American Dryer SL3131, SL2020, SL2929 User Manual

SL2020 / SL2929 / SL3131

Installation/Operator Manual

WARNING: For your safety the information in this manual must be followed to minimize the risk of fire or explosion and to prevent property damage, personal injury or death.

— Do not store or use gasoline or other

flammable vapors and liquids in the vicinity of this or any other appliance.

— WHA T T O DO IF YOU SMELL GAS:

●

Do not try to light any appliance.

●

Do not touch any electrical switch; do not use any phone in your building.

●

Clear the room, building or area of all occupants.

●

Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

●

If you cannot reach your gas supplier, call the fire dep artment.

— Installation and service must be

performed by a qualified installer , service agency or the gas supplier .

A VERTISSEMENT : Assurez-vous de bien suivre les instructions données dans cette notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter tout dommage matériel, toute blessure ou la mort.

—Ne pas entreposer ni utiliser d’essence

ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil.

—QUE F AIRE SI VOUS SENTEZ UNE

ODEUR DE GAZ:

●

Ne pas tenter d’allumer d’appareils.

●

Ne touchez à aucun interrupteur . Ne pas vous servir des téléphones se trouvant dans le bâtiment.

●

Évacuez la pièce, le bâtiment ou la zone.

●

Appelez immédiatement votre fournisseur de gaz depuis un voisin. Suivez les instructions du fournisseur .

●

Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le service des incendies.

—L’installation et l’entretien doivent être

assurés par un installateur ou un service d’entretien qualifié ou par le fournisseur de gaz.

American Dryer Corporation

88 Currant Road

Fall River MA 02720-4781 USA

T elephone: +1 (508) 678-9000 / Fax: +1 (508) 678-9447

e-mail: techsupport@amdry .com

www.amdry.com

ADC Part No. 113401 -18

Retain This Manual in a Safe Place for Future Reference

This product embodies advanced concepts in engineering, design, and safety. If this product is properly maintained, it will provide many years of safe, efficient, and trouble free operation.

Only qualified technicians should service this equipment. OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation

manual included with the dryer. The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.

FOR Y OUR SAFETY

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves the right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or discontinue models. The illustrations included in this manual may not depict your particular dryer exactly .

POUR VO TRE SÉCURITÉ

Ne pas entreposer ni utiliser d’essence ni d’autres vapeurs ou liquides inflammables à proximité de cet appareil ou de tout autre appareil.

IMPORTANT

For your convenience, log the following information:

DATE OF PURCHASE __________________________________________________ MODEL NO. ________________________

RESELLER’S NAME ______________________________________________________________________________________

Serial Number(s) ________________________________________________________________________________________

_______________________________________________________________________________________________________

Replacement parts can be obtained from your reseller or the ADC factory. When ordering replacement parts from the factory , you can FAX your order to ADC at +1 (508) 678-9447 or telephone your order directly to the ADC Parts Department at +1 (508) 678-9000. Please specify the dryer model number and serial number in addition to the description and part number, so that your order is processed accurately and promptly.

“IMPORT ANT NO TE T O PURCHASER”

Information must be obtained from your local gas supplier on the instructions to be followed if the user smells gas. These instructions must be posted in a prominent location near the dryer.

2 American Dryer Corp. 113401-18

▲ WARNING

T able of Contents ________

Proposition 65

Use of this product could expose you to substances

from fuel combustion that contain chemicals

known to the State of California to cause cancer,

birth defects and other reproductive harm.

IMPORTANT

Y ou must disconnect and lockout the electric supply and the gas supply or the steam supply before any covers or guards are removed from the machine to allow access for cleaning, adjusting, installation, or testing of any equipment per OSHA standards.

Please observe all safety precautions displayed on the equipment and/or specified in the installation manual included with the dryer.

Before installation, check that the local distribution conditions, nature of gas and pressure, and adjustment of the appliances are compatible.

CAUTION

Dryer(s) should never be left unattended while in operation.

“Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper operation.”

«Attention: Au moment de l’entretien des commandes, étiquetez tous les fils avant de les débrancher. Des erreurs de câblage peuvent entraîner un fonctionnement inadéquat et dangereux.»

Safety Precautions ................................4

SL2020 Specifications ..........................6

SL2929 Specifications ..........................8

SL3131 Specifications ........................10

Installation Procedures ......................12

Location Requirements......................................... 12

Unpacking/Setting Up .......................................... 1 2

Dryer Enclosure Requirements............................. 12

Fresh Air Supply Requirements............................ 13

Exhaust Requirements ......................................... 13

Electrical Information............................................ 15

Gas Information .................................................... 18

Converting from One Family of Gas to Another..... 21

Gas Pressure Testing........................................... 23

Steam Information ................................................ 23

Water Information ................................................. 24

Preparation for Operation/St art-Up........................ 25

Preoperational T est............................................... 2 5

Preoperational Instructions................................... 2 6

Shutdown Instructions .......................................... 26

Service/Parts Information ..................27

Service ................................................................. 27

Parts .................................................................... 27

WARNING

Children should not be allowed to play on or near the dryer(s). Children should be supervised if near dryer(s) in operation.

Under no circumstances should the dryer door switch(es), lint door/drawer switch(es), or heat safety circuit(s) ever be disabled.

The dryer must never be operated with any of the back guards, outer tops, or service panels removed. Personal injury or fire could result.

The dryer must never be operated without the lint filter/screen in place, even if an external lint collection system is used.

FOR Y OUR SAFETY

Do not dry mop heads in the dryer . Do not use dryer in the presence of dry cleaning fumes.

The dryers must not be installed or stored in an area where it will be exposed to water and/or weather .

The wiring diagram for the dryer is located behind the control panel.

Warranty Information .........................27

Returning Warranty Cards .................................... 27

Warranty .............................................................. 27

Returning Warranty Parts..................................... 27

Routine Maintenance ..........................28

Cleaning ............................................................... 28

Adjustments......................................................... 28

Data Label Information .......................29

List of Acronyms _______________________

HVAC Heating, Ventilating, and Air-Conditioning in WC Inches of Water Column L.C.D. Liquid Crystal Display L.E.D. Light Emitting Diode L.P. Liquid Propane OSHA Occupational Safety and Health Administration R.M.A. Return Material Authorization UL Underwriters Laboratory

113401 -18 www.amdry.com 3

Safety Precautions ____________________

Warning

For your safety, the information in this manual

must be followed to minimize the risk of fire or explosion and to prevent property damage, personal injury, or loss of life.

The dryer must never be operated with any of the back guards, outer tops, or service panels removed. Personal injury or fire could result.

Failure to properly install, maintain, and/or operate dryer according to this manual and operator’s manuals included with dryer may result in conditions, which can cause serious injury, death and/or property damage.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

Purchaser and user should consult the local gas supplier for proper instructions to be followed in the event the user smells gas. The instructions should be posted in a prominent location.

A program should be established for the inspection and cleaning of lint in the burner area, exhaust ductwork, and area around the back of the dryer. The frequency of inspection and cleaning can best be determined from experience at each location.

Do not operate steam dryers with more than 150 psi (10.34 bar) steam pressure. Excessive steam pressure can damage the steam coil and/or harm personnel.

Replace leaking flexible hoses or other steam fixtures immediately. Do not operate the dryer with leaking flexible hoses. Personal injury may result.

Warning

The collection of lint in the burner area and

exhaust ductwork can create a potential fire

hazard.

For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the National Electrical Code ANSI/NFP A NO. 70-LA TEST EDITION or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LA TEST EDITION.

What To Do If Y ou Smell Gas:

• Do not try to light any appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building, or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified installer, service agency, or gas supplier.

Dryers must be exhausted to the outdoors. Although the manufacturer produces a very versatile dryer,

there are some articles that, due to fabric composition or cleaning method, should not be dried in it.

Warning

Dry only water washed fabrics. Do not dry articles

spotted or washed in dry cleaning solvents, combustible detergents, or “all purpose” cleaner. Explosion could result.

Do not dry rags or articles coated or contaminated with gasoline, kerosene, oil, paint, or wax. Explosion could result.

Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer.

Do not dry mop heads. Contamination by wax or flammable solvents will create a fire hazard.

Do not use heat for drying articles that contain plastic, foam, sponge rubber, or similarly textured rubber materials. Drying in a heated tumbler may damage plastics or rubber and also may be a fire hazard.

Note

Failure to electrically ground the dryer properly will

void the warranty.

Warning

Personal injury or fire could result should the dryer

door switch, lint door/drawer, or heat safety circuit

ever be disabled.

Remove articles from the dryer as soon as the drying cycle has been completed.

Warning

Articles left in the dryer after the drying and cooling

cycles have been completed can create a fire

hazard.

For safety, proper operation, and optimum performance, the dryer must not be operated with a load less than 66% of its rated capacity .

Warning

You must disconnect and lockout the electric

supply and the gas supply or the steam supply before any covers or guards are removed from the machine to allow access for cleaning, adjusting, installation, or testing of any equipment per OSHA standards.

Important

The dryer must be installed in a location/

environment, which the ambient temperature remains between 40° F (4.44° C) and 130° F (54.44° C).

The operation of this appliance may affect the operation of other types of gas appliances, which take their air for safe combustion from the same room. If in doubt, consult the appliance manufacturer(s).

4 American Dryer Corp. 113401-18

Use this dryer only for its intended purpose, drying fabrics. The “cool down” cycle of tumble dryers should be used to

reduce the temperature of the items. They should not be removed from the tumble dryer or piled or stacked while hot.

Fabric softeners or similar products should not be used in a tumbler dryer to eliminate the effects of static electricity unless this practice is specifically recommended by the manufacturer of the fabric softener or product.

NOTES ______________________________________________________

_____________________________________________________________

Warning

To reduce the risk of personal injury, install

lockable doors to prevent public access to the rear

of the dryers.

Exhaust duct outlet should be checked periodically for blockages, and if any found, removed.

