StorTrends® iTX Software

CLI (Command Line Interface)

(Version 2.7)

User’s Guide

MAN-STOR-ITX27-CLI

06/07/2010

This publication contains proprietary information which is protected by copyright. No part of this publication can be reproduced, transcribed, stored in a retrieval system, translated into any language or computer language, or transmitted in any form whatsoever without the prior written consent of the publisher, American Megatrends, Inc. American Megatrends, Inc. acknowledges the following trademarks:

Intel and Pentium are registered trademarks of the Intel Corporation. AMD, Athlon, and Athlon XP are trademarks of the Advanced Micro Devices Corporation. Sun and NFS are trademarks of the Sun Microsystems Corporation. Microsoft, Windows, Internet Explorer and MS-DOS are registered trademarks of the Microsoft Corporation and Active Directory is a trademark of the Microsoft Corporation. Macromedia Flash is a trademark of the Macromedia Corporation. IBM, AT, VGA, PS/2, and OS/2 are registered trademarks and XT and CGA are trademarks of the International Business Machines Corporation. Digital, DEC, and OpenVMS are trademarks of Digital Equipment Corporation. Compaq is a registered trademark of the Compaq Corporation. Hewlett-Packard, HP, and HP-UX are registered trademarks of Hewlett-Packard Company. Novell, NetWare, IPX, NCP, and NetWare Core Protocol are registered trademarks of the Novell Corporation. UNIX is a registered trademark in the United States and other countries, licensed exclusively through X/Open Company Ltd. Linux is a registered trademark of Linus Torvalds. Red Hat is a registered trademark of the Red Hat Corporation. Apple and AppleTalk are registered trademarks of Apple Computer Corporation. Yellow Pages is a registered trademark in the United Kingdom of British Telecom. Ethernet is a registered trademark of the Xerox Corporation. 802 is a registered trademark of the Institute of Electrical and Electronic Engineers, Inc. (IEEE).

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. American Megatrends, Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Revision History

02/16/06 Created iTX 2.1 CLI document. 02/16/06 iSCSI Tape command added. 02/16/06 UPS driver config command added. 02/23/06 Synchronous replication commands added. 06/20/06 Volume and Snapshot commands updated. 06/21/06 Synchronous replication, iSCSI configuration updated. 06/23/06 Document is revised and examples are added. 07/14/06 General Server configuration section updated. 07/27/06 Updated for version 2.5.1011 and above. 08/17/06 Added Error Codes section. 04/26/07 Changed the volume chunk size. 04/26/07 Added the SRM commands. 06/28/07 Removed Tape commands. 01/16/09 Updated document and added journal and cdp commands. 12/11/09 Update the network command usage and CLI error text 01/25/10 Updated the OS Agnostic HA related commands and CLI error text 01/25/10 Updated Network Alias commands

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

01/25/10 Updated the iSCSI commands and corrected wrong format updation 03/30/10 Corrected the Create Volume usage and Get Eventlog Usage. 04/11/10 Update the create replication commands 06/07/10 Corrected the output of ‘cli main’. 06/07/10 Removed the term apple 06/07/10 Corrected set -t nfs command. 06/07/10 Corrected set raid commands. 06/07/10 Added available cache options for create raid. 06/07/10 Since alarm and cache is supported for set raid; the ‘not supported’ was removed. 06/07/10 Osinfo commands removed.

Preface

iii

Table of Contents

Revision History ......................................................................................................................................... ii

Table of Contents ..................................................................................................................................... iv

Limited Warranty ....................................................................................................................................... v

Limitations of Liability ................................................................................................................................ v

Technical Support ...................................................................................................................................... v

Web Site ................................................................................................................................................ v

Disclaimer ................................................................................................................................................. vi

Chapter 1 Overview of CLI ..................................................................................................................... 1

Preface ...................................................................................................................................................... 1

Overview of CLI ......................................................................................................................................... 1

Accessing CLI ............................................................................................................................................ 1

Initial Setup ................................................................................................................................................ 2

Network Configuration ........................................................................................................................... 2

Volume Configuration ................................................................................................................................ 3

1. RAID Disk Creation ............................................................................................................................ 3

2. Container and Volume Configuration................................................................................................. 4

3. Enabling Share or Target ................................................................................................................... 5

Chapter 2 Command Set ........................................................................................................................ 7

Command Set ............................................................................................................................................ 7

Alert Configuration ..................................................................................................................................... 9

Date/Time Configuration .......................................................................................................................... 10

Domain Configuration .............................................................................................................................. 10

Event log Commands .............................................................................................................................. 11

Firewall Configuration .............................................................................................................................. 12

General Server Configuration .................................................................................................................. 13

Health Configuration ................................................................................................................................ 13

iSCSI Configuration ................................................................................................................................. 14

License configuration ............................................................................................................................... 16

Network Controller Configuration ............................................................................................................ 17

NAS Quota Configuration ........................................................................................................................ 18

NAS User / Group Configuration ............................................................................................................. 19

Protocol Configuration ............................................................................................................................. 20

RAID & Disk Management Commands ................................................................................................... 21

Share, Directory & ACL Configuration ..................................................................................................... 24

System Control Configuration ................................................................................................................. 26

Volume and Snapshot Commands .......................................................................................................... 26

UPS Configuration ................................................................................................................................... 29

Synchronous replication .......................................................................................................................... 30

Asynchronous Replication ....................................................................................................................... 33

Journal Volume Management ................................................................................................................. 39

Continuous Data Protection..................................................................................................................... 41

Recovery Wizard ..................................................................................................................................... 41

Storage Resource Management ............................................................................................................. 42

Local and Replicated Snapshot validation .............................................................................................. 43

Appendix A Error Codes ...................................................................................................................... 45

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Limited Warranty

The buyer agrees that if this product proves to be defective, American Megatrends is only obligated to repair or replace this product at American Megatrends’ discretion according to the terms and conditions of the warranty registration software that accompanies this product. American Megatrends shall not be liable in tort or contract for any loss or damage, direct, incidental or consequential resulting from the use of this product. Please see the Warranty Registration Software shipped with this product for full warranty details.

Limitations of Liability

American Megatrends, Inc. shall in no event be held liable for any loss, expenses, or damages of any kind whatsoever, whether direct, indirect, incidental, or consequential (whether arising from the design or use of this product or the support materials provided with the product). No action or proceeding against American Megatrends may be commenced more than two years after the delivery of product to Licensee of Licensed Software.

Licensee agrees to defend and indemnify American Megatrends from any and all claims, suits, and liabilities (including attorney’s fees) arising out of or resulting from any actual or alleged act or omission on the part of Licensee, its authorized third parties, employees, or agents, in connection with the distribution of Licensed Software to end-users, including, without limitation, claims, suits, and liability for bodily or other injuries to end-users resulting from use of Licensee’s product not caused solely by faults in Licensed Software as provided by American Megatrends to Licensee.

Technical Support

American Megatrends provides technical support for American Megatrends products purchased directly from American Megatrends or from an American Megatrends-authorized reseller only.

If… Then…

You purchased this product from American Megatrends or from a certified American Megatrends reseller,

This American Megatrends product was installed as part of a system manufactured by a company other than American Megatrends or you purchased an American Megatrends product from an unauthorized reseller,

If the American Megatrends StorTrends® iTX Software fails to operate as described or you are in doubt about a configuration option, please call technical support at 770-246-8645.

Web Site

We invite you to access the American Megatrends’ World Wide Web site at:

http://www.ami.com/

call American Megatrends’ technical support at 770246-8645. Please be prepared to specify the serial number or CD Key of the product (if applicable). call the technical support department of the computer manufacturer or the unauthorized reseller. American Megatrends does not provide direct technical support in this case.

Preface

Disclaimer

This manual describes the operation of the American Megatrends StorTrends® iTX Software. Although efforts have been made to assure the accuracy of the information contained here, American Megatrends expressly disclaims liability for any error in this information, and for damages, whether direct, indirect, special, exemplary, consequential or otherwise, that may result from such error, including but not limited to the loss of profits resulting from the use or misuse of the manual or information contained therein (even if American Megatrends has been advised of the possibility of such damages). Any questions or comments regarding this document or its contents should be addressed to American Megatrends at the address shown on the inside of the front cover.

American Megatrends provides this publication “as is” without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of merchantability or fitness for a specific purpose.

Some states do not allow disclaimer of express or implied warranties or the limitation or exclusion of liability for indirect, special, exemplary, incidental or consequential damages in certain transactions; therefore, this statement may not apply to you. Also, you may have other rights which vary from jurisdiction to jurisdiction.

This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in new editions of the publication. American Megatrends may make improvements and/or revisions in the product(s) and/or the program(s) described in this publication at any time.

Requests for technical information about American Megatrends products should be made to your American Megatrends authorized reseller or marketing representative.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Chapter 1 Overview of CLI

Preface

Our feature rich StorTrends® iTX comes with a built-in command line interface (CLI) that provides extensive options to monitor and control “managed objects”. Wherever applicable, CLI follows industry standards and uses extensible ‘tags’ for new features and objects. The command line utility can be accessed through an in-band special console connected to the StorTrends® iTX system or out-of-band via a SSH or telnet client. It can also be used with scripting languages to automate a set of operations.

Overview of CLI

Our CLI supports commands in excess of 140 verbs and supports XML output format. The design is very similar to DMTF SMASH specifications and is being extended to fully comply with SMASH. Every managed element or object has a SMASH compliant <Target> addressing conforming to the server management instance addressing specification. The commands implemented are essentially “stateless” in nature. SMASH compliant <Verbs> is used to select the management actions, which are complemented by extensive <Option> attributes to control the behavior of the command. <Property> attributes can control the behavior of the output produced by the <Verb> along with various other mapping actions to the CIM schema.

The output produced can be controlled depending on the need, For example, in automation scripting. Output can also be made to be in the W3C standard compliant, self-descriptive XML format. The output format includes new tags pertinent to the object management. Inherent support for multi-lingual documents and Unicode data, along with content separation from presentation, aids in development of management applications that have their own data representation format. CLIs used for monitoring of performance parameters are dished out in XML tags that assist in graphing and charting, and can be right away imported by spreadsheet applications.

Accessing CLI

The CLI can be accessed either through an in-band console connected directly to the ITX box or through the out-of-band / remote CLP agents. It can also be accessed through a remote terminal emulation program using SSH or Telnet. Once connected, the administrator has to login to the system to perform the operations. In a typical console session, the user will be presented with a login screen such as:

“cli” is the special user that has been provided with CLI access. The password is factory defaulted to “password”. Once logged in, the system will present the user with a CLI shell as follows:

CLI>

The user can then enter the supported commands in any order. The supported commands are listed in the next section. To close the session, the user can type the command ‘quit’. This will end the session.

Chapter One: Overview of CLI

Initial Setup

Network Configuration

Once the StorTrends® iTX is installed in a new system, please ensure that the initial network configuration is proper. The system factory defaults to DHCP setup. The configured network settings can be verified by the following CLI commands:

CLI> get –-type or –t port

-–name or –n NIC-1

--info or -i network <Enter>

Example: get –t port –n nic-1 –i network

This will display the NIC-1 network settings.

To configure static IP to this port:

CLI> set –-type or –t port

–-name or –n NIC-1 –-ip or –i 10.0.0.100 –-mask or –m 255.255.255.0 –-gate or –g 10.0.0.7 (optional)

--pridns or –p 10.0.0.2 (optional)

--secdns or –s 0.0.0.0 (optional)

--dnssuff or –f ami.com (optional) network <Enter>

Example: set –t port –n nic-1 –i 10.0.0.100 –g 10.0.0.7

-p 10.0.0.2 –s 0.0.0.0 –f ami.com network

Here 10.0.0.100 is the static IP address, 255.255.255.0 is netmask and 10.0.0.7 is the network gateway.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Volume Configuration

Initial volume configuration can be done in three stages.

1. RAID Disk Creation

At the base level is the RAID CONTROLLER.

CLI> list –-type or –t controller

raid <Enter>

Example: list –t controller raid

This will list the available RAID controllers in the system. By default, Software MD will be shown as a RAID controller with controller number “0”. If Hardware RAID controllers present, then they will take precedence over Software MD.

CLI> list –-type or -t PD

--controllerno or -n 0 raid <Enter>

Example: list –t pd –n 0 raid

This will list the PD’s that are available for configuration in controller number zero. PD’s can be grouped through a RAID level to form a Logical disk – LD.

CLI>create –-type or -t LD

–-stripesize or -p 64 –-diskname or -d /dev/sda (use –d 1 or –d 2…15 on a 3U) –-diskname or –d /dev/sdb –-diskname or –d /dev/sdc –-diskname or –d /dev/sdd

--raidlevel or –r 0

--controllerno or –n 0

--cachemode or –m 3 raid <Enter>

Example: create –t ld –p 64 –d 1 –d 2 –r 1 –n 0 –m 2 raid

This will create a RAID 1 Logical Disk – LD with 64K-chunk size and two disks on a 3U.

Example: create –t ld –p 64 –d /dev/sda –d /dev/sdb –d /dev/sdc –r 5 –n 0 –m 1 raid

This command will crate a RAID 5 Logical disk – LD with 64 k chunk size and three disks on a 1U box.

CLI> list –-type or –t LD

raid <Enter>

Example: list –t ld raid

This will list the available RAID LD’s present in the system.

Chapter One: Overview of CLI

2. Container and Volume Configuration

Next step is the AMI DVM container creation. This can be done by the following commands:

CLI>create –-type or -t container

–-containername or -c container1 –-chunksize or –k 64 –-ldname or –l /dev/md0 volume <Enter>

Example: create –t container –c accounting –k 64 –l /dev/sdb volume (for a 3U)

This command creates a container named “accounting” from the LD /dev/sdb.

On a 1U, LDs are created with names of /dev/mdX, with X as 0, 1, and so on. Therefore the above operation would be accomplished by entering, for example:

Example: create –t container –c marketing –k 64 –l /dev/md1 volume

The next step is the creation of volumes.

