AMS Device Manager
Version 13.5 Planning and Installation Guide
Planning and Installation Guide
May 2017
Disclaimer
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their
accuracy, they are not to be construed as warranties or guarantees, express or implied, regarding the products or services described
herein or their use or applicability. We reserve the right to modify or improve the designs or specifications of such products at any
time without notice. This document is not to be redistributed without permission from Emerson.
Copyright and trademark information
©
Emerson. 2017. All rights reserved.
The Emerson logo is a trademark and service mark of Emerson Electric Co.
AMS, Plantweb™, SNAP-ON™, DeltaV™, RS3™, PROVOX™, Ovation™, FIELDVUE™, and ValveLink™ are marks of one of the Emerson
group of companies.
FOUNDATION™, HART® and WirelessHART® are marks of the FieldComm Group of Austin, Texas, USA.
Intel® and Intel® Core™ are registered trademarks, or trademarks of Intel Corporation in the U.S. and/or other countries.
Microsoft® and Windows® are registered trademarks of the Microsoft Corporation in the United States and/or other countries.
All other marks are property of their respective owners.
Document history
Part number Date Description
10P5824A001 Dec 2008 Update, software version 10.0
Apr 2009 Update, software version 10.1
10P5824A501 Nov 2009 Update, software version 10.5
Apr 2010 Update, software version 11.0
10P5824B101 Aug 2010 Update, software version 11.1
Jan 2011 Update, software version 11.1.1
Sep 2011 Update, software version 11.5
10P5824C001 Nov 2012 Update, software version 12.0
Nov 2013 Update, software version 12.5
10P5824D001 April 2015 Update, software version 13.0
10P5824D002 August 2015 Update, software version 13.0 Service Pack 1
10P5824D003 November 2016 Update, software version 13.1.1
May 2017 Update, software version 13.5
License Agreement
Definitions: The term "You" includes, but is not limited to, users of the Fisher-Rosemount Systems, Inc. (FRSI) product embodied in
the computer program herein, the user’s employer, the employer’s wholly owned subsidiaries, parent company, agents,
employees, contractors, and subcontractors. The term "License Agreement" refers to one of FRSI’s License Agreements, including
but not limited to, all Software License Agreements, accompanying FRSI products, all Beta Test Agreements, and all Master License
Agreements.
Any and all use of this product is subject to the terms and conditions of the applicable License Agreement. The terms and
conditions of the applicable License Agreement by and between You and FRSI shall remain effective to govern the use of this
product.
The existence of a License Agreement by and between You and FRSI must be confirmed prior to using this product. If the site at
which this Program is used is a Licensed Facility under a Master License Agreement with FRSI, the applicable License Certificate that
was sent to You applies. If the site at which this Program is used is NOT a Licensed Facility under a Master License Agreement with
FRSI and the use of the program is NOT governed by a Beta Test Agreement, the use of this Program shall be governed by the
Software License Agreement that is printed in the sales literature, on the package in which the program was delivered, and in this
manual.
License Certificate for AMS Device Manager
If the site at which this Program is used is a Licensed Facility under a Master License Agreement between You and FisherRosemount Systems, Inc., this Licensed Copy is provided for Licensee’s use pursuant to its Master License Agreement with FRSI
("Agreement") as modified herein. If this is an original Licensed Copy, it may be used only on the equipment with which it has been
provided except as otherwise provided in the Agreement. If this is a Licensed Copy of a Revision or Upgrade, it may only be used in
lieu of and under the same terms as the Licensed Copy previously provided to Licensee.
Notwithstanding provisions of the Agreement, the term of the Limited Warranty for this Licensed Copy is 90 days from the date of
shipment from FRSI. Licensee’s other rights and obligations with respect to its use of this Licensed Copy are set forth in the
Agreement. Questions concerning Licensee’s rights and obligations should be directed to Contract Management, FisherRosemount Systems, Inc., 1100 W Louis Henna Blvd, Round Rock, Texas 78681.
Software License Agreement for AMS Device Manager
BY OPENING THIS PACKAGE YOU AGREE TO ACCEPT THESE TERMS AND CONDITIONS. IF YOU DO NOT AGREE WITH THESE TERMS,
YOU SHOULD PROMPTLY RETURN THE PACKAGE UNOPENED AND YOUR MONEY WILL BE REFUNDED. FRSI provides this computer
program and related materials for your use. You assume responsibility for the acquisition of a machine and associated equipment
compatible with the program, and for installation, use, and results obtained from the program.
LICENSE: FRSI grants to you a non-transferable, non-exclusive license to: (a) use all fully paid up licensed programs provided to you
to run a single machine; (b) copy the program for backup or modification purposes in support of the program on the single
machine. You must reproduce and include the copyright notice on any copy or modification. YOU MAY NOT REVERSE ENGINEER,
USE, COPY, OR MODIFY ANY PROGRAM OR RELATED MATERIALS OR ANY COPY, MODIFICATION, IN WHOLE OR IN PART, EXCEPT
AS EXPRESSLY PROVIDED FOR IN THIS LICENSE. IF YOU TRANSFER POSSESSION OF ANY COPY OR MODIFICATION OF THE
PROGRAM OR RELATED MATERIALS TO ANOTHER PARTY, YOUR LICENSE IS AUTOMATICALLY TERMINATED. No license, express or
implied, is granted under any intellectual property directly or indirectly owned by FRSI which does not specifically read on the
program as provided hereunder, nor shall any license, except the license specifically granted herein, be implied in law, implied in
equity, or exist under the doctrine of patent exhaustion.
TITLE: Title to and ownership of the program and related materials shall at all times remain with FRSI or its licensors. Your right to
use the same is at all times subject to the terms and condition of this Agreement. FRSI may, from time to time, revise or update the
program and/or related materials and, in so doing, incurs no obligation to furnish such revisions or updates to you.
TERM: This license is effective upon opening this package. You may terminate it at any time by destroying the program and the
related materials together with all copies and modifications in any form. It will also terminate upon conditions set forth elsewhere
in this Agreement or if you fail to comply with any term or condition of this Agreement. You agree upon such termination to
destroy the program and the related materials together with all copies and modification in any form.
