Page 1
Quality Commercial Cooking Equipment
ITEM #
www.americanrange.com
HEAVY DUTY
AECB
AECB
CHAR ROCK BROILER
The American Range heavy duty Char Rock Broiler
is designed to provide reliable, solid performance
for many years. Self-cleaning, long lasting, natural
volcanic char rock is used to give the authentic effect and true flavor of Char Broiling. The juices from
the meat drip down onto the rocks, resulting in searing flames and smoke that enhances flavor.
Innovative design features heavy duty cast iron top
grates which are pitched with a cast in grease trough
in each blade for fat run off; this minimizes “flareup”.
Individually controlled 35,000 BTU/hr burners are
located every nine inches designed to provide complete coverage of a large cooking area, while providing flexibility to operate chosen burners as
needed, thus saving energy.
All our quality counter appliances come standard
with a stainless steel exterior and the best warranty
in the business. Look to American Range for innovation, reliable performance, quality and attention
to your equipment needs and delivery, now and in
the future.
AECB
SHOWN WITH OPTIONAL STAIN-
LESS STEEL LANDING LEDGE
STANDARD FEATURES
STANDARD FEATURES
Individually controlled cast Iron “H” burners placed every 9”.
Providing maximum output, even heat distribution, flexibility and
low maintenance.
Manual gas control valve for each burner.
Standing pilots for instant ignition for each burner.
Sectioned top grates individually removable for easy cleaning.
Heavy Duty cast iron top grates are angled to control “Flare-up”.
14 GA. all welded heavy duty reinforced fire box.
Stainless steel polished front and trim for easy cleaning, with fully
insulated double layered steel chassis.
Full length grease trough drains the run off into a removable
pan for easy cleaning.
Page 2
HEAVY DUTY CHAR ROCK BROILERHEAVY DUTY CHAR ROCK BROILER
HEAVY DUTY CHAR ROCK BROILER
HEAVY DUTY CHAR ROCK BROILERHEAVY DUTY CHAR ROCK BROILER
HEAVY DUTY CHAR ROCK BROILER
AECBAECB
AECB
AECBAECB
Series
MODEL BURNERS TOTAL BTU KW
AECB-14 14” 24” 13” ¼ 1 35,000 10.26 90
AECB-24 24” 24” 13” ¼ 2 70,000 20.51 165
AECB-34 34” 24” 13” ¼ 3 105,000 30.77 240
AECB-44 44” 24” 13” ¼ 4 140,000 30.77 315
AECB-54 54” 24” 13” ¼ 5 175,000 41.03 390
AECB-64 64” 24” 13” ¼ 6 210,000 61.54 465
AECB-74 74” 24” 13” ¼ 7 245,000 71.80 540
AECB-84 84” 24” 13” ¼ 8 280,000 82.00 615
SALIENT FEASALIENT FEA
SALIENT FEA
SALIENT FEASALIENT FEA
True Charbroiled flavor with natural volcanic char rock. Juices drip onto the rocks resulting in searing
flames and smoke that enhance the flavor of the food.
Individually controlled cast iron “H” shaped burners, 35,000 BTU/hr. spaced for even heat distribution.
Heavy duty cast iron top grates, 5” (127) x 21” (533), reversible, with grease runners to direct the run off to
the removable grease trough. Provides markings on the food. Top grates can be positioned flat or sloped.
AGA and CGA design certified. NSF listed.
AVAILABLE OPTIONSAVAILABLE OPTIONS
AVAILABLE OPTIONS
AVAILABLE OPTIONSAVAILABLE OPTIONS
S/S Landing ledge available in 6” (152),8” (203),10” (254) depth.
WIDTH DEPTH HEIGHT
TURESTURES
TURES
TURESTURES
SHIP. WT. Lbs.
Kg.
41
75
109
143
176
210
244
278
GasGas
Gas: Manifold pressure is 5.0” W.C. for natural gas or 10.0” W.C. for propane gas. Manifold size: ¾” (19) NPT. Specify type of gas and
GasGas
altitude if over 2000 feet.
ClearancesClearances
Clearances: For use in non combustible locations only, Clearance to non combustible construction 0”.
ClearancesClearances
American RAmerican R
American R
American RAmerican R
improvements these specifications are subject to change without prior notice.
ange Corporation ange Corporation
ange Corporation is a quality manufacturer of commercial cooking equipment. Because of continuing product
ange Corporation ange Corporation
T el: 818-897-0808 Fax:818-897-1670
