AMX NXD-500i User Manual

Download

Operation/Reference Guide

Modero® NXD-500i

G4 Touch Panel

5" Wall/Flush Mount Touch Panel with

Intercom

Touch Panels

Initial Release: 11/3/2008

AMX Limited Warranty and Disclaimer

AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of purchase from AMX, with the following exceptions:

• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay components that are warranted for a period of one (1) year.

• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.

• AMX Lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long as the AMX Lighting products are under warranty. AMX does guarantee the control of dimmable loads that are properly connected to our lighting products. The dimming performance or quality cannot be guaranteed due to the random combinations of dimmers, lamps and ballasts or transformers.

• Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.

• AMX Software is warranted for a period of ninety (90) days.

• Batteries and incandescent lamps are not covered under the warranty.

This warranty extends only to products purchased directly from AMX or an Authorized AMX Dealer.

All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will be refused. AMX is not responsible for products returned without a valid RMA number.

AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Dealer for a third party.

This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.

Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state. The owner is advised to consult applicable state laws for full determination of rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY.

Table of Contents

Introduction ........................................................................................................1

NXD-500i Specifications ........................................................................................... 3

Front Bezel Button.................................................................................................... 5

Ethernet and mini-USB Ports .................................................................................... 5

Installation ..........................................................................................................7

Installing the Trim Ring ............................................................................................. 7

Removing the Faceplate ........................................................................................... 8

Installation of an NXD-500i Touch Panel................................................................... 9

Pre-Wall Installation of the Rough-In Box........................................................................ 9

Installing the NXD-500i panel within a Rough-In Box.................................................... 10

Installing the NXD-500i into drywall ............................................................................. 12

Installing the NXD-500i into a Flat Surface using #4 screws ......................................... 15

Installing an NXD-500i into a Rack Mount Kit (NXA-RK5) ............................................. 17

Wiring Guidelines for the NXD-500i Panel.............................................................. 18

Ethernet/RJ-45 Port: Connections and Wiring ........................................................ 18

NXD-500i Touch Panel Accessories ..................................................................19

PS-POE-AF PoE Injector.......................................................................................... 19

Panel Calibration ..............................................................................................21

Calibrating the Modero Panel................................................................................. 21

Configuring Communication ............................................................................. 23

Modero Setup and System Connection .................................................................. 23

Configuring and Using USB with a Virtual Master .................................................. 25

Step 1: Setup the Panel and PC for USB Communication ............................................. 25

Step 2: Confirm the Installation of the USB Driver on the PC ....................................... 25

Step 3: Confirm and View the current AMX USB device connections ........................... 27

Step 4: Use the USB to Configure a Virtual Master (using NetLinx Studio)................... 28

Step 5: Confirm and View the current AMX USB device connections ........................... 29

Configuring a Wired Ethernet Connection.............................................................. 31

Step 1: Configure the Panel’s Wired IP Settings..................................................... 31

IP Settings section - Configuring a DHCP Address over Ethernet................................. 31

IP Settings section - Configuring a Static IP Address over Ethernet ............................. 31

Step 2: Choose a Master Connection Mode Setting............................................... 32

Step 3: Configure an Ethernet Connection Type .................................................... 32

Master Connection section - Virtual Master communication over Ethernet .................. 33

Master Connection section - NetLinx Master Ethernet IP Address - URL Mode ............ 35

Master Connection section - NetLinx Master Ethernet IP Address - Listen Mode ......... 36

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Table of Contents

Master Connection section - NetLinx Master Ethernet IP Address - Auto Mode........... 36

Using G4 Web Control to Interact with a G4 Panel ................................................ 37

Using the NetLinx Master to control the G4 panel ................................................. 38

Upgrading Modero Firmware ...........................................................................43

Upgrading the Firmware via the USB port.............................................................. 43

Step 1: Configure the panel for a USB Connection Type .............................................. 43

Step 2: Prepare NetLinx Studio for communication via the USB port ........................... 44

Step 3: Confirm and Upgrade the firmware via the USB port ....................................... 45

Setup Pages and Descriptions ..........................................................................47

Setup Navigation Buttons....................................................................................... 47

Protected Setup...................................................................................................... 47

Setup Page ............................................................................................................. 48

Information ............................................................................................................. 50

Panel Information Page ................................................................................................. 50

Panel Information Page ................................................................................................. 51

Time & Date Settings Page ........................................................................................... 53

Audio Settings Page...................................................................................................... 54

Supported sampling rates for WAV............................................................................... 55

Protected Setup Navigation Buttons ...................................................................... 56

Protected Setup Page............................................................................................. 57

System Settings Page.................................................................................................... 59

Calibration Page............................................................................................................ 61

G4 Web Control Page ................................................................................................... 62

Other Settings ........................................................................................................ 64

Cache Settings Page...................................................................................................... 64

Setting the image cache ................................................................................................ 65

Clearing the image cache .............................................................................................. 66

Checking image cache status ........................................................................................ 66

Password Settings Page ................................................................................................ 67

Sensor Setup ................................................................................................................. 68

Making the most of the Light bargraph ........................................................................ 69

Making the most of the Motion Sensor feature ............................................................ 69

Tools ....................................................................................................................... 70

Panel Logs Page ............................................................................................................ 71

Checking the Panel Connection Logs ............................................................................ 71

Refreshing the Panel Connections Log .......................................................................... 71

Clearing the Panel Connections Log.............................................................................. 72

Panel Statistics Page ..................................................................................................... 72

Checking the Panel Statistics......................................................................................... 73

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Table of Contents

Refreshing the Panel Statistics ...................................................................................... 73

Clearing the Panel Statistics .......................................................................................... 73

Connection Utility Page ................................................................................................ 74

Using the Connection Utility ......................................................................................... 75

Programming ....................................................................................................77

Button Assignments ............................................................................................... 77

Page Commands ..................................................................................................... 77

Programming Numbers for Colors, Fonts, and Borders.......................................... 83

RGB triplets and names for basic 88 colors .................................................................. 83

Font styles and ID numbers........................................................................................... 85

Border styles and Programming numbers ..................................................................... 86

Telnet Commands ................................................................................................... 88

"^" Button Commands ........................................................................................... 89

Text Effect Names ................................................................................................ 108

Button Query Commands ..................................................................................... 109

Panel Runtime Operations .................................................................................... 118

Input Commands................................................................................................... 122

Embedded codes.................................................................................................. 123

Panel Setup Commands ........................................................................................ 124

Dynamic Image Commands................................................................................... 125

Intercom Commands............................................................................................. 127

Panel IR Commands .............................................................................................. 129

Troubleshooting .............................................................................................131

Appendix A ....................................................................................................135

Text Formatting Codes for Bargraphs/Joysticks................................................... 135

Text Area Input Masking....................................................................................... 136

Input mask character types ......................................................................................... 136

Input mask ranges ....................................................................................................... 137

Input mask next field characters ................................................................................. 137

Input mask operations................................................................................................. 137

Input mask literals ....................................................................................................... 137

Input mask output examples ....................................................................................... 138

URL Resources ...................................................................................................... 139

Special escape sequences ........................................................................................... 139

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

iii

Table of Contents

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Introduction

The NXD-500i 5" Modero Wall/Flush Mount Touch Panel with Intercom (FG2261-02) is a widescreen full-color mini-touch panel with full sound and intercom capability (FIG. 1). It offers the same perimeter footprint as the NXD-CV5, but with a shallower mounting depth.

Touch screen

Introduction

Faceplate

Microphone

Speaker

Front Bezel button

FIG. 1 NXD-500i Color Video Touch Panel

Button Trim Ring

This panel includes a built-in microphone, speakers, a mini-USB port for programming and audio output, and one NetLinx-programmable button.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Introduction

Locking tabs

Touch screen

Button trim ring

Front Bezel button

FIG. 2 NXD-500i Color Video Touch Panel - Schematics

Back box

FIG. 3 shows the connectors located on the NXD-500i Modero panel. The mini-USB port is used both for programming the touch panel and for audio output. The mini-USB port automatically detects the presence of a headphone adaptor, allowing the port to be used for headphone connectivity.

Ethernet 10/100 port

Back box

Mini-USB port

FIG. 3 NXD-500i Color Video Touch Panel - side view of connectors

The NXD-500i supports Intercom functionality, which allows two communicating panels (controlled by the NetLinx Master) to transmit full-duplex audio signals over a network in order for it to be used as an Intercom system.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Key features include:

 Support of AMX's 4th generation (G4) graphics which provide higher brightness, richer

colors, and deeper contrast. The new G4 graphics technology is supported by the TPDesign4 Touch Panel Design application, available for download from www.amx.com.

 Display of images on a large 16:9 image format, while providing a wide 90-degree top-to-

bottom viewing angle.

 A front panel light sensor, motion sensor, IR receiver and a Sleep/Setup Access button.

 Utilization of the Voice Over Internet protocol (VoIP), which allows telephone calls to be

made or received directly from the touch panel.

 Support of AMX Computer Control, which enables remote viewing and control of any

networked computer directly from the panel. This gives the user the ability to launch digital music from a PC, cruise the Internet, check and respond to E-mail, open software files, and launch applications. Anything you can do on your PC can be accomplished through these panels.

 Programmable firmware that can be upgraded via the mini-USB port in the back of the device.

NXD-500i Specifications

The specifications for the 5" Widescreen Modero panel include:

Introduction

Specifications for NXD-500i 5" Widescreen Video Touch Panel (FG2261-02)

Dimensions (HWD): • NXD-500i (with faceplate): 4.15" x 5.59" x 1.97"

Power Requirements: • PoE Powered - No local Power Supply needed.

Memory (factory default): • 128 MB SDRAM

Weight: • 0.80 lbs (0.36 kg)

Certifications: • FCC Part 15 Class B

Panel LCD Parameters: • Aspect ratio: 16 x 9

Active Viewing Area: • 4.25” x 2.55” (10.80cm x 6.48cm)

Viewing Angles: • Up/Down/Left/Right: 40/80/60/60

IR Reception Angle: • Horizontal: +

Audio • G.711 sound standard

(10.50 cm x 14.20 cm x 5 cm)

• CB-TP5i Rough-In/Wallbox (optional): 4.27" x 5.14" x 3.40" (10.86 cm x 13.06 cm x 8.64 cm)

• Max power draw: 5.5W.

• 256 MB integrated Flash Memory (not upgradeable - factory programmed)

•CE

• IEC 60950

•RoHS

• Maximum brightness (luminance): 200 cd/m

• Channel transparency: 8-bit Alpha blending

• Contrast ratio: 250:1

• Display colors: 256 thousand colors (18-bit color depth)

• Dot/pixel pitch: 0.14 mm

• Panel type: TFT Color Active-Matrix

• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency

• Viewing dimensions: 4.3" x 2.58" (109.2 mm x 65.2 mm)

25° (left and right from center)

• Vertical: +

• 75dB SPL@1m

15° (up and down from center)

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Introduction

Specifications for NCXC-500i 5" Widescreen Video Touch Panel (Cont.)

Supported Audio Sample Rates:

Intercom: • Full duplex VoIP capabilities.

Front Panel Components:

Light sensor: • Motion-sensitive light detector for automatic adjustment of the panel

Motion sensor (PIR): • Proximity Infrared Detector to wake the panel when the panel is approached.

Front Bezel button: • Provides both access to the Setup and Calibration page and toggles the

Microphone: • Frequency response of 300 to 3400Hz

Speaker: • Output of 4Ohm

Side Panel Components:

Ethernet 10/100 port: • RJ-45 port for 10/100 Mbps communication. The Ethernet port automatically

Mini-USB connector: • 5-pin Mini-USB connector used for programming, firmware update, and touch

Button Assignments: Button assignments can only be adjusted in TPD4 and not on the panel.

Operating / Storage Environment:

• 48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz, 12000Hz, 11025Hz, and 8000Hz.

brightness (a dim room results in a dimmer LCD display, and a bright room results in a brighter LCD display).

Note: The light sensor can be adjusted via the Sensor Setup page (page 64).

• Activation range: + from center).

Note: This sensor can be adjusted via the Sensor Setup page (see page 64).

panel between a "sleep" or "wake" state. "Sleep" status means the backlight is Off.

• Used for intercom applications

• 2 Watts

• 300Hz cutoff frequency

negotiates the connection speed (10 Mbps or 100 Mbps), and whether to use half duplex or full duplex mode. Power is supplied through Power Over Internet (PoE)

• NXD-500i panels communicate with the NetLinx Master using the ICSP protocol over Ethernet.

• LEDs show communication activity, connections, speeds, and mode information: L/A-link/activity - yellow LED lights On when the Ethernet cables are connected and terminated correctly and then blinks when receiving Ethernet data packets. SPD-speed - Green LED lights On when the connection speed is 100 Mbps and turns Off when the speed is 10 Mbps.

panel file transfer between the PC and the target panel. The connector is also used for providing audio output for external speakers.

Note: When connecting the panel to PC using a CC-USB (or compatible) cable, be sure to power the panel On before attempting to connect the USB cable from the PC to the mini-USB port on the panel. Refer to the Configuring and Using USB with a Virtual Master section on page 25 for more information.

• Button channel range: 1 - 4000 button push and feedback (per address port)

• Button variable text range: 1 - 4000 (per address port)

• Button states range: 1 - 256 (General Button; 1 = Off State, 2 = On State)

• Level range: 1 - 600 (default level value 0-255, can be set up to 1-65535)

• Address port range: 1 - 100

• Operating Temperature: 0° C (32° F) to 40° C (104° F)

• Operating Humidity: 5% - 85% relative humidity (non-condensing)

• Storage Temperature: -20° C (-4° F) to 60° C (140° F)

• Storage Humidity: 5% - 85% RH

25° (left and right from center) and + 15° (up and down

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Introduction

Specifications for NCXC-500i 5" Widescreen Video Touch Panel (Cont.)

Included Accessories: • NXD-500i Installation Guide (93-2261-02)

• Front Bezel (60-2261-11)

Other AMX Equipment: • CB-TP5i Rough-In/Wallbox (FG038-11)

• Back Cover for CB-TP5i Rough-In/Wallbox (FG038-12)

• PS-POE-AF PoE Injector (FG423-80)

• CC-USB Type-A to Mini-B 5-wire programming cable (FG10-5965)

• USB to Headphone Adaptor (FG5966-23)

• NXA-RK5 Rack Mount Kit for 5" Wall Mount panels (FG2904-55):

- 5" Rackmount

- Four Screws, #10-32 x.625, PH Truss, BLK

- Four Washers, #10, Black Nylon

- Three Screws, #4-40 x.250, PPH, BLK

Front Bezel Button

The NXD-500i has only one button on the front of the device, in the center of the button trim ring. This button has several uses:

 Press the button once to start a previously programmed function, or to turn off the display if

not previously programmed.

 Press and hold the button for 6 seconds to put the device into Setup Mode (please see the Setup

Pag e section on page 48 for more information).

 Press and hold the button for 9 seconds to enter Calibration Mode (please see the Panel

Calibration section on page 21 for more information).

 Press and hold the button for 20 seconds to reboot the panel.

Ethernet and mini-USB Ports

The NXD-500i has no power input port. Instead, all power is supplied via the Power over Ethernet (PoE) protocol. With PoE, the power is supplied directly through the Ethernet port through the PS-POE-AF PoE Injector, available from AMX. For more information on the PS-POE-AF POE Injector, please refer to the PS-POE-AF PoE Injector section on page 19.

The mini-USB port is used solely for software upload and audio output. The mini-USB port automatically detects the presence of a headphone adaptor, allowing the port to be used for headphone connectivity. For more information on software upgrading, please refer to the Upgrading the Firmware via the USB port section on page 43.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Introduction

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

While the NXD-500i is designed to fit into pre-existing NXD-CV5 touch panel sites, the actual installation differs from that of the NXD-CV5 is several significant ways. The NXD-500i can be installed either directly into the (optional) CB-TP5i Rough-In Box or another solid surface environment, using either solid surface screws or the included locking tabs for different mounting options. For more information, please refer to the NXD-500i User Manual, available at www.amx.com.

The NXD-500i is contained within a clear outer housing known as the back box (FIG. 4). This back box is removed when installing the device into a wall or into a Rough-In Box. Because of the backbox, the device may be installed into either a pre-wall surface using a CB-TP5i conduit/wallbox, or into a solid surface using the included locking tabs or either solid surface or drywall screws.

Installation

10/100 BaseT Ethernet port

Mini-USB programming port

Plastic backbox

Front of device

FIG. 4 NXD-500i - Side view

Make sure to remove the protective plastic cover from the LCD. If the cover is not removed, the panel may not respond properly to touch points on the LCD or allow proper screen calibration.

Installing the Trim Ring

The outer Trim Ring is secured to the Faceplate with plastic latches. The Trim Ring must first be removed to install the touch panel, and is later resecured when installation is complete.

To install the Trim Ring:

1. Place the Button Trim Ring, latch side down, atop the Faceplate.

2. Firmly press down around the Button Trim Ring until all of the latches are securely inserted into

their openings on the Faceplate, and the Button Trim Ring is securely fastened. Verify that the Button Trim Ring is firmly inserted onto the Faceplate and that no gaps remain between this Trim Ring and the outer surface of the Faceplate.

3. Place the Faceplate back onto the device. Make sure to align the Microphone, Light, and PIR

Motion sensor locations on the main unit to their respective openings on the Faceplate assembly.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Removing the Faceplate

In certain circumstances, the Faceplate must be removed and replaced with a new faceplate. Because the device is installed against a wall, the faceplate must be removed carefully to prevent the two top prongs on the underside of the Faceplate from being broken. To remove the faceplate:

1. Gently lift up on the faceplate from the bottom. Do NOT pull up from the sides or the top.

2. Let the faceplate fall forward from the top of the device and let it pivot from the bottom.

3. Remove the faceplate from the two bottom prongs and install the new trim ring if necessary.

4. Place the Faceplate back onto the device. Make sure to align the Microphone, Light, and PIR

Motion sensor locations on the device to their respective openings on the Faceplate assembly.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Installation of an NXD-500i Touch Panel

The NXD-500i can be installed either directly into the (optional) CB-TP5i Rough-In Box or other solid surface environment, using solid surface screws or the included locking tabs as mounting options. The following sections describe mounting the touch panel directly into a pre-wall rough-in box, a solid surface, drywall, or an NXA-RK5 Rack Mount Kit.

