Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor
Platform

Contributed by DSP Apps May 26, 2003

Introduction

Processors optimized for digital signal
processing are divided into two broad categories:
fixed-point and floating-point. In general, the
cutting-edge fixed-point families tend to be fast,
low power, and low cost, while floating-point
processors offer high precision and wide
dynamic range in hardware.

While the Blackfin® Processor architecture was
designed for native fixed-point computations, it
can achieve clock speeds that are high enough to
emulate floating-point operations in software.
This gives the system designer a choice between
hardware efficiency of floating-point processors
and the low cost and power of Blackfin
Processor fixed-point devices. Depending on
whether full standard conformance or speed is
the goal, floating-point emulation on a fixed­point processor might use the IEEE-754 standard
or a fast floating-point (non-IEEE-compliant)
format.

On the Blackfin Processor platform, IEEE-754
floating-point functions are available as library
calls from both C/C++ and assembly language.
These libraries emulate floating-point processing
using fixed-point logic.

To reduce computational complexity, it is
sometimes advantageous to use a more relaxed
and faster floating-point format. A significant
cycle savings can often be achieved in this way.

This document shows how to emulate fast
floating-point arithmetic on the Blackfin

Processor platform. A two-word format is

employed for representing short and long fast
floating-point data types. C-callable assembly
source code is included for the following
operations: addition, subtraction, multiplication
and conversion between fixed-point, IEEE-754
floating-point, and the fast floating-point
formats.

Overview

In fixed-point number representation, the radix
point is always at the same location. While this
convention simplifies numeric operations and
conserves memory, it places a limit the
magnitude and precision. In situations that
require a large range of numbers or high
resolution, a changeable radix point is desirable.

Very large and very small numbers can be
represented in floating-point format. Floating­point format is basically scientific notation; a
floating-point number consists of a mantissa (or
fraction) and an exponent. In the IEEE-754
standard, a floating-point number is stored in a
32-bit word, with a 23-bit mantissa, an 8-bit
exponent, and a 1-bit sign. In the fast floating-

point two-word format described in this

document, the exponent is a 16-bit signed
integer, while the mantissa is either a 16- or a 32­bit signed fraction (depending on whether the

Copyright 2003, Analog Devices, Inc. All rights reserved. Analog Devices assumes no responsibility for customer product design or the use or application of
customers’ products or for any infringements of patents or rights of others which may result from Analog Devices assistance. All trademarks and logos are property
of their respective holders. Information furnished by Analog Devices Applications and Development Tools Engineers is believed to be accurate and reliable, however
no responsibility is assumed by Analog Devices regarding technical accuracy and topicality of the content provided in Analog Devices’ Engineer-to-Engineer Notes.

short of the long fast floating-point data type is
used).

Normalization is an important feature of floating­point representation. A floating-point number is

normalized if it contains no redundant sign bits

in the mantissa; that is, all bits are significant.
Normalization provides the highest precision for
the number of bits available. It also simplifies
the comparison of magnitudes, because the
number with the greater exponent has the greater
magnitude; only if the exponents are equal is it
necessary to compare the mantissas. All routines
presented in this document assume normalized
input and produce normalized results.

The are some differences in arithmetic

L

flags between the ADSP-BF535
Blackfin Processor and the ADSP­BF531/2/3 Blackfin Processor platforms.
All of the assembly code in this
document was written for the ADSP­BF531/2/3 Blackfin Processor devices.

Short and Long Fast Floating­Point Data Types

The code routines in this document use the two­word format for two different data types. The

short data type (fastfloat16) provides one 16-bit

word for the exponent and one 16-bit word for

the fraction. The long data type (fastfloat32)

provides one 16-bit word for the exponent and

one 32-bit word for the fraction. The fastfloat32

data type is more computationally intensive, but

provides greater precision than the fastfloat16

data type. Signed twos-complement notation is
assumed for both the fraction and the exponent.

