MLG-130DR (HSI)

Installation Manual

WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or death.

Do not store or use gasoline or other flammable vapor and liquids in the vicinity of this or any other appliance.

WHAT DO YOU DO IF YOU SMELL GAS

* Do not try to light any appliance. * Do not touch any electrical switch; do not use

any phone in your building.

* Clear the room, building or area of all

occupants.

* Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's instructions.

* If you cannot reach your gas supplier, call the

fire department.

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

AVERTISSEMENT: Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque dincendie ou dexplosion ou pour éviter tout dommage matériel, toute blessure ou la mort.

Ne pas entreposer ni utiliser dessence ni dautres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de tout autre appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:

* Ne pas tenter dallumer dappareil. * Ne touchez à aucun interrupteur. Ne pas

vous servir des téléphones se trouvant dans

le bâtiment où vous vous trouvez.. * Évacuez la pièce, le bâtiment ou la zone. * Appelez immédiatement votre fournisseur de

gaz depuis un voisin. Suivez les instructions

du fournisseur. * Si vous ne pouvez rejoindre le fournisseur

de gaz, appelez le service des incendies.

Linstallation et lentretien doivent être assurés par un installateur ou un service dentretien qualifié ou par le fournisseur de gaz.

For replacement parts, contact the distributor from which the dryer

was purchased or

American Dryer Corporation

88 Currant Road

Fall River MA 02720-4781

Telephone: (508) 678-9000 / Fax: (508) 678-9447

E-mail: techsupport@amdry.com

030600JJB/tcosta ADC Part No. 113130

Retain This Manual In A Safe Place For Future Reference

American Dryer Corporation products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble-free operation.

ONLY qualified technicians should service this equipment.

OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation/operator's manual included with the dryer.

The following FOR YOUR SAFETY caution must be posted near the dryer in a prominent location.

FOR YOUR SAFETY

Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.

We have tried to make this manual as complete as possible and hope you will find it useful. ADC reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models.

POUR VOTRE SÉCURITÉ

Ne pas entreposer ni utiliser dessence ni dautres vapeurs ou liquides inflammables dans le voisinage de cet appareil ou de yout autre appareil.

Important

For your convenience, log the following information:

DATE OF PURCHAS E MODEL NO.

DISTRI BUTORS NAM E

Serial Number(s)

MLG-130DR

Replacement parts can be obtained from your distributor or the ADC factory. When ordering replacement parts from the factory, you can FAX your order to ADC at (508) 678-9447 or telephone your orders directly to the ADC Parts Department at (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.

IMPORTANT NOTE TO PURCHASER

Information must be obtained from your local gas supplier on the instructions to be followed if the user smells gas. These instructions must be posted in a prominent location near the dryer.

IMPORTANT

YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.

«Attention: Lor des opérations dentretien Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper operation.

des commandes étiqueter tous fils avant

de les déconnecter. Toute erreur de

câblage peut étre une source de danger et

de panne.»

CAUTION

DRYER(S) SHOULD NEVER BE LEFT UNATTENDED WHILE IN OPERATION.

WARNING

CHILDREN SHOULD NOT BE ALLOWED TO PLAY ON OR NEAR THE DRYER(S).

CHILDREN SHOULD BE SUPERVISED IF NEAR DRYER(S) IN OPERATION.

FOR YOUR SAFETY

DO NOT DRY MOP HEADS IN THE DRYER.

DO NOT USE DRYER IN THE PRESENCE OF DRY CLEANING FUMES.

WARNING

UNDER NO CIRCUMSTANCES should the door switch or the heat circuit devices ever be disabled.

WARNING

The dryer must never be operated with any of the back guards, outer tops, or service panels removed. PERSONAL INJURY or FIRE COULD RESULT.

WARNING

DRYER MUST NEVER BE OPERATED WITHOUT THE LINT FILTER/SCREEN IN PLACE, EVEN IF AN EXTERNAL LINT COLLECTION SYSTEM IS USED.

IMPORTANT

PLEASE OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment and/or specified in the installation and operator's manual included with the dryer.

Dryers must not be installed or stored in an area where it will be exposed to water or weather.

The wiring diagram for the dryer is located in the front electrical control box area.

Table of Contents

SECTION I

IMPORTANT INFORMATION ............................................................................... 3

A. Receiving and Handling ............................................................................................................... 3

B. Safety Precautions ...................................................................................................................... 4

SECTION II

SPECIFICATIONS/COMPONENT IDENTIFICATION .................................... 6

A. Specifications ............................................................................................................................. 6

B. Component Identification ............................................................................................................ 8

SECTION III

INSTALLATION PROCEDURES ......................................................................... 10

A. Location Requirements ............................................................................................................. 10

B. Unpacking/Setting Up ............................................................................................................... 11

C. Dryer Enclosure Requirements .................................................................................................. 13

D. Fresh Air Supply Requirements ................................................................................................. 14

E. Exhaust Requirements ............................................................................................................... 15

F. Electrical Information ................................................................................................................ 20

G. Gas Information ........................................................................................................................ 23

H. Preparation For Operation/Start-Up ......................................................................................... 27

I. Preoperational Tests ................................................................................................................. 27

J. Operating Instructions ............................................................................................................... 29

K. Shut Down Instructions ............................................................................................................. 30

SECTION IV

SERVICE/PARTS INFORMATION ...................................................................... 31

A. Service ..................................................................................................................................... 31

B. Parts ........................................................................................................................................ 31

SECTION V WARRANTY INFORMATION

A. Returning Warranty Card(s) ...................................................................................................... 32

B. Parts ........................................................................................................................................ 32

C. Returning Warranty Part(s)........................................................................................................ 32

SECTION VI

ROUTINE MAINTENANCE .................................................................................. 34

A. Cleaning ................................................................................................................................... 34

B. Adjustments ............................................................................................................................. 35

C. Lubrication ............................................................................................................................... 35

SECTION VII

REVERSING TIMER SPIN/DWELL ADJUSTMENTS .....................................36

SECTION VIII PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT

COMPONENTS ........................................................................................................

SECTION IX BURNER and LINT (TUMBLER) CHAMBER MANUAL RESET

HI-LIMIT INSTRUCTIONS ................................................................................... 40

SECTION I

IMPORTANT INFORMATION

A. RECEIVING and HANDLING

The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and wooden skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect further before delivering carrier leaves.

Dryers damaged in shipment:

ALL dryers should be inspected upon receipt and before they are signed for.

2. If there is suspected damage or actual damage, the truckers receipt should be so noted.

3. If the dryer is damaged beyond repair, it should be refused. Those dryers which were not damaged in a damaged shipment should be accepted, but the number received and the number refused must be noted on the receipt.

4. If you determine that the dryer was damaged after the trucker has left your location, you should call the delivering carriers freight terminal immediately and file a claim. The freight company considers this concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult when more than a day or two (2) passes after the freight was delivered. It is your responsibility to file freight claims. Dryer/parts damaged in transit cannot be claimed under warranty.

5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end. ADC assumes no responsibility for freight claims or damages.

6. If you need assistance in handling the situation, please contact the ADC Traffic Manager at (508) 678-9000.

IMPORTANT: The dryer must be transported and handled in an upright position at ALL times.

B. SAFETY PRECAUTIONS

WARNING: For your safety, the information in this manual must be followed to minimize the risk of

fire or explosion or to prevent property damage, personal injury, or loss of life.

