Operation/Reference Guide
UDM-0404
4x4 Multi-Format Distribution Hub
Universal Distribution Matrix
Last Updated: 7/15/2010
AMX Limited Warranty and Disclaimer
This Limited Warranty and Disclaimer extends only to products purchased directly from AMX or an AMX Authorized Partner which
include AMX Dealers, Distributors, VIP’s or other AMX authorized entity.
AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of
purchase, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay components are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.
• AMX lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long
as the AMX lighting products are under warranty. AMX also guarantees the control of dimmable loads that are properly connected to our lighting products. The dimming performance or quality there of is not guaranteed, impart due to the random combinations of dimmers, lamps and ballasts or transformers.
• AMX software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
• AMX AutoPatch Epica, Modula, Modula Series4, Modula CatPro Series and 8Y-3000 product models will be free of defects in
materials and manufacture at the time of sale and will remain in good working order for a period of three (3) years following the
date of the original sales invoice from AMX. The three-year warranty period will be extended to the life of the product (Limited
Lifetime Warranty) if the warranty card is filled out by the dealer and/or end user and returned to AMX so that AMX receives it
within thirty (30) days of the installation of equipment but no later than six (6) months from original AMX sales invoice date. The
life of the product extends until five (5) years after AMX ceases manufacturing the product model. The Limited Lifetime Warranty
applies to products in their original installation only. If a product is moved to a different installation, the Limited Lifetime Warranty
will no longer apply, and the product warranty will instead be the three (3) year Limited Warranty.
All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX
RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After
the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will
be refused. AMX is not responsible for products returned without a valid RMA number.
AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost
savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Authorized Partner for a third party.
This Limited Warranty does not apply to (a) any AMX product that has been modified, altered or repaired by an unauthorized agent or
improperly transported, stored, installed, used, or maintained; (b) damage caused by acts of nature, including flood, erosion, or earthquake; (c) damage caused by a sustained low or high voltage situation or by a low or high voltage disturbance, including brownouts,
sags, spikes, or power outages; or (d) damage caused by war, vandalism, theft, depletion, or obsolescence.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including
negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by
any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the
possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not
apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state.
The owner is advised to consult applicable state laws for full determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT
MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY. EXCEPT AS OTHERWISE LIMITED
BY APPLICABLE LAW, AMX RESERVES THE RIGHT TO MODIFY OR DISCONTINUE DESIGNS, SPECIFICATIONS, WARRANTIES, PRICES, AND POLICIES WITHOUT NOTICE.
Important Safety Markings
Markings Used In This Manual
The following symbols are used on the UDM hardware and throughout this Installation Guide to advise
you of important instructions. All maintenance must be carried out by an AMX trained and qualified
installer.
Voltage
This symbol (FIG. 1) warns the presence of a voltage of sufficient magnitude to cause a severe or fatal
electric shock. Follow the appropriate instructions carefully to avoid the risk of injury.
FIG. 1 Voltage symbol
There are NO user serviceable parts within the UDM Hub.
Important Safety Markings
Rating Label
The rating label, containing important safety information, is found on the underside of the UDM Hub.
Symbols used on this label are explained below;
(IEC 60417-5032)
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received
including interference that may cause undesirable operation.
The UDM Hub is suitable for Alternating current, 100 - 240V AC.
FCC (Federal Communications Commission) Standards;
TESTED TO COMPLY
WITH FCC STANDARDS
FOR HOME OR OFFICE USE
Conforms to particular European Directives.
FIG. 2 Rating Label
UDM-0404 4x4 Multi-Format Distribution Hub
a
Important Safety Markings
Important Instructions
This symbol, used within this manual, indicates an important instruction for the
correct and safe installation, operation or maintenance of your UDM Hub.
Failure to comply with such instruction may result in injury to person or damage to the
UDM hardware.
Compliance
FCC and IEC
Compliance with FCC and IEC standards are found within the rating label; see FIG. 2.
Date of Manufacture
For US customers, the date of manufacture is also found underneath the UDM Hub.
Model Number
Vendor ID
FIG. 3 Date Of Manufacture Sticker (on bottom panel)
UDM-0404/RX02 Date of Manufacture Sticker
Model Number Model number and designation, comprised of up to seven characters.
Vendor ID One- or two-character ID code.
Date Code Three-digit date code, comprised of week of year (1-52) and last digit of year.
Consecutive number Starting at “0001” and continuing to “9999”.
Date Code (WW/Y)
Consecutive Number (4 digits)
b
UDM-0404 4x4 Multi-Format Distribution Hub
Important Safety Markings
Environmental Conditions
The criteria on this page must be observed for the installation of the UDM-0404.
Temperature
DO NOT install or operate the UDM Hub in an area where the ambient temperature exceeds 35ºC (95ºF)
or falls below 5ºC (35ºF).
Ventilation
DO NOT obstruct the rear or side ventilation grilles during operation as this will restrict the airflow and
may cause the main board to overheat.
The UDM Hub is fitted with two cooling fans. These draw cool air through the right side ventilation
grille and expel warm air through the grilles on the left side ventilation grilles.
Humidity
DO NOT install or operate the UDM Hub in an area in which the ambient relative humidity exceeds
85% or an area that is prone to condensation.
Water / Liquids
DO NOT install or operate the UDM Hub near water or in a location which may be prone to water
seepage, dripping or splashing.
DO NOT place objects containing liquids on the appliance.
The hub is not waterproof.
External use
DO NOT operate the UDM Hub externally.
UDM-0404 4x4 Multi-Format Distribution Hub
c
Important Safety Markings
d
UDM-0404 4x4 Multi-Format Distribution Hub
Table of Contents
Table of Contents
Important Safety Markings ................................................................................. a
Markings Used In This Manual .................................................................................. a
Voltage............................................................................................................................ a
Rating Label.............................................................................................................. a
Important Instructions .............................................................................................. b
Compliance ............................................................................................................... b
FCC and IEC .................................................................................................................... b
Date of Manufacture ....................................................................................................... b
Environmental Conditions......................................................................................... c
Temperature .................................................................................................................... c
Ventilation........................................................................................................................ c
Humidity........................................................................................................................... c
Water / Liquids................................................................................................................. c
External use ..................................................................................................................... c
UDM-0404 Multi-Format Distribution Hub .........................................................1
Overview .................................................................................................................. 1
Features.................................................................................................................... 1
Compatibility ............................................................................................................ 1
Product Specifications ............................................................................................. 2
Installation ..........................................................................................................3
Overview .................................................................................................................. 3
Ventilation....................................................................................................................... 3
Wiring and Connections .....................................................................................5
UDM-0404 Front Panel Components ........................................................................ 5
IR Learning Sensor .................................................................................................... 5
OUTPUT Ports (RJ-45)............................................................................................... 5
UDM Port Pinouts ........................................................................................................... 5
UDM-0404 Rear Panel Components ......................................................................... 6
Network Port (RJ45) ................................................................................................. 6
Pinout Configuration ....................................................................................................... 6
Default IP Address .......................................................................................................... 7
Serial Port ................................................................................................................. 7
Serial Port - Default Communication Settings ................................................................. 7
DB9-to-RJ12 Adapter Cable Pinouts ............................................................................... 7
TX (IR Transmit) Ports ............................................................................................... 8
Connecting an IR Device to an IRTX Port ........................................................................ 8
UDM-0404 4x4 Multi-Format Distribution Hub
i
Table of Contents
A/V Source Input Connectors ................................................................................... 8
Audio & Video Formats/Resolutions/Distance .......................................................... 9
VIDEO IN Connectors (HD15)........................................................................................ 10
Connecting a VGA Video Input ..................................................................................... 10
Connecting a Composite Video Input............................................................................ 10
Connecting a Component Video Input .......................................................................... 10
Connecting an S-Video Input......................................................................................... 10
Cascade In/Out Ports .................................................................................................... 10
Device Connectivity (IR TX1/2 and TX3/4 Ports)..................................................... 11
Connecting UDM RX01/RX02 Receivers to the UDM-0404 .................................... 11
IEC Power Connector.............................................................................................. 11
Powering the UDM-0404 On ......................................................................................... 11
Powering the UDM-0404 Off ........................................................................................ 11
Wiring and Connections - UDM Receivers ........................................................13
Overview ................................................................................................................ 13
UDM-RX01 .............................................................................................................. 13
UDM Hub Compatibility ................................................................................................ 13
UDM-RX01 Product Specifications ......................................................................... 13
UDM-RX02 .............................................................................................................. 14
UDM-RX02 - UDM Hub Compatibility ........................................................................... 14
UDM-RX02 Product Specifications ......................................................................... 15
UDM Receivers - Configuration............................................................................... 16
UDM Receivers - Rear Panel Components .............................................................. 16
UDM Hub Port (RJ45).................................................................................................... 16
Serial Port...................................................................................................................... 16
IR Receiver (IR Rx) Port.................................................................................................. 16
IR Transmit (IR Tx) Port.................................................................................................. 16
Connecting an IR Device to the IR Tx Port .................................................................... 17
AUDIO Connectors ................................................................................................. 17
VIDEO Connectors .................................................................................................. 17
VGA Input at Display Device ......................................................................................... 17
Composite Input at Display Device ............................................................................... 17
SVideo Input at Display Device ..................................................................................... 17
Component Input at Display Device .............................................................................. 17
Audio & Video Formats/Resolutions/Distance ........................................................ 18
Video Compensation .............................................................................................. 18
Connecting an External IR Receiver Module ........................................................... 18
Connecting the UDM Receiver to the UDM Hub .................................................... 18
UDM HUB Port LEDs ..................................................................................................... 18
ii
UDM-0404 4x4 Multi-Format Distribution Hub
Table of Contents
Powering on the UDM-RX02................................................................................... 18
System Overview .................................................................................................... 19
Configuration ...................................................................................................21
WebConsole Overview ........................................................................................... 21
Connecting to the UDM-0404................................................................................. 21
Configuration - Status Page ..............................................................................23
Overview ................................................................................................................ 23
Port Configuration Options .................................................................................... 24
Renaming Output Ports................................................................................................. 25
Video Compensation .............................................................................................. 25
Basic Video Compensation ............................................................................................ 25
Advanced Video Compensation .................................................................................... 26
Compensating Video Via the UDM-RC10 Remote Control............................................ 27
Video Compensation (UDM-RX01/RX02) ...................................................................... 28
Dual Output Mode ........................................................................................................ 28
Selecting Inputs For Display ................................................................................... 28
Selecting Multiple Inputs For Display............................................................................ 29
Changing an Input ......................................................................................................... 30
User Control ........................................................................................................... 30
Issuing Commands To a Selected Port .......................................................................... 31
Issuing Commands To Multiple Ports ............................................................................ 32
Assigning a Command to an Endeleo UDM-RC02 Remote Control............................... 32
Passthrough Mode (Inputs A – D) ........................................................................... 34
Configuring a Device for Passthrough Mode ................................................................ 34
Configuring a Port for Passthrough Mode .................................................................... 35
Using Passthrough Mode .............................................................................................. 35
Exiting Passthrough Mode ............................................................................................ 35
Locking One or More Ports..................................................................................... 36
Configuration - Setup Page ..............................................................................37
Overview ................................................................................................................ 37
Device Information ................................................................................................. 37
Network Configuration ........................................................................................... 38
Date and Time Configuration.................................................................................. 38
Restoring Hub Configuration and Connections....................................................... 38
Restoring Configuration and Connections..................................................................... 38
Restoring Connections On Power Up............................................................................ 39
Resetting the UDM-0404 ........................................................................................ 39
UDM-0404 4x4 Multi-Format Distribution Hub
iii
Table of Contents
Configuration - Inputs Page ..............................................................................41
Overview ................................................................................................................ 41
Configuring Inputs A-D ........................................................................................... 41
Configuring Audio Types For Inputs ....................................................................... 42
Configuration - Devices Page ...........................................................................43
Overview ................................................................................................................ 43
Adding Centrally Located Devices .......................................................................... 44
Issuing Commands To a Centrally Located IR Device.............................................. 44
Custom Commands ....................................................................................................... 45
Issuing Commands to Centrally Located Devices.................................................... 45
Configuration - Schedule Page .........................................................................47
Overview ................................................................................................................ 47
Checking the Hub Time ................................................................................................. 48
Scheduling IR Device Control Events ...................................................................... 48
Scheduling Output Device Control Events.............................................................. 51
Scheduling Inputs ................................................................................................... 53
Preset Scheduling ................................................................................................... 55
Scheduling Events - Frequency Options ........................................................................ 56
Configuring the UDM-RC02 Remote Control for Scheduling .................................. 57
Configuration - Protocols Page .........................................................................59
Overview ................................................................................................................ 59
Creating a Serial Protocol ....................................................................................... 59
Updating the UDM Receiver With the Serial Protocol ............................................ 61
Creating and Learning an IR Protocol ..................................................................... 62
IR Learning with a Device’s Remote Control ................................................................. 62
Updating the UDM Receiver With the IR Protocol .................................................. 63
Testing Serial Control Commands........................................................................... 63
Examples of Serial Controls........................................................................................... 64
Deleting Protocols .................................................................................................. 65
Deleting All Protocols (Serial and IR) ...................................................................... 65
Advanced Administration .................................................................................67
Overview ................................................................................................................ 67
Upgrading Firmware and Web Pages On a UDM-0404 .......................................... 67
Firmware Update .......................................................................................................... 67
Web Interface Update ................................................................................................... 68
Upgrading Port Controllers .................................................................................... 68
Copying the Hub Configuration File ....................................................................... 69
Restoring the UDM-0404 Configuration File ................................................................. 69
iv
UDM-0404 4x4 Multi-Format Distribution Hub
Table of Contents
Loading the Hub Configuration File On the UDM-0404 ................................................ 70
Copying Protocols Between UDM Receivers .......................................................... 70
Retrieving IR Files From the UDM Ports........................................................................ 70
Backing up the Hub Configuration File ......................................................................... 71
Restoring the Hub Configuration File............................................................................ 71
Upgrading Input Controllers................................................................................... 72
Backend Commands ............................................................................................... 72
Changing the Login Password ....................................................................................... 72
Obtaining the UDM-0404’s IP Address Via the Command Line .................................... 72
Checking Port Details.................................................................................................... 72
Multi Format Inputs....................................................................................................... 72
User Outputs................................................................................................................. 73
Copying IR/Serial Tables ............................................................................................... 74
Endeleo UDM Receiver Commands ........................................................................ 74
Viewing Video Compensation Settings ......................................................................... 74
Resetting Video Compensation Settings ....................................................................... 75
Endeleo IR Codes ............................................................................................. 77
Overview ................................................................................................................ 77
UDM Hub Control Protocol .............................................................................. 79
Overview ................................................................................................................ 79
UDP (Ethernet) vs SLIP (RS-232) Communication .................................................... 79
Command Format ................................................................................................... 80
Command and Reply Example - Port Connection ................................................... 80
Command and Reply Example - Authentication (Login) .......................................... 81
UDP Over Network (10BaseT) Encapsulation.......................................................... 81
UDM Over Serial Port (SLIP) Encapsulation ............................................................ 81
SLIP Serial Communication Example....................................................................... 82
Handshaking ........................................................................................................... 83
Command Set ......................................................................................................... 83
Authentication ........................................................................................................ 83
Authenticate (Login)...................................................................................................... 83
Logout........................................................................................................................... 83
Command Summary ............................................................................................... 84
Basic Commands..................................................................................................... 84
Input Numbering........................................................................................................... 84
Port Numbering ............................................................................................................ 84
Connect Input to Port ................................................................................................... 84
Disconnect Port............................................................................................................. 85
Input Cascade Selection ................................................................................................ 85
UDM-0404 4x4 Multi-Format Distribution Hub
v
Table of Contents
Lock Port ....................................................................................................................... 85
Unlock Port.................................................................................................................... 86
Query Port..................................................................................................................... 86
Get Port or Input Name ................................................................................................ 86
Get Receiver Info........................................................................................................... 86
Send Remote Command................................................................................................ 87
Set Remote Device Protocol ........................................................................................... 87
Send IR Command To Connected Device ...................................................................... 88
Send Non-specific Serial Command................................................................................ 88
Set Serial Parameters ..................................................................................................... 88
Get Remote Serial Buffer .............................................................................................. 89
Set Hub Identification ................................................................................................... 89
Get Hub or Port Identification and System Information ................................................ 89
Reset Controller ............................................................................................................ 90
Set Protocol................................................................................................................... 90
Set Port Range .............................................................................................................. 90
Status Values .......................................................................................................... 90
Ascii / Hex Conversion ......................................................................................91
Overview ................................................................................................................ 91
vi
UDM-0404 4x4 Multi-Format Distribution Hub
UDM-0404 Multi-Format Distribution Hub
UDM-0404 Multi-Format Distribution Hub
Overview
The UDM-0404 Endeleo Multi-format Distribution Hub (FG-UDM-0404C) delivers any video source,
including Component, RGB, VGA and S-Video to a virtually unlimited number of display devices
(FIG. 1).