Listing 1 Format of the fastfloat16 data type

typedef struct
{
short exp;
fract16 frac;
} fastfloat16;

a

Listing 2 Format of the fastfloat32 data type

typedef struct
{
short exp;
fract32 frac;
} fastfloat32;

Converting Between Fixed-Point and Fast Floating-Point Formats

There are two Blackfin Processor instructions
used in fixed-point to fast floating-point
conversion. The first instruction,
returns the number of sign bits in a number (i.e.
the exponent). The second,

ashift, is used to

normalize the mantissa.

Assembly code for both the short version

(fastfloat16) and the long version (fastfloat32) is

shown below.

Listing 3 Fixed-point to short fast floating-point
(fastfloat16) conversion

/*******************************************
fastfloat16 fract16_to_ff16(fract16);

-----------------­Input parameters (compiler convention):
R0.L = fract16
Output parameters (compiler convention):
R0.L = ff16.exp
R0.H = ff16.frac

-----------------­*******************************************/
_fract16_to_ff16:
.global _fract16_to_ff16;
r1.l = signbits r0.l; // get the number of

sign bits
r2 = -r1 (v);
r2.h = ashift r0.l by r1.l; // normalize

the mantissa
r0 = r2;
rts;
_fract16_to_ff16.end:

signbits,

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 2 of 9

Listing 4 Fixed-point to long fast floating-point
(fastfloat32) conversion

/*******************************************
fastfloat32 fract32_to_ff32(fract32);

-----------------­Input parameters (compiler convention):
R0 = fract32
Output parameters (compiler convention):
R0.L = ff32.exp
R1 = ff32.frac

-----------------­*******************************************/
_fract32_to_ff32:
.global _fract32_to_ff32;
r1.l = signbits r0; // get the number of

// sign bits
r2 = -r1 (v);
r1 = ashift r0 by r1.l; // normalize the

// mantissa
r0 = r2;
rts;
_fract32_to_ff32.end:

Converting two-word fast floating-point numbers

to fixed-point format is made simple by using the

ashift instruction.

a

------------------

*******************************************/

_ff16_to_fract16:

.global _ff16_to_fract16;

r0.h = ashift r0.h by r0.l; // shift the
// binary point

r0 >>= 16;

rts;

_ff16_to_fract16.end:

Listing 6 Long fast floating-point (fastfloat32) to fixed­point conversion

/*******************************************
fract32 ff32_to_fract32(fastfloat32);

------------------

Input parameters (compiler convention):

R0.L = ff32.exp

R1 = ff32.frac

Output parameters (compiler convention):

R0 = fract32

------------------

Assembly code for both the short version

*******************************************/

(fastfloat16) and the long version (fastfloat32) is

shown below.

Listing 5 Short fast floating-point (fastfloat16) to fixed­point conversion

/*******************************************
fract16 ff16_to_fract16(fastfloat16);

------------------

Input parameters (compiler convention):

R0.L = ff16.exp

R0.H = ff16.frac

_ff32_to_fract32:

.global _ff32_to_fract32;

r0 = ashift r1 by r0.l; // shift the
// binary point

rts;

_ff32_to_fract32.end:

Converting Between Fast
Floating-Point and IEEE

Output parameters (compiler convention):

R0.L = fract16

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 3 of 9

Floating-Point Formats

The basic approach to converting from the IEEE
floating-point format to the fast floating-point

a

format begins with extracting the mantissa,
exponent, and sign bit ranges from the IEEE
floating-point word. The exponent needs to be
unbiased before setting the fast floating-point
exponent word. The mantissa is used with the
sign bit to create a twos-complement signed
fraction, which completes the fast floating-point

two-word format.

Doing these steps in reverse converts a fast
floating-point number into IEEE floating-point
format.

It is outside the scope of this document to
provide more detail about the IEEE-754 floating­point format. The attached compressed package
contains sample C code to perform the
conversions.

The compressed package that

L

accompanies this document contain
sample routines that convert between the
fast floating-point and the IEEE floating­point numbers. Note that they do not
treat any special IEEE defined values
like NaN, +∞, or -∞.

Assembly code for both the short version

(fastfloat16) and the long version (fastfloat32) is

shown below.

For the fastfloat16 arithmetic operations

L

(add, subtract, divide), the following
parameter passing conventions are used.
These are the default conventions used
by the Blackfin Processor compiler.