Important

A means of restraint must be used to prevent

straining of the gas supply when the appliance is

moved. An external means of power removal (disconnect device)

must be provided by the installer.

CE ONL Y

Important

This appliance must only be installed and

operated in the country of destination indicated on the dryer’s data plate. If the appliance is to be installed and operated in a country other than the one indicated on the data plate, a data plate amendment must be obtained from American Dryer Corporation.

Warning

This appliance must only operate with the gas type

indicated on the dryer’s data plate. If the appliance is converted (gas type is changed), a data plate amendment must be obtained from American Dryer Corporation.

This appliance may cause spillage of products of combustion from an open-flue appliance fitted in the same room, and that such an appliance shall be tested for clearance of products with the appliance in operation and all windows and doors closed.

_____________________________________________________________

NOTES ______________________________________________________

_____________________________________________________________

113401 -18 www.amdry.com 5

SL2020 Specifications ______________________________________________________________

MAXIMUM CAPACITY

(DRY WEIGHT) PER POCKET

20 lb TUMBLER DIAMETER 25-3 / 4” TUMBLER DEPTH 24” TUMBLER VOLUME TUMBLER/ DRIVE MO TO R BLOWER/FAN MOTOR DOOR OPENING DOOR S ILL HEIGHT

PER POCKET

(DIAMETER)

TOP POCKET / BOTTOM POCKET

7-1/2 cu ft

1/4 hp 1/3 hp

19-3/8”

49” / 13”

WATER CONNECTION 3/4”-11.5 NH

3/4” B.S.P.T.

(Outside No rth Ameri ca)

9.07 kg

65.41 cm

60.96 cm

212.38 L

0.19 kW

0.25 kW

49.21 cm

124.46 cm / 33.02 cm

(North America)

DRYE RS PER 20’/40’ CONTAINER 42 / 84 DRYE RS PER 48’/53’ TRUCK 96 / 1 08

VOLTAGE AVAILABLE 12 0- 24 0 V 1ø 2w 5 0/6 0 Hz APPROXIMATE NET WEIGHT 460 lb APPROXIMATE SHIPPING WEIGHT 485 lb AIRFLOW

HEAT INPUT EXHAUST CONNECTION

Gas

COMPRESSED AIR CONNECTION N / A

PER POCKET

(DIAMETER) PER POCKET

60 Hz 50 Hz

230 cfm

191 cfm

40,000 Btu/hr

4”

208.65 kg

219.99 kg

6.51 cmm

5.40 cmm

10,080 kcal/hr

10.16 cm

COMPRESSED AIR VOLUME N / A INLET PIPE CONNECTION

PER POCKET

3/8” M.B.S .P.T.

3/8” M.N.P.T.

(CE and Australia Only)

VOLTAGE AVAILABLE 200-416V 1,3ø 2,3,4w 50/60 Hz APPROXIMATE NET WEIGHT 460 lb APPROXIMATE SHIPPING WEIGHT 485 lb AIRFLOW

PER POCKET

EXHAUST CONNECTION

(DIAMETER) PER POCKET

60 Hz 50 Hz

230 cfm

191 cfm

4”

208.65 kg

219.99 kg

6.51 cmm

5.40 cmm

10.16 cm

COMPRESSED AIR CONNECTION N / A COMPRESSED AIR VOLUME N / A

OVEN SIZE

kW Btu/hr

4.1 13,843

5.0 17,065

5.4 18,430

5.6 19,112

Electric

6.1 20,819

6.5 22,184

6.8 23,208

7.4 25,255

7.5 25,597

8.1 27,644

PER POCKET

kcal/hr

3,488 4,300 4,644 4,816 5,246 5,590 5,848 6,364 6,450 6,966

VOLTAGE AVAILABLE 12 0- 24 0 V 1ø 2w 5 0/6 0 Hz APPROXIMATE NET WEIGHT 476 lb APPROXIMATE SHIPPING WEIGHT 5 01 lb AIRFLOW

PER POCKET

STEAM CONSUMPTION

PER POCKET

60 Hz 50 Hz

230 cfm

191 cfm

45 lb/hr OPERATING STEAM PRESSURE 15 0 psi m ax EXHAUST CONNECTION

(DIAMETER) PER POCKET

4”

215.91 kg

227.25 kg

6.51 cmm

5.40 cmm

20.41 kg/hr

10.34 bar

10.16 cm

COMPRESSED AIR CONNECTION N / A COMPRESSED AIR VOLUME N / A

Steam

BOILER HORSEPOWER SUPPLY CONNECTION RETURN C ONNEC TION

Shaded areas are stated in metric equivalents 10/17/05

(NORMAL LOAD) PER POCKET

PER POCKET

1.2 Bhp 1/2” F.N.P.T. 1/2” F.N.P.T.

Note

The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.

6 American Dryer Corp. 113401-18

SL2020 Specifications ______________________________________________________________

113401 -18 www.amdry.com 7

SL2929 Specifications ______________________________________________________________

MAXIMUM CAPACITY

(DRY WEIGHT) PER POCKET

30 lb TUMBLER DIAMETER 25 - 3 / 4 ” TUMBLER DEPTH 34 ” TUMBLER VOLUME TUMBLER/DRIVE MOTOR BLOWER/FAN MOTOR DOOR OPENING DOOR SILL HEIGHT

PER POCKET

(DIAMETER)

TOP POCKET / BOTTOM POCKET

10-1/4 cu ft

1/4 hp 1/2 hp

19-3/8”

49” / 13”

WATER CONNECTION 3 /4” -11.5 NH

3/4” B.S.P.T.

(Outside North America)

13.61 kg

65.41 cm

86.36 cm

290.25 L

0.19 kW

0.37 kW

49.21 cm

124.46 cm / 33.02 cm

(North America)

DRYE RS PER 20’/40’ CONTAINER 14 / 28 DRYE RS PER 48’/53’ TRUCK 36 / 3 8

VOLTAGE AVAILABLE 12 0V 1ø 2w 6 0 Hz APPROXIMATE NET WEIGHT 5 35 lb APPROXIMATE SHIPPING WEIGHT 560 lb AIRFLOW HEAT INPUT EXHAUST CONNECTION COMPRESSED AIR CONNECTION N / A

GasElectricSteam

PER POCKET

(DIAMETER) PER POCKET

240 cfm

52,500 Btu/hr

6”

242.67 kg

254.01 kg

6.80 cmm

13,2 30 kca l/h r

15.24 cm

COMPRESSED AIR VOLUME N / A INLET PIPE CONNECTION

PER POCKET

3/8” M.N.P.T.

3/8” M.B.S.P.T.

(CE and Australia Only)

VOLTAGE AVAILABLE APPROXIMATE NET WEIGHT APPROXIMATE SHIPPING WEIGHT AIRFLOW EXHAUST CONNECTION

PER POCKET

(DIAMETER) PER POCKET

N / A COMPRESSED AIR CONNECTION COMPRESSED AIR VOLUME

OVEN SIZE

kW Btu/hr

PER POCKET

kcal/hr

VOLTAGE AVAILABLE APPROXIMATE NET WEIGHT APPROXIMATE SHIPPING WEIGHT AIRFLOW STEAM CONSUMPTION OPERATING STEAM PRESSURE EXHAUST CONNECTION

PER POCKET

(DIAMETER) PER POCKET

N / A COMPRESSED AIR CONNECTION

COMPRESSED AIR VOLUME BOILER HORSEPOWER SUPPLY CONNECTION RETURN C O NNEC TION

Shaded areas are stated in metric equivalents 9/20/05

(NORMAL LOAD) PER POCKET

PER POCKET

Note

The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.

8 American Dryer Corp. 113401-18

SL2929 Specifications ______________________________________________________________

113401 -18 www.amdry.com 9

SL3131 Specifications ______________________________________________________________

MAXIMUM CAPACITY

(DRY WEIGHT) PER POCKET

30 lb TUMBLER DIAMETER 30” TUMBLER DEPTH 27” TUMBLER VOLUME TUMB LER/DRIVE MOTO R BLOWER/FAN MOTOR DOOR OPENING DOOR SILL HEIGHT

PER POCKET

(DIAMETER)

TOP POCKET / BOTTOM POCKET

11.04 cu ft 1/4 hp 1/2 hp

19-3/8”

54-11/16” / 14-7/8”

WATER CONNECTION 3 /4” -11.5 NH

3/4” B.S.P.T.

(Outside North America)

13.61 kg

76.20 cm

68.58 cm

312.62 L

0.19 kW

0.37 kW

49.21 cm

138.91 cm / 37.78 cm

(North America)

DRYERS PE R 20’/40 ’ C ONTAINER 12 / 28 DRYERS PE R 48’/53’ TRUC K 34 / 38

VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz APPROXIMATE NET WEIGHT 550 lb APPROXIMATE SHIPPING WEIGHT 580 lb AIRFLOW

HEAT INPUT EXHAUST CONNECTION

GasElectric

COMPRESSED AIR CONNECTION N / A

PER POCKET

(DIAMETER) PER POCKET

60 Hz 50 Hz

360 cfm 300 cfm

55,000 Btu/hr

6”

249.48 kg

263.08 kg

10.19 cmm

8.49 cmm

13,860 kcal/hr

15.24 cm

COMPRESSED AIR VOLUME N / A INLET PIPE CONNECTION

PER POCKET

1/2” M.N.P.T.

3/8” M.B.S.P.T.

