Ampeg PR-1832HE, PR-1528HE User Manual
P
r
o
u
d
l
y
M
a
d
e
I
n
A
m
e
r
i
c
a
by
INSPIRED BY STEVE BAILEY
AND VICTOR WOOTEN!
INTRODUCTION:
Inspired by two of the most accomplished bassists of our day, Ampeg’s new PR-1832HE
and PR-1528HE Bass Enclosures are truly a performing musician’s dream come true.
Outstanding sound and legendary Ampeg performance have been embodied in rugged, stylish cabinets which are incredibly road-worthy and surprisingly manageable.
The PR-1832HE is a four-way full range bass speaker system inspired by Victor Wooten.
This enclosure packs the punch of traditional 2-10 / 4-10 cabinets, but with the added advantage of the built-in 18" subwoofer. This enclosure is designed for high SPLand low distortion.
The frequency response is smooth and accurate all the way down to 35Hz.
The PR-1832HE features a a single 18", 400 watt, 4" diameter flat wound voice coil sub
low frequency transducer, two 10", 150 watt low frequency transducers, two 6 -1/2", 75 watt
closed-back mid-frequency transducers, and a bullet horn tweeter. This cabinet is biampable
between the 18" sub and the 2-10" low frequency components. Tilt-back cabinet design, 3”
dolly-style casters and a heavy-duty rear bar handle make the cabinet easy to move around.
Heavy-duty self-retracting side handles facilitate loading and unloading.
The PR-1528HE is a three-way full range bass speaker system inspired by Steve Bailey .
This enclosure is a small full range powerhouse with an incredibly smooth frequency
response, designed specifically for true, accurate sound reproduction to please the most
demanding bassist either on stage or in the studio.
The PR-1528HE features a a single 15", 300 watt, 4" diameter flat wound voice coil low
frequency transducer, two 8", 100 watt mid frequency transducers and a bullet horn tweeter.
The cabinet is biampable between the 15" low frequency driver and the 2-8" drivers. Four
removable swivel casters and heavy-duty self-retracting side handles make the cabinet easy
to move.
FEATURES:
•Switchable "Full Range" and "Biamp" operation.
•High power handling: 400 watts RMS / 800 watts program (PR-1528HE),
600 watts RMS / 1200 watts program (PR-1832HE)
•Rugged carpet covered cabinet with extensive internal bracing, tuned low
frequency section, and internally enclosed mid and high frequency sections.
•Slanted front to accommodate both near and far field use.
•Road-tough 16GA perforated steel grill.
•Full-range frequency response.
•Neutrik®Speakon connectors.
PR-1832HE / PR-1528HE Bass Enclosure
CAUTION: THIS UNIT IS CAPABLE OF PRODUCING HIGH SOUND PRESSURE LEVELS. CONTINUED EXPOSURE TO
HIGH SOUND PRESSURE LEVELS CAN CAUSE PERMANENT HEARING IMPAIRMENT OR LOSS. USER CAUTION IS
ADVISED, AND EAR PROTECTION RECOMMENDED IF UNIT IS OPERATED AT HIGH VOLUME. THE CHART BELOW
SHOWS THE U.S. GOVERNMENT’S OCCUPATIONAL SAFETY AND HEALTH ADMINISTRATION (OSHA) REGULATIONS
WHICH WERE IN EFFECT AT THE TIME OF THIS PUBLICATION FOR PERMISSIBLE NOISE EXPOSURE, PER
29CFR1910.95, TABLE G-16:
ACCORDING TO OSHA, ANYEXPOSURE IN EXCESS TO THESE AMOUNTS LISTED ABOVE COULD RESULTIN SOME
HEARING LOSS.
SOUND LEVEL DBA, DURATION PER DAY SOUND LEVEL DBA, DURATION PER DAY
SLOW RESPONSE IN HOURS SLOW RESPONSE IN HOURS
90 8 102 1 - 1 1/2
92 6 105 1
95 4 110 1/2
97 3 115 1/4 or less
100 2
Speakon®is a registered trademark of Neutrik USA