LIMITED WARRANTY: FRSI warrants the media on which the program is furnished to be free from defects in materials and
workmanship under normal use for a period of ninety (90) days from the date of delivery to you as evidenced by a copy of your
invoice. However, FRSI does not warrant that the functions contained in the program will meet your requirements or that the
operation of the program will be uninterrupted or error free. THE PROGRAM AND RELATED MATERIALS ARE PROVIDED "AS IS"
WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. THE ENTIRE RISK AS TO THE QUALITY AND PERFORMANCE OF
THE PROGRAM IS WITH YOU; SHOULD THE PROGRAM PROVE DEFECTIVE, YOU ASSUME THE ENTIRE COST OF ALL NECESSARY
SERVICING, REPAIR, OR CORRECTION.
LIMITATIONS OF REMEDIES: FRSI’s entire liability and your exclusive remedy shall be: (1) the replacement of any media not meeting
FRSI’s "Limited Warranty" and which is returned with a copy of your invoice to Fisher-Rosemount Systems, Inc., 1100 W Louis
Henna Blvd, Round Rock, Texas 78681, USA, or (2) if FRSI is unable to deliver replacement media which is free of defects in
materials or workmanship, you may terminate this Agreement by returning the program and your money will be refunded. IN NO
EVENT WILL FRSI BE LIABLE TO YOU FOR ANY DAMAGES ARISING OUT OF ANY CAUSES WHATSOEVER (WHETHER SUCH CAUSES BE
BASED IN CONTRACT, NEGLIGENCE, STRICT LIABILITY, OTHER TORT, PATENT INFRINGEMENT, OR OTHERWISE), INCLUDING ANY
LOST PROFITS, LOST SAVINGS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO
USE SUCH PROGRAM EVEN IF FRSI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR OF ANY CLAIM BY ANY OTHER
PARTY.
GOVERNING LAW: This Agreement, and all matters concerning its construction, interpretation, performance, or validity, shall be
governed by the laws of the State of Texas.
EXPORT RESTRICTIONS: Licensee shall comply fully with all laws, regulations, decrees, and orders of the United States of America
that restrict or prohibit the exportation (or reexportation) of technical data and/or the direct product of it to other countries,
including, without limitation, the U.S. Export Administration Regulations.
U.S. GOVERNMENT RIGHTS: The programs and related materials are provided with "RESTRICTED RIGHTS." Use, duplication, or
disclosure by the U.S. Government is subject to restrictions set forth in the Federal Acquisition Regulations and its Supplements.
THE PROGRAM IS NOT FOR USE IN ANY NUCLEAR AND RELATED APPLICATIONS. You accept the program with the foregoing
understanding and agree to indemnify and hold harmless FRSI from any claims, losses, suits, judgements and damages, including
incidental and consequential damages, arising from such use, whether the cause of action be based in tort, contract or otherwise,
including allegations that FRSI’s liability is based on negligence or strict liability.
To the extent that a third party owns and has licensed to FRSI any portion of the program, such third party owner shall be a
beneficiary of this Agreement, and shall have the right to enforce its rights under this Agreement independently of FRSI.
GENERAL: You may not sublicense, assign, or transfer the license or the program and related materials without the prior written
consent of FRSI. Any attempt otherwise to sublicense, assign, or transfer any of the rights, duties, or obligations hereunder without
such consent is void.
Should you have any question concerning this Agreement, please contact your FRSI representative or sales office.
YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT, AND AGREE TO BE BOUND BY ITS TERMS AND
CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN US
WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT, EXCEPT THE MASTER LICENSE AGREEMENT, ORAL OR WRITTEN, AND
ANY OTHER COMMUNICATIONS BETWEEN US RELATING TO THE SUBJECT MATTER OF THIS AGREEMENT. YOU AGREE THAT FRSI
MAY AUDIT YOUR FACILITY TO CONFIRM COMPLIANCE OF THE FOREGOING PROVISIONS.
Contents
Contents
Chapter 1 Introduction .................................................................................................................. 1
Before you begin ..................................................................................................................................... 1
Installation overviews ..............................................................................................................................2
Database operations ............................................................................................................................... 3
Uninstall AMS Device Manager ................................................................................................................ 4
Reference documents ............................................................................................................................. 5
Chapter 2 System requirements .....................................................................................................9
Sizing considerations ...............................................................................................................................9
Hardware requirements ........................................................................................................................ 14
Network requirements .......................................................................................................................... 15
Software requirements ..........................................................................................................................16
Windows security requirements ............................................................................................................20
Requirements for system interfaces ...................................................................................................... 22
Chapter 3 Install AMS Device Manager ......................................................................................... 39
Upgrade an AMS Device Manager system ..............................................................................................40
Install Server Plus Station software ........................................................................................................ 45
Install Client SC Station software ........................................................................................................... 46
License AMS Device Manager ................................................................................................................ 48
Configure a Distributed System .............................................................................................................49
Modify a Distributed System ................................................................................................................. 51
Installing AMS Device Manager on domain controllers .......................................................................... 56
Install SNAP-ON applications .................................................................................................................57
Install AMS Device Manager Web Services on a station ..........................................................................57
Mobile workstation ............................................................................................................................... 58
Licensing AMS Device Manager 13.5 on DeltaV stations ........................................................................58
Installing AMS Device Manager 13.5 on DeltaV stations ........................................................................ 59
Licensing AMS Device Manager 13.5 on Ovation stations ...................................................................... 60
Installing AMS Device Manager 13.5 on Ovation stations ...................................................................... 60
Miscellaneous applications ....................................................................................................................61
Chapter 4 Prepare to use AMS Device Manager ............................................................................ 67
Change Windows Firewall settings ........................................................................................................ 67
Usernames and passwords .................................................................................................................... 67
Configure system interfaces ..................................................................................................................68
Add devices to an AMS Device Manager installation .............................................................................. 73
Chapter 5 Troubleshoot installation errors ...................................................................................75
Error messages ......................................................................................................................................75
Appendices and reference
Appendix A DeltaV system interface deployment concepts .............................................................79
Architecture Constraints ....................................................................................................................... 79
AMS Device Manager on Multiple Domain Networks with a Server Plus on each of the DeltaV Control
Networks .............................................................................................................................................. 80
i
Contents
Single AMS Device Manager distributed network that supports multiple DeltaV control networks with or
without Zones .......................................................................................................................................82
AMS Device Configurator supported on DeltaV Control Network .......................................................... 84
Appendix B Ovation system interface deployment concepts ........................................................... 85
AMS Device Manager on the Ovation Control Network .........................................................................85
AMS Device Manager on multiple Ovation systems ............................................................................... 86
Appendix C Other deployment concepts ......................................................................................... 87
HART Interface Solution – External Interfaces ........................................................................................87
HART Custom Solution – Integrated HART Panel Incorporating Multiplexer and Field Termination Panel
(FTP) ..................................................................................................................................................... 88
HART Over PROFIBUS ............................................................................................................................ 89
HART Over PROFIBUS plus PROFIBUS Interface ......................................................................................89
Kongsberg ............................................................................................................................................ 90
AMS Device Manager on a separate network from OpenEnterprise ....................................................... 91
AMS Device Manager with OpenEnterprise Server installed on the same PC .......................................... 92
AMS Device Manager using a redundant OpenEnterprise network ........................................................ 93
HSE linking devices ................................................................................................................................93
Appendix D Version compatibility ...................................................................................................95
Index ................................................................................................................................................. 99
ii
1 Introduction
This AMS Device Manager Planning and Installation Guide contains the following information:
• Chapter 1, Introduction – Provides an overview of AMS Device Manager installation
and directs you to the appropriate procedures for installing AMS Device Manager for
your setup and circumstances.