(CE and Australia Only)

VOLTAGE AVAILABLE 20 0 -41 6 V 1, 3ø 2, 3,4 w 50 /6 0 H z APPROXIMATE NET WEIGHT 550 lb APPROXIMATE SHIPPING WEIGHT 580 lb AIRFLOW

PER POCKET

EXHAUST CONNECTION

(DIAMETER) PER POCKET

60 Hz 50 Hz

360 cfm 300 cfm

6”

249.48 kg

263.08 kg

10.19 cmm

8.49 cmm

15.24 cm

COMPRESSED AIR CONNECTION N / A COMPRESSED AIR VOLUME N / A

OVEN SIZE

kW Btu/hr

7.9 26,962

8.3 28,327

9.0 30,716

11.3 38,566

12.4 42,320

12.5 42,661

13.5 46,074

PER POCKET

kcal/hr

6,794 7,138 7,740

9,719 10,665 10,751 11,6 11

VOLTAGE AVAILABLE 120-240V 1ø 2w 50/60 Hz APPROXIMATE NET WEIGHT 580 lb APPROXIMATE SHIPPING WEIGHT 610 lb AIRFLOW

PER POCKET

STEAM CONSUMPTION

60 Hz 50 Hz

PER POCKET

360 cfm 300 cfm

63 lb/hr OPERATING STEAM PRESSURE 150 p si m ax EXHAUST CONNECTION

(DIAMETER) PER POCKET

6”

263.08 kg

276.69 kg

10.19 cmm

8.49 cmm

28.58 kg/hr

10.34 bar

15.24 cm

COMPRESSED AIR CONNECTION N / A

Steam

COMPRESSED AIR VOLUME N / A BOILER HORSEPOWER SUPPLY CONNECTION RETURN C ONNEC TION

Shaded areas are stated in metric equivalents 9/30/05

(NORMAL LOAD) PER POCKET

PER POCKET

1.75 Bhp

1/2” F.N.P.T.

1/2” M.N.P.T.

Note

The manufacturer reserves the right to make changes in specifications at any time without notice or obligation.

10 American Dryer Corp. 113401-18

SL3131 Specifications ______________________________________________________________

113401 -18 www.amdry.com 11

Installation Procedures _______________

Installation should be performed by competent professional in accordance with local, state, and country codes. In the absence of these codes, the installation must conform to applicable American National S tandards: ANSI Z223.1-LA TEST EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70LATEST EDITION (National Electrical Code) or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/ CGA-B149.2-M91 (L.P . Gas) or LA TEST EDITION (for General Installation and Gas Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION (for Electrical Connections).

Location Requirements _______________

Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1 LATEST EDITION, or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION (for General Installation and Gas Plumbing).

The dryer must be installed on a sound level floor capable of supporting its weight. Carpeting must be removed from the floor area that the dryer is to rest on.

The dryer must not be installed or stored in an area where it will be exposed to water and/or weather.

Provisions for adequate air supply must be provided as noted in this manual (refer to Fresh Air Supply Requirements section).

Clearance provisions must be made from combustible construction as noted in this manual (refer to Dryer Enclosure Requirements section).

Provisions must be made for adequate clearances for servicing and for operation as noted in this manual (refer to Dryer Enclosure Requirements section).

The dryer must be installed with a proper exhaust duct connection to the outside as noted in this manual (refer to Exhaust Requirements section).

The dryer must be located in an area where correct exhaust venting can be achieved as noted in this manual (refer to Exhaust Requirements section).

Unpacking/Setting Up _________________

Remove protective shipping material (i.e., plastic wrap and optional shipping box) from the dryer.

Important

Dryer must be transported and handled in an

upright position at all times.

The dryer can be moved to its final location while still attached to the skid or with the skid removed. To remove the skid from the dryer, locate and remove the 2 bolts securing the base of the dryer to the wooden skid. One is located at the center rear and the other is at the center front.

With the skid removed, use caution and assure all four leveling legs are fully retracted, if the dryer is to be slid into its final position.

Leveling Dryer

The dryer is equipped with 4 leveling legs, 1 at each corner of the base. For optimum performance the dryer should be level front-to-back and side-to-side.

Dryer Enclosure Requirements _______

Bulkheads and partitions should be made of noncombustible material.

Note

Allowances must be made for opening the control

door.

Important

The dryer should be located where a minimum

amount of exhaust ducting will be necessary.

The dryer must be installed with adequate clearance for air openings into the combustion chamber.

Caution

This dryer produces combustible lint and must be

exhausted to the outdoors. Every 6 months,

inspect the exhaust ducting and remove any lint buildup.

Important

The dryer must be installed in a location/

environment, which the ambient temperature

remains between 40° F (4.44° C) and 130° F (54.44° C).

12 American Dryer Corp. 113401-18

A The requirement to allow the door to open completely for

the SL2020/SL2929 is 30-inches (76.2 cm), and for the SL3131 is 33-inches (83.8 cm).

B A minimum overhead clearance of 6-inches (15.24 cm)

is required.

C Dryer should be positioned a minimum of 12-inches

(30.48 cm) away from the nearest obstruction. 24-inches (60.96 cm) is recommended for ease of installation,

maintenance, and service. D 1/16” (1.5875 mm) minimum is required. E Flooring should be level or below dryer cabinet for ease

of removing panels during maintenance. F Dryers may be positioned sidewall to sidewall, however

a 1/16” (1.5875 mm) minimum allowance must be made

for the opening and closing of the control door, along

with the removal of panels during maintenance.

Fresh Air Supply Requirements _______

When the dryer is operating, it draws in room air, heats it, passes this air through the tumbler, and exhausts it out of the building. Therefore, the room air must be continually replenished from the outdoors. If the make-up air is inadequate, drying time and drying efficiency will be adversely affected. Ignition problems and sail switch “fluttering” problems may result, as well as premature motor failure from overheating. The dryer must be installed with provisions for adequate combustion and make-up air supply.

Air supply (make-up air) must be given careful consideration to ensure proper performance of each dryer. Fresh air ventilation openings shall not be blocked and/or sealed. As a general rule, an unrestricted air entrance from the outdoors of 110 inch (678 cm2) for each SL2929, and 80 inch2 (516 cm2) for each SL2020. (Based on 1 inch kcal].)

It is not necessary to have a separate make-up air opening for each dryer. Common make-up air openings are acceptable. However, they must be set up in such a manner that the make-up air is distributed equally to all the dryers.

(710 cm2) is required for each SL3131, 105 inch

[6.5 cm2] per 1,000 Btu [252

Exhaust Requirements ________________

Exhaust ductwork should be designed and installed by a

qualified professional. Improperly sized ductwork will create

excessive back pressure, which results in slow drying,

increased use of energy, and shutdown of the burner by the

airflow (sail) switch, burner hi-limits, or lint chamber hi-limit

protector thermostat. The dryer must be installed with a proper

exhaust duct connection to the outside.

Caution

This dryer produces combustible lint and must be

exhausted to the outdoors.

Improperly sized or installed exhaust ductwork can create

a potential fire hazard.

The ductwork should be laid out in such a way that the

ductwork travels as directly as possible to the outdoors with

as few turns as possible. There should be a minimum

6-inch (15.24 cm) clearance between the back guard and the

first bend in the ductwork for ease of servicing. Single or

independent dryer venting is recommended. It is suggested

that the use of 90° turns be avoided; use 30° and/or 45°

bends instead. The radius of the elbows should preferably

be 1-1/2 times the diameter of the duct. All ductwork should

be smooth inside with no projections from sheet metal

screws or other obstructions, which will collect lint. When

adding ducts, overlap the duct being connected. All ductwork

joints must be taped to prevent moisture and lint from

escaping into the building. Back draft dampers must be

installed in all commonly ducted systems. Inspection doors

should be installed at strategic points in the exhaust ductwork

for periodic inspection and cleaning of lint from the ductwork.

A = 14-inches (35.56 cm) B = 16-inches (40.64 cm)

EXAMPLE: For a bank of 4 SL3131 dryers, 2 unrestricted openings measuring 14-inches by 16-inches (35.56 cm by

40.64 cm) are acceptable. To compensate for the use of registers or louvers used over

the openings, this area must be increased by approximately 33%. Make-up air openings should not be located in an area directly near where exhaust vents exit the building.

Allowances must be made for remote or constricting passageways or where dryers are located at high altitudes or predominantly low pressure areas.

Important

Make-up air must be free of dry cleaning solvent

fumes. Make-up air that is contaminated by dry cleaning solvent fumes will result in irreparable damage to the motors and other dryer components.

Important

It is recommended that exhaust or booster fans

not be used in the exhaust ductwork system.

Exhaust back pressure measured by a manometer/ magnehelic in the exhaust duct must be no less than 0 and must not exceed 0.6 in WC (1.48 mb).

Note

When the exhaust ductwork passes through a wall,

ceiling, or roof made of combustible materials, the opening must be 2-inches (5.08 cm) larger than the duct (all the way around). The duct must be centered within this opening.

As per the National Fuel Gas Code, “Exhaust ducts for type 2 clothes dryers shall be constructed of sheet metal or other noncombustible material. Such ducts shall be equivalent in strength and corrosion resistance to ducts made of galvanized sheet steel not less than 26 gauge (0.0195-inches [0.50 mm]) thick.”

The ductwork for this appliance must be suitable for the appliance category in accordance with national installation regulations of the country of destination.

Note

Component failure due to dry cleaning solvent

fumes will void the warranty.

113401 -18 www.amdry.com 13

Outside Ductwork Protection

To protect the outside end of the horizontal ductwork from the weather, a 90° elbow bent downward should be installed where the exhaust exits the building. If the ductwork travels vertically up through the roof, it should be protected from the weather by using a 180° turn to point the opening downward. In either case, allow at least twice the diameter of the duct between the duct opening and the nearest obstruction (refer to the diagram).

Important

Do not use screens, louvers, or caps on the

outside opening of the exhaust ductwork.

Single Dryer Venting

Important

For extended ductwork runs, the cross-sectional

area of the ductwork can only be increased to an extent. When the ductwork approaches the maximum limits as noted in this manual, a professional HVAC firm should be consulted for proper venting information.

The length of the ductwork from the dryer to the outside exhaust outlet, must not exceed 12 feet (3.66 meters) for the SL3131 and 20 feet (6.10 meters) for the SL2020 and SL2929. The

minimum diameter of this ductwork must be at least 8-inches (20.32 cm) even though the dryer exhaust duct connection is smaller. Including tumbler/dryer elbow

connections or elbows used for outside protection from the weather, no more than 4 90° elbows should be used in the exhaust duct run. If more than the equivalent of four 90° elbows are used, the cross-sectional area of the ductwork must be increased.

