Page 1
Owner’s Guide
for the
V-50H Guitar Amplifier
Made in the
U.S.A.
by
Page 2
THE FRONT PANEL:
1. Power switch is used to turn the amplifier
on and off.
2. Power light indicates the amplifier is
turned on by glowing an iridescent blue color.
3. Reverb controls the amount of reverberation applied to the signal. With the control at
the “0” position there is no reverb applied; as
the control is turned towards “10” the amount
of reverb increases accordingly.
4. Bass adjusts the output level of the low frequencies and offers a cut or boost of 24dB at
50Hz.
5. Mid adjusts the output level of the middle
frequencies and offers a cut or boost of 16dB
at 800Hz.
6. Treble adjusts the output level of the high
frequencies and offers a cut or boost of 12dB
at 6kHz.
7. Gain controls the overall output level of the
amplifier. At lower volume settings the sound
will be clean. As you push the volume higher
and crank your guitar the sound becomes distorted.
8. -6dB Input accepts a standard 1/4” instrument plug from high output electronic instruments. This input is padded 6dB to compensate for higher output sources.
9. 0dB Input accepts a standard 1/4” instrument plug from your electric guitar. This input
is at 0dB level.
THE REAR
PANEL:
10. Main Speaker jack: Use this jack to connect the amplifier to your speaker cabinet.
Always use this jack “first” – if using a second
cabinet, connect it to the Extension Speaker
jack (#11).
11. Ext. Speaker jack: Use this jack to connect the amplifier to a second speaker cabinet
– always use the Main Speaker jack (#10)
“first.”
12. Impedance switch: Use this switch to
match the amplifier to the TOTAL impedance
of your speaker cabinet(s).
13. Preamp Tube: 12AX7A/ 7025 (1)
14. Power Amp Phase Splitter Tube:
12AX7A / 7025 (1)
15,16. Power Tubes: EL34 / 6CA7 (2)
Replace tubes ONLYwith same types! Refer
to enclosed publication about Tubes and Tube
Amplifiers for additional information.
17: Footswitch Jack: Connect the supplied
footswitch here for control of the Reverb on/off
and a switchable 15dB of gain from 250Hz to
8kHz.
18: Power cord connects the amplifier to a
suitable source of A.C. voltage. This is a
grounded, three-wire cord and must be connected to a properly grounded outlet. DO NOT
attempt to defeat the ground connection of
the power cord! If your amp was purchased
outside of the United States, see the sticker
next to the A.C. connector for its power ratings. Follow the above guidelines.
Thank you for choosing Ampeg. In order to obtain the best performance from your new amplifier we recommend you review the information in this owner’s guide prior to its use.
1 2 3 4 5 6 7 8 9
V-50H Guitar Amplifier
CAUTION
AVIS:
RISQUE DE CHOC
ELECTRIQUE. NE PAS OUVRIR.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Made in the U.S.A. by
SLM ELECTRONICS
1400 FERGUSON AVE. / ST. LOUIS, MO 63133
WARNING:
TO REDUCE THE RISK OF FIRE
OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
SPEAKERS
MAIN:
USE FIRST
FOOTSWITCH
REVERB / BOOST ON–OFF
EXT
IMPEDANCE
16 8
10 11 12 13 14 15 16 1817
Page 3
THIS EQUIPMENT HAS BEEN
DESIGNED AND ENGINEERED
TO PROVIDE SAFE AND RELIABLE OPERATION. IN ORDER
TO PROLONG THE LIFE OF THE
UNIT AND PREVENTACCIDENTALDAMAGES OR INJURY,
PLEASE FOLLOW THESE PRECAUTIONARY GUIDELINES:
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK, DO
NOT OPEN CHASSIS; DO NOT
DEFEAT OR REMOVE THE
GROUND PIN OF THE POWER
CORD; CONNECT ONLYTO A
PROPERLY GROUNDED AC
POWER OUTLET.