• Chapter 2, System requirements – Lists the system requirements for AMS Device
Manager, including hardware, software, and security requirements. This chapter
also defines additional requirements for system interface networks and sizing
considerations when planning your system.
• Chapter 3, Install AMS Device Manager – Describes the procedures for installing AMS
Device Manager. This chapter also details AMS Device Manager installation on a
DeltaV or Ovation network.
• Chapter 4, Before using AMS Device Manager – Describes configuration steps
needed before using AMS Device Manager.
• Chapter 5, Troubleshoot installation errors – Provides troubleshooting steps you can
take if you have problems installing AMS Device Manager.
• Appendix A, DeltaV system interface deployment concepts – Provides architecture
diagrams for implementing AMS Device Manager with DeltaV.
• Appendix B, Ovation system interface deployment concepts – Provides architecture
diagrams for implementing AMS Device Manager with Ovation.
• Appendix C, Other deployment concepts – Provides architecture diagrams for
implementing AMS Device Manager with supported system interfaces.
• Appendix D, Version compatibility – Provides matrices on AMS Device Manager
compatibility with SNAP-ON applications, DeltaV, and Ovation.
Introduction
Before you begin
To install and use AMS Device Manager software effectively, you should be familiar with
the basic functions and operation of:
• Microsoft Windows
• Your local area network (LAN) configuration and security
• Your communication devices and field devices
• Network components installed on your system
You should also be aware of:
• AMS Device Manager system requirements (see page 9)
• Database backup procedures (see page 3)
• Database restore procedures (see page 4)
1
Introduction
NOTICE
Do not use the Windows compress feature on the PC drive where AMS Device Manager is
installed. AMS Device Manager will be unable to open your database information.
Reinstallation of AMS Device Manager will be required.
Installation overviews
The following overviews direct you to specific information and procedures required for
your type of installation.
Install a standalone AMS Device Manager system
A standalone AMS Device Manager system is a Server Plus Station that maintains the AMS
Device Manager database, with no associated Client SC Stations.
1. Read Before you begin on page 1.
2. Confirm that your system meets AMS Device Manager requirements on page 9.
3. Do one of the following:
• For a new installation, follow the Server Plus Station installation steps on
page 45.
• For upgrading from AMS Device Manager 11.0 or later, see page 40.
Install a distributed AMS Device Manager system
A distributed AMS Device Manager system is a client/server deployment of AMS Device
Manager Stations. It allows multiple AMS Device Manager Stations access to a common
database and all connected devices in the distributed system.
1. Read Before you begin on page 1.
2. Confirm that your system meets AMS Device Manager requirements on page 9.
3. Do one of the following:
• For a new installation, follow the Server Plus Station and Client SC Station
installation steps on page 39.
• For upgrading from AMS Device Manager 11.0 or later, see page 40.
Install AMS Device Manager on a DeltaV system
1. Read Before you begin on page 1.
2. Confirm that your system meets minimum requirements for a co-deployment (refer
to the documentation provided with your DeltaV system).
3. Follow the installation steps on page 59.
2
Introduction
Install AMS Device Manager on an Ovation system
1. Read Before you begin on page 1.
2. Confirm that your system meets minimum requirements for a co-deployment (refer
to the documentation provided with your Ovation system).
3. Follow the installation steps on page 60.
Database operations
The following database procedures are essential to successfully install or upgrade to AMS
Device Manager 13.5:
• Back up a database on page 3 – Do this procedure before upgrading to AMS
Device Manager 13.5.
• Restore a database on page 4 – Do this procedure after upgrading AMS Device
Manager from version 11.0 or earlier.
Back up a database
Note
If performing a database backup on a PC with User Account Control enabled, log in with a Windows
administrator user to avoid multiple error messages.
1. Enter Database Backup on the Start screen and click Database Backup.
2. In the Backup Database dialog, enter or select the name of the backup file. Select a
secure location on your local drive outside the AMS folder.
3. Click Save.
4. Enter Database Verify Repair on the Start screen and click Database Verify Repair to check
the database for duplicate, missing, and corrupt records.
Notes
For a very large database, the Verify/Repair operation can take a long time.
5. Do one of the following:
• If Database Verify Repair does not return any errors, repeat steps 1 to 3.
• If Database Verify Repair returns any errors, run Database Verify Repair until
there are no more errors and repeat steps 1 to 3.
3
Introduction
Restore a database
Notes
• If you are restoring a database that was created on a different PC and you want to retain the
Device Monitor List and Alert Monitor alerts, before you restore the database on the new
station, ensure that the names of the PC and system interfaces configured on the new station
are the same as the original station.
• If performing a database restore on a PC with User Account Control enabled, log in with a
Windows administrator user to avoid multiple error messages.
• Ensure your Windows user has System > Database Utilities > Restore Database permission in AMS
Device Manager User Manager. See AMS Device Manager Books Online for more information.
1. Close AMS Device Manager and any related applications (for example, Alert Monitor,
Server Plus Connect), if open.
2. Stop all database connections.
3. Right-click the AMS Device Manager Server icon in the Microsoft Windows system
tray and select Stop AMS Device Manager Server from the context menu.
