This unit is designed for long lasting performance, providing the end user complies with assembly and maintenance
procedures. This Instruction Manual is your guide to ensure that you get the best performance out of the equipment.
Amico Accessories Inc. is not responsible for any damage as a result of (but not limited to) abuse and other problems
that may be a direct or indirect result of failure to comply with the instructions provided in this manual.
Please note these key words and symbols:
WARNING Steps where extra care should be taken to prevent injuries and damage
NOTE Steps that point out helpful information
Medical Facility Responsibilities
Preventive maintenance checks must be performed regularly to maintain the quality and performance of this product.
Any parts that may be broken, missing, worn, distorted or contaminated in any way should not be used and all aected
parts should be replaced immediately. Should the necessity of any repair be suspected; please contact your local
distributor.
1 Amico Accessories Inc.
Table of Contents
Installation Preparation
Installation Parts Requirements 3-4
Installation Tools Requirements 5
Installation of Rollstand
Roll Stand Assembly (Roll Stand Base Assembly) 6
Roll Stand Installation (Monitor Head Installation) 7
Installation of Accessories
Basket Installation 8
Handle Installation 9
Warranty Information 10
www.amico.com 2
Installation Parts Requirements
The list below includes all parts required for installation. Please check the contents of your Roll Stand Package to ensure
all parts are included. If any hardware or parts are missing, please contact Amico Accessories Inc.
BasketRoll Stand BaseHandle Package
(Brown Box)
Roll Stand
Casters and
Hardware Kit 1
Hardware Kit 1
Monitor Head (PM5
shelf shown) (Right),
Hardware Kit 2
contents
Roll Stand Post
Hardware Kit 2
contents
3 Amico Accessories Inc.
Installation Parts Requirements
The picture below shows what is included in the box. Picture is for reference only, you may receive dierent contents or
the box layout could be dierent when received.
Head Assembly, Castors, and
Basket
Handle Package
Roll Stand Post
Hardware Packages
Roll Stand Base
www.amico.com 4
Installation Tools Requirements
The table below lists all the tools required for installation.
NOTE: Please ensure that your contents match the list as outlined on the previous pages. If not, please contact
Amico Accessories Inc. at 1-877-264-2697
1. HEX Key 3/16" (47.6 mm) – NOT PROVIDED
2. Philips Screw Driver (Star head) – NOT PROVIDED
3. Socket Wrench (1/2" [1.27 cm] Socket) – NOT PROVIDED
4. 1/2" (1.27 cm) Wrench
A: Tools
1
2
3
4
5 Amico Accessories Inc.
Roll Stand Installation (Roll Stand Base Assembly)
NOTE: Figure 2 is an exploded view of the Roll Stand base assembly.
NOTE: DO NOT use a hammer on the casters or the Roll Stand post.
1. Hardware Kit 1 has the necessary hardware for the instructions in this section. (Figure 1)
2. Push locking casters into the base by hand until it clicks in place. Repeat for all 5 casters.
3. Insert the end of the Roll Stand post with the bushing into the Roll Stand base. Secure the post to the Roll Stand
by inserting the long bolt, through the lock washer, and then the large washer through the base, into the Roll
Stand post and tighten with ½" wrench. Ensure all connections are secured. (Figure 2)
Long Bolt
Large Washer (Silver)
Casters
Roll Stand Post
Lock Washer
Hardware Kit 1
Figure 1
Large Washer
Roll Stand Bushing
Casters
Lock Washer
Long Bolt
Figure 2
www.amico.com 6
Roll Stand Installation (Monitor Head Installation)
WARNING: The Roll Stand Monitor Head is rated for up to 20 lbs (9.07 kg). Ensure that the monitor being mounted
does not exceed this weight.
WARNING: Ensure that there is no gap between the large plastic bushing and the monitor head after assembly.
1. Hardware Package 2 (packaged with selected monitor head) has the hardware necessary for the instructions in
this section.
2. Place the adapter on the top of the post, ensure the side with the lip is facing up
3. Place the large black plastic bushing on top of the adapter, tting the lip of the adapter.
4. Place the small plastic bushing inside the bottom of the monitor head, and place the monitor head assembly into
the adapter.
5. Insert the nylon washer and then the bronze washer into the recessed hole on the top of the head. Next, insert
the head bolt through the two washers, into the hole in the head and tighten using the 1/2’’ (1.27 cm) wrench.