Multiple Dryer (Common) V enting

Important

For extended ductwork runs, the cross-sectional

If it is not feasible to provide separate exhaust ducts for each dryer, ducts from individual dryers may be channeled into a “common main duct.” The individual ducts should enter the bottom or side of the main duct at an angle not more than 45º in the direction of airflow. The main duct should be tapered, with the diameter increasing before each individual duct is added. The minimum diameter of the individual ductwork must be at least 8-inches (20.32 cm).

A = SL2020/SL2929 - 20 feet (6.10 meters)

SL3131 - 12 feet (3.66 meters)

B = 8-inches (20.32 cm)

Important

No more than 4 dryers should be connected to 1

main common duct.

NOTES ____________________________________

___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________ ___________________________________________

NOTE 1 Opening from combustible materials must be 2-inches (5.08 cm)

larger than the duct (all the way around). The duct must be centered within this opening.

NOTE 2 Distance should be 2 times the diameter of the duct to the nearest

obstruction.

14 American Dryer Corp. 113401-18

___________________________________________ ___________________________________________

The illustration below shows the minimum cross-sectional area for multiple dryer round or square venting. These figures must be increased if the main duct run from the last dryer to where it exhausts to the outdoors is longer than 12 feet (3.66 meters) or has more than 1 elbow in it.

Multiple Dryer Venting with 8-Inch (20.32 cm) Diameter

460/480 cfm (13.02/13.59 cmm) Exhaust Connections

NUMBER OF DRYERS 4 3 2 1

MINIMUM C ROSSSECTIONAL AREA

MINIMUM ROUND DUCT DIAMETER

Multiple Dryer Venting with 8-Inch (20.32 cm) Diameter

720 cfm (20.38 cmm) Exhaust Connections at Common Duct

NUMBER OF DRYERS 4 3 2 1

MINIMUM C ROS S SECTIONAL AREA

MINIMUM ROUND DUCT DIAMETER

A = 8-inches (20.32 cm) B = 12 feet (3.66 meters)

SL2020/SL2929

at Common Duct

SQ IN 120 80 80 54

SQ CM 774.2 516.1 516.1 348.4

IN 12 10 10 8

CM 30.48 25.4 25.4 20.32

SL3131

SQ IN 164 120 80 54

SQ CM 1058 774.2 516.1 348.4

IN 14 12 10 8

CM 35.56 30.48 25.4 20.32

Note

Component failure due to improper installation will

void the warranty.

Each pocket should be connected to an independently protected branch circuit. The dryer must be connected with copper wire only. Do not use aluminum wire, which could cause a fire hazard. The copper conductor wire/cable must be of proper ampacity and insulation in accordance with electric codes for making all service connections.

Note

The use of aluminum wire will void the warranty.

An individual ground circuit must be provided to

each pocket, do not daisy chain. Component failure due to improper voltage application will

void the warranty. The manufacturer reserves the right to make changes in

specifications at any time without notice or obligation.

Important

A separate protected circuit must be provided to

each pocket.

It is necessary to have a power disconnect for each pocket. These disconnects must be located within 9 meters of the unit and also be identified as being one of two power sources supplying a dryer.

The dryer must be connected to the electric supply shown on the data label. In the case of 208 VAC or 230/240 VAC, the supply voltage must match the electric service specifications of the data label exactly.

The wire size must be properly sized to handle the related current.

NOTE 1 Opening from combustible materials must be 2-inches (5.08 cm)

larger than the duct (all the way around). The duct must be centered within this opening.

NOTE 2 Distance should be 2 times the diameter of the duct to the nearest

obstruction.

Electrical Information _________________

Electrical Requirements

All electrical connections must be made by a properly licensed and competent electrician. This is to ensure that the electrical installation is adequate and conforms to local, state, and national regulations or codes of the country of origin. In the absence of such codes, all electrical connections, materials, and workmanship must conform to the applicable requirements of the National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in Canada, the Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.

Important

Failure to comply with these codes or ordinances,

and/or the requirements stipulated in this manual

can result in personal injury or component failure.

Warning

208 VAC and 230/240 VAC are not the same. Any

damage done to dryer components due to improper voltage connections will automatically void the warranty.

Warning (Gas Models Only)

Dryers built for use with a voltage between 200

and 230/240 must verify the input voltage during installation. If the nominal voltage is outside of the medium tolerances shown on the diagram below, adjust the autotransformers, located near the burner assemblies. To adjust the autotransformer wiring, place the red wire on the appropriate tap (HIGH, MED, LOW) of the autotransformer. For additional wiring details, refer to the electrical diagram located on the inside of the control panel.

TERM

HIGH

MED

LOW

LINE VOLTAGE

50 Hz 60 Hz

260 226

239 208

217 189

283 249

260 230

236 208

113401 -18 www.amdry.com 15

Electrical Service Specifications Gas and Steam Models Only

E LECT RICAL SE RVICE SPECIFIC ATIONS (PER POCKET )

IMPORTANT:

NOTES

SERVICE

VOLTAGE

208 VAC AND 230/240 VAC ARE NOT THE SAME. Whe n ordering, specify exact voltage.

When fuses are used they must be dual element, time delay, current

: A.

limiting, class RK1 or RK5 ONLY. Calculate/determine correct fuse

value, by applying either local and/or National Electrical Codes to

listed appliance amp draw data.

Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY. For others, calculate/verify correct breaker size according to appliance amp draw rating and type of breaker used. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.

APPROX.

AMP D RAW

60 Hz 50 Hz

PHASE

WIRE

SERVICE

SL2020 Gas

120 1ø 2 8.9 — 15 200 1ø 2 7.7 7.8 15 208 1ø 2 7.6 — 15 220 1ø 2 — 7.4 1 5 230 1ø 2 — 7.3 1 5 240 1ø 2 7.2 7.0 15

SL2929 Gas

120 1ø 2 8.9 — 15

SL3131 Gas

120 1ø 2 10.3 — 15 200 1ø 2 8.7 8.8 15 208 1ø 2 8.4 — 15 220 1ø 2 8.1 8.1 15 230 1ø 2 — 7.4 1 5 240 1ø 2 7.7 7.0 15

SL3131 Steam

120 1ø 2 9.3 — 15 208 1ø 2 6.2 6.0 15 220 1ø 2 5.6 5.5 15 230 1ø 2 — 5.4 1 5 240 1ø 2 5.1 — 15

CIRCUIT

BREAKER

7/10/08

Electric Models Only

All electrically heated dryers must be connected to the electric service shown on the dryer’s data label. The connecting wires must be properly sized to handle the rated current.

ELECTRICAL SERVIC E SPECIFIC ATIONS (PER POCKET)

IMPORTANT:

NOTES

SERVICE

VOLTAGE

208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.

: A.

When fuses are used they must be dual element, time delay, current limiting, class RK1 or RK 5 ONLY. Calculate/determine correct fuse value, by applying either local and/or National Electrical Codes to listed appliance amp draw data. Circuit breakers are thermal-magnetic (industrial) type ONLY. For others, calculate/ve rify correct breaker size according to appliance amp draw rating and type of breaker used. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.

kW PHASE

WIRE

SERVICE

APPROX.

AMP DRAW

60 Hz 50 Hz

CIRCUIT

BREAKER

SL2020

200 5.6 1ø 2 32.7 32.7 45 208 4.1 1ø 2 24.2 — 35 208 6.1 1ø 2 34.0 — 45 220 6.8 1ø 2 35.6 — 45 230 5.0 1ø 2 — 26.4 35 230 7.4 1ø 2 — 36.8 50 240 5.4 1ø 2 27.1 — 35 240 8.1 1ø 2 38.4 38.4 50 208 6.5 3ø 3 22.7 — 30 240 7.5 3ø 3 22.6 — 30 380 6.8 3ø 4 — 15.0 20 400 7.5 3ø 4 — 15.5 20 416 8.1 3ø 4 — 15.8 20

SL3131

200 12.5 1ø 2 68.4 67.7 90 208 7.9 1ø 2 43.8 — 60 208 13.5 1ø 2 70.7 — 90 230 8.3 1ø 2 — 41.3 60 230 12.4 1ø 2 — 59.1 80 240 9.0 1ø 2 42.7 — 60 240 13.5 1ø 2 61.5 — 80 208 13.5 3ø 3 43.3 — 6 0 220 11.3 3ø 3 35.3 — 50 230 12.4 3ø 3 — 36.5 50 240 13.5 3ø 3 37.7 — 50 380 11.3 3ø 4 22.8 22.6 40 400 12.4 3ø 4 — 23.1 40 416 13.5 3ø 4 — 23.7 40

7/10/08

16 American Dryer Corp. 113401-18

Grounding

A ground (earth) connection must be provided and installed in accordance with local, state, and national regulations or codes of the country of origin. In the absence of these codes, grounding must conform to applicable requirements of the National Electrical Code ANSI/NFP A NO. 70-LA TEST EDITION, or in Canada, the installation must conform to applicable Canada Standards: Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LA TEST EDITION. The ground connection may be to a proven earth ground at the location service panel.

For added personal safety, when possible, it is suggested that a separate ground wire (size per local codes) be connected from the ground connection of the dryer to a grounded cold water pipe. Do not ground to a gas pipe or hot water pipe. The grounded cold water pipe must have metal-to-metal connection all the way to the electrical ground. If there are any nonmetallic interruptions, such as, a meter, pump, plastic, rubber, or other insulating connectors, they must be jumped out with a wire (size per local codes) and securely clamped to bare metal at both ends.

Important

For personal safety and proper operation, the dryer

must be grounded.

208-240V Application without Neutral

Caution

The dryer must be grounded. A ground lug has

been provided for this purpose.

Input connection wiring must be sized properly to handle the dryer’s current draw. This information is printed on the dryer’s data label.

Provisions are made for ground connection in each dryer at the electrical service connection area.