4. If the database backup file is located on a network drive, copy it to a local drive.
5. Enter Database Restore on the Start screen and click Database Restore.
6. Select the database backup file you want to restore and click Open.
Uninstall AMS Device Manager
You must uninstall AMS Device Manager if you are upgrading from any versions lower than
12.5. You do not need to uninstall the current AMS Device Manager software if you are
upgrading from version 12.5 or higher.
Note
If you have SNAP-ON applications or the AMS Device Manager Calibration Connector application
installed, uninstall them before uninstalling AMS Device Manager. If your applications use an external
database, you must back up that database before you uninstall the application (if you want to keep
the data).
1. Back up the database (see page 3).
2. Save your license.dat file in a location outside the AMS folder.
3. Right-click the AMS Device Manager Server icon in the Microsoft Windows system
tray and select Stop AMS Device Manager Server from the context menu.
4. Open the Windows Control Panel and use Programs and Features to remove AMS
Device Manager.
4
Introduction
Reference documents
After AMS Device Manager is installed, the following user information tools are copied to
your PC:
• AMS Device Manager Books Online
• AMS Device Manager Planning and Installation Guide
• Release Notes
• Supported Device List
AMS Device Manager Books Online
AMS Device Manager Books Online provides detailed reference and procedural information
for using AMS Device Manager. AMS Device Manager Books Online explains the features
and functions of AMS Device Manager. You should become familiar with AMS Device
Manager Books Online and refer to it regularly as you use AMS Device Manager.
You can access AMS Device Manager Books Online in two ways:
• Click the Help menu on the AMS Device Manager toolbar and select AMS Device
Manager Books Online.
• Enter Books Online on the Start screen and click Books Online.
Use the Contents, Index, or Search tab in the left pane to locate specific topics. You can
save shortcuts to frequently used topics and access them on the Favorites tab.
What’s This? Help
You can get help for device parameters on most AMS Device Manager supported devices
by clicking
dismiss by simply clicking anywhere on the screen. This help is provided by the device
manufacturer and can also be viewed by clicking in a field and pressing the F1 key.
and then clicking on a field. The help is displayed in a window that you can
Electronic documentation
Two user documents are placed on your station when AMS Device Manager is installed.
These documents are available as Portable Document Format (PDF) files, and include the
AMS Device Manager Planning and Installation Guide and the Supported Device List.
You need Adobe Reader to view these files. If you do not have a compatible version of
Adobe Reader on your PC already, you can download Adobe Reader from
www.adobe.com.
To access an electronic document after Adobe Reader is installed, enter Installation Guide or
Supported Device List on the Start screen and click Installation Guide or Supported Device List.
5
Introduction
Release Notes
The Release Notes provide information about the current release of AMS Device Manager,
including supported devices, compatibility issues, and known discrepancies and
workarounds.
The Release Notes are provided in text (.TXT) format. You can access the Release Notes in
two ways:
• Enter Release Notes on the Start screen and click Release Notes.
• Double-click the RELNOTES.TXT file located in the AMS folder after installation or on
the AMS Device Manager DVD1
We recommend that you read the Release Notes before using AMS Device Manager.
Device manuals
Many device manufacturers provide manuals for their devices in PDF format. Run the
AMS_PDF_Installer utility to copy relevant manuals to your hard drive. The utility is located
in the Device Documentation Installer folder on the AMS Device Manager DVD 2.
After installing device manuals, you access them in AMS Device Manager by right-clicking
a device and selecting Help from the context menu. If a device manual is available, it opens
in Adobe Reader. If no manual exists for the selected device, AMS Device Manager Books
Online opens. To see a list of device manuals installed on your station, select Help > Device
from the AMS Device Manager toolbar. Double-click a device to open the associated
manual.
Product data sheets and white papers
AMS Device Manager product data sheets provide product descriptions, features, and
benefits. White papers help you understand AMS Device Manager systems and items
important to system planning. Please have the sheets and white papers ready for reference
when planning a system. For convenience, some product specifications are included in this
guide, but this guide is not intended to duplicate product data sheets or white papers. The
data sheets and white papers are available on the Emerson website.
Knowledge Base Articles
The following Knowledge Base Articles (KBA) provide information on specific AMS Device
Manager requirements or components:
• KBA NK-1700-0119 AMS Device Manager v13.5 Release Information
• KBA NA-0400-0046 Firewall Whitepaper to be Used for AMS Device Manager
Installations
• KBA NA-0400-0084 AMS Device Manager Multiplexer System Interface Setup &
Troubleshooting Guide
• KBA NA-0500-0085 Configuring Windows Firewalls for AMS Device Manager
functionality
6
Introduction
• KBA NA-0700-0015 Microsoft Security and Critical Updates
• KBA NA-0800-0113 Configuring AMS Device Manager for Cross Domain Functionality
• KBA NK-1000-0150 Interoperability of AMS Device Manager Versions with DeltaV
• KBA NA-0700-0071 Interoperability Requirements Between AMS Device Manager and
Ovation
• KBA NK-1300-0136 Device Description Update Manager Architectures and Information
• KBA NK-1300-0138 Softing FG-110 HSE Linking Device is Now Supported With AMS
Device Manager
• KBA NK-1300-0268 AMS Device Manager Support in Virtual Environments
• KBA NK-1500-0051 Suggested Memory Configuration for SQL Server When Used With
AMS Device Manager
• KBA NK-1500-0168 Guideline for Installing a Standard Version of SQL Server 2012 to be
used with AMS Device Manager
7
Introduction
8
2 System requirements
Each PC in your system must meet minimum software and hardware requirements to
ensure successful installation and operation of AMS Device Manager. System interface
networks and SNAP-ON applications may have additional requirements.
Sizing considerations
When determining requirements for an AMS Device Manager system, consider the items
included in the following tables:
Supported
System Sizing Quantity
Number of wired HART
Devices?
Number of FF Devices?
Number of WirelessHART
Devices?
Wireless Gateway? 16 Wireless
WirelessHART Adapters? Each WirelessHART Adapter
Number of PROFIBUS DP
and PROFIBUS PA Devices?
Conventional Devices?
Multiplexers? Each multiplexer requires an AMS
Calibrators? Some calibrator modules require an
Number of devices
connected using DetTronics EQP system
(including EQP Controller)?
Total Tag Count? 30,000 (Per
Total AMS Device Manager
stations including the
Server Plus?
132 (Per System) Although 132 stations are
Maximum Comments
If the system will support more
Gateways for each
Wireless Interface
System)
System requirements
than 3,000 devices, see the
requirements on page 19.
