Analog Devices AD5300BRT, AD5300BRM Datasheet
REV. B
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.
a
AD5300*
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 781/329-4700 World Wide Web Site: http://www.analog.com
Fax: 781/326-8703 © Analog Devices, Inc., 2000
2.7 V to 5.5 V, 140 A, Rail-to-Rail Output
8-Bit DAC in an SOT-23
FUNCTIONAL BLOCK DIAGRAM
POWER-ON
RESET
DAC
REGISTER
INPUT
CONTROL
LOGIC
AD5300
V
DD
GND
V
OUT
SYNC
SCLK
DIN
8-BIT
DAC
REF (+) REF (–)
OUTPUT
BUFFER
POWER-DOWN
CONTROL LOGIC
RESISTOR
NETWORK
FEATURES
Single 8-Bit DAC
6-Lead SOT-23 and 8-Lead SOIC Packages
Micropower Operation: 140 A @ 5 V
Power-Down to 200 nA @ 5 V, 50 nA @ 3 V
2.7 V to 5.5 V Power Supply
Guaranteed Monotonic by Design
Reference Derived from Power Supply
Power-On-Reset to Zero Volts
Three Power-Down Functions
Low Power Serial Interface with Schmitt-Triggered
Inputs
On-Chip Output Buffer Amplifier, Rail-to-Rail
Operation
SYNC Interrupt Facility
APPLICATIONS
Portable Battery Powered Instruments
Digital Gain and Offset Adjustment
Programmable Voltage and Current Sources
Programmable Attenuators
GENERAL DESCRIPTION
The AD5300 is a single, 8-bit buffered voltage out DAC that
operates from a single 2.7 V to 5.5 V supply consuming 115 µA
at 3 V. Its on-chip precision output amplifier allows rail-to-rail
output swing to be achieved. The AD5300 utilizes a versatile
three-wire serial interface that operates at clock rates up to 30 MHz
and is compatible with standard SPI™, QSPI™, MICROWIRE™
and DSP interface standards.
The reference for AD5300 is derived from the power supply
inputs and thus gives the widest dynamic output range. The part
incorporates a power-on-reset circuit that ensures that the DAC
output powers up to zero volts and remains there until a valid
write takes place to the device. The part contains a power-down
feature that reduces the current consumption of the device to
200 nA at 5 V and provides software selectable output loads
while in power-down mode. The part is put into power-down
mode over the serial interface.
The low power consumption of this part in normal operation
makes it ideally suited to portable battery operated equipment.
The power consumption is 0.7 mW at 5 V reducing to 1 µW in
power-down mode.
The AD5300 is one of a family of pin-compatible DACs. The
AD5310 is the 10-bit version and the AD5320 is the 12-bit
version. The AD5300/AD5310/AD5320 are available in 6-lead
SOT-23 packages and 8-lead µSOIC packages.
PRODUCT HIGHLIGHTS
1. Available in 6-lead SOT-23 and 8-lead µSOIC packages.
2. Low power, single supply operation. This part operates from
a single 2.7 V to 5.5 V supply and typically consumes 0.35 mW
at 3 V and 0.7 mW at 5 V, making it ideal for battery powered applications.
3. The on-chip output buffer amplifier allows the output of the
DAC to swing rail-to-rail with a slew rate of 1 V/µs.
4. Reference derived from the power supply.
5. High speed serial interface with clock speeds up to 30 MHz.
Designed for very low power consumption. The interface
only powers up during a write cycle.
6. Power-down capability. When powered down the DAC
typically consumes 50 nA at 3 V and 200 nA at 5 V.
SPI and QSPI are trademarks of Motorola, Inc.
MICROWIRE is a trademark of National Semiconductor Corporation.
*Patent pending; protected by U.S. Patent No. 5684481.
–2–
REV. B
AD5300–SPECIFICATIONS
(VDD = 2.7 V to 5.5 V; RL = 2 k⍀ to GND; CL = 500 pF to GND; all specifications
T
MIN
to T
MAX
unless otherwise noted.)
B Version
1
Parameter Min Typ Max Unit Conditions/Comments
STATIC PERFORMANCE
2
Resolution 8 Bits
Relative Accuracy ±1 LSB See Figure 2.