Electrical Connections

A wiring diagram is located behind the control panel for connection data.

If local codes permit, power to the dryer can be made by the use of a flexible UL listed power cord/pigtail (wire size must conform to rating of dryer), or the dryer can be hard wired directly to the service breaker panel. In both cases, a strain relief must be installed where the wiring enters the dryer.

For CE Models Only

The means for disconnection from the supply must be incorporated into wiring having a minimum contact separation of 3.0 mm in all poles.

Single-Phase (1ø) Wiring Connections/Hookup

The electrical input connections are made into the rear service box located at the upper right area of the dryer. The ground connection is made to the copper lug, also provided in this box. To gain access, the service box cover must be removed.

Gas and Steam Models Only 120-240V Application with Neutral

Important

A strain relief must be used where the input wiring

enters the oven assembly.

Electrically Heated Models Only

The electrical input connections are made at the rear service box located at the right upper section of the dryer. The ground connection is made to a copper lug also provided in this area. To gain access, remove rear service cover.

The only electrical input connections to the dryer are the 3-phase (3ø) power leads (L1, L2, L3, and sometimes neutral) and ground. Single-phase (1ø) power for the control circuit and for any single-phase (1ø) motors (if present) is done internally to the dryer by the factory at the oven contactor . No single-phase (1ø) input connection is required on a 3-phase (3ø) dryer.

The neutral will only be used on 4-wire service. This is typical for 380-416V, 50 Hz.

Caution

The dryer must be grounded. A ground lug has

been provided for this purpose.

Input connection wiring must be sized properly to handle the dryer’s current draw. This information is printed on the dryer’s data label.

113401 -18 www.amdry.com 17

Electric Models Only

Single-Phase (1ø) Wiring Connections/Hookup

3-Phase (3ø) Wiring Connections/Hookup

The dryer and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kPa) for non-CE dryers or 50 mb for CE dryers.

Note

The dryer must be isolated from the gas supply

piping system by closing its individual manual shutoff valve during any pressure test of the gas supply system at test pressures equal to or less than 1/2 psig (3.5 kPa) for non-CE dryers or 50 mb for CE dryers.

Warning

Fire or explosion could result due to failure of

isolating or disconnecting the gas supply as noted.

Note

Undersized gas piping will result in ignition

problems, slow drying, increased use of energy, and can create a safety hazard.

The dryer must be connected to the type of heat/gas indicated on the data label and pressure must be confirmed. If this information does not agree with the type of gas available, do not operate the dryer. Contact the reseller who sold the dryer or contact the manufacturer.

The input ratings shown on the data label are for elevations up to 2,000 feet (610 meters), unless elevation requirements of over 2,000 feet (610 meters) were specified at the time the dryer order was placed with the factory. The adjustment or conversion of dryers in the field for elevations over 2,000 feet (610 meters) is made by changing each burner orifice. If this conversion is necessary, contact the reseller who sold the dryer or contact the manufacturer.

Gas Information _______________________

It is your responsibility to have all plumbing connections, materials, and workmanship conform to local and state regulations or codes of the country of destination. In the absence of such codes, all plumbing connections, materials, and workmanship must conform to the applicable local requirements. In the USA this is the National Fuel Gas Code ANSI Z223.1-LATEST EDITION, or in Canada, the Canadian Installation Codes CAN/CGA-B149.1-M91 (Natural Gas) or CAN/CGAB149.2-M91 (L.P . Gas) or LATEST EDITION.

In Australia, the fuel gas code is AS 5601 / AG 601, local authority, gas, electricity, and any other relevant statutory regulations.

It is important that gas pressure regulators meet applicable pressure requirements, and that gas meters be rated for the total amount of all the appliance Btu being supplied.

Important

Failure to comply with these codes or ordinances,

and/or the requirements stipulated in this manual, can result in personal injury and improper operation of the dryer.

For ease of service, the individual gas supply line of each dryer must have its own manual shutoff valve.

Failure to isolate or disconnect the dryer from supply as noted can cause irreparable damage to the gas valve, voiding the warranty.

Important

If connection to this appliance is made with a

flexible hose, it must be suitable for the appliance category in accordance with national installation regulations of the country of destination, and if in doubt the installer must contact the supplier. The manufacturer of this appliance does not recommend the use of flexible gas supply line/hose. An external gas supply shutoff must be provided.

CE and Australian Dryers

There are 2 N.P.T. to B.S.P.T. adaptors included with each dryer, which must be installed to the gas inlet s. The adaptors are shipped in the upper tumbler.

Important

Pipe joint compounds that resist the action of

natural, propane, and butane gases must be used.

Warning (CE Dryers Only)

This appliance must only be operated with the gas

type indicated on the dryer’s data plate. If the appliance is converted (gas type changed), a data plate amendment must be obtained from American Dryer Corporation for CE approved units.

Gas Connections

Inlet connection ..............1/2” N.P.T.

Inlet supply size ............. 1/2” Diameter Pipe (minimum)

3/8” B.S.P.T. (CE and Australian dryers)

18 American Dryer Corp. 113401-18

Heat Input/Gas Consumption/Orifice (Injector) Data (For Non-CE [European] and Non-AGA [Australia] Models Only)

Gas Specifications for Non-CE and N o n-AGA Approved Dryers***

SL2020

Gas Type and

Nom in a l H eatin g Va lue

Btu/ft3in WC Btu/hr kW DMS mm in WC

Natural 1,000 7.0-13.0 40,000 *Liquid Propane 2,500 11.0 40,000

Supply

Pressure

**Gross

Heat Input

11.72

Orifice Size

3.264

1.854

SL2929

Gas Type and

Nom in a l H eatin g Va lue

Btu/ft3in WC Btu/hr kW DMS mm in WC

Natural 1,000 7.0-13.0 52,500 *Liquid Propane 2,500 11.0 52,500

Supply

Pressure

**Gross

Heat Input

15.37

Orifice Size

4.038

2.082

SL3131

Gas Type and

Nom in a l H eatin g Va lue

Btu/ft3in WC Btu/hr kW DMS mm in WC

Natural 1,000 7.0-13.0 55,000 *Liquid Propane 2,500 11.0 55,000

Shaded areas are stated in metric equivalents * Gas valve’s internal regulator disabled.

** Information is per pocket/tumbler. *** Consult factory for elevations over 2,000 feet (610 meters) for correct orifice size.

Supply

Pressure

**Gross

Heat Input

16.12

Orifice Size

4.089

2.184

**Orifice (Injector) Quantity

Burner

Pressure

13.0 1 10.0

**Orifice (Injector)

Burner

Pressure

Quantity

13.0 1 10.0

**Orifice (Injector)

Burner

Pressure

Quantity

13.0 1 10.0

Heat Input/Gas Consumption/Orifice (Injector) Data (For CE [European] Models Only)

Gas Specifications for CE Approved Dryers***

SL2020

Gas Type and

Nominal Heating Value

Natural ( I Natural ( I Natural ( I

*Natural (I

*Butane (I *Propane (I Buta ne (I Propane (I

) 1,000

2H/I2E

) 830

2ELL

)

2E+

) 3,175

) 2,500

) 3,175

3B/P

) 2,500

Btu/ft

1,000

830

Supply

Pressure

mb Btu/hr kW DMS mm mb 15-30 20-35 15-30

20 25

28-30

37 28-30/50 28-30/50

**Gross

Heat Input

40,000 40,000 40,000 40,000 40,000 40,000 40,000 40,000 40,000

**Fuel

Consumption

11.72 1.133 M3/H

11.72 1.365 M3/H

11.72 1.133 M3/H

11.72 1.365 M3/H

11.72 0.845 kg/H

Orifice Siz e

3.264

2.578

1.613

1.854

**Orifice

(Injector)

Quantity

Burner

Pressure

1 1 1 1 1 1 1 1 1

6.7

9.2

9.2 — — — —

18.0

23.0

SL3131

Gas Type and

Nominal Heating Value

Btu/ft

Natural ( I Natural ( I Natural ( I

*Natural (I

*Butane (I *Propane (I Buta ne (I Propane (I

) 1,000

2H/I2E

) 830

2ELL

)

2E+

) 3,175

) 2,500

) 3,175

3B/P

) 2,500

1,000

830

Shaded areas are stated in metric equivalents * Gas valve’s internal regulator disabled.

** Information is per pocket/tumbler. *** Consult factory for elevations over 2,000 feet (610 meters) for correct orifice size.

Supply

Pressure

mb Btu/hr kW DMS mm mb 15-30 20-35 15-30

20 25

28-30

37 28-30/50 28-30/50

**Gross

Heat Input

55,000 55,000 55,000 55,000 55,000 55,000 55,000 55,000 55,000

**Fuel

Consumption

16.12 1.557 M3/H

16.12 1.876 M3/H

16.12 1.557 M3/H

16.12 1.876 M3/H

16.12 1.162 kg/H

Orifice Siz e

3.988

3.048

1.930

2.184

**Orifice

(Injector)

Quantity

Burner

Pressure

1 1 1 1 1 1 1 1 1

6.9

9.5

9.5 — — — —

18.1

24.9

113401 -18 www.amdry.com 19

Heat Input/Gas Consumption/Orifice (Injector) Data (For AGA [Australian] Models Only)**

Gas Specifications for AGA Approved Dryers

Model

SL2020

SL3131

Shaded areas are stated in metric equivalents * Information is per pocket/tumbler.

** Consult factory for elevations over 2,000 feet (610 meters) for correct orifice size.

Gas

Type

Natura l Propane Natura l Propane

Supply

Pressure

kPa MJ/h DMS mm kPa

1.7-3.2 42.20

2.75 42.20

1.7-3.2 58.03

2.75 58.03

*Gross

Heat Input

Orifice Siz e

3.264

1.854

3.988

2.184

*Orifice (Injector) Quantity

1 1 1 1

Burner

Pressure

0.67

2.30

0.69

2.49

Piping/Connections

The dryer is provided with two 1/2” N.P.T. (3/8” B.S.P.T. for CE and Australian dryers) inlet pipe connections (1 for each tumbler) at the rear of the dryer. If a separate feed is provided for each tumbler from the main supply line (header), then a 1/2” (12.7 mm) line connection is sufficient. However, if the top and bottom tumbler connections are connected together, the supply from the header must be increased to 3/4-inch (19.05 mm). There should be a minimum 6-inch (15.24 cm) clearance between the back guard and the first bend in the gas piping for ease of servicing. It is recommended that a gas shutoff valve be provided to the gas supply line of each dryer for ease in servicing.

