American Standard 091-0325, 091-0321, 091-0320, 091-0326 User Manual
International Patriot 13.2 Liter Toilets
Patriot 13.2L Elongated-RimToilet (091-0325)
VITREOUS CHINA
■ 13.2 Liters (3.5 Gallons) of Water Per Flush
■ Available in Elongated-Rim or Plain-Rim
■ Close-Coupled, Two-Piece Toilet
■ Siphon Vortex Bowl with Shelf-Top Tank
■ Fully Glazed 2" Trapway
■ 12" Rough-In
■ Available in White, Platinum, Natural/Bone, Biscuit, and
Onyx
■ 12" Rough-In
❑ 091-0320 Vitreous China, Two-Piece, Plain-RimToilet,
Includes (131-0320) Bowl and (141-0320) Tank 76 lbs., 4.36 Cubes
❑ 091-0321 Vitreous China, Two-Piece, Plain-RimToilet,
Includes (131-0320) Bowl and (141-0321) Insulated
Tank - 78 lbs., 4.36 Cubes
❑ 091-0325 Vitreous China, Two-Piece, Elongated-RimToilet,
Includes (131-0325) Bowl and (141-0320) Tank 83 lbs., 4.36 Cubes
NOTE: Dimensions May Vary +/- 1/2" and are Subject to
Change or Cancellation
Dimensions for Location of Supply are Suggested
❑ 091-0326 Vitreous China, Two-Piece, Elongated-RimToilet,
Includes (131-0325) Bowl and (141-0321) Insulated
Tank - 85 lbs., 4.36 Cubes
Component Part Weights:
■ 131-0320 Plain-Rim Bowl - 40 lbs., Cubes 2.80
■ 131-0325 Elongated-Rim Bowl - 43 lbs., Cubes 2.80
■ 141-0320 Tank - 36 lbs., Cubes 1.56
■ 141-0321 Insulated Tank - 38 lbs., Cubes 1.56
Flush Actuators:
❏ 495-2120-00 White (Standard on White Tanks)
❏ 495-2120-82 Natural (Standard on Natural/Bone Tanks)
❏ 495-2120-96 Biscuit (Standard on Biscuit Tanks)
❏ 495-2121-00 Polished Chrome (Furnished with Colors Other
Than White, Natural/Bone, and Biscuit)
❏ 495-2121-04 Polished Brass (Optional)
Plain-Rim Elongated-Rim
Water Surface 8-1/4" x 8-3/4" 9" x 8-3/4"
Trap Size 2" 2"
Trap Seal 2-3/8" 2-1/2"
CSA Certified
Toilets 3.30
ALL FIXTURES DIMENSIONS ARE NOMINAL AND MAY VARY WITHIN THE RANGE OF
TOLERANCES ESTABLISHED BY ASME/ANSI STANDARDS, A112.19.2M . ALL
MEASUREMENTS SHOWN ARE SUBJECT TO CHANGE OR CANCELLATION.
Eljer Plumbingware 8/01
9/03
3.