A NAS volume can be created by the following command:

CLI>create –-type or –t volume

–-containername or -c container1 –-volumename or -v nasvol0 –-volumesize or -z 1000 (in GB) –-provisiontype or -p 0 (0 is thin-provisioned, 1 is exact) –-volumetype or -e 0 (type 0 is ROW) –-voldialect or –f 1 (dialect 1 is NAS, 0 is iSCSI)

--chunksize or –k (8 or 64 for 8KB and 64KB chunk sized volume respectively.)

volume <Enter>

Example: create –t volume –c container1 –v volume1 –z 1000 –p 0 – e 0 –f 1 –k 64 volume

This command creates volume “nasvol0” in container “container1” with size of 1000GB, that is thinprovisioned, Redirect-On-Write, and of NAS type with chunk size as 64KB.

Volume size should be in GBs and currently supported volume type is 0 – ROW.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Similarly a SAN volume can be created as follows:

CLI>create –-type or –t volume

–-containername or -c container1 –-volumename or -v sanvol0 –-volumesize or -z 1000 –-provisiontype or -p 0 –-volumetype or -e 0 –-voldialect or -f 0

--chunksize or –k (8 or 64 for 8KB and 64KB chunk sized volume respectively.)

volume <Enter>

Example: create –t volume –c container1 –v volume1 –z 1000 –p 0 – e 0 –f 1 –k 8 volume

This command creates volume “sanvol0” in container “container1” with size of 1000GB, that is thinprovisioned, Redirect-On-Write, and of SAN type with chunk size as 8KB.

3. Enabling Share or Target

To enable NAS share, use the following command syntax. Make sure the corresponding share protocol is enabled in the system.

First, create the directory in the path before creating a share for the path.

CLI>create --path or -p container1_nasvol0/test

dir<Enter>

Example: create –p cont1_nasvol0/test dir

This command creates the subdirectory of “test” within the volume “nasvol0” in the container “cont1”.

Then create the share using the following syntax.

CLI>add –-name or -n NASShare

–-path or -p container1_nasvol0/test –-prototype or -s cifs –-prototype or -s nfs share <Enter>

Example: add –n nasshare –p cont1_nasvol0/test –s cifs –s nfs share

Note: The path specified should be of format:

“ContainerName_VolumeName/directoryName”.

To create a target, use the following commands.

CLI>add –-type or -t lun

--volumename or -v sanvol0

–-containername or -c container1 –-targetname or -n sanvol0 iscsi <Enter>

Example: add –t lun –v sanvol0 –c cont1 –n sanvol0 iscsi

Chapter One: Overview of CLI

Then, to enable the target, use the syntax below:

CLI>enable –-type or –t tgt

–-targetname or -n sanvol0 iscsi <Enter>

Example: enable –t tgt –n sanvol0 iscsi

Next step is to activate a port for iSCSI traffic.

CLI>activate –-type or –t portal

–-ipaddress or -p 10.0.0.100 –-portaltag or -g 1 iscsi

Example: activate –t portal –p 10.0.0.100 –g 2 iscsi

We recommend that you assign different portal tags to the two portals if they are on different subnets.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Chapter 2 Command Set

Command Set

The CLI design being similar to the DMTF SMASH specifications follows the standard to a great extent. The commands supported can be represented grammatically as follows:

The CLI provides a wide range of command sets. These commands are grouped into modules for better understanding. Each command is non-interactive and state-less. The <options> are supported using switches. Our CLI accepts both short and long options for each switch to make it user-friendly. If there is any error in the parameters entered, the CLI will display the usage of that particular command.

CLI also provides extensive online help. Each command supports a help option using ‘-h’ or ‘--help’ that will display the grammar of the command.

To get the main list of targets or modules present in CLI, the user should type the command “main” at the CLI prompt.

The following targets will get displayed:

***************************************************************** TARGET LIST

-----------------------------------------------------------------

1. ug 2. ups

3. dir 4. srm

5. dump 6. raid

7. ndmp 8. alert

9. iscsi 10. share

11. quota 12. system

13. volume 14. domain

15. health 16. license

17. network 18. journal

19. eventlog 20. protocol

21. firewall 22. datetime

23. timezone 24. serverinfo

25. sysupgrade 26. syncreplica

27. asyncreplica 28. recoverywizard

29. snapvalidation For more information on the targets please use the following command

show -t/--target <targetname>

Note : Targetnames are case insensitive

Example : show -t iscsi *****************************************************************

The show option can also be used to show commands based on <verb>, and to display the list of targets or verbs available.

Chapter Two: Command Set 7

For example: To find out how the show command works, type:

CLI>show -h <Enter>

This will display the many ways the show command can be used.

(this is redundant) For example: To display the available targets/verbs, the user has to enter:

CLI>show –d targets <Enter> CLI>show –d verbs <Enter>

The show option can display the functions available for a target or even the functions available for a verb.

For example: To display the functions available for targets/verbs the user has to enter:

CLI>show –t <targetname> <Enter>

Example: show –t ups

CLI>show –v <verbname> <Enter>

Example: show –v list

Note: In the table below, though the <target> is given in the first column together with <verb>, it should

actually be typed at the end of command, complying with SMASH specification. Again, the target is not case-sensitive.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Alert Configuration

These commands configure the way alerts are generated.

Command Argument Description

get alert -t/--type snmp

For example: get –t snmp alert

get alert -t/--type email

For example: get –t email alert

delete alert -t/--type snmp

-v/--value <destination>

-x/--xml alert For example: delete -t snmp -v 10.0.3.155 -v 10.0.0.203 -x alert

delete alert -t/--type email

-v/--value <emailaddress>

-x/--xml alert For example: delete -t email -v sam@yahoo.com -v yyy@ami.com -x alert

set alert -t/--type snmp

-e/--enable or

-d/--disable

-v/--value <alertmask:communityname:destination>

-x/--xml For example: set –t snmp –e –v 1:public:10.10.10.5

-x alert

set alert -t/--type email

-e/--enable or

-d/--disable

-v/--value <alertmask:language:emailaddr>

-s/--emailserver (IP address)

-F <Fully Qualified Domain Name>

-x/--xml

For example:

1:1:sam@yahoo.com -s 10.0.0.79 -F ami.com -x alert

set -t email -e -v

Gives the SNMP alert configuration.

Gives the Email alert configuration.

Deletes the SNMP specified destination from the alert configuration.

Deletes the specified email address from the alert configuration.

Configures SNMP alerts.

Note: <alertmask:communityname:destin ation> For example: <1:public:10.0.0.79> Configures Email alerts. <alertmask:language:emailaddr> <1:1:aaaa@ami.com>

Language 0-Unknown 1-English 2-Japanese 3-Korean 4-Chinese

Alert Mask: 1 - Information 2 - Warning 4 - Fatal Any combination of the three alert masks up to a maximum of seven levels.

Chapter Two: Command Set 9

Date/Time Configuration

These commands configure the time zone and date.

Command Argument Description

set timezone -z/--zone <zone name>

-x/--xml

For example: set –z America/New_York timezone get timezone For example: get timezone Shows the configured time zone. set datetime -n/--ntp <FQDN of NTP server or ipaddress> Configures the NTP server to be

get timezone -c/--count Gets the number of time zones. set datetime -d/--date <date in MM/DD/YYYY>

-t/--time <time in HH:MM:SS>

-x/--xml

For example: set –d 12/01/2006 –t 12:11:55

datetime list timezone For example: list timezone Lists the time zones supported. get datetime For example: get datetime Shows the date & time.

Sets the time zone of StorTrends® iTX to given time zone.

used for time synchronization.

Sets the date and time to given values.

Domain Configuration

These commands configure the domain server to be used for authentication.

Command Argument Description

get domain -t/--type {nis/ms}

-x/--xml

For example: get –t nis domain set domain -t/--type{ nis }

-b/--broadcast {y/n}

-d/--domain <domainname >

-s/--server <server-1>

-s/--server <server-2>

-x/--xml

For example: set -t nis -b n -d NISSERV -s

10.0.0.215 -s 10.0.0.25 -s 10.0.0.5 domain

set domain -t/--type {ms}

-m/--mtype {wg}

-d/--domain< domainname>

-x/--xml

For example: set -t ms -m wg -d MYGROUP

domain set domain -t/--type {ms}

-m/--mtype {/nt/ads}

-d/--domain< domainname>

-D/--nbname<netbiosname> (optional)

-i/--ip <serverip>

-I/--secip<secondary serverip> (optional)

-o/--orgname <orgName> (optional)

-u/--user <Adminname >

-p/--passwd <Adminpassword>

-x/--xml

For example: set –t ms –m ads –d domain1.com –D

domain1 –I 10.10.220.1 –u Administrator –p

password domain

Displays the domain information of either NIS or Microsoft (MS) domains. Sets the NIS domain to given domain with broadcast mode OFF or ON. Servers can be added using the –s/--server switch. If broadcast is set to OFF, then no servers are needed.

Sets the Microsoft domain type to Workgroup.

Sets the Microsoft domain type to NT / ADS.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Event log Commands

These commands display or clear the event log.

Command Argument Description

get eventlog -s/--section {v/s/o/h}

-o/--offset <record-offset>

-n/--recordcount <record-count>

-i/--info

-f/--fatal

-w/--warning or

-a – all eventlog

-x/--xml

For example: get –s vs –o 2 –n 20 –f –w eventlog get eventlog -c/--count

-s/--section {v/s/o/h}

-i/--info

-f/--fatal

-w/--warning or

-a/-- all eventlog

-x/--xml

For example: cli get -s vsoh -a -c eventlog clear eventlog Clears the complete event log.

Lists event log content matching the given criteria.

v-Volume s-System o-OS h-Health

Gets the number of events reported.

Chapter Two: Command Set 11

Firewall Configuration

These commands configure the network firewall options.

Command Argument Description

add firewall -a/--allow or

-b/--block

-i/--ip <ipaddress>

-m/--mask <netmask>

-p/--proto {icmp}

-x/--xml

add firewall -a/--allow

-b/--block

-i/--ip <ipaddress>

-m/--mask <netmask>

-s/--sport <start-port>

-e/--eport <end-port>

-p/--proto {tcp/udp}

For example: add –a –i 10.10.1.1 –s 1200 –e 5000 –

p tcp firewall edit firewall -a/--allow or

-b/--block

-r/--rule<ruleno>

-i/--ip <IP address>

-m/--mask <net mask>

-p/--proto { icmp}

-x/--xml

For example: edit -a -i 10.0.0.218 -r 1 -m

255.255.255.255 -p icmp -x firewall

delete firewall -a/--allow or

-b/--block

-r/--num <rule number>(obtained when viewing the

list of firewalls via the list command below)

-x/--xml

For example: delete -b -r 1 -x firewall edit firewall -a/--allow or

-b/--block

-r/--rule<ruleno>

-i/--ip <IP address>

-m/--mask <net mask>

-s/--sport <start port>

-e/--eport <end port>

-p/--proto {tcp/udp}

-x/--xml

For example: edit -a -i 10.0.0.218 -r 1 -m

255.255.255.255 -s 2000 -e 3000 -p udp -x firewall

list firewall Lists all the blocked and allowed

get firewall -c/--count

-x/--xml

For example: get -c -x firewall

Add allowed or blocked firewall rule with given parameters for the ICMP protocol.

Add allowed or blocked firewall rule with given parameters for TCP and UDP protocols.

Modifies specified allowed or blocked firewall rule with given rule number to the given values for ICMP.

Deletes allowed or blocked firewall rule with given rule number.

Modifies specified allowed or blocked firewall rule with given rule number to the given values for TCP or UDP.

firewall rules. Retrieves the count of allowed or blocked firewall rules.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

General Server Configuration

These commands retrieve the general server information, such as build version, build date and so on. It also allows configuration of a new server name.

Command Argument Description

get serverinfo For example: get serverinfo Displays the server information

such as server name, build version, build date and so on.

set serverinfo -n/--name <server name>

-x/--xml

For example: set –n newitx serverinfo

set serverinfo -p/--password

–u/--user{root/cli}

-x/--xml

create dump Creates a dump of the running

Configures the name of the server. The length of the servername should be less than 16 characters and the first character must be alphabetical. System will prompt you to enter and confirm the new administrator (root/cli) password. Password length should be 32 or less characters.

system that is useful for debugging. The file is placed in /usr/AmiNas.

Health Configuration

These commands get the health information

Command Argument Description

get health -c/--enccount

-x/--xml

For example: get –c health get health -i/--info –n/--enclosure

-x/--xml

For example: get –i –n 0 health

get health -s/--encstatus

–n/--enclosure (optional)

-x/--xml

For example: get –s health

get –s –n 0 health get health -a/--

-x/--xml

For example: get –x –a health

Gets the number of enclosures present in the system.

Gets the health information regarding fan, voltage and temperatures for the given enclosure. Gets the enclosure status for the given enclosure or for all the enclosures.

Gets the enclosure status for all the enclosures.

Chapter Two: Command Set 13

iSCSI Configuration

Note: Targetname input: Only the suffix portion of the targetname is required.

For example: “iqn.1991-10.com.ami:itx001a2b3c4d5e2006:test1” . The user needs to input only “test1”.

Command Argument Description

get iscsi -t/--type {tgtstatus}

-n/--targetname <targetsuffix>

For example: get –t tgtstatus –n target1 iscsi get iscsi -t/--type {tgtname} Gets the iSCSI target name. This

activate iscsi -t/--type {portal}

-p/--ipaddress <Ipaddress of the target machine>

-g/--portaltag <portal tag>

For example: activate –t portal –p 10.15.1.1 –g 3

iscsi deactivate iscsi -t/--type {portal}

-p/--ipaddress <ipaddress of the target machine>

enable iscsi -t /--type {tgt}

-n/--targetname <target suffix>

disable iscsi -t/--type {tgt}

-n/--targetname <target suffix>

For example: cli disable –t tgt –n newtgt iscsi start iscsi To start the iSCSI service. stop iscsi For example: stop iscsi To stop the iSCSI service. set iscsi -t/--type {params}

-o/--choiceno {0-12}

-l/--value <value>

For example: set –t params –o 1 –l 256 iscsi.

get iscsi -t/--type {lunwritecachemode}

-v/--volumename <volume name>

-c/--containername <containername>

set iscsi -t/ --type {lunwritecachemode}

-v/--volumename <volume name>

Gives the status of the target as enabled or disabled.

value is not configurable and is unique to the iTX device. For example: iqn.1991-

10.com.ami:itx0030482c8d788a7e Activates the specified iSCSI portal. You have to specify a portal tag at the time of activation of the portal.