The size of the main gas supply line (header) will vary depending on the distance this line travels from the gas meter or, in the case of L.P. gas, the supply tank, other gas-operated appliances on the same line, etc. Specific information regarding supply line size should be determined by the gas supplier.

Note

Undersized gas supply piping can create a low or

inconsistent pressure, which will result in erratic

operation of the burner ignition system.

TYPICAL NA TURAL GAS INST ALLA TION

TYPICAL L.P. GAS INSTALLA TION

Consistent gas pressure is essential at all gas connections. It is recommended that a 3/4-inch (19.05 mm) pipe gas loop be installed in the supply line servicing a bank of dryers. An in-line pressure regulator must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 13.0 in WC (32.34 mb) pressure.

A plugged tap, accessible for a pressure gauge connection, must be installed in the main gas supply line immediately upstream of the dryers.

Important

Pipe joint compounds that resist the action of

natural, L.P., and butane gases must be used.

Test all connections for leaks by brushing on a soapy water solution (liquid detergent works well).

Warning

Never test for leaks with a flame!!!

20 American Dryer Corp. 113401-18

Converting from One Family of Gas to Another ______________________

Warning (CE Dryers)

This appliance must only be operated with the gas

type indicated on the dryer’s data plate. If the appliance is converted (gas type changed), a data plate amendment must be obtained from American Dryer Corporation (dryer’s serial number is required to purchase a conversion kit).

Important

Any burner changes or conversions must be made

by a qualified professional. The dryers manufactured for Belgium, Luxemburg, Greece,

Estonia, Slovak Republic, Iceland, Malta, Poland and Cyprus cannot be converted from one family of gas to another.

Conversion from Natural Gas to Propane or Butane Gas

The following conversion allows the dryer to be operated with either propane, butane, or LPG. The use of gas valve kit (ADC P/N 140414) disables the internal regulator of the gas valve. Therefore, the gas supply is ungoverned and an external regulator must be provided at the source of the supply (example L.P. tank) or the gas supply line to the dryer. The L.P. kit supplied will depend on the country the dryer is installed in.

Parts Required for Conversion:

Description ADC P/N Qty

Unregulated Gas Conversion Kit*** 140414 2*

OR Regulated L.P. Gas Conversion Kit**** 140416 2* Burner Orifice (Injector) ** 2* L.P. Conversion Label 114515 2*

* This includes 1 for each pocket/tumbler. ** Refer to page 19 for orifice (injector) size. *** Required for unregulated propane or butane only. **** Required for regulated LPG or propane only.

Instructions

Disconnect electrical power to the dryer. Close all shutoff valves (for both top and bottom tumbler) in

dryer’s gas supply line.

Important

Use extreme care when removing and replacing

orifice (injector). This orifice (injector) is made of

brass, which is easily damaged.

Reinstall the burner tube onto the burner base. Use a flat screwdriver to remove the regulator vent cap.

• For unregulated L.P. gas (most countries): install blocking pin (ADC P/N 140414).

• For regulated L.P. gas (some countries): remove the white plastic regulator adjustment screw (under vent cap). Remove spring under screw and replace with spring from kit (ADC P/N 140416). Replace regulator adjustment screw.

Install the gas train back into the dryer gas train enclosure. Be sure the tab at the rear of the gas train engages into the mounting slot.

Connect the union and the 3 electrical plugs. Repeat these steps for the other burner. Affix L.P. Conversion Label (ADC P/N 114515) to the dryer’s

data label. Complete L.P. Kit Conversion Confirmation Label (ADC P/N

114083) and affix this label as close as possible to the dryer’s existing dryer rating (data) label/plate.

Non-CE Dryers

Affix L.P. Conversion Rating Label Addendum (ADC P/N

114090) as close as possible to the dryer’s existing dryer rating (data) label/plate.

CE Dryers

Affix new data plate label that came with the conversion kit. Open all shutoff valves, reconnect electrical power to the dryer,

and test for leaks.

Important

Never test for leaks with an open flame!!! Use a

soapy water solution or product intended for that

purpose.

Important

The following procedures must be performed on

both top and bottom tumblers.

Open the panels located just below each loading door. Locate the gas train and disconnect the union, 3 electrical

plugs, and the gas train mounting screws from the burner. Carefully slide the gas train out of the gas train enclosure. (The carbon ignitor located at the far end of the gas train is very fragile.)

Remove 2 burner tube mounting screws and remove burner tube in order to gain access to the orifice.

Using a 3/8” wrench or socket, remove the existing orifice and replace it with an orifice from the kit.

113401 -18 www.amdry.com 21

Unregulated Gas Valve

Regulate (govern) gas externally (refer to “Supply Pressure” in chart on page 19) to the correct gas pressure for the gas being used. Operate dryer through 1 complete cycle to ensure proper operation.

Regulated Gas Valv e

Refer to “Gas Pressure Adjustment” on this page to adjust the gas valve to the appropriate burner pressure listed on page 19. The supply pressure must also match what is listed on page 19 for the type of gas to be used.

Important

Conversions done improperly can result in a fire or

explosion!

Conversion from Propane or Butane Gas to Natural Gas

The following conversion allows the dryer to be operated with natural gas.

Parts Required for Conversion:

Description ADC P/N Qty

Vent Cap and Spring 140415 2* Burner Orifice (Injector) ** 2*

* This includes 1 for each pocket (tumbler). ** Refer to page 19 for orifice (injector) size.

Instructions

Disconnect electrical power to the dryer. Close all shutoff valves (for both top and bottom tumbler) in

dryer’s gas supply line.

Important

The following procedures must be performed on

both top and bottom tumblers.

Reinstall the burner tube onto the burner base. Select from the following 3 options, the conversion to be

performed:

• Converting from unregulated L.P . to regulated natural gas: use a flat screwdriver to remove the cap with blocking pin and install the regulator vent cap from the kit (ADC P/N 140415).

• Converting from unregulated L.P . to unregulated natural gas: no change to the regulator is required.

• Converting from regulated L.P . to regulated natural gas: remove the white plastic regulator adjustment screw (under vent cap). Remove spring under screw and replace with spring from kit (ADC P/N 140415). Replace regulator adjustment screw.

Install the gas train back into the dryer gas train enclosure. Be sure the tab at the rear of the gas train engages into the mounting slot.

Connect the union and the 3 electrical plugs. Repeat these steps for the other burner. Open all shutoff valves, reconnect electrical power to the dryer,

and test for leaks. Operate the dryer through 1 complete cycle to ensure proper

operation. With dryer operating, check the manifold (burner) pressure

at the tap on the gas valve to ensure proper operating pressure (refer to chart on page 19).

Gas Pressure Adjustment

Disconnect electrical power to the dryer.

Open the panels located just below each loading door. Locate the gas train and disconnect the union, 3 electrical

plugs, and the gas train mounting screws from the burner. Carefully slide the gas train out of the gas train enclosure. (The carbon ignitor located at the far end of the gas train is very fragile.)

Remove 2 burner tube mounting screws and remove burner tube in order to gain access to the orifice.

Using a 3/8” wrench or socket, remove the existing orifice and replace it with an orifice from the kit.

Important

Use extreme care when removing and replacing

orifice (injector). This orifice (injector) is made of

brass, which is easily damaged.

Important

The following procedures must be performed on

both top and bottom tumblers.

To adjust gas valve’s internal regulator, remove the regulator vent cap with the regulator adjustment tool, which is located on the back guard between the gas inlet and exhaust outlet (refer to the illustration below for proper use of adjustment tool). Be sure to use one of the wide ends of the adjustment tool for removal of the vent cap. Once vent cap is removed, the narrow end of the adjustment tool can be used to turn the plastic adjustment screw in the valve. Turn the screw clockwise to raise pressure and counterclockwise to lower pressure.

Gas (burner) pressures are measured with the burner in operation for all burner adjustment conditions. Therefore once the necessary adjustments have been made, the dryer must be operated in a heating cycle to verify that the pressure is correct. If it is not correct, you must discontinue the power to the unit and make further adjustments. Repeat these steps as many times as necessary to achieve the correct burner pressure. Once the adjustment of the valve is complete, the vent cap must be replaced and sealed with, for example, paint to prevent maladjustment by the user.

22 American Dryer Corp. 113401-18

If the gas pressure needs to be adjusted, refer to “Gas Pressure Adjustment” on page 22.

Once test is complete, turn gas cock to “OFF” position. Remove manometer. Tighten screw inside the pressure tap or install plug.

Turn gas cock to “ON” position and check for leaks with soap solution with main burner “ON.”

Edge #1 for vent cap Edge #2 for adjustment screw

Warning (CE Dryers)

This appliance must only be

operated with the gas type indicated on the dryer’s data plate. If the appliance is converted (gas type changed), a data plate amendment must be obtained from American Dryer Corporation.

Conversions done improperly can result in a fire or explosion!

Gas Pressure Testing ______

For proper operation, the gas pressure must be correct, consistent and maintained at the gas pressure rates shown on page 19. Provisions are made at the gas valve for taking gas pressure readings.

There are two types of devices used to measure gas pressure. They are the spring/ mechanical type gauge and the manometer. The use of the spring/mechanical type gauge is not recommended because they are very easily damaged and are not always accurate. The preferred type of gauge is the manometer because it is a simple device to use and is highly accurate. A manometer is simply a glass or transparent plastic tube with a scale graduated in inches or millibars. When it is filled with water and pressure is applied, the water in the tube rises, showing the exact gas pressure.