Pre-Wall Installation of the Rough-In Box

The CB-TP5i Rough-In Box (FG038-11) is an optional metallic box that is secured onto a stud/beam in a pre-wall setting, where no walls are present. Installation procedures and configurations can vary, depending on the installation environment. This section describes the installation procedures for the most common installation scenarios.

In order to guarantee a stable installation of the NXD-500i, the distance between the CB-TP5i and the outer wall surface must be a minimum of .50 inches (1.27cm) and a maximum of .875 inches (2.22cm).

Cutting out the surface slightly smaller than what is outlined in the installation drawings, to allow any necessary cutout adjustments, is highly recommended.

1. Attach the optional Back Cover for the CB-TP5i (FG038-12) if necessary.

2. Fasten the CB-TP5i Rough-In Box to the stud through the holes on the Stud Mounting tabs (FIG. 5),

using either nails or screws.

Stud

Stud Mounting tabs

Wiring knockouts

FIG. 5 CB-TP5i Rough-In Box components

3. Remove the appropriate wiring knockouts from the rough-in box (FIG. 5) to accommodate the

cables being threaded through to the NXD-500i touch panel.

4. Thread the incoming Ethernet and USB wiring through the knockouts. Use of the left wiring

knockouts are recommended with this installation. Leave enough slack in the wiring to accommodate any re-positioning of the panel.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

5. Install the drywall/sheetrock before inserting the main NXD-500i device into the CB-TP5i.

Installing the NXD-500i panel within a Rough-In Box

The Rough-In Box must be mounted prior to continuing this section. Refer to the procedures in the Pre-Wall Installation of the Rough-In Box section on page 9 for detailed pre-wall installation instructions. Verify that all necessary cables have been threaded through the knockouts on the left of the

Rough-In Box and the connections have been tested prior to installation of the NXD-500i.

1. Remove the Faceplate bezel (A in FIG. 6) from the main NXD-500i unit (B in FIG. 6) by gripping

the faceplate from the top and lifting up and then pulling with gentle outward force.

C - Optional CB-TP5i

rough-in/wallbox

Locking Tab

Screws for mounting Back Box to touch panel

B - Main NXD-500i unit consists of the touch panel and back box housing

A - Faceplate/Trim Ring

FIG. 6 NXD-500i panel installation into a CB-TP5i (pre-wall construction)

Stud

Be sure to pull the faceplate UP before pulling it out and away from the rest of the device. Pulling straight outward may lead to damage to the faceplate, including breaking off the tabs that attach the faceplate to the device.

2. Gently unscrew the two screws attaching the NXD-500i to its back box. These are at the bottom of

the device, underneath the touch screen. Carefully remove the NXD-500i from the back box.

While the screws are loosened, you can adjust the LCD to ensure it is parallel to the sides of the backbox, if necessary. While adjusting the LCD is possible, it is not required in most cases.

3. Thread the incoming Ethernet and USB wiring from their terminal locations through the surface

opening. Leave enough slack in the wiring to accommodate any re-positioning of the panel.

4. Push the back box into the wall opening. Insure that the locking tabs lie flush against the back box.

5. Extend the locking tabs on the sides of the back box by tightening the screws inside the box. Not all

of the tabs must be extended to lock the back box in place, but extending a minimum of the top and bottom tabs is highly recommended. Apply enough pressure to the screw head to keep the box flush

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

with the wall: this ensures that the locking tabs will tighten up against the inside of the wall. The back box is clear to allow visual confirmation that the tabs have been extended and are gripping the wall. This also allows visual confirmation if the entire assembly has to be removed from the wall for any reason.

The maximum recommended torque to screw in the locking tabs on the back box is 105 IN-OZ [74 N-CM]. Applying excessive torque while tightening the locking tab screws, such as with powered screwdrivers, can strip out the tabs or damage the back box.

6. Connect both connectors to their corresponding locations along the left side of the NXD-500i touch

panel.

7. Test the incoming wiring by attaching the panel connections to their terminal locations and applying

power via the PoE Injector. Verify that the panel is receiving power and functioning properly to prevent repetition of the installation.Test the incoming wiring by connecting the panel connections to their terminal locations and applying power via the PoE Injector. Verify that the panel is receiving power and functioning properly to prevent repetition of the installation.

Do not disconnect the connectors from the touch panel. The unit must be installed with the attached connectors before being inserted into the Rough-In Box.

8. Install the NXD-500i into the back box.

9. The microphone cable is taped to the back box. Connect the microphone cable to its connector,

making sure that the cable does not interfere with reattachment of the Faceplate.

10. Install the two Plastite screws attaching the NXD-500i to the back box (FIG. 6).

11. Place the Faceplate/Trim Ring assembly (A in FIG. 6) back onto the main NXD-500i unit (B in

FIG. 6). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front faceplate/bezel.

12. Reconnect the terminal Ethernet and USB to their respective locations on the Ethernet port and

NetLinx Master.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Installing the NXD-500i into drywall

Unlike most AMX touchpanels, the NXD-500i comes with a clear plastic backbox (FIG. 7) designed to attach the panel to standard drywall. This backbox has a locking tab on three of the four faces (missing only on the face containing the space for the connections) to help lock the backbox to the wall. These locking tabs are only extended AFTER the backbox is inserted into the wall.

Locking tab screws

Locking tabs - Closed

FIG. 7 NXD-500i backbox with closed and open locking tabs

Locking tabs - Open

When installing the backbox, make absolutely sure that the assembly is in the correct position and in the correct place. Once the locking tabs are extended and locked into place, removing the backbox will be very difficult without having access to the back of the wall itself or damaging the wall.

 Refer to the diagram for detailed installation dimensions as shown in FIG. 8.

 Cutting out the surface slightly smaller than what is outlined in the installation drawings, in

order to make any necessary cutout adjustments, is highly recommended.

1. Prepare the area by removing any screws or nails from the drywall before beginning the cutout

process.

2. Cut out the surface for the back box. Refer to the dimensions in FIG. 8 for more information.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

FIG. 8 NXD-500i Wall Mount panel dimensions

Making sure that the actual cutout opening be slightly smaller than the provided dimensions is highly recommended. This action provides the installer with a margin for error if the opening needs to be expanded. Too little drywall removed is always better than too much.

Installation

3. Remove the Faceplate/bezel (A in FIG. 9) from the main NXD-500i device (B in FIG. 9) by

gripping the faceplate and pulling up and then out with gentle outward force.

4. Thread the incoming Ethernet and USB wiring from their terminal locations through the surface

opening. Leave enough slack in the wiring to accommodate any re-positioning of the panel.

5. Connect both connectors to their corresponding locations along the left side of the NXD-500i touch

panel.

FIG. 9 Wall Mount panel (NXD-500i) installation view for drywall surfaces - top view

6. Test the incoming wiring by attaching the panel connections to their terminal locations and applying

power via the PoE Injector. Verify that the panel is receiving power and functioning properly to prevent repetition of the installation.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Do not disconnect the connectors from the touch panel. The unit must be installed with the attached connectors before being inserted into the drywall.

7. Push the back box into the wall opening. Insure that the locking tabs lie flush against the back box.

8. Extend the locking tabs on the sides of the back box by tightening the screws inside the box. Not all

of the tabs must be extended to lock the back box in place, but extending a minimum of the top and bottom tabs is highly recommended. Apply enough pressure to the screw head to keep the box flush with the wall: this ensures that the locking tabs will tighten up against the inside of the wall.

The back box is clear to allow visual confirmation that the tabs have been extended and are gripping the wall. This also allows visual confirmation if the entire assembly has to be removed from the wall for any reason.

9. Install the NXD-500i into the back box.

10. The microphone cable is taped to the back box. Connect the microphone cable to its connector,

making sure that the cable does not interfere with reattachment of the Faceplate.

11. Install the two Plastite screws attaching the NXD-500i to the back box (FIG. 6).

12. Place the Faceplate/Trim Ring assembly (A in FIG. 9) back onto the main NXD-500i unit (B in

FIG. 9). Make sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front faceplate/bezel.

13. Reconnect the terminal Ethernet and USB to their respective locations on the Ethernet port and

NetLinx Master.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Installing the NXD-500i into a Flat Surface using #4 screws

Three #4 mounting screws (not included) are secured through circular holes located at the left and right sides of the NXD-500i. The most important thing to remember when mounting the NXD-500i is

that the back box must be installed flush against the mounting surface.

 Refer to SP-2261-02 for detailed installation dimensions (reproduced in FIG. 10).

 Cutting out the surface slightly smaller than what is outlined in the installation drawings in

order to make any necessary cutout adjustments, is highly recommended.

1. Prepare the area by removing any screws or nails from the surface before beginning the cutout

process.

2. Cut out the surface for the NXD-500i Wall Mount unit using the dimensions shown in FIG. 10.

FIG. 10 NXD-500i Wall Mount panel dimensions using #4 mounting screws

3. Remove the Faceplate/bezel (A in FIG. 11) from the main NXD-500i unit (B in FIG. 11) by

gripping the faceplate and pulling up and out with gentle force.

4. Thread the incoming Ethernet and USB wiring from their terminal sources through the surface

opening. Leave enough slack in the wiring to accommodate any re-positioning of the panel.

5. Connect all connectors to their corresponding locations along the left side of the un-powered

NXD-500i touch panel.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

 The USB connectors can be from either a USB extension cable or a wireless USB RF

transmitter.

6. Test the incoming wiring by connecting the panel connections to their terminal locations. Verify that

the panel is receiving power and functioning properly before finalizing the installation.

Flat installation surface

Install the three #4 Mounting Screws

(not included) into these three holes

(suggested length of screws is 0.25")

Locking Tab

Attachment is done along the edges of the cutout

B - Main NXD-500i unit

A - Faceplate/Trim Ring

FIG. 11 Wall Mount panel installation configuration for flat surfaces

Do not disconnect the connectors from the touch panel. The unit must be installed with the necessary connectors before being inserted into the solid surface.

7. Carefully slide the main unit into the cutout, making sure that the locking tabs lie flush against the

back box.

8. Insert and secure three #4 Mounting Screws (not included) into the corresponding holes located

along the sides of the NXD-500i, using a grounded Phillips-head screwdriver, until the unit is secure and flush against the wall (FIG. 11).

9. Place the Faceplate/Trim Ring assembly (A in FIG. 11) back onto the device (B in FIG. 11). Make

sure to align the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front bezel/faceplate.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Installing an NXD-500i into a Rack Mount Kit (NXA-RK5)

The NXA-RK5 is a 19" (48.26 cm) wide metal rack-mount (with black matte finish) measuring 3 rack units high.

1. Remove the Faceplate/Trim Ring assembly from the main NXD-500i unit.

2. Thread the incoming Ethernet and USB wiring from their terminal sources through the surface

opening, leaving enough slack in the wiring to accommodate any re-positioning of the panel.

3. Connect all data and power wiring connectors to their corresponding locations along the left side of

the device.

 The USB connectors can be from either a USB extension cable or a wireless USB RF

transmitter.

4. Test the incoming wiring by connecting the panel connections to their terminal locations. Verify that

the panel is receiving power from the PoE Injector and functioning properly.

Do not disconnect the connectors from the touch panel. The unit must be installed with the necessary connectors before being inserted into the equipment rack.

5. Carefully insert the device into the NXA-RK5.

6. Secure the panel to the NXA-RK5 mount by first inserting and then tightening the three included

#4-40 screws.

7. Insert the NXA-RK5 (with the connected NXD-500i unit) into the equipment rack, making sure to

align the screw holes along the sides on the NXA-RK5 with the holes in the equipment rack.

8. Use a grounded Phillips-head screwdriver to secure the NXA-RK5 to the equipment rack using the

included #10-32 screws.

9. Place the Faceplate/Trim Ring assembly back onto the main NXD-500i device. Make sure to align

the Microphone, Light, and PIR Motion sensor locations to their respective openings on the front faceplate/bezel.

10. Reconnect the terminal Ethernet and USB wiring to their respective terminal locations on the

Ethernet port or NetLinx Master.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Installation

Wiring Guidelines for the NXD-500i Panel

The NXD-500i panel utilizes the Power over Ethernet protocol, where it draws power directly from its Ethernet connection. Because of this, the panel has no need for standard power inputs or outputs.

Ethernet/RJ-45 Port: Connections and Wiring

FIG. 12 describes the blink activity for the Ethernet 10/100 Base-T RJ-45 connector and cable. The Ethernet cable is connected to the side of the Wall Mount panels.

A - Activity LED (yellow)

lights when receiving or

transmitting Ethernet

data packets

FIG. 12 Ethernet connector (showing communication and connection LEDs)

A L

ETHERNET

10/100

L - Link LED (green) lights when the Ethernet cables are connected and terminated correctly.

The following table lists the pinouts, signals, and pairing for the Ethernet connector.

Ethernet RJ-45 Pinouts and Signals

Pin Signals Connections Pairing Color

1 TX + 1 --------- 1 1 --------- 2 Orange-White

2 TX - 2 --------- 2 Orange

3 RX + 3 --------- 3 3 --------- 6 Green-White

4 PoE power 4 --------- 4 Blue

5 PoE power 5 --------- 5 4 --------- 5 Blue-White

6 RX - 6 --------- 6 Green

7 PoE power 7 --------- 7 7 --------- 8 Brown-White

8 PoE power 8 --------- 8 Brown

FIG. 13 diagrams the RJ-45 pinouts and signals for the Ethernet RJ-45 connector and cable.

FIG. 13

RJ-45 wiring diagram

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

NXD-500i Touch Panel Accessories

The following section outlines and describes both the included accessories and other AMX equipment available for the NXD-500i.

PS-POE-AF PoE Injector

The PS-POE-AF PoE Injector (FG423-80) is a single-port, self-contained Power-over-Ethernet (PoE) power supply that delivers both DC power and data to PoE-equipped devices by “injecting” DC power through a Cat5 Ethernet cable (FIG. 14). The PoE Injector allows devices such as the NXD-500i to function without an additional power connection other than an Ethernet connection.

FIG. 14 PS-POE-AF Power-Over-Ethernet Power Supply

Power-over-Ethernet eliminates the need for an AC outlet at each device installation point, resulting in easier and less expensive installation. It also can be used to extend the distance between the PoE devices and standard power outlets by up to 328 feet (100 meters).

Each PoE Injector may be used for one device’s power needs. Multiple devices in a network that require PoE will require multiple Injectors.

PS-POE-AF Specifications

Output Specifications

Combined Line and Load Voltage Regulation

Ripple 1% Vp-p max.

Transient Response • 0.5ms for 50%

Protection • Foldback Overcurrent Protection

Input Specifications

AC Input Voltage Range 100-240VAC -10%, +6%

Line Frequency 47-63Hz

AC Input Current • 90VAC Input

Protection • Internal Primary Current Fuse

Excluding Cord ±1%

• Load Change Typical

• Short Circuit Protection

•0.6A max.

• Inrush Limiting

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

NXD-500i Touch Panel Accessories

PS-POE-AF Specifications (Cont.)

General Specifications

Topology • Switching-Fixed

Dielectric Withstand • Primary-Secondary 3000VAC, 4250VDC

Spacing 5mm Primary-Secondary

Leakage Current Less than 250 uA

Efficiency • 65% Typical @ Max. Load

Weight (excluding cord)

Dimension • 5.24L x 2.13W x 1.42H (in)

Case Material Black 94V0 Polycarbonate

Cord and Connectors Dual RJ45 jacks built into the enclosure

EMC Information

FCC • Part 15 Class B

Immunity ESD: EN61000-4-2

RS EN61000-4-3

EFT EN61000-4-4

Surge EN61000-4-5

CS EN61000-4-6

Voltage Dip EN61000-4-11

Harmonic EN61000-3-2

CE CE Compliant

Hold-up Time • @120VAC 10ms min. typ.

Storage Temperature -30° C to +85° C

Approvals and Standards Safety

MTBF 100,000 Calculated Hours

Environmental Specifications

Thermal Performance • Operating Temperature 0° C to 40° C

Relative Humidity Non-Condensing 5% to 95%

Altitude 0-10,000 feet

• Frequency Flyback

• Secondary-Ground 500VDC

• and 120VAC/60 Hz

7 Ounces (200 Grams)

• 133.0L x 54.0W x 36.0H (mm)

• EN55022 Class B

• @240VAC 40ms min. typ.

• cULus: UL/CSA60950

• TUV: EN60950

• CE: LVD, EMCD

• No Derating

• Convectional Cooling

• Non Vented Case

For more information, please refer to the PS-POE-AF PoE Injector Installation Guide, available at www.amx.com.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Panel Calibration

This section outlines the steps for calibrating the touch panel. Calibrating the panel before its initial use and after completing a firmware download is highly recommended.

Modero panels are set up in the factory with specific demo touch panel pages. The first splash screen that appears indicates the panel is receiving power, beginning to load firmware, and preparing to display the default touch panel pages. When the panel is ready, the AMX Splash Screen is replaced by the Initial Panel Page.

Calibrating the Modero Panel

1. Press and hold the grey Front Bezel button (FIG. 15) for 8 seconds to pass over the Setup page and

access the Calibration setup page (FIG. 16).

Front Bezel button

Panel Calibration

4 second press/hold:

Opens the Setup page

6 second press/hold:

Opens the Calibration page

Single press puts

the panel to sleep

FIG. 15 Location of Front Setup Access button

2. Press the crosshairs (on the Calibration page) to set the calibration points on the LCD (FIG. 16).

The request to touch the crosshairs is the first on-screen message

Calibration successful is the second on-screen message that appears after the calibration process is completed

On-screen crosshairs used for calibration of the touch device

FIG. 16 Touch Panel Calibration Screens

3. After the "Calibration Successful." message appears, press anywhere on the screen to continue and

return to the Setup page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Panel Calibration

If the calibration was improperly set and you cannot return to the Calibration page through the panel’s firmware, this firmware page may be accessed via

G4 WebControl, where you can navigate to the Protected Setup page and press the Calibrate button through a VNC window. This action causes the panel to go to the Calibration page seen above, where the actual touch panel may be physically calibrated again using the above procedures.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Communication between the Modero panel and the Master is done using either USB or ETHERNET (DHCP or Static IP). Ethernet communication can only be achieved via a direct Ethernet connection.

