AMX DAS-KP-LCD-G, DAS-KP-LCDS-W User Manual
Operation/Reference Guide
Audio Controller LCD Keypads
Flush-Mount LCD Keypad (DAS-KP-LCD-G)
Surface-Mount LCD Keypad (DAS-KP-LCDS-W)
Distributed Audio
Last Revised: 3/03/2008
AMX Limited Warranty and Disclaimer
This Limited Warranty and Disclaimer extends only to products purchased directly from AMX or an AMX Authorized Partner which
include AMX Dealers, Distributors, VIP’s or other AMX authorized entity.
AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of
purchase, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay components are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.
• AMX lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long
as the AMX lighting products are under warranty. AMX also guarantees the control of dimmable loads that are properly connected to our lighting products. The dimming performance or quality there of is not guaranteed, impart due to the random combinations of dimmers, lamps and ballasts or transformers.
• AMX software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
• AMX AutoPatch Epica, Modula, Modula Series4, Modula CatPro Series and 8Y-3000 product models will be free of defects in
materials and manufacture at the time of sale and will remain in good working order for a period of three (3) years following the
date of the original sales invoice from AMX. The three-year warranty period will be extended to the life of the product (Limited
Lifetime Warranty) if the warranty card is filled out by the dealer and/or end user and returned to AMX so that AMX receives it
within thirty (30) days of the installation of equipment but no later than six (6) months from original AMX sales invoice date. The
life of the product extends until five (5) years after AMX ceases manufacturing the product model. The Limited Lifetime Warranty
applies to products in their original installation only. If a product is moved to a different installation, the Limited Lifetime Warranty
will no longer apply, and the product warranty will instead be the three (3) year Limited Warranty.
All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX
RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After
the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will
be refused. AMX is not responsible for products returned without a valid RMA number.
AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost
savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Authorized Partner for a third party.
This Limited Warranty does not apply to (a) any AMX product that has been modified, altered or repaired by an unauthorized agent or
improperly transported, stored, installed, used, or maintained; (b) damage caused by acts of nature, including flood, erosion, or earthquake; (c) damage caused by a sustained low or high voltage situation or by a low or high voltage disturbance, including brownouts,
sags, spikes, or power outages; or (d) damage caused by war, vandalism, theft, depletion, or obsolescence.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including
negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by
any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the
possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not
apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state.
The owner is advised to consult applicable state laws for full determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT
MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY. EXCEPT AS OTHERWISE LIMITED
BY APPLICABLE LAW, AMX RESERVES THE RIGHT TO MODIFY OR DISCONTINUE DESIGNS, SPECIFICATIONS, WARRANTIES, PRICES, AND POLICIES WITHOUT NOTICE.
Table of Contents
Table of Contents
Matrix Audio Controller LCD Keypads ...............................................................1
Overview .................................................................................................................. 1
DAS-KP-LCD-G Flush Mount LCD Keypad (FG1120-0X) .................................................. 1
DAS-KP-LCDS-W Surface Mount LCD Keypad (FG1120-12) ............................................ 1
Audio Controller Keypads - Features By Model .............................................................. 2
Installing the Surface-Mount LCD Keypad (DAS-KP-LCDS-W) ............................3
Overview .................................................................................................................. 3
Installing the Flush-Mount LCD Keypad
(DAS-KP-LCD-G) ...............................................................................................5
Overview .................................................................................................................. 5
Customizing LCD Keypad Labels ........................................................................7
Overview .................................................................................................................. 7
Customizing SOURCE Labels........................................................................................... 7
Customizing Source Command Labels ............................................................................ 8
Using the LCD Keypads ......................................................................................9
Basic Functionality (Mi Series & Delta) ..................................................................... 9
Turn On a Source (Single Room) ..................................................................................... 9
Turn Off a Source (Single Room) ..................................................................................... 9
Turn a Source On in All Rooms........................................................................................ 9
Turn All Rooms Off (System Off) ..................................................................................... 9
Direct Entry (From The Source Main Screen) ............................................................ 9
Tuner............................................................................................................................... 9
CD ................................................................................................................................... 9
Cable / Satellite............................................................................................................. 10
Presets (Setting & Recalling) .................................................................................. 10
Setting a Preset............................................................................................................. 10
Recalling a Preset .......................................................................................................... 10
Advanced Functionality (Mi Series & DELTA).......................................................... 11
Grouping Rooms .......................................................................................................... 11
Setting/Clearing the Alarm Clock ................................................................................. 12
Locking/Unlocking Keypads ......................................................................................... 12
Tone Control Settings (Bass/Treble/Balance/SRS) ........................................................ 13
Backlight Settings ........................................................................................................ 14
Privacy Mode ................................................................................................................ 14
Matrix Audio Controller LCD Keypads
i
Table of Contents
ii
Matrix Audio Controller LCD Keypads
Matrix Audio Controller LCD Keypads
Matrix Audio Controller LCD Keypads
Overview
The Matrix Audio Controller LCD Keypads (FIG. 1) are compatible with both Delta and Mi Series
Audio Controller Systems and provide Direct Access Control and advanced functionality such as:
Setting and recalling Source Presets
Setting and recalling Source Favorites
Zone Grouping
Alarm clock settings
Keypad Lockout
DAS-KP-LCD-G
Flush Mount LCD Keypad
FIG. 1 Matrix Audio Controller LCD Keypads
DAS-KP-LCDS-W
Surface Mount LCD Keypad
DAS-KP-LCD-G Flush Mount LCD Keypad (FG1120-0X)
The DAS-KP-LCD-G Flush Mount LCD Keypad combines the control functionality of the DAS-KP-4e/
KP-6e and DAS-KP-NUM keypads, with the added benefit of visual feedback.
