AMX NXI NETLINX INTEGRATED CONTROLLER User Manual

NXI
NetLinx Integrated Controller
instruction manual
NetLinx Central Controllers and Cards
AMX Limited Warranty and Disclaimer
AMX Corporation warrants its products to be free of defects in material and workmanship under normal use for
three (3) years from the date of purchase from AMX Corporation, with the following exceptions:
Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay components that are warranted for a period of one (1) year.
Disk drive mechanisms, pan/tilt heads, power supplies, MX Series products, and KC Series products are warranted for a period of one (1) year.
Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.
Software is warranted for a period of ninety (90) days.
Batteries and incandescent lamps are not covered under the warranty.
This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer.
AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform.
This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not
liable for any claim made by a third party or by an AMX Dealer for a third party.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort
claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of
liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX
Corporation or an authorized representative of AMX Corporation has been advised of the possibility of any such
damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or
exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of
the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may
also have other rights that vary from state to state. The owner is advised to consult applicable state laws for full
determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX CORPORATION MAKES NO
OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX CORPORATION
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY
IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS
LIMITED WARRANTY.
Table of Contents
Table of Contents
Product Information .................................................................................................1
Front and Rear Panel Components................................................................................... 1
Specifications .................................................................................................................... 2
Connections and Wiring ..........................................................................................5
Installing the Master or Hub Card...................................................................................... 5
Preparing/connecting captive wires ......................................................................................... 5
RS-232/422/485 Wiring Specifications.............................................................................. 6
Relay Connections and Wiring .......................................................................................... 6
IR/Serial Connections and Wiring ..................................................................................... 6
Input/Output (I/O) Connections and Wiring ....................................................................... 7
Programming ............................................................................................................9
Using the ID Button ........................................................................................................... 9
Device:Port:System (D:P:S) ..................................................................................................... 9
Program Port Commands................................................................................................ 10
ESC Pass Codes............................................................................................................. 12
Notes on Specific Telnet/Terminal Clients ...................................................................... 13
WindowsTM client programs .................................................................................................. 13
Linux Telnet client .................................................................................................................. 13
LED Disable/Enable Send_Commands .......................................................................... 14
RS-232/422/485 Send_Commands ................................................................................ 14
RS-232/422/485 Send_String Escape Sequences ......................................................... 17
IR / Serial Ports (8 - 15) Channels .................................................................................. 18
IR/Serial Send_Commands............................................................................................. 18
Input/Output Send_Commands....................................................................................... 23
NXI NetLinx Integrated Controller
i
Table of Contents
ii
NXI NetLinx Integrated Controller

Product Information

The NXI NetLinx Integrated Controller represents the new generation of AMX multi-port central
controllers. The NXI can be programmed to control RS-232/422/485, Relay, IR/Serial, and Input/
Output devices using the NetLinx programming language and NetLinx Studio program. Depending
on your specific control needs, the NXI can be equipped with either a Master or Hub Card. For use
as a master controller, the NXI accepts the NXC-ME260 NetLinx Master Card.

Front and Rear Panel Components

Remove the faceplate to see the front panel (FIG. 1) containing groups of colored LED indicators
that light when their corresponding control ports receive/ transmit data. These LEDs are grouped by
control type, and are numbered according to their corresponding port (connector) numbers on the
rear panel. The rear panel contains all of the RS-232/422/485, Relay, IR/Serial and I/O connectors,
plus the ID pushbutton and ICSP LED. Figure 1 shows the front and rear panels of the NXI.
I/O LEDs (yellow)
IR/Serial LEDs (red)
Relay LEDs (red)
RS-232/422/485 TX/RX LEDs
Product Information
Master/Hub Card Slot
ICSP LED (green)
Relays (port 7)
IR/Serial (ports 8-15) I/O (port 16)
ID Pushbutton
FIG. 1 NXI front and rear panel components
front
RS-232/422/485 (ports 1-6)
Master/Hub Card Slot
rear
NXI NetLinx Integrated Controller
1
Product Information