WARNING: The dryer must never be operated with any of the back guards, outer tops, or

service panels removed. PERSONAL INJURY or FIRE COULD RESULT.

1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other

appliance.

2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the

user smells gas. The instructions should be posted in a prominent location.

3. WHAT TO DO IF YOU SMELL GAS...

a. DO NOT try to light any appliance.

b. DO NOT touch any electrical switch.

c. DO NOT use any phone in your building.

d. Clear the room, building, or area of ALL occupants.

e. Immediately call your gas supplier from a neighbors phone. Follow the gas suppliers instructions.

f. If you cannot reach your gas supplier, call the fire department.

4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.

5. Dryer(s) must be exhausted to the outdoors.

6. Although ADC produces a very versatile machine, there are some articles that, due to fabric composition or cleaning method, should not be dried in it.

WARNING: Dry only water-washed fabrics. DO NOT dry articles spotted or washed in dry

cleaning solvents, a combustible detergent, or all purpose cleaner.

EXPLOSION COULD RESULT.

WARNING: DO NOT dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint,

or wax.

EXPLOSION COULD RESULT.

WARNING: DO NOT dry mop heads. Contamination by wax or flammable solvent will create a fire

hazard.

WARNING: DO NOT use heat for drying articles that contain plastic, foam, sponge rubber, or

similarly textured rubberlike materials. Drying in a heated tumbler (basket) may damage plastics or rubber and also may be a fire hazard.

7. A program should be established for the inspection and cleaning of lint in the burner area, exhaust duct

work, and area around the back of the dryer. The frequency of inspection and cleaning can best be determined from experience at each location.

WARNING: The collection of lint in the burner area and exhaust duct work can create a potential fire

hazard.

8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the

National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

NOTE: Failure to do so will VOID THE WARRANTY.

9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or heat safety

circuit, ever be disabled.

WARNING: PERSONAL INJURY or FIRE COULD RESULT.

10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.

11. Remove articles from the dryer as soon as the drying cycle has been completed.

WARNING: Articles left in the dryer after the drying and cooling cycles have been complete can

create a fire hazard.

12. READ and FOLLOW ALL CAUTION and DIRECTION LABELS ATTACHED TO THE DRYER.

WARNING: YOU MUST DISCONNECT and LOCKOUT THE ELECTRIC SUPPLY and

THE GAS SUPPLY BEFORE ANY COVERS or GUARDS ARE REMOVED FROM THE MACHINE TO ALLOW ACCESS FOR CLEANING, ADJUSTING, INSTALLATION, or TESTING OF ANY EQUIPMENT per OSHA (Occupational Safety and Health Administration) STANDARDS.

SPECIFICATIONS/COMPONENT IDENTIFICATION

A. SPECIFICATIONS

AXIMUM CAPACITY (DRY WEIGHT

UMBLER (BASKET) DIAMETER

SECTION II

)130 lbs. 60 kg

44-1/2” 113 cm

UMBLER (BASKET) DEPTH

T T

UMBLER (BASKET) MOTOR

LOWER MOTOR

B D

OOR OPENING (DIAMETER UMBLER (BASKET) VOLUME

RYERS PER

D D

RYERS PER

A A

Gas

NLET PIPE SIZE

20’/40’ C 45’/48’ T

OLTAGE AVAILABLE

EAT INPUT

PPRO X. WEIGHT (UNCRATED PPRO X. WEIGHT (CRATED IRFLOW

ONTAINER

RUCK

42-1/2” 107.9 cm

3/4 HP .560 kw

3 HP 2.238 kw

) 31-3/8” 79.7 cm

38.2 cu. ft. 1.08 cu.m.

3/7 9/9

208-460v 3ø 3, 4w 50/60Hz

300,000 btu/hr 75,600 kcal/hr

) 1,500 lbs. 680.4 kg

) 1,725 lbs. 782.5 kg

1,750 cfm 49.6 cmm

1” 2.54 cm

Shaded areas are stated in metric equivalents

NOTE: ADC reserves the right to make changes in specifications at any time, without notice or

obligation.

Specifications

MLG-130DR

NOTE: ADC reserves the right to make changes in specifications at any time, without notice or

obligation.

B. COMPONENT IDENTIFICATION

1. Dryer Front View

Illus. No. Description

1 Microprocessor Control/Keyboard (Touchpad) Panel Assembly (Controls) 2 Control (Top Access) Door Assembly 3 Main Door Assembly 4 Lint Door Assembly 5 Lint Drawer 6 EMERGENCY STOP (E-Stop) Button 7 Wire Diagram (located behind Control Door) 8 Top Console (Module) Assembly

Dryer Rear View

Illus. No. Description

1 Basket (drive) Motor Assembly 2 Blower Motor Mount Assembly 3 Impellor (fan/blower) Assembly 4 Idler Bearing Mount Assembly 5 Tumbler Bearing Mount Assembly

6* Electric Service Relay Box

7 Heating Unit 8 Data Label and Installation Label

* Electric service connections are made in this box.

SECTION III

INSTALLATION PROCEDURES

Installation should be performed by competent technicians in accordance with local and state codes. In the absence of these codes, the installation must conform to applicable American National Standards: ANSI.Z223.1- LATEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code). In Canada, the installation must conform to Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION (for General Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION (for Electrical Connections).

A. LOCATION REQUIREMENTS

Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1-LATEST EDITION.

1. The dryer must be installed on a sound level floor capable of supporting its weight. It is recommended that carpeting be removed from the floor area that the dryer is to rest on.

2. The dryer must not be installed or stored in an area where it will be exposed to water and/or weather.

3. The dryer is for use in noncombustible locations.

4. Provisions for adequate air supply must be provided as noted in this manual (refer to Fresh Air Supply in Section D).

5. Clearance provisions must be made from combustible construction as noted in this manual (refer to Dryer Enclosure Requirements in Section C).

6. Provisions must be made for adequate clearances for servicing and for operation as noted in this manual (refer to Dryer Enclosure Requirements in Section C).

7. Dryer must be exhausted to the outdoors (refer to Exhaust Requirements in Section E).

8. Dryer must be located in an area where correct exhaust venting can be achieved as noted in this manual (refer to Exhaust Requirements in Section E).

IMPORTANT: Dryer should be located where a minimum amount of exhaust duct will be necessary.

B. UNPACKING/SETTING UP

Remove protective shipping material (i.e., plastic wrap and/or optional shipping box) from dryer.

IMPORTANT: Dryer must be transported and handled in an upright position at ALL times.

The dryer can be moved to its final location while still attached to the skid or with the skid removed. To un-skid the dryer, locate and remove the four (4) lag bolts securing the base of the dryer to the wooden skid. Two (2) are at the rear base, and two (2) are located in the bottom of the lint chamber. To remove the two (2) lag bolts located in the lint chamber area, remove the lint drawer and the three (3) Phillips head screws securing the lint door in place.

1. Leveling Dryer

a. To level the dryer, place 4-inch (10.16 cm) metal

shims (refer to the illustration) or other suitable material under the base pads. It is suggested that the dryer be tilted slightly to the rear.

2. If more headroom is needed when moving the dryer

into position, the top console (module) may be removed. To remove the Top Console (module);

a. Rear of Dryer (refer to the illustration on page

12)...