Each Wireless Gateway requires an
AMS Tag
requires an AMS Tag
Tag
AMS Tag
Supported Maximum: 30,000 (Per
System)
supported, it is recommended that
the system has a maximum of 20
Client SC Stations.
9
System requirements
Total Number of
Required
Supported System
Interfaces
DeltaV When installing AMS Device
Ovation AMS Device Manager Server Plus
HART Modem
FOUNDATION fieldbus
modem
Wireless Network
FF HSE Network
Multiplexer Interface You should not exceed 10 of the
Stahl Network Requires Multiplexer Interface
8000 BIM Network Requires Multiplexer Interface
RS3 Network The AMS ValveLink SNAP-ON
PROVOX Network
Kongsberg
HART Over PROFIBUS
ABB
PROFIBUS
System
Interfaces
Devices
Connected per
Interface Comments
Manager on a DeltaV system, an
AMS Device Manager station
must be installed on the
ProfessionalPLUS.
software is NOT supported on an
Ovation Database Server.
32 Channel Multiplexers or 2 of
the 255 Device Multiplexers per
Multiplexer Network. We
recommend a maximum of 3000
devices per station. A system
should have no more than 14
interfaces per station.
licensing.
licensing.
application is not supported with
this interface.
10
System requirements
Total Number of
Required
Supported System
Interfaces
Field Communicator You can only
Calibrator
USB Fieldbus Interface
Det-tronics How many fire and gas detectors
Wireless Interface We recommend a maximum of 5
System
Interfaces
Devices
Connected per
Interface Comments
connect one 375/
475 Field
Communicator at
a time to an AMS
Device Manager
station.
You can only
connect one AMS
Trex unit at a time
to an AMS Device
Manager station
using USB.
You can connect
multiple AMS Trex
units to an AMS
Device Manager
station using WiFi.
are on the Det-Tronics EQP
system?
wireless gateways for each
Wireless Interface.
Supported
Networking Considerations Quantity
Number of Network Domains? If you will be installing AMS
Maximum Comments
Device Manager on a Domain
Controller, it must be installed on
the Domain Controller before
installing on the Non-Domain
Controller computers. See KBA
NA-0800-0113 for more
information about domains and
installing on Domain Controllers.
AMS Device Manager supports
deployment within a single
domain or workgroup or across
multiple domains or workgroups.
11
System requirements
Supported
Networking Considerations Quantity
Number of Network
Workgroups?
Number of Networks that will
have an AMS Device Manager
station?
Number of Ethernet Serial
Hubs?
Network Firewalls N/A Complement firewalls with
The Hosts file on each AMS
Ethernet serial hubs may be used
Maximum Comments
Device Manager station must be
modified to include the
computer names and IP
addresses for all AMS Device
Manager computers in the
network.
AMS Device Manager supports
deployment within a single
domain or workgroup or across
multiple domains or workgroups
(see KBA NA-0800-0113).
to add more serial ports when
distributing the field devices
across multiple AMS Device
Manager stations, and are often
used when multiple remote
systems exist within a plant, and
you need to have consolidated
information available in a single
location such as a maintenance
office. Installing Ethernet serial
hubs lets virtual COM ports be
added to the AMS Device
Manager PC and can significantly
reduce the required length of the
RS-485 network wiring. The
HART Multiplexer Interface and
documenting calibrators can be
used over the existing plant
Ethernet.
antivirus software. If AMS Device
Manager is installed on a DeltaV
workstation, an Ovation Station,
etc., be sure to install an antivirus
software according to the
specifications of those systems.
See KBAs NA-0400-0046 and
NA-0500-0085 for more
information.
12
Networking Considerations Quantity
Will Remote Desktop/Terminal
Services or Terminal Server be
used?
(Yes or No)
5 Concurrent
Supported
Maximum Comments
Use of Remote Desktop/Terminal
Sessions
Services or Terminal Server is
limited to 5 concurrent sessions
when AMS Device Manager is
installed. If you are using
Terminal Server, it must be
installed before AMS Device
Manager installation. The level of
support of Remote Desktop/
Terminal Services with AMS
Device Manager SNAP-ON
applications varies. For more
detailed information, contact the
SNAP-ON application
manufacturer.
When implementing Remote
Desktop/Terminal Services or
Terminal Server, a Client SC
Station license should be
purchased for each session.
Questions regarding station
licensing requirements should be
directed to your local Emerson
sales office.
See page 16 for information
about supported operating
systems.
System requirements
Hardware Considerations Quantity Comments
HART Modems?
Field Communicators?
Calibrators?
HART Multiplexers?
RS232 to RS485 Converters?
Ethernet Serial Hubs?
USB Fieldbus Interface?
PROFIBUS Gateways
PROFIBUS Couplers
13
System requirements
Hardware requirements
PC processing speed, memory, and disk space
Station Type Minimum requirements
Server Plus Station Intel® Core™ 2 Quad processor, 2.4 GHz or greater
4 GB or more of memory
2 GB or more of free hard disk space
Client SC Station Intel® Core™ 2.4 Duo processor, 2.4 GHz or greater
4 GB or more of memory
2 GB or more of free hard disk space
Notes
1
Set virtual memory to 2-3 times the size of the physical memory.
2
The recommended free hard disk space is the amount needed for AMS Device Manager installation, not the amount
needed for daily operation (there are no recommended minimum amounts for daily operation). If you receive a
message during installation that you do not have enough hard disk space, free up as much space as possible and then
retry the installation.
3
Additional hard disk space is required for migrating the database if you are upgrading from an earlier version of AMS
Device Manager. The amount of space required depends on the size of the existing database.
4
Additional space may be required on the Server Plus Station for the database, depending on the size of your database.
5
Additional hard disk space is required for SNAP-ON applications.
1
2, 3, 4, 5
1
2, 3, 4, 5
Serial interfaces
• An RS-232 serial interface is required for a serial HART multiplexer network or
documenting calibrator.
• A serial port with a dedicated interrupt is required for a serial HART modem.
• The use of serial ports on VMWare and Hyper-V virtual PCs is NOT supported.
USB interfaces
• A USB port and USB HART modem drivers are required to use a USB HART modem.
See the Release Notes for a list of supported modems.
• A USB port and USB Fieldbus Interface drivers are required to use the USB Fieldbus
Interface.