The DAS-KP-LCD-G is available in the following colors:
Gloss Black (FG1120-01)
Gloss White (FG1120-02)
Gloss Almond (FG1120-03)
Gloss Ivory (FG1120-04)
DAS-KP-LCDS-W Surface Mount LCD Keypad (FG1120-12)
The DAS-KP-LCDS-W Surface Mount (retrofit) LCD Keypad combines the control functionality of the
DAS-KP-4e-G/KP-6e-G and DAS-KP-NUM-G keypads, with the added benefit of visual feedback.
The DAS-KP-LCDS-W is available in the following color:
Matte White
Matrix Audio Controller LCD Keypads
1
Matrix Audio Controller LCD Keypads
Audio Controller Keypads - Features By Model
The following table indicates the features supported by each of the Matrix Audio Controller Keypads:
Audio Controller Keypads - Features By Model
Model Name Description Features
LCD Keypads:
• DAS-KP-LCD-G (FG1120-0X) Flush Mount LCD Keypad • Direct access control
• DAS-KP-LCDS-W (FG1120-12) Surface Mount LCD Keypad
Pushbutton Keypads:
• DAS-KP-4e-G (FG1120-3X) Flush Mount 4 Source Keypad • Control of 4 sources
• DAS-KPI-4e-G (FG1121-3X)
• DAS-KP-6e-G (FG1120-4X) Flush Mount 6 Source Keypad • Control of 6 sources
• DAS-KPI-6e-G (FG1121-4X)
• DAS-KP-NUM-G (FG1120-2X) Flush Mount Numeric Keypad • 12-button numeric control
• DAS-KPI-NUM-G (FG1121-2X)
Flush Mount 4 Source Keypad
(International)
Flush Mount 6 Source Keypad
(International)
Flush Mount Numeric Keypad
(International)
• Setting/recalling presets
• Setting/recalling favorites
• Zone grouping
• Alarm clock settings
• Keypad lockout
• 5-button navigation control
• Bass, treble and balance control
• Built-in IR receiver
• Metal chassis for enhanced rigidity
• Field-replaceable buttons and bezel
• Opaque button color
• 4-pin input/output connectors
• 5-button navigation control
• Bass, treble and balance control
• Built-in IR receiver
• Metal chassis for enhanced rigidity
• Field-replaceable buttons and bezel
• Opaque button color
• 4-pin input/output connectors
• Direct access control
• Setting/recalling presets
• Setting/recalling favorites
• Zone grouping
• Alarm clock settings
• Keypad lockout
2
Matrix Audio Controller LCD Keypads
Installing the Surface-Mount LCD Keypad (DAS-KP-LCDS-W)
Installing the Surface-Mount LCD Keypad
(DAS-KP-LCDS-W)
Overview
The DAS-KP-LCDS-W Surface Mount LCD Keypad (FIG. 1) is shipped completely assembled. To
correctly install the DAS-KP-LCDS-W (retrofit) in the wall, you must remove the Front Bezel and the
LCD screen.
Please follow these instructions carefully to ensure correct installation and operation.
FIG. 1 DAS-KP-LCDS-W Surface Mount (Retrofit) LCD Keypad
Parts List
• Front Bezel • Keypad Control Board • Mounting Plate
• LCD Touch-screen • Keypad Connector Board • Mounting Screws x 2
Before installing the LCD Keypads, POWER OFF the Matrix Controller (and
Expansion Controllers, if applicable).
1. To remove the Front Bezel, firmly hold the rear connector board with one hand while squeezing the
top and bottom near one edge of the front bezel with the other hand.
While squeezing, gently pull the bezel back and down.
A soft click should be heard when the bezel is freed from the mounting plate.
2. Use a small Phillips screwdriver to remove the four screws in the corners of the LCD board.
Once all the screws have been removed, gently grip each side of the LCD screen and rock it away
from the mounting plate.
This will slowly release the LCD screen from the bank of pins connecting it to the Keypad Control
Board.
Matrix Audio Controller LCD Keypads
3
