UPC20+

Universal Power Controller

instruction manual

Control System Accessories

AMX Limited Warranty and Disclaimer

AMX Corporation warrants its products to be free of defects in material and workmanship under normal use for

three (3) years from the date of purchase from AMX Corporation, with the following exceptions:

• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay components that are warranted for a period of one (1) year.

• Disk drive mechanisms, pan/tilt heads, power supplies, MX Series products, and KC Series products are warranted for a period of one (1) year.

• Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.

• Software is warranted for a period of ninety (90) days.

• Batteries and incandescent lamps are not covered under the warranty.

This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer.

AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform.

This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not

liable for any claim made by a third party or by an AMX Dealer for a third party.

This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort

claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of

liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX

Corporation or an authorized representative of AMX Corporation has been advised of the possibility of any such

damages. This limitation of liability, however, will not apply to claims for personal injury.

Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or

exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of

the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may

also have other rights that vary from state to state. The owner is advised to consult applicable state laws for full

determination of rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX CORPORATION MAKES NO

OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX CORPORATION

EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY

IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS

LIMITED WARRANTY.

UPC20+ Wiring Requirements

In the United States, the UPC20+ must be wired by an authorized electrician in accordance with the National Electrical Code, ANSI/NFPA 70-1987, as well as all local codes.

In the European community, the UPC20+ unit must be wired by an authorized electrician in accordance with all applicable European codes.

A readily accessible disconnect device shall be incorporated into the fixed wiring.

An insulated earthing conductor that is identical in size, insulation material and thickness to be earthed and unearthed branch circuit supply conductors, except that it is green with or without one or more yellow stripes, is to be installed as part of the branch circuit which supplies the unit or system. The earthing conductor described is to be connected to earth at the service equipment, or supplied by a separately derived system, at the supply transformer or motor generator set.

Table of Contents

UPC20+ Wiring Requirements .................................................................................3

Product Information .................................................................................................1

Specifications .................................................................................................................. 3

Control Options Modes...................................................................................................... 5

Motor Control mode ................................................................................................................. 5

Power Control mode ................................................................................................................ 6

Remote Sensor Control mode.................................................................................................. 6

Channel codes (Remote Sensor mode)................................................................................... 7

Installation .................................................................................................................9

P1 Terminal Connections .................................................................................................. 9

P2 Terminal Connections .................................................................................................. 9

Control Mode................................................................................................................... 10

High Voltage Wiring Options ........................................................................................... 12

Single circuit 120/240 VAC .................................................................................................... 12

Dual circuit 120/240 VAC ....................................................................................................... 12

Dual circuit 277 VAC .............................................................................................................. 13

Wiring The UPC20+ to Either The IRX-DM+ Or IRX-SM+ .............................................. 13

Wireless IR Sensor Connection ...................................................................................... 13

Installing the UPC20+ ..................................................................................................... 14

UPC20+ Universal Power Controller

Table of Contents

UPC20+ Universal Power Controller

Product Information

The UPC20+ Universal Power Control is a dual 20 Amp AC power and motor controller designed

for conduit installation. The UPC20+ is housed in a compact metal wall-mount enclosure and is

configurable for a wide variety of power and motor control modes. Low voltage contact-closures,

open collector inputs or serial data from an AMX IR receiver enable control by simple wall panels,

remote systems, or hand-held transmitters. A test switch with an LED indicator for each relay is

provided for local control and status indication.

Using Motor Control mode, the UPC20+ output alternates between two relays, providing a brief

pause in-between relay contacts, to protect the motor. A timing adjustment potentiometer is user

adjustable for automatic release of the relays. (The range is 0 to 90 seconds). 1-, 2-, and 3- button

control modes are selectable.

In Power Control mode, the UPC20+ provides power control for two independent circuits with a

combined total load of 20 Amps. Single-button momentary/latching and 2-button latching modes

are selectable.

 Momentary Power Relay contacts are closed only as long as a closure from input to

common is maintained.

Product Information

 Latching Power Relay contacts are toggled (from open to closed and closed to open)

each time a closure from input to common is momentarily pulsed.

All functions and capabilities of the UPC20+ (including information on high voltage wiring, low

voltage wiring, and DIP switch settings) are described on a sticker installed inside the enclosure.

