DATA SHEET
Minimal Compression HD-SDI Video over IP
Encoder, AES67 Support
NMX-ENC-N1134A (FGN1134A-SA), Stand Alone
NMX-ENC-N1134A-C (FGN1134A-CD), Card
Overview
The NMX-ENC-N1134A provides the excellent encoding capabilities of the N1000
line for HD-SDI inputs. Integrate SDI directly onto the network without the extra
cost or hassle of an added SDI to HDMI converter. In addition, while most
Networked AV solutions with SDI connections operate using H.264 or H.265,
introducing a substantial amount of compression and latency, our minimally
compressed IP format maintains high video quality and delivers it with
imperceptible latency. Once on the network, the SDI feed can be decoded using any
N1000 Decoder. Added USB connectivity will enable users to extend USB over IP for
touch-enabled and KVM applications.
The N1000 Series Encoders and Decoders are an affordable local AV over IP
switching solution that packetizes video into a minimally compressed IP format to
create anywhere from a small 2×1 seamless presentation switcher up to a large
32×32 matrix switcher using off-the-shelf layer-3 network switches. Any source can
be sent to one or more displays by routing through layer-2 / layer-3 switches
utilizing standard Cat5e cable.
Common Applications
An ideal solution for live camera inputs in lecture halls, corporate town hall meetings and training spaces.
Features
SDI Input – Distribute video from an SDI source using N1000 Networked AV technology without adding a SDI-
to-HDMI converter
© 2017 AMX. All rights reserved.
Page 2
Sub-Frame Latency – Combined encode and decode latency of 10 ms at 60 fps, so low it’s below human
VIDEO
Video Input
HD-SDI
Video Output
N1XXX compatible stream, + passthrough HD-SDI
Formats
Formats associated with SMPTE 425, SMPTE 424,
SMPTE 292, and SMPTE 259-C
Output Resolutions
Matched to input
Pass Thru Resolutions
Matched to input
AUDIO
Input Signal Types
Analog Audio Formats: Stereo 2-channel
Analog-To-Digital Conversion: 16-bit 32 kHz, 44.1 kHz
and 48 kHz
Embedded audio following formats associated with
SMPTE 425, SMPTE 424, SMPTE 292, and SMPTE 259-C
Output Signal Types
Ethernet at 48-kHz (standard SVSI audio stream or
AES67, user selectable)
LATENCY
Video Latency
10 ms at 60 fps
Audio Latency
Standard SVSi audio stream = synched to video ; AES67
= 1-msec adjustable to 17-msec
Note
Video and audio latency values are the combined
encode plus decode latency. Total latency from source
to screen will also include any network latency.
COMMUNICATIONS
Ethernet
RJ45
10/100/1000 Mbps, auto-negotiating, auto-sensing,
full/half duplex, DHCP, Auto IP, and Static IP
SFP
1 Gbps port which accepts compatible fiber
transceivers or direct attach cables (fiber or copper
cabling)
PORTS
+12V 2A
One 12 Volt DC power input
P0
8-wire RJ45 female
10/100/1000 Mbps 10/100/1000Base-T auto-sensing
gigabit Ethernet switch port
Provides the network connection, network AV video,
and power to the Encoders
and Decoders
perception, making it ideal for live video feed content
Minimal Proprietary Compression (MPC) – Visually lossless MPC algorithm applied to all resolutions
PoE Powered – Eliminates requirement for local power supply and speeds installation
Native NetLinx – Simplifies integration with AMX control to reduce cost of installation
SFP Fiber/RJ45 Ports – Encoder features SFP fiber/RJ45 copper network ports with USB control inputs for
KVM-over-IP keyboard and mouse operation.
Specifications
2 | NMX-ENC-N1134A
Page 3
P1 (SFP Port)
SFP port (SFP fiber transceiver or direct attach cable
not included)
Provides the network connection and network AV
video
Designed for use with an SFP module (sold or sourced
separately) AMX compatible modules:
•NMX-SFP-1GRJ, RJ45 Module for N1X33/ N2X35 SFP
Cage (FGNVSFP-RJ-1G)
•NMX-SFP-1GSM, Single Mode Module for N1X33/
N2X35 SFP Cage (FGNVSFP-LR-1G)
•NMX-SFP-1GMM, Multimode Module for N1X33/
N2X35 SFP Cage (FGNVSFP-SR-1G)
IR
2-pin terminal Phoenix connector
Provides Infrared (IR) output only (33-60 kHz; typically
39 kHz). Emitter may be necessary (not included)
RS232
3-pin terminal Phoenix connector
Provides a serial control interface. Full duplex
communication. Available terminal speed settings:
9600-115200 baud rate
AUDIO
5-pin terminal Phoenix connector
Provides user-selectable balanced/unbalanced input.