Deactivates the specified iSCSI portal. Enables the specified target.

Disables the specified target.

Sets specified iSCSI Login negotiation parameters. The possible values are:

1. FirstBurstLength (0-256 KB, default=256)

2. MaxBurstLength (must be less than #1, default=256)

3. MaxRecvDataSegmentLength (0-256KB, default=256)

4. MaxConnections (0-4, default=2)

5. DefaultTime2Retain (0-3600, default=20 sec)

6. DefaultTime2Wait (03600,default=2 sec)

7. InitialR2T (0-1, default=No,0)

8. MaxOutStandingR2T (1-8, default=1 sec)

9. ErrorRecoveryLevel (0-2, default=2)

10. ImmediateData (0-1, default=1,yes)

11. DataPduInOrder (0-1, default=1,yes)

12. DataSeqInOrd (01,default=1,yes) Gets the Write Cache mode for the specified disk.

Sets the Write Cache mode for the specified disk.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Command Argument Description

-c/--containername <containername>

-m/--mode {0/1/2}

For example: set –t lunwritecachemode –v v1 –c c1

0 – Write through 1 – Write back

–m 0 iscsi add iscsi -t/--type {processor}

-n/--targetname <target suffix>

remove iscsi -t/--type {processor}

-n/--targetname <target suffix>

get iscsi -t/--type {statistics}

For example: get –t statistics iscsi

Adds the processor to the specified target (used for backup). Removes the processor from the specified target. Gets the iSCSI statistics, for example, No. of iSCSI PDU sent and received, payload, and login/session failures.

get iscsi -t/--type {portalstatus}

Gets the iSCSI Portal Status.

-p/--ipaddress <ipaddress>

get iscsi -t/--type {servicestatus} Gets the iSCSI service status.

(Active/Inactive)

add iscsi -t/--type {lun}

-v/--volumename <volume name>

Adds the LUN to the specified target.

-c/--containername <container name>

-n/--targetname <targetsuffix>

remove iscsi -t/--type {lun}

-v/--volumename <volume name>

Removes the LUN from the specified target.

-c/--containername <container name>

-n/--targetname <target suffix>

get iscsi -t/--type {sessions}

For example: get –t sessions iscsi remove iscsi -t/--type {session}

-s/--sessionid <session id>

Gets the current sessions details including session id. Terminates the session with the given ID. To avoid automatic reconnection by the initiator, you will need to change the security settings for that target prior to

termination. list iscsi -t/--type {tgt} Gets the List of Targets available. list iscsi -t/--type {lun}

-n/--targetname <target suffix>

get iscsi -t/--type {tgtauthsettings}

-n/--targetname <target suffix>

set iscsi -t/--type {peersecret}

-i/--initiatorname < initiatorname. (Default : none)>

-s/--peersecret

Gets the available LUNs in the

given target.

Gets the Authorization settings for

the target.

Sets the peer secret for the initiator.

You will be prompted to enter this

twice.

For example: set –t peersecret –I iqn.1991-

10.com.microsoft:newbox –s iscsi

set iscsi -t/--type {tgtauthsettings}

-n/--targetname <targetsuffix>

-u/--username <user name ‘none’ for default >

-r/--secretname <user password ‘none’ for default >

-i/--initiatorname <initiator name – ‘none’ for default>

get iscsi -t/--type {lun}

-n/--targetname <target suffix>

Sets the Authorization settings for

the target. The secret name should

be at least 12 characters in size

This will give exclusive access to

the LUN for the specified user and

initiator for maximum security.

Gives the LUN's Information for

the specified target.

-v/--volumename<volumename>

-c/--containername<containername>

-i/--info

get iscsi -t/--type {tgtoptimizations}

-n/--targetname <target name>

Gives the Target's Optimization

settings (i.e. whether multiple

initiator logins are supported). set iscsi -t/--type {tgtoptimizations}

-n/--targetname <target suffix>

-p/ --multiplesession {y/n}

-g/--nopinterval < nop ping internal >

Sets the Target's Optimization

settings to allow/disallow multiple

initiators logging in to a target

simultaneously.

Chapter Two: Command Set 15

Command Argument Description

For example: set –t tgtoptimizations –n t1 –p y –g

10 iscsi enable iscsi -t/--type { iSNSservice} Enables the iSNS Service. disable iscsi -t/--type { iSNSservice} Disables the iSNS Service. get iscsi -t/--type {iSNS} Gives the iSNS server's

information i.e. iSNS server IP, server status, command description, last status message.

set iscsi -t/--type {iSNS}

-e/--entityname <entity name>

-a /--aliasname <alias name>

enumerate iscsi -t/--type {initiator}

-n/--targetname <target suffix, ‘none’ for default>

add iscsi -t/--type {iSNSServer}

-i/--ipaddress <ip address>

remove iscsi -t/--type {iSNSServer}

-p/--ipaddress <ip address> rescan iscsi -t/--type {iSNS} Rescan for targets and initiators. update iscsi -t/--type {noderegistrations} Updates the nodes that are

reset iscsi Resets the iSCSI statistics. get iscsi -t/--type {params}

-o/--choice {0-12} set iscsi -t/--tgtname This resets the base iSCSI target

Sets the specified iSNS information.

Gets the iSCSI initiators from the iSNS server. Adds a new iSNS server.

Removes an existing iSNS server.

registered with all iSNS servers this iTX device is registered with.

Gets values of the specified iSCSI login negotiation parameters.

name of the iTX box

This operation should be done with utmost precaution and there should not be any replication pairs in the box. Logout of all existing iSCSI sessions before running this command

License configuration

These commands configure the License.

Command Argument Description

set license -k/--key <key>

-x/--xml set license -f/--file <filename with path>

-x/--xml get license -s/--serviceKey

-x/--xml

get license -l/--licenseInfo

-x/--xml

Sets the entered license key to file.

Sets the license according to the license key given in file path. Gets the license service key necessary if you want to upgrade your iTX license. Gets the current license information.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Network Controller Configuration

These commands configure the network ports. They can also be used to create virtual bonding network ports (teams) for high availability and/or load balancing.

Command Argument Description

get network -t/--type {port}

-c/--count

-x/--xml

For example: get –t port –c count network

get network -t/--type {port / alias}

-n/ --name <name of the adapter >

-i/--info

-x/--xml set network -t/--type {port}

-n/--name <Name of the NIC>

-d/--dhcp

-x/--xml

For example: set –t port –n nic-1 –d network

set network -t/--type {port / alias}

-n/--name <Name of the NIC>

-i/--ip <IP Address>

-m/--mask <net mask>

-g/--gate <Gateway> (optional)

-p/--pridns <Primary DNS> (optional)

-s/--secdns <Secondary DNS>(optional)

-f/--dnssuff <DNS suffix>(optional)

-j/--mtu <size> (optional) get network -t/--type {adp}

-c/--count

-x/--xml list network -t/--type {adp} Displays the available network

create network -t/--type {team}

-m/--mode {1/2/3}

-p/--pri <primary NIC>

-s/--sec <secondary NIC>

-x/--xml

Creates a team named Team-1, Team-2, and so on, depending on available NICs in system For example: create –t team –p nic-1 –s nic-2 –m 1 network

delete network -t/--type {team}

-n/--name <name of the Team>

-x/--xml

For example: delete –t team –n Team-1 network

get network -t/--type {team}

-i/--info

-n/--name <name of the Team>

-x/--xml

For example: get –t team –i –n Team-1 network

get network -t/--type {team}

-i/--info

-n/--name <name of the Team>

-x/--xml list network -t/--type {adp/port}

-x/--xml

add network -t/--type alias

-n/--name <alias name>

Gets the number of ports.

Displays the given network port information.

Configures the given network port to work with DHCP.

Configures the specified network port to work with the given STATIC IP configuration.

Displays the number of network adapters present.

adapters and their status. Creates a network team with the given mode. The supported modes are: 1 – Balance Round Robin 2 – 802.3 AD (with pre-configured switch) 3 – Balance TB

Deletes the network team with the given name.

Displays the number of NICs present in the given team.

Displays the given network team information.

Displays various information for the available network ports including their status. Adding an alias adapter for a specific NIC port

Chapter Two: Command Set 17

Command Argument Description

-p/--port <adapter name> remove network -t/--type alias

-n/--name <alias name>

Removing an alias adapter

NAS Quota Configuration

These commands configure quotas for the NAS volumes of your iTX box.

Command Argument Description

get quota -t/--type {user }

-p/--path <volume path>

-n/--name <user name>

-x/--xml

For example: get –t user –p c0_nas0 –n user1 quota

set quota -t/--type {user }

-p/--path <volume path>

-n/--name <user name>

-q/--quotasize <size>

-f/--filecount <file count>

-x/--xml

For example: set –t user –p c0_nas0 –n user1 –q 4000 –f 400 quota

list quota -p/--path <volume path>

-x/--xml

get quota -p/--path <volume path>

-d/--default

-x/--xml set quota -p/--path <volume path>

-q/--quotasize (KB) <quota size>

-d/--default [y/n]

-x/--xml

Displays the quota configured for the given member.

Configures the quota size of given member. Size should be entered in KB.

Displays the user quota configured for a given volume as specified in path. Displays the default quota configured for the volume.

Sets the default quota limit which should be used for a volume.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

NAS User / Group Configuration

These commands allow viewing and configuration of the NAS Users and groups accounts.

Note: Known Issue: As iTX software supports enabling of ADS and NIS simultaneously, the user/group

list retrieved will be given for both instead of singly.

Command Argument Description

add ug -t/--type {user}

-u/--username <user name>

-i/--id <userid (optional)>

-p/--passwd <password(optional)>

-f/--fullname <Full name>

-x/--xml

For example: add –t user –u user1 –p password –f “User 1” ug

add ug -t/--type {group}

-g/--groupname <group name>

-i/--id <group id (optional)>

-x/--xml delete ug -t/--type {user}

-u/--username <username>

-x/--xml get ug -t/--type {user/group}

-s/--section {local/ads/nis/all}

-c/--count

-x/--xml

For example: get -t user -i -u test1 ug

list ug -t/--type {user/group}

-s/--section (local/ads/nis/all)

-x/--xml

For example: list -t user -s all ug

get ug -t/--type {group}

-i/--info

-g/--groupname <groupname>

-x/--xml

For example: get –t group –I –g groupA ug

get ug -t/--type {user}

-i/--info

-u/--username <username>

-x/--xml set ug -t/--type { user}

-u/--username <username>

-p/--passwd <password>

-f/--fullname <fullname>

-x/--xml

For exmaple: set -t user -u test1 -p test1 -f test1 ug

list ug -t/--type {group}

-g/--groupname <groupname>

-x/--xml delete ug -t/--type {group}

-g/--groupname <groupname>

-x/--xml delete ug -t/--type {group}

-g/--groupname <groupname>

-u/--username <username>

-x/--xml

For example: cli delete –t group –g groupA –u user1 ug

Adds a user. If password is not entered in command line, it will be prompted for. Username is case-sensitive, must be alphanumeric, and 8 -32 characters .

Adds a group. Group name is casesensitive, must be alphanumeric, and 8 -32 characters.

Deletes the given user.

Displays the count of users / groups of specified type.

Displays the specified list of users / groups and their info.

Displays the group info.

Displays the specified user’s info.

Changes the user info to given values for password and/or full name.

Displays the users present in a particular group.

Deletes the given group.

Deletes the given user from the specified group.

Chapter Two: Command Set 19

set ug -t/--type {group}

-g/--groupname <groupname>

-u/--username <username>

-x/--xml

Adds the given user to the specified group. Multiple users can be added using –u/--username switch. (maximum of 8 users at a time)

Protocol Configuration

These commands configure the various network protocols supported.

Command Argument Description

get protocol -t/--type {cifs/nfs/http/snmp/nis/ads/https/ftp/upnp} Gets the status of cifs, nfs, http,

snmp, nis, or ads protocols.

set protocol -t/--type

{cifs/nfs/apple/http/snmp/nis/ads/https/ftp/upnp}

-d/--disable or

-e/--enable

-x/--xml

For example: set –t cifs –e protocol

get protocol -t /--type {snmp}

-n/--communityname

For example: get –t snmp –n protocol

get protocol -t/--type {cifs}

-w/--winserver set protocol -t/--type {cifs}

-s/--winsserver <winsserver name>

-m/--mtype {wg/nt/ads}

-w/--workgroup <workgroupname>

-x/--xml set protocol -t/--type {snmp}

-n/--communityname <communityname>

set protocol -t/--type {nfs}

-i/--ipaddress <ipaddress or “world” >

-d/--disable or

-e/--enable

-x/--xml

For example: set -t nfs -i 10.0.0.124 -i 10.0.0.123 -e -x protocol

list protocol Lists all the protocols and

get protocol -t/--type {nfs}

-c/--count

Enables or Disables the specified protocol.

Gets the community name for snmp.

Gets the Wins server address.

Sets the Wins server address.