WARNING: TO REDUCE THE
RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
CAUTION: NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION: OUR AMPLIFIERS
ARE CAPABLE OF PRODUCING
HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE
TO HIGH SOUND PRESSURE
LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT
OR LOSS. USER CAUTION IS
ADVISED AND EAR PROTECTION IS RECOMMENDED IF
UNIT IS OPERATED AT HIGH
VOLUME.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
"IT IS NECESSARY FOR THE USER TO REFER TO THE INSTRUCTION MANUAL"
“ES NECESARIO QUE EL USUARIO SE REFIERA AL MANUAL DE INSTRUCCIONES.”
"REFERREZ-VOUS AU MANUAL D'UTILISATION"
"UNBEDINGT IN DER BEDIENUNGSANLEITUNG NACHSCHLAGEN"
EXPLANATION OF GRAPHICAL SYMBOLS:
EXPLICACION DE SIMBOLOS GRAFICOS:
EXPLICATION DESSYMBÔLESGRAPHIQUES:
"DANGEROUS VOLTAGE"
“VOLTAJE PELIGROSO”
"DANGER HAUTE TENSION"
"GEFAHLICHE SPANNUNG"
=
=
PRECAUCION
RIESGO DE CORRIENTAZO
NO ABRA
PRECAUCION PARA DISMINUOIR EL RIESGO DE CORRIENTAZO
NO ABRA LA CUBIERTA
NO HAY PIEZAS ADENTRO QUE EL USARIO PUEDO REPARAR
DEJE TODO MANTENIMIENTO A LOS TECHNICOS CALIFICADOS
ATTENTION
RISQUE D'ELECTROCUTION
NE PAS OUVRIR
ATTENTION: POUR REDUIRE D'ELECTROCUTION NE PAS
ENLEVER LE COUVERCLE. AUCUNE PIECE INTERNE N'EST REPRABLE
PAR L'UTILISATEUR. POUR TOUTE REPARATION, S'ADRESSER A UN
TECHNICIEN QUALIFIE.
VORSICHT
ELEKTRISCHE SCHLAGGEFAHR
NICHT OFFENEN
VORSICHT: ZUR MINIMIERUNG ELEKTRISCHER SCHLAGGEFAHR NICHT
DEN DECKEL ABENHMEN. INTERNE TEILE KONNEN NICHT VOM
BENUTZER GEWARTET WERDEN. DIE WARTUNG IS QUALIFIZIERTEM
WARTUNGSPERSONAL ZU UBERLASSEN.
ESTE APARA T O HASIDO DISENADO Y CONSTRUIDO PARA
PROVEER ANOS DE OPERACION SEGURA Y CONFIABLE.
PARAPROLONGAR LA VIDA DE
ESTAUNIDAD E IMPEDIR
DANOS ACCIDENTALES POR
FAVOR SIGAESTAS INSTRUCCIONES PREVENTIVAS:
PRECAUCION: PARADISMINUIR
EL RIESGO DE DESCARGAS
ELECTRICAS: (1) NO ABRALA
CUBIERTA, (2) NO ES
RECOMENDABLE REMOVER O
DESACTIVAR LAPATADEL
POLO A TIERRADELCABLE DE
CORRIENTE, CONECTE CORRECTAMENTE AUNATOMA DE
CORRIENTE A TIERRA.
ADVERTENCIA: PARAEVITAR
DESCARGAS EL ECTRICAS O
PELIGRO DE INCENDIO, NO
DEJE ESTE APARATO
EXPUESTO A LALLUVIAO
HUMEDAD.
PRECAUCION: NO HAY PIEZAS
ADENTRO QUE EL USUARIO
PUEDE REPARAR. DEJE TODO
MANTENIMIENTO A LOS TÉCNICOS CALIFICADOS.
PRECAUCION: NUESTROS
AMPLIFICADORES PUEDEN
PRODUCIR NIVELES DE PRESION DE SONIDO ALTO.
