Rev. 7/15
ELS GO 8BT
Professional Powered Two-Way
Loudspeaker
ELS GO 8BT Contents
CUSTOMER SUPPORT..........................................................................................................................2
UNPACKING.............................................................................................................................2
HANDLING PRECAUTIONS...................................................................................................................3
FEATURES...........................................................................................................................................5
PRODUCT REGISTRATION....................................................................................................................5
REAR PANEL CONTROLS.....................................................................................................................6
REMOTE CONTROL..............................................................................................................................9
BATTERY CHARGING............................................................................................................................9
MOUNTING......................................................................................................................................11
AVAILABLE ACCESSORIES.................................................................................................................11
WARRANTY.......................................................................................................................................13
SPECIFICATIONS.................................................................................................................................14
ELS GO 8BT Introduction
Introduction: Congratulations and thank you for purchasing the American Audio® ELS GO 8BT pro-
fessional sound reinforcement loudspeaker. This loudspeaker is a representation of American Audio’s
continuing commitment to produce the best and highest quality audio products possible at an aordable price. The ELS GO 8BT is a lightweight, battery powered 8-inch active speaker. Its extremely high
eciency design, low power consumption, and plenty of output power is ideal for small and mid-size
events. The ELS GO 8BT is multifunctional. Users can also utilize the microphone input and built-in
MP3/Bluetooth player with USB and SD Card inputs. The speaker includes a poll mount slot and
rubber feet on the bottom of the unit for portable applications and also includes rigging points on the
top, bottom, and rear of the unit for permanent and ight installations. Please read and understand
this manual completely before attempting to operate your new speaker system. This booklet contains
important information concerning the proper and safe operation of your new speaker.
Customer Support: American Audio® provides a toll free customer support line, to provide set up help
and answer any question should you encounter problems during your initial set up or operation. You
may also visit us on the web at www.americandj.com for any comments or suggestions. Service Hours
are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
Caution! There are no user serviceable parts inside this speaker. Do not attempt any repairs, without
being instructed to do so by an authorized American Audio technician. Doing so will void your manufactures warranty. In the unlikely event your speaker may require service, please contact American Audio®.
ELS GO 8BT Unpacking
Every ELS GO 8BT has been thoroughly tested and has been shipped in perfect operating condition.
Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged carefully inspect your units for any damage and be sure all accessories
necessary to operate the system have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for further instructions. Please do not
return the speaker to your dealer without rst contacting customer support.
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 2
ELS GO 8BT Handling Precautions
ELECTRICAL PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
THERE ARE N O USER SERVICEABLE PARTS
INSIDE REFER SERVICE TO YOUR AUTHORIZED
AMERICAN AUDIO
®
SERVICE TECHNICIAN.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
READ INSTRUCTIONS — All the safety and operating
instructions should be read before the product is
operated.
RETAIN INSTRUCTIONS — The safety and operating
instructions should be retained for future reference.
HEED WARNINGS — All warnings on the product and
in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS — All operating and use
instructions should be followed.
CLEANING — The product should be cleaned only with
a polishing cloth or a soft dry cloth. Never clean with
furniture wax, benzine, insecticides or other volatile
liquids since they may corrode the cabinet.
ATTACHMENTS — Do not use a ttachments not
recommended by the product manufacturer as they
may cause hazards.
WATER AND MOISTURE — Do not use this product
near water — for example, near a bathtub, wash
bowl, kitchen sink, or laundry tub; in a wet basement;
or near a swimming pool; and the like.
ACCESSORIES — Do not place this product on an
unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only
with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
CART — A product and cart combination should be
moved with care. Quick stops, excessive force, and
uneven surfaces may cause the product and cart
combination to overturn.
VENTILATION — Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, and these openings must not be
blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug,
or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
POWER SOURCES — This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company.
LOCATION – The appliance should be installed in a
stable location.
NONUSE PERIODS – The power cord of the appliance
be unplugged from the outlet when left un-
should
used for a long period of time.