Sets the snmp community name By default, the public community name is supported. Sets the nfs clients.

whether they are enabled or disabled. Gets the number of NFS clients that have access to NAS shares.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

RAID & Disk Management Commands

These commands allow management of disks and RAID creation. For Hardware RAID please enter the Slotindex (For example: 1, 2,3, and so on) instead of diskname (For example: /dev/sda, /dev/sdb) in the option for -d / --diskname <DiskInfo_OSName or slotindex>

Command Argument Description

get raid -t/--type {pd/ld/controller}

-c/--count

get raid -t/--type {controller}

-a/--alarm

-n <controllerno> list raid -t/--type {pd/ld/controller}

list raid -t/--type {pd/enclosure}

-n <controllerno>

list raid -t/--type {spare}

get raid -t/--type {pd}

-i/--info

-n/--controllerno <controller number>

-d / --diskname <Diskname or slotindex> get raid -t/--type {pd}

-d/--diskname <diskname or slotindex>

-n <ControllerNo>

-m/--cachemode

For example: get –t pd –d 1 –n 0 –m raid

get raid -t/--type {ld}

-l/--ldname < Logical_Osname>

-m/ --cachemode rebuild raid -d/--diskname <diskname or slotindex>

-l/–ldname <ldname> create raid -t/--type {ld}

-s/ --disksize <disksize optional in GB>

-p/--stripesize <stripe size 64 KB>

-d / --diskname <diskname or slotindex>

-a/--sparediskname <sparediskname> (optional)

-e/--distspare <distributedspare> (optional)

-r / --raidlevel <raid

level(0/1/3/5/6/10/1N/10N/50/60) >

-m/--cachemode <cachemode>

-b/--subdisk <subdiskcount>

-n/--controllerno <controllerno>

For example: cli create -t ld -p 64 -d 1:5 -d 1:6 -r 0 -m WriteThrough:ReadAhead:Cached -n 0 raid

delete raid -t/--type {ld}

-l / --ldname <drivename>

For example: delete –t ld –l /dev/md1 raid (1U) For example: delete –t ld –l /dev/sdb raid (3U)

Displays the number of disks, logical drives and controllers respectively. Displays the alarm mode and battery status of controllers respectively. Displays the list of logical drives and controllers respectively. Displays the list of physical drives and enclosures for controller respectively. Displays the list of spare disks.

Displays the information about specified disk.

Gets the physical disk cache mode.

Gets the logical drive cache setting.

Rebuilds a logical drive with the specified disk drive. Creates a logical drive.

-s/ --disksize – only supported for 3U

For LSI RAID Controller - Cache Modes Format writecache:readcache:cachemode

writecache values - WriteThrough / WriteBack / ForceWriteBack

readcache values ReadAheadNone / ReadAhead / ReadAdaptive

cachemode values - Direct / Cached

-p/ --stripesize – only 64 kb supported for 3U

Minimum LD size: 10 GB Deletes specified logical drive.

Chapter Two: Command Set 21

Command Argument Description

expand raid -t/--type {ld}

-l/ -- ldname <ldname >

-d/ --diskname <diskname or slotindex(optional)>

Expands the logical drive to specified disksize using specified disk.

-s/--disksize <disksize in GB>

-b/--subdisk <subdiskcount (Required only for

RAID10N and RAID50)>

-e/--distspare

-n/--controllerno <controllerno (Required only for

LSI RAID controller) For example: expand -t ld -l /dev/sdb -d 2 -s 20 raid

transform raid -t/--type {ld}

Transforms a logical drive.

-l / --ldname <ldname>

-d / --diskname <diskname or slotindex >

-r/ --raidlevel

-s/--size <size (optional)> (enter ss for same size)

-b/--subdisk <subdiskcount (Required only for

RAID10N and RAID50)>

-e/--distspare

-n/--controllerno <controllerno (Required only for

LSI RAID controller) For example: transform -t ld -l /dev/md0 -r 5 -d /dev/sda -d /dev/sdb raid

blink raid -t/--type {ld/pd}

-d / --diskname<diskname or slotindex>

Blinks a disk (not supported on a 1U yet).

-n/--controllerno <controllerno>

For example: blink –t pd –l /dev/sda –n 0 raid

blink raid -t/--type {ld/pd}

-l / --ldname <ldname> set raid -t/--type {pd}

-d / --diskname<diskname or slotindex>

-m / --cachemode

< diskcache mode>

-n/--controllerno <controllerno>

Cache Modes - pd 0 - None 1 - Read 2 - Read-Write 3 - Read-Ahead 4 - Read-Ahead-Write For example: set –t pd –d 2 –m 1 –n 0 raid

Blinks a logical drive (not supported on a 1U yet). Sets the cache mode for disk (HW RAID only).

For LSI RAID Controller - Cache Modes Format writecache:readcache:cachemode

writecache values - WriteThrough / WriteBack / ForceWriteBack

readcache values ReadAheadNone / ReadAhead / ReadAdaptive

cachemode values - Direct / Cached

set raid -t/--type {pd}

-d / --diskname<diskname or slotindex>

-g/--makegood

-n/--controllerno <controllerno>

-x/--xml

For example: set -t pd -d 1:2 -g -n 0 raid

set raid -t/--type {controller}

Sets the alarm mode for controller

-n/--controllerno<controller no>

-a / --alarmmode <alarm mode>

Alarm Modes - controller 0 - NP 1 - Enable 2 - Disable 3 - Mute 4 - UnMute

set raid -t/--type {ld} Set the cache mode for LD

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Command Argument Description

-l / --ldname <ldname>

-m/--cachemode <cache mode>

Cache Modes - ld 0 - None 1 - Read 2 - Write 3 - Read-Write

rescan raid -n/--controllerno <controller number>

remove raid -t/--type {spare}

-d / --diskname <diskname or slotindex>

Initiates rescanning of the storage bus connected to the controller. Removes a drive assigned as a spare disk or dedicated disk.

-l/ --ldname <ldname> (for dedicated spare)

-n/--controllerno <controllerno>

For example: remove -t spare -d 3 -n 0 raid remove -t spare -l /dev/md0 -d /dev/sdb raid

add raid -t/--type {spare}

-d / --diskname or slotindex or

Adds the given drive as a global or

dedicated hot spare. enclosurenumber:slotindexl/--ldname <ldname>(for dedicated spare)

-n/--controllerno <controllerno> For example: add -t spare -d 1:4 -n 0 raid

upgrade raid -t/--type {controller}

-n/--controllerno <controller number>

Upgrades the firmware for

controller.

-o /--code <code>

-l/ --length <length>

upgrade raid -t/--type {pd}

-d / --diskname <diskname or slotindex>

Upgrades the firmware for a

physical disk.

-n/--controllerno <controller number>

-o /--code <code>

-l/ --length <length>

Chapter Two: Command Set 23

Share, Directory & ACL Configuration

These commands work on NAS shares and directory.

Command Argument Description

create dir -p/--path <directory path>

-x/--xml For example: create –p c0_nas0/new dir

list dir -p/--path <directory path>

-x/--xml

delete dir -p/--path <directory path>

-f/--force (optional)

-x/--xml

list share Displays all shares and details of

get share -t/--type {share}

-c/--count

-x/--xml

get share -t/--type {share}

-i/--info

-p/--path < path of the share >

-x/--xml

get share -t/--type {acl}

-p/--path < path of the share >

-x/--xml

add share -n/--name <name of the share >

-p/--path <path to be added>

- s/--prototype {cifs/nfs/upnp/apple/http/ftp}

-x/--xml For example: add –n share0 –p c0_nas0/new –s cifs –s ftp share

delete share -t/--type {share}

-n/--name <name of the share >

-x/--xml For example: delete -t share –n share1 share

delete share -t/--type {acl}

-p <directory path>

-u/--username <username> or -g/--groupname <groupname>

-x/--xml For example: delete -t acl -p c0_v0/test1 -u test1 share

set share -t/--type {acl}

-x/--xml

-p/--path <directory path>

-m/--mode <USERNAME:MODE{user/group}:PERMISSION S:INHERITANCE:ALLOW:LEVEL>

-e/--enable or -d/--disable

-v/--voltype (0 for NT 1 for posix)

-i/--inherited (0 to not inherit 1 otherwise)share

For example:

m user1:user:agf:3:1:0 -m user2:user:agh:5:0:0 -m group1:group:gd:3:1:1 -e -v 1 -i 0 share

set -t acl -p Cont0_Volume0/dir1 -

Creates a subdirectory with the

given complete path.

Displays all directories in the

volume.

Deletes a subdirectory with the

given complete path. The complete

path should also include the

volume path exported by the

system. The subdirectory should be

empty before deletion.

Note: the parent directory cannot

be deleted For example: c0_nas0

each.

Gets the number of shares.

Gets the share information

according to the path given.

Gets the acl permissions of a share.

Adds specified share to the system.

Note: Please make sure a directory

with the same path is made before

creating a share

Deletes a share from the system.

Deletes a acl share from the

system.

Sets the acl permission of the share

(maximum of 4 ACL permissions

can be entered at a time. And 237

acl permissions maximum per

share).

The -e/-d option is to enable or

disable ACL recursively for the

root folder and sub folders

ALLOW FOR NT

0 - Allow ACE 1 - Deny ACE

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

set share -t/--type {share}

-n/--name <name of the share>

-p/--path <path of the share>

-s/--prototype <cifs/nfs/upnp/apple/http/ftp>

-x/--xml For example: set -t share -n test1 -p Container0_Volume0/dir1 -s cifs -s http -s upnp share

LEVEL FOR NT

0 - Apply to all levels 1 – Apply

to first level

PERMISSIONS FOR POSIX

0 - Read Write 1 - Read Only

2 - Deny

PERMISSIONS FOR NT : The 14

bits in following order

A - Traverse Folder / Execute file

B - List Folder / Read Data

C - Read Attributes

D - Read Extended Attributes

E - Create files/ Write Data

F - Create folders / Append Data

G - Write Attributes

H - Write Extended Attributes

I - Delete Subfolders and files

J - Delete

K - Read Permissions

L - Change Permissions

m - Take Ownership

INHERITANCE FOR NT

0 - No inheritance

1 - this folder sub folders and files

2 - this folder and sub folders

3 - this folder and files

4 - subfolders and files only

5 - subfolders only

6 - files only

Sets a share properties.

Chapter Two: Command Set 25

System Control Configuration

These commands configure the System controls.

Command Argument Description

shutdown system For example: shutdown system Shuts the system down. get system

set system -f/--fansensors <on/off>

reboot system Reboots the system.

For example:

-t/--tempsensors <on/off>

-x/--xml

cli get -x system

Gets the auto shutdown

information.

Sets the fan sensors or temperature

sensors on or off for autoshutdown

(only temperature supported at this

release).

Volume and Snapshot Commands

These commands manage the way Containers, Volumes and Snapshots are created, or expanded. While some of these commands are specific to either NAS or iSCSI volumes, most will work in both types of volumes.

Command Argument Description

create volume -t/--type {container}

-c/--containername<containername>

-k/--chunksize< {64} in KB>

-l/--ldname<logical device name> .....

For example: create –t container –c c0 –k 64 –l /dev/md2 volume (1U) For example: create –t container –c c0 –k 64 –l /dev/sdb volume (3U)

create volume -t/--type { volume }

-c/--containername <containername>

-v/--volumename <volumename>

-z/--volumesize <volumesize in GB>

-k/-- <chunksize {64 or 8} in KB }><volumesize>

-p/--provisiontype< provisiontype {0/1/2} >

-e/--volumetype <volumetype {0} >

-f/--voldialect <volumedialect {0/1} >

For example:

AutoNas -k 64 -z 20 -e 0 -p 2 -f 1 volume

create volume -t/--type {snap}

-c/--containername <containername>

-v/--volumename <volumename>

-s/--snapname <snapname> For example: create –t snap –c c0 –v v0 –s snap00 volume

create volume -t/--type {snap}

-c/--containername <containername>

-v/--volumename <volumename>

-s/--snapname <snapname>

-w/--writablesnapname<writablesnapname > For example: create –t snap –c c0 –v v0 –s snap00 –w wsnap00 volume

create volume -t/--type { snap }

-c/--containername <containername>

-v/--volumename <volumename>

-s/--snapname <snapname>

-R/--remotesnap

create -t volume -c Cont0 -v

Creates a container.

Note:

The chunk size should be 64K

The device name should be in the

form /dev/mdx or /dev/sdx where x

can be 0,1,2,3…

Creates a Volume.

Note:

1)volumetype ([0]-ROW

2) voldialect ([[0]-ISCSI [1]-NAS)

3)provisiontype ([0]-Thin [1]-

Exact

2 – Auto(Nas Only)

As a best practice measure, it is

recommended that 20% of

container capacity be reserved (left

free) for snapshots.

Creates a read-only Snapshot.

Note: A total of 254 read-only

Snapshot can be created per

volume. And the total number of

snapshots (read-only + writable) is

992 per iTX device.

Creates a writable Snapshot over a

read-only snapshot.

Note: A total of 254 writable

Snapshot can be created per

volume. But the total number of

snapshots (read-only + writable)

should be 992 per iTX device.

Creates a snapshot on the local

target as well as the remote target if

the volume is replication enabled.

If only –R is given, only the remote

snapshot is created. If only –L is

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Command Argument Description

-L/--localsnap used, then only the local snapshot

will be created.

By default, without the switches –L

and –R, it will create the local

snapshot only.

delete volume -t/--type {container}

-c/--containername<containername>

-f/--force (optional)

Deletes the container.

-r/ option deletes all volumes

within the container recursively.

-r/--recursive (optional)

delete volume -t/--type {volume}

Deletes the specified Volume.

-c/ --containername <containername>

-v/ --volumename <volumename>

-f/--force (optional)

delete volume -t/--type {snap}

Deletes the specified Snapshot.

-c/ --containername <containername>

-v/ --volumename <volumename>

-s/ --snapname <snapname>

-f/--force (optional)

delete volume -t/--type {snap}

-c/ --containername <containername>

-v/ --volumename <volumename>

-s/ --snapname <snapname>

-L/--localsnap

-R/--remotesnap

-f/--force (optional) For example: delete –t snap –c c0 –v v0 –s snap00 –L –R –f volume

delete volume -t/--type {volume}

-c/ --containername <containername>

Deletes the Snapshot on the local

target as well as the remote target if

the volume is replication enabled.

If –R is given, only the remote

snapshot is deleted. If –L is used,

only the local snapshot will be

deleted. By default, without the

switches –L and –R, it will delete

the local snapshot.