Calling Parameters
r0.h = Fraction of x (=Fx)
r0.l = Exponent of x (=Ex)

r1.h = Fraction of y (=Fy)
r1.l = Exponent of y (=Ey)

Return Values
r0.h = Fraction of z (=Fz)
r0.l = Exponent of z (=Ez)

Floating-Point Addition

The algorithm for adding two numbers in two­word fast floating-point format is as follows:

1. Determine which number has the larger
exponent. Let’s call this number X (= Ex, Fx)
and the other number Y (= Ey, Fy).

2. Set the exponent of the result to Ex.

3. Shift Fy right by the difference between Ex
and Ey, to align the radix points of Fx and Fy.

4. Add Fx and Fy to produce the fraction of the
result.

5. Treat overflows by scaling back the input
parameters, if necessary.

6. Normalize the result.

Listing 7 Short fast floating-point (fastfloat16) addition

/*******************************************
fastfloat16
add_ff16(fastfloat16,fastfloat16);

*******************************************/
_add_ff16:
.global _add_ff16;
r2.l = r0.l - r1.l (ns); // is Ex > Ey?
cc = an; // negative result?
r2.l = r2.l << 11 (s); // guarantee shift

// range [-16,15]
r2.l = r2.l >>> 11;
if !cc jump _add_ff16_1; // no, shift y
r0.h = ashift r0.h by r2.l; // yes,

// shift x
jump _add_ff16_2;

_add_ff16_1:
r2 = -r2 (v);
r1.h = ashift r1.h by r2.l; // shift y
a0 = 0;

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 4 of 9

a0.l = r0.l; // you can't do r1.h = r2.h
r1.l = a0 (iu); // so use a0.x as an

// intermediate storage
// place

_add_ff16_2:
r2.l = r0.h + r1.h (ns); // add fractional

// parts
cc = v; // was there an overflow?
if cc jump _add_ff16_3;

// normalize
r0.l = signbits r2.l; // get the number of

// sign bits
r0.h = ashift r2.l by r0.l; // normalize

// the mantissa
r0.l = r1.l - r0.l (ns); // adjust the

// exponent
rts;

// overflow condition for mantissa addition
_add_ff16_3:
r0.h = r0.h >>> 1; // shift the mantissas

// down
r1.h = r1.h >>> 1;
r0.h = r0.h + r1.h (ns); // add fractional

// parts
r2.l = 1;
r0.l = r1.l + r2.l (ns); // adjust the

//exponent
rts;
_add_ff16.end:

For the fastfloat32 arithmetic operations

L

(add, subtract, divide), the following
parameter passing conventions are used.
These are the default conventions used
by the Blackfin Processor compiler.

Calling Parameters
r1 = Fraction of x (=Fx)
r0.l = Exponent of x (=Ex)

r3 = [FP+20] = Fraction of y (=Fy)
r2.l = Exponent of y (=Ey)

a

Return Values
r1 = Fraction of z (=Fz)
r0.l = Exponent of z (=Ez)

Listing 8 Long fast floating-point (fastfloat32) addition

/*******************************************
fastfloat32 add_ff32(fastfloat32,
fastfloat32);

*******************************************/

#define FF32_PROLOGUE() link 0; r3 =
[fp+20]; [--sp]=r4; [--sp]=r5

#define FF32_EPILOGUE() r5=[sp++];
r4=[sp++]; unlink

.global _add_ff32;
_add_ff32:
FF32_PROLOGUE();
r4.l = r0.l - r2.l (ns); // is Ex > Ey?
cc = an; // negative result?
r4.l = r4.l << 10 (s); // guarantee shift

// range [-32,31]
r4.l = r4.l >>> 10;
if !cc jump _add_ff32_1; // no, shift Fy
r1 = ashift r1 by r4.l; // yes, shift Fx
jump _add_ff32_2;

_add_ff32_1:
r4 = -r4 (v);
r3 = ashift r3 by r4.l; // shift Fy
r2 = r0;
_add_ff32_2:
r4 = r1 + r3 (ns); // add fractional parts
cc = v; // was there an overflow?
if cc jump _add_ff32_3;

