ANALOG DEVICES AD5735 Service Manual

Quad-Channel, 12-Bit, Serial Input, 4 mA to 20 mA

and Voltage Output DAC with Dynamic Power Control

Data Sheet

FEATURES

12-bit resolution and monotonicity Dynamic power control for thermal management Current and voltage output pins connectable to a single

terminal

Current output ranges: 0 mA to 20 mA, 4 mA to 20 mA,

and 0 mA to 24 mA ±0.1% total unadjusted error (TUE) maximum

Voltage output ranges (with 20% overrange): 0 V to 5 V,

0 V to 10 V, ±5 V, and ±10 V

±0.09% total unadjusted error (TUE) maximum User-programmable offset and gain On-chip diagnostics On-chip reference: ±10 ppm/°C maximum

−40°C to +105°C temperature range

APPLICATIONS

Process control Actuator control PLCs

GENERAL DESCRIPTION

The AD5735 is a quad-channel voltage and current output DAC that operates with a power supply range from −26.4 V to +33 V.

FUNCTIONAL BLOCK DIAGRAM

–15V AGND

AV +15V

AD5735

On-chip dynamic power control minimizes package power dissipation in current mode. This reduced power dissipation is achieved by regulating the voltage on the output driver from

7.4 V to 29.5 V using a dc-to-dc boost converter optimized for minimum on-chip power dissipation.

The AD5735 uses a versatile 3-wire serial interface that operates at clock rates of up to 30 MHz and is compatible with standard SPI, QSPI™, MICROWIRE®, DSP, and microcontroller interface standards. The serial interface also features optional CRC-8 packet error checking, as well as a watchdog timer that monitors activity on the interface.

PRODUCT HIGHLIGHTS

1. Dynamic power control for thermal management.

2. 12-bit performance.

3. Quad channel.

COMPANION PRODUCTS

Product Family: AD5755, AD5755-1, AD5757, AD5737 External References: ADR445, ADR02 Digital Isolators: ADuM1410, ADuM1411 Power: ADP2302, ADP2303

Additional companion products on the AD5735 product page

5.0V

BOOST_x

DGND

LDAC

SCLK

SDIN

SYNC

SDO

CLEAR

FAU LT

ALERT

AD1

AD0

REFOUT

REFIN

NOTES

1. x = A, B, C, OR D.

Rev. A

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Anal og Devices for its use, nor for any infringements of patents or ot her rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners.

DIGITAL

INTERFACE

REFERENCE

AD5735

GAIN REG A

OFFSET REG A

DAC CHANNEL A

DAC CHANNEL B

DAC CHANNEL C

DAC CHANNEL D

Figure 1.

DC-TO- DC

CONVERTER

DAC A

7.4V TO 29. 5V

CURRENT AND

VO LTAGE

OUTPUT RANGE

SCALING

OUT_x

SET_x

OUT_x

–V

SENSE_x

09961-100

AD5735 Data Sheet

Features.............................................................................................. 1

Applications....................................................................................... 1

General Description ......................................................................... 1

Product Highlights ........................................................................... 1

Companion Products....................................................................... 1

Functional Block Diagram .............................................................. 1

Revision History ............................................................................... 2

Detailed Functional Block Diagram .............................................. 3

Specifications..................................................................................... 4

AC Performance Characteristics ................................................ 7

Timing Characteristics ................................................................ 8

Absolute Maximum Ratings.......................................................... 11

Thermal Resistance .................................................................... 11

ESD Caution................................................................................ 11

Pin Configuration and Function Descriptions........................... 12

Typical Performance Characteristics ........................................... 15

Voltage Outputs .......................................................................... 15

Current Outputs ......................................................................... 19

DC-to-DC Converter................................................................. 23

Reference ..................................................................................... 24

General......................................................................................... 25

Terminology .................................................................................... 26

Theory of Operation ...................................................................... 28

DAC Architecture....................................................................... 28

Power-On State of the AD5735 ................................................29

Serial Interface ............................................................................ 29

Transfer Function .......................................................................29

Registers........................................................................................... 30

Enabling the Output................................................................... 31

Reprogramming the Output Range ......................................... 31

Data Registers ............................................................................. 32

Control Registers........................................................................ 34

Readback Operation .................................................................. 37

Device Features............................................................................... 39

Fault Output ................................................................................ 39

Voltage Output Short-Circuit Protection................................ 39

Digital Offset and Gain Control............................................... 39

Status Readback During a Write .............................................. 39

Asynchronous Clear................................................................... 40

Packet Error Checking............................................................... 40

Watchdog Timer......................................................................... 40

Alert Output................................................................................ 40

Internal Reference...................................................................... 40

External Current Setting Resistor ............................................ 40

Digital Slew Rate Control.......................................................... 41

Dynamic Power Control............................................................ 41

DC-to-DC Converters............................................................... 42

AICC Supply Requirements—Static .......................................... 43

AICC Supply Requirements—Slewing ...................................... 43

Applications Information.............................................................. 45

Voltage and Current Output Pins on the Same Terminal..... 45

Current Output Mode with Internal R

Precision Voltage Reference Selection..................................... 45

Driving Inductive Loads............................................................ 46

Transient Voltage Protection .................................................... 46

Microprocessor Interfacing....................................................... 46

Layout Guidelines....................................................................... 46

Galvanically Isolated Interface ................................................. 47

Outline Dimensions....................................................................... 48

Ordering Guide .......................................................................... 48

................................ 45

SET

REVISION HISTORY

11/11—Rev. 0 to Rev. A

Added Comments to OUTPUT CHARACTERISTICS and ACCURACY, CURRENT OUTPUT Parameters in

Table 1 ................................................................................................ 4

Changes to Power-On State of the AD5735 Section.................. 29

Changes to Readback Operation Section .................................... 37

7/11—Revision 0: Initial Version
