Engineer-to-Engineer Note EE-175

a

Technical notes on using Analog Devices DSPs, processors and development tools

Contact our technical support at [e-mail] and at [e-mail]
Or vi sit our o n-li ne r esou rces htt p:/ /www.analog.com/ee-notes and http://www.analog.com/processors

Emulator Troubleshooting Guide

Contributed by Kathleen Smith and Linda Gray Rev 6 – October 22, 2004

Introduction

DSP Tools Support ([e-mail])
handles all initial e-mail requests regarding
problems with in-circuit emulators (ICEs). Most
problems are resolved by e-mail. Authorization
to return units is reserved until all other options
have been exhausted. To resolve these issues by
e-mail, the support team needs as much
information as possible to identify the problem
and to provide a solution.

The following troubleshooting guide suggests
how to quickly and easily resolve most
installation, connection, and software problems.
It also highlights the information required by the
support team to authorize the return of an
emulator for repair.

Emulator Manuals

The latest manuals are also available via
download from the ADI Web at the URLs listed
below.

HPPCI ICE
HPUSB ICE
USB ICE

http://www.analog.com/dsp/manuals

ADSP-218x EZ-ICE®

http://www.analog.com/processors/proces
sors/ADSP/technicalLibrary/manuals/16Bi
tIndex.html

Summit-ICE™ (now obsolete)

Installation

The VisualDSP++® toolset includes a full set of
documentation in pdf format. These documents
can be found under

>Hardware Tools->ICEs

hardware installation and configuration using
these documents. When reporting faults, confirm
that you followed these procedures and indicate
the exact step number that produced an error. Be
sure to provide the full details of any error
message received.

Help->Contents->Manuals-

in the IDDE. Perform

Apex-ICE™ (now obsolete)

http://www.analog.com/processors/resour
ces/technicalLibrary/manuals/legacyManu
als/legacy_index.html

Other Equipment

The support team needs to know which operating
system, evaluation board, and version of
VisualDSP++ you are using. This information is
used to confirm compatibility and duplicate the
problem. Please indicate whether you have a
third-party multiprocessor board, clustered
multiple boards, or externally configured
memory. All of these factors may affect the
configuration of your equipment.

Copyright 2004, Analog Devices, Inc. All rights reserved. Analog Devices assumes no responsibility for customer product design or the use or application of
customers’ products or for any infringements of patents or rights of others which may result from Analog Devices assistance. All trademarks and logos are property
of their respective holders. Information furnished by Analog Devices Applications and Development Tools Engineers is believed to be accurate and reliable, however
no responsibility is assumed by Analog Devices regarding technical accuracy and topicality of the content provided in Analog Devices’ Engineer-to-Engineer Notes.

a

Software

Latest Emulator Drivers

VisualDSP++ 3.5

The emulation tools are included in the base
VisualDSP++ 3.5 installation. There is no need
for a second ICE software installation procedure
as was required in previous versions of
VisualDSP++. To install emulator support, select
the appropriate components in the installation
wizard (they are selected by default). The
installer handles the installation and/or update of
the emulator hardware device driver.

VisualDSP++ 2.0 and 3.0

The latest upgrade to the emulator software,
version 7.0.2, is available to download from the
ADI website at the URL listed below. Please
ensure that you have these drivers.

http://www.analog.com/processors/resour
ces/crosscore/emulators/archives.html

Test Connections

ADSP-218x

The ADSP-218x tools do not come with utilities
to test the communication between the PC’s
serial port and your EZ-KIT Lite or between the
PC’s serial port and your emulator. However, a
Microsoft® utility is available. See Appendix A,
which is a brief guideline on using the
HyperTerminal test to confirm that
communications are functioning properly.
Perform this test and provide the support team
with the results when you report a problem.

All other Platforms

The tools include the following utilities to test
communications between the PC’s ports and
your emulator:

JTAG ICE Configurator – used to configure the
ICE SW with the target.

Be sure to install VisualDSP++ first, and then the
emulator software.

Restrictions

The Apex, USB and HPUSB ICEs have a USB
interface and are therefore not compatible with
Windows NT.