FIG. 1 UDM-0404
The UDM-0404 supports four high-resolution input ports and four UDM output ports, and supports
multiple methods of delivering sync information between the UDM Hub and the display device,
including common mode.
The UDM-0404 delivers media over easily-installed, dedicated Cat5/5e/6, which de-couples distribution
of the media from the corporate backbone. Users can quickly switch and transmit any video source to the
display device, power on/off display devices, and permission user control to select and play video
sources and media servers on demand.
The UDM-0404 offers four high-resolution input ports on the back of each unit. In total, the UDM-0404
system can distribute any combination of the following: four RGBHV sources, four Component video
sources, four S-Video sources or 12 Composite video sources.
Source inputs to the UDM are industry standard VGA, Composite, Component or S-Video feed, and
output is presented as an RJ45 port for connection to Cat5, 5e or 6 twisted-pair Ethernet cable.
Video inputs are connected via the HD15 Input connector on the rear of the UDM. Adapters are used to
bring the different types of video source into the UDM. See the Audio & Video Formats/Resolutions/
Distance section on page 9 for tested and confirmed distances.
Each UDM has an Ethernet network port to provide connectivity to a central management system, or can
be controlled by the onboard configuration pages. A Serial connection is also provided for CLI
administration and diagnostic purposes.
Features
4 multi-format inputs x 4 outputs
Supports multiple methods of delivering sync, including Common Mode Sync delivery
Digital audio support
Central device control
1U rack-mounting
Compatibility
The UDM-0404 is compatible for use with UDM-RX01 (FG-UDM-RX01) and UDM-RX02
(FG-UDM-RX02) Receivers.
Common Mode Sync delivery is supported only on the UDM-RX02.
UDM-0404 4x4 Multi-Format Distribution Hub
1
UDM-0404 Multi-Format Distribution Hub
Product Specifications
UDM-0404 Specifications
Power Requirements: • 90-264V AC, 50/60Hz
Front Panel Components
IR Sensor: Infrared receive port (IRRX) for learning IR remote control functions from IR con-
Outputs: 4 RJ-45 ports for connection to Endeleo UDM-RX02 Receivers (via Cat5, Cat5e
Rear Panel Components
Network Port: RJ-12 10 BaseT network port is provides network connectivity.
Serial Port: RJ-12 port allows an administrator to control various functions from a command
IRTX Ports: 2 Infrared Transmit (IRTX) ports allow the UDM-0404 to control IR devices via IR
Input Connectors (A-D): 4 sets of Input connections for up to 4 A/V inputs with the following connectors:
IEC Power Connector: Universal switch-mode power supply.
Network Interface: 10baseT
Serial Interface: 9600, 8, N, 1
Max Video Input: • 4 x RGBHV (or)
Operating Environment: • 35°F - 95°F (5°C - 35°C)
Dimensions (HWD):
Weight:
Certifications: • CE/UL/FCC part 15 Class A
Included Accessories: • IEC power cord
Other AMX Equipment: • HD15 to S-Video Cable (FG-UDM-SVID01)
• Max power consumption: 130W
trolled devices.
or Cat6).
line prompt.
emitters attached to the UDM. The IR cable is attached to the IR panel of the controlled device to receive IR commands issued through the software or remote
control.
• Video
• Audio Left
• Audio Right
• SPDIF
• As a Class 1 appliance the UDM-0404 should be connected to a mains supply
with a protective earthing connection.
• The Power On/Off switch is located beside the IEC power connector.
Note: The rating label found beneath the IEC connector contains important
information applicable to the UDM-0404’s installation environment.
• 4 x S-Video (or)
• 12 x CVBS (plus)
• Max. relative humidity - 85% (non-condensing)
1 3/4" x 19" x 12 1/2" (45 mm x 440 mm x 320 mm)
8.8 lb. (4 Kg)
• 19" mounting brackets
• RS-232 DB-9/RJ-12 connection cable
Note: No A/V interface cables supplied.
• HD15 to 3x RCA Breakout Cable (FG-HD15RCA3)
• RS232 DB9/RJ12 Connection Cable (FG-RS01)
• UDM-RX02 Multi-Format Receiver (FG-UDM-RX02)
• UDM-RC10 IR Engineering Remote Control (FG-UDM-RC10)
• IR01 IR Emitter Module (FG-IR01)
• IR02 Endeleo IR Splitter Cable (FG-IR02)
• IR03 External IR Receiver Module (FG-IR03)
2
UDM-0404 4x4 Multi-Format Distribution Hub
Installation
Overview
The UDM-0404 occupies a single rack space in a standard 19" equipment rack. Rack-mounting brackets
and screws are located in the accessories box supplied with the UDM-0404.
Exercise extreme care when lifting or moving the UDM-0404 within the rack to avoid
injury. It is recommended that you seek the assistance of another person when rack
mounting the 0404.
1. Attach the rack-mounting brackets to each side of the UDM-0404 using four M4 screws for each
bracket (FIG. 2).
FIG. 2 Attach the mounting brackets to each side of the UDM-0404
To prevent injury the UDM-0404 must be securely attached to the rack in accordance
with the installation instructions.
ALWAYS use the special rack mount brackets supplied and high quality fixing screws
to ensure the UDM-0404 is installed in the rack correctly.
2. Place the UDM-0404 in the rack and hold steady.
3. Two fixing holes are supplied on each side of the UDM-0404. Secure the UDM-0404 into the rack
using the fixing holes (FIG. 3).
Installation
FIG. 3 Secure the UDM-0404 into the rack using the fixing holes
DO NOT stand other units directly on top of the UDM-0404 when it is rack mounted,
as this will place excessive strain on the mounting brackets.
Ventilation
ALWAYS ensure that the rack enclosure is adequately ventilated.
Sufficient airflow must be achieved (by convection or forced-air cooling) to satisfy the ventilation
requirements of all the items of equipment installed within the rack.
UDM-0404 4x4 Multi-Format Distribution Hub
3
Installation
4
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections
IR L
UDM-0404 Front Panel Components
The components on the front panel of the UDM-0404 are described below (FIG. 4).
earning Sensor
4 RJ45 Output Ports for connection
to UDM-RX02 Receivers
FIG. 4 UDM-0404 - Front Panel Components
IR Learning Sensor
An IR receive port is found at the front of the UDM-0404 to the left-hand side (see FIG. 4). This is used
to learn device IR remote control functions from devices such as DVD players, VCRs etc. Common
functions learned include Power on, Power off, Play, Pause, Stop, etc.
Refer to the Configuration - Protocols Page section on page 59 for details.
Wiring and Connections
OUTPUT Ports (RJ-45)
The four RJ-45 ports on the front panel of the UDM (labelled “1-4”) provide connectivity to
UDM-RX02 Multi-Format Receivers.
UDM Port Pinouts
The following table provides detailed pinout information for the UDM port:
A/V Transmission Over UTP (UDM)
568A
Termination
RJ45
Color Pair # RGB YPbPr CVBS S-Video Color Pair #
Pin #
13Red + Y + CVBS S1 + Y + 2
2 3 Red - Y - CVBS S1 - Y - 2
32Blue + Pr + CVBS S3 + C + 3
4
51Green - Pb - CVBS S2 - 1
6
7 4 Audio, Data, Power + Audio, Data, Power + Audio, Data, Power + Audio, Data, Power + 4
8 4 Audio, Data, Power - Audio, Data, Power - Audio, Data, Power - Audio, Data, Power - 4
1 Green + Pb + CVBS S2 + 1
2 Blue - Pr - CVBS S3 - C - 3
A/V Signals
An incorrectly terminated cable will result in the following scenarios:
Incorrectly Terminated Cable Results
RJ45
Pin # RGBHV Video Component Video Composite Video SVideo
1-2 No RED No Y No Video 1 No Y On With Audio & Data RX
3-6 No BLUE No Pr No Video 2 No C On With Audio & Data RX
4-5 No GREEN No Pb No Video 3 NONE On With Audio & Data RX
7-8 NONE NONE NONE NONE Always OFF
UDM Audio & Data RX
Green LED
Termination
568B
UDM-0404 4x4 Multi-Format Distribution Hub
5
Wiring and Connections
UDM-0404 Rear Panel Components
FIG. 5 shows the components on the rear panel:
Input connections
(A - D)
TX connections for locally connected devices
Serial port (RJ-12)
ETHERNET port (RJ-45)
FIG. 5 UDM-0404 - rear panel components
IEC Power cable
connector/switch
The "Cascade In/Out" ports on the UDM-0404 are reserved for future
implementation.
Network Port (RJ45)
The RJ45 Network port on the rear panel of the UDM-0404 provides 10 BaseT network connectivity.
Pinout Configuration
The following table lists the pinouts, signals, and pairing for the Network port.
RJ45 Network Port Pinouts and Signals
Pin Signals Connections Pairing Color
1 TX + 1 --------- 1 1 --------- 2 Orange-White
2 TX - 2 --------- 2 Orange
3 RX + 3 --------- 3 3 --------- 6 Green-White
4 no connection 4 --------- 4 Blue
5 no connection 5 --------- 5 Blue-White
6 RX - 6 --------- 6 Green
7 no connection 7 --------- 7 Brown-White
8 no connection 8 --------- 8 Brown
FIG. 6 diagrams the pinouts and signals for the Network RJ45 connector and cable.
RJ45 wiring diagram
FIG. 6
Consult the Network Administrator for correct cabling from the UDM-0404 onto the
network. For remote connectivity, the Firewall may have to be configured to open port
2008 for remote connectivity over UDP
6
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections
Default IP Address
The default IP address of the UDM-0404 is 192.168.0.96.
Once the UDM-0404 is switched on, use the Setup option in the UDM WebConsole to configure the
correct IP address (see the Configuration - Setup Page section on page 37).
The IP address may also be configured via the serial port (refer to the Backend Commands section on
page 72).
Serial Port
The Serial port on the rear panel (labelled “10101”) is available for diagnostic and troubleshooting
purposes.
Connecting the Serial port on the UDM-0404 is not an essential step in the
installation process.
The Serial port on the UDM-0404is an RJ12 connector, and requires a DB9-to-RJ12 adapter cable
(FG-RS01) to connect to a PC for Terminal control.
Serial Port - Default Communication Settings
Use hyper terminal with default serial settings to communicate with the UDM-0404 (and UDM-RX01):
Default Serial Settings
Baud Rate: 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control: None
DB9-to-RJ12 Adapter Cable Pinouts
The following table provides the pinout configuration for the DB9-to-RJ12 adapter cable:
DB9-to-RJ12 Adapter Cable Pinouts
DB9 connector Function Abbreviation RJ12 connector
Pin 1 Not used NC
Pin 2 Transmit Data TD or TX or TXD Pin 2
Pin 3 Receive Data RD or RX or RXD Pin 3
Pin 4 Data Set Ready DSR Pin 1
Pin 5 Signal Ground GND Pin 4, 5
Pin 6 Data Terminal Ready DTR Pin 6
Pin 7 Not Used NC
Pin 8 Not Used NC
Pin 9 Not Used NC
UDM-0404 4x4 Multi-Format Distribution Hub
7
Wiring and Connections
TX (IR Transmit) Ports
A maximum of two IR devices (such as DVD players or VCRs) can be connected to the UDM via the
3.5mm stereo TX ports (TX1/2 and TX3/4) on the rear panel (see FIG. 5 on page 6), and controlled via
the WebConsole or remote control.
IR devices controlled via the TX ports are typically installed within the same
equipment rack as the UDM.
An IR02 Endeleo IR Splitter Cable (FG-IR02) can be used on each of the TX ports to allow using 2
devices per port.
If only two devices are connected to the TX ports:
Connecting an IR Device to an IRTX Port
To issue IR commands to the display device such as power on or power off, an IR01 Endeleo IR Emitter
Module (FG-IR01) is needed:
TX1/2 – Transmits IR commands to Device 1.
TX3/4 – Transmits IR commands to Device 2.
FIG. 7 IR01 Endeleo IR Emitter Module
Ensure the position of the device corresponds to the position assigned in the Devices
option of the UDM-0404’s WebConsole.
1. Connect the IR Emitter Module cable to the appropriate IRTX port on the UDM-0404.
2. Run the other end of the cable to the display device, and attach the IR Emitter over the device’s IR
sensor by removing the cover on the reverse side of the IR Emitter.
3. The UDM-0404 is now capable of issuing IR commands to the display device.
IR commands for each device on the system have to be learned by the UDM-0404 in order to function
properly. Refer to the Creating and Learning an IR Protocol section on page 62 on how to learn a
device’s IR commands.
A/V Source Input Connectors
There are four sets of input connectors to the rear panel of the UDM-0404, labelled A, B, C and D
(FIG. 8).
Digital Audio Input (SPDIF)
RCA Audio Inputs (L/R)
Video Input (female HD15)
FIG. 8 A/V Source Input connectors (A and B shown)
8
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections
Audio & Video Formats/Resolutions/Distance
The following table provides recommended maximum distances for cable runs, based on video class
type at various resolutions:
Audio & Video Formats/Resolutions/Distance
Class Format Name UDM-RX01 UDM-RX02
Composite 720x480 NTSC 300 m / 1000’ 300 m / 1000’
Component 720x480 480p 300 m / 1000’ 300 m / 1000’
VGA 640x480 VGA 200 m / 650’ 300 m / 1000’ *
720x576 PAL 300 m / 1000’ 300 m / 1000’
720x576 576p 300 m / 1000’ 300 m / 1000’
1280x720 720p 200 m / 650’ 300 m / 1000’
1920x1080 1080i 150 m / 500’ 300 m / 1000’
1920x1080 1080p 120 m / 400’ 300 m / 1000’
800x600 SVGA 200 m / 650’ 300 m / 1000’ *
1024x768 XGA 200 m / 650’ 300 m / 1000’ *
1280x1024 SXGA 150 m / 500’ 300 m / 1000’ *
1600x1200 UXGA 120 m / 400’ 300 m / 1000’ *
* When using VGA modes with audio enabled, the maximum cable distance is
approximately 200 m / 650’ (UDM-RX02).
It is important to note that the maximum distances indicated above are not absolute, but are
recommended distances that have been tested to deliver video at the specified resolutions, without
significant signal degradation. In particular, lower resolutions (640 x 480, 720 x 480 and 800 x 600) can
often be delivered significantly further than what is indicated in the table.
Several factors affect the overall quality of the displayed video, including the quality of the twisted pair
cable and connectors used, the nature of the video image itself, as well as the particulars of the
installation and how the video is displayed and viewed.
Two major factors affect the quality of signal transmission include:
Cable Distance: Naturally, long distances cable runs (in excess of 300 meters/1000 feet) are
always subject to resistance and capacitance losses which can negatively impact the quality of
the image.
Skew: "Skew" represents the slight delay that results from the variation in wiring lengths for
each of the twisted pairs. The effects of skew on A/V signals increases with cable length.
Excessive skew can adversely affect video image quality, especially at long cable lengths and
high signal resolutions.
UDM Hubs allow you to compensate brightness, sharpness and skew delay via options in the Status page
of the UDM’s built-in WebConsole (see the Video Compensation section on page 25).
UDM-0404 4x4 Multi-Format Distribution Hub
9
Wiring and Connections
VIDEO IN Connectors (HD15)
FIG. 9 provides the pin layout for the VIDEO IN HD15 Connectors:
FIG. 9 VIDEO IN HD15 Connector
Connecting a VGA Video Input
1.
2. Attach the other end of the cable to the appropriate VIDEO IN connection (A or B) on the UDM.
3. Connect any audio to the analog (RCA) audio connectors or digital (SPDIF) connector.
HD15 Pinouts
Input Pin
12345
678910
1112131415
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
VGA
Red
Green
Blue
n/c
Ground
Red - Ground
Green - Ground
Blue - Ground
n/c
Ground
n/c
n/c
Horz. Synch
Vert. Synch
n/c
Component
Pr
Y
Pb
n/c
n/c
Pr - Ground
Y - Ground
Pb - Ground
n/c
n/c
n/c
n/c
n/c
n/c
n/c
S-Video
Luminance
n/c
Chrominance
n/c
n/c
Luminance - Ground
n/c
Chrominance - Ground
n/c
n/c
n/c
n/c
n/c
n/c
n/c
Connect one end of a VGA cable to the source device’s VGA output port.
For example, connect to the Video In connection on Input A of the UDM-0404.
Composite
CVBS1
CVBS2
CVBS3
n/c
n/c
CVBS1 - Ground
CVBS2 - Ground
CVBS3 - Ground
n/c
n/c
n/c
n/c
n/c
n/c
n/c
Ensure the UDM Hub port the RX01/RX02 is attached to is configured correctly within
the Hub’s configuration software. Also ensure the correct Audio Type (Analog L/R,
S/PDIF, or None) is selected for the relevant input. See the Configuring Inputs AD section on page 41 for details.
