Analog Devices AD9875BSTRL, AD9875BST, AD9875-EB Datasheet

REV. 0

Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties that
may result from its use. No license is granted by implication or otherwise
under any patent or patent rights of Analog Devices.

AD9875

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: [phone]www.analog.com
Fax: [phone] © Analog Devices, Inc., 2001

a

Broadband Modem

Mixed-Signal Front End

FUNCTIONAL BLOCK DIAGRAM

REGISTER
CONTROL

Rx

MUX

ADC

PGA

LPF

PGA

TxDAC+

Kx INTERPOLATION

LPF/BPF

Tx

MUX

PLL-A

 L

PLL-B

 M/N

VRC

3

10

10 10

AD9875

Tx+
Tx–

GATE
FB
OSCIN

XTAL

Rx+
Rx–

PWR DN

Tx QUIET

GAIN

Tx [5:0]

Tx SYNC

CLK-A

CLK-B

Rx SYNC

Rx [5:0]

SPORT

V

REF

CLOCK GEN

PRODUCT DESCRIPTION

The AD9875 is a single supply Broadband modem mixed­signal front end (MxFE) IC. The devices contain a transmit
path Interpolation Filter and DAC, and a receive path PGA,
LPF and ADC supporting a variety of Broadband modem
applications. Also on-chip is a PLL clock multiplier that pro­vides all required clocks from a single crystal or clock input.
The AD9875 provides 10-bit converter performance on both
the Tx and Rx paths.

The TxDAC+ uses a selectable digital 2× or 4× interpolation
low-pass or band-pass filter to further oversample transmit
data and reduce the complexity of analog reconstruction filtering.
The transmit path signal bandwidth can be as high as 26 MHz
at an input data rate of 64 MSPS. The 10-bit DAC provides
differential current outputs for optimum noise and distortion
performance. The DAC full-scale current can be adjusted
from 2 mA to 20 mA by a single resistor, providing 20 dB of
additional gain range.

The receive path consists of a PGA, LPF, and ADC. The two-stage
PGA has a gain range of –6 dB to +36 dB, and is programmable
in 2 dB steps, adding 42 dB of dynamic range to the receive path.

MxFE is a trademark of Analog Devices, Inc.
TxDAC+ is a registered trademark of Analog Devices, Inc.

The receive path LPF cutoff frequency can be programmed to either
12 MHz or 26 MHz. The filter cutoff frequency can also be tuned
or bypassed where filter requirements differ. The 10-bit ADC uses
a multistage differential pipeline architecture to achieve excellent
dynamic performance with low power consumption.

The AD9875 provides a voltage regulator controller (VRC) that
can be used with an external power MOSFET transistor to form
a cost-effective 1.3 V linear regulator.

The digital transmit and receive ports are each multiplexed to a
bus width of 5/6 bits and are clocked at a frequency of twice the
10-bit word rate.

The AD9875 ADC and/or DAC can also be used at higher
sampling rates as high as 64 MSPS in a 5-bit resolution non­multiplexed mode.

The AD9875 is pin-compatible with the 12-bit AD9876. Both are
available in a space-saving 48-lead LQFP package. They are speci­fied over the industrial (–40°C to +85°C) temperature range.

FEATURES
Low Cost 3.3 V-CMOS Mixed-Signal Front End (

MxFE™

)
Converter for Broadband Modems
10-/12-Bit D/A Converter (TxDAC+

®

)
64/32 MSPS Input Word Rate
2/4 Interpolating LPF or BPF Transmit Filter
128 MSPS DAC Output Update Rate
Wide (26 MHz) Transmit Bandwidth
Power-Down Mode

10-/12-Bit, 50 MSPS A/D Converter

Fourth Order Low-Pass Filter 12 MHz or 26 MHz
with Bypass
–6 dB to +36 dB Programmable Gain Amplifier

Internal Clock Multiplier (PLL)
Clock Outputs
Voltage Regulator Controller
48-Lead LQFP Package

APPLICATIONS
Powerline Networking
Home Phone Networking
xDSL
Broadband Wireless
Home RF

REV. 0

–2–

AD9875–SPECIFICA TIONS

Test

Parameter Temp Level Min Typ Max Unit

OSC IN CHARACTERISTICS

Frequency Range Full II 10 64 MHz
Duty Cycle 25°CII 405060 %
Input Capacitance 25°C III 3 pF
Input Impedance 25°C III 100 MΩ

