AMS-13 MAGNET CONTACT
1. Contact Type : Reed Switch, Rhodium Plated Contacts
SPST N.O. Type for Closed Loop system
(Contact are Closed with Magnet engaged)
2. Contact Rating: Max. Switching Current : 0.1Amp
Max. Carry Current : 0.3Amp
Breakdown Voltage : 150V DC Min.
Rating(VA.W) : 1.0VA
3. Operating Gap : Up to 5/8" (16mm) Op Gap Face to Side
3/4" (20mm) Op Gap Face to Face
4. Magnet : Alnico-5 5.5×6.0×30L
5. Housing
6. Lead Wire : AWG #22 Length 12 inch
7. Remark : Wide flange for wooden door 3/8" drill hole
8. Dimension :
3/8" dia. UL Vo Grade ABS Resin Epoxed.
:
Color : Standard Ivory, Brown, Gray, White
UL 1061
Press fit or Flange mount.