Before commencing, verify that you are using the latest NetLinx Master and Modero panel firmware, and also verify you are using the latest versions of AMX’s NetLinx Studio and TPDesign4 applications. These are available at www.amx.com.

USB input devices must be plugged into the rear or side USB connectors before the G4 panel is powered-up. The panel will not detect a USB connection of this type until after the unit cycles power.

Modero Setup and System Connection

1. Press the Front Setup Access button for 3 seconds to open the Setup page (FIG. 17).

Configuring Communication

Connection Status

Red Connection Status icon -

indicates no connection to a Master

Green Connection Status icon -

indicates communication to a Master

FIG. 17 Setup page

2. Press the Protected Setup button (located on the lower-left of the panel page) to open the Protected

Setup page and display an on-screen keypad.

3. Enter 1988 into the Keypad’s password field and press Done when finished.

Clearing Password #5, from the initial Password Setup page, removes the need for you to enter the default password before accessing the Protected Setup page.

4. Press the red Device Number field to open the Device Number keypad.

5. Enter a Device Number for the panel into the Device Number Keypad. The default is 0 and the

range is from 1 - 32000.

When using multiple panels within a NetLinx System, remember to assign unique Device Number values to each panel, so that all assigned panels appear in the System listing for the target Master.

6. Press Done to close the keypad, assign the number, and return to the Protected Setup page.

7. Press the on-screen Reboot button to restart the panel and incorporate any changes.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Before continuing, open NetLinx Studio. This program assists in developing a System Number, Master IP/URL, and Master Port number. Refer to the NetLinx Master’s instruction manual for more information.

8. Obtain the System Number and Master IP Address from NetLinx Studio. This information must be

specific for the system used with the configured Modero panel.

9. Press the Front Setup Access button for 4 seconds to open the Setup page.

10. Press the Protected Setup button (located on the lower-left of the panel page) to open the Protected

Setup page.

11. Press the System Settings button (located on the Protected Setup page) to open the System Settings

page (FIG. 18) and begin configuring the communication settings on the panel to match those of the target Master.

Modero

connection

information

MAC Address

from panel is

factory set to a

unique address

FIG. 18 System Connection page

NetLinx Master’s connection information

The two possible Master Connection Types available are USB or Ethernet. A USB connection type is a direct connection from the panel’s mini-USB port to a corresponding USB port on the PC, which is acting as a Virtual Master. An Ethernet connection type involves indirect communication from the panel to a Master via an Ethernet connection to the network.

It is recommended that firmware KIT files only be transferred over a direct connection and only when the panel is connected to a power supply.

The mini-USB connector MUST be plugged into a panel that is already active before the PC can recognize the connection and assign an appropriate USB driver.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Configuring and Using USB with a Virtual Master

NetLinx Studio can be set up to run a Virtual Master where the PC acts as the Master by supplying its own IP Address for communication to the panel. The PC is first equipped with the USB driver, the panel is then configured for USB communication, and then Studio is configured to act as the Master.

For a personal computer to establish a connection to a Modero panel via USB, the target computer must have the appropriate AMX USB driver installed. This installation is bundled into the latest TPDesign4 software setup process or can be downloaded independently from the main Application Files page on www.amx.com.

Step 1: Setup the Panel and PC for USB Communication

If you do not currently have the latest version of TPDesign4, navigate to www.amx.com > Tech Center > Downloadable Files > Application Files > NetLinx Design Tools section of the website

and locate the File Transfer 2 executable (FT2Setup.exe). This will install the native RNDIS USB driver when executed.

2. Download this executable file to a known location on your computer.

3. Launch the Setup.exe file and follow the on-screen prompts to complete the installation.

Step 2: Confirm the Installation of the USB Driver on the PC

The first time each AMX touch panel is connected to the PC, it is detected as a new hardware device and the panel-specific USBLAN driver becomes associated with it. Each time thereafter, the panel is "recognized" as a unique USBLAN device and the association to the driver is done in the background. When the panel is detected for the first time, some user intervention is required during the association between panel and driver.

1. After the installation of the USB driver has been completed, confirm the proper installation of the

large Type-A USB connector to the PC's USB port, and restart the PC.

If the panel is already powered, continue with step 3. The panel MUST be powered and configured for USB communication before connecting the mini-USB connector to the panel’s Program Port.

2. Connect the terminal end of the Ethernet cable to the connector on the side of the touch panel and

then apply power.

3. After the NXD-500i panel powers up, press and hold the Front Setup Access button for 4 seconds

to continue with the setup process and proceed to the Setup page.

4. Select Protected Setup > System Settings (located on the lower-left) to open the System Settings

page (FIG. 19).

No connection is established until the Virtual Master becomes active within NetLinx Studio

Red Connection Status icon -

indicates no connection to a Virtual Master

Green Connection Status icon -

indicates communication to a Virtual Master

FIG. 19 System Settings page - using a USB Connection type

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

5. Toggle the blue Typ e field (from the Master Connection section) until the choice cycles to USB.

Refer to the System Settings Page section on page 59 for more information about the fields on this page.

ALL fields are then greyed-out and read-only, but still display any previous network information.

6. Press the Back button on the touch panel to return to the Protected Setup page.

7. Press the on-screen Reboot button both to save any changes and restart the panel. Remember that

the panel’s connection type must be set to USB prior to rebooting the panel and prior to inserting the USB connector.

8. ONLY AFTER the device displays the first panel page should you THEN insert the mini-USB

connector into the Program Port on the panel. It may take a minute for the panel to detect the new connection and send a signal to the PC, as indicated by a green System Connection icon. If this is the first time for installing the USB driver, a USB driver installation popup window appears on the PC.

9. Click Ye s when told that a digital signature was not found. This action accepts the installation of the

new AMX USB driver. The panel is now configured to communicate directly with the PC.

10. Navigate back to the System Settings page.

 This window states that the panel has been detected by the PC as a USB-compliant device and

the PC is installing an appropriate USB driver to establish a proper communication to the panel.

 This driver was installed on the PC during the installation of the latest NetLinx Studio and

TPDesign4 software application installations. These applications should be installed prior to setting up a USB connection to the panel.

 Windows

 This process completes the association between driver and device. Each time the same touch

notes that the driver does not contain a Microsoft® digital signature.

panel is connected to the computer, the driver is automatically loaded (using a unique name - example USB LAN LINK #1, #2). Each time a different touch panel is connected to the computer, the previous procedures will need to be repeated.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Step 3: Confirm and View the current AMX USB device connections

The USB driver information can be confirmed via two different methods:

 Via the Control panel (previous steps 1 and 2) or

 Via the Unplug or Eject Hardware icon from the Taskbar.

1. Navigate to Start > Settings > Control Panel > and double-click the System icon to launch the

System Properties dialog.

2. Select the Hardware tab and click on the Device Manager button to launch the Device Manager

dialog.

 Within the Device Manager dialog, the AMX USBLAN device appears under Network

Adapters (FIG. 20) and has a unique name such as AMX USB LAN LINK #2. The number changes depending on which recognized panel is currently connected.

USB connected touch panel (showing the recognized panel)

FIG. 20 Device Manager dialog showing USB device

3. Confirm that a new USB detection icon (FIG. 21) appears in the lower-right taskbar on the PC

display window.

4. Double-click on the icon to open the Unplug or Eject Hardware window and confirm the AMX

USB LAN LINK has been installed and is operating properly.

A Virtual NetLinx Master (VNM) is used when the target panel is not connected to a physical NetLinx Master. In this situation, the PC takes on the functions of a Master via a Virtual NetLinx Master. This connection is made by either using the PC’s

Ethernet Address, via TCP/IP using a known PC’s IP Address as the Master, or using a direct mini-USB connection to communicate directly to the panel.

5. Click the Properties button to view further information about the installed USB driver.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

USB

detection

icon

FIG. 21 USB Properties windows

If a yellow exclamation point appears next to the AMX USB LAN LINK device (within the hardware devices section of the Unplug or Eject Hardware window), stop and close the USB operation. Reconnect the USB cable to the panel and repeat the setup procedures. Refer to the Troubleshooting section on page 131 for more detailed information.

To remove the USB driver association from a previously connected touch panel, navigate back to the Device Manager, right-click on the panel’s USB driver (example AMX USB LAN LINK #2) and select Uninstall from the context menu and then OK.

 Once the system completes the removal of the device, the Device Manager window will

refresh, and the device will no longer appear.

 The next time this device is connected to the computer, it will appear as a new hardware

device and will need to be associated again with the driver (refer to Step 2: Confirm the Installation of the USB Driver on the PC section on page 25 for more information).

Step 4: Use the USB to Configure a Virtual Master (using NetLinx Studio)

When configuring the panel to communicate via USB with a Virtual Master on your PC, ONLY the USB connection option must be selected within the Type field. Since this is a direct connection, the PC’s IP Address is not needed.

Before beginning:

1. Verify the panel has been configured to communicate via USB within the System Connection page

and that the USB driver has been properly configured. Refer to the previous section for more information.

2. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx

Studio 2 > NetLinx Studio 2).

3. Select Settings > Master Communication Settings, from the Main menu to open the Master

Communication Settings dialog (FIG. 22).

4. Click the Communications Settings button to open the Communications Settings dialog.

5. Click on the NetLinx Master radio button in the Platform Selection section to indicate that this is

working as a NetLinx Master.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

IP Address of computer (not needed as this is a direct USB connection)

FIG. 22 Assigning Communication Settings for a Virtual Master

6. Click on the Virtual Master radio box from the Transport Connection Option section to configure

the PC to communicate directly with a panel. Everything else, such as the Authentication, is greyed out because this action is not going through the Master’s UI.

7. Click the Edit Settings button on the Communications Settings dialog to open the Virtual NetLinx

Master Settings dialog (FIG. 22).

8. From within this dialog, enter the System number (default is 1).

9. Click OK three times to close the open dialogs, save the settings, and return to the main NetLinx

Studio application.

10. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System. The

default System value is one.

11. Right-click on the Empty Device Tree/System entry and select Refresh System to re-populate the

list.

The panel will not appear as a device below the virtual system number (in the Online Tree tab) until both the system number used in step 7 for the VNM is entered into the Master Connection section of the System Connection page and the panel is restarted.

 The Connection status turns green after a few seconds to indicate an active USB connection to

the Virtual Master on the PC. No Lock icon is displayed because this USB connection is not secured and does not require a username and password.

If the G4 panel does not appear, refer to the Troubleshooting section on page 131 for more information.

 If a few minutes have gone by and the System Connection icon still does not turn green, repeat

the USB connection and Virtual Master setup procedures (outlined in this section). Refreshing the System sends out a request to the panel to respond and completes the communication (turning the System Connection icon green).

Step 5: Confirm and View the current AMX USB device connections

Use the CC-USB Type-A to Mini-B 5-wire programming cable (FG10-5965) to provide communication between the mini-USB Program port on the touch panel and the PC. This method of communication is used to transfer firmware KIT files and TPD4 touch panel files.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

A mini-USB connection is only detected after it is installed onto an active panel. Connection to a previously powered panel which then reboots, allows the PC to detect the panel and assign an appropriate USB driver.

1. Verify this direct USB connection (Type-A on the panel to mini-USB on the panel) is configured

properly using the steps outlined in the previous two sections.

2. With the panel already configured for USB communication and the Virtual Master setup within

NetLinx Studio, its now time to verify the panel is ready to receive files.

3. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System. The

default System value is one.

4. Right-click on the System entry (A in FIG. 23) and select Refresh System. This causes a refresh of

all project systems, establishes a new connection to the Virtual Master, and populates the System list with devices on your particular system.

FIG. 23 Repopulating the System List

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Configuring a Wired Ethernet Connection

It is necessary to tell the panel as to which Master it should be communicating. This "pointing to a Master" is done via the System Settings page, where the IP Address, System Number and Username/ Password information assigned to the target Master is configured. Until those parameters are configured, your Connection Status icon will remain red, indicating that it has no current connection to a Master.

Step 1: Configure the Panel’s Wired IP Settings

This panel has only one method of communicating to a target Master over the Internet: Wired (direct Ethernet connection, as wireless communication is not available on the NXD-500i). The connection parameters may only be configured through the System Connection page. This type of communication can be established either via either a Dynamic IP Address (DHCP) or via a pre-reserved Static IP Address (typically provided by your System Administrator).

IP Settings section - Configuring a DHCP Address over Ethernet

Select Protected Setup > System Settings (located on the lower-left) to open the System Settings

page.

2. Locate the IP Settings section of this page.

Even though the Host, Gateway, Primary DNS, Secondary DNS, and Domain fields appear on the two separate System Connection and Secondary Connection pages;

the information populating these fields is identical.

If the information within one of these fields is altered, the change is reflected on both pages within the altered field. Example: if the domain is altered on the Secondary Connection page, the value is then also changed within the Domain field of the System Connection page.

3. Toggle the DHCP/Static field (from the IP Settings section) until the choice cycles to DHCP.

DHCP will register the unique factory-assigned MAC Address on the panel, and once the communication setup process is complete, reserve an IP Address, Subnet Mask, and Gateway values from the DHCP Server.

4. Press the optional Host Name field to open a Keyboard and enter the Host Name information.

5. Press Done after you are finished assigning the alpha-numeric string of the host name.

6. Do not alter any of the remaining greyed-out fields in the IP Settings section. Once the panel is

rebooted, these values are obtained by the unit and displayed in the DNS fields after power-up.

This information can be found in either the: Workspace- System name > Define Device section of the code that defines the properties for the panel, or in the Device Addressing/Network Addresses in the Tools > NetLinx Diagnostics dialog.

7. Press the Back button to return to the Protected Setup page.

8. Press the on-screen Reboot button to save any changes and restart the panel.

IP Settings section - Configuring a Static IP Address over Ethernet

Select Protected Setup > System Settings located on the lower left to open the System Settings

page.

2. Locate the IP Settings section of this page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Check with your System Administrator for a pre-reserved Static IP Address assigned to the panel. This address must be obtained before Static assignment of the panel continues.

3. Toggle the DHCP/Static field (from the IP Settings section) until the choice cycles to Static.

4. Press the IP Address field to open a Keyboard and enter the Static IP Address provided by your

System Administrator.

5. Press Done after you are finished entering the IP information.

6. Repeat the same process for the Subnet Mask and Gateway fields.

7. Press the optional Host Name field to open the Keyboard and enter the Host Name information.

8. Press Done after assigning the alpha-numeric string of the host name.

9. Press the Primary DNS field to open a Keyboard, enter the Primary DNS Address provided by your

System Administrator, and press Done when compete. Repeat this process for the Secondary DNS field.

10. Press the Domain field to open a Keyboard, enter the resolvable domain Address provided by your

System Administrator, and press Done when complete.

11. Navigate to the Master Connection section of this page to begin configuring the communication

parameters for the target Master.

Step 2: Choose a Master Connection Mode Setting

The Master Connection section of the System Connection page uses three Ethernet MODE settings. URL is the most common method.

 Master Connection MODE options:

• URL (Uniform Resource Locator) is the address that defines the route to a file on the Web or any other Internet facility. In this system, the panel acts as a "Client" and the Master acts as a Server (in that Clients attach to it).

• LISTEN sets the Modero panel to "listen" for broadcasts from the Master (using the panel IP from its URL list). In this system, the panel acts as a "Server" (in that Clients attach to it) and the Master acts as a "Client".

• AUTO is used to instruct the Modero to search for a Master that uses the same System Number (assigned within the Master Connection section) and resides on the same Subnet as itself. In this case, the Master has its UDP feature enabled. This UDP (User Datagram Protocol) is a protocol within the TCP/IP protocol suite that is used in place of TCP when a reliable delivery is not required. This UDP enabling is done through a Telnet session on the Master. Refer to the installation manual for the particular NetLinx Master for more detailed information.

Step 3: Configure an Ethernet Connection Type

When using Ethernet as the selected communication method, the NetLinx Master must first be set up with either a Static IP or DHCP Address obtained from either NetLinx Studio or your System Administrator.

Before beginning:

1. Verify that the panel has been configured to communicate through an Ethernet cable connected from

the panel to a valid Ethernet Hub.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Before commencing, verify that the NetLinx Master is using the latest available version of its firmware.

2. Verify that the NetLinx Master is receiving power and is communicating via an Ethernet connection

with the PC running NetLinx Studio.

3. Verify that the green Ethernet LED on the rear Ethernet port on the Master is illuminated, indicating

a proper connection.

4. Verify that the yellow LED on the rear Ethernet port on the Master is blinking, indicating

communication with the device.

5. After the panel powers-up, press and hold the Front Setup Access button for 3 seconds to proceed

to the Setup page.

6. Select Protected Setup > System Connection (located on the lower-left) to open the System

Connection page (FIG. 24).

Obtained

from

NetLinx

Master

FIG. 24 System Connection page

Master Connection section - Virtual Master communication over Ethernet

When configuring the panel to communicate with a Virtual Master (on your PC) via Ethernet, the Master IP/URL field must be configured to match the IP Address of the PC. Make sure to use the Virtual System value assigned to the Virtual Master within NetLinx Studio.

Before beginning:

1. Verify that the panel has been configured to communicate through an Ethernet cable connected from

the panel to a valid Ethernet Hub.

2. Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx

Studio 2 > NetLinx Studio 2).

3. Select Settings > Master Communication Settings, from the Main menu to open the Master

Communication Settings dialog (FIG. 25).

4. Click the Communications Settings button to open the Communications Settings dialog.

5. Click on the NetLinx Master radio button from the Platform Selection section to indicate that you

are working as a NetLinx Master.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Master IP/URL

System Settings

FIG. 25 Assigning Communication Settings and TCP/IP Settings for a Virtual Master

6. Click on the Virtual Master radio box from the Transport Connection Option section to indicate

you are wanting to configure the PC to communicate with a panel. All other fields will be greyed out because the Master’s UI is not being used.