GROUNDING OR POLARIZATION
• If this product is equipped with a polarized alternating
current line plug (a plug having one blade wider than
the other), it will fit into the outlet only one way. This
is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
• If this product i s equipped with a three-wire
grounding type plug, a plug having a third (grounding)
pin, it will only fit into a grounding type power outlet.
This is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the grounding type plug.
POWER-CORD PROTECTION - Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords at
plugs, convenience receptacles, and the point where
they exit from the product.
OUTDOOR ANTENNA GROUNDING — If an outside
antenna or cable system is connected to the product,
be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges
and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information
with regard to proper grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection t o grounding electrodes, and
requirements for the grounding electrode. See Figure
A.
LIGHTNING — For added protection for this product
during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product
due to lightning and power-line surges.
POWER LINES — An outside antenna system should
not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installing an outside antenna system, extreme care
should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
OVERLOADING — Do not overload wall outlets,
extension cords, or
as this can result in a risk of fire or electric shock.
integral convenience receptacles
ELECTRIC
SERVICE
EQUIPMENT
Fig. A
OBJECT AND LIQUID ENTRY - Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
SERVICING — Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE - Unplug this product
from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
•When the power-supply cord or plug is damaged.
• If liquid has been spilled, or objects have fallen into
the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its
normal operation.
• If the product has been dropped or damaged in any
way.
•When the product exhibits a distinct change in
performance — this indicates a need for service.
REPLACEMENT PARTS -- When replacement parts
are required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, or other hazards.
SAFETY CHECK - Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks to determine that the product
is in proper operating condition.
WALL OR CEILING MOUNTING — The product should
not be mounted to a wall or ceiling.
HEAT — The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce
heat.
ANTENNA
LEAD IN
WIRE
GROUND
CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC — NATIONAL ELECTRICAL CODE
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 3
ELS GO 8BT Safety Precautions
ELS GO 8BT loudspeaker can easily reproduce sound pressure levels (SPL) sucient enough to cause
sever and permanent hearing damage. A great degree of care should be taken to protect your ears to
prolong exposure to SPL in excess of 85dB.
• For adult use only - Keep out of the reach of children.
• Be sure all power is turned o before making speaker connections
• When using the speaker make sure the grille is always attached.
• Always use a power cord that meets the manufactures exact power specications
• Disconnect from main power before making any type of connection
• To reduce the risk of electrical shock or re, do not expose this unit rain or moisture
• This speaker is intended for indoor use only, use of this product outdoors voids all warranties.
• Always mount this speaker in safe and stable matter.
• Power Cord Protection - Power supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where they exit from the speaker.
• Heat -The speaker should be situated away from heat sources such as radiators, heat registers,
stoves, or other mixers (including amplifiers) that produce heat
• Be sure to save the packing carton in the event the unit needs to be returned for service
• Read all documentation before attempting to operate your new mixer. Please save all your docu-
mentation for future reference
• Do not spill water or other liquids in to or on to your speaker
• Be sure that the local power outlet matches that of the required voltage for your speaker.
• Do not attempt to operate this speaker if the power cord has been frayed or broken. Please route
your power cord out of the way of foot trac
• Always have the gain controls set to their lowest level during initial power-up to prevent
speaker damage
• Servicing - The user should not attempt to service the speaker beyond that described in this
manual. All other servicing should be referred to qualified service personnel. The speaker should
only be serviced by qualified personal when;
A. Objects have fallen, or liquid has been spilled into the speaker
B. The speaker has been exposed to rain or water
C. The speaker does not appear to operate normally or exhibits a change in performance
D. The terminal/cross-over plate has been damaged
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 4
ELS GO 8BT Main Features
ELS GO 8BT Speaker:
• XLR/TRS Mic Input
• RCA Line Inputs
• TRS Line Output
• Bluetooth Connectivity
• SD Card & USB Inputs
• Battery Power
ELS GO 8BT File Formats
The chart located to the right, displays the proper
le extensions that can be used with USB/USB
Stick drives.