1) Disconnect the four (4) pin EMERGENCY STOP (E-Stop) Connector B .

2) Remove the Drive Motor blue wires C marked 1, 2, 3 from the Drive Motor Reversing Contactor T1, T2, T3.

3) Remove the Blower Motor red wires D marked 1, 2, 3 from the Blower Motor Overload T1, T2, T3.

4) Disconnect the two (2) pin Rotational Sensor Connector E .

b. Front of Dryer...

1) Open the Control Door

a) Remove the Phillips head screw from the bottom right of the Phase 6 Microprocessor Controller

(computer) Keyboard (touchpad) Panel Assembly.

b) Open the keyboard (touchpad) door.

2) Disconnect the four (4) pin connector.

3) Disconnect the two (2) pin connector.

4) Disconnect the two (2) pin connector from the Phase 6 Microprocessor Controller (computer).

Refer to the wiring diagram on the Control Door.

5) Disconnect the ground (GND) wire from the Phase 6 Microprocessor Controller (computer).

NOTE: b 2 and b 3 apply only to models manufactured after August 1997. Models manufactured

prior to August 1997 require a Pin Extraction Tool (ADC Part No. 122800) to remove the pins from their connectors.

c. Top of Dryer (refer to the illustration below)...

1) Remove the eight (8) sets of nuts and washers F holding the console (module) to the base.

IMPORTANT: The dryer must be transported and handled in an upright position at ALL times.

C. DRYER ENCLOSURE REQUIREMENTS

Even though a 12-inch (30.48 cm) clearance is acceptable, it is recommended that the rear of the dryer be positioned approximately two (2) feet (24-inches) - 0.61 meters (60.96 cm) - from the nearest obstruction (i.e., wall) for ease of installation, maintenance, and service. Bulkheads and partitions should be made from noncombustible materials. The clearance between the bulkhead header and the dryer must be a minimum of 4- inches (10.16 cm) and must not extend more than 4-inches (10.16 cm) to the rear of the front. The bulkhead facing must not be closed in ALL the way to the top of the dryer. A 2-inch (5.08 cm) clearance is required.

NOTE: Bulkhead facing should not be installed until after the dryer is in place. Ceiling area must be

located a minimum of 12-inches (30.48 cm) above the top of the dryer.

IMPORTANT: Even though a minimum of only 12-inches (30.48 cm) is required, 18-inches (45.72

cm) or more is suggested, for steam dryers and especially in cases where sprinkler heads are over the dryers.

NOTE: When fire sprinkler systems are located above the dryers, a minimum of 18-inches (45.72 cm)

above the dryer console (module) is suggested. Dryers may be positioned side wall to side wall, however, 1 or 2-inches (2.54 or 5.08 cm) is suggested for ease of installation and maintenance. Allowances must be made for the opening and closings of the control door and the lint door.

D. FRESH AIR SUPPLY REQUIREMENTS

When the dryer is operating, it draws in room air, heats it, passes this air through the tumbler (basket), and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the make-up air is inadequate, drying time and drying efficiency switch fluttering problems may result, as well as premature motor failure from overheating.

Air supply (make-up air) must be given careful consideration to assure proper performance of each dryer. An unrestricted source of air is necessary for each dryer. An airflow of 1,750 cfm (cubic feet per minute) - 49.55 cmm - must be supplied to each dryer. As a general rule, an unrestricted air entrance from the outdoors (atmosphere) of a minimum of 300 square inches (1935.48 square centimeters) is required for each dryer.

To compensate for the use of registers or louvers used over the openings, this make-up air must be increased by approximately thirty-three percent (33%). Make-up air openings should not be located in an area directly near where exhaust vents exit the building.

is not necessary to have a separate make-up air opening for each dryer. Common make-up air openings are

It acceptable. However, they must be set up in such a manner that the make-up air is distributed equally to ALL the dryers.

EXAMPLE: For a bank of six (6) dryers, two (2) unrestricted openings measuring 36-inches

by 25-inches (1800 square inches) - 91.44 cm by 63.5 cm (11612.88 square centimeters) is acceptable.

will be adversely affected. Ignition problems and sail

Allowances must be made for remote or constricting passageways or where dryers are located at excessive altitudes or predominantly low pressure areas.

IMPORTANT: Make-up air must be provided from a source free of dry cleaning solvent fumes.

Make-up air that is contaminated by dry cleaning solvent fumes will result in irreparable damage to the motors and other dryer components.

NOTE: Component failure due to dry cleaning solvent fumes will VOID THE WARRANTY.

E. EXHAUST REQUIREMENTS

1. General Exhaust Duct Work Information

Exhaust duct work should be designed and installed by a qualified professional. Improperly sized duct work will create excessive back pressure which results in slow drying, increased use of energy, overheating of the dryer, and shut down of the burner by the airflow (sail) switches, burner hi-limits, or tumbler (basket) hi-heat thermostats.

CAUTION: DRYER MUST BE EXHAUSTED TO THE OUTDOORS.

CAUTION: IMPROPERLY SIZED or INSTALLED EXHAUST DUCT WORK CAN

CREATE A POTENTIAL FIRE HAZARD.

NOTE: When a dryer is exhausted separately, it is recommended that a back draft damper be

installed.

NOTE: When dryers are exhausted into a multiple (common) exhaust line, each dryer must be

supplied with a back draft damper.

The duct work should be laid out in such a way that the duct work travels as directly as possible to the outdoors with as few turns as possible. Single or independent dryer venting is recommended. When single dryer venting is used, the duct work from the dryer to the outside exhaust outlet should not exceed 20 feet (6.09 meters). In the case of multiple (common) dryer venting, the distance from the last dryer to the outside exhaust outlet should not exceed 20 feet (6.09 meters). The shape of the duct work is not so critical so long as the minimum cross-sectional area is provided. It is suggested that the use of 90º turns be avoided; use 30º and/or 45º bends/angles instead. The radius of the elbows should preferably be 1-1/2 times the diameter of the duct. Excluding tumbler (basket)/dryer elbow connections or elbows used for outside protection from the weather, no more than three (3) elbows should be used in the exhaust duct run. If more than three (3) elbows are used, the cross-sectional area of the duct work must be increased in proportion to the number of elbows used.

ALL duct work should be smooth inside with no projections from sheet metal screws or other obstructions which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to be connected. ALL duct work joints must be taped to prevent moisture and lint from escaping into the building. Inspection door should be installed at strategic points in the exhaust duct work for periodic inspection and clean-out of lint from the duct work.

IMPORTANT: Exhaust back pressure measured by a manometer in the exhaust duct should not

exceed 0.3 inches of water column (0.74 mb).

NOTE: Where the exhaust duct work passes through a wall, ceiling, or roof made of combustible

materials, the opening must be 2-inches (5.08 cm) larger (all the way around) than the duct. The duct must be centered within this opening.

a. Outside Duct Work Protection

1) To protect the outside end of horizontal duct work from the weather, a 90° elbow bent downward

should be installed where the exhaust exits the building. If the duct work travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward. In either case, allow at least twice the diameter of the duct between the duct opening and the nearest obstruction.

IMPORTANT: DO NOT use screens or caps on the outside of opening of exhaust duct work.