Deletes all the volumes within that

container.

-a/--all

-f/--force (optional)

delete volume -t/--type {snap}

-c/ --containername <containername>

Deletes all Snapshots for that

volume.

-v/ --volumename <volumename>

-a/--all

-f/--force (optional)

expand volume -t/--type {container}

-c/--containername <containername>

-l/--ldname<logical device name> For example: expand –t container –c c0 –l /dev/sdc

Expands Container by adding the

specified LD to it.

Logical Device name eg;/dev/md0

Use:–l option volume

expand volume -t/--type {volume}

Expands Volume.

-c/--containername <containername>

-v/--volumename <volumename>

-z/-- capacity new volume size (in GB) For example: expand –t volume –c c0 –v v0 –z 300 volume

list volume -t/--type {container/volume/snap }

For example: list –t snap volume

List all the

Containers, Volumes, or Snapshots

in system.

list volume -t/--type {volume}

-c/--containername <containername>

list volume -t/--type { snap}

-c/--containername <containername>

-v/--volumename <volumename>

get volume -t/--type {container }

-i/ --info

List the details for all the

Volumes in specified container.

List the details about

SnapShots in specified volume and

container.

Gets the information about the

specified Container.

-c /--containername <containername>

get volume -t/--type {volume}

-i/--info

Gets the information about the

specified Volume.

Chapter Two: Command Set 27

Command Argument Description

-c/ --containername <containername>

-v/--volumename <volumename>

get volume -t/--type {snap}

-c/--containername <containername>

-v/--volumename <volumename>

-u/--schedule

get volume -t/--type { snap}

-i/--info

-c/--containername <containername>

-v/--volumename <volumename>

-s/--snapname <snapname> For example: get –t snap –i –c c0 –v v0 –s snap00 volume

get volume -t/--type {container}

-n /-- count

activate volume -t/--snap {snap}

-c/--containername <containername>

-v/--volumename <volumename>

-s/--snapname <snapname>

-w/--writeable(optional) For example: activate -t snap -c Cont0 -v Volume0

-s Volume0WriteableSnap0 -w volume

deactivate volume -t/--snap {snap}

-c/--containername<containername>

-v/--volumename <volumename>

-s/ --snapname <snapname>

rollback volume -t/--snap {snap}

-c/--containername<containername>

-v/--volumename <volumename>

-s/--snapname <snapname>

freeze volume -t/--type {container/volume/snap} Freezes the UVM

set volume -t/--type {snap}

-u/--schedule

-c/--containername<containername>

-v/--volumename <volumename>

-s/-schedulesnap <scheduleduration:maxsnapshots>

-d/--description <description>

-n/--backtargetname <backuptargetname >

-p/--scheduleType 0-Windows,1-Local [default:Windows] volume For example: set -t snap -c Cont0 -v Volume0ISCSILUN0 -s 5:10 -s 60:20 -d testing -n backuptest -p 0 volume

Gets the snapshot schedule settings

for the specified volume.

Gets the information about the

specified Snapshot.

Gets the number of containers in

system.

Activates writeable Snapshot.

Deactivates the Snapshot.

Rolls back the Snapshot. Requires

disconnecting and stopping of all

I/Os.

Container/volume/snap.

Note: Yet to be implemented.

Set the Snapshot Schedule.

Note: maximum number of read

only snapshots (read-only +

writable) is 254 per volume for a

total of 992 per system.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

UPS Configuration

These commands configure the UPS for power management.

Command Argument Description

get UPS -i/--info

-x/--xml

get UPS -i/--info

-m/--monitor

-x/--xml

set UPS -d/--disable

-x/--xml

set UPS -e/--enable or

-d/--disable

-b/--battery <min battery value>

-t/--timeout <mins>

-m/--mode {1}

-x/--xml For example: set –e –b 10 –t 3 –m 1 ups

set UPS -e/--enable or

d/--disable

-b/--battery <min battery value>

-t/--timeout <mins>

-m/--mode {2}

-i/--masterip <{HostName/Master Ip>

-x/--xml

For example: set -e -b 35 -t 300 -m 2 -i 10.0.0.218 ups

config UPS -i/--info

-x/--xml

config UPS -l/--list

-x/--xml

config UPS -d/--driver <num>

-p/--port <value>

-x/--xml For example: config –d 2 –p 1 ups

Displays the existing UPS

configuration.

Display the monitoring

configuration for the configured

UPS devices.

Disables automatic shutdown.

Sets the UPS configuration to

given values. The enable mode is

to denote the shutdown option.

Timeout should be given in

minutes. Battery is the minimum

battery value below which the

shutdown is triggered Mode checks

whether it set to master or slave.

Note:

Minimum Battery value should be

between 0 and 100 %

Timeout value should be between

0 and 1000 minutes

Sets the UPS configuration to

given values. The battery value

indicates the minimum battery

value at which the alert has to be

generated. Timeout should be

given in minutes. Mode is set to

slave and the masterip is IP

Address of the master.

Note:

Minimum Battery value should be

between 0 and 100

Timeout value should be between

0 and 1000

Displays currently configured

driver for UPS monitoring.

Displays list of available drivers.

Sets driver to use with UPS

monitoring.

Driver number is from list obtained

from –list command.

Port value:

1 – COM1

2 – COM2

u - USB

Chapter Two: Command Set 29

Synchronous replication

These commands configure synchronous replication and High Availability using Windows DSM (iTX 2.7v 2.x).

Command Argument Description

create syncreplica –l/--local < cont_vol_name>

-r/--remote < cont_vol_name>

-p/--priority <resync priority>

-i/--localhost <primary's IP address>

-m/--remotehost <rem host name>

-d/--mode [sync | ha] Example: replication in local volumes create -l c0_v0 -r c1_v1 -p 50 -i 172.16.70.70 -d sync -m local syncreplica

Example: HA in remote volumes create -l c0_v0 -r c1_v1 -p 50 -i 172.16.70.70 -m

172.16.70.102 –d ha syncreplica

update syncreplica –l/--local < cont_vol_name>

-p/--priority <resync priority>

-m/--remotehost <rem host name>

-x/--xmlflag <xml flag>

For example: update -l c0_v0 -p 50 -m

172.16.70.102 -x syncreplica

get syncreplica -l/--local <local-primary cont_vol_name>

For example: get –l c0_v0 syncreplica

list syncreplica -c/--container <container name>

For example: list –c c0 syncreplica

delete syncreplica -l/--local < cont_vol_name >

-f/--force (optional)

split syncreplica -l/--local <local-primary cont_vol_name> Temporarily stops replication of

join syncreplica -l/--local <cont_vol_name> Manually joins or resync the

perform syncreplica -t/--type {failover}

-l/--local <cont_vol_name>

perform syncreplica -t/--type {failback}

-l/--local <cont_vol_name> For example: perform –t failback –l c0_v0 syncreplica

Creates a replication pair. Both the

primary and secondary volumes

should be present before this

operation.

For local volume copy, please enter

remote host as “local”. All other

parameters remain same. Default

resync priority is zero.

Specify sync for –d/--mode option

to create a synchronous replication

pair; specify ha for –d/--mode

option to create an high-availability

pair.

NOTE: management target name

for SR is the name of the virtual

target, as opposed to mtarget in

earlier versions (2.5/2.6).

Updates the given parameters of

the volpair in DDF and in module.

Displays the replication details as

available from DDF as well as

runtime.

Lists available replication pairs in

the given container.

Deletes the given synchronous

replication pair. Note : Use --force

to clean up non-operational pair

locally.

the replication pair. But at a later

time, the replication can be joined

to replicate from the place where it

stopped.

replication on the given

consistency group that was split

earlier. Also, this command should

be used to initiate a failback

resync.

Initiates failover on the given

consistency group. This command

has to be given in the secondary

target. All further I/Os will be

fielded by the secondary from now

on.

This will reinstate the initial

primary to start fielding I/Os after a

successful failback. Resync has to

be completed before activating the

failback.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

High Availability (iTX27 v3.x and up ) These commands configure High Availability which is OS Agnostic

Command Argument Description

syncparams syncreplica

managerg syncreplica -t/--type <action{create/delete/get/editalias/

create syncreplica –l/--local < cont_vol_name>

update syncreplica –l/--local < cont_vol_name>

-r/--remoteip < remote ipaddress >

-x/--xmlflag

For example:

syncparams -r 172.16.70.148 syncreplica

removealias/addalias/changeowner/forcetakeover}>

-n/--rgname <resource group name>

-a/--alias <Alias>

-r/--remoteip <remote ipaddress>

-v/--vipaddress <Virtual iapddress>

-l/--local <localipaddress>

-f/--force

-x/--xmlflag

For example:

managerg -t create -n rg0 -a Alias-1 -a Alias-2 -r

172.16.70.146 -l 172.16.70.176 syncreplica managerg -t get syncreplica managerg -t delete -n rg0 syncreplica managerg -t editalias -n rg0 -v 172.16.70.10 -a Alias-1 syncreplica managerg -t addalias -n rg0 -a Alias-2 syncreplica managerg -t removealias -n rg0 -a Alias-2 syncreplica managerg -t changeowner -n rg0 syncreplica managerg -t forcetakeover -n rg0 syncreplica

-r/--remote < cont_vol_name>

-p/--priority <resync priority>

-i/--localhost <primary's IP address>

-m/--remotehost <rem host name>

-d/--mode [hanodsm]

-g/--rgname <resource group name>

Example: HA NO DSM replication in remote volumes

create -l c0_v0 -r c1_v1 -p 50 -i 172.16.70.70 -d hanodsm -m 172.16.70.1 02 -t iqn.1991-

10.com.ami:itx00c09f2164459104:virtual -g rg0 syncreplica

-p/--priority <resync priority>

-m/--remotehost <rem host name>

Syncparams is used to sync the

iscsi base target names/date and

time between local and remote

machines before creating an HA

pair.

This command has to be executed

in the Primary machine before

creating the first RG between two

iTX machine.

Managerg command is used to

manage and configure Resource

Group. Action denotes the

operation to be perfomed on the

This command is also used to

add/remove/edit virtual IP

configured for a specific RG.

Note: Atleast one VIP should be

present for an RG.

This command is also used the

change the original ownership of

an RG.

--forcetakeover option can be used

to takeover the RG forcefully if the

RG is in an inconsistent state but

this may result in data corruption.

--force option is used to delete an

non operational RG forcefully if

remote is dead.

Creates a replication pair. Both the

primary and secondary volumes

should be present before this

operation.

Default resync priority is 25.

Specify sync for –d/--mode option

to create a synchronous replication

pair; specify hanodsm for –d/--

mode option to create an high-

availability pair.

Updates the given parameters of

the volpair in DDF and in module.

Chapter Two: Command Set 31

Command Argument Description

-g/--rgname <rgname>

-x/--xmlflag <xml flag>

For example: update -l c0_v0 -p 50 -m 172.16.70.102 -x syncreplica

Update command is used to move a

replication volume pair from

Resource group to another.

-g stands for the destination rg

name.

update -l c0_v0 -g rg0 syncreplica

get syncreplica -l/--local <local-primary cont_vol_name>

-r/--rginfo

-o/--owner

For example: get –l c0_v0 syncreplica get -r syncreplica get -o syncreplica

list syncreplica -c/--container <container name>

-r/--group For example: list –c c0 syncreplica list -r syncreplica

delete syncreplica -l/--local < cont_vol_name >

-f/--force (optional)

For Example: delete -l c0_v0 syncreplica delete -l c0_v0 -f syncreplica delete -l c0_v0 -l c1_v2 -l c1_v2 -f syncreplica

split syncreplica -l/--local <local-primary cont_vol_name>

-g/--rgname <resource group name>

For Example: split -l c0_v0 syncreplica split -g rg0 syncreplica

join syncreplica -l/--local <cont_vol_name>

-g/--rgname <resource group name>

For Example: join -l c0_v0 syncreplica join -g rg0 syncreplica

convert syncreplica convert -c/--container <container_name> -v/--

volume <volume_name> -g/--rg <resource_group>

For Example: convert -c c0 -v v0 -g rg0 syncreplica

Displays information about

Resource Group.

This command can be used both in

Primary & Secondary storage

systems.

It Displays the replication details as

available from DDF as well as

runtime.

Lists available replication pairs in

the given container.

It can be used to display the details

about the resource group

configured in the system and the

corresponding replication pairs.

Deletes the given synchronous

replication pair. Note: Use --force

to clean up non-operational pair

locally.

Multiple pairs (up to 64) can be

deleted at the same time by using -l

repeatedly.

Temporarily stops replication of

the replication pair. But at a later

time, the replication can be joined

to replicate from the place where it

stopped.

This command can used to stop all

the replication pairs part of the RG

Manually joins or resync the

replication on the given

consistency group that was split

earlier. Also, this command should

be used to initiate a failback

resync.

This can be used to rejoin all the

volume replication pairs part of the

RG by specigying the RG name.

This command is used to convert a

synchronous replication pair to

operate in a High Availability

mode.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Asynchronous Replication

These commands configure asynchronous replication.

Command Argument Description

create asyncreplica -t/--type <sar/jar/hasar>

-n/--name <snap assisted replication name>

-f/--volumedialect

-a/--primarycontainer <primary contName>

-l/--primaryvolume <primary volName>

-i/--primaryip <primary host IP address>

-s/--secondarycontainer <secondary contName>

-r/--secondaryvolume <secondary volName>

-m/--secondaryip <secondary host IP>

-k/--hasecondaryip <HA secondary host IP> (Only for HA-DR)

-z/--secsnapcount <secondary snap count>

-c/--compression <zlib compression level>(optional)

-e/--encryption (optional)

-b/--dedup (optional)

-w/--wds <bandwidth in mbps> (optional)

-u/--utilization <bandwidth utilization in percentage>

Example: Single volume in CG create -t sar -n name -f 1 -a c0 -l v0 -i

172.16.70.70 -s c1 -r v1 -m 172.16.70.153 -c 6 -z 10 -e asyncreplica

Example: Multiple volumes in CG create –t sar –n name -f 0 –a c0 -l v0 -l v1 -l v2

-i 172.16.70.70 –s c1 -r v0 –r v1 -r v2 -m

172.16.70.153 -153 -c 6 -z 10 -e asyncreplica

delete asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-f/--force(optional)

Example: delete -n name -c c0 -d 1 asyncreplica delete -n name -c c0 –d 1 -f asyncreplica

get asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name> (optional)

-s/--compressionstats (optional)

Example: get -n name -c c0 -d 1 asyncreplica

list asyncreplica -c/--containername <container name>

(optional only if wds enabled)

Creates a asynchronous replication

pair. Both the primary and

secondary volumes should be

present before this operation.