CLOCK OUTPUT CHARACTERISTICS

CLKA Jitter (f

CLKA

Derived from PLL) 25°C III 14 ps rms
CLKA Duty Cycle 25°C III 50 ±5%
CLKB Jitter (f

CLKB

Derived from PLL) 25°C III 33 ps rms
CLKB Duty Cycle 25°C III 50 ±5%

Tx CHARACTERISTICS

Tx Path Latency, 4× Interpolation Full II 82 f

DAC

Cycles

Interpolation Filter Bandwidth (–0.1 dB)

4× Interpolation, LPF Full II 13 MHz
2× Interpolation, LPF Full II 26 MHz

TxDAC

Resolution Full II 10 Bits
Conversion Rate Full II 10 128 MHz
Full-Scale Output Current Full II 2 10 20 mA
Voltage Compliance Range Full II –0.5 +1.5 V
Gain Error Full II –5 ±2+5 % FS
Output Offset Full II 0 7 19 µA
Differential Nonlinearity 25°C III 0.5 LSB
Integral Nonlinearity 25°C III 1 LSB
Output Capacitance 25°C III 5 pF
Phase Noise @ 1 kHz Offset, 10 MHz Signal 25°C III –90 dBc/Hz
Signal-to-Noise and Distortion (SINAD)

10 MHz Analog Out AD9875 (20 MHz BW) Full I 59 61 dB

Wideband SFDR (to Nyquist, 64 MHz Max) 25°C III

5 MHz Analog Out 25°C III 78 dBc
10 MHz Analog Out 25°C III 72 dBc

Narrowband SFDR (3 MHz Window):

10 MHz Analog Out 25°C III 80 dBc

IMD (f1 = 6.9 MHz, f2 = 7.1 MHz) 25°C III –76 dBFS

Rx PATH CHARACTERISTICS

Resolution Full II 10 Bits
Conversion Rate Full II 7.5 55 MHz
Pipeline Delay, ADC Clock Cycles Full II 5.5 Cycles
DC Accuracy

Differential Nonlinearity 25°C II –1.0 ±0.25 +1.0 LSB
Integral Nonlinearity 25°C II –2.0 ±0.5 +2.0 LSB

Dynamic Performance

(A

IN

= –0.5 dBFS, f = 5 MHz)

@ f

OSCIN

= 32 MHz
Signal-to-Noise and Distortion Ratio (SINAD) 25°C III 59.6 dB
Effective Number of Bits (ENOB) 25°C III 9.5 Bits

Signal-to-Noise Ratio (SNR) 25°C III 60 dB

Total Harmonic Distortion (THD) 25°C III –65 dB
Spurious Free Dynamic Range (SFDR) 25°C III 68 dB

Dynamic Performance

(

AIN = –0.5 dBFS, f = 10 MHz

)

@ F

PLLB/2

= 50 MHz
Signal-to-Noise and Distortion Ratio (SINAD) 25°C III 54 dB
Effective Number of Bits (ENOB) 25°C III 8.6 Bits
Signal-to-Noise Ratio (SNR) 25°C III 55 dB
Total Harmonic Distortion (THD) 25°C III –61 dB
Spurious Free Dynamic Range (SFDR) 25°C III 68 dB

(VS = 3.3 V  10%, f

OSCIN

= 32 MHz, f

DAC

= 128 MHz, Gain = –6 dB, R

SET

= 4.02 k,

100  DAC single-ended load, unless otherwise noted. )

REV. 0

–3–

AD9875

Test

Parameter Temp Level Min Typ Max Unit

Rx PATH GAIN/OFFSET

Minimum Programmable Gain 25°C III –6 dB
Maximum Programmable Gain

(12 MHz Filter) 25°C III 36 dB

(26 MHz Filter) 25°C III 30 dB
Gain Step Size 25°C III 2 dB
Gain Step Accuracy 25°C III ±0.4 dB
Gain Range Error 25°C III ±1.0 dB
Offset Error, PGA Gain = 0 dB (AD9875) 25°C III ±4.0 LSB
Absolute Gain Error, PGA Gain = 0 dB 25°C III ±0.8 dB