2. Single Dryer Venting

Where possible, it is suggested to provide a separate exhaust duct for each dryer. The exhaust duct should be laid out in such a way that the duct work travels as directly as possible to the outdoors with as few turns as possible. It is suggested that the use of 90° turns in the ducting be avoided; use 30° and/or 45° angles instead. The shape of the exhaust duct work is not critical so long as the minimum cross section area is provided.

IMPORTANT: Minimum duct size for a dryer is 12-inches (30.48 cm) for a round duct 10-3/4 x

10-3/4 (27.31 cm x 27.31 cm) for a square duct. THE DUCT SIZE MUST NOT

BE REDUCED ANYWHERE DOWN STREAM OF THE DRYER.

IMPORTANT: Exhaust back pressure measured by a manometer at each tumbler (basket) exhaust

duct area should not exceed 0.3 inches of water column (0.74 mb).

It is suggested that the duct work from each dryer (minimum of 12-inches [30.48 cm] for a single dryer) not exceed 15 feet (4.57 meters) with no more than three (3) elbows (including dryer connection). If the duct

work exceeds 15 feet (4.57 meters) or has numerous elbows, the cross-sectional area of the duct work must be increased in proportion to the length and number of elbows in it. In calculating duct size, the crosssectional area of a square or rectangular duct must be increased twenty percent (20%) for each additional 20 feet (6.09 meters). The diameter of a round exhaust duct should be increased ten percent (10%) for each additional 15 feet (4.57 meters). Each 90º elbow is equivalent to an additional 30 feet (9.14 meters), and each 45º elbow is equivalent to an additional 15 feet (4.57 meters).

IMPORTANT: For extended duct work runs, the cross section area of the duct work can only be

increased to an extent. When the duct work approaches the maximum limits as noted in this manual, a professional heating venting air conditioning (HVAC) firm should be consulted for proper venting information.

ALL duct work should be smooth inside with no projections from sheet metal screws or other obstructions which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to be connected. ALL duct work joints must be taped to prevent moisture and lint from escaping into the building. Inspection doors should be installed at strategic points in the exhaust duct work for periodic inspection and clean-out of lint from the duct work.

NOTE: Where the exhaust duct passes through a wall, ceiling, or roof made of combustible materials,

the opening must be 2-inches (5.08 cm) larger (all the way around) than the duct. The duct must be centered within this opening.

a. Outside Duct Work Protection

1) To protect the outside end of horizontal duct work from the weather, a 90° elbow bent downward

IMPORTANT: DO NOT use screens or caps on the outside of opening of exhaust duct work.

3. Multiple Dryer (Common) Venting

If it

is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be

channeled into a common main duct. The individual ducts should enter the bottom or side of the main duct at an angle not more than 45° in the direction of the flow and should be spaced at least 48-3/4 inches (123.83 centimeters) apart. The main duct should be tapered with the diameter increasing before each individual 12-inch (30.48 cm) - minimum for each dryer - duct is added.

IMPORTANT: The ML-130DR is not provided with a back draft damper. When exhausted into a

multiple (common) exhaust line, a back draft damper must be installed at each dryer duct.

IMPORTANT: No more than four (4) dryers should be connected to one (1) main common duct.

The main duct may be any shape or cross-sectional area, so long as the minimum cross section area is provided. The illustration on the bottom of page 19 shows the minimum cross section area for multiple dryer round or square venting. These figures must be increased 10 square inches (64.52 square centimeters) when rectangular main ducting is used, and the ratio of duct width to depth should not be greater than 31/2 to 1. These figures must be increased in proportion if the main duct run to the last dryer to where it exhausts to the outdoors is unusually long (over 20 feet [6.09 meters]) or has numerous elbows (more than two [2]) in it. In calculating duct work size, the cross-sectional area of a square or rectangular duct must be increased twenty percent (20%) for each additional 20 feet (6.09 meters). The diameter of a round exhaust must be increased ten (10) percent for each additional 20 feet (6.09 meters). Each 90° elbow is equivalent to an additional 30 feet (9.14 meters) and each 45° elbow is equivalent to an additional 15 feet (4.57 meters).

IMPORTANT: For extended duct work runs, the cross section area of the duct work can only be

increased to an extent. Maximum proportional duct work runs cannot exceed 20 feet (6.09 meters) more than the original limitations of 20 feet (6.09 meters) with two (2) elbows. When the duct work approaches the maximum limits as noted in this manual, a professional heating venting air conditioning (HVAC) firm should be consulted for proper venting information.

IMPORTANT: Exhaust back pressure measured by a manometer in the exhaust duct should not

exceed 0.3 inches of water column (0.74 mb).

The duct work should be smooth inside with no projections from sheet metal screws or other obstructions which will collect lint. When adding ducts, the duct to be added should overlap the duct to which it is to be connected. building. Inspection doors should be installed at strategic points in the exhaust duct work for periodic inspection and clean-out of lint from the duct work.

ALL duct work joints must be taped to prevent moisture and lint from escaping into the

NOTE: Where the exhaust duct passes through a wall, ceiling, or roof made of combustible materials,

the opening must be 2-inches (5.08 cm) larger (all the way around) than the duct. The duct must be centered within this duct.

a. Outside Duct Work Protection

1) To protect the outside end of horizontal duct work from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the exhaust duct work travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward. In either case, allow at least twice the diameter of the duct between the duct opening and the nearest obstruction.

IMPORTANT: DO NOT use screens or caps on the outside of opening of exhaust duct work.

F. ELECTRICAL INFORMATION

1. Electrical Requirements

It is your responsibility to have electrician to assure that the electrical installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, conform to the applicable requirements of the National Electrical Code ANSI NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

ALL electrical connections made by a properly licensed and competent

ALL electrical connections, material, and workmanship must

IMPORTANT: Failure to comply with these codes or ordinances, and/or the requirements stipulated

in this manual can result in personal injury or component failure.

NOTE: Component failure due to improper installation will VOID THE WARRANTY.

Each dryer should be connected to an independently protected branch circuit. The dryer must be connected with copper wire only. DO NOT use aluminum wire which could cause a fire hazard. The copper conductor wire/cable must be of proper ampacity and insulation in accordance with electric codes for making ALL service connections.

NOTE: The use of aluminum wire will VOID THE WARRANTY.

NOTE: Wiring diagrams are affixed to the inside at the top front control door and the rear upper back

guard/panel.

Electrical Service Specifications

MLG-130D R ( Ga s )

ELECTRIC SERVICE SPECIFICA TIONS

IMPORTANT: 208 VAC and 230 VAC ARE NOT THE SAME. When ordering, specify exac t voltage.

NOTE

: A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK 5 ONLY.

B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct breaker

size according to appliance amp draw rating and type of breaker used.

C. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.

SERVICE

VOLTAGE

208 3ø 3/4 13 --- #12 20 25 230 3ø 3 13 15 #12 20 25

380 3ø 3/4 8 8 #12 12 15 416 3ø 3/4 --- 8 #14 12 15 440 3ø 3/4 8 10 #14 12 15 460 3ø 3/4 7 --- #14 12 15 480 3ø 3/4 7 --- #14 12 15

PHASE

WIRE

SERVICE

APPROX.

AMP DRAW

60 Hz 50 Hz

MINIMUM

WIRE SIZE*

(PER DRYER)

FUSING

Dual Element

Time D e la y

CIRCUIT

BREAKER

* AWG Stranded Type Wire...for individual lengths less than 100 feet (31 meters).

(Motor lead type wire is recommended.)

