PolyKlean
™
Synthetic Air Filter Medias
Choose from three medias to meet
a variety of application requirements:
• Lightweight
• Easy to handle
• Available in pre-cut pad sizes
• Also full length slit width rolls
• Fully incinerable
• Excellent arrestance
• Not affected by moisture
• Non-toxic, non-allergenic
• High dust holding capacity
• Tough, durable, resilient 100%
polyester fibers
Applications
PolyKlean™filter medias are made from tough polyester fibers
bonded with a fire retardant resin to form a variety of high loft
medias structured for performance, economy, and long service life.
Protect HVAC Coils and Ducts
PolyKlean medias are widely used in commercial HVAC systems
and in unitary equipment including unit ventilators, fan coil units,
and packaged terminal air conditioners to protect the heat transfer
surfaces and ductwork from accumulating a build up of dust and dirt.
Extend Final Filter Life
Prefilters reduce operating costs by extending the life of higher
efficiency final filters. PolyKlean filter medias remove the larger,
heavier particles that would quickly plug up high efficiency
extended surface filters.
High Loft Fiber Structure Maximizes
Filter Surface Area
PolyKlean medias are formed into a high loft mat with an extremely
large amount of fiber surface area and a complex maze of fiber
intersections. The intricate fiber structure holds more dirt with
less resistance.
Engineered for IAQ Using Antimicrobial
PolyKlean Gold filters with antimicrobial are engineered to improve
Indoor Air Quality (IAQ). The antimicrobial acts as a preservative to
ensure the integrity of the media throughout the useful life of the filter,
and inhibits the growth of microorganisms documented to affect IAQ.
Save with PolyKlean
™
Media and AmerFrame
®
Holding Frames
PolyKlean filter media pads
are designed for installation
in permanent metal frames.
Substantial cost savings can
be achieved by using pads and
frames compared to disposable
panel filters. The cost of the
frames is quickly recovered
after only a few changeouts.
Better Air is Our Business
®
AmerFrame®filter media frames are
available in 1" and 2" thickness for
installations into standard 2" universal
holding frames. They are built rugged
for years of dependable service.
Page 2
PolyKlean
™
(1) All performance data is based on the ASHRAE 52.1-1992 test method. Performance tolerances conform to
Section 7.4 of ARI Standard 850-93.
Performance Data
(1)
Rated Intial
(1)
Rated average Recommended
Media Resistance (in. w.g.) Arrestance (%) Final Resistance
Type 300 FPM 500 FPM 625 FPM 300 FPM 500 FPM (in. w.g.)
PolyKlean Gold with Antimicrobial (Pressure Sensitive Dry Tack Adhesive on Air Leaving Side)
1" .19 .32 .49 90-95 80-85 1.0
2" .20 .44 .60 90-95 80-85 1.0
PolyKlean Blue (Pressure Sensitive Dry Tack Adhesive on Air Leaving Side)
1
⁄2 " .14 .28 N/R 85-90 70-75 .5
1" .19 .32 .49 90-95 80-85 1.0
2" .20 .44 .60 90-95 80-85 1.0
PolyKlean White (Dry)
1
⁄2 " .16 .30 N/R 80-85 65-70 .5
1" .20 .32 .43 90-95 75-80 1.0
2" .24 .45 .60 90-95 80-85 1.0
PolyKlean™Blue
Commercial grade media
for medium to heavy dirt
loading conditions.
Better Performance
•1⁄2 ", 1", and 2" thickness, blue
tint on the air leaving side
• Blended dual denier fiber
construction (1" and 2")
• Pressure sensitive dry tack
adhesive on air leaving side
Synthetic PolyKlean™Gold
Commercial grade media for
medium to heavy dirt loading
conditions. Manufactured
with antimicrobial.
Best Performance
• Antimicrobial preserves
the media
• 1" and 2" thickness, gold tint
on the air leaving side
• Blended dual denier
fiber construction
• Pressure sensitive dry tack
adhesive on air leaving side
PolyKlean™White
Standard grade media
for light to medium dirt
loading conditions.
Good Performance
•1⁄2 ", 1", and 2" thickness,
solid white in color
• Blended dual denier fiber
construction (1" and 2")
• PolyKlean White is dry —
no adhesive
Temperature Limits
Storage Temperature:
-40˚F to 220˚F
-40˚C to 104˚C
Max. Continuous
Operating Temperature:
175˚F/79˚C
Underwriters Laboratories, Inc.
Classification:
Class 2.
AAF has a policy of continuous product research and
improvement and reserves the right to change
design and specifications without notice.