Rx PATH INPUT CHARACTERISTICS

Input Voltage Range 25°C III 4 Vppd
Input Capacitance 25°C III 4 pF
Differential Input Resistance 25°C III 270 Ω
Input Bandwidth (–3 dB) 25°C III 50 MHz
Input Referred Noise (at +36 dB Gain with Filter) 25°C III 16 µV rms
Input Referred Noise (at –6 dB Gain with Filter) 25°C III 684 µV rms
Common-Mode Rejection 25°C III 40 dB

Rx PATH LPF (Low Cutoff Frequency)

Cutoff Frequency 25°C III 12 MHz
Cutoff Frequency Variation 25 °C III ±7%
Attenuation @ 22 MHz 25°C III 20 dB
Passband Ripple 25°C III ±1.0 dB
Group Delay Variation 25°C III 30 ns
Settling Time

(to 1% FS, Min to Max Gain Change) 25°C III 150 ns
Total Harmonic Distortion at Max Gain (THD) 25°C III –68 dBc

Rx PATH LPF (High Cutoff Frequency)

Cutoff Frequency 25°C III 26 MHz
Cutoff Frequency Variation 25 °C III ±7%
Attenuation @ 44 MHz 25°C III 20 dB
Passband Ripple 25°C III ±1.2 dB
Group Delay Variation 25°C III 15 ns
Settling Time

(to 1% FS, Min to Max Gain Change) 25°C III 80 ns
Total Harmonic Distortion at Max Gain (THD) 25°C III –65 dBc

Rx PATH DIGITAL HPF

Latency (ADC Clock Source Cycles) Full II 1 Cycle
Roll-Off in Stopband Full II 6 dB/Octave
–3 dB Frequency Full II f

ADC

/400 Hz

Rx PATH DISTORTION PERFORMANCE

IMD: f1 = 6.9 MHz, f2 = 7.1 MHz
12 MHz Filter: 0 dB 25°C III –65 dBc

: 30 dB 25°C III –57 dBc

28 MHz Filter: 0 dB 25°C III –65 dBc

: 30 dB 25°C III –56 dBc

POWER-DOWN/DISABLE TIMING

Power-Up Delay (Power-Down-to-Active)
DAC 25°CII 40 µs
PLL 25°CII 10 µs
ADC 25°C II 1000 µs
PGA 25°CII 1 µs
LPF 25°CII 1 µs
Interpolator 25°C II 200 ns
VRC 25°CII 2 µs
Minimum RESET Pulsewidth Low (t

RL

) Full III 5 f

OSCIN

Cycle

DAC I

OUT

Off after Tx QUIET Asserted 25°C II 200 ns

DAC I

OUT

On after Tx QUIET Deasserted 25°CII 1 µs

Power-Down Delay (Active-to-Power-Down)

DAC 25°C II 400 ns

Interpolator 25°C II 200 ns

REV. 0

–4–

AD9875–SPECIFICA TIONS

Test

Parameter Temp Level Min Typ Max Unit

Tx PATH INTERFACE

Maximum Input Nibble Rate, 2× Interp. Full II 128 MHz
Tx-Set Up Time (t

SU

) Full II 3.0 ns

Tx-Hold Time (tHD) Full II 0 ns

Rx PATH INTERFACE

Maximum Output Nibble Rate Full I 110 MHz
Rx-DataValid Time (t

VT

) Full II 3.0 ns

Rx-Data Hold Time (tHT) Full II 1.5 ns

CMOS LOGIC INPUTS

Logic “1” Voltage Full II

V

DRVDD

– 0.7 V
Logic “0” Voltage Full II 0.4 V
Logic “1” Current Full II 12 µA
Logic “0” Current Full II 12 µA
Input Capacitance 25°C III 3 µF

CMOS LOGIC OUTPUTS (1 mA Load)

Logic “1” Voltage Full II

V

DRVDD

– 0.6 V
Logic “0” Voltage Full II 0.4 V
Digital Output Rise/Fall Time Full II 1.5 2.5 ns