EZ-KIT Lite
number begins with KIT- ) of VisualDSP++ do
not support emulation or simulation.

® licensed versions (the serial

Source Code

Ensure that the emulator problems are not caused
by programming issues. If in doubt, zip up your
project and send it to DSP Tools Support
([e-mail]) so that we
can try to reproduce the problem ourselves.

ICETest utility – used to test the communications
between the PC, emulator and target.

These are explained in detail in the VisualDSP++
online help and emulator guides (the URLs are
listed in the installation section above). Use the
guides and explain exactly which step, if any,
causes an error. List all received error messages
and if there are none please confirm that these
utilities have been run with no errors.

Emulator Troubleshooting Guide (EE-175) Page 2 of 7

a

Eliminate Other Possibilities

Emulator problems are often difficult to confirm.
The process of elimination is often a good way to
proceed. Check the hardware in the following list
for errors. If all the hardware is OK, the problem
may lie with the emulator. Be sure to inform the
support team of the checks you made and the
results.

Cables – Ensure proper insertion. Replace them
with other known working cables, if available.

Ports – Use another port or another known
working emulator, if available, on the same port.

PC – Ensure that the PC has adequate resources
and is working OK. Use the emulator on another
PC, if available.

Code – Try the Examples provided with
VisualDSP++ tools.

Custom board – Ensure that it conforms to JTAG
regulations as described in EE-68 which can be
found at the following link:

Debug Session List

Occasionally, a corrupted session key causes the
emulator/debugger to stop responding. To correct
this, follow the guidelines below. Confirm to the
support team that you have tried this, and
provide the results.

1. From the Start menu, open VisualDSP++

whilst holding down the Ctrl key.

2. When the Session List dialog box appears,

delete all sessions currently defined.

3. Immediately define the emulator session

required once more and then activate it.

Frequently Asked Questions

It may be useful to look at our DSP
knowledgebase on the ADI Web at the following
URL:

http://www.analog.com/dsp/knowledgebase

http://www.analog.com/ee-notes/

Power Supply – Try another power supply if
available.

Other emulators – If available, use other
emulators, of the same type or other types to
ensure that the problem is not related to the
particular unit or an incompatibility of the
emulator type.

Emulator Troubleshooting Guide (EE-175) Page 3 of 7

a

Returns Policy

To enable the support team to issue an RMA
number authorizing the return of the emulator for
repair, please do all of the following:

Basic Troubleshooting

Support must know what trouble-shooting
techniques you have carried out and the results.
Refer to the above guidelines and provide as
much detail as possible. The majority of these
issues can be resolved without returning the
emulator. Providing the required information at
the time of the RMA request greatly speeds up
the problem resolution and provides better client
service.

Warranty Details and Proof of Purchase

Emulators that are less than one year old are
within warranty. Repairs within that period are
free of charge. You must supply proof of
purchase for all returns that are within warranty.
Returns that are outside of this one-year period
must be accompanied by a payment order of
$300 (US) for full emulator, $160 (US) for POD
only repair.

not been specifically authorized by Analog
Devices to send back. Any emulator returned to
Analog Devices without an RMA number will
not be accepted.

Using an emulator in any way other than

L

Other Details

Please contact [e-mail]
for an RMA Form, which must be filled out and
returned to them. Information required on this
form includes Customer name and Company
Address, Serial number of the emulator, Sales
Order number, etc.

Issue of RMA Number and Returns Address

The RMA number is valid only for that particular
customer and emulator. Each emulator is
processed separately. Do not use an RMA
number to send back emulator(s) that you have

Emulator Troubleshooting Guide (EE-175) Page 4 of 7

its intended purpose invalidates the
warranty.

a

Appendix: HyperTerminal Test

Background Information

The HyperTerminal test is a utility used to test
the ADSP-218x EZ-ICE over the serial port
interface. The ADSP-218x EZ-ICE requires a
serial port to interface with the PC, and will not
work with the JTAG ICETest utility.

