RIGHT HEIGHT® ELONGATED TOILET
AND
USABLE BUILDING FACILITIES-CHECK LOCAL CODES.
BARRIER FREE
PORTSMOUTH® CHAMPION® PRO
RIGHT HEIGHT® ELONGATED TOILET
❑ 213AA .104
• Features Champion® Flushing System
• Vitreous china
• High Efficiency Toilet (HET), ultra-low consumption
(1.28 gpf/4.8 Lpf), utilizes 20% less water
• Meets EPA WaterSense® Criteria
• Trade exclusive tank
• PowerWash® rim scrubs bowl with each ush
• Robust metal trip lever & metal shank ll valve
• Includes EZ-Install tools w/color match bowl caps
• EverClean® Surface included
• 4" piston-action Accelerator™ ush valve
• Fully-glazed 2-3/8" trapway
• 16-1/2" rim height for accessible applications
• 12" (305mm) rough-in
• Generous 9" x 8" water surface area
• Chrome nish trip lever is supplied
• 1,000g MaP Score** at 1.28gpf
• 10 year warranty
• Coordinates with Portsmouth Suite
❑ 3195A.101 Right Height® Elongated Bowl
❑ 4327A .104 Tan k
Nominal Dimensions:
768 x 423 x 790mm (30-1/4" x 16-5/8" x 31-1/8")
Fixture only, seat and supply sold separately
Compliance Certications Meets or Exceeds the Following Specications:
• ASME A112.19.2-2008/CSA B45.1-08 for Vitreous
China Fixtures
• US EPA WaterSense® Specication for HETs
** Maximum Performance (MaP) testing performed by
IAPMO R&T Lab. MaP Report conducted by Veritec
Consulting, Inc. and Koeller and Company.
To Be Specied:
❏ Color: ❏ White ❏ Linen
❏ Seat: #5214.110 longated traditional slow close
solid plastic seat and cover
#5325.010 Elongated Champion
solid plastic seat and cover
❏ Supply with stop:
®
Slow Close
PORTSMOUTH® CHAMPION® PRO
VITREOUS CHINA
FINISHED WALL
1"
(26 mm)
3-9/16"
(90 mm)
2-1/16"
(52 mm)
8-7/8"
(226 mm)
9-3/8"
(238 mm)
12"
(305 mm)
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (12") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE ORDERED
SEPARAT ELY.
DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
*
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerances established by ANSI Standard A112.19.2.
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
30-1/4"
(768 mm)
13-13/16"
(351 mm)
18-1/2"
(470 mm)
16-1/2"
FINISHED
FLOOR
31-1/8 "
(790 mm)
(419 mm)
16-5/8"
(423 mm)
14"
(356 mm)
10-9/16"
(268 mm)
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES
ICC ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND
© 2014 AS America Inc.
K96
Certified by
IAPMO R&T
Rev. 7/ 14