FIG. 1 shows the UPC20+ (inside view).

The UPC20+ will work the NXC-I/O10 input/output control card.

UPC20+ Universal Power Controller

Product Information

Powe r swi tch

(115/230 VAC)

DIP switch

controls mode

and function

GND

IMPORTANT

SWITCH MUST MATCH INPUT VOLTAGE PRIOR TO APPLYING POWER TO UNIT

RISK OF ELECTRI C SHOCK - MORE THAN ONE

DISCONNECT SWITCH MAY BE REQUIRED TO DE-ENERGIZE

CAUTION

THE EQUIPMENT BEFORE SERVICING

TO CIRCUIT BD

ELECTRONICS

USE COPPER ONLY

75°C INSULATION

PB1 PB2

High voltage terminal and wiring arrangement label

High voltage wiring (120/240, 277 VAC)

Spade terminal block P1

Power and Motor control relays

Test switches with status LEDs

Motor Time Delay Poten tiomete r

Jumper JP1

Low voltage

and IR remote

control

connections

PART # 91-0672-01, REV F

CLASS 2 CIRCUIT ONLY

GND

+12V

DATA

RECEIVER

INPUT

SEE INSIDE COVER FOR DETAILED WIRING

AND DIP SWITCH INFORMATION

NOTE: NO HIGH VOLTAGE THIS CONNECTION

IN 1

IN 2

GND

CONTROL

INPUTS

JP1

REMOTE

CONTACT

IN 4

IN 3

+12

UPC20+

LISTED IND.CONT.EQ. 68WF

Low voltage terminal and wiring arrangement label

Richardson, Texas

800-222-0193 469-624-8000

FIG. 1 UPC20+

The UPC+ cover contains information on high voltage wiring, low voltage wiring, and DIP switch settings.

UPC20+ Universal Power Controller

Product Information

Specifications

UPC20+ Specifications

Power Self-powered when used with 110/220 VAC

Power input (for control board) 120/240V

-or-

12 VDC, 0.2A max

Power output per relay • 20A @ 120/240V

• 6A @ 277V

• 1 HP @ 120V

• 2 HP @ 240V

Total Current through both relays CAN NOT exceed 20 amp.

Maximum operating ambient

55°C

temperature

Approvals UL / C-UL / CE

Includes • 1-, 2-, and 3-button logic modes

• Local test switches with status LEDs

• 120, 240, and 277 VAC control capability

Inputs • 4 closure inputs, operation defined by mode.

• One IR remote sensor input.

• Motor Control mode alternates between the timed operation of the two power relays.

• Power Control mode allows independent control of both power relays.

Control Ports Two 2400 W power relays. Total combined current through both relays is 20

Amps.

Input Power Switch (S1) • Set this switch according to the high voltage wiring that will be connected

to terminals 5 and 6 on P1. Refer to the P1 Terminal Connections on page 9.

• Set switch S1 to the line input voltage value used before applying power to the UPC20+.

High Voltage Terminal Block (P1) High voltage input and output wiring for motor or power control.

Low voltage and Control Terminal Block (P2)

Contact closure, open-collector or CMOS logic level remote control wiring. Inputs 5 - 8 are referenced to the common connection at pin 4.

Jumper JP1 Sets control mode of the unit to contact closure or remote sensor serial

data.

Test Switches (PB1 and PB2) Provides local operation of relays K1 and K2 for testing power circuits or

motors connected to the relay terminals. An LED indicates relay power applied.

Motor Time Delay Potentiometer (R8)

Only used in motor control modes. User adjusted for setting relay release time between 0 and 90 seconds.

DIP Switch (S2) Provides selection of control mode options. See the Motor Control Mode

DIP Switch S2 Positions table on page 5 and the Control Input Wiring to Connector P2 Terminals table on page 5 for control mode settings.

Enclosure Metal with black matte finish, knockouts for conduit.