Note:

1) Volume Dialect

[0] - ISCSI

[1] – NAS

2) Compression Type

[0] – No compression

[1 - 9] – levels

secsnapcount can take values

between 1 to 1022

WDS mode is used only in Snap

Assisted Replication and HA-DR

5) This command can be issued

only in the storage system that will

be the Primary.

6) HA-DR (hasar) option can be

used only after HA is established

across all volumes of the DAR

(DR) group.

7) The HA secondary host IP is the

WAN IP of the HA pair which can

be reached from the SAR (DR)

secondary system.

Deletes the asynchronous

replication pair

-f/--force flag is optional and is

used where asynchronous

replication has to be deleted

forcefully

This command can be issued only

in the storage system that will be

the Primary.

Displays the asynchronous

replication details.

This command can be issued on

both Primary and Secondary

storage systems.

Lists available asynchronous

replication pairs in the given

Chapter Two: Command Set 33

Command Argument Description

Example: list -c c0 asyncreplica

container.

This command can be issued on

both Primary and Secondary

storage systems.

list asyncreplica -c/--containername <container name>

-n/--name <asynchronous replication name>

Example: list -n name -c c0 asyncreplica

pause asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

Example: pause -n name -c c0 –d 1 asyncreplica

Lists all the common snapshots (of

all volumes) in the asynchronous

replication pairs in the given

container.

This command can be issued on

both Primary and Secondary

storage systems.

Pauses the Asynchronous

replication until it is resumed by

resume cli.

This command can be issued in a

primary.

This command can be issued only

when the Asynchronous replication

has one of the following status

1. Paused

2. Idle

3. Active

4. Undefined

For all other status, this command

would return error.

resume asyncreplica

-n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

Example: resume -n name -c c0 –d 1 asyncreplica

Resumes the Asynchronous

replication that was paused before.

This command can be issued in a

primary.

This command can be issued only

when the Asynchronous replication

has one of the following status

1. Paused

For all other status, this command

would return error.

failover asyncreplica

-n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

Example:

Fails over the Asynchronous

replication to the secondary.

This command can be issued only

in the secondary. failover -n name -c c0 –d 1 asyncreplica

failbackjoin asyncreplica

-n/--name <asynchronous name>

-c/--containername <container name>

-d/--index <system assigned name>

Example: failbackjoin -n name -c c0 –d 1 asyncreplica

Prepares the original primary of the

Asynchronous replication for

failback.

This command can be issued only

in the primary.

failback asyncreplica -n/--name <asynchronous replication name> Fails back the Asynchronous

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Command Argument Description

-c/--containername <container name>

-d/--index <system assigned name>

Example: failback -n name -c c0 –d 1 asyncreplica

replication to the original primary.

This command can be issued only

in the original primary acting as a

secondary.

rollbackjoin asyncreplica

-n/--name <asynchronous replication name>

-c/--containername <container name>

-s/--snapgrouptnum <t number>

-d/--index <system assigned name>

Example: rollback -n name -c c0 –s 30 –d 1 asyncreplica

If the status is

FAILED_DUE_TO_ROLLBACK

after a Rollback on Primary, the

replication will continue after

issuing this command on the

primary to make the secondary

ready for resuming replication.

This command can be issued in a

primary.

rollback asyncreplica

-n/--name <asynchronous replication name>

-c/--containername <container name>

-s/--snapgrouptnum <t number>

-d/--index <system assigned name>

Example:

Rolls back all the volumes of the

Asynchronous replication to a

particular set of snapshots.

This command can be issued in a

primary and/or secondary. rollback -n name -c c0 –s 30 –d 1 asyncreplica

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-i/--primaryip <primary host IP address>

-m/--secondaryip <secondary host IP>

-k/--hasecondaryip <HA secondary host IP>

-t/--primarymgmttgt <primary management target name>

-z/--secsnapcount <secondary snap count>

-u/--secondarymgmttgt <secondary management target name>

-g/--wds <wds {0/1}>

-w/--bwutilization <bandwidth utilization in percentage>

Update ‘priority’, ‘compression’,

‘primaryip, ‘secondaryip’,

‘hasecondaryip’

“primarymgmttgt”,

“secondarymgmttgt” fields.

Note:

1) Compression type

[0] - NO compression

[1-9] – Compression Levels

This command can be issued in a

primary.

-b/--bandwidth <bandwidth in mbps>

-f/--dedupe <deduplication {0/1}>

-y/--encryption <encryption {0/1}>

-o/--compression <compression level {0..9}>

Example: update -n myname -d 1 -c Cont0 -o 2 –I

172.16.70.89 -m 172.16.70.90

-u iqn.1991-

10.com.ami:itx00c09f2164459105:mtarget

-t iqn.1991-

10.com.ami:itx00c09f2164459108:mtarget

-z 10 asyncreplica

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-f/--dedupe <deduplication {0/1}>

Update ‘deduplication’ field alone.

This command can be issued in a

primary.

Example: update -n myname -d 1 -c Cont0 -f 1 asyncreplica

Chapter Two: Command Set 35

Command Argument Description

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-z/--secsnapcount <secondary snap count> Example: update -n myname -d 1 -c Cont0 -z 200 asyncreplica

Update ‘secondary snap count’

field alone.

secsnapcount takes value between

1-1022

This command can be issued in a

primary.

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-w/--bwutilization <bandwidth utilization in percentage>

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-b/--bandwidth <bandwidth in mbps>

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-o/--compression {0-9}

Update ‘bandwidth utilization’

field alone.

This command can be issued in a

primary.

Update ‘bandwidth’ field alone.

This command can be issued in a

primary.

Update ‘compression’ field alone.

Note:

1) Compression type

[0] - NO compression

[1-9] – Compression Levels

This command can be issued in a

primary.

update asyncreplica -n/--name <asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-i/--primaryip <primary host IP address>

update asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-m/--secondaryip <secondary host IP>

update asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-k/--hasecondaryip <secondary host IP>

update asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-t/--primarymgmttgt <primary management target name>

update asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-u/--secondarymgmttgt <secondary management target name>

Update ‘primaryip’ field alone.

This command can be issued in a

primary.

Update ‘secondaryip’ field alone.

This command can be issued in a

primary.

Update ‘hasecondaryip’ field alone.

This command can be issued in a

primary of a HA-DR setup.

Update ‘primarymgmttgt’ field

alone.

This command can be issued in a

primary.

Update ‘secondarymgmttgt’ field

alone.

This command can be issued in a

primary.

add asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

Add periodicity information for a

particular Asynchronous

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Command Argument Description

-s/-- schedule>

-d/--index <system assigned name>

Example: add -n myname -c Cont0 -s "0-24 0-7" -d 1 asyncreplica

add -n myname -c Cont0 -s "* 0-7" -d 1 asyncreplica

add -n myname -c Cont0 -s "0-24 *" -d 1 asyncreplica

add -n myname -c Cont0 -s "* *" -d 1 asyncreplica

Replication.

Note :

1) The periodicity can be of one of

the following

a.“<start time>-<end time>

<start_day>-<end day>”

b.“<start time > <start_day>-<end

day>”

c.“<start time>-<end time>

<start_day>”

d.“<start time> <start_day>”

e.“ * *”

f.“ * <start_day>-<end day>”

g.“<start time>-<end time> *”

2) The ‘start time’ and ‘end time’

can take values from 0-24

representing the hour of the day

only.

3) The ‘start day’ and ‘end day’

can take values from 0-7

representing the day of the week

only.

4) ‘*’ indicates all hours of the day

or all days of the week based on its

position.

Note: The end_time and end_day

are not included. Meaning 15-16

means 1500-1559 Hours and 0-2

means Monday and Tuesday

5) A Maximum of 8 periodicity

information is allowed for

Asynchronous Replication pair

6) This command can be issued in

a primary.

remove asyncreplica

-n/--name < asynchronous replication name>

-c/--containername <container name>

-s/-- schedule>

-d/--index <system assigned name>

Example: remove -n myname -c Cont0 -s "0-24 0-7" -d 1 asyncreplica

remove -n myname -c Cont0 -s "* 0-7" -d 1 asyncreplica

Remove periodicity information for

a particular Asynchronous

Replication.

Note:

1) The periodicity format should be

same as above.

2) This command can be issued in

a primary.

remove -n myname -c Cont0 -s "0-24 *" -d 1 asyncreplica

remove -n myname -c Cont0 -s "* *" -d 1 asyncreplica

set asyncreplica -t/--type snap

-c/--containername <containername>

Sets the snapshot schedule for a

CG.

Chapter Two: Command Set 37

Command Argument Description

-n/--cgname <cgname>

-s/--schedulesnap <scheduleduration:maxsnapshots>

-d/--description <description>

-b/--backuptargetname <backuptargetname>

-p/--scheduleType <0-Windows,1-Local> Example: set -t snap -c Cont0 -n mysar0 -s 5:10 -s 60:20 -d testing -b backuptest -p 0 asyncreplica

enable asyncreplica -t hasar

-n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-i/--ip <other HA system IP>

update asyncreplica -n/--name < asynchronous replication name>

-c/--containername <container name>

-d/--index <system assigned name>

-i/--ip <other HA system IP>

Enables HA-DR with the HA pair

system. IP addres should be the

WAN IP of HA pair that can be

reached from DR.

This command can be issued in a

primary of a HA-DR setup. Should

be used when HA was setup on an

existing SAR group.

Removes the HA- DR setup on the

given IP. It must be the IP of the

HA pair. The HA pairing should

be removed after executing this

command.

This command can be issued in a

primary of a HA-DR setup.

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Journal Volume Management

These commands configure a journal and journal file.

create journal

delete journal

get journal

-t/--type journal

-j/--journalname <journalname>

-l/--ldname <ldname>

Example: create -t journal -j jour0 -l /dev/sdb journal

-t/--type journalfile

-j/--journalname <journalname>

-f/--journalfilename <journalfilename>

Example create -t journalfile -j jour0 -f jf0 -z 10 -c cont1 -v v1 -v v2 journal

-t/--type journal

-j/--journalname <journalname>

Example:

delete -t journal -j jour0 journal

-t/--type journalfile

-c/--containername <containername>

-f/--journalfilename <journalfilename>

Example:

delete -t journalfile -c cont0 -f jf0 journal

-t/--type journal

-j/--journalname <journalname

Example:

get -t journal -j Jour0 journal

-t/--type journalfile

-c/--containername <containername>

-f/--journalfilename <journalfilename>

Example: get -t journalfile -c Cont0 -f jf0 journal

-t/--type journalfile

-c/--containername <containername>

-v/--volumename <volumename>

Example: get -t journalfile -c Cont0 -v vol0 -v vol1 -v vol2 journal

-t/ --type snaptable

-c/--containername <containername>

-f/--journal/CG name <journal/CG name>

Example:

Creates journal.

Minimum LD size for journal creation is 10GB

Creates journal file.

1)Minimum LD size for journal creation is 10GB

Deletes journal

Deletes journal file

Gets journal information

Gets journal file information

Gets journal file name for a specific volume.

Gets information for a specific journal file snapshot.

Chapter Two: Command Set 39

list journal list journal list journal

creategroup journal

expand journal

set journal

get -t snaptable -c c0 -f cg0 -n 10 journal

-t/ --type journal List journal information.

-t/ --type journalfile

List journal file information.

-c/--containername <containername

-t/ --type snaptable

-c/--containername <containername>

List information for a specific journal file snapshot.

-f/--journal/CG name <journal/CG name>

Example: list -t snaptable -c containername -f cg0 journal

-t/--type snap

-s <contname:volumename:snapname>

-j <contname:journalfilename>

Creates group snapshot and post event to journal

-d <volume_dialect>

Example: creategroup -t snap -s c0:v0:Vsv0xxxxxxxxxxxxxxSchdL1RT -s c0:v1:VsvixxxxxxxxxxxxxxSchdL1RT -j c0:jf0 -j c0:jf1 -d 0 journal

-t/--type snap

-w <contname:volumename:snapname:writsnapname>

Creates group writeable snapshot and post event to journal

-d <volume_dialect>

Example: creategroup -t snap -w c0:v0:Vsv0xxxxxxxxxxxxxxSchdL1RT1:Vsv0xxx xxxxxxxxxxxSchdL1WT1 -w c0:v1:VsvixxxxxxxxxxxxxxSchdL1RT1:Vsvixxxx xxxxxxxxxxSchdL1WT1 -d 0 journal

-t/--type journal

-j/--journalname <journalname>

-l/--ldname <ldname>

Example:

Expands journal.

1) Minimum LD size for journal expansion is 10GB

expand -t journal -j jour0 -l /dev/sdc journal

-t/--type snap

-c/--containername <containername>

-j/--jfname <jfname>

Sets uniform scheduler settings in journal file volumes.