• A USB port is required to connect and pair an AMS Trex Device Communicator to an
AMS Device Manager station. A device cannot be connected to a Trex unit when the
USB is plugged in.
• A USB port is required to connect a 375 or 475 Field Communicator using a USB
Infrared Data Association (IrDA) adapter. In some cases, IrDA drivers may be
necessary. See the Release Notes for a list of supported adapters.
14
System requirements
• A USB port is required to connect a 475 Field Communicator or Bluetooth modem
using a USB Bluetooth adapter. Only Microsoft Bluetooth components are
supported (see the Release Notes for more information).
• A USB port and drivers are required to connect Fluke 753 and Fluke 754
Documenting Process Calibrators.
• The use of USB ports on VMWare and Hyper-V virtual PCs is supported.
Network requirements
• AMS Device Manager is designed to operate on an Ethernet network running TCP/IP.
• Mobile AMS Device Manager stations are allowed to connect wirelessly using
wireless plant network technology. Some communications slowdown can be
expected with wireless networking.
• AMS Device Manager supports deployment within a single domain or workgroup or
across multiple domains or workgroups. For more information, refer to KBA
NA-0800-0113. The Microsoft Windows Management Instrumentation and
Workstation services must be running on the PC during installation.
• AMS Device Manager does not support deployment between a network workgroup
and a network domain.
• Named IP services (how PCs identify each other on a network) must be functioning
correctly for stations in an AMS Device Manager distributed system to
communicate.
• All stations must be connected to the network before beginning AMS Device
Manager installation. This ensures that all stations can access the AMS Device
Manager database. All stations’ computer names should be recorded (see
page 50).
• All stations’ PC clocks must be synchronized (many third-party tools are available for
this purpose). Clock synchronization is important because the date and time of an
event recorded in the database is based on the clock in the PC that generated that
event.
For information about working with network firewalls, see page 67.
Note
Consult with your IT department about security issues and any other network operation issues or
special requirements for your network.
15
System requirements
Software requirements
Operating systems
AMS Device Manager supports the following Windows operating systems:
Operating System Version
Windows 7 Professional Service Pack 1
Enterprise Service Pack 1
Windows 10 Professional
Enterprise
Windows Server 2008 Standard Service Pack 2
Enterprise Service Pack 2
Windows Server 2008 R2 Standard Service Pack 1
Enterprise Service Pack 1
Windows Server 2012 R2 Standard
Datacenter
Windows Server 2016 Standard
Datacenter
3
3
3
3
3
3
1
1,4
2,4,5
2,4,5
3
3
Notes
1
32-bit and 64-bit versions of the operating systems are supported. 32-bit versions are supported only when co-
deployed with DeltaV or Ovation.
2
Only 32-bit versions of the operating systems are supported when co-deployed with DeltaV or Ovation.
3
Only 64-bit versions of the operating systems are supported.
4
Supported with DeltaV in their virtualized environment.
5
The Windows Server 2008 read-only domain controller is not supported.
• Desktops, laptops, and tablets with touchscreens are supported on Windows 10.
• AMS Device Manager and associated SNAP-ON applications may not be 64-bit applications but will be able to run on
a 64-bit OS with full functionality.
• Intermixing of operating system families is supported only in the following combinations: Windows 7 and Windows
Server 2012 R2 PCs; Windows 10 and Windows Server 2012 R2 PCs. No other combinations are supported.
• A Server operating system and server-class PC (for example, Dell PowerEdge) are recommended if the database is
expected to be greater than 10 GB due to the SQL Server version required (see page 19); or if AMS Device Manager
is installed on a DeltaV ProfessionalPLUS Station, Application Station, or Maintenance Station and Batch Historian or
VCAT will be used.
• The correct operating system service pack (SP) must be installed on your PC before installing AMS Device Manager.
If your PC does not have the correct SP installed, or you are unsure, contact your network administrator.
• See Change Windows Firewall settings on page 67 for additional operating system configuration considerations.
• AMS Device Manager is supported on a Hyper-V virtual PC only when co-deployed with DeltaV on the same
operating systems supported in non-virtualized environments.
• AMS Device Manager is supported on a VMWare virtual PC.
• AMS Device Manager also supports localized versions of the listed operating systems.
16
System requirements
Operating system patches and service packs
Newly released Microsoft critical updates and service packs are installed and tested in the
AMS Device Manager development labs on supported operating systems. Service pack
releases from Microsoft are less frequent but involve many more changes to the operating
system. Full support for a new service pack is usually on the next major product release;
however early versions of service packs are installed when they are made available from
Microsoft, and should an issue be detected, the action we take is very similar to that of
critical updates. For more information, see KBA NA-0700-0015 Microsoft Security and Critical
Updates.
In addition, users can take advantage of the Guardian Support service and website, which
provides fixes, patches and KBAs based on their unique system configuration. For more
information, visit
http://www2.emersonprocess.com/en-US/brands/sureservice/availabilityservices/
guardiansupportservice/Pages/GuardianSupportService.aspx.
Support for Remote Desktop Services
Remote Desktop Services (also known as Terminal Services) is a component of Microsoft
Windows (both server and client versions) that allows you to access applications and data
on a remote computer over a network, even from a client computer that is running an
earlier version of Windows. To use AMS Device Manager 13.5 in a Remote Desktop
Services environment, do the following:
• Set up Remote Desktop Services.
• If you are using a Terminal Server, install it before AMS Device Manager. A Terminal
Server requires a license.
• Limit the use of Remote Desktop Services to 5 concurrent sessions when AMS
Device Manager is installed on Windows server-class computers.
• Ensure that Remote Desktop Services is NOT set to Relaxed Security.
Notes
• Do not attempt to install AMS Device Manager on a PC accessed through a Remote Desktop
Services session; this is not a supported installation method and may produce undesirable
results.
• If multiple users are running AMS Device Manager on a Terminal Server, and one of the users
runs Terminate Servers, the AMS Device Manager application and AMS Device Manager
Servers shut down for all users.
• In a Remote Desktop Services environment, SNAP-ON applications may be limited to only one
session at any given time.
• If AMS Device Manager is co-deployed with DeltaV, Remote Desktop Services is disabled
except on virtual PCs.
• If you are installing a Client SC Station on a licensed Terminal Server, a Client SC Station
license is required for each licensed session.
17
System requirements
Contact Microsoft for Remote Desktop Services licensing information. Questions about
AMS Device Manager licensing requirements should be directed to your local Emerson
sales office.