• Master Volume Control
• Treble & Bass EQ +/-15dB
• Built-In Pole Mount Socket
ELS GO 8BT Registration
The ELS GO 8BT carry a one year (365 days) limited warranty. Please fill out the enclosed warranty
card to validate your purchase. All returned service items whether under warranty or not, must be
freight pre-paid and accompany a return authorization (R.A.) number. The R.A. number must be
clearly written on the outside of the return package. A brief description of the problem as well as the
R.A. number must also be written down on a piece of paper and included in the shipping container.
If the unit is under warranty, you must provide a copy of your proof of purchase invoice. You may
obtain a R.A. number by contacting customer support at (800) 322-6337. All packages returned to
the service department not displaying a R.A. number on the outside of the shipping package will be
returned to the shipper unopened.
The serial and model number for this unit is located on the rear panel Please write down the numbers here and retain them for future reference.
Model No.________________________________ Date Purchased___________________________
Serial No.________________________________ Dealer Name______________________________
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 5
ELS GO 8BT Rear Panel Controls and Features
Rear of ELS GO 8BT
1
26
22
19
15
27
25
24
23
21
20
18
17
16
14
PAUSE
PLAY
NEXT
VOL+
POWER
IR
CH1
MIC
0 0 0 010 10 10 10
LEVEL LEVEL LEVEL LEVEL
CH1
PEAK
POWER
RED :CHARGING
GREEN :CHARGED
CH2
INST
CH2
CH3/4
CH3 ~ 6
DC IN
12V6A
PREV
PRT
VOL-
EQ MODE
CH5/6
STEREO OUT MP3
ECHO
ECHO
STOP
MODE
POWER
0
15 15
BASS
AC 110~240V
EQUALIZER
EQUALIZER
MP3LINK
0 10
LEVEL
15 15
TREBLE
2
3
4
5
6
7
0
8
9
10
11
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 6
1213
ELS GO 8BT Rear Panel Controls and Features
Rear Panel:
1. LCD - This screen will display all relevant information about the functions being selected or the
Mp3 le being played.
2. REPEAT/EQ BUTTON - Press this button once to activate repeat, which will repeat the cur-
rently playing song until stop is pressed. Press and hold this button to activate EQ mode, which
let select among the dierent types equalization that can be applied the song currently playing.
3. USB/SD/BLUETOOTH BUTTON - Press this button once to select the USB & SD drive. Press
this button again to select Bluetooth.
4. STOP/POWER BUTTON - Press this button once to stop the Mp3 player. Press and hold this
button to turn the Mp3 player on/o.
5. STEREO INPUT - 3.5mm input jack for use with personal music players.
6. 1/4” OUTPUT - This output jack is used to link to another speaker.
7. MP3 PLAYER VOLUME CONTROL - This knob is used to regulate output volume of a con-
nected personal music player connected to the Stereo Input jack (5). Turning the knob in a
clockwise direction will increase the volume level.
8. TREBLE CONTROL – This knob is used to adjust the amount treble applied to the output sig-
nal. The maximum amount of treble gain is +15dB and the maximum amount of treble decrease
is -15dB. Turning the knob in a counter-clockwise direction will decrease the amount of treble
applied to a channel signal, turning the knob in a clockwise direction will increase the amount
of treble applied to a channel signal.
9. BASS CONTROL – This knob is used to adjust the amount bass applied to the output signal.
The maximum amount of bass gain is +15dB and the maximum amount of bass decrease is
-15dB. Turning the knob in a counter-clockwise direction will decrease the amount of bass applied to a channel signal, turning the knob in a clockwise direction will increase the amount of
bass applied to a channel signal.
10. MAIN POWER INLET & FUSE HOLDER – This connector is used to supply main power to the
unit via the included detachable power cord. The power connection uses an I.E.C. type con-
nector, use only the supplied polarized AC power cord. Use only a power cord that matches
this type of connection. Be sure to only connect this unit to a power outlet that matches the
printed power label on the unit. Never use a power when the ground prong has been removed
or broken o. The ground prong is used to reduce the risk of electrical shock in case of an
electrical short. This cord is designed to t in one direction only. Do not attempt to force a
cord if it does not t, be sure the cord is being inserted properly.
