AMX AXB-MIDI User Manual

AXB-MIDI

MIDI Interface

instruction manual

AXlink Bus Controllers

AMX Limited Warranty and Disclaimer

AMX Corporation warrants its products to be free of defects in material and workmanship under normal use for
three (3) years from the date of purchase from AMX Corporation, with the following exceptions:

• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch
overlay components that are warranted for a period of one (1) year.

• Disk drive mechanisms, pan/tilt heads, power supplies, MX Series products, and KC Series products are
warranted for a period of one (1) year.

• Unless otherwise specified, OEM and custom products are warranted for a period of one (1) year.

• Software is warranted for a period of ninety (90) days.

• Batteries and incandescent lamps are not covered under the warranty.

This warranty extends only to products purchased directly from AMX Corporation or an Authorized AMX Dealer.

AMX Corporation is not liable for any damages caused by its products or for the failure of its products to perform.
This includes any lost profits, lost savings, incidental damages, or consequential damages. AMX Corporation is not
liable for any claim made by a third party or by an AMX Dealer for a third party.

This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort
claim (including negligence and strict product liability), a contract claim, or any other claim. This limitation of
liability cannot be waived or amended by any person. This limitation of liability will be effective even if AMX
Corporation or an authorized representative of AMX Corporation has been advised of the possibility of any such
damages. This limitation of liability, however, will not apply to claims for personal injury.

Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or
exclusion of incidental or consequential damages for consumer products. In such states, the limitation or exclusion of
the Limited Warranty may not apply. This Limited Warranty gives the owner specific legal rights. The owner may
also have other rights that vary from state to state. The owner is advised to consult applicable state laws for full
determination of rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX CORPORATION MAKES NO

OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX CORPORATION

EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY

IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS

LIMITED WARRANTY.

Table of Contents

Table of Contents

Product Information .................................................................................................1

Installation .................................................................................................................3

Setting the DEVICE DIP Switch ........................................................................................ 3

Preparing Captive Wires for AXlink.......................................................................................... 3

Wiring the AXB-MIDI ......................................................................................................... 3

AXlink data and power connections ......................................................................................... 3

AXlink Wiring Guidelines.......................................................................................................... 4

Wiring AXlink with Optional 12 VDC power supply .................................................................. 4

MIDI cable connectors ............................................................................................................. 5

Replacing the Lithium Battery ........................................................................................... 5

Programming ............................................................................................................7

Send Commands............................................................................................................... 7

IN A and IN B MIDI Signal Routing ................................................................................... 8

MIDI Programming ............................................................................................................ 9

Programming examples ........................................................................................................... 9

Summary of MIDI Messages ........................................................................................... 11

AXB-MIDI MIDI Interface

i

Table of Contents

ii

AXB-MIDI MIDI Interface

Product Information

The AXB-MIDI MIDI Interface is an Axcess device for pass-through and control of Musical
Instrument Digital Interface (MIDI) protocol signals. This unit can act as a MIDI matrix switcher.

AXB-MIDI decodes and encodes MIDI protocol signals and routes the signals according to the
programming within an Axcess Central Controller. The AXB-MIDI communicates with the Central
Controller AXlink data protocols..

Product Information

OUT LED

THRU LED

IN - MIDI B
IN - MIDI A

AXlink Status LED

AXlink

DEVICE

ON

AINB

IN

OUTTHRU

Front

DEVICE DIP Switch

IN A

IN B OUT

THRU

GND

AXP

AXM

PWR

Rear

AXlink

MIDI A INPUT
MIDI B INPUT

MIDI THRU

MIDI OUT

AXlink connector

FIG. 1 AXB-MIDI - front and rear panel components

The AXB-MIDI provides MIDI signal pass-through and device control. Processing of MIDI
signaling is instantly visible via four front panel LEDs. A lithium battery provides data backup in
the event of power failure. The unit can be mounted in an electronic rack using an optional AC-RK
Accessory Rack Kit.

AXB-MIDI Specifications

Dimensions (HWD) 1.51" x 5.55" x 5.45" (3.84 cm x 14.10 cm x 13.84 cm)

Enclosure Metal with black matte finish

Power consumption 75 mA @ 12VDC

DIP Switch 8-position DIP switch sets the AXlink address for the AXB-MIDI.

Connectors • Four 5-pin DIN MIDI connectors (IN A, IN B, THRU and OUT).

AXB-MIDI MIDI Interface

• 4-pin captive wire connector for AXlink control signaling and power from the
Central Controller.

1

Product Information

AXB-MIDI Specifications (Cont.)

Input buffer • 3,072 bytes

Output buffer (AXlink) • 6,143 bytes

Max. Length of
SEND_STRING to device

Max. Length of data packets
from device

LED Indicators • AXlink Status LED (green): Lights to indicate that the AXB-MIDI is

Weight 1 lb. 0.5 oz. (488 grams)

Mounting options Flat surface or Rack mount

Optional Accessories • PS2.8, 12 VDC, 2.8 A Power Supply

•64

•64

operational and interfacing with the Central Controller (when blinking once
per second).

• IN A LED (red): Lights to indicate that there is MIDI data present on the IN A
connector.

• IN B LED (red): Lights to indicate that there is MIDI data present on the IN B
connector.

• THRU LED (red): Lights to indicate MIDI IN A/B signal passing through
without any changes.

• OUT LED (red): Lights to indicate MIDI data is being transmitted out the OUT
connector (after the AXB-MIDI receives AXlink control commands or MIDI
signals from the Central Controller).

• Five-pin DIN MIDI cable

• AC-ARK Accessory Rack Kit

2

AXB-MIDI MIDI Interface