IMPORTANT: The dryer must be connected to the electric supply shown on the data label that is

affixed to the left wall, behind the upper control door area (refer to the illustration on page 9). In the case of 208 VAC or 230 VAC, the supply voltage must match the electric service specifications of the data label exactly.

WARNING: 208 VAC and 230 VAC ARE NOT THE SAME. Any damage done to dryer

components due to improper voltage connections will automatically VOID THE WARRANTY.

NOTE: ADC reserves the right to make changes in specifications at any time, without notice or

obligation.

3. Electrical Connections

NOTE: A wire diagram is located in the front electrical control box for connection data.

The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, and L3), GROUND, and in the case of 4 wire service, the NEUTRAL. Providing local codes permit, power connections to the dryer can be made by use of a flexible underwriters laboratory list cord/pigtail (wire must conform to ratings of the dryer), or the dryer can be hard wired directly to the service breaker. In strain relief must be used where the wire(s) enter the dryer electrical service (relay) box.

ALL cases, a

These electrical connections are made at the terminal block located in the electric service/relay box at the rear, upper left hand corner of the dryer. To gain access into this service box, the service cover must be removed.

NOTE: A CIRCUIT SERVING EACH DRYER MUST BE PROVIDED.

Grounding

Grounding (earth) connections must be provided and installed in accordance with state and local codes. In the absence of these codes, grounding must conform to applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION. The ground connection may be to a proven earth ground at the location service panel.

NOTE: A grounding connection (terminal lug) is provided in the dryers electrical service/relay box at

the rear.

For added personal safety, when possible, it is suggested that a separate ground wire (sized per local codes) be connected from the ground connection of the dryer to a grounded cold water pipe. DO NOT ground to a gas pipe or hot water pipe. The grounded cold water pipe must have metal to metal connection way to the electrical ground. If there are any non-metallic interruptions, such as, a meter, pump, plastic, rubber, or other insulating connectors, they must be jumped out with no. 4 copper wire and securely clamped to bare metal at both ends.

ALL the

IMPORTANT: For personal safety and proper operation, the dryer must be grounded. For proper

operation of the microprocessor (computer), an earth (zero) ground is required.

NOTE: Grounding via metallic electrical conduit (pipe) is not recommended.

G. GAS INFORMATION

It is your responsibility to have ALL plumbing connections made by a qualified professional to assure that the gas plumbing installation is adequate and conforms with local and state regulations or codes. In the absence of such codes, ALL plumbing connections, materials, and workmanship must conform to the applicable requirements of the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION.

IMPORTANT: Failure to comply with these codes or ordinances, and/or the requirements stipulated

in this manual, can result in personal injury and improper operation of the dryer.

The dryer and its individual shut-off valves must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa). The dryer must be isolated from the gas supply piping system by closing its individual manual shut-off valve during any pressure test of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa).

IMPORTANT: Failure to isolate or disconnect dryer from supply as noted can cause irreparable

damage to the gas valve which will VOID THE WARRANTY.

WARNING: FIRE or EXPLOSION COULD RESULT.

1. Gas Supply

The gas dryer installation must meet the American National Standard...National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1 M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION, as well as local codes and ordinances and must be done by a qualified professional.

NOTE: Undersized gas piping will result in ignition problems, slow drying, increased use of energy, and

can create a safety hazard.

The dryer must be connected to the type of heat/gas indicated on the data label affixed to the left wall, behind the upper control door area (refer to the illustration on page 9). If this information does not agree with the type of gas available, DO NOT OPERATE THE DRYER. Contact the distributor who sold the dryer or the ADC factory.

IMPORTANT: Any burner changes or conversions must be made by a qualified professional.

The input ratings shown on the dryer data label are for elevations up to 2,000 feet (609.6 meters), unless elevation requirements of over 2,000 feet (609.6 meters) were specified at the time the dryer order was placed with the factory. The adjustment or conversion of dryers in the field for elevations over 2,000 feet (609.6 meters) are made by changing each burner orifice. If this conversion is necessary, contact the distributor who sold the dryer or contact the ADC factory.

2. Technical Data

a. Gas Specifications

Type of Gas

Natural Liquid Propane G as

Manifold Pressure* 3.5 inches W.C. 8.7 mb 10.5 inches W.C. 26.1 mb Inline Pressure 6.0 inches W.C.

Sh ade d a rea s are stated in metric e qu iva lents

* Measured at the gas valve pressure tap when the gas valve is on.

b. Gas Connections:

Inlet connection ---------- 1-inch N.P.T. Inlet supply size---------- 1-inch N.P.T. (minimum)

Btu/hr input (per dryer)- 300,000 (75,600 kcal/hr)

14.9 mb

10.5 inches W.C.

26.1 mb

1) Natural Gas

Regulation is controlled by the dryers gas valves internal regulator. Incoming supply pressure must be consistent between a minimum of 6.0 inches (14.9 mb) and a maximum of 12.0 inches water column (W.C.) - 29.9 mb - pressure.

2) Liquid Propane (L.P.) Gas

Dryers made for use with L.P. gas have the gas valves internal pressure regulator blocked open so that the gas pressure must be regulated upstream of the dryer. The pressure measured at each gas valve pressure tap must be a consistent 10.5 inches water column (W.C.) - 26.1 mb. There is no regulator or regulation provided in an L.P. dryer. The water column pressure must be regulated at the source (L.P. tank) or an external regulator must be added to each dryer.

Type of Gas

MODEL

NUMBER

ML-130DR 300,000

Sha ded ar ea is state d in metric eq uiva len t

* D.M.S. (D rill Material Size) equivalents are as follows:

Natural Gas ............... #12 = .1890” (4.8006 mm)

Liquid Propane Gas .. #33 = .1130” (2.8702 mm)

Piping/Connections

BTU

Per Hour

Rating

kcal/hr

Rating

75,600 3

Qty. D.M.S.*

Natural Liquid Propane

Part

Number

140863 3 #33 140855 882626

Qty. D.M.S.*

Part

Number

ALL components/materials must conform to National Gas Code Specifications, or in Canada, the Canadian Installation Codes (for General Installation and Plumbing). It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of ALL the appliance BTUs being supplied.

The dryer is provided with a 1-inch N.P.T. inlet pipe connection extending out the back area of the burner box. The minimum pipe size (supply line) to the dryer is 1-inch N.P.T. For ease servicing, the gas supply line of each dryer must have its own shut-off valve.

The size of the main gas supply line (header) will vary depending on the distance this line travels from the gas meter or, in the case of L.P. (liquid propane) gas, the supply tank, other gas-operated appliances on the same line, etc. Specific information regarding supply line size should be determined by the gas supplier.

Conversion

Part N umber

L.P.

Kit

NOTE: Undersized gas supply piping can create a low or inconsistent pressure which will result in

erratic operation of the burner ignition system.

Consistent gas pressure is essential at ALL gas connections. It is recommended that a 1-inch (2.54 cm) pipe gas loop be installed in the supply line serving a bank of dryers. An in-line pressure regulator must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 10.5 inches of water column (W.C.) - 26.1 mb - pressure.

NOTE: A water column (W.C.) test pressure of 3.5 inches (8.7 mb) for natural gas and 10.5 inches

(26.1 mb) for L.P. (liquid propane) dryers is required at the gas valve pressure tap of each dryer for proper and safe operation.