7. Click the Edit Settings button on the Communications Settings dialog to open the Virtual NetLinx

Master Settings dialog (FIG. 25).

8. From within this dialog, enter the System number (default is 1) and note the IP Address of the target

PC being used as the Virtual Master. This IP Address can also be obtained by following these procedures:

9. Click OK three times to close the open dialogs, save your settings, and return to the main NetLinx

Studio application.

10. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System. The

default System value is one.

11. Right-click on the Empty Device Tree/System entry and select Refresh System to re-populate the

list.

12. Power-up your panel and press and hold the grey Front Setup Access button (for 3 seconds) to

continue with the setup process and proceed to the Setup page.

13. Select Protected Setup > System Connection, located on the lower left, to open the System

Connection page (FIG. 26).

14. Press the blue Type field in the Master Connection section until the choice cycles to Ethernet.

15. Press the Mode field until the choice cycles to the word URL.

16. Press the Master IP/URL field to open a Keyboard and enter the IP Address of the PC used as the

Virtual Master.

Enter this IP

into the

field on the

page

 On your PC, click Start > Run to open the Run dialog.

 Enter cmd into the Open field and click OK to open the command DOS prompt.

 From the C:\> command line, enter ipconfig to display the IP Address of the PC. This

IP Addresses of computer (also obtained by using the Start > Run > cmd command)

information is entered into the Master IP/URL field on the panel.

 By selecting URL, the System Number field becomes read-only (grey) because the panel pulls

this value directly from the communicating target Master (virtual or not). A Virtual Master system value can be set within active AMX software applications such as NetLinx Studio, TPD4, or IREdit.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

The System Number is assigned to the Master within the AMX software application (these must match)

Enter the IP Address information of the PC used as a Virtual Master

When using a Virtual Master, there is no need to enter a username and/or password

FIG. 26 Sample System Connection page (for Virtual Master communication)

17. Click Done to accept the new value and return to the System Connection page.

18. Do not alter the Master Port Number value. This is the default value used by NetLinx.

19. Press the Back button to open the Protected Setup page.

20. Press the on-screen Reboot button to save any changes and restart the panel.

Master Connection section - NetLinx Master Ethernet IP Address - URL Mode

In this mode, enter the System Number (zero for an unknown System Number) and the IP/URL of the Master (Master Port Number is defaulted to 1319).

1. Press the blue Type field from the Master Connection section until the choice cycles to Ethernet

(FIG. 26). Refer to the System Settings Page section on page 59 for more information about the fields on this page.

2. Press the Mode field until the choice cycles to URL.

 By selecting URL, the System Number field becomes read-only (grey) because the panel pulls

this value directly from the communicating target Master, virtual or not. A Virtual Master system value can be set within the active AMX software applications such as NetLinx Studio, TPD4, or IREdit.

If the panel does not appear within the OnLine Tree tab of the Workspace window of NetLinx Studio, check to make sure that the NetLinx Master System Number from within the Device Addressing dialog is correctly assigned.

3. Press the Master IP/URL field to open a Keyboard and enter the Master IP Address obtained from

the Diagnostics - Networking Address dialog of the NetLinx Studio application.

4. Click Done to accept the new value and return to the System Connection page.

5. Do not alter the Master Port Number value. This is the default value used by NetLinx.

6. Enter a username and password (into their respective fields) if the target Master has been previously

secured.

7. Press the Back button to open the Protected Setup page.

8. Press the on-screen Reboot button to both save any changes and restart the panel.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

Master Connection section - NetLinx Master Ethernet IP Address - Listen Mode

In this mode, add the Modero panel IP Address into the URL List of the Master by using NetLinx Studio. This mode sets the Modero panel to "listen" for broadcasts from the Master (using the panel IP from its URL list).

1. Obtain either a Static IP for the Modero panel (from your System Administrator) or a DHCP

Address from the IP Settings of the System Connection page.

2. Toggle the Typ e field until Ethernet is selected (from the Master Connection section of the System

Connection page).

3. Press the Mode field (to set the connection Mode) until the choice cycles to Listen. The System

Number and Master IP/URL fields are then greyed out.

4. Enter a username and password into their respective fields if the target Master has been previously

secured.

5. Select the OnLine Tree tab from the Workspace window.

6. Enter the System and Device number for the specific Master associated with the touch panel as seen

in the OnLine Tree tab.

7. Click Add and enter the IP Address of the Modero touch panel into the Add URL dialog.

8. Click OK to enter the IP Address and add it to the list.

9. Click Done when finished adding your panel information to the list.

10. Press the on-screen Reboot button to save any changes and restart the panel.

 The DHCP/Static field, in the IP Settings section of the System Connection page, must be set

to DHCP to get Dynamic IP information for the panel.

 Press the on-screen Reboot (from the Protected Setup page) to save any changes and restart

the panel.

 After power-up, press the front button for 3 seconds to access the Setup page.

 Navigate to the Setup > Protected Setup > System Connection page and note the newly

obtained Dynamic IP Address information from the IP Settings section. This information is then entered into the URL List for the connected NetLinx Master.

Master Connection section - NetLinx Master Ethernet IP Address - Auto Mode

In this mode, enter the System Number of the NetLinx Master. This mode instructs the Modero to search for a Master that uses the same System Number (assigned within the Master Connection section) and

resides on the same Subnet as itself.

1. Toggle the blue Typ e field until Ethernet is selected from the Master Connection section of the

System Connection page.

2. Press the Mode field until the choice cycles to the word Auto .

3. Press the System Number field to launch a Keypad and enter the value for the system number of the

NetLinx Master. This value can be obtained from the NetLinx Studio program > OnLine Tree of the Workspace window.

4. Do not alter the IP Settings section of the System Connection page, as these fields are not applicable

to this connection mode.

5. Enter a username and password into their respective fields if the target Master has been previously

secured.

6. Press the on-screen Reboot button to save any changes and restart the panel.

7. Press the grey Front Setup Access button for 3 seconds to open the Setup page and confirm an

active connection.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

The NetLinx Master and the Modero panel must both be on the same Subnet.

Using G4 Web Control to Interact with a G4 Panel

The G4 Web Control feature allows a PC to interact with a G4-enabled panel via the web. This feature works in tandem with the new browser-capable NetLinx Security firmware update (build 300 or higher). G4 Web Control is only available with the latest Modero panel firmware.

Refer to the G4 Web Control Page section on page 62 for more detailed information on G4 Web control.

Verify that the NetLinx Master (ME260/64 or NI-Series) has been installed with the latest firmware KIT file from www.amx.com. Refer to the NetLinx Master instruction manual for more detailed information on the use of the new web-based NetLinx Security.

1. Press the Front Setup Access button for 3 seconds to open the Setup page.

2. Press the Protected Setup button located on the lower-left of the panel page to open the Protected

Setup page and display an on-screen keypad.

3. Enter 1988 into the Keypad’s password field (1988 is the default password) and press Done when

finished.

Clearing Password #5, from the initial Password Setup page, removes the need to enter the default password before accessing the Protected Setup page.

4. Press the G4 WebControl button to open the G4 Web Control page (FIG. 27).

FIG. 27 G4 Web Control page

5. Press the Enable/Enabled button until it toggles to Enabled (light blue color).

6. The Network Interface Select field is read-only and displays the method of communication to the

web. Verify the selection of the proper interface connection, as this field does not auto-detect the connection type being used (see below).

 Wired is used when a direct Ethernet connection is being used for communication to the web.

This is the default setting if no wireless interface card is detected or if both an Ethernet and wireless card connection is detected by the panel.

 Wireless is used when a wireless card is detected within the internal card slot. The NXD-500i

panel does not provide wireless communication, so this option is not available.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

7. Press the Web Control Name field to open the Web Nam e keyboard.

8. From the Web N am e keyboard, enter a unique alphanumeric string to identify this panel and press

Done when finished. This information is used by the NetLinx Security Web Server to display onscreen links to the panel. The on-screen links use the IP Address of the panel and not the name for communication (FIG. 28).

FIG. 28 Sample relationship between G4 Web Control and Mange WebControl Connections window

9. Press the Web Control Password field to open the Web Pa s swo r d keyboard.

10. From the Web Password keyboard, enter a unique alpha-numeric string to be assigned as the G4

Authentication session password associated with VNC web access of this panel. Press Done when finished.

11. Press the Web Control Port field to open the Web Port Number keypad.

12. Within the keypad, enter a unique numeric value to be assigned to the port being used by the VNC

Web Server and press Done when finished. The default value is 5900. The remaining fields within the G4 Web Control Settings section of this page are read-only and cannot be altered.

13. Press the Up/Down arrows on either sides of the G4 Web Control Timeou t field to increase or

decrease the amount of time the panel can remain idle (no cursor movements) before the session is closed and the user is disconnected.

14. Press the Back button to open the Protected Setup page.

15. Press the on-screen Reboot button to save any changes and restart the panel.

Verify that the NetLinx Master’s IP Address and System Number have been properly entered into the Master Connection section of the System Connection page.

Using the NetLinx Master to control the G4 panel

Refer to the particular NetLinx Master’s instruction manual for detailed information on how to download the latest firmware from www.amx.com. This firmware build enables SSL certificate identification and encryption, HTTPS communication, ICSP data encryption, and disables the ability to alter the Master security properties via a TELNET session.

In order to fully utilize the SSL encryption, your web browser should incorporate the an encryption feature. This encryption level is displayed as a Cipher strength.

Once the Master’s IP Address has been set through NetLinx Studio version 2.x or higher:

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

1. Launch your web browser.

2. Enter the IP Address of the target Master (ex: http://198.198.99.99) into the web browser’s Address

field.

3. Press the Enter key on your keyboard to begin the communication process between the target

Master and your computer.

 Initially, the Master Security option is disabled from within the System Security page, and no

username and password is required for access or configuration.

 Both HTTP and HTTPS Ports are enabled by default via the Manage System > Server page.

 If the Master has been previously configured for secured communication, click OK to accept

the AMX SSL certificate (if SSL is enabled) and then enter a valid username and password into the fields within the Login dialog.

4. Click OK to enter the information and proceed to the Master’s Manage WebControl Connections

window.

5. The Manage WebControl Connections page (FIG. 29) is accessed by clicking on the Manage

connections link within the Web Control section in the Navigation frame. Once activated, this page

displays links to G4 panels running the latest G4 Web Control feature previously setup and activated on the panel.

Compatible devices field (showing G4

G4 panels

FIG. 29 Manage WebControl Connections page (populated with compatible panels)

WebControl links)

Compression Options

6. Click on the G4 panel name link associated with the target panel. A secondary web browser window

appears on the screen (FIG. 30).

7. Click Ye s from the Security Alert popup window to agree to the installation of the G4 WebControl

application on your computer. This application contains the necessary Active X and VNC client applications necessary to view and control the panel pages from your computer.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

FIG. 30 Web Control VNC installation and Password entry screens

The G4 Web Control application is sent by the panel to the computer that is used for communication. Once the application is installed, this popup will no longer appear. This popup will only appear if connecting to the target panel using a different computer.

8. In some cases, a Connection Details dialog (FIG. 31) may appear that requests a VNC Server IP

Address. This is the IP Address of the target touch panel, not the IP of the Master. Depending on the method of communication being used, it can be found in either the:

 Wired Ethernet - System Connection > IP Settings section within the IP Address field.

 Wireless - Not available with the NXD-500i panel.

 If this field does not appear, continue to step 9.

IP Address of touch panel

- obtained from IP Settings section of the System Connection page

FIG. 31 Connection Details dialog

9. If a WebControl password was set up on the G4 WebControl page, a G4 Authentication Session

password dialog box appears on the screen within the secondary browser window.

10. Enter the Web Control session password into the Session Password field (FIG. 30). This password

was previously entered into the Web Control Password field within the G4 Web Control page on the panel.

11. Click OK to send the password to the panel and begin the session. A confirmation message appears

stating "Please wait, Initial screen loading.".

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

The secondary window then shows the same G4 page being displayed on the target G4 panel. A small circle appears within the on-screen G4 panel page and corresponds to the location of the mouse cursor. A left-mouse click on the computer-displayed panel page is the same as an actual touch on the target G4 panel page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Configuring Communication

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Upgrading Modero Firmware

Before beginning the Upgrade process:

 Set up and configure your NetLinx Master. Refer to the particular NetLinx Master Instruction

Manual for detailed setup procedures.

 Calibrate and prepare the communication pages on the panel for use. Refer to the Panel

Calibration section on page 21.

 Refer to the NetLinx Studio version 2.x or higher Help file for more information on uploading

files.

 Configure the panel for a direct connection. Refer to the Configuring Communication section

on page 23 for more information.

The process of updating firmware involves the use of a communicating NetLinx Master. The required steps for updating firmware to a Modero panel are virtually identical to those necessary for updating Kit files to a NetLinx Master, except the target device is a panel instead of a Master. Refer to either the Master’s User Manual or Studio 2.x Help file for those procedures.

A touch panel which is not using a valid username and password will not be able to communicate with a secured Master. If you are updating the firmware on or through a panel which is not using a username or password field, you must first remove the Master Security feature to establish an unsecured connection.

Upgrading Modero Firmware

Upgrading the Firmware via the USB port

Before beginning with this section, verify your panel is both powered and the Type-A USB connector is securely inserted into the PC’s USB port. The panel must be powered on before connecting the

mini-USB connector to the panel.

Establishing a USB connection between the PC and the panel prior to installing the latest NetLinx Studio and TPDesign4 applications will cause a failure in the USB driver installation. This driver must first be saved to the PC as part of the new NetLinx Studio and TPDesign4 application installations.

Step 1: Configure the panel for a USB Connection Type

After the installation of the USB driver has been completed, confirm the proper installation of the large Type-A USB connector to the PC's USB port and restart your machine.

2. After the NXD-500i panel powers-up, press and hold the grey Front Setup Access button for 4

seconds to continue with the setup process and proceed to the Setup page.

3. Select Protected Setup > System Settings, located on the lower-left, to open the System Settings

page.

4. Toggle the blue Typ e field in the Master Connection section until the choice cycles to USB.

ALL fields are now greyed out and read-only, but they still display any previously shown network information.

5. Press the Back button on the touch panel to return to the Protected Setup page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Upgrading Modero Firmware

6. Press the on-screen Reboot button to save any changes and restart the panel. Remember that the

panel’s connection type must be set to USB prior to rebooting the panel and prior to inserting the USB connector.

7. ONLY AFTER the unit displays the first panel page should the mini-USB connector THEN be

inserted into the Program Port on the panel. It may take a minute for the panel to detect the new connection and send a signal to the PC, indicated by a green System Connection icon.

8. Navigate back to the System Connection page.

Step 2: Prepare NetLinx Studio for communication via the USB port

Launch NetLinx Studio 2.x (default location is Start > Programs > AMX Control Disc > NetLinx

Studio 2 > NetLinx Studio 2).

2. Select Settings > Master Communication Settings from the Main menu to open the Master

Communication Settings dialog (FIG. 32).

 If a few minutes have gone by and the System Connection icon still does not turn green,

complete the procedures in the following section to set up the Virtual Master and refresh the System from the Online Tree. This action sends out a request to the panel to respond and completes the communication, turning the System Connection icon green.

IP Address of computer (not needed as this is a direct USB connection)

FIG. 32 Assigning Communication Settings for a Virtual Master

3. Click the Communications Settings button to open the Communications Settings dialog.

4. Click on the NetLinx Master radio button from the Platform Selection section to work as a NetLinx

Master.

5. Click on the Virtual Master radio box from the Transport Connection Option section to configure

the PC to communicate directly with a panel. Everything else, such as the Authentication, is greyedout because the communication is not going through the Master’s UI.

6. Click the Edit Settings button on the Communications Settings dialog to open the Virtual NetLinx

Master Settings dialog (FIG. 32).

7. From within this dialog, enter the System number (default is 1).

8. Click OK three times to close the open dialogs, save the settings, and return to the main NetLinx

Studio application.

9. Click the OnLine Tree tab in the Workspace window to view the devices on the Virtual System. The

default System value is one.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Upgrading Modero Firmware

10. Right-click on the Empty Device Tree/System entry and select Refresh System to re-populate the

list. The panel will not appear as a device below the virtual system number in the Online Tree tab

until both the system number used in step 7 for the Virtual NetLinx Master (VNM) is entered into the Master Connection section of the System Connection page and the panel is restarted.

If the G4 panel does not appear, refer to the Troubleshooting section on page 131 for more information.

Step 3: Confirm and Upgrade the firmware via the USB port

1. Verify that the direct USB connection (Type-A on the panel to mini-USB on the panel) is configured

properly using the steps outlined in the previous two sections.

2. After the Communication Verification dialog window verifies active communication between the

Virtual Master and the panel, click the OnLine Tree tab in the Workspace window (FIG. 33) to view the devices on the Virtual System. The default System value is one.

3. Right-click on the System entry (FIG. 33) and select Refresh System to re-populate the list.

Verify the panel appears in the OnLine Tree tab of the Workspace window. The default Modero panel value is 10001.

Showing the Virtual Master firmware version and device number

Shows NetLinx Studio version number

Showing the current Modero panel firmware version and device number

FIG. 33 NetLinx Workspace window (showing the panel connection via a Virtual NetLinx Master)

The panel firmware is shown on the right of the listed panel. Download the latest firmware file from www.amx.com and then save the Kit file to your computer.

4. If the panel firmware being used is not current, download the latest Kit file by first logging in to

www.amx.com and then navigate to Tec h Ce n t er > Firmware Files and from within the Modero section of the web page locate your Modero panel.

5. Click on the desired Kit file link and after you’ve accepted the Licensing Agreement, verify you

have downloaded the Modero Kit file to a known location.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Upgrading Modero Firmware

6. From within Studio, select Tools > Firmware Transfers > Send to NetLinx Device from the Main

menu to open the Send to NetLinx Device dialog (B in FIG. 34). Verify the panel’s System and Device number values match those values listed within the System folder in the OnLine Tree tab of the Workspace window (A in FIG. 34).