FUSE HOLDER – This housing stores the 5 amp GMA protective fuse for 100V and a 3.15
amp GMA for 230V. Always replace with the exact same type fuse, unless otherwise instructed, by an authorized American Audio® service technician. Replacing with any other type of
fuse than that of the recommended fuse will void your unit warranty.
11. ECHO LEVEL - This knob is used to regulate the Echo output.
12. MAIN POWER SWITCH – This is the main power ON/OFF button. Before main power is
applied, be sure you have made all connections to the speaker. Remember to avoid damaging
pops to the speakers, the mixer is turned on rst and turned o last.
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 7
ELS GO 8BT Rear Panel Controls and Features
13. DC POWER INPUT - Connect the a standard DC power adapter here. (Not Included)
14. CHARGING & BATTERY STATUS LEDS - The red LED will glow when the unit is being charged.
The green LEDs will indicate the charge level and how much battery charge remains.
15. POWER LED - This LED indicates that the speaker is on.
15. PEAK LED - If this LED is lit it means that your signal is clipping. To stop the signal from clip-
ping lower the volume to the point where the LED is blinking along with the bass beat.
17. RCA LINE/STEREO INPUT VOLUME – This knob is used to regulate the output volume of
the line level source connected to the Line Level Input Jack (20).
18. MIC VOLUME - This knob is used to regulate the microphone output volume. Turning the knob
in a clockwise direction will increase the volume level.
19. INSTRUMENT INPUT VOLUME - This knob is used to regulate the volume of the source con-
nected to the instrument input (20). Turning the knob in a clockwise direction will increase the
volume level.
20. BALANCED RCA/LINE LEVEL INPUT – This connection is designed to accept a balanced line
input signal from a mixer or other line level device with a balanced output jack. Use a balanced
cable when the signal cable length exceeds 15 feet, this will reduce excessive signal loss. Be
sure to connect only line level input devices such as mixers and tape machines to this jack.
21. MIC XLR/1/4” INPUT – This jack will accept a XLR or 1/4” plug. The volume output level for
this microphone will be controlled by the MIC Volume knob (16).
22. INSTRUMENT INPUT - 1/4” input jack used to connect an instrument.
23. NEXT/VOL + BUTTON - Press this button once to go to the next song. Press and hold this
button to increase the volume of the Mp3 Player.
24. USB INPUT - Plug in any USB memory stick with Mp3 les to be played.
25. PAUSE/PLAY BUTTON - Press this button once to play your chosen song, press this button
again to momentarily interrupt playing. Press and hold this button to pause the playing song.
26. PREVIOUS/VOL - BUTTON - Press this button once to go to the previous song. Press and
hold this button to decrease the volume of the Mp3 Player.
27. SD INPUT - This slot is used to insert a SD, non-violatile memory card with Mp3 les to be
read.
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 8
ELS GO 8BT Remote Control
This remote features all of the selectable functions, so that you can easily operate your speaker at a distance of up to 3 meters from your audio installation.
1. POWER
2. USB/SD/BLUETOOTH MODE
3. FORWARD SCAN
4. VOLUME +
5. NEXT
6. PLAY/PAUSE BUTTON
7. VOLUME -
8. EQ SELECT
9. TRACK NUMBERS
10. RANDOM
12
10
11
SCAN-
RAN
SCAN+
SEARCH
1
2
3
4
5
6
7
8
11. PREVIOUS
12. REVERSE SCAN
9
ELS GO 8BT Battery Charging
Battery Status:
The Battery LED indicators (14) located on rear of unit will display the charge status of the battery.
The battery life under normal conditions will last 6 hours. Continue to check the battery status on the
rear of the unit to keep track of the battery life. Please do not let the battery fully die, this severly
shortens the life of the battery.