A 1/8 N.P.T. plugged tap, accessible for a test gauge connection, must be installed in the main gas supply line immediately upstream of each dryer.

IMPORTANT: Pipe joint compounds that resist the action of natural gas and L.P. gas must be used.

IMPORTANT: Test ALL connections for leaks by brushing on a soapy water solution (liquid

detergent works well).

WARNING: NEVER TEST FOR LEAKS WITH A FLAME!!!

ALL components/materials must conform to National Gas Code Specifications ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/ CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION.

It is important that gas pressure regulators meet applicable pressure requirements and that gas meters be rated for the total amount of

ALL the appliance BTUs being supplied.

IMPORTANT: The dryer and its individual shut-off valve must be disconnected from the gas supply

piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa).

NOTE: The dryer must be isolated from the gas supply piping system by closing its individual manual

shut-off valve during any pressure test of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa).

H. PREPARATION FOR OPERATION/START-UP

The following items should be checked before attempting to operate the dryer:

1. Read

2. Check incoming supply voltage to be sure that it is the same as indicated on the dryer data label located in

3. Check to assure that the dryer is connected to the type of heat/gas indicated on the dryer data label.

4. The sail switch damper assembly was installed and pre-adjusted at the factory prior to shipping. However,

5. Be sure that

6. Be sure

7. Check

8. Be sure the lint drawer is securely in place.

ALL CAUTION, WARNING, and DIRECTION labels attached to the dryer.

the front top console area as shown in the illustration on THE SUPPLY VOLTAGE MUST MATCH THE ELECTRIC SERVICE EXACTLY.

each sail switch adjustment must be checked to assure that this important safety control is functioning.

ALL gas shut-off valves are in the open position.

ALL back panels (guards) and electric box covers have been replaced.

ALL service doors to assure that they are closed and secured in place.

page 9. In the case of 208 VAC or 230 VAC

NOTE: LINT DRAWER MUST BE ALL THE WAY IN PLACE TO ACTIVATE THE

SAFETY SWITCH OTHERWISE THE DRYER WILL NOT START.

9. Rotate the tumbler (basket/drum) by hand to be sure it moves freely.

10. Check bolts, nuts, screws, terminals, and fittings for security.

11. Check tumbler bearing set screws to insure they are ALL tight.

I. PREOPERATIONAL TESTS

ALL dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or

due to marginal location (installation) conditions.

1. Turn on electric power to the dryer.

2. Make sure the main door is closed and the lint drawer is securely in place.

3. Refer to the Operating Instructions for starting your particular model dryer.

4. Check to insure that the tumbler (basket) starts in the clockwise (CW) direction. Additionally, check the direction of the blower motor impellor (fan) to insure that the impellor (fan) rotates in the clockwise (CW) direction as viewed from the front. If it is, the phasing is correct. If the phasing is incorrect, reverse two (2) of the leads at L1, L2, or L3 of the power supply connections made to the dryer.

IMPORTANT: Dryer blower motor impellor/fan as viewed from the front must turn in the clockwise

(CW) direction, otherwise the dryer efficiency will be drastically reduced and premature component failure can result.

5. Heat Circuit Operational Test

a. Gas Models

1) When the dryer is first started (during initial start-up), the burner has a tendency not to ignite on the first attempt. This is because the gas supply piping is filled with air, so it may take a few minutes for this air to be purged from the lines.

2) The dryer is equipped with a Hot Surface Ignition (HSI) system which has internal diagnostics. If ignition is not established after three (3) attempts, the heat circuit HSI module will LOCKOUT until it is manually reset. To reset the HSI system, open and close the main door and restart the dryer (press the ENTER/START key).

NOTE: During the purging period, check to be sure that ALL gas shut-off valves are open.

3) Once ignition is established, a gas pressure test should be taken at the gas valve pressure tap of each dryer to assure that the water column (W.C.) pressure is correct and consistent.

NOTE: Water column pressure requirements (measured at the gas valve pressure tap)...

Natural Gas ---- 3.5 Inches W.C. (8.7 mb). L.P. Gas-------- 10.5 Inches W.C. (26.1 mb).

IMPORTANT: There is no regulator provided in an L.P. dryer. The water column (W.C.) pressure

must be regulated at the source (L.P. tank) or an external regulator must be added to each dryer.

6. Make a complete operational check of ALL safety-related circuits (i.e., lint drawer switch, and sail switch

on gas models).

NOTE: To check for proper sail switch operation, open the main door and while holding main door

switch plunger in, start the dryer. The dryer should start but the heat circuit should not be activated (on). If the heat (burner) does activate, shut the dryer off and make the necessary adjustments.

7. A reversing tumbler (basket) dryer should never be operated with less than a 60 lb. (2.72 kg) load (dry

weight). The size of the load will affect the coast-down and dwell (stop) times. The tumbler (basket) must come to a complete stop before starting in the opposite direction.

a. Microprocessor (computer) Dryer Models

1) Spin and stop are not adjustable in the Automatic Mode and have been preprogrammed into the microprocessor controller (computer) for 150-seconds spin time in the forward direction and 120-seconds in the reverse direction with a 5-second dwell (stop) time.

2) Spin and stop times are adjustable in the Manual (timed) Mode.

b. Dual Timer Dryer Models

1) Both spin time and stop (dwell) time are adjustable (refer to

page 36).

BASKET COATING The tumbler (basket) is treated with a protective coating. We suggest dampening old garments or cloth material with a solution of water and non-flammable mild detergent and tumbling them in the tumbler (basket) to remove this coating.

8. Each dryer should be operated through one (1) complete cycle to assure that no further adjustments are necessary and that ALL components are functioning properly.

9. Make a complete operational check of ALL operating controls.

a. Microprocessor controller (computer) programs/selections...

1) Each microprocessor controller (computer) has been preprogrammed by the factory with the most commonly used parameter (program) selections. If computer changes are required, refer to the computer programming manual which was shipped with the dryer.

b. Dual Timer check...

1) Heating Timer

2) Cool Down Timer

3) Temperature Selection Switch

J. OPERATING INSTRUCTIONS

NOTE: Before attempting to start the dryer be sure that the main door is closed and the lint drawer is

securely in place.

1. To start the dryer:

a. Microprocessor (computer) dryers...

1) L.E.D. (light emitting diode) display will read REAdY (meaning no cycle in progress).

2) Press the letter on the keyboard (touchpad) corresponding to the cycle desired (i.e., Key E)...

a) The dryer will then start (rotate).

3) L.E.D. display will now show Cycle In Progress and Cycle Status meaning that the dryer is in the drying cycle (dry mode for 30 minutes) and count downwards in minutes.

NOTE: Pressing keyboard (touchpad) key A, B, C, D, and F will also start the dryer. The

six (6) preprogrammed drying cycles (A through F) have been stored in the microprocessor controller (computer) memory. Refer to the Programming Manual supplied with the dryer for more specific operating instructions.

NOTE: The dryer can be stopped at any time by opening the main door or by pressing the CLEAR/

STOP red key. To restart the dryer, press the ENTER/START green key or a preprogrammed cycle key (i.e., E).

