USER MANUAL
802.11n, 2.4G 1T1R Wireless LAN USB Module
WN4608L
Realtek RTL8188ETV
Version 1.2
Networking B.U.
Lite-on Technology Corporation
4F, No. 90, Chien I Rd.,
Chung Ho, New Taipei City 235, Taiwan, R.O.C.
Customer Approval: (Signature)
(Title)
(Company)
(Date)
Page 1/6
PRODUCT FEATURES
Wi-Fi Feature
Operate at ISM frequency Band (2.4GHz)
IEEE Standards Support, 802.11b, 802.11g and 802.11n
CMOS MAC, Baseband PHY, and RF in a single chip for IEEE 802.11b/g/n
compatible WLAN
Complies with USB Specification 2.0, support Full-speed(12Mbps) and
High-Speed(480Mbps)
Enterprise level security supporting: WPA, WPA2
Support 1 transmission and 1 receiving, transmission rate can up to 150Mbps
(Physical Rate) in downstream and upstream
RoHS compliance
Low Halogen compliance
Page 2/6
PRODUCT SPECIFICATIONS
Wi-Fi Function
Standard
IEEE802.11b; IEEE 802.11g; IEEE 802.11n
Bus Interface
USB 2.0
Data Rate
802.11b:
11, 5.5, 2, 1 Mbps
802.11g:
54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n:
MCS 0 to 7 for HT20MHz
MCS 0 to 7 for HT40MHz
Media Access Control
CSMA/CA with ACK
Modulation Techniques
802.11b:
CCK, DQPSK, DBPSK
802.11g:
64QAM, 16QAM, QPSK, BPSK
802.11n:
BPSK, QPSK, 16QAM, 64QAM
Network Architecture
Ad-hoc mode (Peer-to-Peer)
Infrastructure mode
Operation Channel
2.4GHz
11: (Ch. 1-11) – United States
13: (Ch. 1-13) – Europe
14: (Ch. 1-14) – Japan
Frequency Range
802.11bg
2.412 ~ 2.4835 GHz
Transmit Output
Power – 1x1
(Tolerance: ±1.5dBm)
802.11b:
16 dBm@1Mbps
16 dBm@11Mbps
802.11g:
16 dBm@6Mbps
14 dBm@54Mbps
802.11n:
20MHz:
16 dBm@MCS0
13 dBm@MCS7
40MHz:
13 dBm@MCS0
13 dBm@MCS7
Receiver Sensitivity
802.11b:
-82 dBm@11Mbps
802.11g:
-70 dBm@54Mbps
802.11n:
20MHz
MAIN CHIPSET
Realtek RTL8188ETV
FUNCTIONAL SPECIFICATIONS
Page 3/6
-68 dBm@MCS7
40MHz
-65dBm@MCS7
Security
WEP 64&128 bit, WPA, WPA-PSK, WPA2, WPA2-PSK,
WPS, IEEE 802.1X, IEEE 802.11i
Operating Voltage
3.3 V ±5% I/O supply voltage
OS Supported
Microsoft Windows Win7/Win8; Linux based
Power Consumption
Test Condition:
- Operate at HT40
- File Transmission
- Record MAX value
TX Mode:
234 mA
RX Mode:
162 mA
Standby Mode:
147 mA
Antenna Type
Metal Antenna
Page 4/6
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must not
be co-located or operating in conjunction with any other antenna or transmitter.
End-users and installers must be provide with antenna installation instructions
and consider removing the no-collocation statement.
Page 5/6
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains
TX FCC ID: MDZ-WN4608L
The OEM integrator is still responsible for the FCC compliance requirement of the end
product, which integrates this module.
Appropriate measurements (e.g. 15 B compliance) and if applicable additional equipment
authorizations (e.g. Verification , Doc) of the host device to be addressed by the
integrator/manufacturer.
Page 6/6
