AMX AMX78 User Manual

AMX78(3) Owner's Manual 0399

AMX78(3) Owner's Manual 0399

Important Information About Your

AMX78 System

Congratulations on your purchase of the AMX78 vehicle security system
manufactured by Prime Security. To fully benefit from the capabilities of your
AMX78 system, we encourage you to read the Owner’s Manual thoroughly. If
you have any problems or questions regarding your system, consult the dealer
from whom you purchased this product. To locate an authorized Prime dealer,
contact Prime Security directly at 1-800-253-0334 (toll-free within the U.S.) or
1-847-215-2233.

Lifetime Warranty

Prime guarantees the operation of your system control unit and remote
controls for as long as you own your car. (Please refer to your Lifetime Limited
Warranty Card for complete information.) Make sure that you receive your
warranty card from your dealer, complete the required information and mail
the registration portion to Prime Security. You should retain the top portion of
the warranty card for your records.

Remote Controls

Included with your system are two AviGlo™ 4-button/9-channel remote
controls. Once exposed to light, the AviGlo remote control buttons will glow,
making the buttons visible in the dark.

Each of the pair of remote controls is a miniature radio transmitter powered by
a +12 volt battery with a typical range of up to 100 feet. Obstructions,
electrical or radio interference, weather conditions, cellular transmissions,
window tint or a weak remote control battery may reduce the range or
interrupt transmission. (If the system does not immediately respond, release
and press the button again. This works better than holding the button down.)
The second remote can be used by a second driver, or kept as a spare.

Additional remote controls or batteries can be purchased from any authorized
Prime Dealer, or by calling Prime Security toll-free at 1-800-253-0334 (within
the U.S.) or 1-847-215-2233.

Electronic Scan Prevention (ESP)

Your system also includes ESP, which blocks electronic scanner codes
preventing unauthorized operation of your system.

AMX78(3) Owner's Manual 0399

1

Instant Remote Control Code Deletion

In the event of a lost or stolen remote control, all remote controls can be
erased from the system memory preventing unauthorized system operation.
(See the “Programming Table for Remote Controls” on page 9).

One-Step Remote Control Code Learning

The system allows you to add new remote controls in one step. (See the
“Programming Table for Remote Controls” on page 9).

Valet Switch

The valet switch is a small hidden toggle switch which allows you to control all
of the system programmable features. (See “User-Programmable Features” on
page 9). This switch can only be controlled with the use of your ignition key.

NOTE: Be sure to have your dealer show you where the valet switch is located.

2

AMX78(3) Owner's Manual 0399