Steam Information _______________________________

It is your responsibility to have all plumbing connections made by a qualified professional to ensure that the steam plumbing installation is adequate and conforms with local, state, and country regulations or codes.

Care must be exercised when leveling steam dryers into final position. After leveling the dryer, check the downward pitch of the heat exchanger from front to rear with a level. Likewise, check the downward pitch of the return condensate manifold toward its outlet part. Absence of these downward pitches will result in probable water hammer and premature heat exchanger fracture and leakage.

The presence of condensate in the steam will cause water hammer and subsequent heat exchanger failure. The steam supply connection must be taken from the top of a well-dripped steam main. If the supply run-out to the dryer exceeds 25 feet (7.6 meters), it should be dripped just before the control valve with a proper trap and dirt pocket.

Important

Failure to comply with the requirements stipulated in this manual

can result in component failure, which will void the warranty.

Steam Coil pH Level

The normal pH level for copper type steam coils must be maintained between a value of 8.5 to 9.5. For steel type steam coils the pH level must be maintained between a value of 9.5 to 10.5. These limits are set to limit the acid attack of the steam coils.

Important

Coil failure due to improper pH level will void the warranty.

Gas Pressure Test Procedure

Turn gas cock in gas supply line to “OFF” position.

50 Hz dryers: Back out miniature screw inside pressure tap and attach manometer (refer to the illustration on page 21).

60 Hz dryers: Install pressure tap and attach manometer (refer to the illustration on page

21). Turn gas cock to “ON” position. Start the dryer in Heat Mode and wait for

ignition. Gas manifold pressure should be as shown on page 19.

113401 -18 www.amdry.com 23

Steam Requirements – High Pressure

Inlet ---------- 1/2” N.P.T. supply line connection

1 at top manifold

Return ------- 1/2” N.P.T. return line connection

1 at bottom manifold

SL2020 Operatin g S team Pressure

Maximum 150 psig* Heat Input (Normal Load) 1.2

Consumption (Approximate) @ 125 psi (8.6 bar)

45 lb/hr

Bhp

20.41 kg/hr

1.0 MPa

Water pockets in the supply line, caused by low points, will provide wet steam to the coil possibly causing steam coil damage. All horizontal runs of steam supply piping should be pitched 1/4-inch (6.35 mm) for every 1 foot (0.31 meters) back towards the steam supply header causing the condensate in the line to drain to the header. Install a bypass trap in any low point to eliminate wet steam.

Important

Flexible hoses/couplings must be used. Coil

failure due to hard plumbing connections will void

the warranty .

SL3131 Operatin g S team Pressure

Maximum 150 psig* Heat Input (Normal Load) 1.75

Consumption (Approximate) @ 125 psi (8.6 bar)

Shaded areas are stated in metric equivalents * The minimum operating pressure for optimum results is 100 psig (689.47

kPa).

63 lb/hr

Installation Instructions

To ensure an adequate supply of steam is provided, be sure that the steam supply lines and steam return lines are sized and laid out as stipulated in this manual. Inadequate steam supply lines and steam return lines or improper steam plumbing will result in poor performance and can cause component failure. Clean, dry steam must be provided to the dryer.

Important

Steam coil failure due to water hammer by wet

steam will void the warranty.

The presence of condensate in the steam supply line will cause water hammer and subsequent heat exchanger (steam coil) failure. The steam supply connection into the main supply line must be made with a minimum 10-inch (25.4 cm) riser. This will prevent any condensate from draining towards the dryer.

The steam supply line to the dryer must include a 12-inch (30.48 cm) riser along with a drip trap and check valve. This will prevent any condensate from entering the steam coil.

Flexible hoses or couplings must be used. The dryer vibrates slightly when it runs and this will cause the steam coil connections to crack if they are hard piped to the supply and return mains.

Shutoff valves for each dryer should be installed in the supply line, return line, and drip trap return line. This will allow the dryer to be isolated from the supply main and the return main if the dryer needs maintenance work.

Install an inverted bucket steam trap and check valve at least 12-inches (30.48 cm) below the steam coil as close to the coil as possible. A trap with a minimum capacity of 100 lb (45.35 kg) of condensate per hour at 125 psi (8.62 bar) is needed for each unit. (Based on 2 times the steam consumption per hour.)

The supply line and the return line should be insulated. This will save energy and provide for the safety of the operator and maintenance personnel.

1.0 MPa

Bhp

28.58 kg/hr

Water Information _____________________

Before Y ou Start Check Local Codes and Permits

Call your local water company or the proper municipal authority for information regarding local codes.

Important

It is your responsibility to have all plumbing

connections made by a qualified professional to ensure that the plumbing installation is adequate and conforms to local, state, and federal regulations or codes.

It is the installer’s or owner’s responsibility to see that the required water pressure, pipe size, or connections are provided. The manufacturer assumes no responsibility if the fire suppression system is not connected, installed, or maintained properly.

Installation Water Supply

The fire suppression system must be supplied with a minimum water pipe size of 1/2-inch (12.7 mm) and be provided with 40 psi +/- 20 psi (2.75 bar +/- 1.37 bar) of pressure.

If the rear area of the dryer or the water supply is located in an area where it will be exposed to cold/freezing temperatures, provisions must be made to protect these water lines from freezing.

Warning

If the water in the supply line or water solenoid

valve freezes, the fire suppression system will be inoperative!!

Water Connections

The water connection is made to the 3/4”-11.5 NH hose adaptor, which is shipped in the tumbler and must be inst alled to the 1/2” N.P.T. water connection, located at the upper rear of the dryer. A flexible supply line/coupling must be used in an effort to avoid damaging the electric water solenoid valve.

Note

The 3/4”-11.5 NH is a standard hose coupling

screw thread. It is not to be confused with 3/4” N.P.T. The sealing of an NH connection is made with a washer opposed to the mating threads of an N.P.T. assembly. The 2 thread designs are not compatible.

It is recommended that a filter or strainer be installed in the water supply line.

24 American Dryer Corp. 113401-18

Important

Flexible supply line/coupling must be used.

Solenoid valve failure due to hard plumbing

connections will void warranty. The dryer is to be connected to the water mains using a

new hose set and the old hose set should not be reused.

Optional Manual Bypass

Provisions are made in the dryer’s fire suppression system for the installation of an optional manual bypass. The connections for the manual bypass are made at the “cross” or “four way” fitting located in the outlet supply side of the water solenoid valve. The manual ball cock shutoff valve must be located outside of the dryer at a distance from the dryer where it is easily accessible. The use and connection of this manual bypass is at the option or discretion of the owner.

The water connection for the manual bypass is made to the “cross” or “four way” fitting, which has a 3/8” F.N.P.T. and a coupling must be used to provide the minimum 1/2-inch (12.7 mm) supply (feed) line.

Preoperational Test ___________________

All dryers are thoroughly tested and inspected before leaving the factory. However, a preoperational test should be performed before the dryer is publicly used. It is possible that adjustments have changed in transit or due to marginal location (installation) conditions.

Turn on electric power to the dryer. Refer to the Operating Instructions for starting your particular

model dryer.

Gas Dryers

Open all shutoff valves. When a gas dryer is first started (during initial start-up), it has

a tendency not to ignite on the first ignition attempt. This is because the gas supply piping is filled with air, so it may take a few minutes for the air to be purged from the lines.

Note

During the purging period, check to be sure that

all gas shutoff valves are open.

Electrical Requirements

No independent external power source or supply connection is necessary. The 24-volt power to operate the fire suppression system is accomplished internally in the dryer (from the dryer controls).

Warning

Electrical power must be provided to the dryer at

all times. If the main electrical power supply to the dryer is disconnected, the fire suppression system is inoperative!!

Preparation for Operation/Start-Up ___

The following items should be checked before attempting to operate the dryer:

• Read all “CAUTION,” “WARNING,” and “DIRECTION” labels attached to the dryer.

• Check incoming supply voltage to be sure that it is the same as indicated on the data label. In the case of 208 VAC or 230/240 VAC, the supply voltage must match the electric service exactly.

• GAS MODELS – Check to ensure that the dryer is connected to the type of heat/gas indicated on the dryer data label.

• GAS MODELS – Be sure that all gas shutoff valves are in the open position.

• Be sure all back panels (guards) and electric box covers are in place.

• Be sure the service doors are closed and securely in place.

• Be sure the lint door/drawer is securely in place.

• Rotate the tumbler (drum) by hand to be sure it moves freely.

• Check bolts, nuts, screws, terminals, and fittings for tightness and security.

• Check that the vent is connected to the dryer and is exhausted to the outdoors.

• STEAM MODELS – Check to ensure all steam shutoff valves are open.

A gas pressure test should be taken at the gas valve pressure tap of each dryer to ensure that the water column pressure is correct and consistent.

Note

Water column pressure requirements (measured

at the pressure tap of the gas valve body) must be

verified.

Important

In most cases there is no regulator provided in an

L.P. dryer. The water column pressure must be regulated at the source (L.P. tank), or an external regulator must be added to each dryer.

Electrical Dryers

Check to ensure that electric oven/contactor assembly is activating.

Safety Related Circuits

Make a complete operational check of all safety related circuits:

• Door Switch(es)

• Hi-Limit Thermostats

• Sail Switch

Make a complete operational check of all operating controls.

Tumbler Coa ting

The tumbler is treated with a protective coating. We suggest dampening old garments or cloth material with a solution of water and nonflammable mild detergent and tumbling them in the tumbler to remove this coating.

Microprocessor Programs/Selections

Each microprocessor controller (computer) has been preprogrammed by the factory with the most commonly used parameter (program) selections. If computer program changes are required, refer to the computer programming manual, which was shipped with the dryer.

113401 -18 www.amdry.com 25

Preoperational Instructions __________

Important

For more detailed information regarding the

microprocessor controller (computer), refer to the

microprocessor user’s manual included with the dryer.

