Page 1
7"
(179 mm)
FLUENT
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
MODEL NUMBER:
❏ 7186.801 Fluent Widespread
Metal Speed Connect® pop-up drain. Metal lever handles.
❏ 7186.811 Fluent Widespread
Metal Speed Connect® pop-up drain. Metal lever handle
with red and blue indicators.
13-1/2"
(344 mm)
3-5/8"
(93 mm)
1-1/4" MAX.
(32 mm)
3-5/8"
(93 mm)
1-1/16" DIA.
(29 mm)
8"
(203 mm)
1-1/2" MAX.
(38 mm)
®
5-1/4"
(134 mm)
6-7/8"
(174 mm)
MOUNTING
SURFACE
4-1/4"
(111 mm)
GENERAL DESCRIPTION:
Cast brass valve bodies with exible hose connections
for 6" to 12" (152 mm to 30 5mm) installations. 1/4 turn
washerless ceramic disc valve cartridges. Cast brass
spout. Cast brass inlet shanks and 24" stainless steal
braided exible supply hoses with 3/8" compression
connectors. 20 inch (500 mm) long exible stainless steel
drain cable is pre-assembled to faucet body. Metal Speed
Connect® drain body with 1-1/4 inch (32 mm)
tail piece. 1.2 gpm/4.5 L/min. maximum ow rate.
FLEXIBLE
HOSE
6" to 12"
(152 to 305 mm)
FLEXIBLE
FLEXIBLE
HOSE
1-1/4" OD
(32 mm OD)
PRODUCT FEATURES:
Brass Construction: Durable. Ideal for prolonged contact
with water. Provides the nest surface for application of
colors and nishes.
Ceramic Disc Valve Cartridge: Assures a lifetime of
drip-free performance.
Exclusive Speed Connect Metal Drain:
• Fewer parts. Installs in less time.
• No adjustments required - seals the rst time, every time.
• Flexible stainless steel cable - installs effortlessly in
tight spaces.
Lead Free: Faucet contains ≤ 0.25% total lead content by
weighted average.
SUGGESTED SPECIFICATION
Two-handle widespread lavatory faucet shall feature cast brass valve bodies with exible hose connections for 6" to 12"
installations. Shall also feature 1/4 turn washerless ceramic disc valve cartridges. Shall also feature a metal drain body with
stainless steel cable actuation. Fitting shall be American Standard Model #7186.8__.___.
© 2017 AS America, Inc.
Revised 5/17
Page 2
FLUENT
TWO-HANDLE WIDESPREAD LAVATORY FAUCET
®
CODES AND STANDARDS
These products meet or exceed the following
codes and standards:
ANS I A117.1
ASME A112 .18 .1
NSF 61/Section 9 and Annex G
CSA B125.1
Product
Number Description
7186.801
Fluent™ Widespread with metal Speed Connect® pop-up
drain. Metal lever handles.
FLOW RATE*
1.4
1.2
1.0
0.8
0.6
0.4
0.2
GALLONS PER MINUTE
0.0
*Flow rates shown are for mixed hot and cold.
INLET PRESSURE (PSI)
Finish Options
Polished
Chrome
002 224 295
Oil Rubbed
Bronze
806040200
PVD
Brushed
Nickel
718 6. 811
Meets the American Disabilities Act Guidelines and ANSI A117.1
Requirements for the physically challenged.
Fluent™ Widespread with metal Speed Connect pop-up
drain. Metal lever handles with red & blue indicators
© 2017 AS America, Inc.
Revised 5/17