Dimension (HWD) • 8.5" (10.5" including flange) x 4.5" x 2.2"

• (220 mm (270 including flange) x 110 mm x 60 mm)

Weight 3.0 lbs. (1.4 kg) with flange

Options 12 VDC power supply (for 277 VAC applications)

, 50-60 Hz, 0.05/0.025A

, 50-60 Hz (RESISTIVE LOAD)

, 50-60 Hz (FLUORESCENT BALLAST)

, 50-60 Hz (INDUCTIVE LOAD)

UPC20+ Universal Power Controller

Product Information

ATTENTION INSTALLER

FACTORY SET TO INOPERATIVE MODE

(UNIT WILL NOT WORK UNTIL DIP SWITCHES ARE SET)

SEE CHART ON LID TO SET

DIP SWITCHES FOR ACTIVE MODE

FIG. 2 UPC20+ inoperative mode warning label

UPC20+ Universal Power Controller

Product Information

Control Options Modes

If UPC20+ is powered up when changes are made to Dip Switch settings, then power must be cycled before changes can take effect.

Motor Control mode

The table list options and connections for motor control. DIP switch settings provide 1, 2 or 3

button remote control contact arrangements. This mode is typically used for screen and drape motor

control.

In motor control mode, only one power relay (motor) can be energized at a time. When switching

from one direction to another, the first motor is automatically turned off and a half-second delay is

inserted before the other motor will turn on.

Once a motor is turned on, it will automatically be turned off after the amount of time determined

by the motor time delay potentiometer, R8. Delay time can range from 0 to 90 seconds. It is

typically set to allow direction limit switches to operate, or to reach the desired position.

Motor Control Mode DIP Switch S2 Positions

1 2 3 4 Control Mode

On On Off On Single button

Off Off Off On 2-button

Off On Off On Momentary On/Off

 Single Button Mode operates with one pushbutton in a sequence: Up, Stop, Down, Stop

and so on for each successive button press.

 Two/Three Button Mode operates with two pushbuttons, one for Up and one for Down.

 Momentary On/Off operates only when the button is pressed.

Control Input Wiring to Connector P2 Terminals

4 5 6 7 8 Control Mode

Common Up Down Stop N/A Two, three button

Common Up/Stop/Down N/A N/A N/A Single button

UPC20+ Universal Power Controller

Product Information

Contact cl

Power Control mode

The tables below specify the DIP switch settings for momentary, latching, 2-button On/Off, and

(momentary or latching) operation of K1 and K2.

Power Control Mode DIP Switch Positions S2

1 2 3 4 Control Mode

On On On On Momentary On/Off

Off On On On Latching On/Off

On Off Off On Two-Button On, Off

On Off On On #1 Momentary, #2 Latching

Off Off On On #1 Latching, #2 Momentary

Control Input Wiring to P2 Terminals

4 5 6 7 8 Control Mode

Common #1 On/Off #2 On/Off N/A N/A Momentary, Latch On/Off

Common #1 On #2 On #1 Off #2 Off Two-Button On/Off

Remote Sensor Control mode

The UPC20+ can also be controlled via the serial output from an AMX IR sensor. Remote sensor

mode is selected by setting jumper JP1 to the "Remote" position (jumper on the left 2 pins), as

shown in FIG. 3. (The jumper must be in position when power is applied to the UPC20+).

mode

Remote sensor mode

FIG. 3 JP1 mode settings

JP1

If motors of any kind are used, do not set to a Power Control mode. When a Power Control mode is selected, both relays can be on at the same time. Motors can be severely damaged if this happens.

osure

When controlled by a remote sensor, the UPC20+ is in 2, 3-button timer motor control mode. When

the timing potentiometer R8 adjusted to zero ohms (no time delay), the remote sensor provides

momentary control.

A 3-bit code (radio code) set on DIP switch S2 associates an AMX handheld remote control with a

UPC20+. This allows up to 8 UPC20+ and IR sensors to be used in the same room without

interfering with one another. It is possible to control 2 separate UPC20+'s with one handheld

remote control. The 4th switch of DIP switch S2 on the PCB selects between the two UPC20+'s.

The table below lists the results of the 16 possible DIP switch selections in remote sensor mode.

UPC20+ Universal Power Controller

The following table lists the DIP switch settings for Remote Sensor Mode.

DIP Switch Settings for Remote Sensor Mode

Sw. 1 Sw. 2 Sw. 3 Sw. 4 Radio Code UPC20+

Off Off Off Off 0 First

On Off Off Off 1 First

Off On Off Off 2 First

On On Off Off 3 First

Off Off On Off 4 First

On Off On Off 5 First

Off On On Off 6 First

On On On Off 7 First

Off Off Off On 0 Second

On Off Off On 1 Second

Off On Off On 2 Second

On On Off On 3 Second

Off Off On On 4 Second

On Off On On 5 Second

Off On On On 6 Second

On On On On 7 Second

Product Information

Channel codes (Remote Sensor mode)

The table below lists the 5 AMX channel codes and their function in the UPC20+ when in Remote

Sensor mode.