Coin Models

Microprocessor Controller (Computer)

When the microprocessor controller (computer) is in the ready state, the L.C.D. screen will display “Ready, Insert $XX.XX (amount) to Start”.

Insert coin(s). Once the correct “Amount to Start” has been inserted, the L.C.D. will display “Select Temperature”.

Select temperature by pressing “HI,” “MED,” or “LO.” The cycle will start and the L.C.D. will display the Dry Cycle selected and the remaining time.

The dryer will continue through the drying and cooling cycles, until the vended time has expired.

Note

To stop the dryer, open main door. Continuation of

the cycle will resume only after the door has been closed and any one of the 3 temperature selections is pressed.

Non-Coin Models

Microprocessor Controller (Computer)

The L.E.D. display reads “READY” (no cycle in progress). Press the letter on the keypad corresponding to the cycle

desired (e.g. key “D”). The dryer will then start (i.e. blower, tumbler, and heat). The L.E.D. display will read MANUAL DRYING CYCLE D,

___MIN REMAIN.

Shutdown Instructions ________________

If the dryer is to be shutdown (taken out of service) for a period of time, the following must be performed:

Discontinue power to the dryer either at the external disconnect switch or the circuit breaker.

Discontinue the heat supply: Gas Models – Discontinue the gas supply. Shut off external gas supply shutoff valve. Shut off internal gas supply shutoff valve located in the gas

valve burner area. Steam Models – Discontinue the steam supply. Shut off external (location furnished) shutoff valves.

NOTES ____________________________________

Note

The dryer can be stopped at any time by pressing

the “STOP/CLEAR” key, at this time the dryer will go into a cycle pause. If the “STOP/CLEAR” key is pressed again at this point, the cycle that was in progress will be cancelled and returned to the “READY” state.

When the programmed drying time has expired, the non-coin microprocessor controller (computer) will proceed into the Cool Down Cycle.

Once the Cool Down Cycle begins at the end of the heat cycle, the L.E.D. display will read COOL DOWN TEMP __/__ MINUTES remaining. At the end of the heat cycle, the dryer will shut off the heat and continue the fan and tumbler until the Cool Down Time or temperature is reached.

26 American Dryer Corp. 113401-18

Ser vice/Parts Information ____________

Service

Service must be performed by a qualified trained technician. If service is required, contact the reseller from whom the equipment was purchased. If the reseller cannot be contacted or is unknown, contact the Service Department for a reseller in your area.

Note

When contacting the Service Department, be sure

to give them the correct model number and serial number so that your inquiry is handled in an expeditious manner.

Parts

Replacement parts should be purchased from the reseller from whom the equipment was purchased. If the reseller cannot be contacted or is unknown, contact the Parts Department for a reseller in your area. Parts may also be purchased directly from the factory by calling the Parts Department at +1 (508) 678-9000 or you may FAX in your order at +1 (508) 678-9447.

Note

When ordering replacement parts from the reseller

or the manufacturer, be sure to give them the correct model number and serial number so that your parts order can be processed in an expeditious manner.

Warranty Infor mation _________________

Returning Warranty Cards

Before any dryer leaves the factory test area, a warranty card is placed on the inside of the main door glass. These warranty cards are intended to serve the customer where we record the individual installation date and warranty information to better serve you should you file a warranty claim.

If a warranty card did not come with your dryer, contact the Warranty Department or the Service Department at +1 (508) 678-9000.

Important

A separate warranty card must be completed and

returned for each individual dryer.

Note

Be sure to include the installation date when

returning the warranty card(s).

Warranty

For a copy of the commercial warranty covering your particular dryer(s), contact the reseller from whom you purchased the equipment and request a dryer warranty form. If the reseller cannot be contacted or is unknown, warranty information can be obtained from the factory by contacting the Warranty Department at +1 (508) 678-9000.

Note

Whenever contacting the factory for warranty

information, be sure to have the dryer’s model number and serial number available so that your inquiry can be handled in an expeditious manner.

Returning Warranty Parts

All dryer or parts warranty claims or inquiries should be addressed to the Warranty Parts Department. To expedite processing, the following procedures must be followed:

No parts are to be returned without prior written authorization R.M.A. from the factory .

Note

An R.M.A. is valid for only 30 days from date of

issue.

The R.M.A. issued by the factory, as well as any other correspondence pertaining to the returned part(s), must be included inside the package with the failed merchandise.

Each part must be tagged with the following information: Model number and serial number of the dryer from which

part was removed. Nature of failure (be specific). Date of dryer installation. Date of part failure. Specify whether the part(s) being returned is for a credit,

replacement, or a refund.

Note

If a part is marked for a credit or a refund, the

invoice number covering the purchase of the

replacement part must be provided. Warranty tags (Part No. 450064) are available at “no

charge” from ADC upon request.

The company returning the part(s) must clearly note the complete company name and address on the outside of the package.

All returns must be properly packaged to ensure that they are not damaged in transit. Damage claims are the responsibility of the shipper.

Important

No replacements, credits, or refunds will be issued

for merchandise damaged in transit.

All returns should be shipped to the factory in such a manner that they are insured and a proof of delivery can be obtained by the sender.

Shipping charges are not the responsibility of ADC. All returns should be “prepaid” to the factory . Any “C.O.D.” or “COLLECT” returns will not be accepted.

Important

No replacements, credits, or refunds will be issued

if the claim cannot be processed due to insufficient information. The party filing the claim will be notified in writing, either by “FAX” or “CERTIFIED MAIL – Return Receipt Requested,” as to the information necessary to process claim. If a reply is not received by the Warranty Department within 30 days from the FAX/letter date, then no replacements, credits, or refunds will be issued, and the merchandise will be discarded.

113401 -18 www.amdry.com 27

Routine Maintenance _________________

Cleaning

A program and/or schedule should be established for periodic inspection, cleaning, and removal of lint from various areas of the dryer, as well as throughout the ductwork system. The frequency of cleaning can best be determined from experience at each location. Maximum operating efficiency is dependent upon proper airflow. The accumulation of lint can restrict this airflow. If the guidelines in this section are met, the dryer will provide many years of efficient, trouble free, and most importantly, safe operation.

Warning

When cleaning steam coil fins, be careful not to

bend the fins. If fins are bent, straighten by using a fin comb, which is available from local air-conditioning supply houses.

90 Days

Remove lint from gas valve burner area with a dusting brush or vacuum cleaner attachment.

Clean any lint accumulation in and around the motor(s) casing opening.

Warning

Lint from most fabrics is highly combustible. The

accumulation of lint can create a potential fire hazard. Keep dryer area clear and free from combustible materials, gasoline, and other flammable vapors and liquids.

Note

Suggested time intervals shown are for average

usage, which is considered 6 to 8 operational

(running) hours per day.

Important

Dryer produces combustible lint and must be

exhausted to the outdoors. Every 6 months,

inspect the exhaust ducting and remove any lint buildup.

Suggested Cleaning Schedule Every Third or Fourth Load

Clean the lint screen every third or fourth load. A clogged lint screen will cause poor dryer performance. The lint door/ drawer is located just below the loading door of the dryer. Open the lint door/drawer, brush the lint off the lint screen, and remove the lint. Inspect lint screen and replace if torn.

Note

To remove the lint drawer from the dryer, pull

drawer out approximately halfway. Press the lint

door/drawer stop downward and pull the drawer out.

Important

The frequency of cleaning the lint screen can best

be determined from experience at each location.

Weekly

Clean lint accumulation from lint chamber, thermostat, and microprocessor temperature sensor area.

Note

To prevent damage, avoid cleaning and/or

touching ignitor/flame-probe assembly.

Every 6 Months

Inspect and remove lint accumulation in customer furnished exhaust ductwork system and from dryer’s internal exhaust ducting.

Note

The accumulation of lint in the exhaust ductwork

can create a potential fire hazard.

Do not obstruct the flow of combustion and ventilation air. Check back draft dampers in the exhaust ductwork. Inspect and remove any lint accumulation, which can cause the damper to bind or stick.

A back draft damper that is sticking partially closed can result in slow drying and shutdown of heat circuit safety switches or thermostats.

When cleaning the dryer cabinet(s), avoid using harsh abrasives. A product intended for the cleaning of appliances is recommended.

Adjustments 7 Days After Installation

and Every 12 Months Thereafter

Inspect bolts, nuts, screws, setscrews, grounding connections and nonpermanent gas connections (unions, shutoff valves, and orifices). Belts should be examined. Cracked or seriously frayed belts should be replaced. Complete an operational check of controls and valves. Complete an operational check of all safety devices (lint door/ drawer switch, door switches, sail switch, and hi-limit thermostats).

Warning

To avoid the hazard of electrical shock,

discontinue electrical supply to the dryer.

Steam Dryers

Clean the steam coil fins. It is suggested that compressed air and a vacuum cleaner with brush attachment be used.

28 American Dryer Corp. 113401-18

Data Label Information _____________________________________________________________

Standard Label

CE Label

AGA Label

When contacting ADC, the information on the data label is required to ensure proper service/parts assistance. The data label is located at the upper left rear of the dryer behind the back guard.

1. Model Number – This describes the style of dryer and type of heat (gas, electric, or steam).

2. Serial Number – Allows the manufacturer to gather information on your particular dryer.

3. Type of Heat – This describes the type of heat for your particular dryer , gas (either natural gas or L.P . gas), electric, or steam.

4. Heat Input (For Gas Dryers) – This describes the heat input in British thermal units per hour (Btu/hr) or kilowatts (kW).

5. Orifice Size (For Gas Dryers) – Gives the number drill size used.

6. Electric Service – This describes the voltage and current rating for a particular model.

7. Gas Manifold Pressure (For Gas Dryers) – This describes the manifold pressure taken at the gas valve tap.

113401 -18 www.amdry.com 29

ADC Part No. 113401 18 - 07/11/0 8 - 10

American Dryer SL3131, SL2020, SL2929 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Service

Parts

Returning Warranty Cards

Warranty

Returning Warranty Parts

Cleaning