HyperTerminal does a variety of things. It tests
the interface between the "TARGET" (A target is
the customer board with a DSP on it), and the
EZ-ICE. It tests communications from the EZ­ICE box over the ribbon cable to the target
board. HyperTerminal performs other internal
tests such as flash tests and RAM tests. As a
result of being able to actually perform these
tests (see the menu screen from HyperTerminal),
a fundamental test of communication between
the EZ-ICE and the PC occurs. Think of it as a
block diagram where the PC is one block, the
EZ-ICE is another, and the target is the third
block.

------ -------- --------­ | PC | A |EZ-ICE| B |target |
| 1 |<------>| 2 |<------>| 3 |
| | | | | |

------ -------- ---------

If you can see the HyperTerminal menu screen,
you are testing communication path 'A' between
1 and 2. If you can perform the DSP interface
test (i), you are testing path 'B' between 2 and 3.
The fact that you can actually select the test and
see the results tests path 'A'. If you cannot see the
HyperTerminal information, there is no possible
way to bring up a VisualDSP++ session because
path 'A' is not functioning properly. If the DSP
interface test fails, there is no way to bring up a
VisualDSP++ session because path 'B' has failed
and obviously, if path 'A' failed, you could not
run the DSP interface test to test path 'B'.

Running the Test

HyperTerminal is a Windows utility, which
requires that your target is powered up and
connected to your ICE. For Windows 9x/ME,
this utility is found under Start->Programs->

Accessories->Communications->HyperTerminal

For Windows NT and 2000, it is found under
Start->Programs->Accessories->HyperTerminal

->HyperTerminal.
Do not invoke VisualDSP++ and HyperTerminal

at the same time. In other words, do not try to
leave HyperTerminal open (or minimized) in the
background and bring up VisualDSP++. The
COM port has already been allocated to the
HyperTerminal software and cannot be shared
with VisualDSP++. Consequently, VisualDSP++
cannot communicate with the target at the same
time using COM port as HyperTerminal.

To run the HyperTerminal test:

1. With the ICETest utility 1.00.9 installed, you

must know what COM port is being used
when running the HyperTerminal test.

2. Bring up the HyperTerminal utility and click

on the hyperterminal.exe.

3. Fill in any name for the test.

4. Select the COM port connected to your ICE.

5. Select the following COM port properties/

port settings:

• Bits per second= 9600

• Data bits= 8

• Parity = none

• Stop bits = 1

• Flow control = hardware

6. Click OK.

7. With the ICE powered up and connected to

your target, press the ICE Reset button once.
You get the following splash screen:

.

Emulator Troubleshooting Guide (EE-175) Page 5 of 7

a

//////////////////////////////////////////////
20 Boot code v1.0a May 7, 1997
30 Flash code v1.0N July 14, 2000
40

50 <Enter> for menu (1 sec)

60 $$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$$
70 ENTERING EMULATOR
80
90 jumping to FLASH ROM
100
//////////////////////////////////////////////

Look at line 50 (in red). Immediately after you
press the Reset button on the EZ-ICE, press the
Enter key on your keyboard. This opens another
menu that looks like this:

Boot code v1.0a May 7, 1997
20
30 j - jump to emulator in Flash memory
40 c - Compute CRC of Boot code and Flash code
50 i - DSP interface test
60 t - SRAM test
70 f - Flash memory test
80 update - update FLASH ROM
90 erase - erase all FLASH ROM
100 ?–menu
110 $

When this menu appears, you can run the tests in
the menu items by pressing that letter and then
pressing Enter. For example, when you run the i
test, the screen might look like:

being able to see the results in HyperTerminal,
you are testing between the PC and the target
board.

You can also run the SRAM test, which tests the
EZ-ICE system RAM, This test does not test the
DSP's SRAM; the EZ-ICE need not be connected
to a "target board" to run the test. Run the test by
pressing 't' and then Enter.

$t

270 Testing SRAM 0xC000..0xEFFF
280 0 error(s) with 0000, 0000, 0000
290 0 error(s) with 5555, 5555, 5555
300 0 error(s) with AAAA, AAAA, AAAA
310 0 error(s) with FFFF, FFFF, FFFF
320 0 error(s) with increment
330
340 Boot code v1.0a May 7, 1997
350
360 j - jump to emulator in Flash memory
370 c - Compute CRC of Boot code and Flash code
380 i - DSP interface test
390 t - SRAM test
400 f - Flash memory test
410 update - update FLASH ROM
420 erase - erase all FLASH ROM
430 ?–menu

Lines 270 through 320 show the result of this
test. In this example case, the test passed without
errors.