Connecting a Composite Video Input
Connect the UDM-HD15RCA3 Breakout Cable (FG-HD15RCA3, not included) to the source
1.
device’s Composite output ports:
A1 = red RCA
A2 = green RCA
A3 = blue RCA
2. Attach the other end of the cable to the appropriate VIDEO IN connection (A or B) on the UDM.
3. Connect any audio to the analog (RCA) audio connectors or digital (SPDIF) connector.
Connecting a Component Video Input
Connect the UDM-HD15RCA3 Breakout Cable (FG-HD15RCA3, not included) to the video source
1.
device’s Component video output connectors (Red, Green and Blue).
2. Attach the other end of the cable to the appropriate VIDEO IN connection (A or B) on the UDM.
3. Connect any audio to the analog (RCA) audio connectors or digital (SPDIF) connector.
Connecting an S-Video Input
Connect the UDM-SVID01 HD15 to SVideo cable (FG-UDM-SVID01, not included) to the video
1.
source’s S-Video connection.
2. Attach the other end of the cable to the appropriate VIDEO IN connection (A or B) on the UDM.
3. Connect any audio to the analog (RCA) audio connectors or digital (SPDIF) connector.
10
Cascade In/Out Ports
The Ports labelled "Cascade In" and "Cascade Out" are reserved for future use. On the UDM-0404 they
are non-functional.
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections
Device Connectivity (IR TX1/2 and TX3/4 Ports)
A maximum of 4 Devices such as DVD players or VCRs can be connected to the UDM Hub and
controlled through the Browser software or via a remote control. An (optional) IR02 IR splitter cable
(FG-IR02) may be required.
1. Connect an Endeleo IR Emitter Module (FG-IR01) to the relevant IRTX port at the rear of the Hub.
2. Run the other end of the IR Emitter to the device’s IR sensor and attach the bud to the device’s
sensor by removing the cover of the reverse side of the bud.
IR commands for each device on the system have to be learned by the Hub in order to function properly.
Refer to the Protocols and IR section of the UDM-0404 Operation/Reference Guide on how to learn a
device’s IR commands.
Connecting UDM RX01/RX02 Receivers to the UDM-0404
1. Connect a standard Cat5/6 cable to the port marked UDM on the UDM Hub.
2. Connect the other end of the Cat5/6 cable to the “UDM Hub” port on the UDM-RX01 or RX02
Receiver.
3. When the power is switched on 2 LEDs will be visible at the Hub port – Amber (phantom power
enabled) and Green (UDM receiver connected to Hub port).
IEC Power Connector
The UDM-0404 uses a universal switch-mode power supply, which operates from 90-264V AC,
50/60Hz, with a power consumption of 130W fully loaded.
The rating label found to the bottom left of the UDM-0404, beneath the IEC connector,
contains important information applicable to the UDM-0404's installation environment.
The Power On/Off switch is located beside the IEC power connector.
As a Class 1 appliance the UDM-0404 should be connected to a mains supply with a
protective earthing connection.
Powering the UDM-0404 On
Ensure a standard PC mains lead has been connected to the 3-pin power connection, and then
1.
connected to a mains power source.
2. Flip the power switch down to its On (|) position.
Powering the UDM-0404 Off
Where a mains plug (or appliance coupler) is used in the event of a fault, the
UDM-0404 can be disconnected from the mains by removing the lead from the IEC
inlet or from the mains socket.
It is important that the UDM-0404 is installed in such a way that this method remains
readily operable.
The user should have easy access to either the IEC inlet or the mains socket in the
event of a fault.
To turn the UDM-0404 off, flip the Power switch to it’s Off (0) position.
UDM-0404 4x4 Multi-Format Distribution Hub
11
Wiring and Connections
12
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections - UDM Receivers
Wiring and Connections - UDM Receivers
Overview
UDM Receivers include the UDM-RX01 and UDM-RX02. Each Receiver is described in the following
sections.
UDM-RX01
Installed at the display device, the UDM-RX01 (FG-UDM-RX01) converts the signal received from a
UDM Multi-Format Distribution Hub to standard A/V signals (FIG. 10).
FIG. 10 UDM-RX01
With intelligent receiver technology, each UDM-RX01 is powered directly from the UDM Multi-Format
Distribution Hub. As the hub is switched from one video/audio source to another, the receiver detects a
change in signal and automatically switches the output device to its new video format.
UDM Hub Compatibility
The UDM-RX01 is compatible for use with the following UDM Hubs:
UDM-0102 (FG-UDM-0102)
UDM-0404 (FG-UDM-0404)
UDM-1604 (FG-UDM-1604C)
UDM-1604 (FG-UDM-1604)
UDM-RX01 Product Specifications
UDM-RX01 Specifications
Power Requirements: 24VDC @ .75A
Note: The UDM-RX01 is remotely powered by the UDM Multi-Format
Distribution Hub (see Powering on the UDM-RX02 ).
Rear Panel Connectors:
Power Socket: 2.1mm barrel-style DC power socket (female)
UDM Hub (RJ45) Port: Provides audio/video transport as well as control via Cat5, Cat5e or Cat6 to
an UDM Hub.
Serial (RJ12) port: Enables an administrator to control the various functions to the UDM-RX01
from a command line prompt and terminal connection.
• Requires a DB9-to-RJ12 adapter cable (FG-RS01) to connect to a PC.
• 9600, 8 bit, No Parity, 1 Stop Bit
IR Rx Port: 3.5mm stereo input port, for connection of an IR receiver to allow setup of
the UDM-RX01, local compensation controls, and remote control of
centrally located IR devices.
UDM-0404 4x4 Multi-Format Distribution Hub
13
Wiring and Connections - UDM Receivers
UDM-RX01 Specifications (Cont.)
IR Tx Port: 3.5mm stereo IR Transmitter output port allows one IR-controlled device
Audio Connectors: • Black RCA female connector - Digital audio
Video Connectors: • Yellow RCA female connector - CVBS (supports composite video)
Operating Environment: • 35°F - 95°F (5°C - 35°C)
Dimensions (HWD):
Weight:
Certifications: • CE
Other AMX Equipment: • RS232 DB9/RJ12 Connection Cable (FG-RS01)
(such as a DVD or VCR player) to be controlled via optional wired IR emitter.
• White RCA female connector - Analog audio Left
• Red RCA female connector - Analog audio Right
• S-Video - S-video female connector
• VGA - HD15 female connector (supports VGA video)
• Green RCA female connector - Component output: Y
• Blue RCA female connector - Component output: Pb
• Red RCA female connector - Component output: Pr
• Max. relative humidity - 85% (non-condensing)
1" x 8 15/16” x 3 3/8” (25 mm x 227 mm x 85 mm)
1.45 lb. (658 g)
• FCC part 15 Class A
• UDM-RC02 Multi-Format IR Remote Control (FG-UDM-RC02)
• IR01 IR Emitter Module (FG-IR01)
• IR03 External IR Receiver Module (FG-IR03)
• UDM-PS 24VDC, 750mA Power Supply (FG-UDM-PS)
UDM-RX02
With all the same features of the UDM-RX01, the UDM-RX02 adds support for “Common” mode sync,
as well as remote power for long cable distance runs. (FIG. 11).
FIG. 11
UDM-RX02 - UDM Hub Compatibility
The UDM-RX02 is compatible for use with the following UDM Hubs:
UDM-RX02
UDM-0102 (FG-UDM-0102) - This hub supports Common Synch Mode.
UDM-0404 (FG-UDM-0404) - This hub supports Common Synch Mode.
UDM-1604 (FG-UDM-1604C) - This hub supports Common Synch Mode.
UDM-1604 (FG-UDM-1604) - This hub does not support Common Synch Mode. In this case,
the UDM-RX02 will function, but without Common Synch Mode.
14
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections - UDM Receivers
UDM-RX02 Product Specifications
UDM-RX02 Specifications
Power Requirements: 24VDC @ .75A
Note: In most cases the UDM-RX02 is remotely powered by the UDM MultiFormat Distribution Hub (see Powering on the UDM-RX02 ).
Rear Panel Connectors:
Power Socket: 2.1mm barrel-style DC power socket (female)
UDM Hub (RJ45) Port: Provides audio/video transport as well as control via Cat5, Cat5e or Cat6 to
an UDM Hub.
Serial (RJ12) port: Enables an administrator to control the various functions to the UDM-RX02
from a command line prompt and terminal connection.
• Requires a DB9-to-RJ12 adapter cable (FG-RS01) to connect to a PC.
• 9600, 8 bit, No Parity, 1 Stop Bit
IR Rx Port: 3.5mm stereo input port, for connection of an IR receiver to allow setup of
IR Tx Port: 3.5mm stereo IR Transmitter output port allows one IR-controlled device
Audio Connectors: • Black RCA female connector - Digital audio
Video Connectors: • Yellow RCA female connector - CVBS (supports composite video)
Operating Environment: • 35°F - 95°F (5°C - 35°C)
Dimensions (HWD):
Weight:
Certifications: • CE
Other AMX Equipment: • RS232 DB9/RJ12 Connection Cable (FG-RS01)
the UDM-RX02, local compensation controls, and remote control of centrally located IR devices.
(such as a DVD or VCR player) to be controlled via optional wired IR emitter.
• White RCA female connector - Analog audio Left
• Red RCA female connector - Analog audio Right
• S-Video - S-video female connector
• VGA - HD15 female connector (supports VGA video)
• Green RCA female connector - Component output: Y
• Blue RCA female connector - Component output: Pb
• Red RCA female connector - Component output: Pr
• Max. relative humidity - 85% (non-condensing)
1" x 8 15/16” x 3 3/8” (25 mm x 227 mm x 85 mm)
1.45 lb. (658 g)
• FCC part 15 Class A
• UDM-RC02 Multi-Format IR Remote Control (FG-UDM-RC02)
• IR01 IR Emitter Module (FG-IR01)
• IR03 External IR Receiver Module (FG-IR03)
• UDM-PS 24VDC, 750mA Power Supply (FG-UDM-PS)
UDM-0404 4x4 Multi-Format Distribution Hub
15
Wiring and Connections - UDM Receivers
UDM Receivers - Configuration
UDM Receivers are configured via the UDM Hub’s WebConsole. Refer to the Configuration section on
page 21 for details.
UDM Receivers - Rear Panel Components
All of the connectors and ports are located on the rear panel (FIG. 12):
UDM HUB port (RJ45) - from an
“OUTPUT” port on the UDM-0102
Composite (Pr) port
Composite (Pb) port
Composite (Y) port
VGA (HD15) port
S-Video port
CVBS port
Serial port (RJ12)
IR Rx port
IR Tx port
Power connector
(UDM-RX02 only)
FIG. 12 UDM Receivers - rear panel components (UDM-RX02 shown)
RCA audio
(left/right)
SPDIF female Digital Audio port
UDM Hub Port (RJ45)
The UDM-RX01/RX02 connects to the network through a connection to a UDM Hub.
Serial Port
The Serial port is available for diagnostic and troubleshooting purposes.
The Serial port on the UDM Receiver is an RJ12 connector, and requires a DB9-to-RJ12 adapter cable
(FG-RS01) to connect to a PC for Terminal control.
IR Receiver (IR Rx) Port
The IR Rx port is used to enable user control and the remote compensation of the video link to the UDM
Receiver, using the FG-UDM-RC10 and the FG-IR03.
Refer to the Creating and Learning an IR Protocol section on page 62 for information on learning a
device’s IR commands.
IR Transmit (IR Tx) Port
The IR Tx port issues IR commands from the UDM Receiver to a controlled device. One IR device
(such as DVD player or VCR) can be connected to the UDM Receiver via the IR Tx port, and controlled
via the UDM Hub’s WebConsole or via remote control.
16
IR devices controlled via the IRTX ports are typically installed within the same
equipment rack as the UDM Hub and Receiver.
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections - UDM Receivers
Connecting an IR Device to the IR Tx Port
Connect an IR01 Endeleo IR Emitter Module (FG-IR01) to the IR Tx port on the UDM Receiver.
1.
Ensure the position of the device corresponds to the position assigned in the Devices
option of the UDM- Hub’s WebConsole.
2. Run the other end of the IR Emitter cable to the device’s IR sensor, and attach the IR Emitter to the
device’s sensor by removing the cover on the reverse side of the IR Emitter.
IR commands for each device on the system have to be learned by the UDM Hub in order to function
properly. Refer to the Creating and Learning an IR Protocol section on page 62 for information on
learning a device’s IR commands.
AUDIO Connectors
UDM Receivers provide standard Audio RCA output connectors for S/PDIF for digital audio, and
LEFT/RIGHT for analog audio output (see FIG. 12 on page 16).
VIDEO Connectors
VGA Input at Display Device
1.
Attach one end of the Endeleo VGA to VGA cable to the VGA connector on the UDM Receiver.
2. Run the other end to the VGA connector on the display device. Connect firmly.
3. If appropriate connect audio to the audio connectors on the UDM Receiver.
Ensure Input A is configured as a “VGA Input” and named appropriately within the
“Inputs” section of the Hub’s Configuration software. Also ensure the correct Audio
Type (Analog L/R or S/PDIF) is selected for the relevant input.
Composite Input at Display Device
Attach the composite cable (normally yellow) to the CVBS connector on the UDM Receiver.
1.
2. Run the other end of the composite cable to the Composite connector (normally yellow) on the
display device. Connect firmly.
3. If appropriate connect audio to the audio connectors on the UDM Receiver.
SVideo Input at Display Device
1.
Attach the SVideo cable to the 4-pin S Video connector on the UDM Receiver.
2. Run the other end of the SVideo cable to the SVideo connector on the display device. Connect
firmly.
3. If appropriate connect audio to the audio connectors on the UDM Receiver.
Component Input at Display Device
1.
Attach the Component cables (normally green, blue and red) to the Y (green), Pb (blue) and Pr
(red) connectors on the UDM Receiver.
2. Run the other end of the Component cable to the Component connectors (normally green, blue and
red) on the display device. Connect firmly.
3. If appropriate connect audio to the audio connectors on the UDM Receiver.
UDM-0404 4x4 Multi-Format Distribution Hub
17
Wiring and Connections - UDM Receivers
Audio & Video Formats/Resolutions/Distance
Refer to the Audio & Video Formats/Resolutions/Distance section on page 9.
Video Compensation
Video at the Receive end can be compensated using three main methods;
Using the UDM Hub’s WebConsole.
Using the UDM-RC02 Multi-Format IR Remote Control.
Using a hyper terminal session via the serial connector on the UDM Receiver (especially
effective setup method when using long runs).
Connecting an External IR Receiver Module
If passthrough mode (where a device such as a DVD or VCR can be controlled via a remote control) is
required then an IR03 External IR Receiver Module will be needed to pick up IR controls from the
remote control.
Additionally, if the UDM Receiver is to be compensated via a remote control, then an IR Receiver
Module is also needed.
Connecting the UDM Receiver to the UDM Hub
The RJ45 port on the front panel of the UDM Hub labelled “UDM” supports one UDM Receiver. The
UDM Receiver is then be connected to a display device.
1. Connect a standard Cat5/6 Ethernet cable to the RJ45 port labelled UDM on the front panel of the
UDM Hub.
2. Connect the other end of the Ethernet cable to the RJ45 port labelled UDM Hub on the rear panel of
the UDM Receiver.
Ensure the port the UDM-RX01/RX02 is attached to is configured correctly within the
Status option of the WebConsole (for example, if a UDM Receiver is connected to the
Hub, ensure the port in the Status option is configured likewise.
UDM HUB Port LEDs
2 LEDs are visible at the UDM Hub port (on the UDM-RX01/RX02) when the UDM Hub is switched
on:
Green – Connection to UDM Hub (if Cat 5 removed, LED switches off).
Amber – Power (as well as comms if uploading protocols etc. the Amber LED may flicker).
Powering on the UDM-RX02
As a Class 1 appliance, ensure the device is connected to a main socket outlet with a
protective grounding connection.
The UDM-RX02 may be powered by its hub device through a standard CAT5 cable, but it may also be
powered through an optional 24 VDC power supply (FG-UDM-PS) intended to augment power for very
long cable runs.
To connect the UDM Receiver to the optional power supply, insert the barrel connector of the power
supply into the power connector on the UDM Receiver (see FIG. 12 on page 16).
To power down the UDM-RX02, remove the barrel connector of the power supply from the power
connector and then remove the Ethernet cable from the UDM Hub connector.
18
UDM-0404 4x4 Multi-Format Distribution Hub
Wiring and Connections - UDM Receivers
Disconnecting the optional power supply will not power down the UDM-RX02 if its
Ethernet connection to the UDM Hub is intact.