Battery Recharge: To recharge the battery, plug the supplied I.E.C. power supply into the input on
the rear of the unit and plug the other end into a matching power supply. It takes about 4.5 hours to
reach full charge.
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 9
ELS GO 8BT Speaker Set-Up & Looping
ELS GO 8BT Output Set-Up and Looping
PAUSE
NEXT
IR
PLAY
VOL+
CH3/4
PEAK
POWER
CH2
INST
CH2
CH3 ~ 6
DC IN
12V6A
POWER
CH1
MIC
0 0 0 010 10 10 10
LEVEL LEVEL LEVEL LEVEL
CH1
RED :CHARGING
GREEN :CHARGED
RCA-RCA Line Level Cable
PREV
PRT
STOP
MODE
VOL-
EQ MODE
CH5/6
STEREO OUT MP3
ECHO
ECHO
POWER
EQUALIZER
0
15 15
BASS
EQUALIZER
AC 110~240V
0 10
15 15
TREBLE
MP3LINK
LEVEL
PAUSE
NEXT
PREV
PRT
IR
PLAY
VOL+
VOL-
CH3/4
CH2
CH1
1/4” TRS-RCA Line
0
Level Cable
MIC
0 0 0 010 10 10 10
LEVEL LEVEL LEVEL LEVEL
CH1
RED :CHARGING
GREEN :CHARGED
PEAK
POWER
INST
CH2
CH3 ~ 6
DC IN
12V6A
CH5/6
STEREO OUT MP3
ECHO
ECHO
POWER
MODE
EQ MODE
STOP
POWER
EQUALIZER
0
15 15
BASS
EQUALIZER
AC 110~240V
MP3LINK
0 10
LEVEL
0
15 15
TREBLE
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 10
ELS GO 8BT Mounting Options
Pole Mounting – The ELS GO 8BT also include a pole mount option.
The pole mount socket located on the bottom of the speaker may be
used to secure the speaker to a speaker tri-pod, such as the American
Audio® SPS-1B as illustrated on the left. Always be sure to follow the
guidelines listed below when pole mounting your speaker;
• Always be sure the stand is designed to support the weight of
the speaker
• In outdoor situations that are prone to windy conditions and
strong wind gust, be sure to use sandbags as additional tri-pod
support, this will greatly reduce the risk of tipping
• Do not stack speakers on top of each other when mounting on
a tri-pod. Only one speaker should be mounted to a tri-pod at one
time.
• Always position the tri-pod legs away from foot traffic
• Extend the tri-pod legs to their fully extended position to avoid
accidental tipping
• Observe and follow all safety guidelines and regulations specified
by the tri-pod’s manufacturer
• Be sure the tri-pod is situated on a flat, level, and stable surface
• Always tighten all tri-pod locks.
ELS GO 8BT Available Accessories
SPS-1B - Speaker Stands - American Audio® carries the SPS-1B speak-
er stand, which can be used to raise the speakers during use The SPS-1B
is a sturdy aluminum tri-pod and includes a mounting socket bracket for
added security. The SPS-1B can raise the speaker to a maximum height
of six feet and has a maximum weight capacity of 80 pounds. SPS-1B;
weight = 6lbs, pipe diameter - 1 3/8”
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 11
ELS GO 8BT Warranty
1-YEAR LIMITED WARRANTY
A. American Audio® hereby warrants, to the original purchaser, American Audio® products to be
free of manufacturing defects in material and workmanship for a period of 1 Year (365 days) from
the date of purchase. This warranty shall be valid only if the product is purchased within the
United States of America, including possessions and territories. It is the owner’s responsibility to
establish the date and place of purchase by acceptable evidence, at the time service is sought.
B. For warranty service, send the product only to the American Audio® factory. All shipping charges
must be pre-paid. If the requested repairs or service (including parts replacement) are within the
terms of this warranty, American Audio® will pay return shipping charges only to a designated
point within the United States. If the entire instrument is sent, it must be shipped in its original
package. No accessories should be shipped with the product. If any accessories are shipped
with the product, American Audio® shall have no liability whatsoever for loss of or damage to
any such accessories, nor for the safe return thereof.