Web browsers
AMS Device Manager supports the following web browsers:
• Microsoft Internet Explorer version 11
• Microsoft Edge version 25
AMS Device Manager Web Services
AMS Device Manager Web Services provide the ability to import AMS Device Manager
data, in XML format, into business applications such as Microsoft Excel. In addition,
Computerized Maintenance Management Systems (CMMS) and Enterprise Resource
Planning (ERP) systems can use AMS Device Manager Web Services to retrieve data from
AMS Device Manager.
Microsoft Internet Information Services (IIS) and AMS Device Manager 13.5 Server Plus
Station software must be installed on your system before you can install AMS Device
Manager Web Services. AMS Device Manager Web Services is not supported on Client SC
Stations. If you do not have IIS installed, contact your IT department for assistance.
Notes
• Some control systems do not allow IIS to be installed on the same PC. Check your control
system documentation to determine IIS compatibility.
• If you want to install AMS Device Manager Web Services on a DeltaV station, it must be a
DeltaV Application or ProfessionalPLUS station.
• You need local administrator permission to install AMS Device Manager Web Services.
AMS Device Manager Web Services and AMS Asset Portal 3.2
AMS Asset Portal acquires device data as it is connecting to AMS Device Manager Web
Services. To use AMS Device Manager Web Services with AMS Asset Portal for devices, the
following requirements must be met:
• AMS Device Manager Server Plus Station software must be installed on the PC.
• Microsoft Internet Information Services (IIS) must be installed on the PC before
installing AMS Device Manager Web Services. Use the Windows Add or Remove
Programs and Add/Remove Windows Components functions to install IIS (see the
Windows operating system documentation or Windows Help for more information).
• The Data Provider Web Service is required to use AMS Asset Portal. The URL to find
the Web Service is: http://<PCname>/amsdevicemanagerws/
amsdataproviderservice.asmx
18
System requirements
AMS Suite: Asset Performance Management
The AMS Suite APM Client Framework can be installed on an AMS Device Manager 13.5
station. Other components of AMS Suite APM must be installed on additional non-AMS
Device Manager PCs.
Microsoft IIS must be installed and configured on the PC before installing AMS Suite APM.
To enable the SQL reporting service in AMS Suite APM, the following IIS features must to
be added to the IIS defaults (if you are unsure how to do this, contact your IT department):
• ASP.NET
• NET Extensibility
• Request Filtering
• ISAPI
• ISAPI Extensions
• IIS 6 Management Compatibility
For more information about AMS Suite APM, contact your Emerson Sales/Service Office.
.NET Framework
AMS Device Manager requires Microsoft .NET Framework 4.5.2 and 3.5 Service Pack 1.
Database
AMS Device Manager 13.5 uses a named instance, Emerson2012, of SQL Server 2012
Service Pack 3 for its database. The size of your database determines which edition of SQL
Server 2012 Service Pack 3 you must use:
• If your database is less than 10 GB, you can use SQL Server 2012 Express Service Pack
3. The AMS Device Manager 13.5 setup installs this version automatically.
• If your database is greater than 10 GB or will be at some future time, we
recommended that you install a full version of SQL Server 2012 Service Pack 3 before
you install AMS Device Manager.
• If the AMS Device Manager system will support more than 3000 AMS Tags, use the
User Configuration Reports tool, or have more than 10 AMS Device Manager
stations (including AMS Suite APM), a full version of SQL Server 2012 Service Pack 3
is recommended regardless of database size.
A full version of SQL Server 2012 Service Pack 3 must be purchased separately (if you do
not already have it). We recommend that the full version of SQL Server 2012 Service Pack 3
is installed on a server operating system. To install a full version of SQL Server 2012, see
KBA NK-1500-0168.
Notes
• Contact Microsoft for more information about appropriate licensing for a full installation of
SQL Server 2012 Service Pack 3.
19
System requirements
• Additional SQL Server licenses are required when using Client SC Stations. Contact Microsoft
for more information.
• The AMS Device Manager database must be located in the AMS\DB folder on a local partition
of the AMS Device Manager Server Plus Station. Any other location is not supported.
• If you are installing other applications on the computer where AMS Device Manager and a full
version of SQL Server 2012 Service Pack 3 is installed, do NOT use the default Maximum server
memory setting in SQL Server Management Studio. See KBA NK-1500-0051 for more
information.
The AMS Device Manager installation program installs SQL Server on your PC as follows:
• If SQL Server 2012 Service Pack 3 is not installed, the AMS Device Manager 13.5
installation program will install SQL Server 2012 Express Service Pack 3 and create an
Emerson2012.
• If an instance of SQL Server 2012 Service Pack 3 is installed, but not the
Emerson2012 named instance, the AMS Device Manager 13.5 installation program
will create the Emerson2012.
• If the SQL Server 2012 Service Pack 3 Emerson2012 named instance is already
installed, the AMS Device Manager 13.5 installation program will continue with the
next part of the installation program.
• If you have previously installed a full version of SQL Server 2012 Service Pack 3, you
should create the Emerson2012 named instance before installing AMS Device
Manager 13.5 (refer to your SQL Server documentation). Otherwise, the AMS Device
Manager installation will install SQL Server 2012 Express Service Pack 3.
Microsoft Office
The following Microsoft Office applications are supported:
• Microsoft Word 2010, 2013, 2016 (for Drawings and Notes)
• Microsoft Excel 2010, 2013, 2016 (for Bulk Transfer)
Note
All stations in a distributed system must use the same application and version for entering Drawings/
Notes.
Windows security requirements
AMS Device Manager installation
You need Windows system administrator rights to install and configure AMS Device
Manager. Other network security requirements may also apply to the installation. Contact
your network administrator for more information.
20
System requirements
AMS Device Manager users
During installation, the AMSDeviceManager Windows user group is created and given
access to the AMS folder, subfolders, and files. When an administrator adds existing
Windows users in the AMS Device Manager User Manager utility on local or domain PCs
(see AMS Device Manager Books Online), these users are automatically added to the
AMSDeviceManager Windows user group. However, they may not be able to use all AMS
Device Manager features until permissions are assigned to them in User Manager.
For AMS Device Manager stations on a workgroup, Windows users added in the User
Manager utility must be manually added to the AMSDeviceManager Windows user group
using the Windows Control Panel on the Client SC Stations.