System Overview
FIG. 13 provides a basic system diagram representing a UDM Hub, UDM Receiver, and connected
devices:
DVD DSS
Video Out
Audio Out
Video Out
Audio Out
Video In
Ethernet
(network
FIG. 13 UDM System Diagram
Audio In
Video Out
Video In Audio In
Video In
UDM Hub
UDM Receiver
Audio Out
Display
Audio In
Cat5
UDM-0404 4x4 Multi-Format Distribution Hub
19
Wiring and Connections - UDM Receivers
20
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration
WebConsole Overview
Each UDM-0404 Hub can be configured for the correct network environment. It is also possible to
configure each Hub for the correct date and time. Configuration options are available via the UDM’s
built-in WebConsole, as described in this section.
The UDM-RX02 Receiver connected to the UDM-0404 is also configured via the 0404’s WebConsole.
This section describes the pages that comprise the UDM-0404’s WebConsole
interface in the order that they are presented (“Status”, “Setup”, "Inputs", "Devices"
“Schedule” and “Protocols”). However, on initial connection, you’ll probably need to
visit the Setup page first, to specify network configuration and other basic device
setup options for the Hub.
See the Configuration - Setup Page section on page 37 for details.
Connecting to the UDM-0404
Use the included Ethernet Crossover cable for initial setup.
Configuration
1. The default IP address of the UDM-0404 is 192.168.0.96.
2. Enter the IP address into the address field within a browser window.
3. To connect to the UDM-0404, a password is required.
The username should be left blank.
The password is admin (case-sensitive).
4. On initial connection, the Status page is displayed (FIG. 14).
Click links to access the six main
areas of the WebConsole
(initial view is Status)
FIG. 14 Status page (Initial View)
UDM-0404 4x4 Multi-Format Distribution Hub
21
Configuration
After setup you can change TCP/IP address and connect the UDM-0404 to your network equipment
(switch, hub, or serial port).
Use the links in the left-pane of the page to access each of the main Configuration pages, as described in
the following sections.
22
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
Overview
The Status page is the initial view when the UDM-0404’s WebConsole is accessed. To access the Status
page from any other Configuration page in the WebConsole, click on the Status link in the navigation
pane (FIG. 15).
Click to select
an Input for
each Port
Click to access
Port Configuration options
for each Port
Configuration - Status Page
Click to access
User Control options
for each Port
FIG. 15 Main Status page
All of the system control is handled via options in the Status page. From this page it is possible to
configure each Port:
Specify which Input is displayed on each output Port
Adjust video settings to compensate for cable distance
Send device control messages to display devices
Schedule events
UDM-0404 4x4 Multi-Format Distribution Hub
23
Configuration - Status Page
Port Configuration Options
Click on any of the Port (1-4) links on the Status page (see FIG. 15) to access the Port Configuration
options for the selected Port (FIG. 16):
Click to return all Port Configuration options to default settings
Port number and
firmware version
FIG. 16 Port Configuration Options
Click to send current settings
Click to access
Control options
for this port
to the Receiver
The video compensation options shown in FIG. 16 are only presented when a
Receiver is connected to the selected port.
The Port Configuration Options include:
Port Configuration Options
Port Number and
Firmware version:
User Control: Click to access the User Control options for this Port, to allow Administrators to issue
Send Settings To RX: Click to send the current settings to the UDM Receiver connected to this Port.
Default: Click to return all Port Configuration options for this Port to their default settings.
Remote Type: Click to select the type of remote controller to be used for Passthrough control for
Port Name: The current name for this Port. Click and type in this text field to rename this Port.
Bright Up/Down Once any skew has been eliminated the video should be adjusted for brightness
Sharp Up/Down The sharpness of the video should be adjusted last, to eliminate any over or under
Sync: Click to select a sync mode for this port. Options include: Common, Auto, On Green,
Displays the currently selected Port (1-4), and the current firmware version.
commands from the UDM WebConsole. See the User Control section on page 30 for
details.
this Port (if applicable). See the Passthrough Mode (Inputs A – D) section on
page 34 for details.
See the Renaming Output Ports section on page 25 for details.
using a grey scale or equivalent test card.
shoot of the video. Horizontal black and white bars are one useful method of tuning
sharpness.
Negative and Positive). By default "Common" sync is selected - in most situations
the sync mode should not be changed unless there are sync issue with a particular
display device.
24
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
Port Configuration Options (Cont.)
Red/Green/Blue skew: Use this set of radio buttons to manually add skew delay to any of the video colors.
Protocol: Select a control protocol to be used for this Port. See the Testing Serial Control
See the Basic Video Compensation section on page 25 for details.
Commands section on page 63 for details.
Renaming Output Ports
Click on the relevant Port hyperlink on the Status page (see FIG. 15 on page 23) to invoke the Por t
1.
Configuration options for the selected Port (see FIG. 16 on page 24).
2. Type directly into the Name text field to rename the port.
Video Compensation
Options within the Port Configuration page (see FIG. 16 on page 24) allow you to compensate (tune)
outgoing video signals for optimum picture quality.
LCD screens have a tendency to automatically try and compensate the video,
presenting issues when adjusting for skew. Using a CRT monitor to adjust video
quality is often the best way around this.
Basic Video Compensation
On the Status page. click on a Port hyperlink to access the Port Configuration options (see
1.
FIG. 16 on page 24).
2. Adjust Brightness and Sharpness via the Up and Down links.
3. To add skew delay into any of the video colors, click on the appropriate color hyperlink (FIG. 17).
1
2
3
FIG. 17 Skew controls
The skew delay cycles through red, green and blue.
Each radio button is equivalent to 2ns delay.
UDM-0404 4x4 Multi-Format Distribution Hub
25
Configuration - Status Page
Advanced Video Compensation
To enable advanced video compensation options, click on the Enable advanced options checkbox, in the
Setup page (FIG. 18).
FIG. 18 Setup Page - Enable advanced options checkbox
1. In the Status page, click on a Port link to access the Port Configuration options for the selected Port
(see FIG. 16 on page 24).
2. With the Enable advanced options checkbox selected in the Setup page, the Port Configuration
options include the additional Cable Distance field (FIG. 19):
Click to enable "Dual Output"
mode on this Port
Click to enable "Bright" and "Sharp"
Enter approximate distance of
the cable run between the UDM
hub and UDM Receiver in meter
FIG. 19 Port Configuration options - with "Enable advanced options" selected in the
fields for manual adjustments
Setup
page
3. In the Cable Distance field, enter the approximate distance of the cable run from the UDM-0404 to
the UDM Receiver (in meters). This value is used to automatically adjust the brightness and
sharpness of the image.
The Cable Distance field is intended primarily for use with VGA cabling in excess of
200 meters (see the Audio & Video Formats/Resolutions/Distance section on
page 9).
4. To make manual adjustments to Brightness and Sharpness, click on the Advanced checkbox (see
FIG. 19) to enable the Bright and Sharp fields (FIG. 20):
26
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
FIG. 20 Port Configuration options - "Enable advanced options" selected in the
Setup
page and "Advanced" selected
Video compensation settings can also be configured via hyper terminal session. See
the Advanced Administration section on page 67 for details.
Compensating Video Via the UDM-RC10 Remote Control
Video can also be compensated using the Endeleo UDM-RC10 IR Engineering Remote Control
(FIG. 21).
Amber LED blinks to indicate that the RX02 is in Compensation mode
IR RX port
IR03 IR Receiver Module (FG-IR03)
FIG. 21 UDM-RX02 with IR03 IR Receiver Module
UDM-RX02
1. Ensure the IR03 Endeleo External IR Receiver Module (FG-IR03) is attached to the UDM-RX02 at
the IRRX port (FIG. 21).
2. To enter compensation mode, push the ESC and B buttons on the remote control.
3. The amber LED at the Cat5 port on the UDM-RX02 will start to flash, indicating the UDM-RX02 is
in compensation mode.
4. Use the buttons on the remote control to adjust appropriately the following up or down;
Sharpness
Gain
Red, Green and Blue.
5. Once the image displayed is of an acceptable quality, push the A button on the remote control to exit
compensation mode.
UDM-0404 4x4 Multi-Format Distribution Hub
27
Configuration - Status Page
The compensation settings will be specific to this UDM-RX02 and stored internally
(for example, if this UDM-RX02 is replaced or swapped out the compensation
settings will travel with the UDM-RX02). It may therefore be necessary to recompensate the UDM-RX02 / replacement UDM-RX02 if this UDM-RX02 is to be
used elsewhere or is being replaced.
Video Compensation (UDM-RX01/RX02)
Video at the Receive end can be compensated using three main methods;
Dual Output Mode
With the Enable advanced options checkbox selected in the Setup page (see FIG. 18 on page 26), the
Port Configuration options include the Dual Output checkbox (FIG. 20).
Dual Output mode permits a single input to be viewed as two separate output types. For example a port
could be configured for the dual output of VGA and Component video. This means at the UDM
Receiver, the input could be delivered to two separate display devices.
.
Using the WebConsole to compensate each port individually in the Status option (see the
Video Compensation section on page 25).
Using the Endeleo Remote Control to compensate video (see the Compensating Video Via the
UDM-RC10 Remote Control section on page 27).
Using a hyper terminal session via the serial connector on the UDM-RX02 (especially
effective when using long runs). See the Advanced Administration section on page 67 for
details.
Ensure the correct cabling is in place at the RX to accommodate the 2 separate
signals.
Selecting Inputs For Display
1. Each port on the hub has a drop down box, in which will be displayed all of the inputs (as
configured in the Inputs page) available to this particular Port (FIG. 22).
Inputs available to Port 1
FIG. 22 Inputs available for a Port
"Inputs" mean inputs directly connected to the rear of the UDM-0404 (e.g. Inputs A-D,
or devices connected to IRTx ports 1 – 4.
2. Select the appropriate Input (VGA display, DVD, TV Channel) which this port will display.
28
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
Selecting Multiple Inputs For Display
An input can be assigned to multiple ports to save administration time.
1. To change more than one port to display a particular input, select the desired input from the drop
down list beside the Included option (FIG. 23).
FIG. 23 Included drop-down menu
2. Select the checkboxes beneath the Include column beside the relevant ports which are to display the
input selected in the Included drop-down menu. The selected ports are highlighted in blue
(FIG. 24).
Click to select or deselect all Ports
Click checkboxes to include one or more Ports
FIG. 24 Include checkboxes selected for all four Ports (to include Input "A1")
The Include All link toggles all the Ports to be included on or off.
3. Click on Execute to configure the ports to display the Included input (FIG. 25).
Click to set the selected Ports
to use the "Included" input
FIG. 25 Execute button
4. Once the configuration changes are complete, de-select the relevant ports by clicking their
corresponding checkbox in the Include column. The blue highlight disappears, and the specified
Ports are configured to use the Included input - see FIG. 26).
UDM-0404 4x4 Multi-Format Distribution Hub
29
Configuration - Status Page
FIG. 26 Ports re-configured to use the "Included" input ("A1")
Changing an Input
The input being displayed at a Port can be changed at any time via the Input drop-down menu. To change
multiple ports select/include those ports appropriately.
User Control
Administrators can issue commands directly from the UDM WebConsole, via the User Control options
in the Status page (FIG. 27).
Click to access User Control
options for each Port
Click to issue one or two commands
to the selected Port(s)
FIG. 27 User Control options
Click to select a command from a list
of supported controls for each Port
Commands can be issued in multiple ways:
The Control toolbar located at the bottom of the Status page for the selected port(s).
The Control drop-down options for the relevant port
The User Control options for a selected port (click the relevant Port’s link to access User
Control options).
Schedules are also used to issue commands at a pre-determined time to inputs and
devices. Refer to the Configuration - Schedule Page section on page 47 for details.
30
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
Issuing Commands To a Selected Port
Ensure the device’s IR commands have been learned by the Hub first. Refer to the
Configuration - Protocols Page section on page 59.
Control of the input is performed in a similar way to changing the input to be displayed. Commands can
either be issued per Input or issued across all or groups of ports.
1. For the Port that you want to issue a command, open the Control drop-down menu, as shown in
FIG. 28.
Click to execute the selected
Command on this Port
Control drop-down menu
FIG. 28 Control drop-down menu
2. Select the required command from the Control drop-down menu.
Where a custom control is required, type in the IR code for the command. Refer to
the Endeleo IR Codes section on page 77.
3. Once selected, click on Execute (see FIG. 28) to execute the selected command for the relevant
port.
Ensure that an (optional) IR01 Endeleo IR Emitter Module (FG-IR01) is connected to
the Receiver’s IRTX port. Attach it to the Device’s IR sensor before issuing a
command. The IR Emitter transmits the command from the Receiver directly to the
device’s IR sensor.
UDM-0404 4x4 Multi-Format Distribution Hub
31
Configuration - Status Page
Issuing Commands To Multiple Ports
As with the input selection it is also possible to send multiple control commands to all or selected ports.
Because the control strings are stored in the UDM Receivers, a global command across multiple ports
will allow any range of display devices to be controlled simultaneously.
1. Select the Include checkboxes for the Ports to be changed (use the Include All link to toggle all Ports
to be included on or off). The ports are highlighted in blue.
2. Open the Control drop-down menu for one of the selected Ports, and select the control to be
executed.
3. Click on Execute button (see FIG. 28 on page 31).
It is also possible to control centrally located hardware such as DVD players, using
the "Devices" page. See the Issuing Commands To a Centrally Located IR
Device section on page 44 for details.
Assigning a Command to an Endeleo UDM-RC02 Remote Control
Ensure the Infrared command which the UDM-RC02 Remote control will issue has
been learned by the Hub first. Refer to the Protocols and IR learning section of this
manual.
Click on a Port name to access the Port Configuration options for the selected Port.
1.
2. Click the User Control link (FIG. 29). .
Click to access User Control
options for this Port.
FIG. 29 Port Configuration options for Port 1 - User Control link
Alternatively, click on the "User Control" link for the relevant Port on the main Status
Page (see FIG. 28 on page 31).
This action invokes the User Control options for the selected Port (FIG. 30).
32
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
FIG. 30 User Control options for Port 1
Keys 0 to F represent the keys on the UDM-RC02 Remote Control.
Commands for each Key are selected from the Control drop-down menu (provided for each
Key).
3. Open the Control drop-down menu for any Key, and select the command which this key on the
UDM-RC02 Remote Control will issue (FIG. 31).
FIG. 31 Control drop-down menu for Key 2 ("Play" selected)
UDM-0404 4x4 Multi-Format Distribution Hub
33
Configuration - Status Page
Ensure the correct key on the Endeleo Remote corresponds with the correct
command.
4. Select either the Port or Device radio button to specify whether this button on the remote should be
associated with the Port (display device) or an actual Device (e.g. a DVD player added to the system
as a device) when it is pushed.
5. The Endeleo Receiver will now accept the relevant command from the RC02 remote (i.e. Key 2 on
the remote will "Play" the Device (FIG. 32). .
FIG. 32 Port Configuration options for Port 1 - User Control link
Passthrough Mode (Inputs A – D)
Devices can also be placed into Passthrough Mode. Passthrough Mode allows an Endeleo TVM remote
control to be used to control TV channels being viewed through the UDM-0404, or devices connected to
the UDM-0404 (e.g. a DVD player). Passthrough Mode is available for Inputs A-D, as shown in FIG. 33.
FIG. 33 Passthrough Mode options (Inputs A – D)
The following steps must be taken for Passthrough Mode to function correctly:
1. The Device must be added to the system as an Input.
2. IR emitter (on the correct IR port) at the rear of the UDM-0404 must be connected to the device.
3. The Device must be added to the system as a Device and be assigned its learned protocol.
4. The Device’s Port must be configured for Passthrough Mode.
Configuring a Device for Passthrough Mode
The device must to be added to the system as both an Input and as a Device:
1. Cable the device as an input coming into the rear of the chassis (e.g. into Input A as for a normal
input).
2. Add the device as an input in the Inputs option. See theConfiguration - Inputs Page section on
page 41 for details.
3. Learn the device’s protocol using IR Learning – refer to the Configuration - Protocols Page section
on page 59 and Advanced Administration section on page 67.
4. Add the device into the Devices option as normal and assign it its IR protocol. See the
Configuration - Devices Page section on page 43 for details.
Ensure the relevant IR emitter port is cabled up to the device also e.g. if the device is
connected to Input A cable IR port 1 to the device, if Input B cable IR port 2 to the
device etc.
34
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Status Page
Configuring a Port for Passthrough Mode
Click on a Port link for the correct port to access the Port Configuration options (see FIG. 29 on
1.
page 32).
2. Select the Remote Control that will be used to put the device into passthrough mode from the
Remote type drop-down menu (FIG. 34).
FIG. 34 Remote type drop-down menu
3. Click on the Passthrough checkbox for the key dedicated to putting the Receiver into Passthrough
Mode.