Channel Codes and Functions

Channel Function

6 Stop (K1 and K2)

0 #1 up (K1)

1 #1 down (K2)

7 #2 up (K1)

2 #2 down (K2)

UPC20+ Universal Power Controller

Product Information

UPC20+ Universal Power Controller

Installation

P1 Terminal Connections

Low voltage power (see the table below) for internal circuitry is provided from an on-board

transformer, powered by an external 120 or 240 VAC source. An onboard switch is used to select

input voltage. When using the UPC20+ for 277 VAC control, the on-board internal circuitry is

P1 Terminal Connections

Terminal Input/Output Function

1 Output Load 1 out

2 Input Line 1 in

3 Output Load 2 out

4 Input Line 2 in

5 Input Neutral to transformer on PCB which supplies low voltage

6 Input Line to transformer on PCB which supplies low voltage

Installation

K1 and K2 are the power and motor control relay connections to P1 terminals 1 and 2, 3 and 4,

respectively. Each relay is capable of switching the following loads:

 Resistive Load 20 Amps at 120/240 VAC

 Fluorescent Ballast 6 Amps at 277 VAC

 Inductive Load 1 HP

The maximum total combined current through both relays is 20 Amps. There are two 12-gauge

jumpers that are wired to supply board power at 120/240 VAC, and to connect the common

terminals of the relays. The jumpers are removed as needed according to the wiring options

selected.

P2 Terminal Connections

The table below defines the inputs and outputs for Terminal P2.

P2 Low Voltage Terminal Inputs/Outputs

Terminal Input/Output

1 +12 VDC out

2 Serial data in (IR sensor)

3 Ground

4 Ground (common)

5 Input 1

6 Input 2

7 Input 3

8 Input 4

9 +12 VDC in

UPC20+ Universal Power Controller

Installation

Control Mode

The table below defines the control mode functions for Inputs 1 and 2. The UPC20+ Control Mode

Functions for Inputs 3 and 4 table on page 11 defines the control mode functions for Inputs 3 and 4.

UPC20+ Control Mode Functions for Inputs 1 and 2

Control Mode

Motor, Single Button

Motor, 2/3 Button

Motor, Momentary

Powe r, Momentary

Powe r, Latching

S2 Switch Setting

On, On, Off, On Minimum Push 1 = load 1 "on"

Off, Off, Off, On Minimum Push 1 = load 1 "on"

Off, On, Off, On Minimum Push 1 = load 1 "on"

On, On, On, On Minimum Push 1 = load 1 "on"

Off, On, On, On Minimum Push 1 = load 1 "on"

R8 Motor Time Delay Pot

Minimum Push 1 = load 1 "on"

Maximum Push 1 = load 1 "on"

Input 1 (P2, pin 5-to GND)

Release 1 = load 1 "off"

Push 1 again = load 2 "off"

Release 1 = load 1 "off after delay time out"

Push 1 again = load 2 "on"

Release 1 again = load 2 "off after time out"

Note: pushing again restarts cycle.

Release 1 = load 1 "off"

Release 1 = load 1 "off after time out"

Note: both loads cannot be On at the same time.

Release 1 = load 1 "off"

Note: No delay on release.

Release 1 = load 1 "off"

Release 1 = load 1 "still on" Push 1 again = load "off"

Release 1 again = load "still off"

Release 1 = load 1 "still on"

Push 1 again = load "off"

Release 1 again = load "still off"

Note: Both loads can be On at the same time (time delay does not affect).

Input 2 (P2, pin-6 to GND)

Not used

Push 2 = load 2 "on" Release 2 = load 2 "off"

Push 2 = load 2 "on" Release 2 = load 2 "off after time out"

Push 2 = load 2 "on" Release 2 = load 2 "off"

Push 2 = load 2 "on"

Release 2 = load 2 "still on"

Push 2 again = load "off"

Release 2 again = load "still off"

Push 2 = load 2 "on"

Release 2 = load 2 "still on"

Push 2 again = load "off"

Release 2 again = load "still off"

UPC20+ Universal Power Controller

UPC20+ Control Mode Functions for Inputs 1 and 2 (Cont.)