FIG. 34 Using USB for a Virtual Master transfer

7. Select the panel’s Kit file from the Files section.

8. Enter the Device value associated with the panel and the System number associated with the Master

listed in the OnLine Tree tab of the Wor ks pa c e window. The Port field is greyed-out.

9. Click the Reboot Device checkbox. This causes the touch panel to reboot after the firmware update

process is complete. The reboot of the panel can take up 30 seconds after the firmware process has finished.

10. Click Send to begin the transfer. The file transfer progress is indicated on the bottom-right of the

dialog (B in FIG. 34).

11. As the panel is rebooting, temporarily unplug the USB connector on the panel until the panel has

completely restarted.

12. Once the first panel page has been displayed, reconnect the USB connector to the panel.

13. Right-click the associated System number and select Refresh System. This causes a refresh of all

project systems, establishes a new connection to the Master, and populates the System list with devices on your particular system.

14. Confirm that the panel has been properly updated to the correct firmware version.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

This section describes the Setup and Protected Settings pages and their specific functional elements.

Setup Navigation Buttons

These Setup Navigation Buttons (FIG. 35) appear on the left of the panel screen when the Setup page is currently active.

Closes the Setup page

Press to access the Protected Setup page for panel calibration and to access security release passwords and connection settings.

Press to access the Information menu and select either Project Information or Panel Information.

Press to access the Time Adjustment page to alter the time and date settings on the Master.

Press the Audio Adjustments button to access the Audio Settings page to alter the audio parameters on the Modero panel.

Setup Pages and Descriptions

FIG. 35 Setup Navigation Buttons

Protected Setup

This button opens the Protected Setup page which centers around the properties used by the panel to communicate with the NetLinx Master. Refer to both the Protected Setup Navigation Buttons section on page 56 and the Protected Setup section on page 47 for more detailed information.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Setup Page

This page (FIG. 36) centers around basic Modero panel properties, such as the Connection Status of the panel, Display Timeout, Inactivity Page Flip Time, Inactivity page file, and the Panel Brightness.

FIG. 36 Setup page

The elements of the Setup page are described below:

Setup Page Elements

Exit: Returns to the Main touch panel page. In this case, the previous page is the

Connection Status icon: This visual display of the connection status allows the user to have a current

Connection Status: Displays whether the panel is communicating externally, the encryption status

Display Timeout: Sets the length of time the panel can remain idle before activating the sleep

Connection Status

Red Connection Status icon -

indicates no connection to a Master

Green Connection Status icon -

indicates communication to a Master

default Main page.

update of the panel’s connection status regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password).

of the communicating Master, what connection type is being used (Ethernet or USB), and of what System the panel is a part.

This visual display of the connection status is also reflected at the upper-right of each firmware page. This allows the user to have a current visual update of the panel’s connection status regardless of what page is currently active.

• When a connection is established, the message displayed is either: "Connected via Ethernet " or "Connected via USB ".

• If no connection can be established by the Modero panel, it will continue to try and establish a connection while displaying: "Attempting via...".

• The word "Encrypted" appears only when an encrypted connection is established with a target Master.

• The panel must be rebooted before incorporating any panel communication changes and detecting any active Ethernet connections.

The Ethernet connection is only detected after the panel is rebooted.

mode. When the device goes into sleep mode, the LCD is powered down.

• Press the UP/DN buttons to increase/decrease the time until the panel times out. Range = 0 - 240 minutes.

• Use this button to set the timeout value to zero and disable the sleep mode.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Page Elements (Cont.)

Inactivity Page Flip Time:

Panel Brightness: Sets the display brightness level of the panel.

Sets the number of minutes of inactivity before the panel automatically flips to a pre-selected touch panel page. When the device goes into this inactivity mode, the LCD does not power down.

• Press the UP/DN buttons to increase/decrease the time the panel can remain inactive before it flips to the preset page. Range = 0 - 240 minutes.

• Use this button to set the timeout value to zero and disable the inactivity page flip mode.

• The touch panel page used for the Inactivity page flip is shown within a small Inactivity Page field.

• Press the UP/DN buttons to adjust the brightness level. Range = 0 - 100.

• The on-screen bargraph can be dragged to adjust the Brightness level which is then reflected as a corresponding numeric value within the Panel Brightness field.

• The Auto Brightness button, when selected, will cause the panel to dim as the light level decreases, in order to reflect the brightness level of the room. If the panel is touched, the backlight will temporarily brighten the panel more than the previously selected level.

Setup Pages and Descriptions

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Information

Pressing and holding the Information button provides a menu to select either the Panel Information page or the Panel Information page. Select either option to access that page.

Panel Information Page

The Project Information page displays the TPDesign4 (TPD4) project file properties currently loaded on the selected Modero panel (FIG. 37). Refer to the TPDesign4 Touch Panel Program instruction manual for more specific information on uploading TPDesign4 files to a panel.

FIG. 37 Project Information page

The elements of the Project Information page are described in the table below:

Project Information Page Elements

Back: Returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password).

File Name: Displays the name of the TPDesign4 project file downloaded to the panel.

Designer ID: Displays the designer information.

File Revision: Displays the revision number of the file.

Dealer ID: Displays the dealer ID number (unique to every dealer and entered in TPD4).

Job Name: Displays the job name.

Sales Order: Displays the sales order information.

Purchase Order: Displays the purchase order information.

AMX IR Ports: Displays the AMX 38 kHz IR channel port used by the IR receiver on the panel.

• This information is pulled by the panel from AMX IR Receivers section of the TPD4 Project Properties > IR Emitters & Receivers tab.

• For IR reception, this is the port that reports a push on for the corresponding IR code.

• IR receivers and transmitters on G4 panels share the device address number of the panel.

Build Number: Displays the build number information of the TPD4 software used to create the

project file.

Creation Date: Displays the project creation date.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Project Information Page Elements (Cont.)

Revision Date: Displays the last revision date for the project.

Last Save Date: Displays the last date the project was saved.

Blink Rate: Displays the feedback blink rate (10th of second).

Job Comments: Displays any comments associated to the job. These comments are taken from

the TPD4 project file.

Panel Information Page

The Panel Information page (FIG. 38) centers around Modero panel properties that include resolution used, on-board memory, firmware, address/channel information, and string information.

This information is retrieved

from the Modero panel

FIG. 38

Panel Information page

The elements of the Panel Information page are as follows:

Panel Information Page Elements

Back: Returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status, regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master requiring a username and password.

Panel Type: Displays the model of the Modero panel being used.

Firmware Version: Displays the G4 firmware version being used by the panel.

• Verify that the panel has the latest version from www.amx.com.

Setup Port: Displays the setup port information/value being used by the panel.

High Port: Displays the high port (port count) value for the panel.

High Address: Displays the high address (address count) value for the panel.

High Channel: Displays the high channel (channel count) value for the panel.

High Level: Displays the high level (level count) value being used by the panel.

Serial Number: Displays the specific serial number value assigned to the panel.

Setup Pages Version: Displays the type and version of the Setup pages being used by the panel.

Screen Width: Displays the pixel width being used to display the incoming video signal on the

Modero panel.

• The maximum available screen width on a NXD-500i panel is 800 pixels.

Screen Height: Displays the pixel height being used to display the incoming video signal on the

Modero panel.

• The maximum available screen height on a NXD-500i panel is 480 pixels.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Panel Information Page Elements (Cont.)

Screen Refresh Rate: Displays the video refresh rate applied to the incoming video signal from the

Screen Rotation: Displays the degree of rotation applied to the on-screen image.

Power Up Pages: Displays the first touch panel page assigned for display after the device is

Start Up String: Displays the start-up string.

Wake Up String: Displays the wake up string used after an activation from a timeout.

Sleep String: Displays the sleep string used during a panel’s sleep mode.

File System: Displays the amount of Flash memory available on the Modero panel.

RAM: Displays the available RAM (or Extended Memory module) on the Modero

Panel Start Time: Displays the last time the panel booted.

Bulb Hours: Displays the total time that the panel has been at full brightness.

panel. Default rate is 60.

powered-up.

• This information is taken from the TPD4 project file.

• Most projects begin with a Main page.

panel.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Time & Date Settings Page

The Time & Date Settings page (FIG. 39) allows setting and alteration of the time and date information on the NetLinx Master. If either the Time or Date is modified on this page and then updated to the Master by pressing the Set Time button, all devices communicating to that target Master will then be updated to reflect the new information.

Date Display

Time Display

fields

Currently

selected

FIG. 39 Time and Date Settings page

fields

The only way to modify a panel’s time, without altering the Master, is through NetLinx code.

The elements of the Time & Date Setup page are as follows:

Time & Date Setup Page Elements

Back: Returns to the previously active touch panel page without saving changes.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password).

Time Date Refresh/Set: This section provides two options:

• The Get Time/Date button retrieves the Time and Date information from the Master.

• The Set Time/Date button sets the Master to retain and save any time/date modifications made on the Time & Date Setup page.

Time Display fields: • These fields display the time in three formats: STANDARD, STANDARD

AM/PM, and 24 HOUR.

Date Display fields: • These fields display the calendar date information in several different formats.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Time & Date Settings Page Elements (Cont.)

Set Date/Time: This section provides a user with both UP/DN arrow buttons to alter the

NXD-500i touch panels do not have an onboard clock. This page both receives and sets the time and date of the NetLinx Master.

Master’s calendar date and time. The blue circle indicates which field is currently selected.

• Select the Year field and use the UP/DN buttons to alter the year value (range = 2000 - 2037).

• Select the Month field and use the UP/DN buttons to alter the month value (range = 1 - 12).

• Select the Day field and use the UP/DN buttons to alter the day value (range = 1 - 31).

• Select the Hour field and use the UP/DN buttons to alter the hour value (24-hour military).

• Select the Minute field and use the UP/DN buttons to alter the minute value (range = 0 - 59).

• Select the Second field and use the UP/DN buttons to alter the second value (range = 0 - 59).

Audio Settings Page

The Audio Settings page (FIG. 40), accessed by pressing the Audio button on the Setup page, allows adjustment of the master volume parameters and default panel sounds on the panel.

FIG. 40 Audio Settings page

The elements of the Audio Settings page are as follows:

Audio Settings Page Elements

Back: Saves the changes and returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status, regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master, requiring a username and password.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Volume Page Elements (Cont.)

Default Panel Sounds: Sets the panel to play various sounds.

• Activating the Button Hit button plays a default sound when touching an active button.

• Activating the Button Miss button plays a default sound when touching a non-active button or any area outside of the active button

• The Play Test Sound button plays a test WAV/MP3 file over the panel’s internal speakers.

Intercom Mic Level: Allows adjustment of the current Microphone volume level being received from

the intercom.

• Use the UP/DN buttons to adjust the Microphone volume level (range = 0 - 100).

• The Mic Out Level bargraph indicates the current Mic Out level.

Internal Sound Level: This section allows you to adjust the current sound level on the internal panel

speaker:

• Use the UP/DN buttons to adjust the volume output on the internal speakers (range = 0 - 100).

• The Internal Sound Level bargraph indicates the current sound level.

• The Mute button mutes the volume.

Intercom Volume: This section allows alteration of the current intercom volume level:

• Use the UP/DN buttons to adjust the volume level (range = 0 - 100).

• The Master Volume bargraph indicates the current volume level.

• The Mute button toggles the Mute feature.

Supported sampling rates for WAV

The following is a listing of supported sampling rates associated for WAV files played on a NXD-500i panel. Some WAV files currently played on other Modero panels may not work on a NXD-500i. The supported sampling rates for WAV files are:

Supported WAV Sampling Rates

• 48000 Hz • 16000 Hz

• 44100 Hz • 12000 Hz

• 32000 Hz • 11025 Hz

• 24000 Hz • 8000 Hz

• 22050 Hz

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Protected Setup Navigation Buttons

The Protected Setup navigation buttons (FIG. 41) appear on the left of the panel screen when the Protected Setup page is currently active.

Press to access the System Settings page to configure communication settings for the NetLinx Master and the panel.

This button has been disabled.

Press to access the Calibration page to calibrate the panel.

Press to access the G4 Web Control page to enable or disable remote display and control of the panel via a web-enabled PC running a VNC client.

Press to access the Other Settings menu and select either Cache or Passwords.

Press to access the Tools menu and select either Panel Logs, Panel Statistics, or Connection Utility.

FIG. 41 Protected Setup Navigation Buttons

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Protected Setup Page

The Protected Setup page (FIG. 42) centers around the properties used by the panel for proper communication with the NetLinx Master. Enter the factory default password (1988) into the password keypad to access this page.

Provides access to the panel firmware pages by enabling the grey front setup access button:

- Setup page (after a 3-second press/hold)

- Calibration page (after a 6-second

press/hold)

FIG. 42 Protected Setup page-showing default values

The elements of the Protected Setup page are described in the table below:

Protected Setup Page Elements

Back: Saves the changes and returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

Device ID: Number: Opens a keypad that is used to set and display the current device

Options: Allows selection of various touch panel features:

visual update of the panel’s connection status regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master, requiring a username and password.

number.

Name: Opens a keypad that is used to set and display the current device name.

• The Function Show button enables the display of the channel port and channel code in the top left corner of the button, the level port and level code in the bottom left corner, and the address port and address code in the bottom right corner (see FIG. 44 for an example of the function locations).

• Use the Page Tracking button to toggle page tracking. When enabled, the touch panel sends page data back to the NetLinx Master, or vice versa depending on the touch panel settings.

• Use the Te lne t button to enable or disable the telnet server on the panel. This feature focuses on direct telnet communication to the panel.

•Use the Front Button Setup Access button to activate the grey Front Setup Access button (located below the LCD) to access the firmware pages.

- Default condition is On.

- Press and hold this grey button for 3 seconds to access the Setup page.

- Press and hold this grey button for 6 seconds to access the Calibration page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Protected Setup Page Elements (Cont.)

System Recovery: Either resets the touch panel to factory default settings and/or wipes out all

Reboot/Shutdown Panel: Reboot: Pressing this button causes the panel to restart after saving any

existing touch panel pages:

• The Reset System Settings button allows a user to wipe out all current configuration parameters on the touch panel (such as IP Addresses, Device Number assignments, Passwords, and other presets).

- Pressing this button launches a Confirmation dialog (FIG. 43) which asks you to confirm your selection.

- This dialog is configured with a delay timer that does not enable the YES button for 5 seconds. This delay provides an additional amount of time for the user to confirm their decision.

• The Remove User Pages button allows the removal of all current TPD4 touch panel pages currently on the panel (including the pre-installed AMX Demo pages).

- Pressing this button launches a Confirmation dialog (FIG. 43) which asks to confirm your selection.

- This dialog is configured with a delay timer that does not enable the YES button for 5 seconds. This delay provides an additional amount of time for the user to confirm their decision.

changes.

Shutdown: Pressing this button causes the panel to shut down after saving any changes.

FIG. 43

FIG. 44 Button/slider Function Show example

Protected Setup page-System Recovery confirmation dialog

Channel Port

3,132

Level Port

2,8 3,50

Channel Code

Number

Channel Code Number

Button

Address Port

Address Code Number

This dialog has a wait time of 5 seconds before the YES option is enabled.

Channel Port

Level Port

Channel Code

Number

7,10

4,9

Slider

Channel Code Number

Address Port

1,8

Address Code Number

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

System Settings Page

The System Settings page (FIG. 45) sets the Secondary DNS Address information with its corresponding IP communication parameters, NetLinx Master communication settings, and reads the device number assigned to the Modero panel.

IP Settings section

Master Connection section (NetLinx Master properties)

Master Connection features are not saved until the panel is rebooted

Red fields are user-editable

Blue fields cycle through choices

Grey fields are read-only

FIG. 45 System Settings page showing default values (reads and assigns values to the panel and Master)

The elements of the System Settings page are as follows:

System Settings Page Elements

Back: Saves the changes and returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

IP Settings:

DHCP/Static Sets the panel to either DHCP or Static communication modes.

IP Address Sets the secondary IP Address assigned to the panel.

Subnet Mask Sets a subnetwork address to the panel.

Gateway Sets a gateway value to the panel.

Host Name Sets the host name of the panel.

Primary DNS Sets the address of the primary DNS server used for host name lookups.

Secondary DNS Sets a secondary DNS value to the panel.

Domain Sets the unique name on the Internet to the panel for DNS look-up.

visual update of the panel’s connection status, regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master, which requires a username and password.

• DHCP (Dynamic Host Configuration Protocol) assigns IP Addresses from client stations logging onto a TCP/IP network via a DHCP server.

• Static IP is a permanent IP Address that is assigned to a node in a TCP/IP network.

• Subnetwork mask is the technique used by the IP protocol to filter messages into a particular network segment (Subnet).

• Gateway is a computer that either performs protocol conversion between different types of networks/applications or acts as a go-between two or more networks that use the same protocols.

• DNS (Domain Name System) is software that lets users locate computers on a local network or the Internet (TCP/IP network) by host and domain. The DNS server maintains a database of host names for its domain and their corresponding IP Addresses.

• The panel belongs to the DNS domain.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

System Connection Page Elements (Cont.)

IP Settings: (Cont.)

Ethernet Mode Sets the speed of the Ethernet connection to the panel.

MAC Address Displays a read-only field that is factory set by AMX for the built-in Ethernet

Master Connection: Sets the NetLinx Master communication values:

Ty p e Sets the NetLinx Master to communicate with the panel via either USB or

Mode Cycles between the different connection modes (URL, Listen, and Auto)

System Number Allows you to enter a system number. Default value is 0 (zero).

Master IP/URL Sets the Master IP or URL of the NetLinx Master.

Master Port Number Enters the port number used with the NetLinx Master.

Username/Password If the target Master has been previously secured, enter the alphanumeric string

NDP Name

USB IP Settings: Sets IP settings through the mini-USB port.

DHCP/Static Switches between HDHCP and Static connections.

IP Address The IP address of the device

• Choices are: Auto, 10 Half Duplex, 10 Full Duplex, 100 Half Duplex, or

100 Full Duplex.

interface.

Ethernet. This is based on the cable connection from the rear. ICSNet is not a

supported option on this panel.

• Ethernet is a CAT-5 cable (10/100Base T terminated in an RJ-45 connector) used to network computers together and is used in most LAN (local area networks). This description is also used to refer to both wired and wireless communication.