4. The device can now be controlled directly at the Receiver end.
Using Passthrough Mode
Once a device has been configured for Passthrough Mode the relevant remote control is used to control
the device.
Press the previously configured key on the relevant remote control (UDM-RX01 or Sky remote control)
to enter passthrough mode.
If accessing a Sky Box through passthrough, click on the Sky button on the Sky remote
control. Now use the Sky Remote control as normal. (Press TV on the Sky remote to exit
passthrough mode).
If accessing a DVD player through passthrough, click on the relevant button on the DVD
remote control to play, pause, stop eject etc. Use the DVD Remote control as normal.
If accessing an Endeleo TVM Hub through passthrough, click on the Up or Down channel on
the TVM remote control, to toggle between channels.
Exiting Passthrough Mode
Press any key on the UDM-RC02 remote which is not configured as a control enabled key.
If accessing a Tivo or Sky set-top box press TV on the Tivo or Sky remote.
UDM-0404 4x4 Multi-Format Distribution Hub
35
Configuration - Status Page
Locking One or More Ports
Locking an output port to a specific source prevents any user control at that port.
1. On the Status page, select the Locked checkbox beside the relevant port or ports (FIG. 35).
FIG. 35 Locking a port
2. Click on Execute. The port is now locked to that display.
Multiple ports can be locked by clicking on the Include checkbox relevant to the port,
then clicking on Execute to lock the ports.
36
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Setup Page
Overview
Each Hub must be configured for the correct network environment. It is also possible to view device
information, configure the Hub for the correct date and time and specify Restore options, via options in
the Setup page (FIG. 36):
Configuration - Setup Page
Device information
Network Configuration
Date / Time Settings
Restore Options
FIG. 36 Setup Page
Device Information
The top portion of the Setup page provides several Device Information items as well as Fan control,
SLIP authentication and an option to enable advanced video compensation controls:
Setup Page - Device Information
Controller firmware: This display-only field indicates the current controller firmware version.
Port: This display-only field indicates the current port (UDM) firmware version.
Input: This display-only field indicates the current input firmware version.
HTML This display-only field indicates the current HTML (WebConsole) version.
Serial number: This display-only field indicates the unique serial number for this UDM Hub.
Internal temp: This display-only field indicates the current internal temperature of the unit.
Fans: These radio buttons allow you to turn off the internal fans. The default setting is
"Auto" (fans will automatically turn on and off based on the internal temperature reading).
Caution: by turning off the fans, the unit may be susceptible to overheating.
Authenticate SLIP: By default, SLIP authentication is enabled. De-select this option to disable
SLIP authentication.
Enable advanced options: Enable this option to access the advanced video compensation settings (in the
Port Configuration options - see the Advanced Video Compensation section on
page 26).
UDM-0404 4x4 Multi-Format Distribution Hub
37
Configuration - Setup Page
Network Configuration
The UDM-0404 does not support DHCP. Please configure a static IP Address.
1. The following Network Configuration options must be configured (FIG. 37):
FIG. 37 Network Configuration options
a. Hub IP Address, Subnet Mask and Default Gateway
b. UDP Port
c. Hub name (maximum of 30 characters).
2. Once the network environment has been configured, click on Update.
The default IP address is: 192.168.0.96
The default UDP Port is: 2008
All changes are immediate - once the IP address of the hub has been changed
redirect the web browser to the changed address.
Date and Time Configuration
The Setup page is also used to set up the hub date and time, which is used for scheduling (FIG. 38).
FIG. 38 Date and Time Settings
1. Enter the desired values for the current Time and Date.
2. Click on Update when all configuration changes have been completed.
Restoring Hub Configuration and Connections
To ensure the configuration settings for the Hub are retained each time the hub boots it is advisable to
ensure the Restore options at the bottom of the Setup page have been enabled (FIG. 39).
FIG. 39 Restore options
Failure to select the Restore Configuration and Connection options will mean if the
Hub is reset the Hub configuration and connections will need to be re-configured.
38
Restoring Configuration and Connections
To ensure network configuration and port configuration are restored on boot up select Restore
configuration on power up option (see FIG. 39).
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Setup Page
Restoring Connections On Power Up
To ensure inputs are transmitted to the outputs (or ports) on boot up select the Restore connections on
power up option (see FIG. 39).
Resetting the UDM-0404
Where appropriate the Hub can be reset from the Browser interface. Use the Setup option to reset the
Hub.
1. Click the Reset Hub button (see FIG. 39).
The UDM-0404’s network connection will be lost temporarily and video displays will switch off
then on again very quickly.
2. Restart the Hub.
A power down of the Hub must be performed to complete the reset procedure.
UDM-0404 4x4 Multi-Format Distribution Hub
39
Configuration - Setup Page
40
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Inputs Page
Overview
Use the options in the Inputs page (FIG. 40) to set up the video types and audio sources being presented
to each input port and where appropriate renaming these.
Configuration - Inputs Page
FIG. 40 Inputs Page
Configuring Inputs A-D
Each input port can be set to accept a local source:
1. For each Input port (A-D), select the appropriate input type from the Typ e drop-down menu
provided for each Input (FIG. 41).
FIG. 41 Input Type drop-down menu
For RGB, VGA, Component or SVideo inputs, only one connection is possible per
input port.
2. To name the Input Type, type directly into the Name field for each Input (FIG. 42).
UDM-0404 4x4 Multi-Format Distribution Hub
41
Configuration - Inputs Page
FIG. 42 Naming the Input Type
3. Name the Composite video sources appropriately.
FIG. 43 Composite Video sources
If the Input Typ e is Composite, additional Name fields are provided to name each of the 3
composite sources separately (FIG. 43).
Configuring Audio Types For Inputs
Audio types (Analog L/R or S/PDIF) can be configured for each Input. To configure audio for individual
Inputs;
1. Click on Inputs.
2. In the audio section of the Inputs option, under the Ty pe column, select the type of audio
(Analog L/R or S/PDIF) for the relevant input (FIG. 44).
FIG. 44 Configuring audio types for inputs
Ensure audio has been connected from the Input to the rear of the hub. Ensure the
connections are sound and fixed correctly.
42
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Devices Page
Overview
The system allows "centrally located" devices connected to the rear of the UDM-0404 (e.g. VCR, DVD,
DVR or Satellite Decoders) to be managed from the user port. Centrally located devices are connected
directly to the rear of the UDM-0404 via the UDM IR ports (Tx1 – Tx4) using an Endeleo IR Tx bud.
The IR Tx bud will then transmit the IR signal from the UDM-0404 to the device.This is performed
through the Devices page (FIG. 45).
Configuration - Devices Page
FIG. 45 Devices page
An IR02 Endeleo IR Splitter Cable (FG-IR02) will be needed for each of the IR ports if using 2 devices
per IR port.
If only one device connected to IR TX port 1/2 it will by default be Device 1.
If only one device connected to IR TX port 3/4 it will by default be Device 3.
IR TX Ports 1/2
IR TX Ports 3/4
FIG. 46 IR TX ports for locally connected devices
UDM-0404 4x4 Multi-Format Distribution Hub
43
Configuration - Devices Page
Adding Centrally Located Devices
1. Name each device accordingly by typing in the Name text field.
Ensure the correct port is selected.
2. Configure the device with the relevant IR protocol if appropriate.
Refer to the Creating and Learning an IR Protocol section on page 62 for details.
Issuing Commands To a Centrally Located IR Device
The UDM-0404 needs to learn the device’s IR protocol (which button on its remote
performs which function). Refer to the Configuration - Protocols Page section on
page 59.
1. The Control toolbar at the bottom of the screen enables specific commands to be executed via the
browser connection (FIG. 47).
FIG. 47 Control Bar
2. Select the command(s) to be performed for this device from the 1st and 2nd (Command) drop-down
menus (FIG. 48). Two commands can be issued to a device (1
FIG. 48 Optional controls for a device
st
and 2nd).
44
The first command is limited to Power On, Off and A/V Select.
3. Click the Include checkbox to select the device(s) to be sent a command.
4. Click the Send to Included link to send the selected command to the Included device(s).
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Devices Page
Alternatively such commands can be scheduled to occur later. Refer to the
Configuration - Schedule Page section on page 47 for details.
Custom Commands
Custom Commands permits the Administrator to specify custom IR commands which can sent to the
device or display. A list of custom commands and their IR value can be found in the Endeleo IR
Codes section on page 77).
To issue a custom command;
1. Select the custom option within the 2
nd
list of commands.
2. Type in the value of the IR code which is to be sent in the relevant box.
3. Execute the custom command or schedule it to occur later.
Issuing Commands to Centrally Located Devices
It is also possible to control centrally located hardware such as DVD players, via options in the Devices
page. Remember an IR-TX bud coming from the rear of the UDM-0404 will sit over the Device’s IR
sensor.
1. Select the device(s) you wish to control by clicking on the appropriate Include checkboxes
(FIG. 49).
FIG. 49 Selected devices
2. In the Control toolbar at the bottom of the page, select the command(s) to be performed for the
selected device(s) from the 1st and 2nd (Command) drop-down menus (FIG. 48). Two commands
can be issued to a device (1
st
and 2nd).
FIG. 50 Optional controls for a device
UDM-0404 4x4 Multi-Format Distribution Hub
45
Configuration - Devices Page
The first command is limited to Power On, Off and A/V Select.
3. Click the Send to included link to issue the commands (see FIG. 50).
The Device’s commands must have been learned by the UDM-0404 in order to
function. Refer to the Configuration - Protocols Page section on page 59.
46
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
Overview
The UDM-0404 features an on-board clock that allows you to create scheduled events to be executed at a
predetermined time in the future. Scheduled events are listed on the Schedule page (FIG. 51), but are
created using options in both the Status and Devices pages, as described in this section.
Configuration - Schedule Page
FIG. 51 Schedule page
You can create and store up to 16 scheduled events.
There are several basic types of scheduled events:
Scheduled IR Device Controls - Use the Schedule options in the Devices page to schedule
events to be executed at specified times on IR-controlled devices connected to the IRTX (IR
Transmit) Ports on the rear panel (see the TX (IR Transmit) Ports section on page 8). For
example, you could create a scheduled device event that causes the devices connected to TX
Ports 1-4 to power-up and/or power-down at scheduled times each day.
See the Scheduling IR Device Control Events section on page 48 for details.
Scheduled Output Device Control - Use the Schedule options in the bottom toolbar of the
Status page to schedule events to be executed at specified times on display devices connected
to the RJ-45 Output ports on the front panel (see the OUTPUT Ports (RJ-45) section on
page 5). For example, you could create a scheduled port control event that causes the display
devices connected to Outputs 1-4 to power-up and/or power-down at scheduled times each
day.
See the Scheduling Output Device Control Events section on page 51 for details.
Scheduled Input Controls - Use the Schedule options in the top toolbar of the Status page to
schedule inputs (devices connected to the Input connectors on the rear panel of the UDM) to
be displayed on specific Ports (via the UDM receivers connected to the Output ports on the
front of the UDM) at specified times. For example, you could create a scheduled input event
that causes the device connected to Input A to automatically display on Port 1 every day at
9:00am.
See the Scheduling Inputs section on page 53 for details.
UDM-0404 4x4 Multi-Format Distribution Hub
47
Configuration - Schedule Page
Preset Scheduling - Multiple scheduled events can be combined into a single Preset
Checking the Hub Time
Click on the date and time at the top-right of the Status page to refresh the UDM’s internal clock to the
current time (FIG. 52). This can be useful before creating a scheduled event.
FIG. 52 Hub Date and Time
Scheduling IR Device Control Events
Use the Schedule options in the Devices page (bottom toolbar) to create a scheduled IR Device Control
Event (FIG. 53):
Schedule. For example, you could create a Preset Schedule that powers up devices 1-4
(connected to the IRTX Ports on the rear panel), then powers up display devices 1-4
(connected to the RJ-45 Output ports on the front panel), and displays Inputs 1-4 on Ports 1-4.
See the Preset Scheduling section on page 55 for details.
48
IR Device Control toolbar
FIG. 53 Devices page
1. Select up to two commands to be executed from the 1st and 2nd Control drop-down menus at the
bottom of the Devices page (FIG. 54).
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
Select command #1
Select command #2
FIG. 54 Commands to be executed
2. Select the device(s) to which the command should be sent by clicking on the relevant Include
checkboxes (FIG. 55).
FIG. 55 Devices 1 and 2 selected to receive the specified controls
To test the selected commands with the selected Ports, click on the Send To Included link at the
bottom of the Devices page (FIG. 56). Note that clicking here sends the commands to the selected
Ports, but does not schedule the commands,
FIG. 56 Send To Included link
UDM-0404 4x4 Multi-Format Distribution Hub
49
Configuration - Schedule Page
3. Click the Schedule link at the bottom of the Devices page to schedule the specified commands for
the selected Devices (FIG. 57).
FIG. 57 Schedule link
4. This invokes the Schedule page. The commands(s) and Port(s) selected in the Status page will
automatically appear in the scheduled event (FIG. 58).
FIG. 58 Schedule page (indicating "Pwr On" and "Play" commands, and Ports 1 and 2
5. Name the scheduled event in the text field provided.
6. In the Frequency drop-down menu, select a frequency for the scheduled event, and enter the time for
the event to occur in the text fields provided (FIG. 59).
Enter name for scheduled event here
Portscommands
Enter a time for the scheduled event here
Select a frequency for
the scheduled event
FIG. 59 Selecting the event frequency and time
Refer to the Scheduling Events - Frequency Options section on page 56 for a
description of each frequency option.
Click the Add link (see FIG. 59) to add the schedule to the list of scheduled events (FIG. 60).
7.
FIG. 60 Scheduled event added
8. Click the event’s Enabled checkbox (FIG. 61).
Enabled Scheduled Event
FIG. 61 An enabled schedule
50
Once enabled, the scheduled event will execute at the specified time/frequency.
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
Scheduling Output Device Control Events
Use the Schedule options in the bottom toolbar of the Status page to schedule events to be executed at
specified times on display devices connected to the RJ-45 Output ports on the front panel (FIG. 62).
Output Device Control toolbar
FIG. 62 Status page
1. Select up to two commands to be executed from the 1st and 2nd Control drop-down menus at the
bottom of the Status page (FIG. 63).
Select command #1
Select command #2
FIG. 63 Commands to be executed
UDM-0404 4x4 Multi-Format Distribution Hub
51
Configuration - Schedule Page
2. Select the Ports(s) to which the command should be sent by clicking on the relevant Include
checkboxes (FIG. 64).
FIG. 64 Devices 1 and 2 selected to receive the specified controls
3. Click the Schedule link at the bottom of the Status page to schedule the specified commands for the
selected Devices (FIG. 65).
FIG. 65 Schedule link
4. This invokes the Schedule page. The commands(s) and Port(s) selected in the Status page will
automatically appear in the scheduled event (FIG. 66).
Enter name for scheduled event here
Portscommands
FIG. 66 Schedule page (indicating "Pwr On" and "Play" commands, and Ports 1 and 2
5. Name the scheduled event in the text field provided.
6. In the Frequency drop-down menu, select a frequency for the scheduled event, and enter the time for
the event to occur in the text fields provided (FIG. 67).
Enter a time for the scheduled event here
Select a frequency for
the scheduled event
FIG. 67 Selecting the event frequency and time
Refer to the Scheduling Events - Frequency Options section on page 56 for a
description of each frequency option.
Click the Add link (see FIG. 67) to add the schedule to the list of scheduled events (FIG. 68).
7.
52
FIG. 68 Scheduled event added
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
8. Click the event’s Enabled checkbox (FIG. 69).
Enabled Scheduled Event
FIG. 69 An enabled schedule
Once enabled, the scheduled event will execute at the specified time/frequency.
Scheduling Inputs
Use the Schedule link in the top toolbar of the Status page to schedule Inputs to be displayed on specific
Ports at specified times (FIG. 70).
Inputs Control toolbar
FIG. 70 Status page
1. In the Status page, select the Inputs to which the schedule will be applied from the Included drop-
down menu (FIG. 71).
FIG. 71 Included drop-down menu (Status page)
UDM-0404 4x4 Multi-Format Distribution Hub
53
Configuration - Schedule Page
2. Select the Ports on which the input will be displayed by clicking on the Include checkbox at the
relevant ports. The selected ports are highlighted in blue (FIG. 72).
FIG. 72 Selecting the ports on which the input will be displayed
3. Click on the Schedule link at the top of the page (FIG. 73).
FIG. 73 Click the top Schedule link to access the Schedule page
4. This invokes the Schedule page. The Input(s) and port(s) selected in the Status page will
automatically appear in the scheduled event (FIG. 74).