Control Mode

Powe r, 2 Button

Powe r, Momentary #1, Latching #2

S2 Switch Setting

On, Off, Off, On Minimum Push 1 = load 1 "on"

On, Off, On, On Minimum Push 1 = load 1 "on"

R8 Motor Time Delay Pot

Maximum Push 1 = load 1 "on"

Minimum Push 1 = load 1 "on"

Maximum Push 1 = load 1 "on"

Input 1 (P2, pin 5-to GND)

Release 1 = load 1 "still on"

Note: Both loads can be On at the same time.

Release 1 = load 1 "off"

Note: Delay time does not effect loads.

Release 1 = load 1 "still on"

Push 1 again = load 1 "off"

Release 1 again = load 1 "still off"

Release 1 = load 1 "still on"

Push 1 again = load 1 "off"

Release 1 again = load 1 "still off"

Note: Delay time does not affect loads.

Installation

Input 2 (P2, pin-6 to GND)

Push 2 = load 2 "on"

Release 2 = load 2 "still on"

Push 2 = load 2 "on"

Release 2 = load 2 "still on"

Push 2 = load 2 = "on"

Release 2 = load 2 "still on"

Push 2 again = load 2 "off"

Release 2 again = load 2 "still off"

Push 2 = load 2 = "on"

Release 2 = load 2 "still on"

Push 2 again = load 2 "off"

Release 2 again = load 2 "still off"

Push 2 = load 2 "on"

Release 2 = load 2 "off"

Push 2 = load 2 "on"

Release 2 = load 2 "off"

UPC20+ Control Mode Functions for Inputs 3 and 4

Control Mode

Motor, Single Button

Motor, 2/3 Button Off, Off, Off, On Minimum Not used Not used

Motor, Momentary Off, On, Off, On Minimum Not used Not used

Power, Momentary On, On, On, On Minimum Not used Not used

Power, Latching Off, On, On, On Minimum Not used Not used

UPC20+ Universal Power Controller

S2 Switch Setting

On, On, Off, On Minimum Not used Not used

R8 Motor Time Delay Pot

Minimum Not used Not used

Maximum Not used Not used

Input 1 (P2, pin 5-to GND)

Input 2 (P2, pin-6 to GND)

Installation

Load

UPC20+ Control Mode Functions for Inputs 3 and 4 (Cont.)

Control Mode

Power, Two Button On, Off, Off, On Minimum Push 3 = load 1 "off"

Power, Momentary #1, Latching #2

Power, Latching #1, Momentary #2

S2 Switch Setting

On, Off, On, On Minimum Not used Not used

R8 Motor Time Delay Pot

Maximum Push 3 = load 1 "off"

Maximum Not used Not used

Input 1 (P2, pin 5-to GND)

Release 3 = load 1 "still off"

Input 2 (P2, pin-6 to GND)

Push 4 = load 2 "off"

Release 4 = load 2 "off"

Push 4 = load 2 "off"

Release 4 = load 2 "off"

High Voltage Wiring Options

Single circuit 120/240 VAC

Single circuit connections (FIG. 4) are for most motor and screen control applications.

Neut

Board Powe r

FIG. 4 Single circuit 120/240 VAC power wiring

or Motor #2

432

Line

or Motor #1

Line #1, Line #2, and Line to transformer are common.

Terminal Block P1

Dual circuit 120/240 VAC

Dual circuit connections provide power from two 120/240 VAC supply systems. FIG. 5 shows a

dual circuit 120/240 VAC power wiring. Refer to FIG. 1 on page 2 for the location of the Terminal

Block P1 on the circuit board.

eut

Load#2Line

Load #1

Line #1 in and Line to transformer are common. Line #2 in is an independent circuit.

Board Powe r

Terminal Block P1

FIG. 5 Dual circuit 120/240 VAC power wiring

UPC20+ Universal Power Controller

Installation

Dual circuit 277 VAC

Dual circuit connections provide power from 277 VAC for fluorescent ballasts (FIG. 6). Circuit

board power is provided by a separate 120/240 VAC high voltage circuit, or 12 VDC connected to

terminals 1 and 6 on the low voltage terminal block. For dual circuit 120/240 VAC operation,

remove the short 12 AWG wire jumper.