// normalize
r0.l = signbits r4; // get the number of

// sign bits
r1 = ashift r4 by r0.l; // normalize the

// mantissa

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 5 of 9

r0.l = r2.l - r0.l (ns); // adjust the
// exponent

FF32_EPILOGUE();
rts;

// overflow condition for mantissa addition
_add_ff32_3:
r1 = r1 >>> 1;
r3 = r3 >>> 1;
r1 = r1 + r3 (ns); // add fractional parts

r4.l = 1;
r0.l = r2.l + r4.l (ns); // adjust the

// exponent
FF32_EPILOGUE();
rts;
_add_ff32.end:

Floating-Point Subtraction

The algorithm for subtracting one number from
another in two-word fast floating-point format is
as follows:

1. Determine which number has the larger
exponent. Let’s call this number X (= Ex, Fx)
and the other number Y (= Ey, Fy).

2. Set the exponent of the result to Ex.

3. Shift Fy right by the difference between Ex
and Ey, to align the radix points of Fx and Fy.

4. Subtract the fraction of the subtrahend from
the fraction of the minuend to produce the
fraction of the result.

5. Treat overflows by scaling back the input
parameters, if necessary.

6. Normalize the result.

Assembly code for both the short version

(fastfloat16) and the long version (fastfloat32) is

shown below.

a

Listing 9 Short fast floating-point (fastfloat16)
subtraction

/*******************************************
fastfloat16 sub_ff16(fastfloat16,
fastfloat16);

*******************************************/
.global _sub_ff16;
_sub_ff16:
r2.l = r0.l - r1.l (ns); // is Ex > Ey?
cc = an; // negative result?
r2.l = r2.l << 11 (s); // guarantee shift

// range [-16,15]
r2.l = r2.l >>> 11;
if !cc jump _sub_ff16_1; // no, shift y
r0.h = ashift r0.h by r2.l; // yes, shift

// x
jump _sub_ff16_2;

_sub_ff16_1:
r2 = -r2 (v);
r1.h = ashift r1.h by r2.l; // shift y
a0 = 0;
a0.l = r0.l; // you can't do r1.h = r2.h
r1.l = a0 (iu); // so use a0.x as an

// intermediate storage place

_sub_ff16_2:
r2.l = r0.h - r1.h (ns); // subtract

// fractions
cc = v; // was there an overflow?
if cc jump _sub_ff16_3;

// normalize
r0.l = signbits r2.l; // get the number of

// sign bits
r0.h = ashift r2.l by r0.l; // normalize

// mantissa
r0.l = r1.l - r0.l (ns); // adjust

// exponent
rts;

// overflow condition for mantissa
subtraction

_sub_ff16_3:
r0.h = r0.h >>> 1; // shift the mantissas

// down

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 6 of 9

r1.h = r1.h >>> 1;
r0.h = r0.h - r1.h (ns); // subtract

// fractions
r2.l = 1;
r0.l = r1.l + r2.l (ns); // adjust the

//exponent
rts;
_sub_ff16.end:

Listing 10 Long fast floating-point (fastfloat32)
subtraction

/*******************************************
fastfloat32 sub_ff32(fastfloat32,
fastfloat32);

*******************************************/

#define FF32_PROLOGUE() link 0; r3 =
[fp+20]; [--sp]=r4; [--sp]=r5

#define FF32_EPILOGUE() r5=[sp++];
r4=[sp++]; unlink

.global _sub_ff32;
_sub_ff32:
FF32_PROLOGUE();
r4.l = r0.l - r2.l (ns); // is Ex > Ey?
cc = an; // negative result?
r4.l = r4.l << 10 (s); // guarantee shift

// range [-32,31]
r4.l = r4.l >>> 10;
if !cc jump _sub_ff32_1; // no, shift Fy
r1 = ashift r1 by r4.l; // yes, shift Fx
jump _sub_ff32_2;

_sub_ff32_1:
r4 = -r4 (v);
r3 = ashift r3 by r4.l; // shift Fy
r2 = r0;

_sub_ff32_2:
r4 = r1 - r3 (ns); // subtract fractions
cc = v; // was there an overflow?
if cc jump _sub_ff32_3;

a

// normalize
r0.l = signbits r4; // get the number of

// sign bits
r1 = ashift r4 by r0.l; // normalize the

// mantissa
r0.l = r2.l - r0.l (ns); // adjust the

//exponent
FF32_EPILOGUE();
rts;