Input Ports
Enter name for scheduled event here
Preset toolbar
54
FIG. 74 Schedule page (indicating Input "A1" and Ports 1 and 2
5. Name the scheduled event in the text field provided.
6. In the Frequency drop-down menu, select a frequency for the scheduled event, and enter the time for
the event to occur in the text fields provided (FIG. 75).
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
Enter a time for the scheduled event here
Select a frequency for
the scheduled event
FIG. 75 Selecting the event frequency and time
Refer to the Scheduling Events - Frequency Options section on page 56 for a
description of each frequency option.
7. Click the Add link (see FIG. 75) to add the schedule to the list of scheduled events (FIG. 76).
FIG. 76 Scheduled event added
8. Click the event’s Enabled checkbox (FIG. 77).
Enabled Scheduled Event
FIG. 77 An enabled schedule
Once enabled, the scheduled event will execute at the specified time/frequency.
Each new scheduled event is displayed on the Schedule page.
Preset Scheduling
It is possible to create a scheduled Preset (or Combination) event - events based on schedules already
created (such as combining two or more existing events), via options in the Schedule page.
1. In the Schedule page (which displays a listing of all currently scheduled events), click each
schedule’s Preset link (FIG. 78).
FIG. 78 Schedule page - Preset links
2. The individual scheduled event numbers appear in the Preset toolbar at the bottom of the page
(FIG. 79).
3. Specify a frequency for the Preset event by selecting from the Frequency drop-down menu
(FIG. 79).
4. Enter a Tim e for the Preset event by typing directly into the text fields provided (FIG. 79).
UDM-0404 4x4 Multi-Format Distribution Hub
55
Configuration - Schedule Page
Enter Preset name
Schedule numbers
FIG. 79 Schedule page - Preset toolbar
Select frequency
Enter time
Add Preset event
The Frequency and Time specified here overrides any previously created frequency /
times used in the Preset schedule.
5. If an interval is required between each individual schedule within the Preset schedule, specify a time
interval (in minutes) in the Interval field (FIG. 79).
6. Assign the Preset schedule a unique name by replacing the default text (FIG. 79).
7. Finally click the Add hyperlink button. The Preset event should now appear in the event list.
8. Enable the event also by clicking on the tick box beneath the Enable column beside the
combination event (FIG. 80).
Enabled Scheduled Event
FIG. 80 Enabling a Preset schedule
No tick box appears to the left of the combined event as several combined events can
not be added together.
Scheduling Events - Frequency Options
A scheduled event can execute in a number of ways, according to the frequency option selected in the
Frequency drop-down menu:
Scheduled Events - Frequency Options
Hour: Event happens at a specified time and then every 60 minutes.
Day: Event happens at a specified time and then every 24 hours.
Weekday: Event happens at a specified time and then every 24 hours
(Monday through Friday).
Sunday: Event happens every Sunday at specified time.
Monday-Saturday: As with Sunday.
56
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Schedule Page
Configuring the UDM-RC02 Remote Control for Scheduling
Ensure the relevant schedules have been defined before assigning schedules to the
UDM-RC02 Remote Control.
1. In the Status page, click the appropriate Port name hyperlink to access the Port Configuration
options shown in FIG. 81:
FIG. 81 Port Configuration options
2. Click on the User Control link at the top right of the page (see FIG. 81). This invokes the Control
Options page for the selected Port (FIG. 82).
FIG. 82 Control Options page
3. Keys 0 to F represent the keys on the UDM-RC02 Remote Control. For each Key, select the
schedule (from the Schedule drop-down menu) to be issued by the selected Key on the UDM-RC02
Remote Control (FIG. 83).
UDM-0404 4x4 Multi-Format Distribution Hub
57
Configuration - Schedule Page
FIG. 83 Control Options page - Schedule drop-down menu
Ensure the correct key on the UDM-RC02 Remote Control corresponds with the
correct schedule.
4. The Receiver will now accept the relevant command from the UDM-RC02 Remote Control.
For each Device selected, you must specify a
Protocol from the Protocol drop-down menu
(Protocols are not used for Ports)
58
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Protocols Page
Overview
Protocols for serial and infrared devices used in the system can be created via options in the Protocols
page. These protocols allow the UDM-0404 to control serial and infrared devices connected via the Hub.
To access the Protocols page from any other Configuration page in the WebConsole, click on the
Protocols link in the navigation pane (FIG. 84).
Configuration - Protocols Page
FIG. 84 Protocols Page
For Serial devices the following information is key to the successful function of the serial device;
Serial cable and pinouts;
Serial settings for correct communication with the device and
Manufacturer’s command strings equivalent to the command to be executed from the
UDM-0404.
For IR devices the device’s IR controls (remote control key presses) will have to be learned by the
UDM-0404.
Creating a Serial Protocol
1. Open the Serial Protocol drop-down menu, and select New (FIG. 85).
FIG. 85 Serial Protocol drop-down menu
This action invokes several additional fields: Name, Settings and Initialise (FIG. 86):
FIG. 86 Creating a new serial protocol
UDM-0404 4x4 Multi-Format Distribution Hub
59
Configuration - Protocols Page
2. Name the serial protocol appropriately and assign the protocol Settings (baud rate and parity).
When configuring the serial settings "OP" means Odd, Parity and "EP" means Even,
Parity.
3. Click on Initialise to clear the UDM Receiver of any pre-loaded serial commands, and invoke the
Action options shown in FIG. 87.
FIG. 87 Creating a serial command for the action
4. Select an Action to be performed from the Action drop-down menu (FIG. 88).
Click to add this Action/Serial command
string to the new Serial protocol
Type the serial command string associated
with the selected Action in this text field
FIG. 88 Creating a serial command for the action
5. Enter the serial command (serial string) equivalent for this action in the Serial command text field.
The serial string which reflects the action has to be accurate for the serial command
to work. Consult the Manufacturer’s web site or documentation to ascertain the
correct string for this serial device.
6. Click Add to create the new protocol.
7. Repeat if necessary for other serial commands which are to be stored under this protocol name.
Once complete, the protocol can be assigned to relevant devices.
It is presumed that the serial device connected to the Endeleo RX has the
appropriate serial settings as described and the correct serial cable/pinouts
configured in order to function correctly with the Receiver.
60
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Protocols Page
Updating the UDM Receiver With the Serial Protocol
The UDM-RX02 Receiver which will issue the relevant serial commands to the device must be
connected to the UDM-0404’s relevant port (via Cat5/e/6 cable). Once the Serial Protocol and
commands have been created, follow these steps to update the connected UDM Receiver with the new
protocol:
Remember the serial commands are stored within the UDM Receiver.
1. On the Status page (see FIG. 15 on page 23), click on the port number (hyperlink) to which the
serial device is attached. This invokes the Port Configuration options for the selected Port.
It is the Endeleo Receiver which will issue the serial command over the serial cable
connected between the Receiver and the device.
2. Click on the Protocol drop-down menu (FIG. 89).
Select the Serial protocol to
download to the UDM Receiver
connected to this Port
FIG. 89 Port Configuration options - Protocol drop-down menu
3. Select the Serial protocol which this UDM Receiver will download. This may take a few minutes
depending on how many commands are within the protocol.
4. A message will appear saying “Loading Protocol – Please wait”. Once this has disappeared the
Serial protocol has been downloaded to the UDM Receiver. Commands can now be sent from the
Hub WebConsole to the serial device.
A new table for this device’s Serial control is what is actually being created. When the
administrator decides to create further commands particular to this serial device they
will be stored within this table e.g power off, power on. If new commands are to be
created in future ensure the correct Serial Protocol has been selected before defining
new commands to ensure commands are stored in the correct table. There is one
protocol/table per UDM Receiver.
UDM-0404 4x4 Multi-Format Distribution Hub
61
Configuration - Protocols Page
Creating and Learning an IR Protocol
IR protocols can be learned by the UDM-0404 by using the device’s remote control to program its
commands into the UDM-0404. This is performed via options in the Protocols page.
The device’s own remote control can still be used locally at the device to control the
device.
The UDM-0404 can learn between 8 and 25 IR commands, depending on the command length and
protocol used.
IR Learning with a Device’s Remote Control
In the Protocol page, open the IR protocol drop-down menu, and select New (FIG. 90).
1.
FIG. 90 IR Protocol drop-down menu
This action invokes two additional fields: Name and Initialise (FIG. 91):
FIG. 91 Creating a new IR protocol
2. Name the IR protocol appropriately, and click on Initialise.
3. Select the action which is to be performed from the Action drop down menu (e.g. vol up - FIG. 92).
FIG. 92 IR protocol - Action drop-down menu
Ensure the device’s remote control is pointing to the IR sensor located at the front of
the UDM-0404 when performing key presses. If not the key presses may not be
stored in the UDM-0404.
62
4. Click on Step 1 (FIG. 93).
FIG. 93 Capturing IR Protocol - Step 1
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Protocols Page
5. A message saying Press key on remote will appear (FIG. 94).
FIG. 94 Capturing IR Protocol - "Press key on remote"
6. Click the key on the device’s remote control which will manage the action Power O n .
7. Click on Step 2 to repeat the process for this command.
8. A message saying Press key on remote will appear. Click the key on the device’s remote control
which will manage the action Pow e r On.
The IR learning process requires that the command on the device’s remote is learned
twice (i.e the same remote control command needs to be repeated at Step 2).
Updating the UDM Receiver With the IR Protocol
A UDM-RX01/02 Receiver, which will issue the relevant IR commands to the device,
must be connected to the relevant port via a Cat5/e/6 cable. Remember the IR
commands are stored within the Receiver.
1. Ensure the Infrared Protocol has been created previously.
2. Click on the Status page.
3. Click on the port number hyperlink which the device is attached to. It is the Receiver which will
transmit the IR command to the devices IR interface.
4. Once the port properties become visible click on the arrow to the right of the Protocol field.
5. Select the IR protocol which this Receiver will download. This may take a few minutes depending
on how many commands are within the table.
6. A message will appear saying “Loading Protocol – Please wait” once this has disappeared the IR
protocol has been downloaded to the RX device. IR commands can now be sent from the Hub Web
pages to the device.
Testing Serial Control Commands
Device serial codes can be tested via options in the Status page, before they are added to the protocol
library.
Serial commands are stored in the UDM-RX02, and care should be taken to keep any
serially programmed units associated with the correct display device type.
The UDM-RX02 can store approximately eight serial commands per device, depending on the length of
the serial string.
1. On the Status page. click on a Port hyperlink to access the Port Configuration options.
2. In the Protocol drop-down menu, select Serial to enable the Serial-specific configuration options
shown in FIG. 95.
UDM-0404 4x4 Multi-Format Distribution Hub
63
Configuration - Protocols Page
FIG. 95 Serial configuration options
Any serial protocols that have been created previously are also available via this
drop-down menu. Refer to the Creating and Learning an IR Protocol section on
page 62 for details.
3. Select the appropriate Baud Rate and Parity settings from the drop-down menus.
4. Click on Initialize to initialize the UDM-RX02.
5. Enter the serial string equivalent to perform the desired control function in the Serial Command text
field (see FIG. 95).
The UDM-0404 supports a predetermined set of actions (commands), against which you can
associate serial strings. For a listing of supported commands, check the Control drop-down menu.
Either enter ASCII text directly into the serial command box or where a HEX code is required.
Precede the double-digit HEX code with a “%” symbol.
The example below (FIG. 96) is from a Panasonic screen where the actual command string requires
a “Start of Text” header (stx), the character command POF (Power Off) and a “End of Text” header
(etx).
Both the headers have therefore been added in HEX and the character string uses ASCII.
Select Baud Rate
Select Parity
Click to initialize the UDM-RX02
Enter Serial command string
Test the entered command
FIG. 96 Panasonic screen - command screen
6. Once you have finished entering the string you can test that it operates as expected, via the Te st
hyperlink. This sends the string typed into the Serial Command text box to the device connected.
Repeat the process as many times as required to test a complete set of controls before saving them to the
protocol library.
Examples of Serial Controls
Screen Type Command Ascii code Hex code
NEC 30/40” LCD Power Off 00!%0D %00%00%21%0D
Power On 00”%0D %00%00%22%0D
CVBS Input Select 00_v1%0D %00%00%5f%76%31%0D
DSR Data Set Ready
Panasonic Power Off %02POF%03 %02%50%4F%46%03
The video mode select commands (VGA select etc.) are extremely useful commands and enable a serial
string to be associated with a change of input type, allowing a display automatically switched to the
appropriate input port on a change of the video type from the UDM-0404.
See the Ascii / Hex Conversion section on page 91 for details.
64
UDM-0404 4x4 Multi-Format Distribution Hub
Configuration - Protocols Page
Deleting Protocols
Protocols can be deleted individually by type (Delete) or all protocols can be removed from the UDM0404 (Delete all) i.e. all serial and all Infrared protocols can be deleted using Delete All.
1. Click on the Protocols option.
2. To delete a protocol click the Delete hyperlink in the serial section to delete a serial protocol or click
the Delete hyperlink in the Infrared section to delete an infrared protocol.
The last created or currently highlighted serial or infrared protocol will be deleted
when using the Delete hyperlink.
Deleting All Protocols (Serial and IR)
All protocols can be deleted from the UDM-0404.
1. Click on the Protocols option.
2. To delete all protocols click the Delete all hyperlink in the Serial section i.e. the top half of the
screen. This deletes all Serial and all Infrared protocols.
UDM-0404 4x4 Multi-Format Distribution Hub
65
Configuration - Protocols Page
66
UDM-0404 4x4 Multi-Format Distribution Hub
Advanced Administration
Overview
System upgrades of the UDM-0404 can be performed following consultation with Endeleo support.
Upgrade files can be downloaded from the Endeleo web site.
Tools required to perform system upgrades include;
TFTP client
Necessary files (e.g. RX firmware, Hub Firmware, Port Controller, Web Pages, Input Ports,
EPLDs)
Working knowledge of UDM-0404.
Due to changes in Web page and hub files since a previous download, loading new
web page, configuration, or hub files may require a complete reinstallation of all
pertinent firmware. If the latest Web page or hub file version number does not match
the UDM’s firmware version number, reloading the latest firmware file, configuration
file, and web page file may be necessary
Upgrading Firmware and Web Pages On a UDM-0404
The following procedures can also be used to upgrade the Web Page archive on the UDM-0404. Replace
filenames appropriately.
Advanced Administration
Firmware Update
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
Obtain the firmware and Web Pages files and store them in a directory or folder on your PC. For
example, create C:\UDM\Hub.
1. Run your TFTP client. If using the Windows client, move to step 2.
2. For the Windows TFTP client, start a command session on the PC. Change to the directory where
the .ROM files are stored on the PC (e.g. cd\udm and cd\hub).
3. Type in the following command at the prompt, observing the parameters below:
TFTP -i [ip address of UDM-0404UDM-0404] PUT [filename.ROM]
For example, typing in TFTP -i 192.168.0.96 PUT F03121614300.ROM will upload the file
F03121614300.ROM to the UDM-0404 with IP address 192.168.0.96.
FIG. 97 Issuing TFTP commands to the Hub
4. Press Enter to execute the command.
5. A successful transfer message should be returned. This may appear after a minute or so, depending
on the network environment and the size of the file.
6. The network connection to the hub will be broken as the hub will reset. It is recommended that the
hub is powered off and then powered on at this point.
UDM-0404 4x4 Multi-Format Distribution Hub
67
Advanced Administration
7. The command window can be closed, or you may continue on to the Web Interface file.
Web Interface Update
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
Obtain the firmware and Web Pages files and store them in a directory or folder on your PC. For
example, create C:\UDM\Hub.
1. Run your TFTP client. If using the Windows client, move to step 2.
2. For the Windows TFTP client, start a command session on the PC. Change to the directory where
3. Type in the following command at the prompt, observing the parameters below;
4. Press Enter to execute the command.
5. A successful transfer message should be returned. This may appear after a minute or so, depending
6. The network connection to the hub will be broken as the hub will reset. It is recommended that the
7. The command window can be closed, or you may continue on to the Web Interface file.
the .ROM files are stored on the PC:
e.g. cd\udn and cd\hub.
TFTP -i [ip address of UDM-0404] PUT [filename.ROM]
For example, typing in TFTP -i 192.168.0.96 PUT C03121614300.ROM will upload the file
C03121614300.ROM to the UDM-0404 with IP address 192.168.0.96.
on the network environment and the size of the file.
hub is powered off and then powered on at this point.
Upgrading Port Controllers
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
1. Obtain the Port Controller file and store it in a directory or folder on your PC. For example, create
C:\UDM\Port.
2. Run your TFTP client. If using the Windows client, move to step 2.
3. Start a command session on the PC. Change to the directory where the .ROM files are stored on the
PC:
e.g. cd\udm and cd\port
4. Type in the following command at the prompt, observing the parameters below;
TFTP -i [IP address] PUT [filename].[portnumber]
For example, typing in TFTP -i 192.168.0.96 PUT R26201610800.001 will upload the file
R26201610800 to port 1 on the UDM-0404 with IP address 192.168.0.96.