POWER SUPPLY

All Blocks Powered Up

I

S_TOTAL

(Total Supply Current) Full I 262 288 mA

I

S_TOTAL

(Tx_QUIET Pin Asserted) 25°C III 172 mA

Digital Supply Current (I

DRVDD

+ I

DVDD

)25°C III 77 mA

Analog Supply Current (I

AVDD

)25°C III 185 mA

Power Consumption of Functional Blocks:

Rx LPF 25°C III 110 mA
ADC and FPGA 25°C III 55 mA
Rx Reference 25°C III 2 mA
Interpolator 25°C III 33 mA
DAC 25°C III 18 mA
PLL-B 25°C III 8 mA
PLL-A 25°C III 24 mA
Voltage Regulator Controller 25°C III 1 mA

All Blocks Powered Down

Supply Current I

S

, f

OSCIN

= 32 MHz Full II 19 22 mA

Supply Current I

S

, f

OSCIN

Idle Full II 10 12 mA

Power Supply Rejection

Tx Path (∆V

S

= 10%) 25°C III 62 dB

Rx Path (∆VS = 10%) 25°C III 54 dB

SERIAL CONTROL BUS

Maximum SCLK Frequency (f

SCLK

) Full II 25 MHz

Clock Pulsewidth High (t

PWH

) Full II 18 ns

Clock Pulsewidth Low (t

PWL

) Full II 18 ns
Clock Rise/Fall Time Full II 1 ms
Data/Chip-Select Setup Time (t

DS

) Full II 25 ns

Data Hold Time (t

DH

) Full II 0 ns

Data Valid Time (tDV) Full II 20 ns

RECEIVE-TO-TRANSMIT ISOLATION

(10 MHz, Full-Scale Sinewave Output/Output)
Isolation: Tx Path to Rx Path, Gain = +36 dB 25°C III –75 dB
Isolation: Rx Path to Tx Path, Gain = –6 dB 25°C III –70 dB

VOLTAGE REGULATOR CONTROLLER

Output Voltage (V

FB

with SI2301 Connected) Full I 1.25 1.30 1.35 V

Line Regulation (∆V

FB%

/∆V

DVDD%

× 100%) 25°C III 100 %

Load Regulation (∆V

FB

/∆I

LOAD

)25°C III 60 mΩ

Maximum Load Current (I

LOAD

) Full II 250 mA

Specifications subject to change without notice.

(continued)

REV. 0

AD9875

–5–

CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection. Although
the AD9875 features proprietary ESD protection circuitry, permanent damage may occur on
devices subjected to high-energy electrostatic discharges. Therefore, proper ESD precautions are
recommended to avoid performance degradation or loss of functionality.

Model Temperature Range Package Description Package Option

AD9875BST –40°C to +85°C 48-Lead LQFP ST-48
AD9875-EB –40°C to +85°C Evaluation Board
AD9875BSTRL –40°C to +85°C BST Reel

ABSOLUTE MAXIMUM RATINGS*

Power Supply (VS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.9 V

Digital Output Current . . . . . . . . . . . . . . . . . . . . . . . . . 5 mA

Digital Inputs . . . . . . . . . . . . . . . . . –0.3 V to DRVDD 0.3 V

Analog Inputs . . . . . . . . . . . . . . . . . . –0.3 V to AVDD 0.3 V

Operating Temperature . . . . . . . . . . . . . . . . . –40°C to +85°C

Maximum Junction Temperature . . . . . . . . . . . . . . . . 150°C

Storage Temperature . . . . . . . . . . . . . . . . . . –65°C to +150°C

Lead Temperature (Soldering 10 sec) . . . . . . . . . . . . . 300°C

*Stresses greater than those listed under Absolute Maximum Ratings may cause

permanent damage to the device. This is a stress rating only; functional operation
of the device at these or any other conditions above those indicated in the
operational section of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect device reliability.

EXPLANATION OF TEST LEVELS

I – Devices are 100% production tested at 25°C and guaran-

teed by design and characterization testing for industrial
operating temperature range (–40°C to +85°C).

II – Parameter is guaranteed by design and/or characterization

testing.

III –Parameter is a typical value only.

THERMAL CHARACTERISTICS
Thermal Resistance

48-Lead LQFP



JA

= 57°C/W



JC

= 28°C/W

WARNING!