• USB option cannot be used on Modero panels which are not equipped with a USB port.

(ETHERNET Only - disabled when USB is selected)

• URL - In this mode, enter the IP/URL, Master Port Number, and username/password (if used) on the Master.

- The System Number field is read-only because the panel obtains this information from the communicating Master.

• Listen - In this mode, add the Modero panel address into the URL List in NetLinx Studio and set the connection mode to Listen. This mode allows the Modero touch panel to "listen" for the Master’s communication signals.

- The System Number and Master IP/URL fields are red-only.

• Auto - In this mode, enter the System Number and a username/password (if applicable). This mode is used when both the panel and the NetLinx Master are on the same Subnet and the Master has its UDP feature enabled.

- Master IP/URL field is read-only.

(ETHERNET Only - disabled when USB is selected)

• Default value is 1319. (ETHERNET Only - disabled when USB is selected)

(into each field) assigned to a pre-configured user profile on the Master. This profile should have the pre-defined level of access/configuration rights.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Calibration Page

The Calibration page (FIG. 46) allows you to calibrate the touch panel for maximum sensitivity.

 Press and hold the Front Setup Access button for 6 seconds to access the Calibration page.

 Press the crosshairs to calibrate the panel and return to the last active firmware page.

The request to touch the crosshairs is the first on-screen message

Calibration successful is the second on-screen message that appears after the calibration process is completed

On-screen crosshairs used for calibration of the touch device

FIG. 46

Calibration page (actually 3 separate screens)

If the calibration was improperly set and the Calibration page cannot be reached through the panel’s firmware, this firmware page may be accessed via

G4 Web Control. Navigate to the Protected Setup page and press the Calibrate button through the VNC window. This action causes the panel to go to the Calibration page seen above, where the touch panel may be physically recalibrated again using the above procedures.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

G4 Web Control Page

The G4 Web Control page (FIG. 47) centers around enabling and disabling both the display and control of your panel (via the web). An external PC running a VNC client, installed during the initial communication to the G4 panel, makes this possible.

FIG. 47 G4 Web Control page

Each panel supports the open standard Virtual Network Computing (VNC) interface. These panels contain a VNC server that allows them to accept a connection from any other device running a VNC client. Once a connection is established to that target device, the client can control the touch panel remotely. The elements of the G4 Web Control page are as follows:

G4 Web Control Page Elements

Back: Saves the changes and returns to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status regardless of what page is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master (requiring a username and password).

G4 Web Control Settings: Sets the IP communication values for the touch panel and contains:

Enable/Enabled • The Enable/Enabled button allows you to toggle between the two G4

activation settings:

- Enable - deactivates the G4 Web Control feature on the panel.

- Enabled - activates the G4 Web Control feature on the panel and allows an external PC running a VNC client to access the panel after the remaining fields are configured.

Network Interface Select Displays the detected method of communication to the web:

• Wired is used when a direct Ethernet connection is being used for communication to the web. This is a default setting.

Web Control Name Allows entry of a unique alphanumeric string used as the display name of the

Web Control Password Allows entry of the G4 Authentication session password associated for VNC

Web Control Port Allows entry of the VNC Web Server’s port value.

Maximum Number of Connections

panel within the Manage WebControl Connections window of the new NetLinx Security browser window.

• This Web Control tab displays a G4 icon alongside the link to the Web Control Name given to this panel (FIG. 48).

web access of this panel.

• Default value is 5900.

This read-only field displays the maximum number of users that can be simultaneously connected to the target panel via the Web.

• Default value is 1.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

G4 Web Control Page Elements (Cont.)

G4 Web Control Settings (Cont.):

Current Connection Count This read-only field displays the current number of users connected to the

G4 Web Control Timeout: Sets the length of time (in minutes) the panel can remain idle (no cursor

target panel via the Web. This value cannot exceed the Maximum number field.

movements) before the session is closed and the user is disconnected.

• Minimum value = 0 minutes (panel never times-out)

• Maximum value = 240 minutes (panel times-out after 240 minutes/4hours)

FIG. 48

Sample relationship between G4 Web Control and Mange WebControl Connections window

Refer to the Using G4 Web Control to Interact with a G4 Panel section on page 37 for more detailed instructions on how to use the G4 Web Control page with the new web-based NetLinx Security application.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Other Settings

Holding down the Other Settings button provides a menu to select the Image Caching page, the Password Settings page, or the Sensor Settings page. Select either option to access that page.

Cache Settings Page

The Cache Settings page (FIG. 49) configures the allocation of memory for image caching. The G4 graphics engine caches images to decrease load time of previously viewed images. RAM caching is always enabled, and both static and dynamic images are stored in the RAM cache as they are viewed. The size of RAM cache is automatically configured to take into account available memory versus memory that may be needed by the panel later. As the RAM cache approaches its maximum size, the oldest items in the cache may be discarded to make room for newer items. If Flash caching is enabled, dynamic images that would have been discarded will actually be moved to Flash, since retrieving images on Flash is typically faster than across a network, although it is slower than using a RAM cache. Note that since static images are already stored on Flash, they are never moved to the Flash cache, so Flash caching applies only to dynamic images. Images in Flash cache are moved back to RAM cache the next time they are viewed. As the Flash cache approaches its maximum size, the least recently used items may be discarded to make room for new items.

FIG. 49 Cache Settings Page

The elements of this page are as follows:

Cache Settings Page Elements

Back: Saves all changes and returns to the previous page.

Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state

of the panel to the master.

• Bright red - disconnected

• Bright green - connected. Blinks when a blink message is received to dark green every 5 seconds for half a second then go back to bright green.

• Bright yellow - panel missed a blink message from the master. It will remain yellow for 3 missed blink messages and then turn red. It will return to green when a blink message is received.

Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master.

Image Cache Settings: Allocates Flash memory for image caching.

Flash Cache Size Press the Up and Down arrows to add and remove flash memory. Flash

memory allocation cannot exceed the amount of Flash memory on the panel.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Cache Settings Page Elements (Cont.)

Flash/RAM Cache Expires Press the Up and Down arrows to change the amount of time the images stay

Enable: Press this button to toggle the image Flash cache option On and Off.

Clear Cache: Press this button to clear both the Flash and RAM cache of all stored images.

Image Cache Status: The status of the memory available versus in use.

RAM Max Size The maximum amount of memory available for all image caching.

RAM Current Size The memory currently in use for caching static and dynamic images.

RAM Hit Rate The percentage of image requests (static and dynamic) satisfied by accessing

Items in Cache (RAM) The number of images that are currently stored in the RAM cache.

Flash Current Size The maximum flash space allocated for image caching. Flash space is used for

Flash Hit Rate The percentage of image requests (dynamic only) that are satisfied by

Items in Cache (Flash) The number of images that are currently stored in the Flash cache.

in cache memory. The options are:

• Never

• 2 Hours

• 8 Hours

•1 Day

•2 Days

•5 Days

the cache.

100 * (# of cache hits) / (# of cache hits + # of cache misses)

# of cache hits - the number of times an image was requested that the image was found in the cache

# of cache misses - the number of times an image was requested that the image could not be found in the cache, and the image had to either be loaded from flash or obtained via the network (for dynamic images). It is considered a RAM Cache Miss even if the image is subsequently found in flash cache.

caching only when there is not enough available memory in the RAM cache for a newly requested image (it is used only for dynamic images).

accessing the flash cache.

100 * (# of flash cache hits) / (# of flash cache hits + # of flash cache misses)

# of flash cache hits - # of times a dynamic image could not be found in RAM cache but was found in flash cache

# of flash cache misses - # of times a dynamic image could not be found in either RAM or flash cache. RAM cache hits are not relevant in this calculation.

Setting the image cache

In the Protected Setup page:

1. Press the Cache button in the Protected Setup Navigation Buttons section. This opens the Image

Cache page.

2. Set the cache expiration in the field Flash/RAM Cache Expires. The Up and Down arrows increment

through the available time frames.

3. Press the Enable button to turn on image caching. The button is illuminated when enabled.

Flash memory may be allocated for image caching, but RAM cache is always enabled.

Select the Up and Down arrows for the field Flash Cache Size to increase or reduce the amount of Flash memory used; the maximum amount of flash that can be allocated for caching is 75% of available flash.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Clearing the image cache

In the Protected Setup page:

1. Press the Cache button in the Protected Setup Navigation Buttons section. This opens the Image

Cache page.

2. Press Clear Cache. This clears all image cache currently stored on the panel (both Flash and

RAM).

Checking image cache status

In the Protected Setup page:

1. Press the Cache button in the Protected Setup Navigation Buttons section. This opens the Image

Cache page. All status information is located in the Image Cache Status section of the page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Password Settings Page

The options on the Password Settings page allow you to assign the passwords required for users to access the Protected Setup page (FIG. 50).

FIG. 50 Password Settings page

Features on this page include:

Password Settings Page

Back: Saves all changes and returns to the previous page.

Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state

of the panel to the master.

• Bright red - disconnected

• Bright green - connected. Blinks when a blink message is received to dark green every 5 seconds for half a second then go back to bright green.

• Bright yellow - panel missed a blink message from the master. It will remain yellow for 3 missed blink messages and then turn red. It will return to green when a blink message is received.

Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master.

In Panel Password Change:

Accesses the alphanumeric values associated to particular password sets.

• The PASSWORD 1, 2, 3, 4 and 5 (protected) buttons open a keyboard to enter alphanumeric values associated to the selected password group.

Note: Clearing Password #5 removes the need to enter a password before accessing the Protected Setup page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Sensor Setup

The Sensor Setup page (FIG. 51) allows adjustment of the Light and Motion Sensor parameters on a Modero touch panel.

FIG. 51 Sensor Setup page

The elements of the Sensor Setup page are described in the table below:

Sensor Setup Page Elements

Back: Saves the changes and returns you to the previously active touch panel page.

Connection Status icon: This visual display of the connection status allows the user to have a current

visual update of the panel’s connection status regardless of the page that is currently active.

• A Lock only appears on the icon if the panel has established a connection with a currently secured target Master requiring a username and password.

Light: The Light bargraph displays a vertical bargraph indicating the light level

detected by the on-board photo-sensor.

Light Sensor: Allows the user to review the Modero panel light sensor port and channel

settings:

• The Sensor Level field indicates the level used to report the light sensor level back to the NetLinx Master (set in TPD4) (read-only).

• The Sensor Level Port field indicates the port used to report the light sensor level back to the NetLinx Master (set in TPD4) (read-only).

• The Sensor Channel field indicates the level used to report the sensor channel back to the NetLinx Master (set in TPD4). It is On when below the Light Sensor threshold level (read-only).

• The Sensor Channel Port field indicates the port used to report the sensor channel back to the NetLinx Master (set in TPD4) (read-only).

Motion Sensor: Provides the following fields:

• The Motion Detection field displays a reactive button that changes color (illuminates) when motion is detected by the Modero panel’s front motion sensor.

• The Motion Sensor Port field indicates the port used to report the motion sensor channel back to the NetLinx Master (set in TPD4) (read-only).

• The Motion Sensor Channel field indicates the channel used to report the motion sensor channel back to the NetLinx Master (set in TPD4) (read-only).

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Sensor Setup Page Elements (Cont.)

Wake On Motion: The Wake Panel Sensitivity relates to the sensitivity of the motion sensor to

Motion: The Motion bargraph displays a vertical bargraph indicating the current value of

detect motion and wake the panel accordingly.

• Toggle the Enable/Enabled button to either active/inactive this feature:

- Enable - activates this feature. Activating this feature reactivates the panel from a panel timeout (sleep) mode.

- Enabled - (illuminated when selected) deactivates this feature and makes the panel use the specified Display Timeout value set on the Setup Page.

• Use the Wake Panel UP/DN buttons to alter the sensitivity value.

- Range = 0 - 100.

• The horizontal WAKE PANEL SENSITIVITY bargraph indicates the current motion sensitivity value associated with waking the panel from a timeout.

the motion detected by the on-board motion detector.

Making the most of the Light bargraph

By setting a certain minimum or maximum amount of light to be received by the device, the Light bargraph may be used to trigger particular commands in NetLinx. The red line on the Light Sensor bargraph is the threshold level. It is used to determine the level of light at which to activate the Light Sensor Channel. The channel is activated when the light level is below the threshold and deactivated when above the threshold. For more information, refer to the Programming section on page 77.

Making the most of the Motion Sensor feature

The motion sensor works by detecting the heat of objects passing by the front of the touch panel. Because of this, the sensor works best when detecting lateral movement, such as when a person walks in front of the touch panel from left to right. This appears in the Motion Sensor bar based on the signal strength: a hand waved directly in front of the motion sensor is going to produce a stronger signal than a person walking by at the outer range of the sensor. The sensitivity may be modified by environmental conditions, such as increased body heat or outside heat sources such as sunbeams or heater vents. To set the Motion Sensor to best effect:

1. Ascertain the intended sensitivity of the Motion Sensor. For instance, check to see if commands are

to be initiated by someone walking past the touch panel, if someone enters the room at the edge of the touch panel’s range, or if someone specifically reaches for the panel’s face.

2. Open the Sensor Setup page (FIG. 51) from the Protected Setup menu section.

3. Watch the movement of the Motion Sensor bar while holding perfectly still. This allows tracking of

other factors that might affect the Motion Sensor, such as air conditioner vents or moving curtains.

4. Copy the movement intended to set off the Sensor while watching the Motion Sensor bar, such as

walking past the device. In particular, watch for the spikes in the bar where the sensor picked up the most movement.

5. Set the Motion Sensor bar to the desired sensitivity, making sure that it is located below the spikes

previously noted. If the bar is set above the level of the spikes, the Motion Sensor may never be set off by that level of motion.

6. Repeat the movement and check to see if the movement exceeds the bar setting. Adjust the bar as

necessary to set the desired sensitivity.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Tools

The Tools button provides a menu to select either the Panel Logs Page section on page 71, the Panel Statistics Page section on page 72, or the Connection Utility Page section on page 74. Select any of the

options to access that page.

FIG. 52 Tools menu

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Panel Logs Page

The options on the Panel Logs page allows viewing and tracking of the connection history for the panel (FIG. 53).

FIG. 53 Panel Logs page

Features on this page are as follows:

Panel Logs Page

Back: Saves all changes and returns to the previous page.

Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state

of the panel to the master.

• Bright red - disconnected

• Bright green - connected. Blinks when a blink message is received to dark green every 5 seconds for half a second then go back to bright green.

• Bright yellow - panel missed a blink message from the master. It will remain yellow for 3 missed blink messages and then turn red. It will return to green when a blink message is received.

Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master.

Connection Logs A history of all connections, attempts, and failures for the panel.

Clear Clears the Connection Logs history.

Refresh Refreshes the Connection Logs history.

Page Indicates the current page of the Connection Logs.

Use the Up and Down arrows to move from one page to the next.

Checking the Panel Connection Logs

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools

menu.

2. Within the Tools menu, press the Panel Logs button. All connection data is contained in the section

Connection Logs.

Refreshing the Panel Connections Log

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools

menu.

2. Within the Tools menu, press the Panel Logs button.

3. Push the Refresh button.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Clearing the Panel Connections Log

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools

menu.

2. Within the Tools menu, press the Panel Logs button.

3. Push the Clear button and confirm your selection.

Panel Statistics Page

The options on the Panel Statistics page allow you to track the connection status for the panel. The Panel Statistics page tracks ICSP messages, Blink messages, and Ethernet connection statistics (FIG. 54).

FIG. 54 Panel Statistics page

Features on this page are as follows:

Panel Statistics Page

Back: Saves all changes and returns to the previous page.

Connection Status icon: The icon in the upper-right corner of each Setup page shows online/offline state of

the panel to the master.

• Bright red - disconnected

• Bright green - connected. Blinks when a blink message is received to dark green every 5 seconds for half a second then go back to bright green.

• Bright yellow - panel missed a blink message from the master. It will remain yellow for 3 missed blink messages and then turn red. It will return to green when a blink message is received.

Note: a Lock appears on the icon if the panel is connected to a secured NetLinx Master.

ICSP Messages Messages sent between the master and the touch panel; it is the protocol they use

to communicate to each other.

Tot al • Received - The total ICSP messages received by the panel.

• Processed - The total ICSP messages processed by the panel.

• Dropped - The total ICSP messages dropped by the panel.

Last 15 Minutes • Received - The total ICSP messages received by the panel in the last 15

minutes.

• Processed - The total ICSP messages processed by the panel in the last 15 minutes.

• Dropped - The total ICSP messages dropped by the panel in the last 15 minutes.

Blink Messages The master sends this message once every 5 seconds to all connected devices.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Panel Statistics Page (Cont.)

Tot al • Received - The total Blink messages received by the panel.

• Missed - The total Blink messages missed by the panel.

Last 15 Minutes • Received - The total Blink messages received by the panel in the last 15 minutes.

• Missed - The total Blink messages missed by the panel in the last 15 minutes.

Ethernet Statistics The Ethernet connection statistics for the panel.

Wireless Statistics Since the NXD-500i does not have wireless capability, this field is disabled.

Clear Clears all panel connection statistics.

Refresh Refreshes all panel connection statistics.

Checking the Panel Statistics

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu.

2. Within the Tools menu, press the Panel Statistics button. All connection statistics are contained on

this page, e.g., Received, Processed, and Dropped ICSP Messages.

Refreshing the Panel Statistics

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu.

2. Within the Tools menu, press the Panel Statistics button.

3. Push the Refresh button.

Clearing the Panel Statistics

Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools menu.

2. Within the Tools menu, press the Panel Statistics button.

3. Push the Clear button.

4. Confirm the selection.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Connection Utility Page

The options on the Connection Utility page allows the panel to be used as a site survey tool. While in this page, move around the wireless network coverage area to check for any weak points within the spaces between the WAPs (FIG. 55).

FIG. 55 Connection Utility page

Features on this page include:

Connection Utility Page

Close: Closes the Connection Utility popup.

Connection Status icon: The icon in the upper-right corner of the utility provides a constant visual i

indication of current connection status.

A message is sent to the master once per second and expects a response.