5. Push Enter to execute the command.
6. Upload the file to any other ports requiring this upgrade by changing the last 3 digits of the
command to the relevant port number. For example, enter TFTP -i 192.168.0.96 PUT
R26201610800.002 to upload the file to port 2 on the UDM-0404 with IP address 192.168.0.96.
7. The command window can be closed.
68
UDM-0404 4x4 Multi-Format Distribution Hub
Advanced Administration
FIG. 98 Issuing TFTP commands to the UDM Receiver via the UDM-0404
Copying the Hub Configuration File
Copying the Hub Configuration file permits the Administrator to make backups of key data entered by
Administrators, such as Input names, Port names, Devices and the Hub setup.
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
Create a directory or folder on the PC to store the configuration file. For example, create
C:\UDM\Config.
To backup the Hub Configuration file:
1. Run your TFTP client. If using the Windows client, move to step 2.
2. Start a command session on the PC. Change to the directory where the Hub Configuration file is to
be stored on the PC:
e.g. cd\udm and cd\config.
3. Type in the following command at the prompt, observing the parameters below:
TFTP -i [IP address] get hxxxxx.hub
Where hxxxxxx.hub is the name of the hub configuration file.
The file name must start with an h.
If the name of the Hub Configuration file is not known, typing in h followed by any logical
characters will find the file, as only one file beginning with h is in the UDM-0404.
Use a name that will identify the hub configuration file for the project. For example,
hmyproject.hub is an acceptable name.
4. When complete, close the command window.
Restoring the UDM-0404 Configuration File
Run your TFTP client. If using the Windows client, move to step 2.
1.
2. Start a command session on the PC. Change to the directory where the Hub Configuration file is to
be stored on the PC:
e.g. cd\udm and cd\config.
3. Type in the following command at the prompt, observing the parameters below:
TFTP -i [IP address] put hxxxxx.hub
UDM-0404 4x4 Multi-Format Distribution Hub
69
Advanced Administration
Restoring the hub configuration file can cause the UDM-0404 web pages to be
damaged. Follow the direction for loading the web pages to restore the damaged file.
4. When complete, close the command window.
Loading the Hub Configuration File On the UDM-0404
1.
2. Start a command session on the PC. Change to the directory where the .ROM files are stored on the
3. Type in the following command at the prompt, observing the parameters below;:
4. Once the command has been typed in, push Enter to execute the command.
5. Upload the file to any other ports requiring this upgrade by changing the last 3 digits of the
6. The command window can be closed.
Where hxxxxxx.hub is the name of the hub configuration file.
Hub configuration file names start with an h.
Run your TFTP client. If using the Windows client, move to step 2.
PC:
e.g. cd\hub.
TFTP –i [ip address of UDM-0404] PUT [filename.ROM].
For example, typing in TFTP –i 192.168.0.96 PUT FUDM129.ROM
will upload the file FUDM129.ROM to the UDM-0404 with IP address 192.168.0.96.
command to the relevant port number.
For example, type TFTP –i 192.168.0.96 PUT R26201610800.002 to upload the file to port 2 on
the UDM-0404 with IP address 192.168.0.96.
Copying Protocols Between UDM Receivers
Once protocols have been learned by the Hub through the Web browser, they will remain on the Hub.
Protocols are assigned to individual UDM Receivers (UDM-RX01) by using the Web interface pages.
The protocols can be transferred between UDM-0404s by using the TFTP file transfer utility.
All learned protocols are stored in the hub in a file starting with either an i or an s.
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
Retrieving IR Files From the UDM Ports
Run your TFTP client. If using the Windows client, move to step 2.
1.
2. Create a folder on the C: drive named RX.
3. Browse the new RX folder with your TFTP client.
4. At the command prompt, type the following command to retrieve an IR/Serial file from the
UDM Receiver connected to port 1:
C:\RX\ TFTP –i <ip address of hub> get iname.001 <enter>
Example:
C:\RX\ TFTP –i 192.168.0.96 get isony.001 <enter>
5. To get a file off the RX connected to port 4 use this command:
C:\RX\ TFTP –i 192.168.0.96 get isony.004 <enter>
The file name you create must start with an “i” and end in an extension from .001 to .004.
6. To put the file onto another Receiver on the same hub you must first copy the newly created file to
all extensions (.001 - .004), or at least the extension of the port to which the RX is connected.
C:\RX\ copy isony.001 isony.002 <enter>
70
UDM-0404 4x4 Multi-Format Distribution Hub
Advanced Administration
7. Repeat for other extensions:
C:\RX\ copy isony.001 isony.003 <enter>
C:\RX\ copy isony.001 isony.004 <enter>
8. Use the put command to send to the RX units on the other hub ports that need the IR/Serial file.
C:\RX\ TFTP –i 192.168.0.96 put isony.002 <enter>
Once an IR protocol has been learned for a specific port, it can simply be copied across to other
ports using the TFTP application and the network port. To copy an IR protocol to another port:
9. Create a directory or folder on the PC to store the protocol file. For example, create
C:\UDM\Protocol
10. You must GET the IR file from the Receiver via the hub. IR files all start with an I and use a file
extension to indicate number. These could therefore take the form isonymode1.001, IRtable.001 etc.
11. At the command prompt use the following command:
TFTP –I [IP address of hub] GET irtable.hub
Entering the extension ".hub" will download the hub configuration file, which will
capture such data as the input configuration, setup information, input and port
names, and the protocol files. The same file is used for serial (s) or IR (i) protocols.
Backing up the Hub Configuration File
1.
Run your TFTP client. If using the Windows client, move to step 2.
2. Start a command session on the PC. Change to the directory where the Hub Protocol file is to be
stored on the PC:
e.g. cd\udm and cd\protocol.
3. Type in the following command at the prompt, observing the parameters below:
TFTP -i [IP address] get ixxxxx.hub or TFTP -i [IP address] get sxxxxx.hub
Where ixxxxxx.hub is the name of the hub configuration file.
The file name must start with an i or an s.
If the name of the Hub Protocol file is not known typing in i or s followed by any logical characters
will find the file, as there is only one protocol file in the UDM-0404.
A file name starting with either i or s will retrieve that file. Use a name that will identify the protocol
file for the project. For example: imyprotocol.hub is an acceptable name.
4. When complete, close the command window.
Restoring the Hub Configuration File
1.
Run your TFTP client. If using the Windows client, move to step 2.
2. Start a command session on the PC. Change to the directory where the Hub Configuration file is to
be stored on the PC:
e.g. cd\udm and cd\protocol.
3. Type in the following command at the prompt, observing the parameters below:
TFTP -i [IP address] put ixxxxx.hub
-or-
TFTP -i [IP address] put sxxxxx.hub
Where ixxxxxx.hub is the name of the hub protocol file.
All hub protocol file names start with an i or s.
4. When complete, close the command window.
5. When the protocol file is restored, it will usually automatically associate correctly with the
configuration file when it is restored. However, it is wise to check each UDM port using the Web
interface to verify the correct protocol is assigned.
UDM-0404 4x4 Multi-Format Distribution Hub
71
Advanced Administration
Upgrading Input Controllers
Input Controllers are numbered .001 to .004 and identified by the letter u before the
filename.
1. Run the TFTP client.
2. Start a command session on the PC and change to the directory where the .ROM files are stored on
3. Type in the following command at the prompt observing the parameters below;
4. Push Enter to execute the command.
Backend Commands
In case of human error the Command Line can be used to perform several Administrative tasks on the
multi format video hub.
Changing the Login Password
the PC e.g. cd\hub.
TFTP –i [IP address] PUT u[filename].[portnumber]
For example typing in TFTP –i 192.168.0.96 PUT ufilename.001 will upload the Input controller
file to Input 1 on the UDM-0404 with IP address 192.168.0.96.
Create a hyperterminal session with the UDM-0404 using default serial connections.
1.
2. To change the password enter the original password and new password separated by a colon at the
login prompt.
For Example type in admin:endeleo at the login prompt, to change the password from admin to
endeleo.
3. Reset the Hub. A power off then on is now required.
Obtaining the UDM-0404’s IP Address Via the Command Line
Type i at the command prompt. (FIG. 99) Push enter.
1.
FIG. 99 Issuing the i command
Checking Port Details
Port details (resolution, port firmware) can be checked via the command line also.
Multi Format Inputs
The multi format inputs located at the rear of the Hub are numbered 129 through to 132 for
administrative purposes.
72
Multi format inputs
Input Input Number
A 129
B 130
C 131
D 132
UDM-0404 4x4 Multi-Format Distribution Hub
Advanced Administration
1. To check the input port configuration, type in the following – a question mark followed by the Input
Number (129, 130, 131 or 132):
Example: ? 129
2. Push Enter.
3. The following information will be displayed (FIG. 100);
FIG. 100 Querying a multi format input port
The table below describes typical values returned when using the ? command on an input port.
Multi-Format Input Configuration
Value Description
129 Input A
00.06.00 Input Controller Version
XGA Extended Graphics Array
1024x768 Screen Resolution
799 Vertical lines on screen
H+ Horizontal polarity (+/-)
V+ Vertical polarity (+/-)
User Outputs
To view a port’s properties, type a question mark before the port number.
1.
Ensure there is a space between the question mark and the number. (FIG. 101)
For example ? 1 will display Port 1 properties.
FIG. 101
Querying a port
2. Push Enter once the command has been entered.
3. The table below describes typical values returned when using the ? command on a Hub port.
Value Description
Port 1 Port number on UDM-0404
01.11.00 Port Controller version
Clock Master 8406 Master (version)
Disconnected / Connected Connected to RX
Port Power On or Off
Port Number Checksum Port in Master or Slave hub
UDM-0404 4x4 Multi-Format Distribution Hub
73
Advanced Administration
Copying IR/Serial Tables
To copy the IR/Serial tables from a UDM-0404:
Windows XP Pro has a built in TFTP client program. If you are using another
operating system, or have an alternate TFTP client, follow the directions of your OS
and install TFTP client if necessary. Consult with AMX Technical Support as to the
appropriate client for your OS.
1. Run your TFTP client. If using the Windows client, move to step 2.
2. Create a folder on the C: drive named Endeleo.
3. Open a command prompt (Start, Run, type "cmd" <enter>) and change it to the C:\Endeleo
4. Connect the serial cable (RJ12 to DB9) that is supplied with the UDM-0404.
5. Open a Hyperterminal session and connect to the UDM-0404 (9600, 8, None,1, None)
6. Type the following command at the prompt:
directory.
TFTP -i <ip address of the UDM-0404> get ixxxx.hub <enter>
Example:
C:\Endeleo\TFTP -i 192.168.1.201 get iudm.hub <enter>
FIG. 102 GET iudm.hub prompt
7. After hitting Enter, you should watch the Hyperterminal session window to see the file download
from the UDM-0404.
FIG. 103 File download from the UDM-0404
8. The transfer is now complete.
Endeleo UDM Receiver Commands
Several Receiver-specific commands can be used for information purposes.
Viewing Video Compensation Settings
The z command will report the current compensation settings configured within the UDM Receiver.
1. Use Hyperterminal to connect to the Receiver via its serial port.
2. At the command prompt type in setup.
3. Once in setup mode to view the compensation settings, type in z. (FIG. 104)
74
UDM-0404 4x4 Multi-Format Distribution Hub
FIG. 104 Video Compensation Settings
Resetting Video Compensation Settings
The x command resets all compensation settings at the Receiver back to default.
1. Use Hyperterminal to connect to the Receiver via its serial port.
2. At the command prompt type in setup.
3. Once in setup mode type in x to reset the compensation settings if required.
Advanced Administration
UDM-0404 4x4 Multi-Format Distribution Hub
75
Advanced Administration
76
UDM-0404 4x4 Multi-Format Distribution Hub
Endeleo IR Codes
Overview
The following is a list of IR Codes used by Endeleo in learning serial or IR controls for display devices.
Note that several of the items in the following table are not represented in the Action drop-down menus
for IR and Serial protocols (in the Web Configuration Interface).
For example, “AV SELECT 1" is available in the Action drop-down menu (see “A/V Sel”), and needs no
custom code reference. However, a custom command like “AV SELECT 2" would be only be accessed
by Custom 31, since this command is not represented in the Action drop-down menu options.
IR code Description IR code Description
0-9 Keys 0 to 9 52 Cursor up *
10 Channel up * 53 Cursor down *
11 Channel down * 54 Cursor left *
12 Power Off 55 Cursor right *
13 Mute 56 Esc
14 Volume up 57 Info
15 Volume down 58 Help
16 Program up 59 Teletext *
17 Program down 60 Services *
18 10+ key (for two digit channel entry) 61 Box office *
20 Channel restore (back) * 62 Interactive *
21 Power On 63 TV guide *
30 A/V select 1 64 Red *
31 A/V select 2 * 65 Green *
32 A/V select 3 * 66 Blue *
40 Device select (DVD/VCR) * 67 Yellow *
41 Enter * 70 Play
42 Clear
44 TV Input
45 TV Power
46 Live TV
47 Thumbs up
48 Thumbs down
50 Menu 80 Select pass through *
51 Select Function 81 Cancel pass through *
* 71 Pause
Endeleo IR Codes
*
* 72 Stop
* 73 Record
* 74 Fast forward
* 75 Rewind
* 76 Slow *
90 -99 Custom 1... through to Custom 10
An asterisk in the Description column for any IR Code in this table indicates that the
command will require custom code (since the command is not represented in the
Actions list.
UDM-0404 4x4 Multi-Format Distribution Hub
77
Endeleo IR Codes
78
UDM-0404 4x4 Multi-Format Distribution Hub
UDM Hub Control Protocol
Overview
The information in this section applies to UDM-0404, UDM-1604 and UDM-1604C
Hubs.
The UDM Hub often forms part of a larger system where control of switching and management functions is
provided by an external system (for example, AMX or Crestron controllers).
This section describes the protocol for communications between the management software and the UDM hub
using either a 10BaseT network connection or a SLIP encapsulated serial stream to the console port. It also
describes (where applicable) the commands usable by a user with a terminal connection to the console port.
Unless otherwise specified, all data and command values are shown in decimal
(base 10).
UDP (Ethernet) vs SLIP (RS-232) Communication
The UDM hub communicates over a 10BaseT connection using UDP packets or over a serial link using UDP
packets encapsulated using SLIP. In both cases, the UDM hub accepts a set of command and data values to
carry out various actions, which are detailed in this section.
These command and data values are encapsulated in a frame for transmission from the host to the hub. In most
cases this encapsulation will be provided by the host software, but in the case of simple SLIP commands, it
might have to be supplied by the customer software or driver.
By default, the UDM Hub is configured for UDP (Ethernet) communication.
To use SLIP (RS-232) communication, the Authenticate SLIP option on the Setup web
configuration page must be enabled (FIG. 105):
UDM Hub Control Protocol
FIG. 105 Setup Page - Authenticate SLIP option enabled
By default, the Authenticate SLIP option is disabled, which precludes the use of
RS-232 communication on the Hub.
Beyond enabling the Authenticate SLIP option shown in FIG. 105, the crucial difference between UDP and
SLIP commands is that SLIP commands must be encapsulated with:
SEND_STRING UDM, "$C0"
UDM-0404 4x4 Multi-Format Distribution Hub
79
UDM Hub Control Protocol
For example:
BUTTON_EVENT[dvTP,3] // POWER TV
{
PUSH:
{
SEND_STRING UDM,"$C0" // SLIP command
wait 2
SEND_STRING UDM,"87,$01,$01,$01,$02,21"
wait 4
SEND_STRING UDM, "$C0" // SLIP command
}
}
The waits used in the example above are not required.
By comparison, the equivelant code written for UDP would be:
BUTTON_EVENT[dvTP,3] // POWER TV
{
PUSH:
{
SEND_STRING UDM,"87,$01,$01,$01,$02,21"
}
}
Command Format
UDM commands consist of a command value, together with a number of relevant parameters (normally 6
bytes in total) which are transmitted to the hub, generally described as follows:
Byte #0123456..n
Byte value Command
value
User
defined
Data value 1 Data value 2 Data value 3 Data value 4 Other data
for some
commands
The data packet returned by any command may be longer than described - any additional data in a packet may
be ignored. Some endeleo tools and diagnostics use this extra information, but it is not required for control
purposes
Command and Reply Example - Port Connection
Command values differ for each command as do the values and length of the accompanying data.For example,
to connect port 1 to VGA input 2 on the UDM the command format is as follows:
Byte # 0 1 2 3 4 5
Byte value 1 User defined Port Input Sub Input Input Type
So the data values which must be sent to the hub would be:
Byte # Value Description
0 1 Command value for Connect Input to Port
1 0 User defined - can be any value - this first byte is normally replaced in the reply with a
2 1 Port number
3 2 Input number
4 1 Sub input number (for a VGA input all sub inputs are used in the connection so this value
5 0 VGA type (other types are listed in the command description later in the document)
Status value, other User defined values are just returned unaltered in the reply from the
hub and can be used for checking etc
is not used - it is only important when specifying connections for composite input types)
80
UDM-0404 4x4 Multi-Format Distribution Hub
UDM Hub Control Protocol
The hub replies to all commands, and the reply format are also detailed in this document. For the switching
command described above, the reply would be:
Byte # 0 1 2 3 4 5
Byte value 1 Status Port Input Selected Sub Input Input Type
The reply packet starts with the command value, then a Status value (1 for success, other values are listed in
section 6.0).
