Ampire LDS-NTG50-CP Installation manual

BENZ (NTG4.5/4.7&NTG5.1/5.2/5.5) WIRING DIAGRAM

---- LDS-NTG45-CP/LDS-NTG50-CP

Connect to CARPLAY-USB cable
Multimedia USB

WIFI ANTENNA

Microphone cable

LCD OUT cable

LCD IN cable

Reset Dip Switch LED

NTG4.5/4.7--DIP SWITCH SETTING
(After changing the dip code,press "reset"or power-on again)

DIP S/W

PIN 1
PIN 2
PIN 3

PIN 4

PIN 5

PIN 6
PIN 7

PIN 8

Status
OFF/ON

OFF/ON
OFF/ON
OFF/ON

OFF/ON

OFF/ON
OFF/ON

OFF/ON

Description
7inch (800*480) / 5.8 inch (480*234)
NG / NG
NG / NG

Reversing gridline/Enable 360 panoramic

NG / NG

Rear view camera CVBS input / RGB input

NG / NG

After market rear camera / Original rear camera

ON

OFF

RGB input cable

Update adapter

Power cable

Optional cable

BLACK---Stereo audio output

LCD_OUT

LCD_IN

NTG5.1/5.2/5.5
(After changing the dip code,press "reset"or power-on again)

DIP S/W

PIN 1, 2
PIN 2, 3
PIN 1
PIN 2
PIN 4
PIN 5
PIN 6

PIN 7
PIN 8

--DIP SWITCH S

Status

OFF/ON
OFF/ON

ON

ON
OFF/ON
OFF/ON
OFF/ON
OFF/ON

OFF/ON

ETTING

Description

15~18 C class 7 inch / 15~17 S class 12.3 inch

NG/15~17 S class 12.3 inch with other parameters

15~18 year,all BENZ models with 8.4inch monitor

15~18 A/B/E/CLA/GLE class with 7 inch monitor

Reversing gridline/Enable 360 panoramic

NG / NG
Rear view camera CVBS input / RGB input
NG / NG

After market rear camera / Original rear camera

Connect to RGB output device

RED---12V output for rear view camera

ORANGE--Reverse control cable (connect to reversing light) for AVM
/without reversing gridline

YELLOW---RCA Front/Rear video input(Connect to front
/rear view camera/360 AVM/DVR

Stereo audio cable

REMARK:Please keep in the AUX interface when switch the CarPlay interface

1) Lo

ng press

2) Short press "C" or " ★ "b

3) K

no

b to c

ontr

Microphone

and hold "

ol up

/dow

either-or

Connect to the
original headunit
cable(The original
cable is blue).

Plug into the original
headunit's LVDS port

" butt

on to swit

utton to o

pen "Siri".

n/righ

t/left

/ok.

Connect to the Phone's original cable

Connect to original headunit

With original AUX IN

Connect to the original cable of
the original headunit

Connect to original
USB port

NTG5 without original AUX IN

ch MENU

,short pres

s" " button again,

exit MENU

.
