 1=enabled, 0=disabled
}

ifc = b#00000011111111; { clear pending interrupt }

EE-23 Page 6

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

nop;

icntl = b#00000;
{ ||||+- | IRQ0: 0=level, 1=edge
|||+-- | IRQ1: 0=level, 1=edge
||+--- | IRQ2: 0=level, 1=edge
|+---- 0
|----- | IRQ nesting: 0=disabled, 1=enabled
}

mstat = b#1000000;
{ ||||||+- | Data register bank select
|||||+-- | FFT bit reverse mode (DAG1)
||||+--- | ALU overflow latch mode, 1=sticky
|||+---- | AR saturation mode, 1=saturate, 0=wrap
||+----- | MAC result, 0=fractional, 1=integer
|+------ | timer enable
+------- | GO MODE
}

{***********************************************************************
*******
*
* ADSP 1847 Codec initialization
*
* At this point, the rx autobuffer is already running, but w/o
interrupts
* enabled. I1,m1 operates a 3 byte auto-buffer for TX_BUF. We write
to
* TX0 here to start the tx autobuffer going.
*
* Every time the tx autobuffer wraps, an interrupt occurs that will
* clear STAT_FLAG
************************************************************************
*******}

i4 = ^init_cmds;

af=pass 0;
ifc = b#00000011111111; { clear any pending interrupt }
nop;
{ enable rx interrupt }
imask = b#0000110000;
{ |||||||||+ | timer
||||||||+- | SPORT1 rec or IRQ0
|||||||+-- | SPORT1 trx or IRQ1
||||||+--- | BDMA
|||||+---- | IRQE

EE-23 Page 7

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

||||+----- | SPORT0 rec
|||+------ | SPORT0 trx
||+------- | IRQL0
|+-------- | IRQL1
+--------- | IRQ2
}

idle; { wait for a wrap }
ax0 = 0xc000; { start interrupt }
tx0 = ax0;

ar=14;
af = pass ar; { interation count for tx int }

check_init:
af = pass af; { buffer to be sent to }
if ne jump check_init; { the codec }

check_aci1:
ax0 = dm(status); { once initialized, wait for codec }
ar = ax0 and 2; { to come out of auto-calibration }
if eq jump check_aci1; { wait for bit set }

check_aci2:
ax0 = dm (status); { wait for bit clear }
ar = ax0 and 2;
if ne jump check_aci2;
idle;

ar = 0x8600;
dm (control) = ar; { un-mute left DAC }
idle;

ar = 0x8700; { un-mute right DAC }
dm (control) = ar;
idle;

i4=^xecho; { re-vector frame interrupt service routine }

ax0=pm(i4,m7);

i4=^vrx0;

pm(i4,m7)=ax0;

{------------------------------------------------------------------------------

-

- wait for interrupt and loop forever

-

------------------------------------------------------------------------------}

talkthru: idle;
jump talkthru;

EE-23 Page 8

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]

{******************************************************************************
*
* Interrupt service routines
*
******************************************************************************}

{------------------------------------------------------------------------------

-

- Frame interrupt for Codec initialization & interface

-

------------------------------------------------------------------------------}
frame_int:

af = pass af;

if eq rti; { if not initializing }
ax0=pm(i4,m7); { ad1847 command }

dm(control)=ax0; { place in transmit slot 0 }
af=af-1;

rti;

xecho: jump echo; { frame proc. for after initialization }

echo: ar=dm(right_in); { loopback inputs to outputs }
dm(right_out)=ar;
dm(left_out)=ar;
rti;

{------------------}

irqe: reset fl1;
rti;

.endmod;

EE-23 Page 9

Notes on using Analog Devices’ DSP, audio, & video components from the Computer Products Division

Phone: (800) ANALOG-D or [phone], FAX: [phone], EMAIL: [e-mail]