The remainder of the reply varies by command, in this case the original parameters are returned, but these may
normally be ignored.
Command and Reply Example - Authentication (Login)
Since the host has to login to the hub before any commands can be executed, this serves as another example.
To login, the command format is as follows:
Byte # 0 1 2 3..n
Byte value 98 User defined Password length Password string
So, assuming a password of 'admin', the data values which must be sent to the hub would be:
Byte # Value Description
0 98 Command value for login
1 0 User defined - can be any value - this first byte is normally replaced in the reply with a Status
value, other User defined values are just returned unaltered in the reply from the hub and can
be used for checking etc
2 5 Length of password string
3 97 First character in password ('a' has an ASCII value of 97 decimal)
4 100 Second character in password ('d' has an ASCII value of 100)
5 109 Third character in password ('m' is ASCII 109)
6 105 Fourth character in password ('i' is ASCII 105)
7 110 Fifth character in password ('n' is ASCII 110)
The hub replies to all commands, and the reply format are also detailed in this document. For the login
command described above, the reply would be:
Byte # 0 1 2 3 4 5
Byte value 98 Status Undefined Undefined Undefined Undefined
The reply packet starts with the command value, then a Status value (1 for success, 70 for incorrect password).
The remainder of the reply varies by command, in this case the original parameters are returned, but these may
normally be ignored.
UDP Over Network (10BaseT) Encapsulation
If the UDM hub is connected using the 10BaseT network connection, then the commands must be sent over
that network. For the network to operate correctly, these commands must be encapsulated in a network packet.
This is normally done transparently by the host software.
The hub communicates over a 10BaseT network over UDP port 2008.
UDM Over Serial Port (SLIP) Encapsulation
The UDP packets may also be transported over a serial connection to the serial port on the hub. The UDP data
is transferred using SLIP (Serial line internet protocol) encapsulation. This scheme is defined in RFC1055, and
involves framing the UDP data using special characters and substitution of special sequences when data may
include the framing characters.
A brief description follows:
Begin and end the data by adding a character with value 192
If the data contains 192 as a valid data value, substitute with the sequence 219, 220
If the data contains the value 219, substitute with sequence 219, 221
UDM-0404 4x4 Multi-Format Distribution Hub
81
UDM Hub Control Protocol
The following example shows SLIP encoding for a UDP packet, showing the start and end characters (192)
and substitution of special sequences when the data includes the start and end characters:
Responses which are SLIP framed will require decoding at the host.
SLIP Serial Communication Example
Typically, host systems may not provide support for SLIP encapsulation, so the host must use the normal
mechanism for sending serial characters, and add the encapsulation. For most commands, this just consists of
adding a 192 character to the beginning of the serial command and one at the end.
For example, assuming that the host has a function call to send a serial character of SendChar() (this will vary
from system to system), then the switching example in 1.2 above would become:
SendChar(192); // send begin character
SendChar(1); // send command value
SendChar(0); // send first parameter (user defined)
SendChar(1); // send second parameter (port number)
SendChar(2); // send third parameter (input number)
SendChar(1); // send fourth parameter (sub input number)
SendChar(0); // send fifth parameter (input type)
SendChar(192); // send end character
The hub would reply with eight serial characters, six for the reply described in this document, together with the
SLIP encapsulation characters of 192 at the beginning and 192 at the end i.e the hub reply string would look
like:
Byte # Value Description
0 192 (equivalent C0 hex) SLIP begin character
1 1 Returned command value
2 1 Status (success)
3 1 Returned port number
4 2 Returned input number
5 1 Returned sub input number
6 0 Returned input type
7 192 SLIP end character
UDP data 17 03 192 69 219 25
SLIP data 192 17 03 219 220 69 219 221 25 192
82
Similarly, the login example in 1.3 above would result in the following. In this example, we have assumed that
the SendChar() command in the host can accept an ASCII value in quotes as well as a decimal number:
SendChar(192); // send begin character
SendChar(98); // send command value
SendChar(0); // send first parameter (user defined)
SendChar(5); // send second parameter (password length)
SendChar('a'); // send third parameter (first character in password)
SendChar('d'); // send fourth parameter (second password character)
SendChar('m'); // send fifth parameter (third password character)
SendChar('i'); // send sixth parameter (fourth password character)
SendChar('n'); // send seventh parameter (fifth password character)
SendChar(192); // send end character
UDM-0404 4x4 Multi-Format Distribution Hub
UDM Hub Control Protocol
Handshaking
Although UDP is not deterministic (there is no guarantee that a UDP packet will be delivered), using UDP
greatly simplifies the stack processing in the hubs. To accommodate UDP, this protocol requires that the hubs
send a completion reply on receipt (and completion) of any command. This is not a great restriction since some
commands may not complete (selection of a disabled input for example) and status must be returned and
decoded anyway.
To facilitate decoding, returned status messages duplicate the command and add a status return value.
Returned status replies can therefore be matched with commands, even if delivered out of order. If a reply is
not received, the sender must retry. Since all commands are stateless, such a simple scheme is adequate.
The command format allows for a number of user-defined bytes to be sent with the command, which will be
returned in the status. These may be used, for example, for sequence numbering or decoding.
Command Set
In each of the following descriptions, only the contents of the UDP data packet are specified.
Authentication
Before any SLIP (ethernet UDP commands do not require authentication) commands can be executed the user
must be authenticated - this uses the same password mechanism as authentication from the console command
line or from a web browser.
This authentication process may be disabled using a Setup web page option.
Authenticate (Login)
Provides authentication information for this UDP session - the password is the same as for web browser and
console sessions (default is admin). If the password is correct, further UDP commands will be accepted.
Currently, the password is unencrypted.
Byte # 0 1 2 3..n
Byte value 98 User defined Password length Password string
Return Status:
Byte # 0 1 2 3 4 5
Byte value 98 Status Undefined Undefined Undefined Undefined
The status value returned is as follows:
Status value Description
1 Command completed successfully
70 Unable to authenticate (password incorrect)
If the session is not logged (hasn't been correctly authenticated) then any command will return a status value of
70.
Logout
Logs the UDP session out - further communications will require a login command to be sent:
Byte #012345
Byte value 97 User Defined User Defined User Defined User Defined User Defined
Return Status:
Byte # 0 1 2 3 4 5
Byte value 97 Status Undefined Undefined Undefined Undefined
The status value returned is as follows:
Status Value Description
1 Command completed successfully
70 System is already logged out
UDM-0404 4x4 Multi-Format Distribution Hub
83
UDM Hub Control Protocol
Command Summary
Command 0 1 2 3 4 5 6
Connect 1 X Port Input
Disconnect 6 X Port
Cascade input select 9 X Input Cascade value
Lock Port 2 X Port
Unlock port 3 X Port
Query port 12 X Port
Get port or input name 79 X Port Sub port Type
Get receiver info 88 X Port
Send remote command 87 X Port Remote
Get remote serial buffer 89 X Port Terminator
Set hub ID 67 X Length of ID string Start of string (data)
Get hub or port ID 78 X Port
UDP
command
Remote
parameters
Reset 99 X 156
Set Protocol 75 X Protocol
Set port range 66 X Min Max
Basic Commands
Input Numbering
The UDM has a flexible architecture to maximise use of the available matrix. The UDM1604 is a 16 output
port hub, with four analog input ports and four TVM input ports. Each analog input port can be used for a
variety of input types, VGA, S-Video, component and composite, and input ports are specified by a main
number, together with a sub input number if the input can be split.
The Input number is specified as follows:
Value Description Value Description
1 Input A 5 TVM input 1
2 Input B 6 TVM input 2
3 Input C 7 TVM input 3
4 Input D 8 TVM input 4
If the Input is of type 1 (composite) then the Sub input field (with values 1,2,3) can further specify which of
the three composite inputs on an Input to use for this connection.
Input A would come from the 'A' labelled VGA connector or if the cascade input is selected for this input,
from the upstream hub.
Port Numbering
There are 16 output ports, numbered 1 to 16.
Connect Input to Port
Selects the input on the ports specified by the Port property, or if non zero, the port specified in the command.
Byte #012345
Byte value 1 User Defined Port Input Sub Input Input Type
84
UDM-0404 4x4 Multi-Format Distribution Hub
UDM Hub Control Protocol
Input type can have the following values:
Value Description
0 VGA
1 Composite (CVBS)
2 S-Video
3 Component analog (YPbPr)
4 TV (from TVM)
Return Status:
Byte # 0 1 2 3 4 5
Byte value 1 Status Port Input Selected Sub Input Input Type
Disconnect Port
Disconnects the current input from the Port specified by the Port property, or if non-zero, from the port
specified in the command.
Byte #012345
Byte value 6 User Defined Port User Defined User Defined User Defined
Return Status:
Byte # 0 1 2 3 4 5
Byte value 6 Status Port User Defined User Defined User Defined
Input Cascade Selection
Each input in the UDM can either come from the VGA connector on the hub or from the cascade connector of
another upstream hub. This command selects this option for each of the four VGA ports.
Byte #012345
Byte value 9 User Defined Input Cascade value User Defined User Defined
Cascade value takes the following values:
Value Description
0 No cascade - VGA input
1 Cascade from upstream hub
Return Status:
Byte # 0 1 2 3 4 5
Byte value 9 Status Port User Defined User Defined User Defined
Lock Port
Locks the port (or range of ports) specified by the Port property, or if non zero, the port specified in the
command, so that the connected input may no longer be changed on that port.
Byte #012345
Byte value 2 User Defined Port User Defined User Defined User Defined
Return Status:
Byte # 0 1 2 3 4 5
Byte value 2 Status Port User Defined User Defined User Defined
The status return is a copy of the command with the first user defined byte replaced
by a status value - status values are described in a separate section.
UDM-0404 4x4 Multi-Format Distribution Hub
85
UDM Hub Control Protocol
Unlock Port
Unlocks the port (or range of ports) specified by the Port property, or if non zero, the port specified in the
command, so that selected inputs on that port may be changed.
Byte #012345
Byte value 3 User Defined Port User Defined User Defined User Defined
Return Status:
Byte value 3 User Defined Port User Defined User Defined User Defined
Query Port
Queries a particular port for connection and status information. The command returns the currently connected
input, and information in the flags byte about current connection status.
Byte #012345
Byte value 12 User Defined Port User Defined User Defined User Defined
Return Status:
Byte value 12 Status Port Input User Defined Flags
The Flags byte contains additional information about the input selected, defined as follows:
Byte #0123 4 5
Byte #0123 4 5
Flag bit Description if set Description if clear
1 Port input selection is locked Port input selection is unlocked
2 Port link disconnected Port link connected
Get Port or Input Name
Retrieves a string identifier from the port specified. Sub port should be specified if the port type is an Input
port as input sub ports may have different names.
Byte #012345
Byte value 79 User Defined Port Sub Port Port Type User Defined
The Port Type parameter can take the following values:
Value Description
1 Output port
2 Video input port
3 Audio input port
4 Device
Return Status:
Byte # 0 1 2 3 4 5 6 7..7+length
Byte value 79 Status Port Sub Port Port Type User Defined Name Length Name String
Get Receiver Info
Retrieves information about the connected receiver on a port.
Byte #012345
Byte value 88 User Defined Port User Defined User Defined User Defined
Return Status:
Byte # 0 1 2 3 4..n
Byte value 88 Status Port User Defined Parameter block
86
UDM-0404 4x4 Multi-Format Distribution Hub
UDM Hub Control Protocol
The parameter block contains at least the following - it may contain extra information, but if not defined here
it can be ignored:
Byte offset (from 4) Receiver information
0 Receiver type
1 Flags
2 Receiver version number - major
3 Receiver version number - minor
Send Remote Command
Sends a command to the Rx (which is normally sent on to the screen or other device connected to the Rx).
Remote command specifies the type of action taken, with optional parameters.
Byte #0123 4 5..n
Byte value 87 User Defined Port User Defined Remote command Remote parameters
Return Status:
Byte # 0 1 2 3 4 5
Byte value 87 Status Port User Defined Remote device command Remote device parameter
All these commands start with the header above (bytes 0-3), but use the remote device command value to
perform separate functions as described below.
Set Remote Device Protocol
Sets the control protocol being used by the remote device. The system treats control codes in a device
independent way, and this parameter allows the translation between the device independent value (see below)
and the code sent to the device. Device address sets the addressing of the protocol (if allowed). This allows the
same protocol to be used for transmit and receive without conflict. If this is zero, then the default (for that
protocol) will be used.
Byte # 4 5 6 7 8
Byte value 1 Control protocol
for transmit
Device address
for transmit
Control protocol
for receive
Device address
for receive
IR protocol values are defined as follows:
IR protocol Description IR protocol Description
1 Table driven (generic) 117 Serial 2400 baud odd parity
2 Sony 118 Serial 4800 baud odd parity
3 NEC (endeleo remote) 119 Serial 9600 baud odd parity
4 Sky 120 Serial 1200 baud even parity
112 Serial 1200 baud 121 Serial 2400 baud even parity
113 Serial 2400 baud 122 Serial 4800 baud even parity
114 Serial 4800 baud 123 Serial 9600 baud even parity
115 Serial 9600 baud 124 Serial 19200 baud
116 Serial 1200 baud odd parity 125 Serial 38400 baud
The table driven protocol output requires that the relevant driver file has been loaded or learnt in the receiver.
Similarly the serial protocol selection requires that a relevant serial protocol driver has been uploaded or learnt.
The protocol selection connects this driver file to the output and sets the baud rate. A serial device driver may
have a variable or fixed baud rate. If it is fixed then all the serial protocol values above are equivalent, if the
driver has a variable rate then the baud rate is set appropriately from the value above.
The default protocol values are 3 (endeleo remote) for reception and 1 (table driven) for transmission.
UDM-0404 4x4 Multi-Format Distribution Hub
87
UDM Hub Control Protocol
Send IR Command To Connected Device
Sends a control command out through the IR blaster or serial port connected to the remote receiver. This is
translated in the receiver to the appropriate control protocol previously selected. The receiver must already be
loaded with the right driver for the codes used, and the device being controlled must allow the necessary
actions.
Byte # 4 5
Byte value 2 IR Code
Device control codes are defined as follows:
IR Code Description IR Code Description
0-9 Keys 0 to 9 57 Info
10 Channel up 58 Help
11 Channel down 59 Te l et e xt
12 Power off 60 Services
13 Mute 61 Box office
14 Vol ume up 62 Interactive
15 Vol ume dow n 63 TV guide
16 Program up 64 Red
17 Program down 65 Green
18 10+ key (for two digit channel entry) 66 Blue
20 Channel restore (back) 67 Yell ow
21 Power up 70 Play
22 Unmute 71 Pause
30 A/V select 1 72 Stop
31 A/V select 2 73 Record
32 A/V select 3 74 Fast forward
40 Device select (DVD/VCR) 75 Rewind
50 Menu 90 Custom 1 .. through to
51 Select Function 99 Custom 10
52 Cursor up 128 Select composite input
53 Cursor down 136 Select VGA input
54 Cursor left 144 Select S-Video input
55 Cursor right 152 Select Component (YPbPr) input
56 Esc
88
Send Non-specific Serial Command
Sends a serial string to the serial output (if present) on the remote receiver. This allows direct control of the
serial output (independent of the device protocol loaded in the receiver).
It is preferred that serial control be accomplished by loading the appropriate driver file into a receiver and
using the generic control commands (this allows the same command to be issued to a variety of different
devices, for example), but this command can be used for more direct control if required.
Byte # 4 5..n
Byte value 3 Serial string for onward transmission
Set Serial Parameters
Sets serial port parameters for the serial interface (if present) on the Rx. DTR may be controlled by the value in
offset 7 - a non zero value will assert it.
Baud rate values are split into most significant byte (MSB) and least significant byte (LSB), so for example:
9600 baud has MSB = 37 and LSB= 128 since 9600 = 37x256 + 128
If the baud rate in this command is zero (both MSB and LSB), then the baud rate of the remote device will
remain unchanged.
Byte # 4 5 6 7
Byte value 4 Baud rate MSB Baud rate LSB DTR (0 for off)
UDM-0404 4x4 Multi-Format Distribution Hub