ESD SENSITIVE DEVICE

ORDERING GUIDE

REV. 0

AD9875

–6–

PIN CONFIGURATION

36
35
34
33
32
31
30
29
28
27
26
25

DRVSS
DRVDD
Rx [0]
Rx [1]
Rx [2]
Rx [3]
Rx [4]
Rx [5]
Rx SYNC
CLK-B
CLK-A
Tx SYNC

13 14 15 16 17 18 19 20 21 22 23 24

DVSS

DVDD

FB

GATE

GAIN

Tx QUIET

Tx [5]

Tx [4]

Tx [3]

Tx [2]

Tx [1]

Tx [0]

1
2
3
4
5
6
7
8

9
10
11
12

OSCIN

SENABLE

SCLK

SDATA

AVDD
AVSS

Tx+
Tx–

AVSS
FSADJ
REFIO

PWR DN

48 47 46 45 44 39 38 3743 42 41 40

XTAL

AVDD

AVSS

Rx–

Rx+

AVSS

AVSS

REFT

REFB

AVSS

AVDD

RESET

PIN 1
IDENTIFIER

TOP VIEW

(Not to Scale)

AD9875

Pin Name Function

1 OSCIN Crystal Oscillator Inverter Input
2 SENABLE Serial Bus Enable Input
3 SCLK Serial Bus Clock Input
4 SDATA Serial Bus Data I/O
5, 38, 47 AVDD Analog 3.3 V Power Supply
6, 9, 39, 42, 43, 46 AVSS Analog Ground
7 Tx+ Transmit DAC+ Output
8 Tx– Transmit DAC– Output
10 FSADJ DAC Full-Scale Output Current Adjust with External Resistor
11 REFIO DAC Bandgap Decoupling Node
12 PWR DN Power-Down Input
13 DVSS Digital Ground
14 DVDD Digital 3.3 V Power Supply
15 FB Regulator Feedback Input
16 GATE Regulator Output to FET Gate
17 GAIN Transmit Data Port (Tx[5:0]) Mode Select Input
18 Tx QUIET Transmit Quiet Input
19–24 Tx[5:0] Transmit Data Input
25 Tx SYNC Transmit Synchronization Strobe Input
26 CLK-A L × f

OSCIN

Clock Output

27 CLK-B M/N × f

OSCIN

Clock Output
28 Rx SYNC Receive Data Synchronization Strobe Output
29–34 Rx[5:0] Receive Data Output
35 DRVDD Digital I/O 3.3 V Power Supply
36 DRVSS Digital I/O Ground
37 RESET Reset Input
40 REFB ADC Reference Decoupling Node
41 REFT ADC Reference Decoupling Node
44 Rx+ Receive Path + Input
45 Rx– Receive Path – Input
48 XTAL Crystal Oscillator Inverter Output

PIN FUNCTION DESCRIPTIONS

REV. 0

AD9875

–7–

DEFINITIONS OF SPECIFICATIONS
CLOCK JITTER

The clock jitter is a measure of the intrinsic jitter of the PLL
generated clocks. It is a measure of the jitter from one rising
and of the clock with respect to another edge of the clock nine
cycles later.

DIFFERENTIAL NONLINEARITY ERROR
(DNL, NO MISSING CODES)

An ideal converter exhibits code transitions that are exactly 1 LSB
apart. DNL is the deviation from this ideal value. Guaranteed
no missing codes to 10-bit resolution indicates that all 1024
codes respectively, must be present over all operating ranges.

INTEGRAL NONLINEARITY ERROR (INL)

Linearity error refers to the deviation of each individual code
from a line drawn from “negative full scale” through “positive
full scale.” The point used as “negative full scale” occurs 1/2 LSB
before the first code transition. “positive full scale” is defined as
a level 1 1/2 LSB beyond the last code transition. The deviation
is measured from the middle of each particular code to the true
straight line.

PHASE NOISE

Single-sideband phase noise power density is specified relative
to the carrier (dBc/Hz) at a given frequency offset (1 kHz) from
the carrier. Phase noise can be measured directly on a generated
single tone with a spectrum analyzer that supports noise marker
measurements. It detects the relative power between the carrier
and the offset (1 kHz) sideband noise and takes the resolution
bandwidth (rbw) into account by subtracting 10 log(rbw). It
also adds a correction factor that compensates for the imple­mentation of the resolution bandwidth, log display and detector
characteristic.