Tighten the head bolt until there is no gap between the large black plastic bushing and the adapter. (Figure 3)
6. Place the doming label in the recessed slot on the head to cover the screw.
Doming Label
Head Bolt
Bronze Washer
Nylon Washer
Monitor Head (PM 5 shelf shown)
Small Black Plastic Bushing
Large Black Plastic Bushing
Ensure there is no gap
between here
Adapter
Large plastic bushing
Head Bolt
(bolt will have threadlock)
Doming Label
Small plastic bushing
Adapter
Lip faces up
Bronze WasherNylon Washer
Hardware Package 2
7 Amico Accessories Inc.
Roll Stand Post
Figure 3
Basket Installation
WARNING: DO NOT tighten one screw all the way into the clamp assembly without tightening the other. Only
tighten the rst screw after the second screw is at least half way into the clamp assembly or the clamp may be
damaged. (Figure 4)
WARNING: DO NOT overtighten the screws as this may strip the thread.
WARNING: The basket is rated for up to 10 lbs (4.547 kg). Ensure the load that is placed in the basket does not
exceed this weight.
1. Remove the clamp devices from the basket assembly using the 3/16" (47.6 mm) HEX Key, and place the clamp
assembly at the desired height on the Roll Stand post.
2. Line the holes of the top clamp assembly on the basket with the holes on the clamp device. Partially secure
one of the two bolts BUT DO NOT TIGHTEN, then partially secure the second bolt. Once both bolts are started,
partially secure the bolts in the bottom clamp assembly in the same way. Once all four bolts are partially secured,
Tighten in a CROSS Pattern. (Figure 5 and 6)
Clamp DeviceClamp Assembly
3/16’’ (47.6 mm)
HEX Bolt
Clamp Device
Roll Stand
Post
INCORRECTCORRECT
Clamp Assembly
on Basket
×
Figure 4
Basket
Roll Stand Post
Double Clamp Basket SampleTighten using Cross Pattern
Figure 5
Figure 6
www.amico.com 8
Handle Installation
WARNING: DO NOT tighten one screw all the way in the clamp device without the other. Only tighten the rst
screw after the second screw is at least half way into the clamp assembly or the clamp maybe damaged. (Figure 7)
WARNING: Ensure the clamp device is the correct side up. The rounded edge of the clamp faces up while the more
squared edge faces down. The nished side of the handle faces up. (Figure 8)
1. Place the clamp device at the desired height on the Roll Stand post.
2. Line up the holes up on the handle with the holes on the clamp device. Start one of the two HEX bolts BUT DO
NOT TIGHTEN, then start the second bolt. Once both bolts are started, tighten the bolts. (Figure 9)
Clamp
Assembly
UP (more rounded edges)
Roll Stand
Post
INCORRECTCORRECT
×
Clamp Assembly
on Clamp
Figure 7
Clamp Device
3/16’’ Hex Bolt
Roll Stand Post
DOWN (more squared edges)
Figure 8
Roll Stand Handle
9 Amico Accessories Inc.
Figure 9
Accessories
Warranty Policy
Amico Accessories warrants all mounting accessories to be free from defects in material and workmanship for a period of twelve
(12) months from the date of shipment. Within this period Amico Accessories will repair or replace any part which is proven to
be defective. We don’t just send parts and pieces, we replace the product!
Amico Accessories will warrant its material to be free from defect for an additional period of four (4) years, ve (5) years from
the date of shipment. Within this period, Amico Accessories will replace any part at no charge, which is proven to be defective.
Shipping and Installation costs after the rst twelve (12) months will be borne by the customer.
This warranty is valid only when the product has been properly installed according to Amico Accessories specications, used in
a normal manner and serviced according to factory recommendations. It does not cover products that are not manufactured
by Amico Accessories. It does not cover failures due to damage which occurs in shipments or failures which resulted from
accidents, misuse, abuse, neglect, mishandling, alteration, misapplication or damage that may be attributable to acts of God.
Amico Accessories shall not be liable for incidental or consequential damages resulting from use of equipment.
All claims for warranty must rst be approved by Amico Accessories. A valid Return Goods Authorization (RGA) number must
be obtained from Amico Accessories prior to commencement of any service work. Warranty work, which has not been pre-
authorized by Amico Accessories, will not be reimbursed.
AMICO ACCESSORIES DOES NOT HONOR VERBAL STATEMENTS CONCERNING THE WARRANTY.
The distributor and/or dealer are not sanctioned to create verbal warranties about the product described in this agreement. Any
statements will not be honored or be made part of the agreement of sale. This document is the nal complete and exclusive
terms of the agreement.
THIS WARRANTY IS INCLUSIVE AND REPLACES ALL OTHER WARRANTIES.
Amico Accessories shall not, under any circumstances be liable for incidental or consequential damages including, but not
limited to, prot, loss of sales or injuries to person(s) or property. Correction of noncompliance as noted above will result in
completion of all liabilities of Amico Accessories, whether based on agreement, neglect or changed materials, designs or
specications without notice.
All claims for warranty must rst be approved by Amico Accessories Service Department: accessories@amico.com or
1.877.264.2697). A valid Return Goods Authorization number must be obtained from Amico Accessories prior to commencement