Differential Nonlinearity ±0.25 LSB Guaranteed Monotonic by Design. See Figure 3.
Zero Code Error +0.5 +3.5 LSB All Zeros Loaded to DAC Register. See Figure 6.
Full-Scale Error –0.5 –3.5 LSB All Ones Loaded to DAC Register. See Figure 6.
Gain Error ±1.25 % of FSR
Zero Code Error Drift –20 µV/°C
Gain Temperature Coefficient –5 ppm of FSR/°C
OUTPUT CHARACTERISTICS
3
Output Voltage Range 0 V
DD
V
Output Voltage Settling Time 4 6 µs 1/4 Scale to 3/4 Scale Change (40 Hex to C0 Hex).
R
L
= 2 kΩ; 0 pF < CL < 500 pF. See Figure 16.
Slew Rate 1 V/µs
Capacitive Load Stability 470 pF RL =
∞
1000 pF RL = 2 kΩ
Digital-to-Analog Glitch Impulse 20 nV-s 1 LSB Change Around Major Carry. See Figure 19.
Digital Feedthrough 0.5 nV-s
DC Output Impedance 1 Ω
Short Circuit Current 50 mA V
DD
= 5 V
20 mA V
DD
= 3 V
Power-Up Time 2.5 µs Coming Out of Power-Down Mode. V
DD
= 5 V
5 µs Coming Out of Power-Down Mode. VDD = 3 V
LOGIC INPUTS
3
Input Current ±1 µA
V
INL
, Input Low Voltage 0.8 V VDD = 5 V
V
INL
, Input Low Voltage 0.6 V VDD = 3 V
V
INH
, Input High Voltage 2.4 V VDD = 5 V
V
INH
, Input High Voltage 2.1 V VDD = 3 V
Pin Capacitance 3 pF
POWER REQUIREMENTS
V
DD
2.7 5.5 V
I
DD
(Normal Mode) DAC Active and Excluding Load Current
V
DD
= 4.5 V to 5.5 V 140 250 µAV
IH
= VDD and VIL = GND
V
DD
= 2.7 V to 3.6 V 115 200 µAV
IH
= VDD and VIL = GND
I
DD
(All Power-Down Modes)
V
DD
= 4.5 V to 5.5 V 0.2 1 µAV
IH
= VDD and VIL = GND
VDD = 2.7 V to 3.6 V 0.05 1 µAV
IH
= VDD and VIL = GND
POWER EFFICIENCY
I
OUT/IDD
93 % I
LOAD
= 2 mA. VDD = 5 V
NOTES
1
Temperature ranges are as follows: B Version: –40° C to +105°C.
2
Linearity calculated using a reduced code range of 4 to 251. Output unloaded.
3
Guaranteed by design and characterization, not production tested.
Specifications subject to change without notice.
AD5300
–3–REV. B
TIMING CHARACTERISTICS
1, 2
Limit at T
MIN
, T
MAX
Parameter VDD = 2.7 V to 3.6 V VDD = 3.6 V to 5.5 V Unit Conditions/Comments
t
1
3
50 33 ns min SCLK Cycle Time
t
2
13 13 ns min SCLK High Time
t
3
22.5 13 ns min SCLK Low Time
t
4
13 13 ns min SYNC to SCLK Falling Edge Setup Time
t
5
5 5 ns min Data Setup Time
t
6
4.5 4.5 ns min Data Hold Time
t
7
0 0 ns min SCLK Falling Edge to SYNC Rising Edge
t
8
50 33 ns min Minimum SYNC High Time
NOTES
1
All input signals are specified with tr = tf = 5 ns (10% to 90% of VDD) and timed from a voltage level of (VIL + VIH)/2.
2
See Figure 1.
3
Maximum SCLK frequency is 30 MHz at VDD = 3.6 V to 5.5 V and 20 MHz at VDD = 2.7 V to 3.6 V.
Specifications subject to change without notice.
SCLK
SYNC
DIN
t
8
DB15
DB0
t
4
t
3
t
2
t
7
t
5
t
6
t
1
Figure 1. Serial Write Operation
(VDD = 2.7 V to 5.5 V; all specifications T
MIN
to T
MAX
unless otherwise noted.)