NOTE: Selection (settings) changes can be made at any time during the drying cycle by pressing the

CLEAR/STOP

red key twice. The L.E.D. (light emitting diode) display will return to

REAdY at which time a new cycle selection can be made.

b. Dual Timer Dryers

1) Select Drying Time and Cool Down Time desired...

a) Turn Heat Timer clockwise (CW) to the desired time (i.e., 1 minute to 60 minutes)

b) Turn Cool Down Timer clockwise (CW) to the desired time (i.e., 0 minute to 30 minutes)

2) Select Drying Temperature (HI TEMP, LO TEMP, or PERM PRESS).

3) Push Push To Start Switch...

a) Dryer will now start.

4) To stop the dryer, open the main door.

K. SHUT DOWN INSTRUCTIONS

If the dryer is to be shut down (taken out of service) for a period of time, the following must be performed:

1. Discontinue power to the dryer either at the external disconnect switch or the circuit breaker.

2. Discontinue the heat supply:

a. SHUT OFF external gas supply shut-off valve.

b. SHUT OFF internal gas supply shut-off valve located in the gas valve burner area.

SECTION IV

SERVICE/PARTS INFORMATION

A. SERVICE

1. Service must be performed by a qualified trained technician, service agency, or gas supplier. If service is required, contact the distributor from whom the ADC equipment was purchased. If the distributor be contacted or is unknown, contact the ADC Service Department for a distributor in your area.

NOTE: When contacting the ADC Service Department, be sure to give them the correct model

number and serial number so that your inquiry is handled in an expeditious manner.

B. PARTS

1. Replacement parts should be purchased from the distributor from whom the ADC equipment was purchased. If the distributor cannot be contacted or is unknown, contact the ADC Parts Department for a distributor in your area. Parts may also be purchased directly from the factory by calling the ADC Parts Department at (508) 678-9000 or you may FAX in your order at (508) 678-9447.

cannot

NOTE: When ordering replacement parts from the ADC dealer or the ADC factory be sure to give

them the correct model number and serial number so that your parts order can be processed in an expeditious manner.

SECTION V

WARRANTY INFORMATION

A. RETURNING WARRANTY CARD(S)

1. Before any dryer leaves the ADC factory test area, a warranty card is placed on the back side of the main

door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.

a. If a warranty card did not come with your dryer, contact the ADC Warranty Department or ADC

Service Department at (508) 678-9000.

B. PARTS

For a copy of the ADC commercial warranty covering your particular dryer(s), contact the ADC distributor from whom you purchased the equipment and request a dryer warranty form. If the distributor cannot be contacted or is unknown, warranty information can be obtained from the factory by contacting the ADC Warranty Department at (508) 678-9000.

NOTE: Whenever contacting the ADC factory for warranty information, be sure to have the dryers

model number and serial number available so that your inquiry can be handled in an

expeditious manner.

C. RETURNING WARRANTY PART(S)

ALL dryer or parts warranty claims or inquires should be addressed to the ADC Warranty Parts Department. To expedite processing, the following procedures must be followed:

1. No parts are to be returned to ADC without prior written authorization (Return Material Authorization)

from the factory.

NOTE: An R.M.A. (Return Material Authorization) is valid for only sixty (60) days from date of

issue.

a. The R.M.A. issued by the factory, as well as any other correspondence pertaining to the returned

part(s), must be included inside the package with the failed merchandise.

2. Each part must be tagged with the following information:

Model number and serial number of the dryer from which part was removed.

b. Nature of failure (be specific).

c. Date of dryer installation.

d. Date of part failure.

e. Specify whether the part(s) being returned is for a replacement, a credit, or a refund.

NOTE: If a part is marked for a credit or a refund, the invoice number covering the purchase of the

replacement part must be provided.

NOTE: Warranty tags (ADC Part No. 450064) are available at no charge from ADC upon request.

3. The company returning the part(s) must clearly note the complete company name and address on the outside of the package.

4. ALL returns must be properly packaged to insure that they are not damaged in transit. Damage claims

are the responsibility of the shipper.

IMPORTANT: No replacements, credits, or refunds will be issued for merchandise damaged in

transit.

5. ALL returns should be shipped to the ADC factory in such a manner that they are insured and a proof of delivery can be obtained by the sender.

6. Shipping charges are not the responsibility of ADC. ALL returns should be prepaid to the factory. Any C.O.D. or COLLECT returns will not be accepted.

IMPORTANT: No replacements, credits, or refunds will be issued if the claim cannot be processed

due to insufficient information. The party filing the claim will be notified in writing, either by FAX or CERTIFIED MAIL - Return Receipt Requested, as to the information necessary to process claim. If reply is not received by the ADC Warranty Department within thirty (30) days from the FAX/letter date, then no replacement, credit, or refund will be issued, and the merchandise will be discarded.

SECTION VI

ROUTINE MAINTENANCE

A. CLEANING

A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the duct work system. The frequency of cleaning can best be determined from experience at each location. Maximum operating efficiency is dependent upon proper air circulation. The accumulation of lint can restrict this airflow. If the guidelines in this section are met, an ADC dryer will provide many years of efficient, trouble-free, and - most importantly - safe operation.

WARNING: LINT FROM MOST FABRICS IS HIGHLY COMBUSTIBLE. THE

ACCUMULATION OF LINT CAN CREATE A POTENTIAL FIRE HAZARD.

WARNING: KEEP DRYER AREA CLEAR and FREE FROM COMBUSTIBLE

MATERIALS, GASOLINE, and OTHER FLAMMABLE VAPORS and LIQUIDS.

NOTE: REMOVE POWER FROM THE MACHINE BEFORE PERFORMING ANY

MAINTENANCE IN THE MACHINE (cleaning the lint drawers and lint screens are the only exceptions).

NOTE: Suggested time intervals shown are for average usage which is considered six (6) to eight (8)

operational (running) hours per day.

CLEAN LINT FROM LINT DRAWER/SCREEN EVERY THIRD or FOURTH LOAD.

NOTE: The frequency of cleaning the lint screens can best be determined from experience at each

location.

WEEKLY

Clean lint accumulation from the lint chamber, thermostat, and microprocessor temperature sensor (sensor bracket) area.

WARNING: TO AVOID HAZARD OF ELECTRICAL SHOCK, DISCONTINUE

ELECTRICAL POWER SUPPLY TO THE DRYER.

90 DAYS

Remove lint from around tumbler (basket), drive motors, and surrounding areas. Remove lint from the gas valve burner area with a dusting brush or vacuum cleaner attachment.

NOTE: To prevent damage, avoid cleaning and/or touching the Hot Surface Ignitor.

Remove lint accumulation from inside the control box and at rear area behind the control box.

Impellor (fan/blower) shaft bearings should be lubricated using Shell Alvania grease NLGI 2 or its equivalent. Generically, this grease would be described as an NLGI grade 2 multipurpose industrial grease with a lithium thickener and mineral base oil.

6 MONTHS

Inspect and remove lint accumulation in customer furnished exhaust duct work system and from dryers internal exhaust ducting.

NOTE: THE ACCUMULATION OF LINT IN THE EXHAUST DUCT WORK CAN

CREATE A POTENTIAL FIRE HAZARD.

NOTE: DO NOT OBSTRUCT THE FLOW OF COMBUSTION and VENTILATION AIR.

CHECK CUSTOMER FURNISHED BACK DRAFT DAMPERS IN THE EXHAUST DUCT WORK. INSPECT and REMOVE ANY LINT ACCUMULATION WHICH CAN CAUSE THE DAMPER TO BIND or STICK.