EXPOSICION CONTINUADAA
LOS NIVELES DE PRESION DE
SONIDO ALTO PUEDE CAUSA
DANO PERMANENTE ASU
OIDO. ES ACONSEJADO QUE
USE PRECAUCION ALUSUARIO
Y ES RECOMENDADO PROTECCION PARALOS OIDOS SI LA
UNIDAD ES OPERADAA VOLUMEN ALTO.
CET ÉQUIPEMENT AVAIT ÉTÉ
INVENTÉ ET ARRANGÉ POUR
POURVOIR DES ANNÉES
D'USAGE SAUF ET SÛR. POUR
PROLONGER LA VIE DE CET
APPAREILETPOUR EMPÊCHER
LES DOMMAGES ET LES TORTS
ACCIDENTELS, SUIVEZ LES
INSTRUCTIONS DE PRÉCAUTION.
AVERTISSEMENT: POUR
RÉDUIRE LES RISQUES D'ÉLECTROCUTION: (1) N’OUVREZ
PAS LE CHÂSSIS, (2) NE PAS
ESSAYER DE SUPPRIMER LA
BROCHE CORRESPONDANT À
LA TERRE.
ATTENTION: POUR RÉDUIRE
LES RISQUES D'UN FEU OU
D'ÉLECTROCUTION, N’EXPOSEZ PAS L'APPAREIL À LA
PLUIE OU À LA MOITEUR.
ATTENTION: IL N'Y A PAS
D’ÉLÉMENTS RÉPARABLES
DANS L'APPAREIL. CONSULTER
UN TECHNICIEN QUALIFIÉ
POUR LES RÉPARATIONS.
ATTENTION: NOS AMPLIFICATEURS SONT CAPABLES DE LA
PRODUCTION DES NIVEAUX DE
SON D'UNE HAUTE PRESSION.
L'EXPOSITION CONTINUE AUX
CES NIVEAUX PEUT CAUSER
LA SURDITÉ PERMANENTE. LA
PRUDENCE EST ADVISÉ À UTILISATEUR ET LAPROTECTION
DES OREILLES EST RECOMMANDÉ SI L'APPAREILEST
UTILISÉ À UN HAUT NIVEAU DE
VOLUME.
The V-50H is covered with a durable Tolex material: wipe it clean with a lint-free cloth. Never
spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
El V-50H esta cubierto con un material durable Tolex: limpielo con una toalla seca. Nunca rocie
el gabinete con sustancias limpiadoras. Evite usar materiales abrasivos con los cuales
pueda danar el acabado.
Le V-50H est couvert avec «Tolex» un revêtement noir et durable. Essuyez cette matière avec
une toile propre et sans charpie. Ne pulvérisez jamais les agents de nettoyage sur l'appareil.
Evitez les nettoyeurs abrasifs qui peuvent endommager le «Tolex.»
Page 4
Ampeg is proudly Made in America.
©1997 SLMElectronics, 1400 Ferguson Avenue, St. Louis, MO 63133 U.S.A.
V-50H TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 50 Watts RMS @ 5 % THD 8 ohm load 120 VAC
SIGNAL TO NOISE RATIO 70dB Typical
POWER REQUIREMENTS 120 VAC, 60Hz, 110VA
100/115 VAC, 50/60Hz, 110VA
230 VAC, 50/60Hz, 110VA
GAIN 69dB
TREBLE 12dB Boost and Cut @ 6kHz
MID 16dB Boost and Cut @ 800Hz
BASS 24dB Boost and Cut @ 50Hz
SIZE AND WEIGHT 29.5” W x 11.5” H x 9” D
34 lbs.
Ampeg continually develops new products, as well as improves existing ones. For this reason,
the specifications and information in this manual are subject to change without notice.
Ampeg continuamente desarrolla nuevos productos, así como también mejora los existentes. Por esta razón,
las especifaciones é información incluidos en este manual están sujetos a cambios sin previo aviso.
Ampeg développe continuellement des nouvels produits, ainsi d'améliorer ceux qui existe. Pour cette
raison les spécifications et les informations dans ce manuel peuvent se changer sans préavis.
P/N 47-277-16 • 09/97