Testing DSP Emulation Port

130 Expect 0x0F5A got 0x0000 – ERROR
140 Expect 0xA5F0 got 0x0000 – ERROR
150
160 Boot code v1.0a May 7, 1997
170
180 j - jump to emulator in Flash memory
190 c - Compute CRC of Boot code and Flash code
200 i - DSP interface test
210 t - SRAM test
220 f - Flash memory test
230 update - update FLASH ROM
240 erase - erase all FLASH ROM
250 ?–menu
260 $

Notice line 110. Press 'i' then press Enter and run
the interface test. Lines 130 through 140 show
that an error occurred. This test writes to a
register inside the DSP and then reads it back. If
the target board is not connected (or is
malfunctioning), this test will fail just like above.
This test checks the interface between the "target
board" and the EZ-ICE. However, by virtue of

By typing 'f' then Enter, the flash test is selected.
Typically, flash tests are destructive to the
contents of the flash; this is no exception. To get
into this test, type 'f', Enter, then Yes and Enter
You must type Yes within 1 second of the Enter
or the test will not be performed. If you do not do
it fast enough, it looks like this:

$f

441 The emulator code in Flash will be
erased and must be reprogrammed
442 Enter 'yes' to continue test
443 $abort

A passed test looks like this:

$f

450 The emulator code in Flash will be
erased and must be reprogrammed
460 Enter 'yes' to continue test
470 $yes
480 Testing...
490 passed erase test

Emulator Troubleshooting Guide (EE-175) Page 6 of 7

a

500 passed increment pattern test
510 passed all zero test
520
530 Boot code v1.0a May 7, 1997
540
550 j - jump to emulator in Flash memory
560 c - Compute CRC of Boot code and Flash code
570 i - DSP interface test
580 t - SRAM test
590 f - Flash memory test
600 update - update FLASH ROM
610 erase - erase all FLASH ROM
620 ?-menu
630 $

Line 450 warns you that the flash will be erased
and will need to be reprogrammed. Lines 490­510 say the flash passed the various different
tests.

When you install the emulator software and run
this test for the first time, it asks you to press
Reset so it can check the firmware version. It
then writes this version to the Registry and does
not need to check it again. If you run
HyperTerminal and select the flash test, the test
is destructive to the flash and erases it. If you
start VisualDSP++, the .DLL is invoked.
Unfortunately, the .DLL has no way of knowing
that the flash was destroyed, so it fails.

To restore the flash in the emulator, perform the
following procedure or you will not be able to
use the emulator with the debugger.

1) Close the debugger and HyperTerminal.

2) Go to START > Run and type in regedit.

3) Go to H_KEY_Current User > Software >

Analog Devices > VisualDSP

218x folder.

and delete the

4) Close the Registry.

5) Restart the VisualDSP++ debugger and

select the proper ICE session that represents
your target. This assumes you corrected the
problem discovered during the
HyperTerminal DSP interface test.

By deleting the registry key, the .DLL is forced to
go out and recheck the version. When it does, it
will be incorrect, and the .DLL will reprogram the
flash.

Document History

Revision Description

Rev 6 – October 22, 2004

by Linda Gray

Rev 5 – March 26, 2004

by Kathleen Smith

Rev 4 – October 23, 2003

by Kathleen Smith

Rev 3 – April 01, 2003

by Kathleen Smith

Rev 2 – December 03, 2002

by Kathleen Smith

Rev 1 – November 01, 2002

by Kathleen Smith

URLs updated according to redesign of ww.analog.com site.
Updated to current emulator hardware product offer

Added Price Change and updated emulator software support
Added actual DSP Tools Technical Support e-mail address and USB-ICEs

Added POD repair price, also note of invalidating warranty, corrected URLs

Added HPPCI ICE; removed mention of customer serial number

Added Emulator Serial Number

Initial release

Emulator Troubleshooting Guide (EE-175) Page 7 of 7