NOTE: A back draft damper that is sticking partially closed can result in slow drying and shut down of

the heat circuit safety switches or thermostats.

NOTE: When cleaning the dryer cabinet(s), avoid using harsh abrasives. A product intended for the

cleaning of appliances is recommended.

B. ADJUSTMENTS

7 DAYS AFTER INSTALLATION and EVERY 6 MONTHS THEREAFTER

Inspect bolts, nuts, screws, (bearing set screws), nonpermanent gas connections (i.e., unions, shut-off valves, orifices), and grounding connections. Fan (impellor) V-belts, along with the motor and drive chains should be examined and replaced if necessary. Tighten loose V-belts when necessary. Complete operational check of controls and valves. Complete operational check of ALL safety devices (i.e., door switches, lint drawer switch, sail switch, burner and hi-limit thermostats).

C. LUBRICATION

The fan shaft bearings should be lubricated every three (3) months. Use Shell Alvania grease NLGI grade 2 or its equivalent. Generically, this grease would be described as an NLGI grade 2 multipurpose industrial grease with a lithium thickener and mineral base oil. Lubrication is necessary. The motor bearings...and under normal/ most conditions the tumbler bearings are permanently lubricated. It is physically possible to re-lubricate the tumbler bearings if you choose to do so even though this practice may not be necessary. Use Shell Alvania grease NLGI grade 2 or its equivalent. Generically, this grease would be described as an NLGI grade 2 multipurpose industrial grease with a lithium thickener and mineral base oil. The tumbler bearings used in the dryer DO NOT have a grease fitting. Provisions are made in the bearings housing for the addition of a grease fitting which can be obtained elsewhere, or from ADC by ordering kit P/N 882159 (includes 2 fittings).

SECTION VII

REVERSING TIMER SPIN/DWELL ADJUSTMENTS

Timer models have an electronic reversing timer in the electrical service box which is located in the upper left rear area of the dryer.

Both the Dwell (stop) Time and the tumbler (basket) Spin Time are adjustable by mode selection switches located on the electronic timer (as noted in the illustration below).

TIMING LEGEND

SPIN TIME

Switch Position Number 1 2 3 4 5

Time in Seconds* 30 60 90 120 150

DWELL (Stop) TIME

Switch Position Number 1 2 3 4 5

Time in Seconds* 5 6 8 10 12

* Values shown are +/- 1 second.

SECTION VIII

PROCEDURE FOR FUNCTIONAL CHECK

OF REPLACEMENT COMPONENTS

1. Microprocessor (computer) Board

a. Upon completing installation of the replacement microprocessor (computer) board, reestablish power to

the dryer.

b. Start the drying cycle by pressing any of the preset cycles in letters A-F.

c. Verify that the motor(s) and the heat indicator dots, in the microprocessor (computer) L.E.D. (light

emitting diode) display are on. (Refer to the illustration below.)

1) Tumbler (Basket) in Forward Mode (clockwise [CW]) indicator

2) Tumbler (Basket) in Reverse Mode (counterclockwise [CCW]) indicator

3) Heat on indicator

4) On indicator (dryer is in Operation Mode)

5) Air Jet indicator

d. Verify that the motor(s) heat, and door indicator lights on the back side of the microprocessor (computer)

board are lit. (Refer to the illustration below.)

1) FAN (Blower) L.E.D. indicator

2) FOR (Forward) output L.E.D. indicator

3) Rev (Reverse) output L.E.D. indicator

4) Air (Air Jet) output L.E.D. indicator

5) HT 1 (Heat) output L.E.D. indicator

6) Fuse (Main Fuse) input L.E.D. indicator

7) Lint (Lint Door) input L.E.D. indicator

8) Main (Main Door) input L.E.D. indicator

9) Drum (Tumbler [Basket] Hi-Limit) input L.E.D. indicator

10) Sail (Sail Switch) input L.E.D. indicator

11) Burn (Burner Hi-Limit) input L.E.D. indicator

12) Flame (Burner Control Failure) input L.E.D. indicator

13) Power Supply

e. Open main door. The dryer must stop and

(light emitting diode) display must go out. (Refer to illustration on page 37.)

f. Try to restart the dryer with the main door open.

g. The microprocessor (computer) boards L.E.D. display must read MAIN dOOR.

h. Close the main door and restart the dryer.

i. Functional check of microprocessor (computer) board is complete.

2. Hot Surface Ignition (HSI) System

a. Upon completing installation of the

replacement Hot Surface Ignition (HSI) module, reestablish power to the dryer.

b. The HSI modules red indicator

light will light for up to approximately 5-seconds (self check routine).

ALL indicator dots of the microprocessor (computer) L.E.D.

If the HSI modules red indicator light stays on or flashes continuously, then the HSI module is wired incorrectly or has failed.

c. Start the drying cycle.

d. The hot surface ignitor will turn on, and a few seconds later the gas valve

approximately 4-seconds the hot surface ignitor will shut off. Ignition (flame) should now be established.

e. With the burner flame on, remove the flame sensor wire from the S2 terminal of the HSI module. The

burner flame must shut off immediately.

f. Stop the drying cycle, with the flame sensor wire still removed, restart the drying cycle.

g. The hot surface ignitor will turn on, and after a few seconds later the gas valve will be energized and the

hot surface ignitor will shut off. Ignition (flame) should be evident for approximately 7-seconds and then shut off.

h. The HSI module will attempt two (2) additional ignition trials after which the HSI module will lockout and

the red indicator light will flash continuously.

will be energized. After

i. Functional check of the Hot Surface Ignition (HSI) Module is complete.

1) Replace the flame sensor wire from the S2 terminal to the HSI module.

SECTION IX

BURNER and LINT (TUMBLER) CHAMBER MANUAL RESET HI-LIMIT INSTRUCTIONS

(FOR PHASE 6 MODELS)

This dryer was manufactured with a manual reset burner hi-limit (gas models only) and tumbler/lint chamber hi-limit thermostat which is monitored by the Phase 6 computer. If either manual reset thermostat is open prior to start of the drying cycle, the dryer will start momentarily and then shut down, the Phase 6 computer will display an error code with an audio indication. If the tumbler/lint chamber hi-limit thermostat is open, the display will read dRUM SAFETY FAIL. If the burner hi-limit thermostat is open, the display will read bURNER SAFETY FAIL.

If either manual reset hi-limit thermostat opens during a drying cycle, the display will show the applicable error code described above along with an audio indication. If the drum temperature is above 100º F (38º C), the dryer will continue to run with no heat for three (3) minutes or until the drum temperature has flattened below 100º F (38º C). The clear/stop button on the Phase 6 keyboard (touchpad) must be pressed to clear the error condition. The open manual reset hi-limit thermostat must be reset manually prior to the start of the next cycle.

This hi-temperature condition may be caused due to a restricted exhaust, poor airflow or improper burner operation.

The location of the burner hi-limit is on the right side of the burner box and the tumbler hi-limit is located in the lint chamber area.

WARNING: Discontinue power to dryer before attempting to reset hi-limit.

IMPORTANT

This dryer is equipped with a burner hilimit and tumbler/lint chamber hi-limit thermostat which must be reset manually.

WARNING: Discontinue power to dryer before attempting to reset hi-limit.

ADC P/N: 114093

ADC 113130 1- 03/28/00-25

American Dryer Corp MLG-130DR-HSI User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