-s/--schedulesnap <scheduleduration:maxsnapshots>

-d/--description <description>

-b/--backuptargetname <backuptargetname>

-p/--scheduleType <0-Windows,1-Local>

Example: set -t snap -c Cont0 -j mysar0 -s 5:10 -s 60:20 -d testing -b backuptest -p 0 journal

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Continuous Data Protection

These commands are to view cdp for journal file.

rollback cdp

review cdp

delete cdp

get cdp

-c/--container <containername>

-f/--journalfile <jfname>

Example: rollback -c c0 -f jf0 cdp

-c/--container <containername>

-f/--journalfile <jfname>

-s/--basesnap <t-number>

-t/--deltatime <deltat from basesnap>

-i/--deltaio <delta IO from deltat>

-e/--eventindex <deltaevt from basesnap>

Example: review -c c0 -f jf0 -s 1 -t 10 -i 54 cdp review -c c2 -f jf1 -s 1 -e 15 cdp

-c/--container <containername>

-f/--journalfile <jfname>

Example: delete -c c0 -f jf0 cdp

-t review

-c/--container <containername>

-f/--journalfile <jfname>

Example: get -t review -c c0 -f jf0 cdp

Recovery Wizard

These commands are used as part of recovery wizard.

get recoverywizard -c/--container <container name>

-v/--volume<volumename>

-x/--xml (optional)

-n/--tnum <writable snapshot number> (optional)

Example: get -c c0 -v vol1 recoverywizard get -c c0 -v vol1 -v vol2 -v vol3 -n 1 -x recoverywizard

review recoverywizard

-c/--container <container name>

-v/--volume<volumename>

-s/--snap<snapname>

-x/--xml (optional)

Example: review -c c0 -v vol1 -s snapv1T1 recoverywizard review -c c0 -v vol1 -v vol2 -v vol3 -s snap4v1T2 –s snap5v2T2 -s snap6v3T2 recoverywizard

Performs rollback on journal file.

Performs CDP Review operation for journal file.

1) -t and -i options ignored if -e is specified

2) Delta time and IO must not be specified for event review

Delete a currently existing CDP session.

Gets CDP Review Progress operation for journal file.

Get recoverywizard lists the snaps

that have common‘t’ number

across the given set of volume(s).

Review recoverywizard activates a

set of snaps that have common ‘t’

number across the given set of

volume(s), adds them to a LUN

and enables them as a target to

which an initiator can login to

review the data.

Chapter Two: Command Set 41

remove recoverywizard

rollback recoverywizard

-c/--container <container name>

-v/--volume<volumename>

-s/--snap<snapname>

-t/--tgt_name<tgt_name>

-x/--xml (optional)

Example: remove -c c0 -v vol1 -s snap1 -t iqn.1991-

10.com.ami:itx00c09f2164459105:t08212006tgt1 recoverywizard

remove -c c0 -v vol1 -v vol2 -v vol3 –s snap4v1T2

-s snap5v2T2 -s snap6v3T2 -t iqn.1991-

10.com.ami:itx00c09f2164459105:t08222006tgt2 recoverywizard

-c/--container <container name>

-v/--volume<volumename>

-s/--snap<snapname>

-x/--xml (optional)

Example: rollback -c c0 -v vol1 -s snap1 recoverywizard rollback -c c0 -v vol1 -v vol2 -v vol3 –s snap4v1T2 -s snap5v2T2 -s snap6v3T2 recoverywizard

Storage Resource Management

These commands are used as part of SRM.

list srm -q/--queue <workflow, pending, report>

-n/--num_tasks <number of tasks>

-o/--offset < offset in the queue >

-f/--filename <xml filename >

-x/--xml

Example: list -q report -n 20 -o 5 srm list -q pending -n 20 -o 5 srm

clear srm -q/--queue <workflow , pending, report >

-x/--xml

Example: clear -q report srm

start srm Example:

start srm

stop srm Example:

stop srm

Remove recoverywizard disables

the target enabled in the Review

recoverywizard, removes the set of

snaps that have common ‘t’

number across the given set of

volume(s) from the LUN, and

deactivates the snapshot.

Note:

1) All Snaps have same‘t’ number.

Rollback recoverywizard rollbacks

the set of volumes to set of

snapshots.

Note:

1) All Snaps have same‘t’ number.

List the tasks in report, pending

and workflow queue of the

SRM

Clears the SRM queues such as

workflow, pending, and report

Start the Storage resource

management activity. This is by

default started in the iTX box

Stop the Storage resource

management activity

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Local and Replicated Snapshot validation

These commands are used as part of snap validation.

enable snapvalidation

disable snapvalidation

pause snapvalidation

resume snapvalidation

get snapvalidation

list snapvalidation

resume snapvalidation

pause snapvalidation

-t/--type local

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: enable -t local -c Cont0 -v Volume0 snapvalidation

-t/--type local

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: disable –t local -c Cont0 -v Volume0 snapvalidation

-t/--type local

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: pause -t local -c Cont0 -v Volume0snapvalidation

-t/--type local

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: resume –t local -c Cont0 -v Volume0snapvalidation

-t/--type local

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: get -t local -c Cont0 -v Volume0snapvalidation

-t/--type local

-x/--xml

Example: list -t local snapvalidation

-t/--type (SRP/HA)

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example:

resume -t SRP -c Cont0 -v Volume0 snapvalidation resume -t HA -c Cont0 -v Volume0 snapvalidation

-t/--type (SRP/HA)

-c/--containername <containername>

This will enable local NAS snap validation for the given NAS volume. Once enabled, it will be in “resumed” state by default – meaning ALL scheduled snaps will be validated, both already present and those that will be created new. This will disable local NAS snap validation for already enabled NAS volume.

This pause validation of NAS snapshots for already enabled NAS volume.

This will resume validation of NAS snapshots for already paused (enabled) NAS volume.

This will return the status – paused / resumed of the given NAS Volume for snap validation. It will also return the list of snapshots that are validated so far with the status (passed / failed)

This will return the list of NAS volumes that are enabled for NAS snap validation, along with the current status – paused / resumed.

This will resume replica validation for the given volume or volumes SRP/HA. The remote system information will be taken from the given replica pair itself, so no need to add them separately.

SRP – Sync replica module HA – High availablility module

Pauses the already running SRP/HA replica validation of given

Chapter Two: Command Set 43

get snapvalidation

resume snapvalidation

pause snapvalidation

get snapvalidation

-v/--volumename<volumename>

-x/--xml

Example: pause -t SRP -c Cont0 -v Volume0 snapvalidation pause -t HA -c Cont0 -v Volume0 snapvalidation

t/--type (SRP/HA)

-c/--containername <containername>

-v/--volumename<volumename>

-x/--xml

Example: get -t SRP -c Cont0 -v Volume0 snapvalidation get -t HA -c Cont0 -v Volume0 snapvalidation

-t/--type (CG)

-c/--containername<containername>

-n/--cgname <cgname>

-x/--xml

Example: resume -t CG -c Cont0 -n CG1 snapvalidation

-t/--type (CG)

-c/--containername <containername>

-n/--cgname <cgname>

-x/--xml

Example:

pause -t CG -c Cont0 -n CG1 snapvalidation

-t/--type (CG)

-c/--containername<containername>

-n/--cgname <cgname>

-x/--xml

Example: get -t CG -c Cont0 -n CG1 snapvalidation

set.

SRP – Sync replica module HA – High availability module

This will return the status – paused / resumed as well as the list of snapshots validated. For SRP/HA with multiple volumes, the each validated snap of each volume will be returned.

SRP – Sync replica module HA – High availability module

This will resume replica validation for the given volume or volumes CG. The remote system information will be taken from the given replica pair itself, so no need to add them separately. CG – Snap assisted replication module

Pauses the already running CG replica validation of given set.

CG – Snap assisted replication module

This will return the status – paused / resumed as well as the list of snapshots validated. For CGs with multiple volumes, the each validated snap of each volume will be returned.

CG – Snap assisted replication module

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Appendix A Error Codes

Code Description

0 Command Succeeded 1 Command Failed 2 Invalid Parameter 3 Insufficient buffer 4 Insufficient memory 5 Invalid Operation 6 Error in opening file 10 User does not exist 11 User already exists 12 Selected user is a NIS user 13 User type did not match ADS NIS and LOCAL 14 User Count in UserList is not set 15 Invalid User ID 20 Group does not exist 21 Group already exists 22 Selected group is a NIS Group 23 Group Count in GroupList is not set 24 Group type did not match ADS, NIS and LOCAL 25 Invalid Group ID 26 Not able to init CLI command list 27 Not able to init CLI error list 31 Share does not exist 32 Share already exists 33 Path does not exist 34 Share does not exist 35 Invalid share count 36 Unable to create share entry 37 Unable to delete the share entry 38 Share operations not possible on iSCSI volumes 40 Read less number of event log records, than requested. 41 Event log database is full. 42 Event log database is Empty. 43 Event is not in list 44 Corrupted event list file 45 No Matching records were found. 46 Log database is Empty. 47 Read less number of records, than requested. 51 Volume does not exist 52 Volume already exists 53 Volume is busy. Retry later. 54 Disk is not available for use by the volume 55 Disk count is invalid for the requested raid level 56 Invalid Raid level 57 Volume is not ready or Volume does not exist 58 Raid Volume is a bootable volume 59 No Raid OS volume 60 Snapshot unsupported 61 Snapshot is inactive 62 Invalid Snapshot count 63 iSCSI Volume sync error 64 Snapshot is mounted 65 Readable snapshot cannot be mounted 68 Input has missing parameters 69 Input has excess parameters

Index 45

Code Description

70 Null parameter 71 Invalid disk channel 72 Invalid Disk 73 Invalid Username 74 Invalid password 75 Invalid groupname 76 Invalid Network port 77 Invalid Path 78 Invalid Volume Name 79 Invalid share name 80 Invalid server name 81 Invalid member type 82 Invalid member count 83 Invalid access rights 84 Invalid address 85 Retry after system reboot 86 Invalid member name 87 Invalid service type 88 Invalid service status 90 Command is not processed 91 Command not supported 92 Reply packet is not good 93 Connection to Mstor Engine is lost 94 API is returned as success. but it got excess data than requested 95 Invalid payload size 96 Invalid host name 97 Invalid RPM name 98 Error in installing RPM 99 UPnP Share Does not exists 110 File open Error 111 User Operation busy 112 Unable to delete user 113 Unable to add group 114 Group operation busy 115 Unable to update user data 116 Unable to update group data 117 Invalid group ID 118 User ID already exists 119 Group ID already exists 120 Primary group error 121 Usergroup cache empty 122 Fewer members read 150 Group or Key does not exists in the file 151 Group already exists in the file 160 Error in initializing the health monitoring interface 161 Error in reading sensor value 162 Health monitoring SDK is not initialized 163 Path is used by other share 164 Record not found 165 Record addition failed 166 Record deletion failed 167 Record update failed 168 Entry not available 169 Error in getting container list 170 Volume list is NULL 171 Snapshot list is NULL 172 Entry addition failed 174 Error in setting ACL recursively

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Code Description

175 Error in mounting the share 200 Upgrade version error 201 Upgrade package already installed 202 Upgrade package dependency failure 203 Upgrade package installation failed 204 Upgrade requires more disk space 205 Invalid package name 220 Error in upgrade operation 230 Duplicate IP address 231 Invalid IP address 232 Invalid subnet mask 233 Invalid gateway 234 Invalid DNS server 235 Failed to set IP 240 Disks are differing in geometry 241 The partition of the disks differ 250 Raid Device is busy with resync or rebuild 251 Directory is shared 252 Error in deleting directory 253 Error in creating directory 254 Directory operations are not possible on ISCSI volumes 260 Invalid IPX internal network number 261 Invalid IPX external network number 262 Invalid IPX frame type 263 Invalid CIFS workgroup 264 Invalid SNMP Trap Destination 265 Invalid SNMP community 266 Invalid domain name 267 Duplicate SNMP Trap Destination 268 Duplicate Email ID 270 ACL database error 280 Error_net_join 281 ADS domain already exists 282 NIS domain already exists 290 Invalid time 291 Invalid date 292 Sync to NTP fail 293 Invalid time zone 300 Invalid network team mode 301 Invalid network team member 302 Invalid network team name 303 Network team already exists 304 Network adapter part of team 305 Invalid network team deletion order 306 Prerequisite not met 307 Network team does not exist 310 Invalid Rule Index 311 Rule limit exceeded 312 Rule Already exists 320 EVMS API General Failure 330 Invalid License File 331 Error in trying to update Evaluation License over existing Extended License 332 Incompatible License according to the Product Type 333 Invalid Customer ID 334 Invalid version 335 Invalid license features 336 License General error 337 License file open error

Index 47

Code Description

338 License file read write error 350 Duplicate Alias Name 351 Alias not found 352 Invalid Alias Name 353 DHCP is not supported for Alias Adapters 354 Maximum Alias Adapter count exceeded 355 Maximum Alias per NIC exceeded 500 No Target found 501 Object Not Found 502 Internal error 503 Limits exceeded for operation 504 Object does not have date 505 iSNS status returned 506 iSNS task error 507 Cannot communicate with iSNS daemon 508 Internal iSNS error 509 iSNS server signals error 510 iSNS object not found 511 iSCSI Service not running 512 Invalid Target name 513 iSNS service not running 514 Current operation failed as it needs iSCSI to be enabled on this Volume 515 Password for this user has to be between 12 and 16 characters 516 ISCSI Disk still in use 517 Too many ISNS servers 518 ISNS Server error 519 Cannot perform this operation; there are no iSNS servers 520 Unknown iSNS error 521 Cannot remove ISNS server, an operation is in progress 522 LUN serial number error 523 Error in loading SMA module 524 Error in unloading SMA module 525 Maximum number of LUNs/Volumes has been reached for this target 526 Cannot add NAS volume to target 527 Deactivate portal to change portal tag 528 LUN had been already added to target 529 Invalid LUN 550 Invalid Disk Selection 551 Invalid RAID Number 552 No RAID is Present 553 Invalid RAID Level 554 Invalid Cache Type 555 Invalid Disk Count for the RAID Level 556 Invalid Spare Disk Count 557 Invalid Disk Information 558 Selected array is part of Volume...Cannot be deleted 559 RAID Disks cannot be used as Spares 560 Size of Raid Array is greater than 2 TB 561 Distributed Spares is not supported in RAID0, RAID1 and RAID1n 562 Rebuild failed 601 Invalid controller 603 Function not supported 604 Null Controller list 605 Function not supported 606 Spare disk unsupported 607 Disk count limit exceeded 608 Error in initializing disk 609 IOCTL failure