• If it is received, the button stays green.

• If it is missed, the button goes yellow.

• After three misses (3 seconds), it will go red until a response from the master is received, and then it will be green again.

Once per second, a user can know if the immediate area is a good wireless area (all green), an area of limited coverage (lots of yellow, some green, some red), or an area with no coverage (all red).

Connection Information

Master IP The IP Address for the connected master.

Panel IP The IP Address for the panel.

Connection Statistics

Messages Sent The number of messages sent from the panel to the master.

Responses Received The number of responses the panel has received from the master.

Responses Missed The number of expected responses from the master to the panel missed.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

Using the Connection Utility

Press the Tools button in the Protected Setup Navigation Buttons section to open the To ol s menu.

2. Within the Too l s menu, press the Connection Utility button to launch the Connection Utility popup.

3. Move the panel within the network. The Connection Information notes the IP of the connected

master and the IP of the panel. The Connection Statistics show the current quality of the panel connection.

4. Push Close when finished using the site survey tool.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Setup Pages and Descriptions

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

The NXD-500i may be programmed, using the commands in this section, to perform a wide variety of operations using Send_Commands and variable text commands.

A device must first be defined in the NetLinx programming language with values for the Device: Port: System (in all programming examples - Panel is used in place of these values and represents all

Modero panels).

Verify that you are using the latest NetLinx Master and Modero firmware, and verify that you are using the latest version of NetLinx Studio and TPD4.

Button Assignments

Programming

• Button Channel Range: 1 - 4000 Button push and Feedback (per address port)

• Button Variable Text range: 1 - 4000 (per address port)

• Button States Range: 1 - 256 (0 = All states, for General buttons 1 = Off state and 2 = On state).

• Level Range: 1 - 600 (Default level value 0 - 255, can be set up to 1 - 65535)

• Address port Range: 1 - 100

These button assignments can only be adjusted in TPD4 and not on the panels themselves.

Page Commands

These Page Commands are used in NetLinx Programming Language and are case insensitive.

Page Commands

@APG

Add a specific popup page to a specified popup group.

@CPG

Clear all popup pages from specified popup group.

Add the popup page to a group if it does not already exist. If the new popup is added to a group which has a popup displayed on the current page along with the new pop-up, the displayed popup will be hidden and the new popup will be displayed.

Syntax:

"'@APG-<popup page name>;<popup group name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. popup group name = 1 - 50 ASCII characters. Name of the popup group.

Example:

SEND_COMMAND Panel,"'@APG-Popup1;Group1'"

Adds the popup page ’Popup1’ to the popup group ’Group1’.

Syntax:

"'@CPG-<popup group name>'"

Var iable :

popup group name = 1 - 50 ASCII characters. Name of the popup group.

Example:

SEND_COMMAND Panel,"'@CPG-Group1'"

Clears all popup pages from the popup group ’Group1’.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

Page Commands (Cont.)

@DPG

Delete a specific popup page from specified popup group if it exists.

@PDR

Set the popup location reset flag.

@PHE

Set the hide effect for the specified popup page to the named hide effect.

@PHP

Set the hide effect position.

@PHT

Set the hide effect time for the specified popup page.

Syntax:

"'@DPG-<popup page name>;<popup group name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. popup group name = 1 - 50 ASCII characters. Name of the popup group.

Example:

SEND_COMMAND Panel,"'@DPG-Popup1;Group1'"

Deletes the popup page ’Popup1’ from the popup group ’Group1’.

If the flag is set, the popup will return to its default location on show instead of its last drag location.

Syntax:

"'@PDR-<popup page name>;<reset flag>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

reset flag = 1 = Enable reset flag 0 = Disable reset flag

Example:

SEND_COMMAND Panel,"'@PDR-Popup1;1'"

Popup1 will return to its default location when turned On.

Syntax:

"'@PHE-<popup page name>;<hide effect name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

hide effect name = Refers to the popup effect names being used.

Example:

SEND_COMMAND Panel,"'@PHE-Popup1;Slide to Left'"

Sets the Popup1 hide effect name to ’Slide to Left’.

Only 1 coordinate is ever needed for an effect; however, the command will specify both. This command sets the location at which the effect will end at.

Syntax:

"'@PHP-<popup page name>;<x coordinate>,<y coordinate>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PHP-Popup1;75,0'"

Sets the Popup1 hide effect x-coordinate value to 75 and the y-coordinate value to 0.

Syntax:

"'@PHT-<popup page name>;<hide effect time>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

hide effect time = Given in 1/10ths of a second.

Example:

SEND_COMMAND Panel,"'@PHT-Popup1;50'"

Sets the Popup1 hide effect time to 5 seconds.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Page Commands (Cont.)

@PPA

Close all popups on a specified page.

@PPF

Deactivate a specific popup page on either a specified page or the current page.

@PPG

Toggle a specific popup page on either a specified page or the current page.

@PPK

Kill a specific popup page from all pages.

If the page name is empty, the current page is used. Same as the ’Clear Page’ command in TPDesign4.

Syntax:

"'@PPA-<page name>'"

Var iable :

page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PPA-Page1'"

Close all popups on Page1.

If the page name is empty, the current page is used (see example 2). If the popup page is part of a group, the whole group is deactivated. This command works in the same way as the ’Hide Popup’ command in TPDesign4.

Syntax:

"'@PPF-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PPF-Popup1;Main'"

Deactivates the popup page ’Popup1’ on the Main page.

Example 2:

SEND_COMMAND Panel,"'@PPF-Popup1'"

Deactivates the popup page ’Popup1’ on the current page.

If the page name is empty, the current page is used (see example 2). Toggling refers to the activating/deactivating (On/Off) of a popup page. This command works in the same way as the ’Toggle Popup’ command in TPDesign4.

Syntax:

"'@PPG-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PPG-Popup1;Main'"

Toggles the popup page ’Popup1’ on the ’Main’ page from one state to another (On/Off).

Example 2:

SEND_COMMAND Panel,"'@PPG-Popup1'"

Toggles the popup page ’Popup1’ on the current page from one state to another (On/Off).

Kill refers to the deactivating (Off) of a popup window from all pages. If the pop-up page is part of a group, the whole group is deactivated. This command works in the same way as the 'Clear Group' command in TPDesign 4.

Syntax:

"'@PPK-<popup page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page.

Example:

SEND_COMMAND Panel,"'@PPK-Popup1'"

Kills the popup page ’Popup1’ on all pages.

Programming

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

Page Commands (Cont.)

@PPM

Set the modality of a specific popup page to Modal or NonModal.

@PPN

Activate a specific popup page to launch on either a specified page or the current page.

@PPT

Set a specific popup page to timeout within a specified time.

@PPX

Close all popups on all pages.

A Modal popup page, when active, only allows use of the buttons and features on that popup page. All other buttons on the panel page are inactivated.

Syntax:

"'@PPM-<popup page name>;<mode>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. mode = NONMODAL converts a previously Modal popup page to a NonModal.

MODAL converts a previously NonModal popup page to Modal. modal = 1 and non-modal = 0

Example:

SEND_COMMAND Panel,"'@PPM-Popup1;Modal'"

Sets the popup page ’Popup1’ to Modal.

SEND_COMMAND Panel,"'@PPM-Popup1;1'"

Sets the popup page ’Popup1’ to Modal.

If the page name is empty, the current page is used (see example 2). If the popup page is already on, do not re-draw it. This command works in the same way as the ’Show Popup’ command in TPDesign4.

Syntax:

"'@PPN-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PPN-Popup1;Main'"

Activates ’Popup1’ on the ’Main’ page.

Example 2:

SEND_COMMAND Panel,"'@PPN-Popup1'"

Activates the popup page ’Popup1’ on the current page.

If timeout is empty, the popup page will clear the timeout.

Syntax:

"'@PPT-<popup page name>;<timeout>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. timeout = Timeout duration in 1/10ths of a second.

Example:

SEND_COMMAND Panel,"'@PPT-Popup1;30'"

Sets the popup page ’Popup1’ to timeout within 3 seconds.

This command works in the same way as the 'Clear All' command in TPDesign 4.

Syntax:

"'@PPX'"

Example:

SEND_COMMAND Panel,"'@PPX'"

Close all popups on all pages.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Page Commands (Cont.)

@PSE

Set the show effect for the specified popup page to the named show effect.

@PSP

Set the show effect position.

@PST

Set the show effect time for the specified popup page.

PAG E

Flip to a specified page.

Syntax:

"'@PSE-<popup page name>;<show effect name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

show effect name = Refers to the popup effect name being used.

Example:

SEND_COMMAND Panel,"'@PSE-Popup1;Slide from Left'"

Sets the Popup1 show effect name to ’Slide from Left’.

Only 1 coordinate is ever needed for an effect; however, the command will specify both. This command sets the location at which the effect will begin at.

Syntax:

"'@PSP-<popup page name>;<x coordinate>,<y coordinate>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'@PSP-Popup1;100,0'"

Sets the Popup1 show effect x-coordinate value to 100 and the y-coordinate value to 0.

Syntax:

"'@PST-<popup page name>;<show effect time>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

show effect time = Given in 1/10ths of a second.

Example:

SEND_COMMAND Panel,"'@PST-Popup1;50'"

Sets the Popup1 show effect time to 5 seconds.

Flips to a page with a specified page name. If the page is currently active, it will not redraw the page.

Syntax:

"'PAGE-<page name>'"

Var iable :

page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'PAGE-Page1'"

Flips to page1.

Programming

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

Page Commands (Cont.)

PPOF

Deactivate a specific popup page on either a specified page or the current page.

PPOG

Toggle a specific popup page on either a specified page or the current page.

PPON

Activate a specific popup page to launch on either a specified page or the current page.

Syntax:

"'PPOF-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'PPOF-Popup1;Main'"

Deactivates the popup page ’Popup1’ on the Main page.

Example 2:

SEND_COMMAND Panel,"'PPOF-Popup1'"

Deactivates the popup page ’Popup1’ on the current page.

Syntax:

"'PPOG-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'PPOG-Popup1;Main'"

Toggles the popup page ’Popup1’ on the Main page from one state to another (On/Off).

Example 2:

SEND_COMMAND Panel,"'PPOG-Popup1'"

Toggles the popup page ’Popup1’ on the current page from one state to another (On/Off).

If the page name is empty, the current page is used (see example 2). If the popup page is already On, do not re-draw it. This command works in the same way as the ’Show Popup’ command in TPDesign4.

Syntax:

"'PPON-<popup page name>;<page name>'"

Var iable :

popup page name = 1 - 50 ASCII characters. Name of the popup page. page name = 1 - 50 ASCII characters. Name of the page the popup is displayed On.

Example:

SEND_COMMAND Panel,"'PPON-Popup1; Main'"

Activates the popup page ’Popup1’ on the Main page.

Example 2:

SEND_COMMAND Panel,"'PPON-Popup1'"

Activates the popup page ’Popup1’ on the current page.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

Programming Numbers for Colors, Fonts, and Borders

Colors can be used to set the colors on buttons, sliders, and pages. The lowest color number represents the lightest color-specific display and the highest number represents the darkest display. For example, 0 represents light red, and 5 is dark red.

RGB triplets and names for basic 88 colors

RGB Values for all 88 Basic Colors

Index No. Name Red Green Blue

00 Very Light Red 255 0 0

01 Light Red 223 0 0

02 Red 191 0 0

03 Medium Red 159 0 0

04 Dark Red 127 0 0

05 Very Dark Red 95 0 0

06 Very Light Orange 255 128 0

07 Light Orange 223 112 0

08 Orange 191 96 0

09 Medium Orange 159 80 0

10 Dark Orange 127 64 0

11 Very Dark Orange 95 48 0

12 Very Light Yellow 255 255 0

13 Light Yellow 223 223 0

14 Yellow 191 191 0

15 Medium Yellow 159 159 0

16 Dark Yellow 127 127 0

17 Very Dark Yellow 95 95 0

18 Very Light Lime 128 255 0

19 Light Lime 112 223 0

20 Lime 96 191 0

21 Medium Lime 80 159 0

22 Dark Lime 64 127 0

23 Very Dark Lime 48 95 0

24 Very Light Green 0 255 0

25 Light Green 0 223 0

26 Green 0 191 0

27 Medium Green 0 159 0

28 Dark Green 0 127 0

29 Very Dark Green 0 95 0

30 Very Light Mint 0 255 128

31 Light Mint 0 223 112

32 Mint 0 191 96

33 Medium Mint 0 159 80

34 Dark Mint 0 127 64

35 Very Dark Mint 0 95 48

36 Very Light Cyan 0 255 255

37 Light Cyan 0 223 223

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

RGB Values for all 88 Basic Colors (Cont.)

Index No. Name Red Green Blue

38 Cyan 0 191 191

39 Medium Cyan 0 159 159

40 Dark Cyan 0 127 127

41 Very Dark Cyan 0 95 95

42 Very Light Aqua 0 128 255

43 Light Aqua 0 112 223

44 Aqua 0 96 191

45 Medium Aqua 0 80 159

46 Dark Aqua 0 64 127

47 Very Dark Aqua 0 48 95

48 Very Light Blue 0 0 255

49 Light Blue 0 0 223

50 Blue 0 0 191

51 Medium Blue 0 0 159

52 Dark Blue 0 0 127

53 Very Dark Blue 0 0 95

54 Very Light Purple 128 0 255

55 Light Purple 112 0 223

56 Purple 96 0 191

57 Medium Purple 80 0 159

58 Dark Purple 64 0 127

59 Very Dark Purple 48 0 95

60 Very Light Magenta 255 0 255

61 Light Magenta 223 0 223

62 Magenta 191 0 191

63 Medium Magenta 159 0 159

64 Dark Magenta 127 0 127

65 Very Dark Magenta 95 0 95

66 Very Light Pink 255 0 128

67 Light Pink 223 0 112

68 Pink 191 0 96

69 Medium Pink 159 0 80

70 Dark Pink 127 0 64

71 Very Dark Pink 95 0 48

72 White 255 255 255

73 Grey1 238 238 238

74 Grey3 204 204 204

75 Grey5 170 170 170

76 Grey7 136 136 136

77 Grey9 102 102 102

78 Grey4 187 187 187

79 Grey6 153 153 153

80 Grey8 119 119 119

81 Grey10 85 85 85

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

RGB Values for all 88 Basic Colors (Cont.)

Index No. Name Red Green Blue

82 Grey12 51 51 51

83 Grey13 34 34 34

84 Grey2 221 221 221

85 Grey11 68 68 68

86 Grey14 17 17 17

87 Black 0 0 0

255 TRANSPARENT 99 53 99

Font styles and ID numbers

Font styles can be used to program the text fonts on buttons, sliders, and pages. The following chart shows the default font type and their respective ID numbers generated by TPDesign4.

Default Font Styles and ID Numbers

Font ID # Font type Size Font ID # Font type Size

1 Courier New 9 19 Arial 9

2 Courier New 12 20 Arial 10

3 Courier New 18 21 Arial 12

4 Courier New 26 22 Arial 14

5 Courier New 32 23 Arial 16

6 Courier New 18 24 Arial 18

7 Courier New 26 25 Arial 20

8 Courier New 34 26 Arial 24

9 AMX Bold 14 27 Arial 36

10 AMX Bold 20 28 Arial Bold 10

11 AMX Bold 36 29 Arial Bold 8

32 - Variable Fonts start at 32.

Fonts must be imported into a TPDesign4 project file. The font ID numbers are assigned by TPDesign4. These values are also listed in the Generate Programmer’s Report.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

Border styles and Programming numbers

Border styles may be used to program borders on buttons, sliders, and popup pages.

Border Styles and Programming Numbers

No. Border styles No. Border styles

0-1 No border 10-11 Picture frame

2 Single line 12 Double line

3 Double line 20 Bevel-S

4 Quad line 21 Bevel-M

5-6 Circle 15 22-23 Circle 15

7 Single line 24-27 Neon inactive-S

8 Double line 40-41 Diamond 55

9 Quad line

The TPDesign4 Touch Panel Design program has pre-set border styles that are user-selectable.

The following number values may not be used for programming purposes when changing border styles. TPD4 border styles may ONLY be changed by using the name.

TPD4 Border Styles by Name

No. Border styles No. Border styles

1 None 27 Cursor Bottom

2 AMX Elite -L 28 Cursor Bottom with Hole

3 AMX Elite -M 29 Cursor Top

4 AMX Elite -S 30 Cursor Top with Hole

5 Bevel -L 31 Cursor Left

6 Bevel -M 32 Cursor Left with Hole

7 Bevel -S 33 Cursor Right

8 Circle 15 34 Cursor Right with Hole

9 Circle 25 35 Custom Frame

10 Circle 35 36 Diamond 15

11 Circle 45 37 Diamond 25

12 Circle 55 38 Diamond 35

13 Circle 65 39 Diamond 45

14 Circle 75 40 Diamond 55

15 Circle 85 41 Diamond 65

16 Circle 95 42 Diamond 75

17 Circle 105 43 Diamond 85

18 Circle 115 44 Diamond 95

19 Circle 125 45 Diamond 105

20 Circle 135 46 Diamond 115

21 Circle 145 47 Diamond 125

22 Circle 155 48 Diamond 135

23 Circle 165 49 Diamond 145

24 Circle 175 50 Diamond 155

25 Circle 185 51 Diamond 165

26 Circle 195 52 Diamond 175

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

TPD4 Border Styles by Name (Cont.)