Specifications

NXI Specifications
Power requirements 1.09 A @ 12 VDC (NXI only/no card)
Memory 64K of IR memory:·
• 32K IR memory for IR ports 8-11
• 32K IR memory for IR ports 12-15
Ports:
RS-232/422/485 ports (#1-6) Six RS-232/422/485 control ports with XON/XOFF (transmit on/transmit off),
and CTS/RTS (clear to send/ready to send), 300-230,400 baud.
Channel range = 1-255
• Channels 1-254 provide feedback only.
• Channel 255 (CTS Push channel): Reflects the state of the CTS Input if a 'CTSPSH' command was sent to the port.
Relay port (#7) 12-channel relay port.
Channel range = 1-12
IR/Serial ports (#8-15) 8 IR/Serial control ports that support high-frequency carriers up to 1.14 MHz.
Channel range = 1-32,767
• Channels 1-253 (output): IR commands.
• Channel 254 (feedback): Power Fail (used with 'PON' and 'POF' commands).
• Channel 255 (feedback): Power status (when IOLink is set).
I/O port (#16) 8-channel I/O port for contact closure, 0-5 VDC voltage sensing, or interac-
tive power sensing for IR ports.
Channel range = 1-8
Front panel components:
Card slot Accepts NXC-ME260 NetLinx Master or Hub card.
Hub Cards:
• NXC-NH - Hub Card
• NXC-HS - Hub Server Card
• NXC-HE - Hub Expander Card
RS-232/422/485 LEDs 6 sets of red and yellow LEDs light to indicate ports 1-6 are transmitting or
receiving RS-232, 422, or 485 data:
• TX LEDs (red) blink when transmitting data.·
• RX LEDs (yellow) blink when receiving data.
Relay LEDs 12 red LEDs light to indicate relay channels 1-12 are active (closed).
IR/Serial LEDs 8 red LEDs light to indicate IR/Serial channels 1-8 are transmitting control
data.
I/O LEDs 8 yellow LEDs light when I/O channels 1-8 are active.
2
NXI NetLinx Integrated Controller
Product Information
NXI Specifications (Cont.)
Rear Panel Components:
RS-232/422/485 (ports 1-6) Six 10-pin (male) connectors that support bi-directional RS-232/422/485
Relay (port 7) Three 8-pin (male) relay connectors (normally open) that support up to 12
IR/Serial (ports 8-15) Two 8-pin (male) connectors that support IR or serial (wired) IR control.
I/O (port 16) 8-channel I/O port for contact closure, 0-5 VDC voltage sensing, or interac-
ICSP LED (green) Blinks in unison with the Master card's NetLinx LED indicating the ICSP bus
ID pushbutton Sets the NetLinx ID (D:P:S) assignment for the NXI.
Enclosure Metal with black matte finish
Front faceplate Plastic gray faceplate with translucent viewing window
Weight 4.10 lbs (1.85 kg)
Dimensions (HWD) 1.72" x 17.0" x 8.80" (43.68 mm x 431.80 mm x 223.52 mm)
Included accessories 4 CC-NIRC IR Emitter cables
Optional accessories • CSB Cable Support Bracket
communication (XON/XOFF, CTS/RTS, 300-230,400 baud).
• Channel range = 1-255
• Channels 1-254 provide feedback only.·
• Channel 255 (CTS Push channel): Reflects the state of the CTS input if a 'CTSPSH' command was sent to the port.
independent external relay devices. Each relay can switch up to 24 VDC or 28 VAC @ 1 A.
• Channel range = 1-12
The eight IR/Serial control ports support high-frequency carriers up to
1.14 MHz.
• Channel range = 1-32,767
• Channels 1-253: = IR commands
• Channel 254: = PowerFail (used with 'PON' and 'POF' commands)
• Channel 255: = Power status (when IOLink is set)
tive power sensing for IR ports.
• The 10-pin (male) connector has inputs that detect 0-1.5 VDC (low) as a Push, and 3.5-5 VDC (high) as a Release.
• When used as an input, each of the eight I/O ports act as a switch to ground and are rated at 200 mA @ 12 VDC.
• Channel range = 1-8
is synchronized.
• 12 VDC power supply
• CC-N232 RS-232/422 cables
• CC-NIRC IR cables
• CC-NREL Relay cables
• CC-NSER IR/Serial cables
NXI NetLinx Integrated Controller
3
Product Information
4
NXI NetLinx Integrated Controller

Connections and Wiring

Installing the Master or Hub Card

The NXC-ME260 NetLinx Master or any Hub Card can be installed in the NXI. The card mounts in
a horizontal position, through the master card slot on the rear panel of the NXI enclosure (see
FIG. 1 on page 1).
To install a Master or Hub Card in an NXI:
1. Discharge the static electricity from your body by touching a grounded metal object.
2. Unplug all the connectors from the NXI.
3. Remove the two screws that hold the front plate on the Master or Hub Card, and remove the
front plate.
4. Align the edges of the card with the guide slots inside the Master Card slot on the NXI.
5. Slide the card about halfway into the slot.
6. Inside the Master Card slot on NXI, locate the 6-pin control cable connector.
Connections and Wiring
7. Plug the connector from the NXI into the 6-pin terminal on the Master or Hub Card. This
connector is keyed to ensure correct orientation.
8. Once the control cable is connected, gently slide the card all the way in until you feel the rear
edge of the card lightly snap into place.
9. Re-apply power and other connections as necessary.

Preparing/connecting captive wires

1. Strip 0.25 inch of wire insulation off all wires.
2. Insert each wire into the appropriate opening on the connector according to the wiring
diagrams and connector types described in this section. Do not tighten the screws excessively;
doing so may strip the threads and damage the connector.
NXI NetLinx Integrated Controller
5