The installation creates a share of the AMS folder. It also allows connected Client SC
Stations to use the Drawings/Notes feature of AMS Device Manager. If your situation
makes this security configuration undesirable, consult your operating system
documentation or your system administrator.
AmsServiceUser
A Windows user account called AmsServiceUser is automatically created on each AMS
Device Manager station and added to the AMSDeviceManager Windows user group. The
AmsServiceUser account is not created if it exists on the domain controller where AMS
Device Manager stations are connected. The local or domain AmsServiceUser accounts are
also added to the AMSDeviceManager Windows user group on all AMS Device Manager
stations during installation.
Note
If you are installing an AMS Device Manager distributed system on domain controller PCs or a mix of
domain controllers and non-domain controller PCs, do all the domain controller installations first
(see page 56).
This user account runs the AMS Device Manager Servers. If your AMS Device Manager
system is located on a network that requires periodic changing of passwords, the
AmsServiceUser account password can be changed using the AMSPasswordUtility.exe utility
from the AMS\Bin folder on each AMS Device Manager station. You should only run the
utility after all AMS Device Manager stations have been installed. Do not use the Windows
User Accounts or AMS User Manager to modify this user, or change this password as AMS
Device Manager will no longer function.
Note
If the AMS Device Manager Calibration Connector application (see page 62) is installed when you
change the password for the AmsServiceUser, you must also change the password for
AmsCalibrationConnectorWS properties. This requires a change in the Windows Services console of
your workstation. If you are unsure how to do this, contact your IT department.
21
System requirements
Requirements for system interfaces
Requirements for system interfaces are in addition to the hardware and software
requirements for AMS Device Manager.
HART modems
HART modems let AMS Device Manager communicate with HART devices using a PC serial
port, PC USB port, or Bluetooth connectivity. Serial and USB HART modems attach directly
to a PC or laptop computer. Bluetooth HART modems require a self-contained power
source as well as a Bluetooth-ready workstation PC. The PC can have Bluetooth capability
built-in or use a Bluetooth adapter and Microsoft Bluetooth software components. HART
modems are not supported with USB to RS-232 converters or with Ethernet converters.
You must configure AMS Device Manager to send and receive data to and from the PC
serial communications port or USB port (USB HART modem software is required). If a
Bluetooth HART modem is used, you must prepare the PC for its use. Contact your IT
department for assistance. HART modems also allow multidropping up to 16 HART
devices.
Notes
• If your USB or Bluetooth HART modem manufacturer provided supporting driver software,
install it before configuring the modem for use with AMS Device Manager.
• Bluetooth is not natively supported on Windows Server 2008, Windows Server 2012, or
Windows Server 2016.
Field Communicators
The 475 and 375 Field Communicators are portable, handheld communicators from
Emerson used in the field or in the shop to configure, test, and diagnose HART and
FOUNDATION fieldbus devices. For information on using the 475 or 375, see the Field
Communicator User's Manual.
The Field Communicator Interface is a licensable option that lets you use a Field
Communicator and AMS Device Manager together to transfer HART and FOUNDATION
fieldbus data. The 475 communicates with an AMS Device Manager station using a USB
IrDA adapter (ordered separately) or the Microsoft Windows Bluetooth interface on a
Bluetooth-enabled PC. The 375 communicates with an AMS Device Manager station using
a USB IrDA adapter (ordered separately). You can communicate with only one Field
Communicator at a time on a PC. Communication between AMS Device Manager and a
connected Field Communicator is initiated by the AMS Device Manager software.
The AMS Trex Device Communicator uses the Field Communicator license, and
communicates with AMS Device Manager on USB and Wireless. You can connect only one
concurrent AMS Trex unit at a time to an AMS Device Manager station using USB. You can
connect multiple AMS Trex units to an AMS Device Manager station using WiFi.
22
System requirements
Documenting calibrators
With the optional Calibration Assistant SNAP-ON application, a documenting calibrator
can be used to automate the collection of device calibration data.
When the documenting calibrator is connected to AMS Device Manager, test definitions
can be checked out (downloaded) to the calibrator. The calibrator is then attached to the
corresponding field device, tests are run, and data is collected. This data can then be
checked in (uploaded) to AMS Device Manager for electronic record keeping and report
generation.
See the Release Notes for a list of supported documenting calibrators and pertinent
information about individual calibrators. See the AMS Device Manager Supported Device List
to determine if a device supports calibration.
8000 BIM
The 8000 BIM System Interface displays HART field devices connected to an 8000 BIM
system.
The physical connection between your AMS Device Manager PC and the 8000 BIM system
requires one of the following:
• A serial connection using an RS-485 converter (BIM)
• An Ethernet connection using TCP/IP addressing (eBIM)
Supported analog input modules:
• 8101-HI-TX — 4-20mA, 8 channel, Div. 2/2
• 8201-HI-IS — 4-20mA, 8 channel, Div. 2/1
• 8301-HI-IS — 4-20mA, 8 channel, Div. 1/1
Supported analog output modules:
• 8102-HO-IP — 4-20mA, 8 channel, Div. 2/2
• 8202-HO-IS — 4-20mA, 8 channel, Div. 2/1
• 8302-HO-IS — 4-20mA, 8 channel, Div. 1/1
ABB
The ABB System Interface lets you use AMS Device Manager to view and configure HART
devices connected to I/O modules supported by the ABB System 800xA control system.
AMS Device Manager Client SC Station or Server Plus Station software can be installed on
an ABB Station if PC hardware and software requirements are met, or on a separate PC. The
ABB Station must have the 800xA station software installed and configured for AMS Device
Manager to communicate with HART instruments connected using the ABB Controller.
The ABB System Interface requires:
• That the ABB Network is licensed in AMS Device Manager.
23
System requirements
• That the ABB Station software version is 5.1 along with the “Performance Pack”
enhancement release from ABB.
• That the ABB communications certificate be manually installed. See
ABBSystemInterface-Readme.pdf inside the SNAP-ONS And Tools\ABB HPT Certificate folder
on the AMS Device Manager DVD 1 for installation instructions.
• The AMS Device Manager user must be the same as the ABB user on the station that
runs the "ABB HART Pass Through Service".
• Use of the AC 800M series controllers.
• Use of supported multiplexers, including:
- Pepperl+Fuchs KFD2-HMM-16
- MTL4840
- Elcon Series 2700-G
24
