Model # Description Finishes
25 mm
7-5/16"
(187 mm)
7-5/16"
(187 mm)
8888110
SLIP-ON NON-DIVERTER TUB SPOUT
• For 1/2" copper pipe
• Metal Construction
• 6-11/16" length to center of outlet
.002 Polished Chrome
.295 Brushed Nickel (PVD)
.013 Polished Nickel
.278 Legacy Bronze
SHOWER SYSTEMS
WALL MOUNT TUB SPOUTS
Roughing-In
Dimensions
(1") MIN.
2-5/8"
7-5/16"
(66 mm)
(187 mm)
1/2" COPPER
8888111
8888109
8888108
NON- DIVERTER 1/2 IPS TUB SPOUT
• For 1/2" copper pipe
• Metal Construction
• 6-11/16" length to center of outlet
SLIP-ON DIVERTER TUB SPOUT
• For 1/2" copper pipe
• Metal Construction
• 6-11/16" length to center of outlet
DIVERTER 1/2 IPS TUB SPOUT
• For 1/2" copper pipe
• Metal Construction
• 6-11/16" length to center of stream outlet
.002 Polished Chrome
.295 Brushed Nickel (PVD)
.013 Polished Nickel
.278 Legacy Bronze
.002 Polished Chrome
.295 Brushed Nickel (PVD)
.013 Polished Nickel
.278 Legacy Bronze
.002 Polished Chrome
.295 Brushed Nickel (PVD)
.013 Polished Nickel
.278 Legacy Bronze
25 mm
(1") MIN.
7-5/16"
25 mm
(1") MIN.
25 mm
(1") MIN.
2-5/8"
(66 mm)
(187 mm)
2-5/8"
(66 mm)
2-5/8"
(66 mm)
1/2" COPPER
1/2" COPPER
1/2" COPPER
© 2018 AS America, Inc.
4/18