OUTPUT COMPLIANCE RANGE

The range of allowable voltage at the output of a current-output
DAC. Operation beyond the maximum compliance limits may
cause either output stage saturation, resulting in nonlinear per­formance or breakdown.

SPURIOUS–FREE DYNAMIC RANGE (SFDR)

The difference, in dB, between the rms amplitude of the DACs
output signal (or ADC’s input signal) and the peak spurious
signal over the specified bandwidth (Nyquist bandwidth unless
otherwise noted).

PIPELINE DELAY (LATENCY)

The number of clock cycles between conversion initiation and
the associated output data being made available.

OFFSET ERROR

First transition should occur for an analog value 1/2 LSB above
negative full scale. Offset error is defined as the deviation of the
actual transition from that point.

GAIN ERROR

The first code transition should occur at an analog value 1/2 LSB
above negative full scale. The last transition should occur for an
analog value 1 1/2 LSB below the nominal full scale. Gain error
is the deviation of the actual difference between first and last
code transitions and the ideal difference between first and last
code transitions.

INPUT REFERRED NOISE

The RMS output noise is measured using histogram techniques.
The ADC output codes’ standard deviation is calculated in LSB,
and converted to an equivalent voltage. This results in a noise
figure that can be directly referred to the Rx input of the AD9875.

SIGNAL-TO-NOISE AND DISTORTION RATIO (SINAD)

SINAD is the ratio of the RMS value of the measured input
signal to the RMS sum of all other spectral components below
the Nyquist frequency, including harmonics but excluding dc.
The value for SINAD is expressed in decibels.

EFFECTIVE NUMBER OF BITS (ENOB)

For a sine wave, SINAD can be expressed in terms of the num­ber of bits. Using the following formula,

N = (SINAD – 1.76) dB/6.02

it is possible to get a measure of performance expressed as N,
the effective number of bits.

SIGNAL-TO-NOISE RATIO (SNR)

SNR is the ratio of the rms value of the measured input signal to
the rms sum of all other spectral components below the Nyquist
frequency, excluding harmonics and dc. The value for SNR is
expressed in decibels.

TOTAL HARMONIC DISTORTION (THD)

THD is the ratio of the rms sum of the first six harmonic com­ponents to the rms value of the measured input signal and is
expressed as a percentage or in decibels.

POWER SUPPLY REJECTION

Power Supply Rejection specifies the converters maximum
full-scale change when the supplies are varied from nominal to
minimum and maximum specified voltages.

REV. 0

–Typical Tx Digital Filter Performance Characteristics

–8–

NORMALIZED – f

s

10

–60

–100

0

–50

–70
–80

–10

–30

–20

–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

INTERPOLATION

FILTER

INCLUDING SIN(X)/X

TPC 1. 4 Low-Pass Interpolation Filter

NORMALIZED – f

S

10

–60

–100

0

–50

–70
–80

–10

–30

–20

–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

INTERPOLATION

FILTER

INCLUDING SIN(X)/X

TPC 2. 2 Low-Pass Interpolation Filter

NORMALIZED – f

S

10

–60

–100

0

–50

–70
–80

–10

–30

–20

–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

INTERPOLATION

FILTER

INCLUDING SIN(X)/X

TPC 3. 4 Bandpass Interpolation Filter, fS /2 Modulation,
Adjacent Image Preserved

NORMALIZED – f

S

–60

–100

–50

–70
–80

–30
–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

10

0

–10
–20

INTERPOLATION

FILTER

INCLUDING SIN(X)/X

TPC 4. 2 Bandpass Interpolation Filter, fS /2 Modulation,
Adjacent Image Preserved

NORMALIZED – fS

10

–60

–100

0

–50

–70
–80

–10

–30

–20

–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

INTERPOLATION

FILTER

INCLUDING SIN(X)/X

TPC 5. 4 Bandpass Interpolation Filter, fS /4 Modulation,
Lower Image Preserved

NORMALIZED – fS

10

–60

–100

0

–50

–70
–80

–10

–30

–20

–40

–90

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

MAGNITUDE – dB

INCLUDING SIN(X)/X

INTERPOLATION

FILTER

TPC 6. 4 Bandpass Interpolation Filter, fS /4 Modulation,
Upper Image Preserved

AD9875