C. This warranty is void if the serial number has been altered or removed; if the product is modied
in any manner which American Audio® concludes, after inspection, aects the reliability of the
product; if the product has been repaired or serviced by anyone other than the American Audio®
factory unless prior written authorization was issued to purchaser by American Audio®; if the
product is damaged because not properly maintained as set forth in the instruction manual.
D. This is not a service contract, and this warranty does not include maintenance, cleaning or peri-
odic check-up. During the period specied above, American Audio® will replace defective parts
at its expense, and will absorb all expenses for warranty service and repair labor by reason of
defects in material or workmanship. The sole responsibility of American Audio® under this war ranty shall be limited to the repair of the product, or replacement thereof, including parts, at the
sole discretion of American Audio®. All products covered by this warranty were manufactured
after January 1, 1990, and bear identifying marks to that eect.
E. American Audio® reserves the right to make changes in design and/or improvements upon its
products without any obligation to include these changes in any products theretofore manufac tured.
F. No warranty, whether expressed or implied, is given or made with respect to any accessory sup plied with products described above. Except to the extent prohibited by applicable law, all
implied warranties made by American Audio® in connection with this product, including warran-
ties of merchantability or tness, are limited in duration to the warranty period set forth above.
And no warranties, whether expressed or implied, including warranties of merchantability or
tness, shall apply to this product after said period has expired. The consumer’s and or Dealer’s
sole remedy shall be such repair or replacement as is expressly provided above; and under no
circumstances shall American Audio® be liable for any loss or damage, direct or consequential,
arising out of the use of, or inability to use, this product.
G. This warranty is the only written warranty applicable to American Audio® Products and super sedes all prior warranties and written descriptions of warranty terms and conditions heretofore
published.
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 12
ELS GO 8BT Notes
©American Audio® - www.AmericanAudio.us - ELS GO 8BT - Instruction Manual Page 13
ELS GO 8BT Technical Specifications
Model: American Audio® ELS GO 8BT - Professional Powered Sound
Reinforcement Loud Speaker
Dimensions: 12.5” (W) x 12.25” (D) x 18” (H) / 320mm x 310mm x 455mm
Weight: 17 Lbs. / 8 kgs
Battery Life: 6 Hours
Battery Charge Time: 4.5 Hours
Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)
Operational humidity: 25 to 85% RH (non-condensation)
Storage temperature: -20 to 60˚C (4 to 140˚F)
Frequency Response: 50Hz - 20KHz
Nominal Dispersion: LF: 8” (185mm) Non-press paper cone with cloth suspension,
1” (25.5mm) KSV coil, 20OZ magnet
Amplifier Section:
Power supply: AC 115v-230v, 50/60Hz
Power consumption:
Accessories: I.E.C. Power Cord
Input Sensitivity:
MIC: 3mV
Instrument: 20mV
Line: 300mV
Output Sensitvity: 92dB(1m/1w)
Max. SPL: 110dB
Input Impedance:
MIC: Balanced 4.4K OHM Unbalanced 2.2K OHM
Instrument: 470K OHM
Line: 10K OHM
Crossover:
Low Pass: 20KHz
Low Cut: 60Hz
S/N Ratio: Line 100dB, Mic 80dB
Channel Equalizer:
Bass: Shelving Filter +20dB +3dB at 1KHz
Treble: Shelving Filter +20dB +3dB at 1KHz
NOTE:
The specifications are subject to change to any improvement by negotiations in advance. The parts are subject to change to any
improvement within the range of the specifications.
All Rights Reserved. All content, trademarks and logos are copyright by their respective owners. The Bluetooth® word mark and
logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is under license.
©American Audio® World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-3322 Fax: 323-725-6100
Web: www.AmericanAudio.us E-mail: info@americanaudio.us
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@americandj.eu / www.americandj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Loading...