No. Border styles No. Border styles

53 Diamond 185 97 Menu Bottom Rounded 185

54 Diamond 195 98 Menu Bottom Rounded 195

55 Double Bevel -L 99 Menu Top Rounded 15

56 Double Bevel -M 100 Menu Top Rounded 25

57 Double Bevel -S 101 Menu Top Rounded 35

58 Double Line 102 Menu Top Rounded 45

59 Fuzzy 103 Menu Top Rounded 55

60 Glow-L 104 Menu Top Rounded 65

61 Glow-S 105 Menu Top Rounded 75

62 Help Down 106 Menu Top Rounded 85

63 Neon Active -L 107 Menu Top Rounded 95

64 Neon Active -S 108 Menu Top Rounded 105

65 Neon Inactive -L 109 Menu Top Rounded 115

66 Neon Inactive -S 110 Menu Top Rounded 125

67 Oval H 60x30 111 Menu Top Rounded 135

68 Oval H 100x50 112 Menu Top Rounded 145

69 Oval H 150x75 113 Menu Top Rounded 155

70 Oval H 200x100 114 Menu Top Rounded 165

71 Oval V 30x60 115 Menu Top Rounded 175

72 Oval V 50x100 116 Menu Top Rounded 185

73 Oval V 75x150 117 Menu Top Rounded 195

74 Oval V 100x200 118 Menu Right Rounded 15

75 Picture Frame 119 Menu Right Rounded 25

76 Quad Line 120 Menu Right Rounded 35

77 Single Line 121 Menu Right Rounded 45

78 Windows Style Popup 122 Menu Right Rounded 55

79 Windows Style Popup (Status Bar) 123 Menu Right Rounded 65

80 Menu Bottom Rounded 15 124 Menu Right Rounded 75

81 Menu Bottom Rounded 25 125 Menu Right Rounded 85

82 Menu Bottom Rounded 35 126 Menu Right Rounded 95

83 Menu Bottom Rounded 45 127 Menu Right Rounded 105

84 Menu Bottom Rounded 55 128 Menu Right Rounded 115

85 Menu Bottom Rounded 65 129 Menu Right Rounded 125

86 Menu Bottom Rounded 75 130 Menu Right Rounded 135

87 Menu Bottom Rounded 85 131 Menu Right Rounded 145

88 Menu Bottom Rounded 95 132 Menu Right Rounded 155

89 Menu Bottom Rounded 105 133 Menu Right Rounded 165

90 Menu Bottom Rounded 115 134 Menu Right Rounded 175

91 Menu Bottom Rounded 125 135 Menu Right Rounded 185

92 Menu Bottom Rounded 135 136 Menu Right Rounded 195

93 Menu Bottom Rounded 145 137 Menu Left Rounded 15

94 Menu Bottom Rounded 155 138 Menu Left Rounded 25

95 Menu Bottom Rounded 165 139 Menu Left Rounded 35

96 Menu Bottom Rounded 175 140 Menu Left Rounded 45

Programming

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

TPD4 Border Styles by Name (Cont.)

No. Border styles No. Border styles

141 Menu Left Rounded 55 149 Menu Left Rounded 135

142 Menu Left Rounded 65 150 Menu Left Rounded 145

143 Menu Left Rounded 75 151 Menu Left Rounded 155

144 Menu Left Rounded 85 152 Menu Left Rounded 165

145 Menu Left Rounded 95 153 Menu Left Rounded 175

146 Menu Left Rounded 105 154 Menu Left Rounded 185

147 Menu Left Rounded 115 155 Menu Left Rounded 195

148 Menu Left Rounded 125

Telnet Commands

These Telnet Commands are used in NetLinx Studio and are case insensitive.

Telnet Commands

set motion beep

Enables/disables button beep sound.

show sensors

Displays realtime data from motion and light sensors.

cal light

Initiates light sensor calibration routine.

This will enable/disable the button beep sound when the motion sensor detects a motion level that rises above the threshold set by the user. It is intended to be used as an aid during motion testing.

This command is similar to the batt mon command in operation, except that it displays realtime data related to the Motion and Light sensors. Sensor data is displayed as scrolling text at the rate of 200 ms (default). The loop interval is optional and is in units of "100 milliseconds", e.g., interval = 2 results in a loop interval of 200 ms (5 hz). See table below for an example of the output. The following is a description of data items that are displayed:

Motion - level: The level of motion detected by the sensor. Motion - threshold: The threshold set by the user for activating the Channel. Light - lux: The amount of lux observed by the light sensor. Light - avg: The average logarithmic value of lux (avg log(lux)). Light - BL lvl: The current backlight level (brightness). Light - BL abs: The backlight level determined by the auto-brightness feature (absolute).

This value is a measure of the light sensor calibration. At full brightness (when "BL lvl" =

100), this value should also equal 100. Light - threshold: The light threshold set by the user. When "BL lvl" falls below the

threshold the channel is activated with a "push" or "on". Above threshold is "release" or "off".

This command will initiate a light sensor calibration routine. This routine takes 30 seconds to complete. There is currently no indication that the command is complete. During this routine, the firmware will record the maximum light value detected and use this value as the normal light level in which the panel will be operating. This will enable the panel's "auto-brightness" feature to operate correctly.

Be sure to move away from the front of the panel during the light calibration to allow the light sensor to "see" maximum brightness. Also, the panel should be positioned (installed) and operating in the expected light conditions that the panel will be expected to be used.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

"^" Button Commands

These Button Commands are used in NetLinx Studio and are case insensitive.

All commands that begin with "^" have the capability of assigning a variable text address range and button state range. A device must first be defined in the NetLinx programming language with values for the Device: Port : System (in all programming examples - Panel is used in place of these values).

 Variable text ranges allow you to target 1 or more variable text channels in a single

command.

 Button State ranges allow you to target 1 or more states of a variable text button with a single

command.

 "." Character is used for the 'through' notation, also the "&" character is used for the 'And'

notation.

"^" Button Commands

^ANI

Run a button animation (in 1/10 second).

^APF

Add page flip action to a button if it does not already exist.

^BAT

Append non-unicode text.

Syntax:

"'^ANI-<vt addr range>,<start state>,<end state>,<time>'"

Var iable :

variable text address range = 1 - 4000. start state = Beginning of button state (0= current state). end state = End of button state. time = In 1/10 second intervals.

Example:

SEND_COMMAND Panel,"'^ANI-500,1,25,100'"

Runs a button animation at text range 500 from state 1 to state 25 for 10 second.

Syntax:

"'^APF-<vt addr range>,<page flip action>,<page name>'"

Var iable :

variable text address range = 1 - 4000. page flip action = Stan[dardPage] - Flip to standard page

Prev[iousPage] - Flip to previous page Show[Popup] - Show Popup page Hide[Popup] - Hide Popup page Togg[lePopup] - Toggle popup state ClearG[roup] - Clear popup page group from all pages ClearP[age] - Clear all popup pages from a page with the specified page name ClearA[ll] - Clear all popup pages from all pages

page name = 1 - 50 ASCII characters.

Example:

SEND COMMAND Panel,"'^APF-400,Stan,Main Page'"

Assigns a button to a standard page flip with page name 'Main Page'.

Syntax:

"'^BAT-<vt addr range>,<button states range>,<new text>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). new text = 1 - 50 ASCII characters.

Example:

SEND_COMMAND Panel,"'^BAT-520,1,Enter City'"

Appends the text 'Enter City' to the button’s OFF state.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

"^" Button Commands (Cont.)

^BAU

Append unicode text.

^BCB

Set the border color to the specified color.

^BCF

Set the fill color to the specified color.

Same format as ^UNI.

Syntax:

"'^BAU-<vt addr range>,<button states range>,<unicode text>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). unicode text = 1 - 50 ASCII characters. Unicode characters must be entered in Hex

format.

Example:

SEND_COMMAND Panel,"'^BAU-520,1,00770062'"

Appends Unicode text '00770062' to the button’s OFF state.

Only if the specified border color is not the same as the current color.

Note: Color can be assigned by color name (without spaces), number or R,G,B value

(RRGGBB or RRGGBBAA).

Syntax:

"'^BCB-<vt addr range>,<button states range>,<color value>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). color value = Refer to theRGB Values for all 88 Basic Colors table on page 83 for more

information.

Example:

SEND_COMMAND Panel,"'^BCB-500.504&510,1,12'"

Sets the Off state border color to 12 (Yellow). Colors can be set by Color Numbers, Color name, R,G,B,alpha colors (RRGGBBAA) and R, G & B colors values (RRGGBB). Refer to theRGB Values for all 88 Basic Colors table on page 83.

Only if the specified fill color is not the same as the current color.

Note: Color can be assigned by color name (without spaces), number or R,G,B value

(RRGGBB or RRGGBBAA).

Syntax:

"'^BCF-<vt addr range>,<button states range>,<color value>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). color value = Refer to theRGB Values for all 88 Basic Colors table on page 83 for more

information.

Example:

SEND_COMMAND Panel,"'^BCF-500.504&510.515,1,12'"

SEND_COMMAND Panel,"'^BCF-500.504&510.515,1,Yellow'"

SEND_COMMAND Panel,"'^BCF-500.504&510.515,1,#F4EC0A63''"

SEND_COMMAND Panel,"'^BCF-500.504&510.515,1,#F4EC0A'"

Sets the Off state fill color by color number. Colors can be set by Color Numbers, Color name, R,G,B,alpha colors (RRGGBBAA) and R, G & B colors values (RRGGBB).

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

"^" Button Commands (Cont.)

^BCT

Set the text color to the specified color.

^BDO

Set the button draw order.

^BFB

Set the feedback type of the button.

Only if the specified text color is not the same as the current color.

Note: Color can be assigned by color name (without spaces), number or R,G,B value

(RRGGBB or RRGGBBAA).

Syntax:

"'^BCT-<vt addr range>,<button states range>,<color value>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). color value = Refer to theRGB Values for all 88 Basic Colors table on page 83 for more

information.

Example:

SEND_COMMAND Panel,"'^BCT-500.504&510,1,12'"

Sets the Off state border color to 12 (Yellow). Colors can be set by Color Numbers, Color name, R,G,B,alpha colors (RRGGBBAA) and R, G & B colors values (RRGGBB).

Determines what order each layer of the button is drawn.

Syntax:

"'^BDO-<vt addr range>,<button states range>,<1-5><1-5><1-5><15><1-5>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). layer assignments = Fill Layer = 1

Image Layer = 2 Icon Layer = 3 Text Layer = 4 Border Layer = 5 Note: The layer assignments are from bottom to top. The default draw order is 12345.

Example:

SEND_COMMAND Panel,"'^BDO-530,1&2,51432'"

Sets the button’s variable text 530 ON/OFF state draw order (from bottom to top) to Border, Fill, Text, Icon, and Image.

Example 2:

SEND_COMMAND Panel,"'^BDO-1,0,12345'"

Sets all states of a button back to its default drawing order.

ONLY works on General-type buttons.

Syntax:

"'^BFB-<vt addr range>,<feedback type>'"

Var iable :

variable text address range = 1 - 4000. feedback type = (None, Channel, Invert, On (Always on), Momentary, and Blink).

Example:

SEND_COMMAND Panel,"'^BFB-500,Momentary'"

Sets the Feedback type of the button to 'Momentary'.

Programming

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

"^" Button Commands (Cont.)

^BIM

Set the input mask for the specified address.

^BLN

Set the number of lines removed equally from the top and bottom of a composite video signal.

Syntax:

"'^BIM-<vt addr range>,<input mask>'"

Var iable :

variable text address range = 1 - 4000. input mask = Refer to theText Area Input Masking section on page 136 for character

types.

Example:

SEND_COMMAND Panel,"'^BIM-500,AAAAAAAAAA'"

Sets the input mask to ten ’A’ characters, that are required, to either a letter or digit

(entry is required).

The maximum number of lines to remove is 240. A value of 0 will display the incoming video signal unaffected. This command is used to scale non 4x3 video images into non 4x3 video buttons.

Syntax:

"'^BLN-<vt addr range>,<button states range>,<number of lines>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). number of lines = 0 - 240.

Example:

SEND_COMMAND Panel,"'^BLN-500,55'"

Equally removes 55 lines from the top and 55 lines from the bottom of the video button.

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

"^" Button Commands (Cont.)

^BMC

Button copy command. Copy attributes of the source button to all the destination buttons.

Note that the source is a single button state. Each state must be copied as a separate command. The <codes> section represents what attributes will be copied. All codes are 2 char pairs that can be separated by comma, space, percent or just ran together.

Syntax:

"'^BMC-<vt addr range>,<button states range>,<source port>,<source address>,<source state>,<codes>'"

Var iable :

variable text address range = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). source port = 1 - 100. source address = 1 - 4000. source state = 1 - 256. codes: BM - Picture/Bitmap

BR - Border CB - Border Color CF - Fill Color CT - Text Color EC - Text effect color EF - Text effect FT - Font IC - Icon JB - Bitmap alignment JI - Icon alignment JT - Text alignment LN - Lines of video removed OP - Opacity SO - Button Sound TX - Text VI - Video slot ID WW - Word wrap on/off

Example:

SEND_COMMAND Panel,"'^BMC-425,1,1,500,1,BR'"

SEND_COMMAND Panel,"'^BMC-425,1,1,500,1,%BR'"

Copies the OFF state border of button with a variable text address of 500 onto the OFF state border of button with a variable text address of 425.

Example 2:

SEND_COMMAND Panel,"'^BMC-150,1,1,315,1,%BR%FT%TX%BM%IC%CF%CT'"

Copies the OFF state border, font, Text, bitmap, icon, fill color and text color of the button with a variable text address of 315 onto the OFF state border, font, Text, bitmap, icon, fill color and text color of the button with a variable text address of 150.

Programming

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

Programming

"^" Button Commands (Cont.)

^BMF

Set any/all button parameters by sending embedded codes and data.

Syntax:

"'^BMF-<vt addr range>,<button states range>,<data>'"

Var iable s:

variable text address char array = 1 - 4000. button states range = 1 - 256 for multi-state buttons (0 = All states, for General buttons

1 = Off state and 2 = On state). level range = 1 - 600 (level value is 1 - 65535). data: ’%B<border style>’ = Set the border style name. See theBorder Styles and Programming

Numbers table on page 86. ’%B’,<border 0-27,40,41> = Set the borer style number. See theBorder Styles and

Programming Numbers table on page 86. ’%DO<1-5><1-5><1-5><1-5><1-5> = Set the draw order. Listed from bottom to top.

Refer to the ^BDO command on page 91 for more information. ’%F’,<font 1-8,10,11,20-29,32-xx> = Set the font. See theDefault Font Styles and ID

Numbers table on page 85. ’%F<font 01-08,10,11,20-29,32-xx>’ = Set the font. See theDefault Font Styles and ID

Numbers table on page 85. ’%MI<mask image>’ = Set the mask image. Refer to the ^BMI command on page 96 for

more information. ’%T<text >’ = Set the text using ASCII characters (empty is clear). ’%P<bitmap>’ = Set the picture/bitmap filename (empty is clear). ’%I’,<icon 01-9900, 0-clear>’ = Set the icon using values of 01 - 9900 (icon numbers are

assigned in the TPDesign4 Resource Manager tab - Slots section). ’%I<icon 01-9900, 0-clear>’ = Set the icon using values of 01 - 9900 (icon numbers are

assigned in the TPDesign4 Resource Manager tab - Slots section). ’%J’,<alignment of text 1-9> = As shown the following telephone keypad alignment

chart:

3 6

Zero can be used for an absolute position

’%JT<alignment of text 0-9>’ = As shown the above telephone keypad alignment chart, BUT the 0 (zero) is absolute and followed by ’,<left>,<top>’

’%JB<alignment of bitmap/picture 0-9>’ = As shown the above telephone keypad alignment chart BUT the 0 (zero) is absolute and followed by ’,<left>,<top>’

’%JI<alignment of icon 0-9>’ = As shown the above telephone keypad alignment chart, BUT the 0 (zero) is absolute and followed by ’,<left>,<top>’

NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom

AMX NXD-500i User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

NXD-500i Specifications

Front Bezel Button

Ethernet and mini-USB Ports

Installation

Installing the Trim Ring

Removing the Faceplate

Installation of an NXD-500i Touch Panel

Pre-Wall Installation of the Rough-In Box

Installing the NXD-500i panel within a Rough-In Box

Installing the NXD-500i into drywall

Installing the NXD-500i into a Flat Surface using #4 screws

Installing an NXD-500i into a Rack Mount Kit (NXA-RK5)

Wiring Guidelines for the NXD-500i Panel

Ethernet/RJ-45 Port: Connections and Wiring

NXD-500i Touch Panel Accessories

PS-POE-AF PoE Injector

Panel Calibration

Calibrating the Modero Panel

Configuring Communication

Modero Setup and System Connection

Configuring and Using USB with a Virtual Master

Step 1: Setup the Panel and PC for USB Communication

Step 2: Confirm the Installation of the USB Driver on the PC

Step 3: Confirm and View the current AMX USB device connections

Step 4: Use the USB to Configure a Virtual Master (using NetLinx Studio)

Step 5: Confirm and View the current AMX USB device connections

Configuring a Wired Ethernet Connection

Step 1: Configure the Panel’s Wired IP Settings

IP Settings section - Configuring a DHCP Address over Ethernet

IP Settings section - Configuring a Static IP Address over Ethernet

Step 2: Choose a Master Connection Mode Setting

Step 3: Configure an Ethernet Connection Type

Master Connection section - Virtual Master communication over Ethernet

Master Connection section - NetLinx Master Ethernet IP Address - URL Mode

Master Connection section - NetLinx Master Ethernet IP Address - Listen Mode

Master Connection section - NetLinx Master Ethernet IP Address - Auto Mode

Using G4 Web Control to Interact with a G4 Panel

Using the NetLinx Master to control the G4 panel

Upgrading Modero Firmware

Upgrading the Firmware via the USB port

Step 1: Configure the panel for a USB Connection Type

Step 2: Prepare NetLinx Studio for communication via the USB port

Step 3: Confirm and Upgrade the firmware via the USB port

Setup Pages and Descriptions

Setup Navigation Buttons

Protected Setup

Setup Page

Information

Panel Information Page

Panel Information Page

Time & Date Settings Page

Audio Settings Page

Supported sampling rates for WAV

Protected Setup Navigation Buttons

Protected Setup Page

System Settings Page

Calibration Page

G4 Web Control Page

Other Settings

Cache Settings Page

Setting the image cache

Clearing the image cache

Checking image cache status

Password Settings Page

Sensor Setup

Making the most of the Light bargraph

Making the most of the Motion Sensor feature

Tools

Panel Logs Page

Checking the Panel Connection Logs

Refreshing the Panel Connections Log

Clearing the Panel Connections Log

Panel Statistics Page

Checking the Panel Statistics

Refreshing the Panel Statistics