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Code Description

610 No spare support 611 Max limit reached 612 No MD device available 613 MD creation failed 614 Add entry to configuration file failed 615 disk is not free 616 Minimum disk count 617 Error in updating configuration file 618 Error in reading from configuration file read error 619 Raid hot remove failed 620 Disk partitioning failed 621 Raid hot add failed 622 No raid array found 623 OS raid device error 624 Swap raid device error 625 Device open Error 626 Error raid creation in progress 627 Invalid Sub raid disk count 628 Error on transforming offline raid 629 Invalid raid number 631 Invalid spare disk count 632 Illegal spare type 633 Invalid raid cache type 634 Invalid raid drive size 635 Maximum raid size 636 Insufficient disk space 637 Raid cannot be shrunk 638 API failure 639 Disk is not a Spare 640 Var Log device error 642 LD Create & Expand/Transform not supported while another LD Expand/Transform is in progress 643 LD Expand/Transformation is in progress, not able to change the configuration 644 Battery Not Available 645 Cache type is not supported by the controller 701 Container count limit exceeded 702 FileSystem error 703 Volume creation error 704 DM mount error 705 Delete container error 706 Create container error 707 Duplicate device error 708 Volume Deletion error 709 DM umount error 710 NAS Volume freeze error 711 NAS Volume unfreeze error 712 Start Container failed 713 Stop Container failed 714 Invalid LD Device 715 Invalid Container chunk size 716 Resource is busy 717 Error in getting container info 718 Invalid Container name 719 Error in deactivating snap 720 Error in activating snap 721 Error in creating snap 722 Error in deleting snap 723 Error in mounting volume 724 Error in unmounting volume

Index 49

Code Description

725 Error in mounting file system 726 Error in getting snap info 727 Error in creating writable snap 728 Error in getting volume info 729 Max space reached 730 Invalid dialect 731 Invalid Snap 732 Error in rolling back Snap 734 Error in unmounting file system 735 Error in reading metadata 736 Serial already exists 737 Invalid mount type 738 Quota operations not possible on iSCSI volumes 739 Snapshot already activated 740 Snapshot already deactivated 741 Maximum volume count limit reached 742 Error in resizing the volume 743 Unsupported option 744 Error in DM reload 745 FileSystem growth failure 746 Volume already activated 747 Volume already deactivated 748 DMsetup info error 749 No space left in container 750 Permission denied 751 Session not found 752 Max user session limit 753 Max session limit 754 Management administrator not found 760 Maximum management stations configured 800 No free space to expand 801 Volume expansion limit exceeded 802 Read only snapshot count exceeded 803 Read write snapshot count exceeded 852 License – Read only snapshot count exceeded the license count 853 License – iSCSI volume license expired/disabled 854 License - SAS hard disk license expired/disabled 855 License – SATA hard disk license expired/disabled 856 License - Enclosure count exceeded/disabled 857 License - NAS volume license expired/disabled 858 License - Container size exceeded the license limit 859 License - Invalid License Key 860 License - License Structure is missing or License is absent 861 License - Service key is missing 862 License - Updation of Evaluation time failed 863 License - Limit on the particular feature is reached 864 License - Time for the particular feature usage expired or disabled 865 License - License Structure is corrupted 866 License - Temp file creation failed 867 License - Incorrect License for the System 868 License - Error Copying files 869 License - License File Decryption Failure 870 License - License File Encryption Failure 871 License - Setting License Failure 872 License - License Key is absent, License Module is not loaded. 873 License - Incorrect System for the License Key 874 Error in WINBIND 875 Error in YPBIND

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Code Description

876 Error in BIND 877 License - HA pair creation license expired/disabled 878 License - Unable to Read the License File 879 License - License Validation Failure 880 License - New Motherboard or New Motherboard with Some External NIC cards found, For service key

generation, remove all External NIC cards from the system 881 License - Thin provision license expired/disabled, request denied. 882 License - ILM license expired/disabled, request denied. 883 License - Applying Old License File Again, request denied. 900 Replication is enabled 901 Incorrect Replication 902 Replication is enabled, secondary volume present in container 903 Replication is enabled, replication pair non-operational 904 Resource group is not owned 905 Resource group already started 906 Resource group is out of sync 907 Unable to get resource group information 908 Invalid resource group state 909 Machines chosen for HA are not identical 910 Subnet does not match in machines. All NICS should be on different subnets 911 Remote Resource group not accessible 912 Unable to set virtual ipaddress 913 Maximum of 1 Alias per NIC per RG exceeded 914 Primary Target Name already used for a different volume in secondary 915 Error in regenerating target name 916 Portal is inactive in Local/Remote 917 Replication command timed out on the remote box due to it being busy 918 No Target found for volume either in Primary/Secondary 919 Replication – Operation not permitted on Secondary 1001 Replication - General error 1002 Replication - Invalid parameters 1003 Replication - Insufficient memory for performing the operation 1004 Replication - Permission denied 1005 Replication - system busy 1006 Replication - Fatal error 1007 Replication - Master Logical drive NOT available 1008 Replication - Volume error 1009 Replication - Volume size error 1010 Replication - iSCSI target serial number error 1011 Replication - Error while accessing Container DDF 1012 Replication - Error while accessing Replication DDF 1013 Replication - Initiator error 1014 Replication - Remote device error 1015 Replication - Error while accessing tab bits 1016 Replication - iSCSI login error 1017 Replication - Error while activation 1018 Replication - Remote Volume device NOT found 1019 Replication - Remote Management device NOT found 1020 Replication - Sync replication feature is not licensed or time period expired 1021 Replication - Error in establishing MPIO Session: Please check if secondary or link to it is alive, and it's

portal is activated 1022 Replication - Error in creating HA Pair. Volume is part of a SAR pair 1023 Replication - Resource group count exceeded 1024 Replication - Resource group already present 1025 Replication - Resource group not present 1026 Replication - Failed to modify the resource group config 1027 Replication - Resource group entry not present 1028 Replication - Duplicate entry present in resource group config

Index 51

Code Description

1029 Replication - Volume is not in sync 1030 Replication - Box owns RG but volumes are secondary 1031 Replication - Box is not the orignal owner of the RG 1032 Replication - Box does not own RG but volumes are primary 1101 Asynchronous Replication – Asynchronous Replication CG not found 1102 Asynchronous Replication – General Failure 1103 Asynchronous Replication – Duplicate Asynchronous Replication CG name 1104 Asynchronous Replication – Volume already part of Asynchronous Replication CG name 1105 Asynchronous Replication – Invalid Volume size 1106 Asynchronous Replication – Invalid Asynchronous Replication CG role 1107 Asynchronous Replication – Invalid volume count 1108 Asynchronous Replication – Volume not empty 1109 Asynchronous Replication – IOCTL error 1110 Asynchronous Replication – Error in Handshake 1111 Asynchronous Replication – Maximum CG reached 1112 Asynchronous Replication - Invalid opertion - replication not yet started - No valid snaps found 1113 Asynchronous Replication - CG config metadata area is corrupted 1114 Asynchronous Replication - Error in getting passive side CG info 1115 Asynchronous Replication - Error in getting passive side CG list 1116 Asynchronous Replication - Error in updating passive side CG info 1117 Asynchronous Replication - Error in passive side resume operation 1118 Asynchronous Replication - Error in passive side pause operation 1119 Asynchronous Replication - No common T number snapshot found 1120 Asynchronous Replication - Given T number snapshot info not available 1121 Asynchronous Replication - Given volume already part of another CG 1122 Asynchronous Replication - Remote machine unavailable 1123 Asynchronous Replication - Invalid Remote machine CG info 1124 Asynchronous Replication - Active volumes already paired with another SAR CG in this remote box 1125 Asynchronous Replication - Volumes having different scheduler settings 1126 Asynchronous Replication - Invalid Volume Chunk Size 1127 Asynchronous Replication - Unable to get the initiator name 1128 Asynchronous Replication - Unable to get mtarget name 1130 Asynchronous Replication - Minimum snapshot retention should be more than 3 per level 1131 Asynchronous Replication - Volume part of synchronous replication or HA grouping 1132 Asynchronous Replication - Invalid configuration 1200 JM – Failed to create Journal 1201 JM – Journal File count limit exceeded 1202 JM – Failed to create Journal File 1203 JM – Error in getting Journal info 1204 JM – Error in starting Journal 1205 JM – Error in stopping Journal 1206 JM – Invalid Journa Name 1207 JM – Journal Count limit exceeded 1208 JM – Failed to delete Journal 1209 JM – Journal Event Failed 1210 JM – Failed to expand Journal 1211 JM – Failed to delete Journal File 1212 JM – Error in getting Journal File Name 1213 Invalid T number 1214 JM – Journal in use 1215 JM – JournalFile size exceeded the Free Space available in Journal 1250 JM – Reached EOF 1300 Snap Validation – Info file creation error 1301 Snap Validation – Already paused 1302 Snap Validation – Already resumed 1303 Snap Validation – Config file creation error 1304 Snap Validation – Block Dedupe enabled 1305 Snap Validation – Remote side snapshot not available

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

Code Description

1306 Snap Validation – Local snapshot not available 1307 Snap Validation – User snapshot validation pending 1308 Snap Validation – Snapshot already validated 1325 Read only snap count max reached 1326 Snap count per volume max reached 1327 Snap count per system max reached 1345 Duplicate Frequency/Level entered for Snapshot Schedule 1351 iSCSI MirrorConfig – Physical disk size mismatch found 1352 iSCSI MirrorConfig – Invalid physical disk mapping found 1353 iSCSI MirrorConfig – Hotspare creation failed 1354 iSCSI MirrorConfig – Logical drive creation failed 1355 iSCSI MirrorConfig – Container creation failed 1400 CDP – General error 1401 CDP – Invalid parameter 1402 CDP – Invalid Journal file name 1403 CDP – Invalid Container name 1404 CDP – Journal not present 1405 CDP – Failed to open resource 1406 CDP – Snapshot not available 1407 CDP – Memory constraint 1408 CDP – Snapshot not available in Journal 1409 CDP – CDP session for given parameters not available 1410 CDP – Failed to renew CDP session 1411 CDP – Event missing in Journal file 1412 CDP – Thread creation error 1413 CDP – Journal file overflow error 1414 CDP – Snapshot is in unstable state 1415 CDP – Failed to read from journal file 1504 Upgrading packages failed 1506 Upgrade Checksum failed 1507 Upgrade error in downloading image 1508 Upgrade image version is older than current version 1509 Upgrade image version is same as current version 1510 Insufficient disk space for upgrade 1511 Upgrade image file is corrupted 1512 Error in performing upgrade 1513 Invalid parameters in upgrade 1514 Upgrade image version is invalid 1515 License is not valid for upgrade 1516 Invald IP address or Host name 1517 Error in performing upgrade 2001 Remote Communication - General Error 2002 Remote Communication - Invalid Parameters 2003 Remote Communication - Insufficient memory for performing the operation 2004 Remote Communication - Permission Denied 2005 Remote Communication - Management Target Busy 2006 Remote Communication - Fatal Error 2010 Remote Communication - Invalid Packet Signature 2011 Remote Communication - Version Error 2012 Remote Communication - No such remote module 2013 Remote Communication - Connection Error 2014 Remote Communication - Inter-node Initiator error 2015 Remote Communication - Login Error 2016 Remote Communication - Module Connection Error 2017 Remote Communication - Remote Device Error 4096 DVM - Lib node open error 4097 DVM - Lib invalid data 4098 DVM - Device End of file

Index 53

Code Description

4099 DVM - Device open error 4100 DVM - Device access error 4101 DVM - general error 4102 DVM - Lib DM suspend error 4103 DVM - Lib DM resume error 8192 DVM - generic error 8193 DVM - memory allocation errors 8194 DVM - IOCTL Parameter passing failures copy_from_user, copy to user etc 8195 DVM - generic invalid parameter error 8196 DVM - container name is empty / unrecognizable by DVM driver 8197 DVM - volume is empty / unrecognizable by DVM driver 8198 DVM - snapshot name is empty / unrecognizable by DVM driver 8199 DVM - Error persisting metadata to disk (or) reading metadata from disk 8200 DVM - The number of LD segments is invalid 8201 DVM - The stripe size for the LD segments is invalid 8202 DVM - Duplicate container name 8203 DVM - Too many containers in the system 8204 DVM - Failed to open the LD segment 8205 DVM - volume size specified container 8206 DVM - invalid provisioning type specified 8207 DVM - snap type specified is invalid 8208 DVM - invalid UUID specified 8209 DVM - duplicate volume name specified 8210 DVM - duplicate volume UUID specified 8211 DVM - too many volumes in the system 8212 DVM - cannot create exact provisioned volume - No space available 8213 DVM - when trying to take a snap of snapshot - assumes writ. snapshot is another ioctl 8214 DVM - duplicate snap name 8215 DVM - too many snaps in the volume or a writable snapshot already exists 8216 DVM - too many snaps in the system 8217 DVM - if the ld segment length is invalid 8218 DVM - when trying to take a "writable" snap of volume 8219 DVM - volume is in use 8220 DVM - snap is in use 8221 DVM - snap rollback bg fail 8222 DVM - compaction bg fail 8223 DVM - compaction already running 8224 DVM - cannot pause compaction 8225 DVM - cannot stop compaction 8226 DVM - log fail 8227 DVM - Container couldn't start, conflicts in vol-index with existing container-volumes 8228 DVM - Obsolete command 8229 DVM – Redundant Snapshot 8230 DVM - Operation failed on invalidated snapshot 8231 DVM – Invalid Pinned Volume 8232 DVM – Pinned Volume exists 8233 DVM – Source & Dest Volume size mismatch 8234 DVM – Destination Volume is not empty 8236 DVM - No events

StorTrends® iTX Software CLI (Command Line Interface) (Version 2.7) User’s Guide

American Megatrends MAN-STOR-ITX27-CLI User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