For Dual 277 VAC Circuits Power Circuit Board Electronics From 12 VDC or

120/240 VAC

Te r m in a l Block P2

1 2 3 4 5 6 7 8 9

12 VDC External Power to Circuit Board Electronics

FIG. 6 Low voltage and 277 VAC high voltage wiring

120/240 VAC

Line

Remove Board Power

Neut

Line #2

Load #2

3 Remove Line

Line #1

Load #1

Line #1 in, Line #2 in, and Line to transformer are all independent

Terminal Block P1

If motors of any kind are used, do not set to a power control mode. When a power control mode is selected, both relays can be on at the same time. Motors can be severely damaged if this happens.

Wiring The UPC20+ to Either The IRX-DM+ Or IRX-SM+

Wire the UPC20+ to the sensor as shown in FIG. 7. .

123

PWR

FIG. 7 Wiring diagram for UPC20+ to IRX-DM+ or IRX-SM+

GNDIN

UPC20+

IRX-DM+ or IRX-SM+

connector

Top v i ew

PWR

2AUX OUT

3OUT

GND

Wireless IR Sensor Connection

The wireless IR sensor connections are located on P2, terminals 1 - 3. Terminal 1 is +12 VDC out,

terminal 2 is serial data in, and terminal 3 is GND. The +12 VDC is short circuit protected, and the

output supplies up to 25 mA for the remote sensor.

For dual circuit 277 VAC operation, remove both 12 AWG wire jumpers.

UPC20+ Universal Power Controller

Installation

Installing the UPC20+

To install the UPC20+ unit:

1. Mount the UPC20+ on a wall or solid surface in the location where it will be used; it can be

mounted either horizontally or vertically.

2. Remove the cover.

3. Prepare terminal block P1.

a. Set power switch S1.

b. Configure jumpers according to high voltage wiring requirements.

4. Install conduit. Provide conduit for high voltage, low voltage and control wiring requirements

using the 0.5 inch or 0.75 inch conduit connector knockouts.

5. Connect high voltage wiring to the terminal block P1.

6. Connect control wiring.

a. Set control mode DIP switch S2 and control jumper JP1. Refer to the Control Options

Modes section on page 5 for more detailed information.

b. Install wiring for contact closure or remote control mode.

7. Test low voltage and high voltage wiring. Conduct tests to confirm proper installation and

functions of desired control modes.

UPC20+ Universal Power Controller

AMX reserves the right to alter specifications without notice at any time.

ARGENTI NA • AUST RALIA • B ELGIUM • BRAZIL • CANADA • CHINA • E NGLAND • FRANCE • GERMAN Y • GREEC E • HONG K ONG • IN DIA • IND ONESIA • ITALY • JAPAN

LEBANON • MALAYSIA • MEXICO • NETHERLANDS • NEW ZEALAND • PHILIPPINES • PORTUGAL • RUSSIA • SINGAPORE • SPAIN • SWITZERLAND • THAILAND • TURKEY • USA

ATLANTA • BOSTON • CHICAGO • CL EVELAND • DALLAS • DENVER • INDIANAPOLIS • LOS ANGELES • MINNEAPOLIS • PHILADELPHIA • PHOENIX • PORTLAND • SPOKANE • TAMPA

3000 RESEARCH DRIVE, RICHARDSON, TX 75082 USA • 800.222.0193 • 469.624.8000 • 469-624-7153 fax • 800.932.6993 technical support • www.amx.com

041-004-2236 3/05

In Canada doing business as Panja Inc.

Last Revision: 03/09/05

AMX UPC20+ User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

UPC20+ Wiring Requirements

Product Information

Specifications

Control Options Modes

Motor Control mode

Power Control mode

Remote Sensor Control mode

Channel codes (Remote Sensor mode)

Installation

P1 Terminal Connections

P2 Terminal Connections

Control Mode

High Voltage Wiring Options

Single circuit 120/240 VAC

Dual circuit 120/240 VAC

Dual circuit 277 VAC

Wiring The UPC20+ to Either The IRX-DM+ Or IRX-SM+

Wireless IR Sensor Connection

Installing the UPC20+