ABSOLUTE MAXIMUM RATINGS*
(TA = 25°C unless otherwise noted)
VDD to GND . . . . . . . . . . . . . . . . . . . . . . . . . . –0.3 V to +7 V
Digital Input Voltage to GND . . . . . . . –0.3 V to V
DD
+ 0.3 V
V
OUT
to GND . . . . . . . . . . . . . . . . . . . –0.3 V to VDD + 0.3 V
Operating Temperature Range
Industrial (B Version) . . . . . . . . . . . . . . . –40°C to +105°C
Storage Temperature Range . . . . . . . . . . . . –65°C to +150°C
Junction Temperature (T
J
Max) . . . . . . . . . . . . . . . . . . 150°C
SOT-23 Package
Power Dissipation . . . . . . . . . . . . . . . . . . . (T
J
Max–TA)/θ
JA
θJA Thermal Impedance . . . . . . . . . . . . . . . . . . . . 240°C/W
Lead Temperature, Soldering
Vapor Phase (60 sec) . . . . . . . . . . . . . . . . . . . . . . . 215°C
Infrared (15 sec) . . . . . . . . . . . . . . . . . . . . . . . . . . 220°C
µSOIC Package
Power Dissipation . . . . . . . . . . . . . . . . . . . (T
J
Max–TA)/θ
JA
θJA Thermal Impedance . . . . . . . . . . . . . . . . . . . . 206°C/W
θ
JC
Thermal Impedance . . . . . . . . . . . . . . . . . . . . . 44°C/W
Lead Temperature, Soldering
Vapor Phase (60 sec) . . . . . . . . . . . . . . . . . . . . . . . 215°C
Infrared (15 sec) . . . . . . . . . . . . . . . . . . . . . . . . . . 220°C
*Stresses above those listed under Absolute Maximum Ratings may cause perma-
nent damage to the device. This is a stress rating only; functional operation of the
device at these or any other conditions above those listed in the operational sections
of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
ORDERING GUIDE
Temperature Branding Package
Model Range Information Option*
AD5300BRT –40°C to +105°C D2B RT-6
AD5300BRM –40°C to +105°C D2B RM-8
*RT = SOT-23; RM = µSOIC.
CAUTION
ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the AD5300 features proprietary ESD protection circuitry, permanent damage may
occur on devices subjected to high-energy electrostatic discharges. Therefore, proper ESD
precautions are recommended to avoid performance degradation or loss of functionality.
WARNING!
ESD SENSITIVE DEVICE
AD5300
–4–
REV. B
PIN CONFIGURATIONS
TOP VIEW
(Not to Scale)
6
5
4
1
2
3
V
OUT
GND
V
DD
SYNC
SCLK
DIN
AD5300
TOP VIEW
(Not to Scale)
8
7
6
5
1
2
3
4
NC
AD5300
SYNC
V
OUT
GND
V
DD
SCLK
DIN
NC
NC = NO CONNECT
SOT-23 SOIC
PIN FUNCTION DESCRIPTIONS
SOT-23 Pin Numbers
Pin
No. Mnemonic Function
1V
OUT
Analog output voltage from DAC. The output amplifier has rail-to-rail operation.
2 GND Ground reference point for all circuitry on the part.
3V
DD
Power Supply Input. These parts can be operated from 2.5 V to 5.5 V and VDD should be decoupled
to GND.
4 DIN Serial Data Input. This device has a 16-bit shift register. Data is clocked into the register on the
falling edge of the serial clock input.
5 SCLK Serial Clock Input. Data is clocked into the input shift register on the falling edge of the serial clock
input. Data can be transferred at rates up to 30 MHz.
6 SYNC Level triggered control input (active low). This is the frame synchronization signal for the input
data. When SYNC goes low, it enables the input shift register and data is transferred in on the fall-
ing edges of the following clocks. The DAC is updated following the 16th clock cycle unless SYNC
is taken high before this edge in which case the rising edge of SYNC acts as an interrupt and the
write sequence is ignored by the DAC.