// overflow condition for mantissa
// subtraction

_sub_ff32_3:
r1 = r1 >>> 1;
r3 = r3 >>> 1;
r1 = r1 - r3 (ns); // subtract fractions

r4.l = 1;
r0.l = r2.l + r4.l (ns); // adjust the

// exponent
FF32_EPILOGUE();
rts;
_sub_ff32.end:

Floating-Point Multiplication

Multiplication of two numbers in two-word fast
floating-point format is simpler than either
addition or subtraction, because there is no need
to align the radix points. The algorithm to

multiply two numbers x and y (Ex, Fx and Ey,

Fy) is as follows:

1. Add Ex and Ey to produce the exponent of the
result.

2. Multiply Fx by Fy to produce the fraction of
the result.

3. Normalize the result.

Assembly code for both the short version

(fastfloat16) and the long version (fastfloat32) is

shown below.

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 7 of 9

Listing 11 Short fast floating-point (fastfloat16)
multiplication

/*******************************************
fastfloat16 void mult_ff16(fastfloat16,
fastfloat16);

*******************************************/
.global _mult_ff16;
_mult_ff16:
r3.l = r0.l + r1.l (ns);
a0 = r0.h * r1.h;

r2.l = signbits a0; // get the number of
// sign bits

a0 = ashift a0 by r2.l; // normalize the
// mantissa

r0 = a0;
r0.l = r3.l - r2.l (ns); // adjust the

// exponent
rts;
_mult_ff16.end:

Listing 12 Long fast floating-point (fastfloat16)
multiplication

/*******************************************
fastfloat32 void mult_ff32(fastfloat32,

fastfloat32);
*******************************************/

#define FF32_PROLOGUE() link 0; r3 =
[fp+20]; [--sp]=r4; [--sp]=r5

#define FF32_EPILOGUE() r5=[sp++];
r4=[sp++]; unlink

.global _mult_ff32;
_mult_ff32:
FF32_PROLOGUE();
r0.l = r0.l + r2.l (ns); // add the

// exponents

// perform 32-bit fractional multiplication
a1 = a0 = 0;
r5 = 0;
r5.l = (a0 = r1.l * r3.l) (fu);
a1 = r5;

a

r2 = (a0 = r1.h * r3.h),
a1 += r1.h * r3.l (m);

r5 = (a1 += r3.h * r1.l) (m);
r5 = r5 >>> 15;
r1 = r2 + r5;

// normalize
r4.l = signbits r1; // get the number of

// sign bits
r1 = ashift r1 by r4.l; // normalize the

// mantissa
r0.l = r0.l - r4.l (ns); // adjust the

// exponent
FF32_EPILOGUE();
rts;
_mult_ff32.end:

Summary

The two-word fast floating-point technique

described in this document can greatly improve
floating-point computational efficiency on the
fixed-point Blackfin Processor platform. The
specific operations described above can be used
as standalone routines, or as starting points for
more advanced calculations specific to a
particular application. The compressed source
code package that accompanies this document
provides a starting for using the fast floating­point method in new projects.

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 8 of 9

a

References

Analog Devices (DSP Division). Digital Signal Processing Applications: Using the ADSP-2100 Family
(Volume 1). NJ: Prentice Hall, 1992.

Knuth, D. E. The Art of Computer Programming: Volume 2 / Seminumerical Algorithms. Second Edition.
Reading, MA: Addison-Wesley Publishing Company, 1969.

IEEE. IEEE Standard for Binary Floating-Point Arithmetic: ANSI/IEEE Std 754-1985. New York: The

Institute of Electrical and Electronics Engineers, 1985.

Document History

Version Description
May 26, 2003 by Tom L. Code updated to check for overflow conditions; New test cases added
May 12, 2003 by Tom L. Updated according to new naming conventions
February 19, 2003 by Tom L. Initial release

Fast Floating-Point Arithmetic Emulation on the Blackfin® Processor Platform (EE-185) Page 9 of 9