Dedicated audio input
BNC for embedded audio on video stream
HD-SDI In
BNC
HD-SDI Out
BNC for HD-SDI pass through
USB connectors (front panel)
One USB-B and two USB-A control inputs
CONTROLS AND INDICATORS – FRONT PANEL
RESET Button
Recessed pushbutton
Press to initiate a 'warm restart' causing the processor
to reset, but not lose power. A reset does NOT affect
the current settings
ID Button
Recessed pushbutton
Press to send a notification out on the network to
identify the unit (the notification causes a pop-up
dialog in N-Able and N-Command)
POWER LED
On solid (green) when operating power is supplied (via
PoE or local power supply)
This activity is also shown by the PWR LED on the rear
panel
STATUS LED
On flashing (green) when there is software activity
This activity is also shown by the STAT LED on the rear
panel
CONTROLS AND INDICATORS – REAR PANEL
PWR LED
Same as POWER LED described above
3 | NMX-ENC-N1134A
Page 4
SDI LED
On (green) when there is a connection to a valid video
source
STAT LED
Same as STATUS LED described above
STRM LED
On (green) when the unit is streaming video
POWER SUPPLY
Power Supply, External, Optional
2.0 Amp @ 12 Volts DC; 100-240 Volts AC power
supply; optional. NMX-ACC-N9312 (FGN9312)
Power over Ethernet (PoE), External, Optional
Can be powered via a PoE switch or other equipment
with a PoE source. Conforms to IEEE 802.3af Class 3
(802.3at Type 1)
Note
In order for the unit to receive Power over Ethernet
(PoE), it must be connected to a switch or other
equipment that has a PoE PSE (Power Sourcing
Equipment) port.
Warning: Do not run wiring that is connected to a PoE
PSE port outside of the building where the PSE resides.
It is for intra-building use only. PoE does not pass
through the daisy chain (P1) port.
ENVIRONMENTAL
Temperature
32° to 104°F (0° to 40°C)
Humidity
10% to 90% RH (non-condensing)
Heat Dissipation
Up to ~44 BTU/hr
GENERAL
Dimensions (HWD)
1.05” x 7.888” x 5.5” (2.67 cm x 20.04 cm x 13.8 cm)
Weight
1.55 lbs (0.7 kg)
Mounting Options
Stand alone, surface mount, wall mount, or rack
mount
Surface and wall mounting requires (not included):
•NMX-ACC-N9101 (FGN9101), Mounting Wings for
SVSI N-Series Encoders and Decoders
Rack mounting requires one of the following (not
included):
•NMX-ACC-N9102 (FGN9102), 1RU Rack Shelf for Two
Side-by-Side for SVSI N-Series Encoders and Decoders
•NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage
with Power for Six SVSI N-Series Card Units
Regulatory Compliance
FCC, CE, and NTRL
Recommended Accessories
•NMX-ACC-N9312 (FGN9312), Power Supply 12V
External
•NMX-ACC-N9382 (FGN9382), 1RU Power Supply 16Channel 12V for up to 16 SVSI N-Series Encoders and
Decoders
•NMX-ACC-N9101 (FGN9101), Mounting Wings for
SVSI N-Series Encoders and Decoders
•NMX-ACC-N9102 (FGN9102), 1RU Rack Shelf for Two
Side-by-Side SVSI N-Series Encoders and Decoders
•NMX-ACC-N9206 (FGN9206), 2RU Rack Mount Cage
with Power for Six SVSI N-Series Card Units
•NMX-SFP-1GRJ, RJ45 Module for N1X33/ N2X35 SFP
Cage (FGNVSFP-RJ-1G)
4 | NMX-ENC-N1134A
Page 5
•NMX-SFP-1GSM, Single Mode Module for N1X33/
N2X35 SFP Cage (FGNVSFP-LR-1G)
•NMX-SFP-1GMM, Multimode Module for N1X33/
N2X35 SFP Cage (FGNVSFP-SR-1G)
